Search Results (17)

To address the challenge of low modulation recognition accuracy for Low Probability of Intercept (LPI) radar waveforms under low Signal-to-Noise Ratio (SNR) conditions—a critical limitation in current radar signal processing research—this study proposes a novel recognition framework anchored in an improved EfficientNet model. First, to generate time–frequency images, the radar signals are initially subjected to time–frequency analysis using the Choi–Williams Distribution (CWD). Second, the Mobile Inverted Bottle-neck Convolution (MBConv) structure incorporates the Simple Attention Module (SimAM) to improve the network’s capacity to extract features from time–frequency images. Specifically, the original serial mechanism within the MBConv structure is replaced with a parallel convolution and attention approach, further optimizing feature extraction efficiency. Third, the network’s loss function is upgraded to Focal Loss. This modification aims to mitigate the issue of low recognition rates for specific radar signal types during training: by dynamically adjusting the loss weights of hard-to-recognize samples, it effectively improves the classification accuracy of challenging categories. Simulation experiments were conducted on 13 distinct types of LPI radar signals. The results demonstrate that the improved model validates the effectiveness of the proposed approach for LPI waveform modulation recognition, achieving an overall recognition accuracy of 96.48% on the test set. Full article

Radar signal recognition under low signal-to-noise ratio (SNR) conditions is a critical issue in modern electronic reconnaissance systems, which face significant challenges in recognition accuracy due to signal diversity. A novel method for radar signal detection based on the bagging support vector machine (SVM) is proposed in this paper.This method firstly utilizes the Choi–Williams distribution (CWD) and the smooth pseudo Wigner-Ville distribution (SPWVD) to obtain different time–frequency images of radar signals, which effectively leverages CWD’s strong time–frequency aggregation and SPWVD’s robust cross-interference resistance. Moreover, histograms of oriented gradient (HOG) features are extracted from time–frequency images to train multiple SVM classifiers by bootstrap sampling. Finally, the performance of each SVM classifier is aggregated using plurality voting to reduce the risk of model overfitting and improve recognition accuracy. We evaluate the effectiveness of the proposed method using 12 different types of radar signals. The experimental results demonstrate that its overall identification rate reaches around 79% at an SNR of −10 dB, and it improves the recognition rate by 5% compared with a single classifier. Full article

Low probability of intercept (LPI) radar signals are widely used in electronic countermeasures due to their low power and large bandwidth. However, they are susceptible to interference from noise, posing challenges for accurate identification. To address this issue, we propose an LPI radar signal recognition method based on feature enhancement with deep metric learning. Specifically, time-domain LPI signals are first transformed into time–frequency images via the Choi–Williams distribution. Then, we propose a feature enhancement network with attention-based dynamic feature extraction blocks to fully extract the fine-grained features in time–frequency images. Meanwhile, we introduce deep metric learning to reduce noise interference and enhance the time–frequency features. Finally, we construct an end-to-end classification network to achieve the signal recognition task. Experimental results demonstrate that our method obtains significantly higher recognition accuracy under a low signal-to-noise ratio compared with other baseline methods. When the signal-to-noise ratio is −10 dB, the successful recognition rate for twelve typical LPI signals reaches 94.38%. Full article

With the increasing complexity of radar jamming threats, accurate and automatic jamming recognition is essential but remains challenging. Conventional algorithms often suffer from sharply decreased recognition accuracy under low jamming-to-noise ratios (JNR).Artificial intelligence-based jamming signal recognition is currently the main research directions for this issue. This paper proposes a new radar jamming recognition framework called Diff-SwinT. Firstly, the time-frequency representations of jamming signals are generated using Choi-Williams distribution. Then, a diffusion model with U-Net backbone is trained by adding Gaussian noise in the forward process and reconstructing in the reverse process, obtaining an inverse diffusion model with denoising capability. Next, Swin Transformer extracts hierarchical multi-scale features from the denoised time-frequency plots, and the features are fed into linear layers for classification. Experiments show that compared to using Swin Transformer, the proposed framework improves overall accuracy by 15% to 10% at JNR from −16 dB to −8 dB, demonstrating the efficacy of diffusion-based denoising in enhancing model robustness. Compared to VGG-based and feature-fusion-based recognition methods, the proposed framework has over 27% overall accuracy advantage under JNR from −16 dB to −8 dB. This integrated approach significantly enhances intelligent radar jamming recognition capability in complex environments. Full article

The accuracy of low probability of intercept (LPI) radar waveform recognition is an important and challenging problem in electronic warfare. Aiming at the problem of the difficulty in feature extraction and the low recognition rates of the LPI radar signal under a low signal-to-noise ratio, and inspired by the symmetry theory, we propose a new approach for the LPI radar signal recognition method based on a dual-channel convolutional neural network (CNN) and feature fusion. Our new approach contains three main modules: the preprocessing module that converts the LPI radar waveforms into two-dimensional time-frequency images using the Choi–Williams distribution (CWD) transformation and performs image binarization, the feature extraction module that extracts different features obtained from the images, and the recognition module that utilizes a multi-layer perceptron (MLP) network to fuse these features and distinguish the type of LPI radar signals. In the feature extraction module, a two-channel CNN model is proposed that extracts Histogram of Oriented Gradients (HOG) features and deep features from time-frequency images, respectively. Finally, the recognition module recognizes the radar signals using a Softmax classifier based on the fused features from two channels. The experimental results from 12 types of LPI radar signals prove the superiority and robustness of the proposed model. Its overall recognition rate reaches 97% when the signal-to-noise ratio is −6 dB. Full article

This paper presents a novel approach that applies WiFi-based IQ data and time–frequency images to classify human activities automatically and accurately. The proposed strategy first uses the Choi–Williams distribution transform and the Margenau–Hill spectrogram transform to obtain the time–frequency images, followed by the offset and principal component analysis (PCA) feature extraction. The offset features were extracted from the IQ data and several spectra with maximum energy values in the time domain, and the PCA features were extracted via the whole images and several image slices on them with rich unit information. Finally, a traditional supervised learning classifier was used to label various activities. With twelve-thousand experimental samples from four categories of WiFi signals, the experimental data validated our proposed method. The results showed that our method was more robust to varying image slices or PCA numbers over the measured dataset. Our method with the random forest (RF) classifier surpassed the method with alternative classifiers on classification performance and finally obtained a 91.78% average sensitivity, 91.74% average precision, 91.73% average F1-score, 97.26% average specificity, and 95.89% average accuracy. Full article

Cardiovascular Disease (CVD) is a primary cause of heart problems such as angina and myocardial ischemia. The detection of the stage of CVD is vital for the prevention of medical complications related to the heart, as they can lead to heart muscle death (known as myocardial infarction). The electrocardiogram (ECG) reflects these cardiac condition changes as electrical signals. However, an accurate interpretation of these waveforms still calls for the expertise of an experienced cardiologist. Several algorithms have been developed to overcome issues in this area. In this study, a new scheme for myocardial ischemia detection with multi-lead long-interval ECG is proposed. This scheme involves an observation of the changes in ischemic-related ECG components (ST segment and PR segment) by way of the Choi-Williams time-frequency distribution to extract ST and PR features. These extracted features are mapped to a multi-class SVM classifier for training in the detection of unknown conditions to determine if they are normal or ischemic. The use of multi-lead ECG for classification and 1 min intervals instead of beats or frames contributes to improved detection performance. The classification process uses the data of 92 normal and 266 patients from four different databases. The proposed scheme delivered an overall result with 99.09% accuracy, 99.49% sensitivity, and 98.44% specificity. The high degree of classification accuracy for the different and unknown data sources used in this study reflects the flexibility, validity, and reliability of this proposed scheme. Additionally, this scheme can assist cardiologists in detecting signal abnormality with robustness and precision, and can even be used for home screening systems to provide rapid evaluation in emergency cases. Full article

A combination of spectral kurtosis (SK), based on Choi–Williams distribution (CWD) and hidden Markov models (HMM), accurately identifies initial gearbox failures and diagnoses fault types of gearboxes. First, using the LMD algorithm, five types of gearbox vibration signals are collected and decomposed into several product function (PF) components and the multicomponent signals are decomposed into single-component signals. Then, the kurtosis value of each component is calculated, and the component with the largest kurtosis value is selected for the CWD-SK analysis. According to the calculated CWD-SK value, the characteristics of the initial failure of the gearbox are extracted. This method not only avoids the difficulty of selecting the window function, but also provides original eigenvalues for fault feature classification. In the end, from the CWD-SK characteristic parameters at each characteristic frequency, the characteristic sequence based on CWD-SK is obtained with HMM training and diagnosis. The experimental results show that this method can effectively identify the initial fault characteristics of the gearbox, and also accurately classify the fault characteristics of different degrees. Full article

This paper focuses on the dynamic responses of a metro train–bridge system under train-braking. Experiments were performed on the elevated Metro Line 21 of Guangzhou (China). A continuous, three-span, rigid-frame bridge (42 m + 65 m + 42 m) and a standard B-type metro train were selected. The acceleration signals were measured at the center-points of the main span and one side-span, and the acceleration signals of the car body and the bogie frame were measured simultaneously. The train–bridge system’s vibration characteristics and any correlations with time and frequency were investigated. The Choi–Williams distribution method and wavelet coherence were introduced to analyze the obtained acceleration signals of the metro train–bridge system. The results showed that the Choi–Williams distribution provided a more explicit understanding of the time–frequency domain. The correlations between different parts of the bridge and the train–bridge system under braking conditions were revealed. The present study provides a series of measured dynamic responses of the metro train–bridge system under train-braking, which could be used as a reference in further investigations. Full article

Detecting pain based on analyzing electroencephalography (EEG) signals can enhance the ability of caregivers to characterize and manage clinical pain. However, the subjective nature of pain and the nonstationarity of EEG signals increase the difficulty of pain detection using EEG signals analysis. In this work, we present an EEG-based pain detection approach that analyzes the EEG signals using a quadratic time-frequency distribution, namely the Choi–Williams distribution (CWD). The use of the CWD enables construction of a time-frequency representation (TFR) of the EEG signals to characterize the time-varying spectral components of the EEG signals. The TFR of the EEG signals is analyzed to extract 12 time-frequency features for pain detection. These features are used to train a support vector machine classifier to distinguish between EEG signals that are associated with the no-pain and pain classes. To evaluate the performance of our proposed approach, we have recorded EEG signals for 24 healthy subjects under tonic cold pain stimulus. Moreover, we have developed two performance evaluation procedures—channel- and feature-based evaluation procedures—to study the effect of the utilized EEG channels and time-frequency features on the accuracy of pain detection. The experimental results show that our proposed approach achieved an average classification accuracy of 89.24% in distinguishing between the no-pain and pain classes. In addition, the classification performance achieved using our proposed approach outperforms the classification results reported in several existing EEG-based pain detection approaches. Full article

Low Probability of Intercept (LPI) radar waveform recognition is not only an important branch of the electronic reconnaissance field, but also an important means to obtain non-cooperative radar information. To solve the problems of LPI radar waveform recognition rate, difficult feature extraction and large number of samples needed, an automatic classification and recognition system based on Choi-Williams distribution (CWD) and depth convolution neural network migration learning is proposed in this paper. First, the system performs CWD time-frequency transform on the LPI radar waveform to obtain a 2-D time-frequency image. Then the system preprocesses the original time-frequency image. In addition, then the system sends the pre-processed image to the pre-training model (Inception-v3 or ResNet-152) of the deep convolution network for feature extraction. Finally, the extracted features are sent to a Support Vector Machine (SVM) classifier to realize offline training and online recognition of radar waveforms. The simulation results show that the overall recognition rate of the eight LPI radar signals (LFM, BPSK, Costas, Frank, and T1–T4) of the ResNet-152-SVM system reaches 97.8%, and the overall recognition rate of the Inception-v3-SVM system reaches 96.2% when the SNR is −2 dB. Full article

As the number of mobile users and video traffics grow explosively, the data rate demands increase tremendously. To improve the spectral efficiency, the spectrum are reused inter cell or intra cell, such as the ultra dense network with multi-cell or the cellular network with Device-to-Device communications, where the co-channel interferences are brought and needs to be suppressed. According to the time-frequency energy sensing to the communication signals, the desired signal and the interference signal have different energy concentration areas on the time frequency plane, which provide opportunities to suppress the co-channel interference with time varying filter. This paper analyzes the time-frequency distributions of the Gaussian pulse shaping signals, discusses the effect of the analyzing window length on the time-frequency resolution, exploits the equivalence between the time frequency analysis at the baseband and at the radio front end, and finally reveals the advantages of the proposed masking threshold constrained time varying filter based co-channel interference mitigation method. The pass region for the linear time varying filter is generated according to the time-varying energy characteristics of the I/Q separated 4-QAM pulse shaping signals, where the optimum masking threshold is obtained by the optimum-BER criterion. The proposed co-channel interference suppression method is evaluated in aspect of BER performance, and simulation results show that the proposed method outperforms existing methods with low-pass or band-pass filters. Full article

In this paper, a new approach for fault detection and location of open switch faults in the closed-loop inverter fed vector controlled drives of Electric Multiple Units is proposed. Spectral kurtosis (SK) based on Choi–Williams distribution (CWD) as a statistical tool can effectively indicate the presence of transients and locations in the frequency domain. Wavelet-packet energy Shannon entropy (WPESE) is appropriate for the transient changes detection of complex non-linear and non-stationary signals. Based on the analyses of currents in normal and fault conditions, SK based on CWD and WPESE are combined with the DC component method. SK based on CWD and WPESE are used for the fault detection, and the DC component method is used for the fault localization. This approach can diagnose the specific locations of faulty Insulated Gate Bipolar Transistors (IGBTs) with high accuracy, and it requires no additional devices. Experiments on the RT-LAB platform are carried out and the experimental results verify the feasibility and effectiveness of the diagnosis method. Full article

This paper presents an EEG-based brain-computer interface system for classifying eleven motor imagery (MI) tasks within the same hand. The proposed system utilizes the Choi-Williams time-frequency distribution (CWD) to construct a time-frequency representation (TFR) of the EEG signals. The constructed TFR is used to extract five categories of time-frequency features (TFFs). The TFFs are processed using a hierarchical classification model to identify the MI task encapsulated within the EEG signals. To evaluate the performance of the proposed approach, EEG data were recorded for eighteen intact subjects and four amputated subjects while imagining to perform each of the eleven hand MI tasks. Two performance evaluation analyses, namely channel- and TFF-based analyses, are conducted to identify the best subset of EEG channels and the TFFs category, respectively, that enable the highest classification accuracy between the MI tasks. In each evaluation analysis, the hierarchical classification model is trained using two training procedures, namely subject-dependent and subject-independent procedures. These two training procedures quantify the capability of the proposed approach to capture both intra- and inter-personal variations in the EEG signals for different MI tasks within the same hand. The results demonstrate the efficacy of the approach for classifying the MI tasks within the same hand. In particular, the classification accuracies obtained for the intact and amputated subjects are as high as $88.8\%$ and $90.2\%$ , respectively, for the subject-dependent training procedure, and $80.8\%$ and $87.8\%$ , respectively, for the subject-independent training procedure. These results suggest the feasibility of applying the proposed approach to control dexterous prosthetic hands, which can be of great benefit for individuals suffering from hand amputations. Full article

For passive radar detection system, radar waveform recognition is an important research area. In this paper, we explore an automatic radar waveform recognition system to detect, track and locate the low probability of intercept (LPI) radars. The system can classify (but not identify) 12 kinds of signals, including binary phase shift keying (BPSK) (barker codes modulated), linear frequency modulation (LFM), Costas codes, Frank code, P1-P4 codesand T1-T4 codeswith a low signal-to-noise ratio (SNR). It is one of the most extensive classification systems in the open articles. A hybrid classifier is proposed, which includes two relatively independent subsidiary networks, convolutional neural network (CNN) and Elman neural network (ENN). We determine the parameters of the architecture to make networks more effectively. Specifically, we focus on how the networks are designed, what the best set of features for classification is and what the best classified strategy is. Especially, we propose several key features for the classifier based on Choi–Williams time-frequency distribution (CWD). Finally, the recognition system is simulated by experimental data. The experiments show the overall successful recognition ratio of 94.5% at an SNR of −2 dB. Full article
