Open AccessArticle
Contamination of Brush Seals by Oil and Salt and Its Impact on Rubbing and Hysteresis Behaviour
Int. J. Turbomach. Propuls. Power 2019, 4(4), 40; https://doi.org/10.3390/ijtpp4040040 - 11 Dec 2019
Viewed by 113
Abstract
The literature already contains some experimental, analytical and numerical investigations on the rubbing and hysteresis behaviour of brush seals. What the investigations have in common is that they were carried out with new and uncontaminated seals, or that such a condition was assumed. [...] Read more.
The literature already contains some experimental, analytical and numerical investigations on the rubbing and hysteresis behaviour of brush seals. What the investigations have in common is that they were carried out with new and uncontaminated seals, or that such a condition was assumed. The influence of contamination has not been explicitly investigated yet. Particularly in stationary gas and steam turbines, foreign substances can accumulate on and in the bristle package during steady-state operation. In the case of a rubbing event with a contaminated brush seal, e.g., during shutdown of the machine, the process is not expected to be comparable to that assumed in the presence of a new, uncontaminated seal. The present paper is dedicated to the question of the influence of contamination on the total frictional power loss generated during rubbing and the distribution of heat fluxes in friction contact. For this purpose, rub tests with two seals were carried out on the brush seal test rig of the Institute of Thermal Turbomachinery (ITS) in new conditions. Subsequently, the sealing packages were contaminated with oil or a salt mixture. After the treatment, the rub tests were repeated and compared with the previous tests. In addition, stiffness measurements were used to assess the degree of contamination. A strong influence on the rubbing behaviour by the contamination was detected. Contamination causes the flexibility of the bristle package to be greatly reduced. As a result, especially at the beginning of the first measurements, the total power losses and rotor heat inputs are strongly increased. This flexibility is partly regained in the course of the measurements. As expected, contamination also influences the hysteresis behaviour of the seal. A highly increased leakage rate after rubbing could be observed, because the bristles remained close to their deflected positions. In the case of the salted seal, however, an improvement in the leakage performance could be observed after several repeat tests. Full article
Open AccessArticle
Uncoupled CFD-FEA Methods for the Thermo-Structural Analysis of Turbochargers
Int. J. Turbomach. Propuls. Power 2019, 4(4), 39; https://doi.org/10.3390/ijtpp4040039 - 28 Nov 2019
Viewed by 144
Abstract
In turbocharger design, the accurate determination of thermally induced stresses is of particular importance for life cycle predictions. An accurate, transient, thermal finite element analysis (FEA) of turbocharger components requires transient conjugate heat transfer (CHT) analysis. However, due to the vastly different timescales [...] Read more.
In turbocharger design, the accurate determination of thermally induced stresses is of particular importance for life cycle predictions. An accurate, transient, thermal finite element analysis (FEA) of turbocharger components requires transient conjugate heat transfer (CHT) analysis. However, due to the vastly different timescales of the heat transfer mechanisms in fluid and in solid states, unsteady CHT simulations are burdened by high computational costs. Hence, for design iterations, uncoupled CFD and FEA approaches are needed. The quality of the uncoupled thermal analysis depends on the local heat transfer coefficients (HTC) and reference fluid temperatures. In this paper, multiple CFD-FEA methods known from literature are implemented in a numerical model of a turbocharger. In order to describe the heat transfer and thermal boundary layer of the fluid, different definitions of heat transfer coefficients and reference fluid temperatures are investigated with regard to calculation time and accuracy. For the transient simulation of a long heating process, the combination of the CFD-FEA methods with the interpolation FEA approach is examined. Additionally, a structural-mechanical analysis is conducted. The results of the developed methods are evaluated against experimental data and the results of the extensive unsteady CHT numerical method. Full article
Show Figures

Graphical abstract

Open AccessArticle
Simulation of a Radial Pump Fast Startup and Analysis of the Loop Response Using a Transient 1D Mean Stream Line Based Model
Int. J. Turbomach. Propuls. Power 2019, 4(4), 38; https://doi.org/10.3390/ijtpp4040038 - 26 Nov 2019
Viewed by 156
Abstract
A predictive transient two-phase flow rotodynamic pump model has been developed in the Code for Analysis of THermalhydraulics during an Accident of Reactor and safety Evaluation (CATHARE-3). Flow inside parts of the pump (suction, impeller, diffuser and volute) is computed according to a [...] Read more.
A predictive transient two-phase flow rotodynamic pump model has been developed in the Code for Analysis of THermalhydraulics during an Accident of Reactor and safety Evaluation (CATHARE-3). Flow inside parts of the pump (suction, impeller, diffuser and volute) is computed according to a one-dimensional discretisation following a mean flow path. Transient governing equations of the model are solved using an implicit resolution method and integrated along the curvilinear abscissa of the element. This model has been previously qualified at the component scale by comparison to an existing experimental database. The present study aims at extending the validation at the system scale: a whole experimental test loop is modelled. The ability of the transient pump model to predict flow rate, head and torque as a function of time during a 1-s pump fast start-up is evaluated. The transient evolution of the pressure upstream and downstream from the centrifugal pump is well predicted by the simulation compared to the measurements. Local quantities such as pressure and velocity inside elements of the circuit are analysed. In the considered case, inertial effects of the global circuit are dominant when compared to pump inertial effects due to the high characteristic lengths of the pipes. The main perspective of this work consists in the simulation of similar pump transients, in cavitating conditions. Full article
Show Figures

Figure 1

Open AccessArticle
On the Influence of High Turbulence on the Convective Heat Flux on the High-Pressure Turbine Vane LS89
Int. J. Turbomach. Propuls. Power 2019, 4(4), 37; https://doi.org/10.3390/ijtpp4040037 - 08 Nov 2019
Viewed by 218
Abstract
High-pressure turbine vanes and blades are subjected to a turbulent combustor flow affecting the heat transfer and boundary layer transition, hence, the temperature distribution. The accurate prediction of the temperature distribution is crucial for a reliable design and cooling implementation. Engine-representative measurements are [...] Read more.
High-pressure turbine vanes and blades are subjected to a turbulent combustor flow affecting the heat transfer and boundary layer transition, hence, the temperature distribution. The accurate prediction of the temperature distribution is crucial for a reliable design and cooling implementation. Engine-representative measurements are hence mandatory for improving design tools. Recently, convective heat transfer measurements were conducted on a high-pressure turbine inlet guide vane (VKI LS89 airfoil) in the Isentropic Compression Tube (CT-2) facility at the von Karman Institute. This contribution focuses on the effect of high freestream turbulence generated by a new turbulence grid allowing a range of turbulence intensities in excess of 10% with representative length scales of the order of 1–2 cm. Three cases with varying turbulence levels are discussed in this paper. The different flow conditions are exit isentropic Mach numbers of 0.70–0.97, Reynolds numbers of 0.53 × 106 and 1.15 × 106 and a constant temperature ratio equal to 1.36. The heat transfer distributions along the vane suction side indicate a clear link between boundary layer transition and the stream-wise pressure gradients even at high levels of freestream turbulence intensity. Differences are put in evidence in the dynamics of the transition development. Future developments will focus also on the contribution of the other flow parameters under high turbulence. Heat transfer predictions from the boundary layer code TEXSTAN and Reynolds-Averaged Navier–Stokes code elsA (ensemble logiciel pour la simulation en Aérodynamique) are additionally compared to the experiments. Inherent difficulties associated with high turbulence modelling are clear from this early numerical work. Full article
Show Figures

Graphical abstract

Open AccessArticle
A Gas Turbine Cooled-Stage Expansion Model for the Simulation of Blade Cooling Effects on Cycle Performance
Int. J. Turbomach. Propuls. Power 2019, 4(4), 36; https://doi.org/10.3390/ijtpp4040036 - 08 Nov 2019
Viewed by 146
Abstract
Modern gas turbine firing temperatures (1500–2000 K) are well beyond the maximum allowable blade material temperatures. Continuous safe operation is made possible by cooling the HP turbine first stages, nozzle vanes and rotor blades, with a portion of the compressor discharge air, a [...] Read more.
Modern gas turbine firing temperatures (1500–2000 K) are well beyond the maximum allowable blade material temperatures. Continuous safe operation is made possible by cooling the HP turbine first stages, nozzle vanes and rotor blades, with a portion of the compressor discharge air, a practice that induces a penalty on the thermal efficiency cycle. Therefore, a current issue is to investigate the real advantage, technical and economical, of raising maximum temperatures much further beyond current values. In this paper, process simulations of a gas turbine are performed to assess HP turbine first-stage cooling effects on cycle performance. A new simplified and properly streamlined model is proposed for the non-adiabatic expansion of the hot gas mixed with the cooling air within the blade passage, which allows for a comparison of several cycle configurations at different turbine inlet temperatures (TIT) and total turbine expansion ratio (PR) with a realistically acceptable degree of approximation. The calculations suggest that, at a given PR, the TIT can be increased in order to reach a higher cycle efficiency up to a limit imposed by the required amount and temperature of the cooling air. Beyond this limit, no significant gains in thermal efficiency are obtained by adopting higher PR and/or increasing the TIT, so that it is convenient in terms of cycle performance to design at a lower rather than higher PR. The small penalty on cycle efficiency is compensated by the lower plant cost. The results of our model agree with those of some previous and much more complex and computationally expensive studies, so that the novelty of this paper lies in the original method adopted on which the proposed model is based, and in the fast, accurate, and low resource intensity of the corresponding numerical procedure, all advantages that can be crucial for industry needs. The presented analysis is purely thermodynamic and it includes no investigation on the effects of the different configurations on plant costs. Therefore, performing a thermo-economic analysis of the air-cooled gas turbine power plant is the next logical step. Full article
Show Figures

Figure 1

Open AccessArticle
Metamodel-Assisted Multidisciplinary Design Optimization of a Radial Compressor
Int. J. Turbomach. Propuls. Power 2019, 4(4), 35; https://doi.org/10.3390/ijtpp4040035 - 03 Nov 2019
Viewed by 311
Abstract
Kriging is increasingly used in metamodel-assisted design optimization. For expensive simulations; however, one can afford only a few samples to build the Kriging model, which consequently lacks prediction accuracy. We propose a bounded Kriging able to handle optimization problems with a small initial [...] Read more.
Kriging is increasingly used in metamodel-assisted design optimization. For expensive simulations; however, one can afford only a few samples to build the Kriging model, which consequently lacks prediction accuracy. We propose a bounded Kriging able to handle optimization problems with a small initial database. During the optimization, the proposed Kriging suggests designs close to database samples and finds optimal designs while staying in a feasible region (with respect to mesh and CFD convergence). The bounded Kriging is applied along with the ordinary Kriging to a multidisciplinary design optimization of a radial compressor. The shape of the compressor blades is optimized by considering the aero performance at different operating points and the mechanical stresses. The objective of the optimization is to maximize the efficiency at two operating points, while constraints are imposed on the maximum stress level in the material, the choke mass flow, the pressure ratio and the momentum of inertia of the impeller. While ordinary Kriging stopped prematurely because of many failing design evaluations, the bounded Kriging satisfied all constraints and reached an improvement of 2.59% in efficiency over the baseline design that does not comply with any constraints. The bounded Kriging covers a special need for robust methods in optimization able to deal with challenging geometries and a small database, which is the case for most industrial design optimizations. Full article
Show Figures

Figure 1

Open AccessArticle
Surge Limit Prediction for Automotive Air-Charged Systems
Int. J. Turbomach. Propuls. Power 2019, 4(4), 34; https://doi.org/10.3390/ijtpp4040034 - 01 Oct 2019
Viewed by 309
Abstract
Compressor surge has been investigated and predicted since the early days of turbomachinery research. Experimental testing of turbomachinery applications is still needed to determine whether stable compressor operation is possible in the expected application regime. Measuring compressor maps and operating ranges on hot [...] Read more.
Compressor surge has been investigated and predicted since the early days of turbomachinery research. Experimental testing of turbomachinery applications is still needed to determine whether stable compressor operation is possible in the expected application regime. Measuring compressor maps and operating ranges on hot gas test stands is common. The test benches are designed and optimized to ensure ideal inflow and outflow conditions as well as low measurement uncertainty. Compressor maps are used to match turbocharger and application. However, a shift in surge limit, caused by the piping system or application, can only be adequately addressed with full engine tests. Ideal measurements use the corresponding piston engine in the charged-air system. This can only take place in the development process, when surge detection is unfavorable from an economic perspective. The surge model for turbochargers presented here is an extension of the Greitzer’s surge model, which considers the effect of inlet throttling. Application components, such as air filters, pipe elbows and flow straighteners, reduce pressure in front of the compressor and flow conditions might differ from those in laboratory testing. Experimental results gathered from the hot gas test stand at TU Darmstadt indicate strong variation in surge limit, influenced by inlet throttling. An extension to the surge model is developed to explain the observed phenomena. The model was validated using extensive experimental variations and matches the experienced surge limit shift. Additional measurements with a piston engine downstream of the turbocharger demonstrated the validity of the surge model. The results also show that surge is a system-dependent phenomenon, influenced by compressor aerodynamics and boundary conditions. Full article
Show Figures

Figure 1

Open AccessArticle
Turbine Cascades of Last Stage Blades for Wide Range of Operating Conditions
Int. J. Turbomach. Propuls. Power 2019, 4(4), 33; https://doi.org/10.3390/ijtpp4040033 - 24 Sep 2019
Cited by 1 | Viewed by 304
Abstract
Recent trends in the electric energy market such as biomass, waste incineration or combined cycle power plants require innovative solutions in steam turbine design. Variable operating conditions cause significant changes in flow field surrounding the steam turbine last stage blades. Therefore, the enlargement [...] Read more.
Recent trends in the electric energy market such as biomass, waste incineration or combined cycle power plants require innovative solutions in steam turbine design. Variable operating conditions cause significant changes in flow field surrounding the steam turbine last stage blades. Therefore, the enlargement of operating range for last stage blades presents new challenges in design of turbine cascades. Several turbine cascades were designed and analyzed by commercial and in-house software of CTU Prague. Selected profiles were experimentally validated in the high-speed wind tunnel for 2D cascade measurements of the Institute of Thermomechanics of the Czech Academy of Sciences which is equipped by an adjustable supersonic inlet nozzle, perforated inserts at side walls and adjustable perforated tailboard. Comparisons are presented of numerical results with optical and pneumatic measurements for a wide range of inlet and outlet Mach numbers for optimized hub and tip profile cascades. Full article
Show Figures

Figure 1
