Open AccessArticle

The Development of Electroconvection at the Surface of a Heterogeneous Cation-Exchange Membrane Modified with Perfluorosulfonic Acid Polymer Film Containing Titanium Oxide

Department of Physical Chemistry, Kuban State University, 149 Stavropolskaya st., 350040 Krasnodar, Russia
*
Author to whom correspondence should be addressed.
Membranes 2020, 10(6), 125; https://doi.org/10.3390/membranes10060125
Received: 12 May 2020 / Revised: 14 June 2020 / Accepted: 15 June 2020 / Published: 17 June 2020
(This article belongs to the Special Issue Fouling and Anti-Fouling of Ion-Exchange Membranes)
One way to enhance mass transfer and reduce fouling in wastewater electrodialysis is stimulation of electroconvective mixing of the solution adjoining membranes by modifying their surfaces. Several samples were prepared by casting the perfluorosulfonic acid (PFSA) polymer film doped with TiO2 nanoparticles onto the surface of the heterogeneous cation-exchange membrane MK-40. It is found that changes in surface characteristics conditioned by such modification lead to an increase in the limiting current density due to the stimulation of electroconvection, which develops according to the mechanism of electroosmosis of the first kind. The greatest increase in the current compared to the pristine membrane can be obtained by modification with the film being 20 μm thick and containing 3 wt% of TiO2. The sample containing 6 wt% of TiO2 provides higher mass transfer in overlimiting current modes due to the development of nonequilibrium electroconvection. A 1.5-fold increase in the thickness of the modifying film reduces the positive effect of introducing TiO2 nanoparticles due to (1) partial shielding of the nanoparticles on the surface of the modified membrane; (2) a decrease in the tangential component of the electric force, which affects the development of electroconvection. View Full-Text
Keywords: fouling; ion-exchange membrane; surface modification; electroconvection; voltammetry; chronopotentiometry; impedance spectroscopy fouling; ion-exchange membrane; surface modification; electroconvection; voltammetry; chronopotentiometry; impedance spectroscopy
Show Figures

Figure 1

MDPI and ACS Style

Gil, V.; Porozhnyy, M.; Rybalkina, O.; Butylskii, D.; Pismenskaya, N. The Development of Electroconvection at the Surface of a Heterogeneous Cation-Exchange Membrane Modified with Perfluorosulfonic Acid Polymer Film Containing Titanium Oxide. Membranes 2020, 10, 125.
