Bayer color filter array (CFA) images are captured by a single-chip image sensor covered with a Bayer CFA pattern which has been widely used in modern digital cameras. In the past two decades, many compression methods have been proposed to compress Bayer CFA images. These compression methods can be roughly divided into the compression-first-based (CF-based) scheme and the demosaicing-first-based (DF-based) scheme. However, in the literature, no review article for the two compression schemes and their compression performance is reported. In this article, the related CF-based and DF-based compression works are reviewed first. Then, the testing Bayer CFA images created from the Kodak, IMAX, screen content images, videos, and classical image datasets are compressed on the Joint Photographic Experts Group-2000 (JPEG-2000) and the newly released Versatile Video Coding (VVC) platform VTM-16.2. In terms of the commonly used objective quality, perceptual quality metrics, the perceptual effect, and the quality–bitrate tradeoff metric, the compression performance comparison of the CF-based compression methods, in particular the reversible color transform-based compression methods and the DF-based compression methods, is reported and discussed. Full article

We introduced a digital photo image analysis in color space to estimate the spectrum of fluor components dissolved in a liquid scintillator sample through the hue and wavelength relationship. Complementary metal oxide semiconductor (CMOS) image sensors with Bayer color filter array (CFA) technology in the digital camera were used to reconstruct and decode color images. Hue and wavelength are closely related. To date, no literature has reported the hue and wavelength relationship measurements, especially for blue or close to the UV region. The non-linear hue and wavelength relationship in the blue region was investigated using a light emitting diode source. We focused on this wavelength region, because the maximum quantum efficiency of the bi-alkali photomultiplier tube (PMT) is around 430 nm. It is necessary to have a good understanding of this wavelength region in PMT-based experiments. The CMOS Bayer CFA approach was sufficient to estimate the fluor emission spectrum in the liquid scintillator sample without using an expensive spectrophotometer. Full article

In this paper, we performed a feasibility study of using a water-based liquid scintillator (WbLS) for conducting imaging analysis with a digital camera. The liquid scintillator (LS) dissolves a scintillating fluor in an organic base solvent to emit light. We synthesized a liquid scintillator using water as a solvent. In a WbLS, a suitable surfactant is needed to mix water and oil together. As an application of the WbLS, we introduced a digital photo image analysis in color space. A demosaicing process to reconstruct and decode color is briefly described. We were able to estimate the emission spectrum of the fluor dissolved in the WbLS by analyzing the pixel information stored in the digital image. This technique provides the potential to estimate fluor components in the visible region without using an expensive spectrophotometer. In addition, sinogram analysis was performed with Radon transformation to reconstruct transverse images with longitudinal photo images of the WbLS sample. Full article

As the color filter array (CFA)2.0, the RGBW CFA pattern, in which each CFA pixel contains only one R, G, B, or W color value, provides more luminance information than the Bayer CFA pattern. Demosaicking RGBW CFA images $I^{RGBW}$ is necessary in order to provide high-quality RGB full-color images as the target images for human perception. In this letter, we propose a three-stage demosaicking method for $I^{RGBW}$ . In the first-stage, a cross shape-based color difference approach is proposed in order to interpolate the missing W color pixels in the W color plane of $I^{RGBW}$ . In the second stage, an iterative error compensation-based demosaicking process is proposed to improve the quality of the demosaiced RGB full-color image. In the third stage, taking the input image $I^{RGBW}$ as the ground truth RGBW CFA image, an $I^{RGBW}$ -based refinement process is proposed to refine the quality of the demosaiced image obtained by the second stage. Based on the testing RGBW images that were collected from the Kodak and IMAX datasets, the comprehensive experimental results illustrated that the proposed three-stage demosaicking method achieves substantial quality and perceptual effect improvement relative to the previous method by Hamilton and Compton and the two state-of-the-art methods, Kwan et al.’s pansharpening-based method, and Kwan and Chou’s deep learning-based method. Full article

Low lighting images usually contain Poisson noise, which is pixel amplitude-dependent. More panchromatic or white pixels in a color filter array (CFA) are believed to help the demosaicing performance in dark environments. In this paper, we first introduce a CFA pattern known as CFA 3.0 that has 75% white pixels, 12.5% green pixels, and 6.25% of red and blue pixels. We then present algorithms to demosaic this CFA, and demonstrate its performance for normal and low lighting images. In addition, a comparative study was performed to evaluate the demosaicing performance of three CFAs, namely the Bayer pattern (CFA 1.0), the Kodak CFA 2.0, and the proposed CFA 3.0. Using a clean Kodak dataset with 12 images, we emulated low lighting conditions by introducing Poisson noise into the clean images. In our experiments, normal and low lighting images were used. For the low lighting conditions, images with signal-to-noise (SNR) of 10 dBs and 20 dBs were studied. We observed that the demosaicing performance in low lighting conditions was improved when there are more white pixels. Moreover, denoising can further enhance the demosaicing performance for all CFAs. The most important finding is that CFA 3.0 performs better than CFA 1.0, but is slightly inferior to CFA 2.0, in low lighting images. Full article

A joint demosaicing and denoising task refers to the task of simultaneously reconstructing and denoising a color image from a patterned image obtained by a monochrome image sensor with a color filter array. Recently, inspired by the success of deep learning in many image processing tasks, there has been research to apply convolutional neural networks (CNNs) to the task of joint demosaicing and denoising. However, such CNNs need many training data to be trained, and work well only for patterned images which have the same amount of noise they have been trained on. In this paper, we propose a variational deep image prior network for joint demosaicing and denoising which can be trained on a single patterned image and works for patterned images with different levels of noise. We also propose a new RGB color filter array (CFA) which works better with the proposed network than the conventional Bayer CFA. Mathematical justifications of why the variational deep image prior network suits the task of joint demosaicing and denoising are also given, and experimental results verify the performance of the proposed method. Full article

It is commonly believed that having more white pixels in a color filter array (CFA) will help the demosaicing performance for images collected in low lighting conditions. However, to the best of our knowledge, a systematic study to demonstrate the above statement does not exist. We present a comparative study to systematically and thoroughly evaluate the performance of demosaicing for low lighting images using two CFAs: the standard Bayer pattern (aka CFA 1.0) and the Kodak CFA 2.0 (RGBW pattern with 50% white pixels). Using the clean Kodak dataset containing 12 images, we first emulated low lighting images by injecting Poisson noise at two signal-to-noise (SNR) levels: 10 dBs and 20 dBs. We then created CFA 1.0 and CFA 2.0 images for the noisy images. After that, we applied more than 15 conventional and deep learning based demosaicing algorithms to demosaic the CFA patterns. Using both objectives with five performance metrics and subjective visualization, we observe that having more white pixels indeed helps the demosaicing performance in low lighting conditions. This thorough comparative study is our first contribution. With denoising, we observed that the demosaicing performance of both CFAs has been improved by several dBs. This can be considered as our second contribution. Moreover, we noticed that denoising before demosaicing is more effective than denoising after demosaicing. Answering the question of where denoising should be applied is our third contribution. We also noticed that denoising plays a slightly more important role in 10 dBs signal-to-noise ratio (SNR) as compared to 20 dBs SNR. Some discussions on the following phenomena are also included: (1) why CFA 2.0 performed better than CFA 1.0; (2) why denoising was more effective before demosaicing than after demosaicing; and (3) why denoising helped more at low SNRs than at high SNRs. Full article

The demand for a high-resolution metal-oxide-semiconductor (CMOS) image sensor has increased in recent years, and pixel size has shrunk below 1.0 μm to allow accumulation of numerous pixels in a limited area. However, shrinking the pixel size lowers the sensitivity and increases crosstalk because the aspect ratio is worsened by maintaining the height of the pixel. This work introduces a high-sensitivity pixel with a quad-WRGB (White, Red, Green, Blue) color filter array (CFA), spatial deep-trench isolation (S-DTI), and a spatial tungsten grid (S-WG). The optical performance of the suggested pixel was analyzed by performing 3D optical simulations at 1.0, 0.9, and 0.8 μm pixel pitches as small-sized pixels. The quad-WRGB CFA is compared with the quad-Bayer CFA, and the S-DTI and S-WG are compared with the conventional DTI and WG. We confirmed an improvement in the sensitivity of the suggested pixel using the quad-WRGB CFA with S-DTI and S-WG to a maximum of 58.2%, 67.0%, and 66.3% for 1.0, 0.9, and 0.8 μm pixels, respectively. Full article

In this paper, we propose a weights-based image demosaicking algorithm which is based on the Bayer pattern color filter array (CFA). When reconstructing the missing G components, the proposed algorithm uses weights based on posteriori gradients to mitigate color artifacts and distortions. Furthermore, the proposed algorithm makes full use of the correlation of R–B channels in high frequency when interpolating R/B values at B/R positions. Experimental results show that the proposed algorithm is superior to previous similar algorithms in composite peak signal-to-noise ratio (CPSNR) and subjective visual effect. The biggest advantage of the proposed algorithm is the use of posteriori gradients and the correlation of R–B channels in high frequency. Full article

Existence of mobile devices with high performance cameras and powerful image processing applications eases the alteration of digital images for malicious purposes. This work presents a new approach to detect digital image tamper detection technique based on CFA artifacts arising from the differences in the distribution of acquired and interpolated pixels. The experimental evidence supports the capabilities of the proposed method for detecting a broad range of manipulations, e.g., copy-move, resizing, rotation, filtering and colorization. This technique exhibits tampered areas by computing the probability of each pixel of being interpolated and then applying the DCT on small blocks of the probability map. The value of the coefficient for the highest frequency on each block is used to decide whether the analyzed region has been tampered or not. The results shown here were obtained from tests made on a publicly available dataset of tampered images for forensic analysis. Affected zones are clearly highlighted if the method detects CFA inconsistencies. The analysis can be considered successful if the modified zone, or an important part of it, is accurately detected. By analizing a publicly available dataset with images modified with different methods we reach an 86% of accuracy, which provides a good result for a method that does not require previous training. Full article

Recently, several red-green-blue-white (RGBW) color filter arrays (CFAs), which include highly sensitive W pixels, have been proposed. However, RGBW CFA patterns suffer from spatial resolution degradation owing to the sensor composition having more color components than the Bayer CFA pattern. RGBW CFA demosaicing methods reconstruct resolution using the correlation between white (W) pixels and pixels of other colors, which does not improve the red-green-blue (RGB) channel sensitivity to the W channel level. In this paper, we thus propose a demosaiced image post-processing method to improve the RGBW CFA sensitivity and resolution. The proposed method decomposes texture components containing image noise and resolution information. The RGB channel sensitivity and resolution are improved through updating the W channel texture component with those of RGB channels. For this process, a cross multilateral filter (CMF) is proposed. It decomposes the smoothness component from the texture component using color difference information and distinguishes color components through that information. Moreover, it decomposes texture components, luminance noise, color noise, and color aliasing artifacts from the demosaiced images. Finally, by updating the texture of the RGB channels with the W channel texture components, the proposed algorithm improves the sensitivity and resolution. Results show that the proposed method is effective, while maintaining W pixel resolution characteristics and improving sensitivity from the signal-to-noise ratio value by approximately 4.5 dB. Full article

In this paper, we propose an effective directional Bayer color filter array (CFA) demosaicking algorithm based on residual interpolation (RI). The proposed directional interpolation algorithm aims to reduce computational complexity and get more accurate interpolated pixel values in the complex edge areas. We use the horizontal and vertical weights to combine and smooth color difference estimations. Compared with four directional weights in minimized Laplacian residual interpolation, the proposed algorithm not only guarantees the quality of color images but also reduces the computational complexity. Generally, the directional estimations may be inaccurately calculated because of the false edge information in irregular edges. We alleviate it by using a new method to calculate the directional color difference estimations. Experimental results show that the proposed algorithm provides outstanding performance compared with some previous algorithms, especially in the complex edge areas. In addition, it has lower computational complexity and better visual effect. Full article

Recently, several RGB-White (RGBW) color filter arrays (CFAs) have been proposed, which have extra white (W) pixels in the filter array that are highly sensitive. Due to the high sensitivity, the W pixels have better SNR (Signal to Noise Ratio) characteristics than other color pixels in the filter array, especially, in low light conditions. However, most of the RGBW CFAs are designed so that the acquired RGBW pattern image can be converted into the conventional Bayer pattern image, which is then again converted into the final color image by using conventional demosaicing methods, i.e., color interpolation techniques. In this paper, we propose a new RGBW color filter array based on a totally different color interpolation technique, the colorization algorithm. The colorization algorithm was initially proposed for colorizing a gray image into a color image using a small number of color seeds. Here, we adopt this algorithm as a color interpolation technique, so that the RGBW color filter array can be designed with a very large number of W pixels to make the most of the highly sensitive characteristics of the W channel. The resulting RGBW color filter array has a pattern with a large proportion of W pixels, while the small-numbered RGB pixels are randomly distributed over the array. The colorization algorithm makes it possible to reconstruct the colors from such a small number of RGB values. Due to the large proportion of W pixels, the reconstructed color image has a high SNR value, especially higher than those of conventional CFAs in low light condition. Experimental results show that many important information which are not perceived in color images reconstructed with conventional CFAs are perceived in the images reconstructed with the proposed method. Full article

In this paper, we propose a green (G)-channel restoration for a red–white–blue (RWB) color filter array (CFA) image sensor using the dual sampling technique. By using white (W) pixels instead of G pixels, the RWB CFA provides high-sensitivity imaging and an improved signal-to-noise ratio compared to the Bayer CFA. However, owing to this high sensitivity, the W pixel values become rapidly over-saturated before the red–blue (RB) pixel values reach the appropriate levels. Because the missing G color information included in the W channel cannot be restored with a saturated W, multiple captures with dual sampling are necessary to solve this early W-pixel saturation problem. Each W pixel has a different exposure time when compared to those of the R and B pixels, because the W pixels are double-exposed. Therefore, a RWB-to-RGB color conversion method is required in order to restore the G color information, using a double-exposed W channel. The proposed G-channel restoration algorithm restores G color information from the W channel by considering the energy difference caused by the different exposure times. Using the proposed method, the RGB full-color image can be obtained while maintaining the high-sensitivity characteristic of the W pixels. Full article
