Search Results (57)

In hub-motor electric vehicles (HMEVs), performance is adversely affected by the mechanical-electromagnetic coupling effect arising from deformations of the air gap in the Permanent Magnet Brushless Direct Current Motor (PM BLDC), which are exacerbated by varying road conditions. In this paper, a Model Predictive Control (MPC) strategy for HMEVs equipped with air suspension (AS) is introduced to enhance ride comfort. Firstly, an 18-degree of freedom (DOF) full-vehicle model incorporating unbalanced electromagnetic forces (UEMFs) induced by motor eccentricities is developed and experimentally validated. Additionally, a Minimum Model Error Extended Kalman Filter (MME-EKF) observer is designed to estimate unmeasurable state variables and account for errors resulting from sprung mass variations. To further improve vehicle performance, the MPC optimization objective is formulated by considering the suspension damping force and dynamic displacement constraints, solving for the optimal suspension force within a rolling time domain. Simulation results demonstrate that the proposed MPC approach significantly improves ride comfort, effectively mitigates coupling effects in hub driving motors, and ensures that suspension dynamic stroke adheres to safety criteria. Comparative analyses indicate that the MPC controller outperforms conventional PID control, achieving substantial reductions of approximately 41.59% in sprung mass vertical acceleration, 14.29% in motor eccentricity, 1.78% in tire dynamic load, 17.65% in roll angular acceleration, and 16.67% in pitch angular acceleration. Full article

This work presents a sensorless brushless DC motor (BLDCM) drive control, optimized for solar photovoltaic (PV)- and battery-fed light electric vehicles (LEVs). A back-electromotive force (EMF) observer integrated with an enhanced quadrature-phase-locked-loop (QPLL) structure is proposed for accurate rotor position estimation, addressing limitations of existing control methods at low speeds and under dynamic conditions. The study replaces the conventional arc-tangent technique with a QPLL-based approach, eliminating low-pass filters to enhance system adaptability and reduce delays. The experimental results demonstrate a significant reduction in commutation error, with a nearly flat value at 0 degrees during steady-state and less than 8 degrees under dynamic conditions. Furthermore, the performance of a modified single-ended primary-inductor converter (SEPIC) for maximum power point tracking (MPPT) in solar-powered LEVs is verified, minimizing current ripple and ensuring smooth motor operation. The system also incorporates a regenerative braking mechanism, extending the vehicle’s range by efficiently recovering kinetic energy through the battery with 30.60% efficiency. The improved performance of the proposed method and system over conventional approaches contributes to the advancement of efficient and sustainable solar-powered BLDC motor-based EV technologies. Full article

The use of electric automobiles, or EVs, is essential to environmentally conscious transportation. Battery EVs (BEVs) are predicted to become increasingly accepted for passenger vehicle transportation within the next 10 years. Although enthusiasm for EVs for environmentally friendly transportation is on the rise, there remain significant concerns and unanswered research concerns regarding the possible future of EV power transmission. Numerous motor drive control algorithms struggle to deliver efficient management when ripples in torque minimization and improved dependability control approaches in motors are taken into account. Control techniques involving direct torque control (DTC), field orientation control (FOC), sliding mode control (SMC), intelligent control (IC), and model predictive control (MPC) are implemented in electric motor drive control algorithms to successfully deal with this problem. The present study analyses only sophisticated control strategies for frequently utilized EV motors, such as the brushless direct current (BLDC) motor, and possible solutions to reduce torque fluctuations. This study additionally explores the history of EV motors, the operational method between EM and PEC, and EV motor design techniques and development. The future prospects for EV design include a vital selection of motors and control approaches for lowering torque ripple, as well as additional research possibilities to improve EV functionality. Full article

As robots are increasingly used in remote, safety-critical, and hazardous applications, the reliability of robots is becoming more important than ever before. Robotic arm joint motor-drive systems are vulnerable to hardware failures due to harsh operating environment in many scenarios, which may yield various joint failures and result in significant downtime costs. Targeting the most common robotic joint brushless DC (BLDC) motor-drive systems, this paper proposes a robust online diagnostic method for semiconductor faults for BLDC motor drives. The proposed fault diagnostic technique is based on the stator current signature analysis. Specifically, this paper investigates the performance of the BLDC joint motors under open-circuit faults of the inverter switches using finite element co-simulation tools. Furthermore, the proposed methodology is not only capable of detecting any open-circuit faults but also identifying faulty switches based on a knowledge table by considering various fault conditions. The robustness of the proposed technique was verified through extensive simulations under different speed and load conditions. Moreover, simulations have been carried out on a Kinova Gen-3 robot arm to verify the theoretical findings, highlighting the impacts of locked joints on the robot’s end-effector locations. Finally, experimental results are presented to corroborate the performance of the proposed fault diagnostic strategy. Full article

In this paper, we propose the design, development, and testing of high-torque and lightweight actuators suitable for lightweight robotic applications. The detailed design of the actuator module is described, and its performance evaluation is also presented. Further, the mathematical modelling of the actuator is discussed. Various performance analysis tests were carried out for the elucidation of the designed actuator, which included primarily position, velocity, and torque analyses. The position accuracy analysis included position repeatability at the maximum payload for calculating the acceptable tolerance. The velocity elucidation included a velocity test for the variable load. The torque analysis of the actuator was completed at different supply currents. These tests and the results indicate that the proposed actuator has high precision in reaching the desired position and provides a stabilized performance with variable loads up to the limit for which it was designed. Based on the torque output and the weight, the proposed actuator could be a good fit for lightweight robotic applications. Full article

Low power brushless direct current (BLDC) motors are used in many consumer appliances. These motors have a relatively high winding resistance and therefore current control loop can be avoided in some cases, but fast and accurate speed regulation can be still needed. To minimize harmonics and generated sound noise, improved sinusoidal pulse width modulation (PWM) has been tested in the paper. As the most suitable commutation type, the sine wave with the third harmonic component has been selected. This type of communication reduced the torque ripple of the motor. This paper analyses the possibility to improve traditional proportional-integral-derivative (PID) speed regulator with Fuzzy logic block. A simulation model of BLDC motor, inverter, speed detection circuit and controller have been created. Simulation results showed that by applying the Fuzzy-based PID controller, the transient time can be reduced from 0.2 s to 0.05 s and overshoot can be avoided in comparison with traditional PID controller. Experimental results show a significant improvement in the motor dynamics—the overshoot and transient time were reduced twice. The difference with simulation results and experimental ones can be explained by delays introduced by the microcontroller. Full article

This paper deals with the application of a fuzzy-logic-based controller for a drive with a BLDC motor. Two main aspects of the work are presented in this paper. The first of them is focused on the design process of the fuzzy model. For this purpose, the rules of the applied fuzzy system are defined according to the Lyapunov function. The gain coefficients of the controller are optimized using the Chameleon Swarm Algorithm. Various issues and aspects were analyzed in the simulation tests (robustness against parameter changes, the influence of the controller parameters on the precision of control, stages of optimization, etc.). The presented work confirms the assumptions regarding precision and stable operation (also in the presence of changes in the object parameters—the mechanical time constants of the engine) in connection with the applied fuzzy speed controller. Moreover, the second part of the manuscript presents the low-cost power electronic device developed for laboratory tests. It uses STM32 ARM-based microcontrollers (state variable measurement, control algorithm calculation, control signal generation) and a Raspberry Pi 4B microcomputer (control application—reference value and parameter definition). The experiment performed for the control structure—an electric drive with a BLDC motor—verified the theoretical considerations. Full article

This study presents the tilt integral derivative (TID) controller technique for controlling the speed of BLDC motors in order to improve the real-time control of brushless direct current motors in electric vehicles. The TID controller is applied to the considered model to enhance its performance, e.g., torque and speed. This control system manages the torque output, speed, and position of the motor to ensure precise and efficient operation in EV applications. Brushless direct current motors are becoming more and more popular due to their excellent torque, power factor, efficiency, and controllability. The differences between PID, TID, and PI controllers are compared. The outcomes demonstrated that the TID control enhanced the torque and current stability in addition to the BLDC system’s capacity to regulate speed. TID controllers provide better input power for BLDC (brushless DC) drives than PI and PID controllers do. Better transient responsiveness and robustness to disturbances are features of TID controller design, which can lead to more effective use of input power. TID controllers are an advantageous choice for BLDC drive applications because of their increased performance, which can result in increased system responsiveness and overall efficiency. In an experimental lab, a BLDC motor drive prototype is implemented in this study. To fully enhance the power electronic subsystem and the brushless DC motor’s real-time performance, a test bench was also built. Full article

In this paper, a single-phase BLDC motor is applied to a cooling fan motor and a Drive IC integration analysis method of the single-phase BLDC motor is proposed. Single-phase BLDC motors have a simple structure, are easy to manufacture, and are low cost, so they are used in applications where low outputs and low costs are advantageous. Single-phase BLDC motors use a full-bridge inverter (Drive IC), and this inverter (Drive IC) has dead time due to switching. Therefore, in order to consider dead time when analyzing a single-phase BLDC motor, analysis through integration with Drive IC is necessary. This paper compares the types of single-phase BLDC motors, designs a model that satisfies target performance, and conducts research on Drive IC integration analysis through FEA. A prototype motor was manufactured and tested, and the validity of the Drive IC integration analysis was verified. Full article

This paper presents the operation of a remotely controlled, wheel-legged robot. The developed Wi-Fi connection framework is established on a popular ARM microcontroller board. The implementation provides a low-cost solution that is in congruence with the newest industrial standards. Additionally, the problem of limb structure and motor speed control is solved. The design process of the mechanical structure is enhanced by a nature-inspired metaheuristic optimization algorithm. An FOC-based BLDC motor speed control strategy is selected to guarantee dynamic operation of the drive. The paper provides both the theoretical considerations and the obtained prototype experimental results. Full article

A novel approach to the design of power factor correction (PFC) and torque ripple minimization in a brushless direct current (BLDC) motor drive with a new pulse width modulation (PWM) technique is demonstrated. The drive was designed to have a better power factor (PF) and less torque ripple. On the other hand, the modified Zeta converter is used to enhance the power factor of the proposed system. The modified Zeta converter is operated in discontinuous inductor current mode (DICM) by using a voltage follower technique, which only needs a voltage sensor for power factor correction (PFC) operation and DC-link voltage control. The output voltage of the VSI is determined by switching patterns generated by the PWM-ON-PWM switching strategy, and it reduces the torque ripples. The proposed drive is developed and simulated in a MATLAB/Simulink environment. The power factor of 0.9999 is produced by the PFC modified zeta converter topology and the PWM-ON-PWM scheme reduce the torque ripple in the commutation region by 34.2% as compared with the PWM-ON scheme. This demonstrates the effectiveness of the suggested control method. Full article

The adoption of the brushless DC motor in the electric drive vehicle industry continues to grow due to its robustness and ability to meet torque–speed requirements. This work presents the implementation of a fault-tolerant control (FTC) for a BLDC motor designed for electric vehicles. This paper focuses on studying the defect in the Ha sensor and its signal reconstruction, assuming possible cases, but the same principle is applied to the other two sensors (H_b and H_c ). In this case, the fault diagnosis allows for the correction and reconstruction of the signal in order to compel the system to work despite the presence of a fault. Indeed, several robust control systems are used within the work to regulate the speed of the motor properly, such as control via fuzzy logic and control via a neural network. This paper presents three BLDC control configurations for EVs, PID, fuzzy logic (FL), and an artificial neural network (ANN), discusses the pros and cons, and develops corresponding mathematical models to enhance a fault-tolerant control strategy which is analyzed and studied using MATLAB-based simulations (by discussing the two cases, the steady state and the transient state), allowing for a novel design based on the analytical models developed. The results obtained from the simulation of this system improved the speed controlled by the neural network compared to the fuzzy logic controller. At the same time, the sensor failure had no effect on the system’s operation due to the efficiency of the FTC control. Full article

A modular approach to the construction of electric machines, drive systems, power supply systems is a new direction of modern technology development. Especially, the modular approach is promising for electric vehicles due to such positive aspects as increased efficiency, fault tolerance, overall reliability, safety, enhanced control capabilities, etc. In this work, the modular approach is comprehensively applied to an EV powertrain system, which includes a dual three-phase (DTP) BLDC motor with two machine modules of an asymmetric configuration, two battery modules and a supercapacitor module (SCM). The proposed H–H configuration of modular EV powertrain system includes four voltage source inverters that combine the power modules with the open ends of the windings (OEW) of the module machine armature, and provide control of their operation. Based on the developed mode system of the OEW machine module operation for EV traction and braking, a general control algorithm for the proposed configuration of the modular EV powertrain system has been developed. It combines the control of the operating modes with the functions of maintaining the required SOC level of the SCM and equalizing the SOCs of the two battery modules. The conducted simulation and experimental studies confirmed the workability and effectiveness of the proposed solutions. Full article

Outrunner brushless DC motors (BLDC) are a type of permanent magnet synchronous motor (PMSM) widely used in electric micro-mobility vehicles, such as scooters, electric bicycles, wheelchairs, and segways, among others. Those vehicles have many operational constraints because they are driven directly by the user with light protective wearing. Therefore, to improve control strategies to make the drive safer, it is essential to model the traction system over a wide range of operating conditions in a street environment. In this work, we developed an electro-mechanical model based on the Hardware-in-the-Loop (HIL) structure for a two-wheeler electric scooter, using the BLDC motor to explore its response and to test linear controllers for speed and torque management under variable operating conditions. The proposed model includes motor parameters, power electronics component characteristics, mechanical structure, and external operating conditions. Meanwhile the linear controllers will be adjusted or tuned though a heuristic approach based on Genetic Algorithms (GAs) to optimize the system’s response. The HIL scheme will be able to simulate a wide range of conditions such as user weight, slopes, wind speed changes, and combined conditions. The designed model can be used to improve the design of the controller and estimate mechanical and electrical loads. Finally, the results of the controller tests show how the proposed cascade scheme, tuned through the GA, improves the system behavior and reduces the mean square error with respect to a classical tuning approach between 20% and 60%. Full article

Regarding the importance of the Internet of Things (IoT) and the Metaverse as two practical emerging technologies to enhance the digitalization of public transportation systems, this article introduces an approach for the improvement of IoT and unmanned electric vehicles in the Metaverse, called the Internet of Unmanned Electric Vehicles (IoUEVs). This research includes two important contributions. The first contribution is the description of a framework for how unmanned electric vehicles can be used in the Metaverse, and the second contribution is the creation of a digital twin for an unmanned electric vehicle. In the digital twin section, which is the focus of this research, we present a digital twin of an electronic differential system (EDS) in which the stability has been improved. Robust fuzzy logic algorithm-based speed controllers are employed in the EDS to independently control the EV wheels driven by high-performance brushless DC (BLDC) electric motors. In this study, the rotor position information of the motors, which is estimated from the low-precision Hall-effect sensors mounted on the motors’ shafts, is combined and converted to a set of common switching signals for empowering the EDS of the electric vehicle traction drive system. The proposed digital twin EDS relies on an accurate Hall sensor signals-based synchronizing/locking strategy with a dynamic steering pattern capable of running in severe road conditions with different surface profiles to ensure the EV’s stability. Unlike recent EDSs, the proposed digital twinning approach includes a simple practical topology with no need for auxiliary infrastructures, which is able to reduce mechanical losses and stresses and can be adapted to IoUEVs more effectively. Full article
