This review summarizes the use of Auger Electron Spectroscopy (AES) for microchemical analysis of two different types of dielectric/(Al,Ga)N-based systems: (i) extrinsic dielectric PECVD SiO₂, ALD Al₂O₃, and ECR-CVD SiN_x films on Al_xGa_1−xN/GaN structures in the context of their application in microelectronic power devices and (ii) intrinsic Al₂O₃ films on AlN epitaxial layers grown by high-temperature oxidation for nanostructured technology of various gas/ion sensors. Particular attention is given to AES depth profiling across complete multilayer cross-sections, combining qualitative analysis of spectral line shape and intensity evolution as well as kinetic energy shifts with quantitative elemental depth distributions. This approach enables identification of chemical states and oxidation-related transformations at dielectric/semiconductor interfaces. Reported results demonstrate that AES provides micro- to nanometer-scale chemical information essential for distinguishing interfacial from the bulk properties. The capabilities and inherent limitations of AES depth profiling, including sputter-induced artifacts are also addressed, highlighting the role of optimized experimental conditions in reliable interface analysis. Full article

Al_xGa_1-xN layers with up to 53% Al composition and 1.3 µm total thicknesses were grown utilizing step-graded layers on dense arrays of 10 × 10 µm² GaN tiles. While the layers were fully relaxed and crack-free, the higher Al composition sample showed increased X-ray line width, which did not correlate with a lack of increased dislocation density (as measured by TEM). Full article

Including an n-doped layer in asymmetric double quantum wells restricts confined carriers into V-shaped potential profiles, forming discrete conduction subbands and enabling intersubband transitions. Most studies on doped semiconductor heterostructures focus on how external fields and structural parameters dictate optical absorption. However, electromagnetically induced transparency remains largely unexplored. Here, we show that the effect of an n-doped layer GaAs/Al_xGa_1−xAs in an asymmetric double quantum well system is quite sensitive to the width and position of the doped layer. By self-consistently solving the Poisson and Schrödinger’s equations, we determine the electronic structure using the finite element method within the effective mass approximation. We found that the characteristics of the n-doped layer can modulate the resonance frequencies involved in the electromagnetically induced transparency phenomenon. Our results demonstrate that an n-doped layer can control the electromagnetically induced transparency effect, potentially enhancing its applications in optoelectronic devices. Full article

Semiconductors characterized by ultrawide bandgaps (UWBGs), exceeding the SiC bandgap of 3.2 eV and the GaN bandgap of 3.4 eV, are currently under focus for applications in high-power and radio-frequency (RF) electronics, as well as in deep-ultraviolet optoelectronics and extreme environmental conditions. These semiconductors offer numerous advantages, such as a high breakdown field, exceptional thermal stability, and minimized power losses. This study used numerical simulation to investigate, at the material level, the single-particle radiation response of various UWBG semiconductors, such as aluminum gallium nitride alloys (Al_xGa_1−xN), diamond, and β-phase gallium oxide (β-Ga₂O₃), when exposed to ground-level neutrons. Through comprehensive Geant4 simulations covering the entire spectrum of atmospheric neutrons at sea level, this study provides an accurate comparison of the neutron radiation responses of these UWBG semiconductors focusing on the interaction processes, the number and nature of secondary ionizing products, their energy distributions, and the production of electron–hole pairs at the origin of single-event effects (SEEs) in microelectronics devices. Full article

A graded composition superlattice structure is proposed by combining simulation with experimentation. The structural factors affecting graded symmetric superlattices and graded asymmetric superlattices and their action modes are simulated and analyzed. A Mg-doped graded symmetric superlattice structure with high Al content, excellent structural quality, good surface morphology and excellent electrical properties was grown by MOCVD equipment. The Al_xGa_1−xN superlattice with Al composition of 0.7 in the barrier exhibits a hole concentration of approximately 5 × 10¹⁵ cm⁻³ and a resistivity of 66 Ω·cm. Full article

AlGaN is attractive for fabricating deep ultraviolet (DUV) optoelectronic and electronic devices of light-emitting diodes (LEDs), photodetectors, high-electron-mobility field-effect transistors (HEMTs), etc. We investigated the quality and optical properties of Al_xGa_1−xN films with high Al fractions (60–87%) grown on sapphire substrates, including AlN nucleation and buffer layers, by metal–organic chemical vapor deposition (MOCVD). They were initially investigated by high-resolution X-ray diffraction (HR-XRD) and Raman scattering (RS). A set of formulas was deduced to precisely determine x(Al) from HR-XRD data. Screw dislocation densities in AlGaN and AlN layers were deduced. DUV (266 nm) excitation RS clearly exhibits AlGaN Raman features far superior to visible RS. The simulation on the AlGaN longitudinal optical (LO) phonon modes determined the carrier concentrations in the AlGaN layers. The spatial correlation model (SCM) analyses on E₂(high) modes examined the AlGaN and AlN layer properties. These high-x(Al) Al_xGa_1−xN films possess large energy gaps E_g in the range of 5.0–5.6 eV and are excited by a DUV 213 nm (5.8 eV) laser for room temperature (RT) photoluminescence (PL) and temperature-dependent photoluminescence (TDPL) studies. The obtained RTPL bands were deconvoluted with two Gaussian bands, indicating cross-bandgap emission, phonon replicas, and variation with x(Al). TDPL spectra at 20–300 K of Al_0.87Ga_0.13N exhibit the T-dependences of the band-edge luminescence near 5.6 eV and the phonon replicas. According to the Arrhenius fitting diagram of the TDPL spectra, the activation energy (19.6 meV) associated with the luminescence process is acquired. In addition, the combined PL and time-resolved photoluminescence (TRPL) spectroscopic system with DUV 213 nm pulse excitation was applied to measure a typical AlGaN multiple-quantum well (MQW). The RT TRPL decay spectra were obtained at four wavelengths and fitted by two exponentials with fast and slow decay times of ~0.2 ns and 1–2 ns, respectively. Comprehensive studies on these Al-rich AlGaN epi-films and a typical AlGaN MQW are achieved with unique and significant results, which are useful to researchers in the field. Full article

Quaternary (Al_xGa_1−x)_yIn_1−yP alloys grown on GaAs substrates have recently gained considerable interest in photonics for improving visible light-emitting diodes, laser diodes, and photodetectors. With two degrees of freedom (x, y) and keeping growth on a lattice-matched GaAs substrate, the (Al_xGa_1−x)_0.5In_0.5P alloys are used for tuning structural, phonon, and optical characteristics in different energy regions from far-infrared (FIR) → near-infrared (NIR) → ultraviolet (UV). Despite the successful growth of (Al_xGa_1−x)_0.5In_0.5P/n⁺-GaAs epilayers, limited optical, phonon, and structural characteristics exist. Here, we report our results of carefully examined optical and vibrational properties on highly disordered alloys using temperature-dependent photoluminescence (TD-PL), Raman scattering spectroscopy (RSS), and Fourier-transform infrared reflectivity (FTIR). Macroscopic models were meticulously employed to analyze the TD-PL, RSS, and FTIR data of the (Al_0.24Ga_0.76)_0.5In_0.5P/n⁺-GaAs epilayers to comprehend the energy-dependent characteristics. The Raman scattering and FTIR results of phonons helped analyze the reflectivity spectra in the FIR region. Optical constants were carefully integrated in the transfer matrix method for evaluating the reflectivity $\mathrm{R}\left(\mathrm{E}\right)$ and transmission $\mathrm{T}\left(\mathrm{E}\right)$ spectra in the NIR → UV regions, validating the TD-PL measurements of bandgap energies $\left({\mathrm{E}}_{\mathrm{g}}^{\mathrm{P}\mathrm{L}}\right)$. Full article

This research explores the architecture and efficacy of GaN/Al_xGa_1−xN-based heterojunction phototransistors (HPTs) engineered with both a compositionally graded and a doping-graded base. Employing theoretical analysis along with empirical fabrication techniques, HPTs configured with an aluminum compositionally graded base were observed to exhibit a substantial enhancement in current gain. Specifically, theoretical models predicted a 12-fold increase, while experimental evaluations revealed an even more pronounced improvement of approximately 27.9 times compared to conventional GaN base structures. Similarly, HPTs incorporating a doping-graded base demonstrated significant gains, with theoretical predictions indicating a doubling of current gain and experimental assessments showing a 6.1-fold increase. The doping-graded base implements a strategic modulation of hole concentration, ranging from 3.8 × 10¹⁶ cm⁻³ at the base–emitter interface to 3.8 × 10¹⁷ cm⁻³ at the base–collector junction. This controlled gradation markedly contributes to the observed enhancements in current gain. The principal mechanism driving these improvements is identified as the increased electron drift within the base, propelled by the intrinsic electric field inherent to both the compositionally and doping-graded structures. These results highlight the potential of such graded base designs in enhancing the performance of GaN/Al_xGa_1−xN HPTs and provide crucial insights for the advancement of future phototransistor technologies. Full article

In this study, we propose a polarized electron blocking layer (EBL) structure using Al_xGa_1−xN/Al_xGa_1−xN to enhance the internal quantum efficiency (IQE) of AlGaN-based ultraviolet light-emitting diodes (UV LEDs). Our findings indicate that this polarized EBL structure significantly improves IQE compared to conventional EBLs. Additionally, we introduce an electric-field reservoir (EFR) optimization method to maximize IQE. Specifically, optimizing the polarized EBL structure of Al_xGa_1−xN/Al_xGa_1−xN enhances the hole drift rate, resulting in an IQE improvement of 19% and an optical output power increase of 186 mW at a current of 210 mA. Full article

In our pursuit of high-power terahertz (THz) wave generation, we propose innovative edge-terminated single-drift region (SDR) multi-quantum well (MQW) impact avalanche transit time (IMPATT) structures based on the Al_xGa_1−xN/GaN/Al_xGa_1−xN material system, with a fixed aluminum mole fraction of x = 0.3. Two distinct MQW diode configurations, namely p⁺-n junction-based and Schottky barrier diode structures, were investigated for their THz potential. To enhance reverse breakdown characteristics, we propose employing mesa etching and nitrogen ion implantation for edge termination, mitigating issues related to premature and soft breakdown. The THz performance is comprehensively evaluated through steady-state and high-frequency characterizations using a self-consistent quantum drift-diffusion (SCQDD) model. Our proposed Al_0.3Ga_0.7N/GaN/Al_0.3Ga_0.7N MQW diodes, as well as GaN-based single-drift region (SDR) and 3C-SiC/Si/3C-SiC MQW-based double-drift region (DDR) IMPATT diodes, are simulated. The Schottky barrier in the proposed diodes significantly reduces device series resistance, enhancing peak continuous wave power output to approximately 300 mW and DC to THz conversion efficiency to nearly 13% at 1.0 THz. Noise performance analysis reveals that MQW structures within the avalanche zone mitigate noise and improve overall performance. Benchmarking against state-of-the-art THz sources establishes the superiority of our proposed THz sources, highlighting their potential for advancing THz technology and its applications. Full article

AlGaN-based LEDs are promising for many applications in deep ultraviolet fields, especially for water-purification projects, air sterilization, fluorescence sensing, etc. However, in order to realize these potentials, it is critical to understand the factors that influence the optical and electrical properties of the device. In this work, Al_xGa_1−xN (x = 0.24, 0.34, 0.47) epilayers grown on c-plane patterned sapphire substrate with GaN template by the metal organic chemical vapor deposition (MOCVD). It is demonstrated that the increase of the aluminum content leads to the deterioration of the surface morphology and crystal quality of the AlGaN epitaxial layer. The dislocation densities of Al_xGa_1−xN epilayers were determined from symmetric and asymmetric planes of the ω-scan rocking curve and the minimum value is 1.01 × 10⁹ cm⁻². The $\left(10\overline{1}5\right)$ plane reciprocal space mapping was employed to measure the in-plane strain of the Al_xGa_1−xN layers grown on GaN. The surface barrier heights of the Al_xGa_1−xN samples derived from XPS are 1.57, 1.65, and 1.75 eV, respectively. The results of the bandgap obtained by PL spectroscopy are in good accordance with those of XRD. The Hall mobility and sheet electron concentration of the samples are successfully determined by preparing simple indium sphere electrodes. Full article

The leakage of the electronic current of a laser diode (LD) has some significant influences on the performance of the LD. In this study, commercial simulation software LASTIP is used to numerically evaluate the performances of LDs by using different wavelengths and Al contents of the electron blocking layer (EBL). These LDs a adopt multilayer structure, which contains cladding layers, waveguide layers, multiple quantum well layers, contact layers and an Al_xGa_1−xN EBL. The influence mechanism of EBL is theoretically examined by analyzing the simulated performances. It is found that for short-wavelength violet LDs, the electrical and optical properties of the LD will reach the optimum state when the Al content (x) in the EBL is nearly 0.25. For long-wavelength green LDs, it will achieve optimum electrical and optical properties when the Al content in the EBL is as low as possible. We also compare the simulation results of LDs with emission wavelengths in the range of violet and green, including blue cyan, for a more general evaluation. According to the simulated results, it is verified that the influence of the EBL’s Al content on LD performance enhances as the wavelength increases. Full article

Power electronics are becoming increasingly more important, as electrical energy constitutes 40% of the total primary energy usage in the USA and is expected to grow rapidly with the emergence of electric vehicles, renewable energy generation, and energy storage. New materials that are better suited for high-power applications are needed as the Si material limit is reached. Beta-phase gallium oxide (β-Ga₂O₃) is a promising ultra-wide-bandgap (UWBG) semiconductor for high-power and RF electronics due to its bandgap of 4.9 eV, large theoretical breakdown electric field of 8 MV cm⁻¹, and Baliga figure of merit of 3300, 3–10 times larger than that of SiC and GaN. Moreover, β-Ga₂O₃ is the only WBG material that can be grown from melt, making large, high-quality, dopable substrates at low costs feasible. Significant efforts in the high-quality epitaxial growth of β-Ga₂O₃ and β-(Al_xGa_1−x)₂O₃ heterostructures has led to high-performance devices for high-power and RF applications. In this report, we provide a comprehensive summary of the progress in β-Ga₂O₃ field-effect transistors (FETs) including a variety of transistor designs, channel materials, ohmic contact formations and improvements, gate dielectrics, and fabrication processes. Additionally, novel structures proposed through simulations and not yet realized in β-Ga₂O₃ are presented. Main issues such as defect characterization methods and relevant material preparation, thermal studies and management, and the lack of p-type doping with investigated alternatives are also discussed. Finally, major strategies and outlooks for commercial use will be outlined. Full article

The nanotribological properties of aluminum gallium nitride (Al_xGa_1−xN) epitaxial films grown on low-temperature-grown GaN/AlN/Si substrates were investigated using a nanoscratch system. It was confirmed that the Al compositions played an important role, which was directly influencing the strength of the bonding forces and the shear resistance. It was verified that the measured friction coefficient (μ) values of the Al_xGa_1−xN films from the Al compositions (where x = 0.065, 0.085, and 0.137) were in the range of 0.8, 0.5, and 0.3, respectively, for Fn = 2000 μN and 0.12, 0.9, and 0.7, respectively, for Fn = 4000 μN. The values of μ were found to decrease with the increases in the Al compositions. We concluded that the Al composition played an important role in the reconstruction of the crystallites, which induced the transition phenomenon of brittleness to ductility in the Al_xGa_1−xN system. Full article

The growth of nanoscale columnar Al_xGa_1-xN/AlN heterostructures on the surface of silicon substrates using plasma-activated nitrogen molecular-beam epitaxy was investigated in this work. Silicon substrates include atomic-smooth cSi substrate, Si substrate with a transition layer of porous silicon porSi/cSi and a hybrid substrate involving a silicon carbide layer grown with matched substitution of the atoms on the surface of porous silicon SiC/porSi/cSi. A complex analysis performed using a set of structural and spectroscopic techniques demonstrated that the epitaxial growth of the nuclear AlN layer on all types of the substrates in a N-enriched environment resulted in the formation of Al_xGa_1-xN/AlN heterostructures with a Ga-polar surface, which was realized only on the SiC/porSi/cSi substrate. The layer of Al_xGa_1-xN on cSi and porSi/cSi substrates was in the state of disordered alloy with an excess of gallium atom content. It was shown that a great difference in the lattice parameters of a substrate–film pair resulted not only in the appearance of a number of various defects but also in a considerable effect on the chemical process of the formation of the alloys, in our case, the Al_xGa_1-xN alloy. It was shown that nanoscale columns of Al_xGa_1-xN formed on SiC/porSi/cSi substrate were inclined relative to the c-axis, which was connected with the features of the formation of a SiC layer by the matched substitution of the atoms on the porous Si substrate, resulting in the formation of the inclined (111) SiC facets at the boundary of the (111) Si surface and pores in Si. Optical studies of the grown samples demonstrated that the optical band-to-band transition for the AlxGa1-xN alloy with E_g = 3.99 eVB was observed only for the heterostructure grown on the SiC/porSi/cSi substrate. A qualitative model is proposed to explain the difference in the formation of Al_xGa_1-xN layers on the substrates of cSi, porSi/cSi and SiC/porSi/cSi. The results obtained in our work demonstrate the availability of using SiC/porSi/cSi substrates for the integration of silicon technology and that used for the synthesis of nanoscale columnar Al_xGa_1-xN heterostructures using plasma-activated molecular-beam epitaxy with a nitrogen source. Full article
