As a result of the 2017 Pohang earthquake, numerous piloti-type structures incurred damage, and the cause was attributed to the wide spacing of transverse reinforcement. Improper spacing of transverse reinforcement can lead to brittle failure of columns, potentially causing the collapse of buildings. This study aimed to analyze the failure mode of columns where load and displacement are concentrated due to vertical irregularity, and to quantify the spacing of shear reinforcement according to the degree of vertical irregularity to prevent shear failure of the column. First, a vertically irregular frame with vertical irregularity and an RC moment frame with the same upper and lower structural systems was modeled, and the failure mode of the column was analyzed. In this paper, the failure modes were classified into shear failure, flexure–shear failure, and flexural failure based on the shear capacity ratio. The analysis results showed that in the case of vertical irregularity, the shear demand of the column was evaluated as high due to the high flexural stiffness of the horizontal members, and the failure mode of the column was classified as shear failure. The impact of the spacing of shear reinforcement on the shear strength of the structure was also examined. Next, an analysis was performed according to the degree of vertical irregularity by adjusting the thickness of the first-floor shear wall, and as a result, the proportion of the entire columns classified as shear failure increased as the vertical irregularity increased. It was confirmed that the minimum spacing of shear reinforcement of 150 mm specified in Korean standards becomes inadequate when the degree of vertical irregularity exceeds 2.6. At a vertical irregularity of 8.3, the spacing required to prevent shear failure decreased to 136 mm, which is 9.33% less than the minimum specified by the Korean standards. This indicates that even if the code’s minimum spacing is adhered to, shear failure can still occur in columns. In order to prevent shear failure of the column, the spacing of the shear reinforcement should be designed smaller, because the shear force increases as the vertical irregularity increases. For piloti-type structures with high horizontal irregularity, there is a need to design shear reinforcement narrower than the minimum standard to prevent shear failure of the column. Full article

The increasing frequency of earthquake events worldwide, particularly in South Korea, necessitates detailed seismic hazard assessments to mitigate the risks to urban infrastructure. This study addresses this pressing need by developing a comprehensive multi-hazard assessment framework specific to the Gyeonggi-do Province. By leveraging advanced geospatial computation techniques and geographic information systems, this study integrated geotechnical data, terrain information, and building inventories to evaluate seismic site effects, earthquake-induced landslide hazards, and structural vulnerability. This method uses geostatistical methods to construct geotechnical spatial grids that correlate site-specific seismic responses to potential hazards. The key findings revealed significant variations in seismic site responses owing to local subsurface characteristics, emphasizing the importance of site-specific seismic hazard maps for urban disaster preparedness. The framework’s effectiveness was validated by analyzing the 2017 Pohang earthquake, which demonstrated a strong correlation between predicted and observed damage. This study highlights the importance of ongoing seismic hazard assessment methodology development and advocates interdisciplinary collaboration to improve urban resilience, ultimately protecting communities from the impacts of future earthquakes. Full article

In Korea, the underground silo structure for low- and intermediate-level radioactive waste disposal facilities has been constructed and operated since 2014. Large-scale earthquakes occurred in 2016 and 2017, respectively, in Gyeongju and Pohang areas near the underground silo structures, and interest in the stability of the underground silo increased significantly. In this paper, one-dimensional free-field analyses have been carried out before the three-dimensional silo dynamic analyses subjected to earthquake loadings. As an additional study, a new form of the finite element equilibrium equation is derived in terms of relative motions, which is essentially the same equation expressed in terms of total motions where the base shear force is applied to the earthquake load. The accuracy of conventional finite element solutions is evaluated by directly comparing them with closed-form solutions by frequency domain analysis such as SHAKE91. Full article

The adoption of artificial intelligence in post-earthquake inspections and reconnaissance has received considerable attention in recent years, owing to its exponential increase in computation capabilities and inherent potential in addressing disadvantages associated with manual inspections. Herein, we present the effectiveness of automated deep learning in enhancing the assessment of damage caused by the 2017 Pohang earthquake. Six classical pre-trained convolutional neural network (CNN) models are implemented through transfer learning (TL) on a small dataset, comprising 1780 manually labeled images of structural damage. Feature extraction and fine-tuning TL methods are trained on the image datasets. The performances of various CNN models are compared on a testing image dataset. Results confirm that the MobileNet fine-tuned model offers the best performance. Therefore, the model is further developed as a web-based application for classifying earthquake damage. The severity of damage is quantified by assigning damage assessment values, derived using the CNN model and gradient-weighted class activation mapping. The web-based application can effectively and automatically classify structural damage resulting from earthquakes, rendering it suitable for decision making, such as in resource allocation, policy development, and emergency response. Full article

Earthquakes with magnitudes over 5.0 occurred near Gyeongju and Pohang in southern Korea in 2016 and 2017, respectively. These earthquakes had both low- and high-frequency components. Due to earthquakes with high-frequency motions, damage to nonstructural systems has been observed to be relatively more than that in structural systems. Consequently, the seismic design or performance evaluation of nonstructural components in critical facilities has emerged as a key research area in Korea. This study presents the results of experimental and numerical analyses using a high-fidelity finite element (FE) simulation in the ABAQUS platform for a press-to-connect piping system as a nonstructural component. Press-to-connect piping systems based on NFPA-13 with two elbows, a flexible coupling, and a T-joint were used. In addition, a cyclic loading protocol was applied using the KBC 2016 and IBC 2015. Based on the component-level experimental test, an FE model of the press-to-connect elbow was developed, and the high-fidelity large-scale piping system with an elbow was validated in this study. In both the experimental and analytical results, no leakage or plastic deformation of the piping system was observed under cyclic loading conditions. The results of the high-fidelity simulation model of the large-scale piping system were identical to those of the experimental test. More specifically, the error of the von-Mises stress at the upper and lower elbows was less than 9%, and the angle between the elbows was less than 2%, corresponding to the limit state of the drift ratio of the building system. Therefore, the high-fidelity simulation model of a large-scale piping system can have high application value. In addition, the design requirements and engineering demands of the piping system, such as the condition of ASME B and PV section III for service level D, were satisfied. Full article

In this study, we analyze the case of induced seismicity in Pohang, South Korea, in 2017 to investigate the effect of seismic risk perception on the local residential property market. Based on a hedonic pricing model with a difference-in-differences method, we examine the geographic distribution of the effects of unexpected earthquake hazards. Our results indicate an overall reduction in local property values, but the magnitudes of negative externality for housing prices decrease with respect to the distance from the epicenter. In areas within 3 km of the epicenter, the asset value reduced by approximately 20% after an earthquake event, but if the distance from the epicenter was higher than 12 km, the negative effect on the price was not significant. In addition, we examine how the experience of seismic events affect the preference on the anti-seismic building structure. The results show that the market valuation on the anti-seismic system significantly escalated after the earthquake. Full article

The interest in the seismic performance of nuclear power plants has increased worldwide since the Fukushima Daiichi Nuclear Power Plant incident. In Korea, interest in the seismic safety of nuclear power plants has increased since the earthquake events in Gyeongju (2016) and Pohang (2017). In Korea, studies have been conducted to apply seismic isolation systems to ensure seismic safety while minimizing the design changes to nuclear power plants. Nuclear power plants with seismic isolation systems may have a higher seismic risk due to the failure of the piping system in the structure after a relatively large displacement. Therefore, it is essential to secure the seismic safety of pipes for the safe operation of nuclear power plants. The seismic safety of pipes is determined by seismic fragility analysis. Seismic fragility analysis requires many seismic response analyses because it is a statistical approach to various random variables. Typical numerical conditions affecting the seismic response analysis of pipes are the convergence conditions and mesh size in numerical analysis. This study examined the change in the seismic safety of piping according to the numerical conditions. The difference in the seismic response analysis results of the piping according to the mesh size was analyzed comparatively. In addition, the change in the seismic fragility curve of the piping according to the convergence conditions was investigated. Full article

In general, the stone pagoda structures with discontinuous surfaces are vulnerable to lateral forces and are severely damaged by earthquakes. After the Gyeongju earthquake in 2016 and the Pohang earthquake in 2017, numerous stone pagoda structures were damaged due to slippage, rotation, and the separation of stacked stone. To evaluate seismic resistance of masonry stone pagoda structures, we analyzed the seismic behavior of stone pagoda structures using the shaking table test. Shaking frequency, permanent displacement, maximum acceleration, rocking, and sliding were assessed. Responses to simulations of the Bingol, Gyeongju, and Pohang earthquakes based on the Korean seismic design standard (KDS 41 17 00) were analyzed for return periods of 1000 and 2400 years. We found that the type of stylobate affected the seismic resistance of the stone pagoda structure. When the stylobates were stiff, seismic energy was transferred from lower to upper regions of the stone pagoda, which mainly resulted in deformation of the upper region. When the stylobates were weak, earthquake energy was absorbed in the lower regions, which was associated with large stylobate deformations. The lower part of the tower body was mainly affected by rocking, because the structural members were slender. The higher part of the stone pagoda was mainly affected by sliding, because the load and contact area decreased with height. Full article

Earthquake activities in and around the Korean Peninsula are relatively low in number and intensity compared with neighboring countries such as Japan and China. However, recent seismic activity caused great alarm and concern among citizens and government authorities, and uncovered the level of preparedness toward earthquake disasters. A survey has been conducted on 1256 participants to investigate the seismic literacy of Korean citizens, including seismic knowledge, awareness and management using a questionnaire of citizen earthquake literacy (CEL). The results declared that the citizens had low awareness and literacy, which means that they are not properly prepared for earthquake hazards. To develop an earthquake risk reduction plan and program efficiently and effectively, not only must it appropriately characterize the target audience, but also indicate high potential earthquake zones and potential earthquake damage. Therefore, this study mapped and analyzed the seismic vulnerability in southeast Korea using LogitBoost, logistic model tree (LMT), and logistic regression (LR) machine learning algorithms based on a building damage inventory map. The damaged buildings’ locations were generated after the 2017 Pohang earthquake using the damage proxy map (DPM) method from the Sentinel-1 synthetic aperture radar (SAR) data. DPMs detected coherence loss, which indicates damaged buildings in urban areas in the Pohang earthquake and shows a good correlation with the Korea Meteorological Administration (KMA) report with modified Mercalli intensity (MMI) scale values of more than VII (seven). The damage locations were randomly divided into two datasets: 50% for training the vulnerability models and 50% for validating the models in terms of accuracy and reliability. Fifteen seismic-related factors were used to construct a model of each algorithm. Model validation based on the area under the receiver operating curve (AUC) was used to determine model accuracy. The AUC values of seismic vulnerability maps using the LogitBoost, LMT, and LR algorithms were 0.769, 0.851, and 0.749, respectively. We suggest that earthquake preparedness efforts should focus on reconstruction, retrofitting, renovation, and seismic education in areas with high seismic vulnerability in South Korea. The results of this study are expected to be beneficial for engineers and policymakers aiming at developing disaster risk reduction plans, policies, and programs due to future seismic activity in South Korea. Full article

In Korea, the earthquakes in Gyeongju (2016) and Pohang (2017) have led to increased interest in the seismic design of nonstructural elements. Among these, the suspended ceiling can cause personal injury and property damage. In addition, most suspended ceilings that are used in Korea neither have seismic design details nor meet the current seismic design standards. There are two seismic design methods for suspended ceilings using a perimeter clip and a brace. In the United States and Japan, seismic design of ceilings is typically used, but the concepts of applying and installing braces are different. This is because the typical ceiling systems are different in the United States and Japan. In this study, a brace-applied ceiling system that is suitable for a suspended ceiling with a steel panel was applied in the indirect suspended ceiling mainly used in Korea. In addition, the seismic performance was verified through a shaking table test. All the specimens were applied with anti-falling clips that are designed to prevent the panels from falling, and they satisfy KDS 41 17 00, which is a Korean seismic design life safety standard. Without considering these factors, the performance level is lower than a nonseismic designed ceiling, which is not properly designed or constructed. Full article

Since 2016, the frequency and scale of earthquakes have been rapidly increasing in South Korea. In particular, the damage caused by the Gyeongju and Pohang earthquakes has attracted considerable attention since 2017, leading to changes in social insensitivity to safety and the perception of seismic damage to facilities. However, the current risk assessment technology for earthquake-damaged buildings is subjective and inaccurate, as it is based on visual inspection for a limited time. Accordingly, this study focuses on improving the method of analysis of disaster-damaged buildings. To this end, the study analyzes the risk factors of earthquake-damaged buildings by comparing point cloud data using 3D scanning technology with Building Information Modeling (BIM) spatial information, which is based on the existing design information. To apply this technology, existing design information was acquired through BIM modeling of the existing 2D design drawings of Building E in the Daeseong Apartment Complex (located in Heunghae-eup, Pohang City). This study is expected to contribute to improving the efficiency of measurement technology for earthquake-damaged buildings by analyzing old buildings’ BIM-based 3D modeling visualization information without drawing information, and thus improving the accuracy of seismic damage risk measurement by scanning point cloud data. Full article

The earthquake environmental effects (EEEs) around the epicentral area of the Pohang earthquake (M_w-5.4) that occurred on 15 November 2017 have been collected and classified using the Environmental Seismic Intensity Scale (ESI-07 scale) proposed by the International Union for Quaternary Research (INQUA) focus group. The shallow-focus 15 November Pohang earthquake did not produce any surface rupture, but caused extensive secondary environmental effects and damage to life-line structures. This earthquake was one of the most damaging earthquakes during the instrumental seismic era of the Korean Peninsula. The EEEs included extensive liquefaction, ground cracks, ground settlement, localized rockfall, and variation of the water table. The main objective of this paper was to carry forward a comparative assessment of the Pohang earthquake’s intensity based on traditional macroseismic scales and the ESI-07 scale. With that objective, this study will also make a substantial contribution to any future revision of the ESI-07 scale, which mostly comprises case studies from Europe and South America. The comparison of the ESI-07 scale with traditional intensity scales similar to the intensity scale used by the Korean Meteorological Administration for the epicentral areas showed 1–2-degree differences in intensity. Moreover, the ESI scale provided a clearer picture of the intensity around the epicentral area, which is mostly agricultural land with a lack of urban units or buildings. This study urges the integration of the traditional and ESI-07 scale for such small magnitude earthquakes in the Korean Peninsula as well as around the world in future. This will predict seismic intensity more precisely and hence provide a more-effective seismic hazard estimation, particularly in areas of low seismic activity. The present study will also provide a useful and reliable tool for the seismic hazard assessment of similar earthquakes around the study area and land-use planning at a local scale considering the secondary effects. Full article

The practical constitutive model UBCSAND2, which combines two-mobilized planes—a maximum shear stress plane and a horizontal plane within a framework of classical plasticity approach—is used to incorporate shear-induced effects in both loading and unloading as well as principal stress rotation effects. UBCSAND2 was calibrated by capturing cyclic direct simple shear (CDSS) test results of Pohang sand, which was collected from liquefied paddy fields due to the 2017 Pohang earthquake (M_w = 5.4) in South Korea. The model procedure focuses on simple shear condition because it best simulates field conditions under earthquake loading. The calibrated UBCSAND2 model is then used to assess the liquefaction-induced damages that occurred at the quay wall and backfill layer in Youngil-man port near the epicenter of the Pohang earthquake. The numerical results show that liquefaction mostly occurred in silty sand layers, in which the excess pore pressure ratio reached almost one. The estimated displacements of the quay wall and the predicted settlement of reclaimed area obtained from the analysis were in good agreement with those obtained from field measurements. Full article

The purpose of this study is to examine the factors of disaster experience that impact the effectiveness of disaster education on school students (children and teens). Following the magnitude 5.4 Pohang earthquake in 2017, Pohang City Hall conducted a school earthquake disaster education program over a period of four months (August to November) in 2018. Professors and graduate students from the Ulsan National Institute of Science and Technology taught around 5000 middle and high school students, while also conducting surveys. The experiences of the Pohang earthquake were analyzed and divided into cognitive responses and emotional responses. Students who felt activated emotional responses, surprise and fear, but not joy, tended to have more effective educational experiences. On the other hand, unpleasant emotional reactions, such as anger and sadness, had a negative effect on educational effectiveness. The cognitive response, which is perceived intensity in this research, did not impact educational effectiveness significantly. These results imply that the emotional responses of students are more important than their cognitive responses in providing a disaster education program. This means that even though an earthquake may be small in magnitude and may not cause physical damage, we still need to provide immediate disaster education to the children and teens if they are surprised and afraid of future disasters. Full article

Ground motions are used as input for the response history analyses of a structure. However, the number of ground motions recorded at a site located in low-to-moderate seismic regions such as the Korean Peninsula is few. In this case, artificial ground motions need to be used, which can reflect the characteristics of source mechanism, travel path, and site geology. On 15 November, 2017, the Pohang earthquake, with a magnitude of 5.4 and a focal depth of 9 km, occurred near the city of Pohang. This earthquake caused the most significant economic loss among the earthquakes that occurred in the Korean Peninsula. During the Pohang earthquake, valuable ground motions were recorded at stations distributed in the Korean Peninsula. In this study, a ground motion model is proposed based on ground motions recorded during the 2017 Pohang earthquake. The accuracy of the proposed model is verified by comparing measured and simulated ground motions at 111 recording stations. Full article
