Search Results (20)

Search Parameters:
Keywords = Barker codes

Order results
Result details
Results per page
Select all
Export citation of selected articles as:
16 pages, 2271 KiB
Article
Foucault–Barker Mask: Nonconventional Schlieren Technique
by Cristina M. Gómez-Sarabia and Jorge Ojeda-Castañeda
Optics 2025, 6(2), 23; https://doi.org/10.3390/opt6020023 - 4 Jun 2025
Viewed by 316
Abstract
We present a theoretical framework for designing optical masks, which are useful for implementing nonconventional Schlieren techniques. We revisit the use of effective transfer functions, which emphasize the role of symmetries in the design of coded masks. The proposed technique implements an optical [...] Read more.
We present a theoretical framework for designing optical masks, which are useful for implementing nonconventional Schlieren techniques. We revisit the use of effective transfer functions, which emphasize the role of symmetries in the design of coded masks. The proposed technique implements an optical autocorrelation of a mask, which is coded with the Barker sequences. For the same purpose, one can also use masks coded with the pseudorandom sequences. For the sake of completeness, we link our deterministic theoretical framework with a simple statistical model. The proposed technique may be useful for the automatic sensing of phase gradients. Full article
Show Figures

Figure 1

11 pages, 3395 KiB
Article
Defect Detection in Solid Timber Panels Using Air-Coupled Ultrasonic Imaging Techniques
by Xiaochuan Jiang, Jun Wang, Ying Zhang and Shenxue Jiang
Appl. Sci. 2024, 14(1), 434; https://doi.org/10.3390/app14010434 - 3 Jan 2024
Cited by 6 | Viewed by 1744
Abstract
This paper reports on investigations of the air-coupled ultrasonic (ACU) method to detect common defects in solid timber panels made of Chinese fir (Cunninghamia lanceolata (Lamb.) Hook.). The ACU technology is a non-contact method for nondestructive timber testing with quicker scanning rates [...] Read more.
This paper reports on investigations of the air-coupled ultrasonic (ACU) method to detect common defects in solid timber panels made of Chinese fir (Cunninghamia lanceolata (Lamb.) Hook.). The ACU technology is a non-contact method for nondestructive timber testing with quicker scanning rates compared to contact methods. A testbed was set up consisting of commercially available piezo-ceramic ACU transducers and in-house manufactured signal processing circuits. To demonstrate the suitability of the ACU technique, through-transmission measurement results are presented for samples with defects such as knots, wormholes, and cracks. Pulse compression methods (Barker-coded method) were used to improve the power of received signals based on cross-correction algorithms. Results showed defects of timber panels made of Chinese fir can be detected with a thickness of less than 40 mm. Defects larger than 3 mm in diameter could be detected with high precision. Applying the pulse compression method showed better results than using common sine signals as excitation signals since it increased the signal-to-noise ratio, which is especially important for air-coupled measurement of high-attenuation materials like timber materials. The measurement results on reference samples demonstrated that ACU technology is a promising method for timber defect detection, especially for the quality assessment of engineered wood products. Full article
Show Figures

Figure 1

21 pages, 7059 KiB
Article
Transcranial Ultrasonic Focusing by a Phased Array Based on Micro-CT Images
by Yuxin Yin, Shouguo Yan, Juan Huang and Bixing Zhang
Sensors 2023, 23(24), 9702; https://doi.org/10.3390/s23249702 - 8 Dec 2023
Cited by 3 | Viewed by 3223
Abstract
In this paper, we utilize micro-computed tomography (micro-CT) to obtain micro-CT images with a resolution of 60 μm and establish a micro-CT model based on the k-wave toolbox, which can visualize the microstructures in trabecular bone, including pores and bone layers. The transcranial [...] Read more.
In this paper, we utilize micro-computed tomography (micro-CT) to obtain micro-CT images with a resolution of 60 μm and establish a micro-CT model based on the k-wave toolbox, which can visualize the microstructures in trabecular bone, including pores and bone layers. The transcranial ultrasound phased array focusing field characteristics in the micro-CT model are investigated. The ultrasonic waves are multiply scattered in skull and time delays calculations from the transducer to the focusing point are difficult. For this reason, we adopt the pulse compression method and the linear frequency modulation Barker code to compute the time delay and implement phased array focusing in the micro-CT model. It is shown by the simulation results that ultrasonic loss is mainly caused by scattering from the microstructures of the trabecular bone. The ratio of main and side lobes of the cross-correlation calculation is improved by 5.53 dB using the pulse compression method. The focusing quality and the calculation accuracy of time delay are improved. Meanwhile, the beamwidth at the focal point and the sound pressure amplitude decrease with the increase in the signal frequency. Focusing at different depths indicates that the beamwidth broadens with the increase in the focusing depth, and beam deflection focusing maintains good consistency in the focusing effect at a distance of 9 mm from the focal point. This indicates that the phased-array method has good focusing results and focus tunability in deep cranial brain. In addition, the sound pressure at the focal point can be increased by 8.2% through amplitude regulation, thereby enhancing focusing efficiency. The preliminary experiment verification is conducted with an ex vivo skull. It is shown by the experimental results that the phased array focusing method using pulse compression to calculate the time delay can significantly improve the sound field focusing effect and is a very effective transcranial ultrasound focusing method. Full article
Show Figures

Figure 1

19 pages, 1919 KiB
Article
Modified Nested Barker Codes for Ultra-Wideband Signal–Code Constructions
by Vadim A. Nenashev, Aleksandr R. Bestugin, Alexey V. Rabin, Sergei V. Solenyi and Sergey A. Nenashev
Sensors 2023, 23(23), 9528; https://doi.org/10.3390/s23239528 - 30 Nov 2023
Cited by 2 | Viewed by 2058
Abstract
Currently, various applications of ultra-wideband signal–code constructions are among the most vibrant technologies, being implemented in very different fields. The purpose of this research consists of analyzing Barker codes and searching for the optimal nested representations of them. We also aim to synthesize [...] Read more.
Currently, various applications of ultra-wideband signal–code constructions are among the most vibrant technologies, being implemented in very different fields. The purpose of this research consists of analyzing Barker codes and searching for the optimal nested representations of them. We also aim to synthesize signal–code constructions based on the tenets of nesting of alternative modified Barker codes, which employ an asymmetric alphabet. The scientific merit of the paper is as follows: on the basis of new analytic expressions, modified nested codes and signal–code constructions were obtained, applicable for the establishment of the unambiguous association of the component values of the nested codes with any lobes of the normalized autocorrelation function. With these analytical expressions, we are, hence, able to determine the values of the binary asymmetrical components of the nested codes related to the side lobes of the normalized autocorrelation function. In this way, we clearly obtain better (low) levels for these lobes than by using the autocorrelation function, as established by the equivalent conventional Barker codes, including the nested constructions. Practical application of these modulated ultra-wideband signals ensures improved correlational features, high-fidelity probabilistic detection, and more precise positional detection of physical bodies depending on the range coordinate. Full article
Show Figures

Figure 1

21 pages, 4782 KiB
Article
Multipath Detection and Mitigation of Random Noise Signals Propagated through Naturally Lossy Dispersive Media for Radar Applications
by Ana Vazquez Alejos and Muhammad Dawood
Sensors 2023, 23(23), 9447; https://doi.org/10.3390/s23239447 - 27 Nov 2023
Cited by 2 | Viewed by 1429
Abstract
This paper describes a methodological analysis of the Brillouin precursor formation to understand the impairments undergone by like-noise and random noise waveforms propagating through naturally dispersive media commonly found in radar applications. By means of a frequency-domain methodology based on considering the frequency [...] Read more.
This paper describes a methodological analysis of the Brillouin precursor formation to understand the impairments undergone by like-noise and random noise waveforms propagating through naturally dispersive media commonly found in radar applications. By means of a frequency-domain methodology based on considering the frequency response of the medium under study, the effect of these dispersive media on the evolution of an input signal can be seen as frequency filtering. The simulations were performed at a center frequency of 1.5 GHz and for a signal bandwidth of 3 GHz. Four random noise signals were considered: Barker codes, PRBS codes, Frank codes, Costas codes and additive white Gaussian noise. The experienced impairments were assessed in terms of cross-correlation function (CCF) degradation. The differences in the behavior of each type of phase and frequency coded signal to face the dispersive propagation have been demonstrated in terms of parameters used for information retrieval: peak amplitude decay, CCF secondary sidelobe level and multipath detectability. Finally, a frequency filtering approach is proposed to mitigate the impairments due to dispersive propagation under multipath conditions. Full article
(This article belongs to the Special Issue Radar Receiver Design and Application)
Show Figures

Figure 1

17 pages, 9489 KiB
Article
Search and Study of Marked Code Structures for a Spatially Distributed System of Small-Sized Airborne Radars
by Vadim A. Nenashev and Sergey A. Nenashev
Sensors 2023, 23(15), 6835; https://doi.org/10.3390/s23156835 - 31 Jul 2023
Cited by 4 | Viewed by 1731
Abstract
When forming the radar situation of a terrain, in order to increase its information content and to extract useful information, multi-position spatially distributed systems for integrating multi-angle radar data established by small-sized UAV-based airborne radars are used. In this case, each radar station [...] Read more.
When forming the radar situation of a terrain, in order to increase its information content and to extract useful information, multi-position spatially distributed systems for integrating multi-angle radar data established by small-sized UAV-based airborne radars are used. In this case, each radar station belonging to a multi-position system as a probing signal must have its own unique marked signal. Such a setup will allow the signals reflected from ground objects and zones to be “attached” to specific receiving-transmitting positions of the multi-position system. This requirement results from the fact that each transceiver position emits one probing signal, and then receives all the echo signals reflected from the underlying surface and previously emitted by other radar devices of the multi-position system. Such a setup of multi-position systems requires the researcher to look for and investigate specialized systems of marked code structures used to modulate the probing signals in order to identify them in a joint radar channel. Thus, the problem at hand is how to look for and investigate novel marked code structures used to generate a system of probing signals, the use of which will allow it to be “attached” to a specific receiving-transmitting position of a multi-position onboard system and to identify them in a joint radar channel in the course of the remote sensing of the underlying surface. The purpose of this work is to conduct a study on the subject of the squeak and choice of a system of code structures that have a low level of side lobes of autocorrelation functions and uniformly distributed values of the levels of the cross-correlation function. To achieve this goal, the relevance of the study is substantiated in the introduction. The second section analyzes the level of side lobes for classical and modified Barker codes with an asymmetric alphabet. On the basis of this analysis, it was concluded that it is expedient to apply this approach for codes longer than Barker codes. Therefore, in the third section, the features of the generation of M-sequences are considered. The fourth section presents a technique for searching for new marked code structures, taking into account their mutual correlation properties for modifying M-sequences in order to implement multi-positional systems. The fifth section presents computer experiments on the search for marked code structures based on the modifications of M-sequences and presents the numerical characteristics of the correlation properties of the considered marked codes. And finally, in the sixth section, the final conclusions of the study are presented and recommendations are given for their further practical application. The practical significance of this study lies in the fact that the proposed new marked code structures are necessary for the synthesis of probing signals in the implementation of spatially distributed systems that function for the high-probability detection and high-precision determination of the coordinates of physical objects and are also necessary for the formation of radar images in a multi-position mode. Full article
Show Figures

Figure 1

12 pages, 3868 KiB
Technical Note
Chaotic Coding for Interference Suppression of Digital Ionosonde
by Sijia Han, Wei Guo, Peng Liu, Te Wang, Caiyun Wang, Qingyu Fang, Jian Yang, Lingling Li, Dapeng Liu and Jianping Huang
Remote Sens. 2023, 15(15), 3747; https://doi.org/10.3390/rs15153747 - 27 Jul 2023
Cited by 2 | Viewed by 1600
Abstract
External interference in ionospheric sounding seriously degrades the quality of echo signals and data; thus, it should be eliminated. This paper presents a method for suppressing interference using chaotic coding with a set of Bernoulli map sequences; compared with other commonly used coding [...] Read more.
External interference in ionospheric sounding seriously degrades the quality of echo signals and data; thus, it should be eliminated. This paper presents a method for suppressing interference using chaotic coding with a set of Bernoulli map sequences; compared with other commonly used coding methods such as Barker code, complementary code, and Barker-like codes, through simulation, the ambiguity function (AF) of Bernoulli map codes has better performance in terms of peak sidelobe level (PSL), integral sidelobe ratio (ISL), noise suppression (NS), and signal-to-noise ratio (SNR). Experimental tests were performed using a vertical ionosonde in Yinchuan, Ningxia Hui Autonomous Region, China, and the ionosonde was operated by alternating 40-bit Barker-like coding and 40-bit Bernoulli map coding each day to compare the effectiveness of interference suppression. The results showed that using Bernoulli map coding could remove interference and improve SNR significantly, thereby improving the data quality of the resulting ionograms. Full article
(This article belongs to the Special Issue Advanced Radar Signal Processing and Applications)
Show Figures

Figure 1

23 pages, 7882 KiB
Article
Application of Pulse Compression Technique in High-Temperature Carbon Steel Forgings Crack Detection with Angled SV-Wave EMATs
by Min He, Wenze Shi, Chao Lu, Guo Chen, Fasheng Qiu, Ying Zhu and Yuan Liu
Sensors 2023, 23(5), 2685; https://doi.org/10.3390/s23052685 - 1 Mar 2023
Cited by 8 | Viewed by 2470
Abstract
In order to solve the difficulty in localization and poor signal-to-noise ratio (SNR) of the angled shear vertical wave (SV wave) electromagnetic acoustic transducer (EMAT) in cracks detection of high-temperature carbon steel forgings, a finite element (FE) model of the angled SV wave [...] Read more.
In order to solve the difficulty in localization and poor signal-to-noise ratio (SNR) of the angled shear vertical wave (SV wave) electromagnetic acoustic transducer (EMAT) in cracks detection of high-temperature carbon steel forgings, a finite element (FE) model of the angled SV wave EMAT detection process was established, and the influence of specimen temperature on the EMAT excitation, propagation, and reception processes was analyzed. A high-temperature resistant angled SV wave EMAT was designed to detect carbon steel from 20 °C to 500 °C, and the influence law of the angled SV wave at different temperatures was analyzed. Then a circuit-field coupled FE model of angled SV wave EMAT in the carbon steel detection process based on the Barker code pulse compression technique was established, and the effects of the Barker code element length, impedance matching method, and matching component parameters on the pulse compression effect were analyzed. In addition, the noise suppression effect and the SNR of the crack-reflected wave in the tone-burst excitation method and the Barker code pulse compression technique were compared. The results show that the amplitude of the block-corner reflected wave decreases from 556 mV to 195 mV, and the SNR decreases from 34.9 dB to 23.5 dB when the specimen temperature increases from 20 °C to 500 °C. When the temperature is 500 °C, the SNR of the crack-reflected wave obtained by the Barker code pulse compression technique can be improved by 9.2 dB compared to the tone-burst excitation method with 16 synchronous averages. The study can provide technical and theoretical guidance for online crack detection for high-temperature carbon steel forgings. Full article
(This article belongs to the Special Issue Advanced Sensing and Evaluating Technology in Nondestructive Testing)
Show Figures

Figure 1

14 pages, 1320 KiB
Article
Reduction of Doppler and Range Ambiguity Using AES-192 Encryption-Based Pulse Coding
by Luke Kamrath, Michael Baginski and Scott Martin
Sensors 2023, 23(5), 2568; https://doi.org/10.3390/s23052568 - 25 Feb 2023
Cited by 2 | Viewed by 2207
Abstract
This research investigates the use of a Binary Phase Shift Key (BPSK) sequence derived from the 192-bit key Advanced Encryption Standard (AES-192) algorithm for radar signal modulation to mitigate Doppler and range ambiguities. The AES-192 BPSK sequence has a non-periodic nature resulting in [...] Read more.
This research investigates the use of a Binary Phase Shift Key (BPSK) sequence derived from the 192-bit key Advanced Encryption Standard (AES-192) algorithm for radar signal modulation to mitigate Doppler and range ambiguities. The AES-192 BPSK sequence has a non-periodic nature resulting in a single large and narrow main lobe in the matched filter response but also produces undesired periodic side lobes that can be mitigated through the use of a CLEAN algorithm. The performance of the AES-192 BPSK sequence is compared to an Ipatov–Barker Hybrid BPSK code, which effectively extends the maximum unambiguous range but has some limitations in terms of signal processing requirements. The AES-192 based BPSK sequence has the advantage of having no maximum unambiguous range limit, and when the pulse location within the Pulse Repetition Interval (PRI) is randomized, the upper limit on the maximum unambiguous Doppler frequency shift is greatly extended. Full article
Show Figures

Figure 1

18 pages, 2220 KiB
Article
An Application of Analytic Wavelet Transform and Convolutional Neural Network for Radar Intrapulse Modulation Recognition
by Marta Walenczykowska, Adam Kawalec and Ksawery Krenc
Sensors 2023, 23(4), 1986; https://doi.org/10.3390/s23041986 - 10 Feb 2023
Cited by 12 | Viewed by 3146
Abstract
This article analyses the possibility of using the Analytic Wavelet Transform (AWT) and the Convolutional Neural Network (CNN) for the purpose of recognizing the intrapulse modulation of radar signals. Firstly, the possibilities of using AWT by the algorithms of automatic signal recognition are [...] Read more.
This article analyses the possibility of using the Analytic Wavelet Transform (AWT) and the Convolutional Neural Network (CNN) for the purpose of recognizing the intrapulse modulation of radar signals. Firstly, the possibilities of using AWT by the algorithms of automatic signal recognition are discussed. Then, the research focuses on the influence of the parameters of the generalized Morse wavelet on the classification accuracy. The paper’s novelty is also related to the use of the generalized Morse wavelet (GMW) as a superfamily of analytical wavelets with a Convolutional Neural Network (CNN) as classifier applied for intrapulse recognition purposes. GWT is used to obtain time–frequency images (TFI), and SqueezeNet was chosen as the CNN classifier. The article takes into account selected types of intrapulse modulation, namely linear frequency modulation (LFM) and the following types of phase-coded waveform (PCW): Frank, Barker, P1, P2, and Px. The authors also consider the possibility of using other time–frequency transformations such as Short-Time Fourier Transform(STFT) or Wigner–Ville Distribution (WVD). Finally, authors present the results of the simulation tests carried out in the Matlab environment, taking into account the signal-to-noise ratio (SNR) in the range from −6 to 0 dB. Full article
(This article belongs to the Special Issue Radar Signal Detection, Recognition and Identification)
Show Figures

Figure 1

14 pages, 3478 KiB
Article
Detection and Parameter Estimation Analysis of Binary Shift Keying Signals in High Noise Environments
by Van Minh Duong, Jiri Vesely, Petr Hubacek, Premysl Janu and Nhat Giang Phan
Sensors 2022, 22(9), 3203; https://doi.org/10.3390/s22093203 - 21 Apr 2022
Cited by 6 | Viewed by 2564
Abstract
In this paper, a new method for detecting and estimating the parameters of a binary phase shift keying (BPSK) signal, based on a cross-correlation function, is proposed. The proposed method consists of two stages. The first stage is used to detect or estimate [...] Read more.
In this paper, a new method for detecting and estimating the parameters of a binary phase shift keying (BPSK) signal, based on a cross-correlation function, is proposed. The proposed method consists of two stages. The first stage is used to detect or estimate a signal carrier frequency, and the second stage is used to estimate its pulse width or symbol rate. Firstly, the proposed method is investigated by use of a simulated BPSK signal in the form of Barker Codes 7, 11, and 13 in the MATLAB environment. Based on the simulation results, the functionality of this method is verified using a real-time BPSK signal generated by an E8267C generator. This is described in the second part of this paper. The experimental test results confirm that the proposed method is able to detect and estimate the parameters of all BPSK signals with SNR21 dB. Full article
(This article belongs to the Section Intelligent Sensors)
Show Figures

Figure 1

14 pages, 2764 KiB
Article
Hybrid Coded Excitation of the Torsional Guided Wave Mode T(0,1) for Oil and Gas Pipeline Inspection
by Zeng Fan, Xudong Niu, Baichun Miao and Hongying Meng
Appl. Sci. 2022, 12(2), 777; https://doi.org/10.3390/app12020777 - 13 Jan 2022
Cited by 12 | Viewed by 2867
Abstract
Ultrasonic guided wave testing is an essential technique in non-destructive testing for structural integrity of oil and gas pipelines. This technique, based on the pulse-echo method, is often used for the long-range detection of pipelines at any location. However, guided waves suffer from [...] Read more.
Ultrasonic guided wave testing is an essential technique in non-destructive testing for structural integrity of oil and gas pipelines. This technique, based on the pulse-echo method, is often used for the long-range detection of pipelines at any location. However, guided waves suffer from high attenuation when they propagate in attenuative material structures and multiple wave modes due to the excitation, which reduces the power of echo signals and induces corruption caused by coherent noise. In this paper, a developed hybrid coded excitation method that uses the convolution of a Barker code and Golay code pair is proposed and applied for an ultrasonic guided wave testing system to excite the torsional guided wave mode T(0,1) in a steel pipe. The proposed method combines the advantages of these two coding methods and increases the flexibility of code lengths. The performance is evaluated by signal to noise ratio and peak sidelobe level of the processed signal. Both theoretical simulations and experiments have investigated using the proposed codes composed of Barker codes and Golay code pairs of different lengths and combinations. The experimental results show the significant improvement of the signal to noise ratio and the peak sidelobe level due to the proposed hybrid code usage for the excitation of guided waves. The values are further improved to around 32 dB and around −24 dB, respectively. Overall, the proposed hybrid coded method for improving the echo SNR can benefit from guided wave testing to reduce coherent and random noise levels and many other potential applications. Full article
Show Figures

Figure 1

12 pages, 3605 KiB
Article
Optimization of the Unambiguity of Cross-Correlated Ultrasonic Signals through Coded Excitation Sequences for Robust Time-of-Flight Measurements
by Marius Schäfer, Hendrik Theado, Michael M. Becker and Sarah C. L. Fischer
Signals 2021, 2(2), 366-377; https://doi.org/10.3390/signals2020023 - 16 Jun 2021
Cited by 6 | Viewed by 3306
Abstract
The cross-correlation function (CCF) is an established technique to calculate time-of-flight for ultrasonic signals. However, the quality of the CCF depends on the shape of the input signals. In many use cases, the CCF can exhibit secondary maxima in the same order of [...] Read more.
The cross-correlation function (CCF) is an established technique to calculate time-of-flight for ultrasonic signals. However, the quality of the CCF depends on the shape of the input signals. In many use cases, the CCF can exhibit secondary maxima in the same order of magnitude as the main maximum, making its interpretation less robust against external disturbances. This paper describes an approach to optimize ultrasonic signals for time-of-flight measurements through coded excitation sequences. The main challenge for applying coded excitation sequences to ultrasonic signals is the influence of the piezoelectric transducer on the outgoing signal. Thus, a simulation model to describe the transfer function of an experimental setup was developed and validated with common code sequences such as pseudo noise sequences (PN), Barker codes and chirp signals. Based on this model an automated optimization of ultrasonic echoes was conducted with random generated sequences, resulting in a decrease in the secondary positive maximum of the CCF to 56.6%. Based on these results, further empiric optimization leveraging the nonlinear regime of the piezoelectric transducer resulted in an even lower secondary positive maximum of the CCF with a height of 25% of the first maximum. Experiments were conducted on different samples to show that the findings hold true for small variations in the experimental setup; however, further work is necessary to develop transfer functions and simulations able to include a wider parameter space, such as varying transducer types or part geometry. Full article
Show Figures

Figure 1

15 pages, 48698 KiB
Article
Vibro-Thermal Wave Radar: Application of Barker Coded Amplitude Modulation for Enhanced Low-Power Vibrothermographic Inspection of Composites
by Saeid Hedayatrasa, Joost Segers, Gaétan Poelman, Wim Van Paepegem and Mathias Kersemans
Materials 2021, 14(9), 2436; https://doi.org/10.3390/ma14092436 - 7 May 2021
Cited by 14 | Viewed by 2508
Abstract
This paper proposes an efficient non-destructive testing technique for composite materials. The proposed vibro-thermal wave radar (VTWR) technique couples the thermal wave radar imaging approach to low-power vibrothermography. The VTWR is implemented by means of a binary phase modulation of the vibrational excitation, [...] Read more.
This paper proposes an efficient non-destructive testing technique for composite materials. The proposed vibro-thermal wave radar (VTWR) technique couples the thermal wave radar imaging approach to low-power vibrothermography. The VTWR is implemented by means of a binary phase modulation of the vibrational excitation, using a 5 bit Barker coded waveform, followed by matched filtering of the thermal response. A 1D analytical formulation framework demonstrates the high depth resolvability and increased sensitivity of the VTWR. The obtained results reveal that the proposed VTWR technique outperforms the widely used classical lock-in vibrothermography. Furthermore, the VTWR technique is experimentally demonstrated on a 5.5 mm thick carbon fiber reinforced polymer coupon with barely visible impact damage. A local defect resonance frequency of a backside delamination is selected as the vibrational carrier frequency. This allows for implementing VTWR in the low-power regime (input power < 1 W). It is experimentally shown that the Barker coded amplitude modulation and the resultant pulse compression efficiency lead to an increased probing depth, and can fully resolve the deep backside delamination. Full article
(This article belongs to the Special Issue Mechanical Characterization of FRP Composite Materials)
Show Figures

Figure 1

14 pages, 5601 KiB
Article
An Ultrasonic Object Detection Applying the ID Based on Spread Spectrum Technique for a Vehicle
by Donghee Yi, Heetae Jin, Moon Chan Kim and Suk Chan Kim
Sensors 2020, 20(2), 414; https://doi.org/10.3390/s20020414 - 11 Jan 2020
Cited by 10 | Viewed by 6049
Abstract
When an ultrasonic sensor generates an ultrasonic wave and detects an obstacle from a reflected wave, a signal transmitted by other ultrasonic sensors would be interference. In this paper, to overcome the interference, a transducer transmits a signal with a unique ID modulated. [...] Read more.
When an ultrasonic sensor generates an ultrasonic wave and detects an obstacle from a reflected wave, a signal transmitted by other ultrasonic sensors would be interference. In this paper, to overcome the interference, a transducer transmits a signal with a unique ID modulated. The interference is ignored by verifying that the reflected signal includes its ID. The ID verification process uses a correlation between the received signal and the ID. Therefore, the ID is selected from orthogonal codes with good cross-correlation. Long code has the advantage of being more robust to interference. However, the reflected wave from nearby obstacles might return before the transmission ends. Therefore, the 7-bit Barker code is applied for near obstacle detection and a 31-bit Gold code is used for distant obstacle detection. The modulation technique is DQPSK, which is available in a narrow bandwidth and has a simple receiver structure. In ID recognition based on correlation, a near–far problem occurs due to a large amplitude difference between the received wave and interference. The addition of a zero-crossing detector solves this problem. The hardware is implemented based on the algorithm proposed in this paper. The simulation showed a detection rate of at least 90% and the the result of the real measurement represented a detection rate of 97.3% at 0.5 m and 94.5% at 2 m. Full article
(This article belongs to the Special Issue Selected Papers from the 3rd Global IoT Summit)
Show Figures

Figure 1
