A Gas Turbine Cooled-Stage Expansion Model for the Simulation of Blade Cooling Effects on Cycle Performance

Department of Mechanical and Aerospace Engineering, University of Roma Sapienza, 00185 Roma, Italy
*
Author to whom correspondence should be addressed.
Int. J. Turbomach. Propuls. Power 2019, 4(4), 36; https://doi.org/10.3390/ijtpp4040036
Received: 11 June 2019 / Revised: 22 September 2019 / Accepted: 25 September 2019 / Published: 8 November 2019
Modern gas turbine firing temperatures (1500–2000 K) are well beyond the maximum allowable blade material temperatures. Continuous safe operation is made possible by cooling the HP turbine first stages, nozzle vanes and rotor blades, with a portion of the compressor discharge air, a practice that induces a penalty on the thermal efficiency cycle. Therefore, a current issue is to investigate the real advantage, technical and economical, of raising maximum temperatures much further beyond current values. In this paper, process simulations of a gas turbine are performed to assess HP turbine first-stage cooling effects on cycle performance. A new simplified and properly streamlined model is proposed for the non-adiabatic expansion of the hot gas mixed with the cooling air within the blade passage, which allows for a comparison of several cycle configurations at different turbine inlet temperatures (TIT) and total turbine expansion ratio (PR) with a realistically acceptable degree of approximation. The calculations suggest that, at a given PR, the TIT can be increased in order to reach a higher cycle efficiency up to a limit imposed by the required amount and temperature of the cooling air. Beyond this limit, no significant gains in thermal efficiency are obtained by adopting higher PR and/or increasing the TIT, so that it is convenient in terms of cycle performance to design at a lower rather than higher PR. The small penalty on cycle efficiency is compensated by the lower plant cost. The results of our model agree with those of some previous and much more complex and computationally expensive studies, so that the novelty of this paper lies in the original method adopted on which the proposed model is based, and in the fast, accurate, and low resource intensity of the corresponding numerical procedure, all advantages that can be crucial for industry needs. The presented analysis is purely thermodynamic and it includes no investigation on the effects of the different configurations on plant costs. Therefore, performing a thermo-economic analysis of the air-cooled gas turbine power plant is the next logical step. View Full-Text
Keywords: blade cooling; gas turbine efficiency; TIT-expansion ratio for optimal efficiency blade cooling; gas turbine efficiency; TIT-expansion ratio for optimal efficiency
Show Figures

Figure 1

MDPI and ACS Style

Masci, R.; Sciubba, E. A Gas Turbine Cooled-Stage Expansion Model for the Simulation of Blade Cooling Effects on Cycle Performance. Int. J. Turbomach. Propuls. Power 2019, 4, 36.
