Terahertz Applications for Nondestructive Testing

A special issue of Applied Sciences (ISSN 2076-3417). This special issue belongs to the section "Optics and Lasers".

Deadline for manuscript submissions: closed (30 August 2022) | Viewed by 27548

Special Issue Editor


E-Mail Website
Guest Editor
National Physical Laboratory, Hampton Road, Teddington TW11 0LW, UK
Interests: terahertz measurements and metrology; terahertz spectroscopy; terahertz applications; nonlinear optics; terahertz imaging; terahertz communications
Special Issues, Collections and Topics in MDPI journals

Special Issue Information

Dear Colleagues,

Terahertz technologies have reached a level of maturity where they are being increasing adopted for industrial deployment. Nondestructive testing, condition monitoring, and quality control are the primary areas of industrial terahertz applications. This Special Issue on “Terahertz Applications for Nondestructive Testing” is organised in association with the Terahertz Users Group run by the British Institute of Non-Destructive Testing (BINDT) and the International Committee on Non-Destructive Testing (ICNDT). It is an opportunity for providers and developers of THz instrumentation to showcase their technologies to the user community. Equally, it is an opportunity for THz users to bring their needs and challenges to the attention of technology providers.

Dr. Mira Naftaly
Guest Editor

Manuscript Submission Information

Manuscripts should be submitted online at www.mdpi.com by registering and logging in to this website. Once you are registered, click here to go to the submission form. Manuscripts can be submitted until the deadline. All submissions that pass pre-check are peer-reviewed. Accepted papers will be published continuously in the journal (as soon as accepted) and will be listed together on the special issue website. Research articles, review articles as well as short communications are invited. For planned papers, a title and short abstract (about 100 words) can be sent to the Editorial Office for announcement on this website.

Submitted manuscripts should not have been published previously, nor be under consideration for publication elsewhere (except conference proceedings papers). All manuscripts are thoroughly refereed through a single-blind peer-review process. A guide for authors and other relevant information for submission of manuscripts is available on the Instructions for Authors page. Applied Sciences is an international peer-reviewed open access semimonthly journal published by MDPI.

Please visit the Instructions for Authors page before submitting a manuscript. The Article Processing Charge (APC) for publication in this open access journal is 2400 CHF (Swiss Francs). Submitted papers should be well formatted and use good English. Authors may use MDPI's English editing service prior to publication or during author revisions.

Keywords

  • terahertz technologies
  • nondestructive testing
  • condition monitoring
  • quality monitoring

Benefits of Publishing in a Special Issue

  • Ease of navigation: Grouping papers by topic helps scholars navigate broad scope journals more efficiently.
  • Greater discoverability: Special Issues support the reach and impact of scientific research. Articles in Special Issues are more discoverable and cited more frequently.
  • Expansion of research network: Special Issues facilitate connections among authors, fostering scientific collaborations.
  • External promotion: Articles in Special Issues are often promoted through the journal's social media, increasing their visibility.
  • e-Book format: Special Issues with more than 10 articles can be published as dedicated e-books, ensuring wide and rapid dissemination.

Further information on MDPI's Special Issue polices can be found here.

Published Papers (9 papers)

Order results
Result details
Select all
Export citation of selected articles as:

Editorial

Jump to: Research, Review

1 pages, 145 KiB
Editorial
Foreword to the Special Issue on Terahertz Nondestructive Testing
by Robert A. Smith
Appl. Sci. 2021, 11(24), 11724; https://doi.org/10.3390/app112411724 - 10 Dec 2021
Cited by 2 | Viewed by 2005
Abstract
It is my pleasure to introduce this Special Issue on “Terahertz Nondestructive Testing”, one of the most promising new technologies to be applied to non-destructive inspection problems [...] Full article
(This article belongs to the Special Issue Terahertz Applications for Nondestructive Testing)

Research

Jump to: Editorial, Review

11 pages, 1883 KiB
Article
A Terahertz Fast-Sweep Optoelectronic Frequency-Domain Spectrometer: Calibration, Performance Tests, and Comparison with TDS and FDS
by Janis Kutz, Lars Liebermeister, Nico Vieweg, Konstantin Wenzel, Robert Kohlhaas and Mira Naftaly
Appl. Sci. 2022, 12(16), 8257; https://doi.org/10.3390/app12168257 - 18 Aug 2022
Cited by 10 | Viewed by 1680
Abstract
We report calibration and performance tests of a terahertz fast-sweep optoelectronic frequency-domain spectrometer designed for industrial applications, aimed at quantifying its performance specifications and demonstrating its suitability for envisaged usage. The frequency scale is calibrated using atmospheric water vapour lines and a silicon [...] Read more.
We report calibration and performance tests of a terahertz fast-sweep optoelectronic frequency-domain spectrometer designed for industrial applications, aimed at quantifying its performance specifications and demonstrating its suitability for envisaged usage. The frequency scale is calibrated using atmospheric water vapour lines and a silicon wafer etalon; the amplitude linearity is verified using a set of silicon plates. Instrument performance is tested by measuring transmission properties of a variety of representative samples and comparing with a time-domain spectrometer and a frequency-domain spectrometer. Full article
(This article belongs to the Special Issue Terahertz Applications for Nondestructive Testing)
Show Figures

Figure 1

9 pages, 12853 KiB
Article
Kilohertz Pixel-Rate Multilayer Terahertz Imaging of Subwavelength Coatings
by Daniel Molter, Kim-Sophie Ellenberger, Jens Klier, Stefan Duran, Joachim Jonuscheit, Georg von Freymann, Nico Vieweg and Anselm Deninger
Appl. Sci. 2022, 12(10), 4964; https://doi.org/10.3390/app12104964 - 13 May 2022
Cited by 11 | Viewed by 2170
Abstract
The acquisition speed of terahertz time-domain spectroscopy systems has undergone a significant improvement in recent years. With the development of dual-laser-based sampling techniques such as ASOPS or ECOPS, waveform acquisition rates in the kilohertz range have become feasible. Here, we present measurements of [...] Read more.
The acquisition speed of terahertz time-domain spectroscopy systems has undergone a significant improvement in recent years. With the development of dual-laser-based sampling techniques such as ASOPS or ECOPS, waveform acquisition rates in the kilohertz range have become feasible. Here, we present measurements of sub-wavelength layers in multilayer systems at a rate of 1.6 kHz, where the individual layer thicknesses are analyzed in real time. For demonstration, we image layers on metallic and non-metallic disks with a 300 mm diameter, acquiring 240,000 pixels in only 2.5 min. By combining a rotation of the samples with a linear translation of the measurement head, we maximize the measurement yield. Owing to a “single-shot” (625 µs) dynamic range of 40 dB and a bandwidth above 3 THz of the ECOPS system, we achieve sub-micron repeatability for each layer. Full article
(This article belongs to the Special Issue Terahertz Applications for Nondestructive Testing)
Show Figures

Figure 1

18 pages, 3347 KiB
Article
THz Time-Domain Ellipsometer for Material Characterization and Paint Quality Control with More Than 5 THz Bandwidth
by Helge Ketelsen, Rüdiger Mästle, Lars Liebermeister, Robert Kohlhaas and Björn Globisch
Appl. Sci. 2022, 12(8), 3744; https://doi.org/10.3390/app12083744 - 8 Apr 2022
Cited by 10 | Viewed by 2679
Abstract
Quality control of car body paint in the automotive industry is a promising industrial application of terahertz technology. Terahertz time-domain spectroscopy in reflection geometry enables accurate, fast, and nondestructive measurement of individual layer thicknesses of multi-layer coatings. For high precision thickness measurements, the [...] Read more.
Quality control of car body paint in the automotive industry is a promising industrial application of terahertz technology. Terahertz time-domain spectroscopy in reflection geometry enables accurate, fast, and nondestructive measurement of individual layer thicknesses of multi-layer coatings. For high precision thickness measurements, the frequency dependent complex refractive index of all layers must be calibrated very accurately. THz time-domain ellipsometry is self-referencing and provides reliable, frequency resolved material properties with high signal-to-noise ratio. The method is characterized by a high sensitivity to optical material properties and layer thicknesses. We present characterization results in the frequency range 0.1–6 THz for typical automotive paints and different substrates such as polypropylene (PP), which features a high material anisotropy. We demonstrate that the broadband material properties derived from ellipsometry allow for inline thickness measurements of multi-layer car body paints with high accuracy. Full article
(This article belongs to the Special Issue Terahertz Applications for Nondestructive Testing)
Show Figures

Figure 1

14 pages, 1153 KiB
Article
Polymer Pellet Fabrication for Accurate THz-TDS Measurements
by Keir N. Murphy, Mira Naftaly, Alison Nordon and Daniel Markl
Appl. Sci. 2022, 12(7), 3475; https://doi.org/10.3390/app12073475 - 29 Mar 2022
Cited by 12 | Viewed by 2925
Abstract
We investigate fabrication of compacts using polytetrafluoroethylene (PTFE) and polyethylene (PE), and the effect of compaction conditions on their terahertz transmission properties. The conditions used to fabricate compressed powder samples for terahertz time-domain spectroscopy (THz-TDS) can impact the accuracy of the measurements and [...] Read more.
We investigate fabrication of compacts using polytetrafluoroethylene (PTFE) and polyethylene (PE), and the effect of compaction conditions on their terahertz transmission properties. The conditions used to fabricate compressed powder samples for terahertz time-domain spectroscopy (THz-TDS) can impact the accuracy of the measurements and hence the interpretation of results. This study investigated the effect of compaction conditions on the accuracy of the THz-TDS analysis. Two polymers that are commonly used as matrix materials in terahertz spectroscopy studies were explored using a compaction simulator and a hydraulic press for sample preparation. THz-TDS was used to determine the refractive index and loss coefficient to compare the powder compacts (pellets) to the values of solid material. Sample porosity, axial relaxation and tensile strength were measured to assess the material’s suitability for terahertz spectroscopy. It was found that PTFE is the preferable material for creating THz-TDS samples due to its low porosity and high tensile strength. PE was found to show significant porosity at all compaction pressures, making it an unsuitable material for the accurate determination of optical parameters from THz-TDS spectroscopy measurements. The larger particle sizes of PE resulted in compacts that exhibited significantly lower tensile strength than those made from PTFE making handling and storage difficult. Full article
(This article belongs to the Special Issue Terahertz Applications for Nondestructive Testing)
Show Figures

Figure 1

11 pages, 3414 KiB
Article
Non-Destructive Porosity Measurements of 3D Printed Polymer by Terahertz Time-Domain Spectroscopy
by Mira Naftaly, Gian Savvides, Fawwaz Alshareef, Patrick Flanigan, GianLuc Lui, Marian Florescu and Ruth Ann Mullen
Appl. Sci. 2022, 12(2), 927; https://doi.org/10.3390/app12020927 - 17 Jan 2022
Cited by 7 | Viewed by 2765
Abstract
The porosity and inhomogeneity of 3D printed polymer samples were examined using terahertz time-domain spectroscopy, and the effects of 3D printer settings were analysed. A set of PETG samples were 3D printed by systematically varying the printer parameters, including layer thickness, nozzle diameter, [...] Read more.
The porosity and inhomogeneity of 3D printed polymer samples were examined using terahertz time-domain spectroscopy, and the effects of 3D printer settings were analysed. A set of PETG samples were 3D printed by systematically varying the printer parameters, including layer thickness, nozzle diameter, filament (line) thickness, extrusion, and printing pattern. Their effective refractive indices and loss coefficients were measured and compared with those of solid PETG. Porosity was calculated from the refractive index. A diffraction feature was observed in the loss spectrum of all 3D printed samples and was used as an indication of inhomogeneity. A “sweet spot” of printer settings was found, where porosity and inhomogeneity were minimised. Full article
(This article belongs to the Special Issue Terahertz Applications for Nondestructive Testing)
Show Figures

Figure 1

7 pages, 1982 KiB
Article
Nondestructive Tomographic Imaging of Rust with Rapid THz Time-Domain Spectroscopy
by Hwan Sik Kim, Seung Yeob Baik, Joong Wook Lee, Jangsun Kim and Yeong Hwan Ahn
Appl. Sci. 2021, 11(22), 10594; https://doi.org/10.3390/app112210594 - 11 Nov 2021
Cited by 8 | Viewed by 2173
Abstract
In this study, we developed a rapid nondestructive tool for testing rust spread in a metal covered by a paint layer by using a THz time-domain spectroscopy system at a speed of 100 Hz/pixel. Time-of-flight imaging helps identify rust formation by exclusively obtaining [...] Read more.
In this study, we developed a rapid nondestructive tool for testing rust spread in a metal covered by a paint layer by using a THz time-domain spectroscopy system at a speed of 100 Hz/pixel. Time-of-flight imaging helps identify rust formation by exclusively obtaining the reflection from the steel below the paint surface. The use of frequency-selective imaging allows us to manipulate the contrast in rust imaging. Higher contrast is generally obtained when monitoring using the higher frequency component. In addition, we monitored the spread of rust in a steel plate under the influence of two different chemical solutions: NaCl and acid. We found that in the early stages, the decrease in THz reflection was governed by the high-frequency components due to the formation of lepidocrocite, whereas the low-frequency component develops as the proportion of hematite increases with time. Full article
(This article belongs to the Special Issue Terahertz Applications for Nondestructive Testing)
Show Figures

Figure 1

Review

Jump to: Editorial, Research

18 pages, 1846 KiB
Review
Selected Applications of Terahertz Pulses in Medicine and Industry
by Philip F. Taday, Michael Pepper and Donald D. Arnone
Appl. Sci. 2022, 12(12), 6169; https://doi.org/10.3390/app12126169 - 17 Jun 2022
Cited by 10 | Viewed by 3484
Abstract
This article contains a brief summary of areas where terahertz technology is making an impact in research and industrial applications. We cover some of its uses in the pharmaceutical setting, where both imaging and spectroscopy play important roles. Medical applications are also being [...] Read more.
This article contains a brief summary of areas where terahertz technology is making an impact in research and industrial applications. We cover some of its uses in the pharmaceutical setting, where both imaging and spectroscopy play important roles. Medical applications are also being pursued in many research laboratories, primarily for imaging purposes and following on from the first results just over 20 years ago. The three-dimensional imaging capability of pulsed terahertz allows for the observation of tumours below the surface of tissue, such as basal cell carcinoma of skin. The recent use of the technology in studies of cultural heritage has shown to increase our understanding of the past. The power of terahertz is exemplified by the discussion on its importance in different industries, such as semiconductor circuit manufacturing and automotive assembly. Full article
(This article belongs to the Special Issue Terahertz Applications for Nondestructive Testing)
Show Figures

Figure 1

11 pages, 2735 KiB
Review
An Overview of Terahertz Imaging with Resonant Tunneling Diodes
by Jue Wang, Mira Naftaly and Edward Wasige
Appl. Sci. 2022, 12(8), 3822; https://doi.org/10.3390/app12083822 - 10 Apr 2022
Cited by 15 | Viewed by 4327
Abstract
Terahertz (THz) imaging is a rapidly growing application motivated by industrial demands including harmless (non-ionizing) security imaging, multilayer paint quality control within the automotive industry, insulating foam non-invasive testing in aerospace, and biomedical diagnostics. One of the key components in the imaging system [...] Read more.
Terahertz (THz) imaging is a rapidly growing application motivated by industrial demands including harmless (non-ionizing) security imaging, multilayer paint quality control within the automotive industry, insulating foam non-invasive testing in aerospace, and biomedical diagnostics. One of the key components in the imaging system is the source and detector. This paper gives a brief overview of room temperature THz transceiver technology for imaging applications based on the emerging resonant tunneling diode (RTD) devices. The reported results demonstrate that RTD technology is a very promising candidate to realize compact, low-cost THz imaging systems. Full article
(This article belongs to the Special Issue Terahertz Applications for Nondestructive Testing)
Show Figures

Figure 1
