Search Results (26)

This article introduces an advanced theoretical approach, named the Trigonometric Kalman Filter (TKF), to enhance measurement accuracy for multi-head rotational encoders. Leveraging the processing capabilities of a Field-Programmable Gate Array (FPGA), the proposed TKF algorithm uses trigonometric functions and sophisticated signal fusion techniques to provide highly accurate real-time angle estimation with rapid response. The inclusion of the Coordinate Rotation Digital Computer (CORDIC) algorithm enables swift and efficient computation of trigonometric values, facilitating precise tracking of angular position and rotational speed. This approach represents a notable advancement in control systems, where high accuracy and minimal latency are essential for optimal performance. The paper addresses key challenges in angle measurement, particularly the signal fusion inaccuracies that often impede precision in high-demand applications. Implementing the TKF with an FPGA-based pure fixed-point method not only enhances computational efficiency but also significantly reduces latency when compared to conventional software-based solutions. This FPGA-based implementation is particularly advantageous in real-time applications where processing speed and accuracy are critical, and it demonstrates the effective integration of hardware acceleration in improving measurement fidelity. To validate the effectiveness of this approach, the TKF was rigorously tested on a precision drive control system, configured for a direct PMSM drive in an astronomical telescope mount equipped with a standard $0.5$m telescope frequently used by astronomers. This real-world application highlights the TKF’s ability to meet the stringent positioning and measurement accuracy requirements characteristic of astronomical observation, a field where minute angular adjustments are critical. The FPGA-based design enables high-frequency updates, essential for managing the minor, precise adjustments required for telescope control. The study includes a comprehensive computational analysis and experimental testing on an Altera Stratix FPGA board, presenting a detailed comparison of the TKF’s performance with other known methods, including fusion techniques such as differential methods, $\alpha$–$\beta$ filters, and related Kalman filtering applied to one sensors. The study demonstrates that the four-head fusion configuration of the TKF outperforms traditional methods in terms of measurement accuracy and responsiveness. Full article

This paper presents a low-latency coordinate rotation digital computer (CORDIC) algorithm to accelerate the computation of arctangent functions, and it describes the corresponding iterative and pipelined architecture of this novel algorithm. As compared to the existing methods based on CORDIC, the proposed method can effectively reduce the number of iterations by dedicated pre-rotation and comparison processes. Moreover, the proposed CORDIC algorithm supports all vectors with arbitrary angles while maintaining convergence. By error analysis, the proposed algorithm can achieve the same accuracy as the conventional CORDIC algorithm during floating-point arctangent function computation and reduce the number of iterations by approximately 50%. This paper presents two new architectures—the iterative architecture, which can be more resource efficient, and the pipelined architecture, which can achieve a throughput rate of one datum per clock. Finally, the experimental comparison results indicate that the proposed method outperforms extant methods as it exhibits low latency, requires fewer resources to compute the arctangent function for floating-point inputs, and necessitates no digital signal processing (DSP) and memory for fixed-point inputs. Full article

Within the realm of digital signal processing and communication systems, FPGA-based CORDIC (Coordinate Rotation Digital Computer) processors play pivotal roles, applied in trigonometric calculations and vector operations. However, soft errors have become one of the major threats in high-reliability FPGA-based applications, potentially degrading performance and causing system failures. This paper proposes a fault classification and diagnosis method for FPGA-based CORDIC processors, leveraging Fast Fourier Transform (FFT) and Convolutional Neural Networks (CNNs). The approach involves constructing fault classification datasets, optimizing features extraction through FFT to shorten the time of diagnosis and improve the diagnostic accuracy, and employing CNNs for training and testing of faults diagnosis. Different CNN architectures are tested to explore and construct the optimal fault classifier. Experimental results encompassing simulation and implementation demonstrate the improved accuracy and efficiency in fault classification and diagnosis. The proposed method provides fault prediction with an accuracy of more than 98.6% and holds the potential to enhance the reliability and performance of FPGA-based CORDIC circuit systems, surpassing traditional fault diagnosis methods such as Sum of Square (SoS). Full article

With the rapid development of technologies like artificial intelligence, high-performance computing chips are playing an increasingly vital role. The inverse hyperbolic sine and inverse hyperbolic cosine functions are of utmost importance in fields such as image blur and robot joint control. Therefore, there is an urgent need for research into high-precision, high-performance hardware Intellectual Property (IP) for arcsinh and arccosh functions. To address this issue, this paper introduces a novel 128-bit low-latency floating-point hardware IP for arcsinh and arccosh functions, employing an enhanced Coordinate Rotation Digital Computer (CORDIC) algorithm, achieving a computation precision of 113 bits in just 32 computation cycles. This significantly enhances computational efficiency while reducing hardware implementation latency. The results indicate that, when compared to Python standard results, the calculated error of the proposed hardware IP does not exceed $8\times {10}^{-34}$. Furthermore, this paper synthesizes the completed IP using the TSMC 65 nm process, with a total IP area of 2.1056 mm${}^2$. Operating at a frequency of 300 MHz, its power is 22.4 mW. Finally, hardware implementation and resource analysis are conducted and compared on an Field Programmable Gate Array (FPGA). The results show that the improved algorithm trades a slight area increase for lower latency and higher accuracy. The designed hardware IP is expected to provide a more accurate and efficient computational tool for applications like image processing, thereby advancing technological development. Full article

With the continuous development of satellite payload and system-on-chip (SoC) technology, spaceborne real-time synthetic aperture radar (SAR) imaging systems play a crucial role in various defense and civilian domains, including Earth remote sensing, military reconnaissance, disaster mitigation, and resource exploration. However, designing high-performance and high-reliability SAR imaging systems that operate in harsh environmental conditions while adhering to strict size, weight, and power consumption constraints remains a significant challenge. In this paper, we introduce a spaceborne SAR imaging chip based on a SoC architecture with system fault-tolerant technology. The fault-tolerant SAR SoC architecture has a CPU, interface subsystem, memory subsystem, data transit subsystem, and data processing subsystem. The data processing subsystem, which includes fast Fourier transform (FFT) modules, coordinated rotation digital computer (CORDIC) modules (for phase factor calculation), and complex multiplication modules, is the most critical component and can achieve various modes of SAR imaging. Through analyzing the computational requirements of various modes of SAR, we found that FFT accounted for over 50% of the total computational workload in SAR imaging processing, while the CORDIC modules for phase factor generation accounted for around 30%. Therefore, ensuring the fault tolerance of these two modules is crucial. To address this issue, we propose a word-length optimization redundancy (WLOR) method to make the fixed-point pipelined FFT processors in FFT modules fault tolerant. Additionally, we propose a fault-tolerant pipeline CORDIC architecture utilizing error correction code (ECC) and sum of squares (SOS) check. For other parts of the SoC architecture, we propose a generic partial triple modular redundancy (TMR) hardening method based on the HITS algorithm to improve fault tolerance. Finally, we developed a fully automated FPGA-based fault injection platform to test the design’s effectiveness by injecting errors at arbitrary locations. The simulation results demonstrate that the proposed methods significantly improved the chip’s fault tolerance, making the SAR imaging chip safer and more reliable. We also implemented a prototype measurement system with a chip-included board and demonstrated the proposed design’s performance on the Chinese Gaofen-3 strip-map continuous imaging system. The chip requires 9.2 s, 50.6 s, and 7.4 s for a strip-map with 16,384 × 16,384 granularity, multi-channel strip-map with 65,536 × 8192 granularity, and multi-channel scan mode with 32,768 × 4096 granularity, respectively, and the system hardware consumes 6.9 W of power to process the SAR raw data. Full article

In the field of digital signal processing, such as in navigation and radar, a significant number of high-precision arctangent function calculations are required. Lookup tables, polynomial approximation, and single/double-precision floating-point Coordinate Rotation Digital Computer (CORDIC) algorithms are insufficient to meet the demands of practical applications, where both high precision and low latency are essential. In this paper, based on the concept of trading area for speed, a four-step parallel branch iteration CORDIC algorithm is proposed. Using this improved algorithm, a 128-bit quad-precision floating-point arctangent function is designed, and the hardware circuit implementation of the arctangent algorithm is realized. The results demonstrate that the improved algorithm can achieve 128-bit floating-point arctangent calculations in just 32 cycles, with a maximum error not exceeding $2\times {10}^{-34}$ rad. It possesses exceptionally high computational accuracy and efficiency. Furthermore, the hardware area of the arithmetic unit is approximately 0.6317 mm${}^2$, and the power consumption is about 40.6483 mW under the TSMC 65 nm process at a working frequency of 500 MHz. This design can be well suited for dedicated CORDIC processor chip applications. The research presented in this paper holds significant value for high-precision and rapid arctangent function calculations in radar, navigation, meteorology, and other fields. Full article

The radial artery reflects the largest amount of physiological and pathological information about the human body. However, ultrasound signal processing involves a large number of complex functions, and traditional digital signal processing can hardly meet the requirements of real-time processing of ultrasound data. The research aims to improve computational accuracy and reduce the hardware complexity of ultrasound signal processing systems. Firstly, this paper proposes to apply the coordinate rotation digital computer (CORDIC) algorithm to the whole radial artery ultrasound signal processing, combines the signal processing characteristics of each sub-module, and designs the dynamic filtering module based on the radix-4 CORDIC algorithm, the quadrature demodulation module based on the partitioned-hybrid CORDIC algorithm, and the dynamic range transformation module based on the improved scale-free CORDIC algorithm. A digital radial artery ultrasound imaging system was then built to verify the accuracy of the three sub-modules. The simulation results show that the use of the high-performance CORDIC algorithm can improve the accuracy of data processing. This provides a new idea for the real-time processing of ultrasound signals. Finally, radial artery ultrasound data were collected from 20 volunteers using different probe scanning modes at three reference positions. The vessel diameter measurements were averaged to verify the reliability of the CORDIC algorithm for radial artery ultrasound imaging, which has practical application value for computer-aided clinical diagnosis. Full article

This paper presents a new recursive trigonometric (RT) technique for Field-Programmable Gate Array (FPGA) design implementation. The traditional implementation of trigonometric functions on FPGAs requires a significant amount of data storage space to store numerous reference values in the lookup tables. Although the coordinate rotation digital computer (CORDIC) can reduce the required FPGA storage space, their implementation process can be very complex and time-consuming. The proposed RT technique aims to provide a new approach for generating trigonometric functions to improve communication accuracy and reduce response time in the FPGA. This new RT technique is based on the trigonometric transformation; the output is calculated directly from the input values, so its accuracy depends only on the accuracy of the inputs. The RT technique can prevent complex iterative calculations and reduce the computational errors caused by the scale factor K in the CORDIC. Its effectiveness in generating highly accurate cosine waveform is verified by simulation tests undertaken on an FPGA. Full article

Timing-mismatch errors among channels in time-interleaved analog-to-digital converters (TIADCs) greatly degrade the whole performance of the system. Therefore, techniques for calibrating timing mismatch are indispensable, and a new fully-digital calibration technique is presented in this article. Based on a Hilbert filter, modified moving averagers (MMAs) and inverse cosine functions, the proposed estimation algorithm is fast (within 1200 sample points) and accurate. Meanwhile, the coordinate rotational digital computer (CORDIC) algorithm, which is used to implement inverse cosine functions, is also improved, giving it higher precision. In addition, a compensation method based on second-order Taylor series approximation with less hardware resource consumption is provided. Through analyses and simulations, this calibration technique proved to be suitable for TIADCs with an arbitrary number of channels, in which the signal-to-noise and distortion ratio (SNDR) and the spurious-free dynamic range (SFDR) were, respectively, improved from 24.06 dB and 24.57 dB to 67.96 dB and 85.69 dB. Full article

The work in this paper extends a memristive chaotic system with transcendental nonlinearities to the fractional-order domain. The extended system’s chaotic properties were validated through bifurcation analysis and spectral entropy. The presented system was employed in the substitution stage of an image encryption algorithm, including a generalized Arnold map for the permutation. The encryption scheme demonstrated its efficiency through statistical tests, key sensitivity analysis and resistance to brute force and differential attacks. The fractional-order memristive system includes a reconfigurable coordinate rotation digital computer (CORDIC) and Grünwald–Letnikov (GL) architectures, which are essential for trigonometric and hyperbolic functions and fractional-order operator implementations, respectively. The proposed system was implemented on the Artix-7 FPGA board, achieving a throughput of 0.396 Gbit/s. Full article

This paper proposes an algorithm and hardware realization of generalized chaotic systems using fractional calculus and rotation algorithms. Enhanced chaotic properties, flexibility, and controllability are achieved using fractional orders, a multi-scroll grid, a dynamic rotation angle(s) in two- and three-dimensional space, and translational parameters. The rotated system is successfully utilized as a Pseudo-Random Number Generator (PRNG) in an image encryption scheme. It preserves the chaotic dynamics and exhibits continuous chaotic behavior for all values of the rotation angle. The Coordinate Rotation Digital Computer (CORDIC) algorithm is used to implement rotation and the Grünwald–Letnikov (GL) technique is used for solving the fractional-order system. CORDIC enables complete control and dynamic spatial rotation by providing real-time computation of the sine and cosine functions. The proposed hardware architectures are realized on a Field-Programmable Gate Array (FPGA) using the Xilinx ISE 14.7 on Artix 7 XC7A100T kit. The Intellectual-Property (IP)-core-based implementation generates sine and cosine functions with a one-clock-cycle latency and provides a generic framework for rotating any chaotic system given its system of differential equations. The achieved throughputs are $821.92$ Mbits/s and $520.768$ Mbits/s for two- and three-dimensional rotating chaotic systems, respectively. Because it is amenable to digital realization, the proposed spatially rotating translational fractional-order multi-scroll grid chaotic system can fit various secure communication and motion control applications. Full article

Recently, much research has focused on the design of biped robots with stable and smooth walking ability, identical to human beings, and thus, in the coming years, biped robots will accomplish rescue or exploration tasks in challenging environments. To achieve this goal, one of the important problems is to design a chip for real-time calculation of moving length and rotation angle of the biped robot. This paper presents an efficient and accurate coordinate rotation digital computer (CORDIC)-based efficient chip design to calculate the moving length and rotation angle for each step of the biped robot. In a previous work, the hardware cost of the accurate CORDIC-based algorithm of biped robots was primarily limited by the scale-factor architecture. To solve this problem, a binomial approximation was carefully employed for computing the scale-factor. In doing so, the CORDIC-based architecture can achieve similar accuracy but with fewer iterations, thus reducing hardware cost. Hence, incorporating CORDIC-based architecture with binomial approximation, pipelined architecture, and hardware sharing machines, this paper proposes a novel efficient and accurate CORDIC-based chip design by using an iterative pipelining architecture for biped robots. In this design, only low-complexity shift and add operators were used for realizing efficient hardware architecture and achieving the real-time computation of lengths and angles for biped robots. Compared with current designs, this work reduced hardware cost by 7.2%, decreased average errors by 94.5%, and improved average executing performance by 31.5%, when computing ten angles of biped robots. Full article

The use of RISC-based embedded processors aimed at low cost and low power is becoming an increasingly popular ecosystem for both hardware and software development. High-performance yet low-power embedded processors may be attained via the use of hardware acceleration and Instruction Set Architecture (ISA) extension. Recent publications of AI have demonstrated the use of Coordinate Rotation Digital Computer (CORDIC) as a dedicated low-power solution for solving nonlinear equations applied to Neural Networks (NN). This paper proposes ISA extension to support floating-point CORDIC, providing efficient hardware acceleration for mathematical functions. A new DMA-based ISA extension approach integrated with a pipeline CORDIC accelerator is proposed. The CORDIC ISA extension is directly interfaced with a standard processor data path, allowing efficient implementation of new trigonometric ALU-based custom instructions. The proposed DMA-based CORDIC accelerator can also be used to perform repeated array calculations, offering a significant speedup over software implementations. The proposed accelerator is evaluated on Intel Cyclone-IV FPGA as an extension to Nios processor. Experimental results show a significant speedup of over three orders of magnitude compared with software implementation, while applied to trigonometric arrays, and outperforms the existing commercial CORDIC hardware accelerator. Full article

This paper proposes a novel architecture for the computation of X^Y-like functions based on the QH CORDIC (Quadruple-Step-Ahead Hyperbolic Coordinate Rotation Digital Computer) methodology. The proposed architecture converts direct computing of function X^Y to logarithm, multiplication, and exponent operations. The QH CORDIC methodology is a parallel variant of the traditional CORDIC algorithm. Traditional CORDIC suffers from long latency and large area, while the QH CORDIC has much lower latency. The computation of functions lnx and e^x is accomplished with the QH CORDIC. To solve the problem of the limited range of convergence of the QH CORDIC, this paper employs two specific techniques to enlarge the range of convergence for functions lnx and e^x, making it possible to deal with high-precision floating-point inputs. Hardware modeling of function X^Y using the QH CORDIC is plotted in this paper. Under the TSMC 65 nm standard cell library, this paper designs and synthesizes a reference circuit. The ASIC implementation results show that the proposed architecture has 30 more orders of magnitude of maximum relative error and average relative error than the state-of-the-art. On top of that, the proposed architecture is also superior to the state-of-the-art in terms of latency, word length and energy efficiency (power × latency × period /efficient bits). Full article

Accelerometer-based motion sensing has been extensively applied to fall detection. However, such applications can only detect fall accidents; therefore, a system that can prevent fall accidents is desirable. Bed falls account for more than half of patient falls and are preceded by a clear warning indicator: the patient attempting to get out of bed. This study designed and implemented an Internet of Things module, namely, Bluetooth low-energy-enabled Accelerometer-based Sensing In a Chip-packaging (BASIC) module, with a tilt-sensing algorithm based on the patented low-complexity COordinate Rotation DIgital Computer (CORDIC)-based algorithm for tilt angle conversions. It is applied for detecting the postural changes (from lying down to sitting up) and to protect individuals at a high risk of bed falls by prompting caregivers to take preventive actions and assist individuals trying to get up. This module demonstrates how motion and tilt sensing can be applied to bed fall prevention. The module can be further miniaturized or integrated into a wearable device and commercialized in smart health-care applications for bed fall prevention in hospitals and homes. Full article
