Taxonomic Review of the Genus Caloptilia Hübner, 1825 (Lepidoptera: Gracillariidae) with Descriptions of Three New Species and Seven Newly Recorded Species from Korea

by
Da-Som Kim
1,
Young-Min Shin
2,
Ji-Young Lee
3 and
Bong-Kyu Byun
3,*
1
Basic Science Division, National Science Museum of Korea, Daejeon 34143, Republic of Korea
2
Division of Forest Biodiversity, Korea National Arboretum, Pocheon 11816, Republic of Korea
3
Department of Biological Science and Biotechnology, Hannam University, Daejeon 34054, Republic of Korea
*
Author to whom correspondence should be addressed.
Insects 2022, 13(12), 1107; https://doi.org/10.3390/insects13121107
Submission received: 26 October 2022 / Revised: 21 November 2022 / Accepted: 24 November 2022 / Published: 30 November 2022
(This article belongs to the Special Issue Systematics, Ecology and Evolution of Lepidoptera)
Browse Figures
Review Reports Versions Notes

Abstract

:

Simple Summary

Caloptilia is a genus of the family Gracillariidae, one of the most diverse groups of Microlepidoptera, with more than 2000 described species worldwide. The species of this family are known as leafminers because they mine into the leaves of various host plants. Caloptilia has been poorly studied in Korea, with 50% fewer known species than those in the neighboring countries, viz., China, Russia, and Japan. In this study, we aimed to clarify fauna of the genus Caloptilia in Korea by describing three new species and seven newly recorded species in the country. In addition, we list all known species from Korea, along with images of the adult specimens and genitalia.

Abstract

In this study, 29 species of Caloptilia Hübner, 1825, belonging to the family Gracillariidae, were recognized in Korea. Among these, three species, i.e., C. purpureus sp. nov., C. koreana sp. nov., and C. xanthos sp. nov., are described as new to science. In addition, seven species of this genus are reported for the first time in Korea. All known species were enumerated, based on their available information. Adult specimens and genitalia of the new and newly recorded species were examined and described using all available information.

1. Introduction

The family Gracillariidae is one of the most diverse groups of Microlepidoptera, with more than 2000 described species belonging to 112 genera worldwide [1]. The genus Caloptilia is the second largest group in the family, comprising more than 450 species worldwide [1]. They are cosmopolitan in distribution, with 180 species, ca. 40% of the total known species, found in the Palearctic region. They can be distinguished from the other genera based on the following observations (i) adults in a resting posture raising their head upward; (ii) abdomens (A) with a membranous tergite and sclerotized sternite on A8; (iii) females with a pair of signa; (iv) final instar larvae with leaf rolling behavior that pupate within the leaves of host plants [2,3].
This study is part of a larger study on this family that was recently conducted in Korea to update the faunistic information for 91 species of 25 genera under seven subfamilies [4,5,6,7,8,9,10,11,12,13,14,15,16,17,18].
Among them, the genus Caloptilia was not well studied until Shin et al. [5] enumerated 19 species from Korea, with four newly reported species. Of them, two species, C. fidella and C. illicii, were misidentified as Gracillaria albicapitata and C. sapporella, respectively. Recently, Lee and Jeun (2022) [16] reported two newly recorded species: C. pyrrhaspis (Meyrick) and C. syrphetias (Meyrick). To date, 21 species of this genus have been reported in this country.
In this study, a more intense investigation of the genus Caloptilia was conducted, using the results of an examination of the big collection from the 1970s. We found three new species, C. purpureus sp. nov., C. koreana sp. nov., and C. xanthos sp. nov., and recorded seven species for the first time in Korea. These include C. acericola Kumata, 1966 [19], C. celtidis Kumata, 1982 [2], C. dentata Liu and Yuan, 1990 [20], C. kadsurae Kumata, 1966 [18], C. monticola Kumata, 1966 [18], C. recitata (Meyrick, 1918) [21], and C. soyella (van Deventer, 1904) [22]. Here, we provide a description of these three new species along with the taxonomic arrangements and annotated checklist of all known species. In addition, information on collection locality, host plant, and distributional range is provided.

2. Materials and Methods

The specimens examined in this study were deposited at the Systematic Entomology Laboratory of Hannam University, Daejeon, Korea (HNSUEL). Male and female genitalia were dissected and mounted with Euparal solution, following the procedure described by Holloway et al. [23]. Images of the adults were taken using a digital camera (Canon EOS 600D, Canon Inc., Ota, Tokyo, Japan), and images of the genitalia were captured using a digital camera attached to a microscope, LEICA M205C (Leica Microsystems, Wetzlar, Hesse, Germany) and refined using Photoshop CS5 software. Terminology for the genitalia of both sexes was followed after Landry [24].

3. Results

3.1. Description of New Species

3.1.1. Caloptilia purpureus sp. nov. Kim and Byun, 2022 Bora-ga-neun-na-bang

LSID. urn:lsid:zoobank.org:act:7985CE24-A706-4AF9-B8E5-55405021EDAC
Type. Holotype. [KOREA] [JN] 1♂, Mt. Geumo, Dolsan-eup, Yeosu-si, 10 October 2018 (emergence data: 28 October 2018) (leg. UH Heo), gen. slide no. HNUSEL-5592-coll. UH Heo; Paratype. [JN] 1♀, Mt. Geumo, Dolsan-eup, Yeosu-si, 10 October 2018 (emergence data: 1 November 2018) (leg. UH Heo), gen. slide no. HNUSEL-5591-coll. UH Heo.
Diagnosis. This species is similar to C. theivora in appearance, but can be distinguished by the costal margin with narrow yellowish streak after the blotch apically and metallic purple ground color of forewing. In the genitalic structures, the new species is different from the latter by having numerous long setae on apex of valva in male genitalia and two signa on corpus bursae in female genitalia.
Adult (Figure 1a). Forewing length 3.5 mm. Head grayish ochreous and tinged with violet reflection; frons pale yellowish white and face yellow; maxillary palpus yellow with a tiny fuscous spot on the median part; labial palpus yellow with apex fuscous; antenna pale ochreous and scape fuscous. Thorax pale grayish fuscous; fore legs fuscous with whitish tarsus; hind femur yellow with a fuscous median broad band; hind tibia and tarsus pale ochreous.
Forewing ground color grayish fuscous with violet reflection; a triangular goldish yellow blotch, covering nearly half of forewing, extends to wing fold with blackish edges and 2–3 blackish dots on apical margin; a goldish yellow streak begins just after blotch apically, occupying 1/4 of forewing and broader at median without any edges; veins with Sc and R1 close, R3 and R4 very close, M2 stalked with M3. Hindwing is similar to C. koreana.
Male genitalia (Figure 2a). Tegumen ovate with parallel side to apex and as long as vinculum or slightly longer than vinculum. Valva up-curved, elongated, rectangular shape with parallel side from base to 1/3 of valva, dilated on apex, dorsal margin more elongated on apex and apical margin straight; long and slender setae along apical margin to a half of ventral margin, more sparse ventrally, more short and strong setae sparse along the apical margin. Vinculum triangular shape with acute apex. Juxta small and ‘u’ shaped. Aedeagus bar-shaped, apex somewhat rectangular shape, slightly sclerotized and slightly bent inward without any cornuti.
Female genitalia (Figure 3a). Papillae anales moderated, long setae on vertex sparser with a pair of long scales on each, laterally of base; posterior apophyses triangular shaped broadening to base and as long as anterior. Ostium bursae small in opening size; sternum VIII divided into two lateral parts and shot as long as 1/6 of posterior apophyses. Dustus bursae very slender, as long as 2.5 times of corpus bursae and coiled near corpus bursae. Corpus bursae ovate with two signa on median; signa with different size each other, blunt and rather rectangular apex.
Etymology. The specific name is derived from the color of forewing, purple.
Distribution. Korea (endemic, Yeosu-si).
Host plants. Sageretia theezans (L.) Brongn. [Rhamnaceae] in Korea (in this study).
Remarks. This species was reared from Sageretia theezans (L.) Brongn. of the family Rhamnaceae in this study.
The triangular yellow costal blotch of the new species almost the same as C. theivora; however, costal margin with narrow yellowish streak after the blotch apically. In the new species, long setae on apical of valva dense along margin, whereas C. theivora naked at median of apical margin. In female genitalia, there are two signa on corpus bursae in new species, while C. theivora has only a signum.

3.1.2. Caloptilia koreana sp. nov. Kim and Byun, 2022 Han-guk-ga-neun-na-bang

LSID. urn:lsid:zoobank.org:act:EFDBC3D3-71BA-4ED2-9391-28991F5E14A1
Type. Holotype. [KOREA] [GG] 1♀, Lake Yuklim, Gwangneung, 7 September 2017 (leg. Lim, Kim, Lee, Shin, Roh), gen. slide no. HNUSEL-5575-coll. KNAE.
Diagnosis. This species is similar to C. chrysolampra, but can be distinguished by the more extended size of the yellow costal blotch of the forewing and female genitalia with well sclerotized ductus bursae in the new species, whereas they are very slender and membranous in the latter.
Adult (Figure 1b). Forewing length 3 mm in female. Head grayish ochreous and occiput gray with flat and large scales; frons white and face pale yellowish white; maxillary palpus white with a tiny fuscous spot on the first segment laterally; labial palpus silvery white with a tiny fuscous spot laterally and fuscous apically; each segment of antenna grayish fuscous, pale ochreous basally. Thorax grayish with a pale ochreous median line; tegular more darkened to fuscous posteriorly; fore and middle legs fuscous with whitish tarsus; hind legs pale ochreous with tiny fuscous spots apically.
Forewing ground color grayish fuscous, tinged with violet reflection; a yellow dorso-basal streak from base to 1/6 of forewing; large and rounded yellow blotch begins at 1/3 to base and extends to wing fold, the interval between blotch and dorsal margin broadens more apically and tiny blackish dots sparsely on costal margin; venation with R1 arising from before middle, R2 arising from 2/3 of cell, R3, R4 and R5 not close, M2 and M3 stalked, M3 and CuA close near discal end of cell. Hindwing lanceolate and ground color silvery dark gray; vein with Rs reaching to subapex of costa, M1 and M2 form a branch, M3 distant from M2, then close to Cu.
Male genitalia. Unknown.
Female genitalia (Figure 3b). Papillae anales somewhat acute on vertex, short and sclerotized on base; posterior apophyses broaden at base and slightly sclerotized; anterior apophyses as long as posteriores. Lamella postvaginalis with a well sclerotized flap, the flap reversed pot shaped; ostium bursae with same width as ductus bursae.
Ductus bursae strongly sclerotized with many horizontal wrinkles, as long as corpus bursae, slightly curved to small ‘S’ shape and broadened to near the corpus bursae. Corpus bursae ellipse form and slightly sclerotized near ductus bursae with two signa on 1/4 of corpus bausae; signa falciform, somewhat straight, and acute apically.
Etymology. The specific name is derived from the type locality, Korea.
Distribution. Korea (endemic, Gwangneung).
Host plants. Unknown.
Remarks. This species is similar to C. chrysolampra, but can be distinguished by the size of yellow costal blotch of the forewing. The yellow costal blotch of new species extends more to nearly apex, and forewing ground color grayish fuscous. In female genitalia, ductus bursae well sclerotized with a pair of falciform shaped two signa.

3.1.3. Caloptilia xanthos sp. nov. Kim and Byun, 2022 No-rang-jeom-ga-neun-na-bang

LSID. urn:lsid:zoobank.org:act:F542A98A-295C-4BB0-BC8B-96CD6BB15CE4
Type. Holotype. [KOREA] [JN] 1♀, Namseong-ri, Cheonggye-myeon, Muan-gun, 3 July 2019 (leg. BK Byun), gen. slide no. HNUSEL-5602-coll. HNUSEL.
Diagnosis. This species is similar to C. theivora, but can be distinguished by rather long corpus bursae with two signa in female genitalia
Adult (Figure 1c). Forewing length 4 mm. Head covered with pale grayish fuscous. Thorax grayish fuscous with two ochreous lateral line on tegular; legs fuscous and white; middle tarsus white with a fuscous median band. Forewing purplish fuscous with a yellow costal blotch; a yellow costal blotch begins at 1/3 to base and is triangular with very acute apex without edges; venation with R1 arising from 1/3 of cell, R3, R4 and R5 not close, M1 distant from M2+M3 at base, M2 and M3 stalked, M3 and CuA not close. Hindwing lanceolate and ground color silvery dark gray; veins with Rs reaching to apex of costa, M1 and M2 form a branch, M3 distant from M2.
Male genitalia. Unknown.
Female genitalia (Figure 3c). Papillae anales slightly swollen with rounded process on vertex; posterior apophyses as long as anterior and slightly broadened at base. Ostium bursae on a sclerotized ellipse form disc and small in opening size; antrum slightly sclerotized and reduced. Ductus bursae as long as 1.7 times of corpus bursae and slender. Corpus bursae elongated, very long and slender with a lot of minute spinules on whole surface; signa dislocated from each other, well sclerotized and base more elongated to inner side.
Etymology. The specific name is derived from the yellowish patch of forewing.
Distribution. Korea (endemic, Muan-gun).
Host plants. Unknown.
Remarks. This species is similar to C. theivora, but the new species has two signa on corpus bursae of female genitalia, whereas the latter has a signum. This species is similar to the members of the genus Caloptilia in appearance. In the new species, the yellow triangular costal blotch in the forewing is almost the same as C. theivora; however, it can be distinguished by the small yellow spots along the costal margin from the end of blotch to near the subapex, then tinged with yellowish scales toward apex. In female genitalia, there are two singa on corpus bursae, instead of only one sigum in the latter.

3.2. Redescription of New Records

3.2.1. Caloptilia acericola Kumata, 1966 Gin-no-lang-ga-neun-na-bang

Caloptilia acericola Kumata, 1966: 2–3 [19]. TL: Hokkaido, Japan. TD: EIHU (Holotype; Paratypes).
Adult (Figure 4a). Forewing length 5 mm.
Male genitalia (Figure 2b).
Female genitalia (Figure 5a).
Material examined. [GG] 1♀, Korea National Arboretum, Gwangneung, 20 May 2008 (leg. SY Park, BW Lee, SR Kim, DH Kwon), gen. slide no. HNUSEL-5577-coll. KNAE; [GW] 3♂, 2♀, Mt. Odae, 27 May 1991 (leg. BK Byun), gen. slide no. NAK-533, HNUSEL-5603, 5604-coll. HNUSEL; 1♂, Mt. Odaesan, Jinbu-Myeon, Pyeongchang, 20 June 2012 (leg. SY Park, JO Lim, JS Lim), gen. slide no. HNUSEL-5608-coll. KNAE; [CB] 1♂, Mt. Minjuji, Maegok-myeon, Yeongdong-gun, 22 May 2014 (leg. IJ Choi, JW Nam, MH Kim), gen. slide no. HNUSEL-5571-coll. KNAE; 1♂, Namwon-si, Sannae-myeon, Jeongnyeongchi 23 May 2012 (leg. NH Ahn, JJ Park), gen. slide no. HNUSEL 5581-coll. NIBR; [GN] 1♂, Namhae, 1 June 1994 (leg. BK Byun), gen. slide no. HNUSEL-5552-coll. HNUSEL.
Distribution. Korea (new record), Japan, Russia.
Host plants. Acer japonicum Thunb., A. palmatum Thunb., A. pictum Thunb. ex Murray [Sapindaceae] in Japan [1,19]. A. pictum Thunb. ex Murray, A. pseudosieboldianum (Pax) Kom. [Sapindaceae] in Russia [1,25,26].
Remarks. This species has been confused with C. aceris; however, it can be distinguished with the presence of a minute spinule on ductus bursae of female genitalia, which is absent in the latter.

3.2.2. Caloptilia celtidis Kumata, 1982 Huin-mu-nui-ga-neun-na-bang

Caloptilia celtidis Kumata, 1982: 76–79 [2]. TL: Honshu, Japan. TD: EIHU (Holotype); EIHU, BMNH (Paratypes).
Adult (Figure 4b). Forewing length 5 mm. Two forms with aestival and autumnal.
Male genitalia (Figure 2c).
Female genitalia (Figure 5b).
Material examined. [JN] 2♀, Mt. Wangui, Haeryong-myeon, Suncheon-si. 30 July 2016 (emergence date: 10 August 2016), gen. slide no. HNUSEL-5613-coll. UH Heo; 1♀, experiment forest of Seoul University, Gwangyang-si, 13 September 2016 (emergence date: 29 September 2016)-coll. UH Heo; 1♂, Mt. Jogye, Suncheon-si, 4 July 2018 (leg. BK Byun), gen. slide no. HNUSEL-5561-coll. HNUSEL.
Distribution. Korea (new record), China, Hong Kong, Japan.
Host plants. Celtis sinensis Persoon [Cannabaceae] in Korea (in this study). C. sinensis Persoon [Cannabaceae] in China [1,20]. C. jessoensis Koidz., C. sinensis Persoon [Cannabaceae] in Japan [1,2].
Remarks. This species was reared from Celtis sinensis Persoon of the family Cannabaceaee in this study.

3.2.3. Caloptilia dentata Liu & Yuan, 1990 Ne-mo-mu-nui-ga-neun-na-bang

Caloptilia (Caloptilia) dentata Liu & Yuan, 1990: 186 [20]. TL: Beijing, China. TD: IZAS (Holotype; Paratypes).
Adult (Figure 4c). Forewing length 5 mm.
Male genitalia (Figure 2d).
Female genitalia. see Liu & Yuan [20].
Material examined. [JB] 2♂, 1♀, Jangan-ri, Songgwang-myeon, Suncheon-si, 4 July 2018 (leg. BK Byun), gen. slide no. HNUSEL-5504-coll. HNUSEL; 2♀, Seji-myeon, Naju-si, 31 July 2018 (leg. BK Byun)-coll. HNUSEL; [GN] 1♂, Mt. Keum, Namhae, 7 August 1982 (leg. KT Park), gen. slide no. HNUSEL-5473-coll. HNU
Distribution. Korea (new record), China.
Host plants. Acer truncatum Bunge [Sapindaceae] in China [1,20].

3.2.4. Caloptilia kadsurae Kumata, 1966 Nam-o-mi-ja-ga-neun-na-bang

Caloptilia kadsurae Kumata, 1966: 19 [19]. TL: Honshu, Japan. TD: EIHU (Holotype; Paratypes).
Adult (Figure 4d). Forewing length 5.2 mm.
Male genitalia (Figure 2e).
Female genitalia (Figure 5c).
Material examined. [JN] 2♂, Wando Arboretum, Wando, 31 August 2019 (emergence date: 16 September 2019) (leg. UH Heo), gen. slide no. HNUSEL-5593, 5594-coll. UH Heo; [JJ] 1♀, Sanghyo-dong, Seogwipo-si, 24 July 2019 (leg. BK Byun), gen. slide no. HNUSEL-5558-coll. HNUSEL.
Distribution. Korea (new record), Japan.
Host plants. Kadsura japonica Dunal [Magnoliaceae] in Korea (in this study). K. japonica Dunal [Magnoliaceae] in Japan [1,19].
Remarks. This species was reared from K. japonica Dunal of the family Magnoliaceae in this study.

3.2.5. Caloptilia monticola Kumata, 1966 Oe-ban-jeom-ga-neun-na-bang

Caloptilia monticola Kumata, 1966: 8 [19]. TL: Honshu, Japan. TD: EIHU (Holotype; Paratypes).
Adult (Figure 4e). Forewing length 6 mm.
Male genitalia. see Kumata 1966 [19].
Female genitalia (Figure 5d).
Material examined. [GB] 1♀, Mt. Tonggo, Geumgangsong-myeon, Uljin-gun, 23 June 2017 (leg. BS Park, SM Na, DJ Lee), gen. slide no. HNUSEL-5587-coll. INU.
Distribution. Korea (new record), China, Japan, Russia.
Host plants. Acer argutum Maxim., A. ginnala Maxim., A. pentaphyllum Diels., A. pictum Thunb. ex Murray, A. rufinerve Siebold & Zucc., A. semenovii Regel & Herd, A. ukurunduense Trautv. & Mey. [Sapindaceae] in China [1,20,27]. A. argutum Maxim., A. distylum Siebold & Zucc., A. ginnala Maxim., A. micranthum Siebold & Zucc., A. pictum Thunb. ex Murray, A. rufinerve Siebold & Zucc., A. tschonoskii Maxim., A. ukurunduense Trautv. & Mey. [Sapindaceae] in Japan [1,2,19]. A. pictum Thunb. ex Murray, A. semenovii Regel & Herd, A. sp., A. ukurunduense Trautv. & Mey. [Sapindaceae] in Russia [1,28,29].

3.2.6. Caloptilia recitata (Meyrick, 1918) Keun-gal-saeg-mu-nui-ga-neun-na-bang

Gracillaria recitata Meyrick, 1918b: 178–179 [21]. TL: Assam, India. TD: BMNH (Syntypes).
Caloptilia recitata: Issiki, 1957: 30 [30].
Adult (Figure 4f). Two forms with aestival and autumnal.
Aestival: Forewing orange brown with yellow blotch; basal part grayish brown; a yellow costal blotch extends along costa margin near apex, a half of blotch to base broadens to wing fold, back to narrow and a row of tiny black spots along costal margin within blotch; a black spot on the center of forewing near the boundary line of the yellow blotch; cilia brown on dorsal margin and blackish gray on tornus.
Autumnal: Forewing ground color purplish brown; basal-costa margin dark brown; a boundary line of yellow blotch more obscure than aestival form; a row of tiny blackish spots along costa margin, a spot on 2/3 to base, which is more distinct and larger.
Male genitalia (Figure 2f). Tegumen concave to inner surface, as long as 2/3 of vinculum and apex round. Valva moderate in shape with other species of this group; spatulate shaped, base narrow and broadens to apex with slender scales densely. Vinculum elongated, triangular and apical round. Aedeagus slender, bar-shaped and narrowed to apex; a long and slender cornuti on apical part, three of short and stout cornuti near base and the last one more elongated with bifurcated apical part.
Female genitalia (Figure 5e). Well sclerotized except for corpus bursae. posterior apophyses as long as anteriores. Ostium bursae moderate opening size, antrum with two sclerotized projections on both sides. Ductus bursae 2 times longer than corpus bursae, tubular, narrows caudally, broadens again to corpus bursae and slightly twists near corpus bursae. Corpus bursae membranous except for connection part with ductus bursae, elongated and slightly hollowed medially; two signa above median part and rapidly curved inside.
Material examined. [DJ] 1♂, Daedeok, Jeonmin-dong, 5 June 2015 (leg. BK Byun), gen. slide no. HNUSEL-5392-coll. HNUSEL; [JN] 1♂, Chusan-ri, Ongryong-myeon, Gwangyang, 2 June 2018 (leg. BK Byun), gen. slide no. HNUSEL-5560-coll. HNUSEL; [JB] 4♂, 4♀, Sangseo-myeon, Buan-gun, 29 September 2018 (leg. BK Byun), gen. slide no. HNUSEL-5543, 5544-coll. HNUSEL.
Distribution. Korea (new record), China, Hong Kong, Japan, India, Nepal.
Host plants. Cotinus coggygria Scop., Rhus javanica L., Toxicodendron sylvestre (Siebold & Zucc.) Kuntze, T. trichocarpum (Miq.) Kuntze in China [Anacardiaceae] [1,20]. R. javanica L., T. sylvestre (Siebold & Zucc.) Kuntze, T. trichocarpum (Miq.) Kuntze in Japan [Anacardiaceae] [1,2]. R. javanica L. in Nepal [Anacardiaceae] [1,2].
Remarks. This species was collected from Ailanthus altissima (Mill.) [Simaroubaceae] with pupal cocoon on the back side.

3.2.7. Caloptilia soyella (van Deventer, 1904) Tob-ni-ga-neun-na-bang

Gracillaria soyella van Deventer, 1904: 22–25 [22]. TL: Java, Indonesia. TD: RNHL (Lectotype; Paralectotype).
Caloptilia soyella: Issiki, 1950: 451 [31].
Adult (Figure 4g). Forewing length 4.2 mm.
Male genitalia (Figure 2g).
Female genitalia (Figure 5f,g). Papillae anales moderate with slender scales on apex; posterior apophyses 1.5 times longer than anteriores; sterigma well sclerotized; ostium bursae with ‘M’ shaped sclerotized lobe on center. Ductus bursae membranous, slender and 4 times longer than apophyses posteriores. Corpus bursae ovate with two sclerotized signa; each signum placed symmetrically, curved inner side and more narrowed apically.
Material examined. [JN] 1♀, Mt. Jeseok, Boseong-gun, 15 September 2016 (emergence date: 29 September 2016), (leg. UH Heo), gen. slide no. HNUSEL-5597-coll. UH Heo; 2♂, Seji-myeon, Naju-si, 31 July 2018 (leg. BK Byun), gen. slide no. HNUSEL-5556, 5557-coll. HNUSEL.
Distribution. Korea (new record), China, Japan, India, Indonesia, Viet Nam, Fiji, Cape Verde.
Host plants. Lespedeza cyrtobotrya Miq. [Fabaceae] in Korea (in this study). Cajanus cajan (L.) Millsp., Glycine max (L.) Merr., Kummerovia striana Schindler, Lespedeza cyrtobotrya Miq., Phaseolus mungo L., Vigna angularis (Willd.) Ohwi & H. Ohashi in China [Fabaceae] [1,20]. G. max (L.) Merr., K. striana Schindler, L. cyrtobotrya Miq., P. calcaratus Roxb., V. angularis (Willd.) Ohwi & H. Ohashi in Japan [Fabaceae] [1,2]. C. cajan (L.) Millsp., P. mungo L. in India [Fabaceae] [1,32]. Soya hispida Moench in Indonesia [Fabaceae] [1,22].
Remarks. This species was reared from Lespedeza cyrtobotrya Miq. of the family Fabaceae in this study.

3.3. Checklist of the Genus Caloptilia in Korea

Genus Caloptilia Hübner, 1825
Caloptilia Hübner, 1825: 427 [33].
Type species: Tinea upupaepennella Hübner, 1796 [34].
Antiolopha Meyrick, 1894 [35].
Calliptilia Agassiz, 1847 [36].
Cecidoptilia Kumata, 1982 [2].
Coriscium Zeller, 1839 [37].
Minyoptilia Kumata, 1982 [2].
Ornix Treitschke, 1833 [38].
Phylloptilia Kumata, 1982 [2].
Poeciloptilia Hübner, 1825 [34].
Rhadinoptilia Kumata, 1982 [2].
Sphyrophora Vári, 1961 [39].
Timodora Meyrick, 1886 [40].

3.3.1. Caloptilia acericola Kumata, 1966 Gin-no-lang-ga-neun-na-bang

Caloptilia acericola Kumata, 1966: 2–3 [19]. TL: Hokkaido, Japan. TD: EIHU (Holotype; Paratypes).
Forewing length 5 mm.
Material examined. [GG] 1♀, Korea National Arboretum, Gwangneung, 20 May 2008 (leg. SY Park, BW Lee, SR Kim, DH Kwon), gen. slide no. HNUSEL-5577-coll. KNAE; [GW] 3♂, 2♀, Mt. Odae, 27 May 1991 (leg. BK Byun), gen. slide no. NAK-533, HNUSEL-5603, 5604-coll. HNUSEL; 1♂, Mt. Odaesan, Jinbu-Myeon, Pyeongchang, 20 June 2012 (leg. SY Park, JO Lim, JS Lim), gen. slide no. HNUSEL-5608-coll. KNAE; [CB] 1♂, Mt. Minjuji, Maegok-myeon, Yeongdong-gun, 22 May 2014 (leg. IJ Choi, JW Nam, MH Kim), gen. slide no. HNUSEL-5571-coll. KNAE; 1♂, Namwon-si, Sannae-myeon, Jeongnyeongchi 23 May 2012 (leg. NH Ahn, JJ Park), gen. slide no. HNUSEL 5581-coll. NIBR; [GN] 1♂, Namhae, 1 June 1994 (leg. BK Byun), gen. slide no. HNUSEL-5552-coll. HNUSEL.
Distribution. Korea (new record), Japan, Russia.
Host plants. Acer japonicum Thunb., A. palmatum Thunb., A. pictum Thunb. ex Murray [Sapindaceae] in Japan [19]. A. pictum Thunb. ex Murray, A. pseudosieboldianum (Pax) Kom. [Sapindaceae] in Russia [1,25,26].

3.3.2. Caloptilia aceris Kumata, 1966 Dan-pung-ip-ga-neun-na-bang

Caloptilia aceris Kumata, 1966: 1 [19]. TL: Hokkaido, Japan. TD: EIHU (Holotype; Paratypes).
Forewing length 5.2 mm.
Material examined. [DJ] 1♂, Mt. Manin, Haso-dong, Dong-gu, 26 May 2018 (leg. BK Byun), gen. slide no. HNUSEL-5579-coll. HNUSEL.
Distribution. Korea, China, Japan, Russia.
Host plants. Acer miyabei Maxim., A. palmatum Thunb., A. pictum Thunb. ex Murray, A. saccharum Marschall [Sapindaceae] in China [1,27]. A. miyabei Maxim., A. palmatum Thunb., A. pictum Thunb. ex Murray, A. saccharum Marschall [Sapindaceae] in Japan [1,2,19]. A. pictum Thunb. ex Murray [Sapindaceae] in Russia [1,29].

3.3.3. Caloptilia alni Kumata, 1966 O-li-na-mu-ga-neun-na-bang

Caloptilia alni Kumata, 1966: 12 [19]. TL: Hokkaido, Japan. TD: EIHU (Holotype; Paratypes).
Forewing length 7 mm.
Material examined. [GW] 1♂, Chuncheon-Dam, 24 July 1991 (leg. KT Park & BK Byun), gen. slide no. HNUSEL-5044-coll. HNUSEL; 1♀, Mt. Chiak, Wonju-city, 24 April 1998 (leg. Bae, Paek, Lee, Ahn), gen. slide no. HNUSEL-5048-coll. INU.
Distribution. Korea, China, Japan, Russia.
Host plants. Alnus hirsuta Turcz., A. japonica (Thunb.) Steud. in China [Betulaceae] [1,20]. A. hirsuta Turcz., A. japonica (Thunb.) Steud. in Japan [Betulaceae] [1,19]. A. hirsuta Turcz., A. japonica (Thunb.) Steud. in Russia [Betulaceae] [1,28].

3.3.4. Caloptilia azaleella (Brants, 1913) San-cheol-jjug-ga-neun-na-bang

Gracillaria azaleella Brants, 1913: lxx–lxii [41]. TL: Japan. TD: Unknown.
Gracillaria azalea: Busck, 1914 [42].
Gracillaria anthracosperma: Meyrick, 1931 [43].
Forewing length 5.1 mm.
Material examined. [GG] 2♂, Mt. Myeongji, Gapyeong-gun, 30 September 2014 (emergence date: 10 October 2014), gen. slide no. HNUSEL-5611, 5612-coll. UH Heo.
Distribution. Korea, China, Japan, Russia, Australia, New Zealand, Austria, Belgium, Czech Republic, Denmark, Finland, France, Germany, Hungary, Ireland, Italy, Luxembourg, Netherlands, Norway, Poland, Portugal, Slovakia, Sweden, Switzerland, United Kingdom, Canada, United States, South Africa.
Host plants. Rhododendron yedoense var. poukhanense in Korea [Ericaceae] [1,44]. R. decandrum Makino, R. indicum (L.) Sweet, R. kaempferi Planch, R. kiusianum Makino, R. macrosepalum Maxim. R. viscistylum Nakai in Japan [Ericaceae] [1,2]. R. sp. in New Zealand [Ericaceae] [1,45]. Azalea sp. in Austria [Ericaceae] [1,46]. R. simsii Planch. in Czech Republic [Ericaceae] [1,47]. R. japonicum Sur., R. sp. in Denmark [Ericaceae] [1,48,49]. R. obtusum (Lindl.) Planch. in France [Ericaceae] [1,50]. R. indicum (L.) Sweet, R. simsii Planch., R. sp. in Germany [Ericaceae] [1,51,52,53,54]. R. indicum (L.) Sweet, R. japonicum Sur., R. sp. in Netherlands [Ericaceae] [1,41,54]. R. sp. in Portugal [Ericaceae] [1,55]. R. indicum (L.) Sweet in Slovakia [Ericaceae] [1,56]. R. sp. in Sweden [Ericaceae] [1,57]. R. indicum (L.) Sweet in Switzerland [Ericaceae] [1,58]. R. indicum (L.) Sweet, R. simsii Planch. R. sp. in United Kingdom [Ericaceae] [1,59,60]. R. indicum (L.) Sweet, R. sp. in United states [Ericaceae] [1,42,61]. R. indicum (L.) Sweet in South Africa [Ericaceae] [1,39].

3.3.5. Caloptiliaceltidis Kumata, 1982 Huin-mu-nui-ga-neun-na-bang

Caloptilia celtidis Kumata, 1982: 76–79 [2]. TL: Honshu, Japan. TD: EIHU (Holotype); EIHU, BMNH (Paratypes).
Forewing length 5 mm.
Material examined. [JN] 2♀, Mt. Wangui, Haeryong-myeon, Suncheon-si. 30 July 2016 (emergence date: 10 August 2016), gen. slide no. HNUSEL-5613-coll. UH Heo; 1♀, experiment forest of Seoul University, Gwangyang-si, 13 September 2016 (emergence date: 29 September 2016)-coll. UH Heo; 1♂, Mt. Jogye, Suncheon-si, 4 July 2018 (leg. BK Byun), gen. slide no. HNUSEL-5561-coll. HNUSEL.
Distribution. Korea (new record), China, Hong Kong, Japan.
Host plants. Celtis sinensis Persoon [Cannabaceae] in Korea (in this study). C. sinensis Persoon [Cannabaceae] in China [1,20]. C. jessoensis Koidz., C. sinensis Persoon [Cannabaceae] in Japan [1,2].
Remarks. This species was reared from Celtis sinensis Persoon of the family Cannabaceae in this study.

3.3.6. Caloptilia chrysolampra (Meyrick, 1936) Beo-deul-ga-neun-na-bang

Gracillaria chrysolampra Meyrick, 1936: 38 [62]. TL: Taiwan. TD: BMNH (Syntypes).
Caloptilia chrysolampra: Issiki, 1957 [30].
Forewing length 5 mm.
Material examined. [GJ] 1♀, Pyeong-dong, Gwangsan-gu, 20 May 2018 (leg. BK Byun), gen. slide no. HNUSEL-5584-coll. HNUSEL; 2♀, Pyeong-dong, Gwangsan-gu, 21 May 2018 (leg. BK Byun), gen. slide no. HNUSEL-5659-coll. HNUSEL; [GG] 1♀, Gwang Neung, 8 June 1977 (leg. KT Park)-coll. HNUSEL; 1♀, Gwangrung, 7 August 1986 (leg. KT Park, MK Ko)-coll. HNUSEL; 1♂, Sangnim-ri, Docheok-myeon, Gwangju, 11 August 2018 (leg. BK Byun), gen. slide no. HNUSEL-5658-coll. HNUSEL; [GW] 1♂, Chugok, 30 July 1986 (leg. KT Park, U Park)-coll. HNUSEL; 2♀, Mt. Samak, 19 July 1989 (leg. KT Park), gen. slide no. HNUSEL-5040-coll. HNUSEL; 2♀, Mt. Seolak, 9 August 1989 (leg. BK Byun)-coll. HNUSEL; 1♂, Mt. Jeombong, Girin-myeon, Inje, 3 August 2017 (leg. Lim, Lee, Choi, Shin, Roh)-coll. KNAE.
Distribution. Korea, China, Japan, Taiwan.
Host plants. Salix pseudo-lasiopyne in Korea [Salicaceae] [1,44]. Populus nigra L., S. babylonica L., 1753 in China [Salicaceae] [1,20]. P. nigra L., S. babylonica L., in Japan [Salicaceae] [1,2]. S. sp. in Taiwan [Salicaceae] [1,62].

3.3.7. Caloptilia dentata Liu & Yuan, 1990 Ne-mo-mu-nui-ga-neun-na-bang

Caloptilia (Caloptilia) dentata Liu & Yuan, 1990: 186 [20]. TL: Beijing, China. TD: IZAS (Holotype; Paratypes).
Forewing length 5 mm.
Material examined. [JB] 2♂, 1♀, Jangan-ri, Songgwang-myeon, Suncheon-si, 4 July 2018 (leg. BK Byun), gen. slide no. HNUSEL-5504-coll. HNUSEL; 2♀, Seji-myeon, Naju-si, 31 July 2018 (leg. BK Byun)-coll. HNUSEL; [GN] 1♂, Mt. Keum, Namhae, 7 August 1982 (leg. KT Park), gen. slide no. HNUSEL-5473-coll. HNU
Distribution. Korea (new record), China.
Host plants. Acer truncatum Bunge [Sapindaceae] in China [1,20].

3.3.8. Caloptilia hidakensis Kumata, 1966 Go-lo-soe-ga-neun-na-bang

Caloptilia hidakensis Kumata, 1966: 4 [19]. TL: Hokkaido, Japan. TD: EIHU (Holotype; Paratype).
Forewing length 6 mm.
Material examined. [GG] 1♀, Mt. Hwaak, 25 August 1998 (Paek, Lee & Ahn), gen. slide no. HNUSEL-5047-coll. INU; 1♂, Mt. Bongmisan, Danwolmyeon, Yangpyeong, 22 October 2008 (leg. BW Lee, SY Park, SR Kim), gen. slide no. HNUSEL-5391-coll. HNUSEL; [GW] 1♀, Mt. Bangadariyaksuteo, Odaesan, Pyeongchang, 22 July 2009 (leg. SY Park & JS Lim), gen. slide no. HNUSEL-5548-coll. HNUSEL; [JN] 1♀, Suncheon, 4 September 1991 (leg. SS Kim)-coll. HNUSEL.
Distribution. Korea, Japan, Russia.
Host plants. Acer pictum Thunb. ex Murray [Sapindaceae] in Japan [1,19].

3.3.9. Caloptilia kadsurae Kumata, 1966 Nam-o-mi-ja-ga-neun-na-bang

Caloptilia kadsurae Kumata, 1966: 19 [19]. TL: Honshu, Japan. TD: EIHU (Holotype; Paratypes).
Forewing length 5.2 mm.
Material examined. [JN] 2♂, Wando Arboretum, Wando, 31 August 2019 (emergence date: 16 September 2019) (leg. UH Heo), gen. slide no. HNUSEL-5593, 5594-coll. UH Heo; [JJ] 1♀, Sanghyo-dong, Seogwipo-si, 24 July 2019 (leg. BK Byun), gen. slide no. HNUSEL-5558-coll. HNUSEL.
Distribution. Korea (new record), Japan.
Host plants. Kadsura japonica Dunal [Magnoliaceae] in Korea (in this study). Kadsura japonica Dunal [Magnoliaceae] in Japan [1,19].
Remarks. This species was reared from Kadsura japonica Dunal of the family Magnoliaceae in this study.

3.3.10. Caloptilia kisoensis Kumata, 1982 Sin-na-mu-ga-neun-na-bang

Caloptilia (Caloptilia) kisoensis Kumata, 1982: 45–47 [2]. TL: Honshu, Japan. TD: EIHU (Holotype; Paratypes).
Forewing length 5.1 mm.
Material examined. [DJ] 1♀, Mt. Manin, Haso-dong, Dong-gu, 26 May 2018 (leg. BK Byun), gen. slide no. HNUSEL-5578-coll. HNUSEL; [GG] 1♀, Mt. Suri-san, Kunpo City, 25 July 1997 (leg. JS Lee & HK Lee)-coll. HNUSEL; [GW] 1♀, Chuncheon-Dam, 15 June 1995 (leg. HK Lee & MS Go)-coll. HNUSEL; 1♀, Mt. Taegisan, Dunnae-myeon, Hoengseong-gun, 5 June 2018 (leg. TG Lee, HK Kim, CM Jang), gen. slide no. HNUSEL-5660-coll. INU.
Distribution. Korea, Japan, Russia.
Host plants. Acer ginnala Maxim., A. pictum Thunb. ex Murray [Sapindaceae] in Korea [1,41]. A. ginnala Maxim., A. pictum Thunb. ex Murray [Sapindaceae] in Japan [1,2].

3.3.11. Caloptilia koreana sp. nov. Kim and Byun, 2022 Han-gug-ga-neun-na-bang

Type. Holotype. [KOREA] [GG] 1♀, Lake Yuklim, Gwangneung, 7 September 2017 (leg. Lim, Kim, Lee, Shin, Roh), gen. slide no. HNUSEL-5575-coll. KNAE.
Distribution. Korea (endemic, Gwangneung).
Host plants. Unknown.

3.3.12. Caloptilia leucothoes Kumata, 1982 San-jin-dal-lae-ga-neun-na-bang

Caloptilia (Caloptilia) leucothoes Kumata, 1982: 68 [2]. TL: Hokkaido, Japan. TD: EIHU (Holotype), EIHU, BMNH (Paratypes).
Forewing length 4.3 mm.
Material examined. [DJ] 1♂, Daedeok, Jeonming-dong, 5 June 2015 (leg. BK Byun), gen. slide no. HNUSEL-5394-coll. HNUSEL; [GG] 1♀, Yeoncheon, Mt. Godae, 30 April 2001 (leg. Bae, Kim & Kim)-coll. INU; 1♀, Obsevatory, Korea National Arboretum, Gwangneung, 16 July 2018 (leg. BS Park, YM Shin)-coll. KNAE; [GW] 1♀, Chuncheon, 17 June 1984 (leg. KT Park)-coll. HNUSEL; 2♂, Chuncheon, 21 March 1993 (leg. BK Byun), gen. slide no. HNUSEL-5547-coll. HNUSEL; 1♀, Mt. Taegisan, Dunnae-myeon, Hoengseong-gun, 5 June 2018 (leg. TG Lee, HK Kim, CM Jang), gen. slide no. HNUSEL-5564-coll. INU.
Distribution. Korea, Japan, Russia.
Host plants. Leucothoe grayana Maxim., Rhododendron albrechti Maxim., R. dauricum L., R. dilatatum Miq., R. reticulatum D. Don, R. sp. [Ericaceae] in Japan [1,2]. Menziesia pentandra Maxim. [Ericaceae] in Russia [1,29].

3.3.13. Caloptilia magnoliae Kumata, 1966 Mog-lyeon-ga-neun-na-bang

Caloptilia magnoliae Kumata, 1966: 17 [19]. TL: Hokkaido, Japan. TD: EIHU (Holotype; Paratypes).
Forewing length 8 mm.
Material examined. [GG] 1♂, Mt. Myeongji, Gapyeong-gun, 8 September 2013 (emergence date: 15 September 2013) (leg. UH Heo), gen. slide no. HNUSEL-5609, 5661-coll. HNUSEL; [JB] 1♀, Mt. Degyu, 22 July 1983 (leg. SB An)-coll. HNUSEL.
Distribution. Korea, Japan.
Host plants. Machilus thunbergii Siebold & Zucc. [Lauraceae] (in this study); Magnolia sp. [Magnoliaceae] in Korea [1,63]. M. kobus DC [Magnoliaceae] in Japan [1,19].

3.3.14. Caloptilia mandschurica (Christoph, 1882) Bug-bang-min-ga-neun-na-bang

Gracillaria mandschurica Christoph, 1882: 39–40 [64]. TL: Russia. TD: BMNH (Holotype; Allotype).
Caloptilia (Caloptilia) mongolicae: Kumata, 1982 [2].
Forewing length 6 mm.
Material examined. [SU] 3♂, 2♀, Hongneung, 1 April 1998 (leg. BK Byun) gen. slide no. HNUSEL-5388, 5393-coll. HNUSEL; [DJ] Daedeok, Jeonming-dong, 13 March 2013 (leg. BK Byun)-coll. HNUSEL; [SJ] 3♂, 8♂, Sejong-si, Geumnam, 30 April 2015 (leg. BK Byun), gen. slide no. HNUSEL-5545, 5546-coll. HNUSEL; [GG] 1♂, Suweon, 13 April 1977 (leg. KT Park)-coll. HNUSEL; [GW] 1♂, Chuncheon 11 June 1989 (leg. KT Park), gen. slide no. HNUSEL-5054-coll. HNUSEL; 1♂, Chuncheon, 27 July 1985 (leg. KT Park)-coll. HNUSEL; 1♀, Sambae-ri, Gonggeoun-myeon, Hoenseong-gun, 27 September 2016 (leg. SM Na, DJ Lee)-coll. INU; 2♀, Mt. Taegisan, Dunnae-myeon, Heongseong-gun, 5 June 2018 (leg. TG Lee, HK Kim, CM Jang)-coll. INU; 1♀, Mt. Jeombong, Gilin-myeon, Inge-gun, 25 July 2018 (BS Park, YM Shin, SB Choi)-coll. KNAE; [CB] 2♂, Boeun, Songnisan-myeon, Galmok-ri, 5 May 2017 (leg. BK Byun)-coll. HNUSEL; [CN] 1♂, Daegok-ri, Haemi-myeon, Seosan-si, 16 May 2019 (leg. BK Byun)-coll. HNUSEL; [JB] 1♀, Cheoncheon-myeon, Wolgok-ri, 5 April 2013 (leg. BK Byun)-coll. HNUSEL; [JN] 3♀, Mt. Jogye, Suncheon-si, 4 July 2018 (leg. BK Byun)-coll. HNUSEL.
Distribution. Korea, China, Japan, Russia.
Host plants. Quercus mongolica subsp. crispula (Blume) [Fagaceae] in Korea (in this study). Castanea crenata Siebold & Zucc., Q. acutissima Carruth., Q. dentata Thunb., Q. mongolica subsp. crispula (Blume) Menitsky in China [Fagaceae] [1,20]. C. crenata Siebold & Zucc., Q. acutissima Carruth., Q. crispula Blume, Q. dentata Thunb., Q. mongolica subsp. crispula (Blume) Menitsky, Q. serrata Thunb. in Japan [Fagaceae] [1,2,65,66]. Q. mongolica Fisch. & Turcz. in Russia [Fagaceae] [1,64].
Remarks. This species was reared from Quercus mongolica subsp. crispula (Blume) of the family Fagaceae in this study.

3.3.15. Caloptilia monticola Kumata, 1966 Oe-ban-jeom-ga-neun-na-bang

Caloptilia monticola Kumata, 1966: 8 [19]. TL: Honshu, Japan. TD: EIHU (Holotype; Paratypes).
Forewing length 6.21 mm
Material examined. [GB] 1♀, Mt. Tonggo, Geumgangsong-myeon, Uljin-gun, 23 June 2017 (leg. BS Park, SM Na, DJ Lee), gen. slide no. HNUSEL-5587-coll. INU.
Distribution. Korea (new record), China, Japan, Russia.
Host plants. Acer argutum Maxim., A. ginnala Maxim., A. pentaphyllum Diels., A. pictum Thunb. ex Murray, A. rufinerve Siebold & Zucc., A. semenovii Regel & Herd, A. ukurunduense Trautv. & Mey. [Sapindaceae] in China [1,20,27]. A. argutum Maxim., A. distylum Siebold & Zucc., A. ginnala Maxim., A. micranthum Siebold & Zucc., A. pictum Thunb. ex Murray, A. rufinerve Siebold & Zucc., A. tschonoskii Maxim., A. ukurunduense Trautv. & Mey. [Sapindaceae] in Japan [1,2,19]. A. pictum Thunb. ex Murray, A. semenovii Regel & Herd, A. sp., A. ukurunduense Trautv. & Mey. [Sapindaceae] in Russia [1,28,29].

3.3.16. Caloptilia pulverea Kumata, 1966 Heug-gal-saeg-jeom-ga-neun-na-bang

Caloptilia pulverea Kumata, 1966:13 [19]. TL: Hokkaido, Japan. TD: EIHU (Holotype), EIHU, BMNH (Paratypes).
Forewing length 6 mm.
Material examined. [GN] 1♂, 1♀, Mt. Gaji, 19 August 1993 (leg. KT Park & BK Byun), gen. slide no. HNUSEL-5055, 5605-coll. HNUSEL.
Distribution. Korea, China, Japan, Russia.
Host plants. Alnus hirsuta Turcz., A. japonica (Thunb.) Steud., A. matsumurae Callier, A. maximowiczii Callier, A. rugosa (Du Roi) Spreng. in China [Betulaceae] [1,20]. A. firma Siebold & Zucc., A. japonica (Thunb.) Steud., A. matsumurae Callier, A. maximowiczii Callier, A. serratuloides Callier in Japan [Betulaceae] [1,2,19]. A. japonica (Thunb.) Steud., A. maximowiczii Callier in Russia [Betulaceae] [1,28].

3.3.17. Caloptilia purpureus sp. nov. Kim and Byun, 2022 Bo-la-ga-neun-na-bang

Type. Holotype. [KOREA] [JN] 1♂, Mt. Geumo, Dolsan-eup, Yeosu-si, 10 October 2018 (emergence data: 28 October 2018) (leg. UH Heo), gen. slide no. HNUSEL-5592-coll. UH Heo; Paratype. [JN] 1♀, Mt. Geumo, Dolsan-eup, Yeosu-si, 10 October 2018 (emergence data: 1 November 2018) (leg. UH Heo), gen. slide no. HNUSEL-5591-coll. UH Heo.
Distribution. Korea (endemic, Yeosu-si).
Host plants. Sageretia theezans Brongn. [Rhamnaceae] in Korea (in this study).
Remarks. This species was reared from S. theezans Brongn. of the family Rhamnaceae in this study.

3.3.18. Caloptilia pyrrhaspis (Meyrick, 1931) No-lang-jul-ga-neun-na-bang

Gracillaria pyrrhaspis Meyrick, 1931: 17 [43]. TL: Szechuan, China. TD: BMNH (Holotype).
Caloptilia bicolor Ermolaev, 1977: 105, 110 [67].
Caloptilia pyrrhaspis: Kumata, 1982: 74 [2].
Forewing length 4 mm.
Material examined. [GG] 1♀, Mt. Myeongji, Gapyeong-gun, 8 September 2013 (emergence date: 25 September 2013) (leg. UH Heo), gen. slide no. HNUSEL-5596-coll. HNUSEL; [GB] 1♂, Bonghwa-gun, Seokpo-ri, 14 August 2013 (leg. BK Byun), gen. slide no. HNUSEL-5570-coll. HNUSEL.
Distribution. Korea, China, Japan, Russia.
Host plants. Betula davurica Pall. [Betulaceae] in Korea (in this study). Betula dahurica Pall., B. ermanii Chamisso, B. grossa Siebold & Zucc. [Betulaceae] in Chian [1,20]. B. ermanii Chamisso, B. grossa Siebold & Zucc. [Betulaceae] in Japan [1,2]. B. dahurica Pall., B. platyphylla Sukaczev [Betulaceae] in Russia [1,29,67].
Remarks. This species was reared from Betula davurica Pall. of the family Betulaceae in this study.

3.3.19. Caloptilia recitata (Meyrick, 1918) Keun-gal-saeg-mu-nui-ga-neun-na-bang

Gracillaria recitata Meyrick, 1918b: 178–179 [21]. TL: Assam, India. TD: BMNH (Syntypes).
Caloptilia recitata: Issiki, 1957: 30 [30].
Forewing length 6 mm.
Material examined. [DJ] 1♂, Daedeok, Jeonmin-dong, 5 June 2015 (leg. BK Byun), gen. slide no. HNUSEL-5392-coll. HNUSEL; [JN] 1♂, Chusan-ri, Ongryong-myeon, Gwangyang, 2 June 2018 (leg. BK Byun), gen. slide no. HNUSEL-5560-coll. HNUSEL; [JB] 4♂, 4♀, Sangseo-myeon, Buan-gun, 29 September 2018 (leg. BK Byun), gen. slide no. HNUSEL-5543, 5544-coll. HNUSEL.
Distribution. Korea (new record), China, Hong Kong, Japan, India, Nepal.
Host plants. Cotinus coggygria Scop., Rhus javanica L., Toxicodendron sylvestre (Siebold & Zucc.) Kuntze, T. trichocarpum (Miq.) Kuntze in China [Anacardiaceae] [1,20]. R. javanica L., T. sylvestre (Siebold & Zucc.) Kuntze, T. trichocarpum (Miq.) Kuntze in Japan [Anacardiaceae] [1,2]. R. javanica L. in Nepal [Anacardiaceae] [1,2].
Remarks. This species was collected from Ailanthus altissima (Mill.) [Simaroubaceae] with pupal cocoon on the back side.

3.3.20. Caloptilia rhois Kumata, 1982 Ot-na-mu-ga-neun-na-bang

Caloptilia (Caloptilia) rhois Kumata, 1982: 62–65 [2]. TL: Honshu, Japan. TD: EIHU (Holotype; Paratypes).
Forewing length 6 mm.
Material examined. [SJ] 1♂, Sejong-si, Geumnam, 30 April 2015 (leg. BK Byun) gen. slide no. HNUSEL-5555-coll. HNUSEL; [DJ] 1♂, Daedeok, Jeonmin-dong, 9 April 2014 (leg. BK Byun) gen. slide no. HNUSEL-5588-coll. HNUSEL; [JB] 1♂, Eumnae-ri, Mugu-eup, Muju-gun, 9 August 2019 (leg. BK Byun) gen. slide no. HNUSEL-5586-coll. HNUSEL; [JN] 2♂, Mt. Gahak, 26 July 2005 (leg. BK Byun) gen. slide no. HNUSEL-4156, 5060-coll. HNUSEL.
Distribution. Korea, China, Japan, Hong Kong.
Host plants. Rhus javanica L., Toxicodendron succedaneum (L.) Kuntze in China [Anacardiaceae] [1,24]. R. javanica L., T. succedaneum (L.) Kuntze in Japan [Anacardiaceae] [1,2].

3.3.21. Caloptilia sapporella (Matsumura, 1931) Jol-cham-na-mu-ga-neun-na-bang

Gracillaria sapporella Matsumura, 1931: 1101 [68]. TL: Japan. TD: EIHU (Syntype).
Caloptilia illicii Kumata, 1966: Shin et al., 2015 (misidentification) [5].
Forewing length 5 mm.
Material examined. [SJ] 1♂, Geumcheon-ri, Geumnam-myeon, 17 August 2017 (leg. SM Na, YB Cha), gen. slide no. HNUSEL-5583-coll. INU; [GG] 1♂, Gwangleung, 28 July 2000 (leg. BK Byun, WI Bae), gen. slide no. HNUSEL-5573-coll. HNUSEL; 1♀, Sangsaek-ri, Gapyeong-eup, Gapyeong-gun (leg. BK Byun), gen. slide no. HNUSEL-5568-coll. HNUSEL; 1♂, Sohol-eup, Pocheon-si, 13 August 2019 (leg. BK Byun), gen. slide no. HNUSEL-5572-coll. HNUSEL; [GW] 1♂, Janggoal, Chuncheon, 22 July 1995 (leg. JS Lee), gen. slide no. HNUSEL-5562-coll. HNUSEL; 1♀, Bukbang-myeon, Hongcheon-gun, 26 August 2019 (leg. BK Byun), gen. slide no. HNUSEL-5585-coll. HNUSEL; [JN] 1♂, Mt. Wolchul, Seongjeon, Gangjin, 5 May 1999 (leg. HG Lee), gen. slide no. 5582-coll. NAAS; 1♂, Mt. Baekun, Gwangyang, 18 May 2012 (leg. BK Byun), gen. slide no. HNUSEL-5037-coll. HNUSEL; 1♀, Chusan-ri, Ongryong-myeong, Gwangyang, 28 May 2018 (leg. BK Byun), gen. slide no. HNUSEL-5567-coll. HNUSEL; [GN] 1♂, Namhae, 1 June 1994 (leg. BK Byun), gen. slide no. NAK-534-coll. HNUSEL; 1♂, same locality, 2 June 1994 (leg. BK Byun), gen. slide no. NAK-535-coll. HNUSEL.
Distribution. Korea, China, Japan, Russia.
Host plants. Quercus acutissima Carruth. in Korea [Fagaceae] [1,63]. Castanea crenata Siebold & Zucc., Q. acuminata (Michx.) Sargent, Q. dentata Thunb., Q. mongolica subsp. crispula (Blume) Menitsky, Q. serrata Thunb. in China [Fagaceae] [1,20]. C. crenata Siebold & Zucc., Q. acutissima Carruth., Q. crispula Blume, Q. dentata Thunb., Q. mongolica subsp. crispula (Blume) Menitsky, Q. serrata Thunb. in Japan [Fagaceae] [1,2,66]. Q. dentata Thunb., Q. mongolica Fisch. & Turcz., Q. mongolica subsp. crispula (Blume) Menitsky in Russia [Fagaceae] [1,29,69].
Remarks. This species was misidentified in Shin et al. 2015, as Caloptilia sapporella to C. fidella.

3.3.22. Caloptilia schisandrae Kumata, 1966 O-mi-ja-ga-neun-na-bang

Caloptilia schisandrae Kumata, 1966: 18 [19]. TL: Hokkaido, Japan. TD: EIHU (Holotype; Paratypes).
Forewing length 7 mm.
Material examined. [GW] 1♂, Mt. Gariwang, Jeongseon, 30 July 2013 (leg. SS Kim), gen. slide no. HNUSEL-5389-coll. HNUSEL.
Distribution. Korea, China, Japan, Russia.
Host plants. Schisandra chinensis Baill. in Korea [Magnoliaceae] [1,70]. S. chinensis Baill. in Japan [Magnoliaceae] [1,19]. S. chinensis Baill. in Russia [Magnoliaceae] [1,31].

3.3.23. Caloptilia soyella (van Deventer, 1904) Tob-ni-ga-neun-na-bang

Gracillaria soyella van Deventer, 1904: 22–25 [22]. TL: Java, Indonesia. TD: RNHL (Lectotype; Paralectotype).
Caloptilia soyella: Issiki, 1950: 451 [31].
Forewing length 4.2 mm.
Material examined. [JN] 1♀, Mt. Jeseok, Boseong-gun, 15 September 2016 (emergence date: 29 September 2016), (leg. UH Heo), gen. slide no. HNUSEL-5597-coll. UH Heo; 2♂, Seji-myeon, Naju-si, 31 July 2018 (leg. BK Byun), gen. slide no. HNUSEL-5556, 5557-coll. HNUSEL.
Distribution. Korea (new record), China, Japan, India, Indonesia, Viet Nam, Fiji, Cape Verde.
Host plants. Lespedeza cyrtobotrya Miq. [Fabaceae] in Korea (in this study). Cajanus cajan (L.) Millsp., Glycine max (L.) Merr., Kummerovia striana Schindler, Lespedeza cyrtobotrya Miq., Phaseolus mungo L., Vigna angularis (Willd.) Ohwi & H. Ohashi in China [Fabaceae] [1,20]. G. max (L.) Merr., K. striana Schindler, L. cyrtobotrya Miq., P. calcaratus Roxb., V. angularis (Willd.) Ohwi & H. Ohashi in Japan [Fabaceae] [1,2]. C. cajan (L.) Millsp., P. mungo L. in India [Fabaceae] [1,32]. Soya hispida Moench in Indonesia [Fabaceae] [1,22].
Remarks. This species was reared from Lespedeza cyrtobotrya Miq. of the family Fabaceae in this study.

3.3.24. Caloptilia stigmatella (Fabricius, 1781) Baeg-yang-na-mu-ga-neun-na-bang

Tinea stigmatella Fabricius, 1781: 295–296 [71]. TL: United Kingdom. TD: GLAHM (Holotype).
Gracillaria consimilella Frey & Boll, 1876 [72].
Phalaena cruciella Goeze, 1783 [73].
Tinea equestris de Fourcroy, 1785 [74].
Gracillaria ochracea Haworth, 1828 [75].
Gracillaria purpurea Haworth, 1828 [75].
Gracillaria purpuriella Chambers, 1872 [76].
Tinea triangulella Panzer, 1794 [77].
Tinea triangolosella Costa, 1836 [78].
Gracillaria trigona Haworth, 1828 [75].
Tinea upupaepennella Hübner, 1796 [34].
Forewing length 6–6.2 mm.
Material examined. [GW] 1♂, 1♀, Sogumgang, 8 August 1988 (leg. KT Park), gen. slide no. HNUSEL-5041, 5043-coll. HNUSEL; [GB] 1♀, Bonghwa-gun, Seokpo-ri, 14 August 2013 (leg. BK Byun)-coll. HNUSEL.
Distribution. Korea, China, Japan, Russia, Mongolia, India, Armenia, Austria, Belgium, Bosnia and Herzegovina, Bulgaria, Croatia, Czech Republic, Estonia, Finland, France, Georgia, Germany, Hungary, Ireland, Italy, Kyrgyzstan, Latvia, Leichtenstein, Lithuania, Luxembourg, Macedonia, Morocco, Netherlands, Norway, Poland, Portugal, Romania, Serbia, Slovakia, Spain, Sweden, Switzerland, Tajikstan, Turkey, Turkmenistan, Ukraine, Uzbekistan, United Kingdom, Canada, United states
Host plants. Populus sp. in Korea [Salicaceae] [1,63]. P. nigra L., Salix bakko Kimura, Salix miyabeana (Seemen), S. sp. in Japan [Salicaceae] [1,2,79]. Robinia pseudacacia L. in Russia [Fabaceae] [1,80]; Myrica gale L., in Russia [Myricaceae] [1,80]; Chosenia arbutifolia (Pall.) A. K. Skvortsov, P. nigra L., P. suaveolens Fish. ex Loud., P. tremula L., P. sp., S. caprea L., S. sachalinensis Schmidt & Sekka, S. sp. in Russia [Salicaceae] [1,28,29,81,82]. P. nigra var. italica Münchh., P. sp. S. alba L., S. eleagnos Scop., S. purpurea L., S. repens L. S. sp. in Austria [Salicaceae] [83,84,85]. P. sp., S. repens L. in Belgium [Salicaceae] [1,86]. S. purpurea L. in Bulgaria [Salicaceae] [1,87]. P. alba L., P. tremula L., S. cinerea L., S. incanaelaeagnos Scop. in Czech Republic [Salicaceae] [88,89]. P. alba L., P. sp., S. incanaelaeagnos Scop., S. lanata L., S. sp. in Germany [Salicaceae] [1,51,90,91,92]. P. alba L., P. tremula L., S. incanaelaeagnos Scop., S. sp. in Italy [Salicaceae] [1,93,94,95]. P. tremula L. in Latvia [Salicaceae] [1,96]. P. sp., P. tremula L., S. sp. in Lithuania [1,97,98]. S. pedicellata Desf. in Morocco [Salicaceae] [99]. P. nigra var. italica Münchh., P. tremula L., S. triandra L., Salix sp. in Netherlands [Salicaceae] [1,100,101]. P. sp., S. sp. in Norway [Salicaceae] [1,102]. P. alba L., P. tremula L., P. × canadensis Moench., S. alba L., S. caprea L., S. fragilis L., S. purpurea L., S. triandra L. in Poland [Salicaceae] [1,103,104,105]. P. alba L., S. atrocinerea Brot., S. salviifolia Brot., S. × fragilis L. in Portugal [Salicaceae] [1,106]. P. nigra var. italica Münchh., P. sp., S. caprea L., S. sp. in Slovakia [Salicaceae] [1,90,107]. P. sp., S. sp. in Sweden [Salicaceae] [1,57]. P. nigra var. italica Münchh., P. tremula L., S. sp. in Switzerland [Salicaceae] [1,108]. P. sp., S. sp. [Salicaceae] in United Kingdom [1,59]. P. sp., S. longifolia Lam., S. sp. in United states [1,76,109].

3.3.25. Caloptilia syrphetias (Meyrick, 1907) Hu-bag-na-mu-ga-neun-na-bang

Gracilaria syrphetias Meyrick, 1907: 984 [110]. TL: Ceylon, Sri Lanka. TD: NHMUK.
Gracilaria zopherotarsa: Meyrick, 1936: 39 [62].
Caloptilia perseella: Kumata, 1982: 93 [2].
Forewing length 7.1 mm.
Distribution. Korea (Jeju Island), Brunei Darussalam, China, Hong Kong, India, Indonesia, Japan, Malaysia, Sri Lanka, Thailand.
Host plants. Machilus thunbergii Siebold et Zucc. [Lauraceae] [16].

3.3.26. Caloptilia theivora (Walsingham, 1891) Dong-baeg-ga-neun-na-bang

Gracillaria theivora Walsingham, 1891: 49–50 [111]. TL: Ceylon, Sri Lanka. TD: BMNH (Lectotype; Paralectotype).
Caloptilia theivora: Issiki, 1950 [31].
Forewing length 5 mm.
Material examined. [GB] 1♀, Uleung-gun, Naegujeon, 15 July 2014 (leg. BK Byun), gen. slide no. HNUSEL-5600-coll. HNUSEL; [JN] 1♂, Suncheon, 4 November 1991 (leg. SS Kim); 1♂, Suncheon, 6 November 1991 (leg. SS Kim), gen. slide no. HNUSEL-5061-coll. HNUSEL; 1♂, Boseong, Hoeryeong-ri, 8 October 2014 (leg. BK Byun), gen. slide no. HNUSEL-5657-coll. HNUSEL; 1♀, Mt. Jogey, Suncheon-si, 4 July 2018 (leg. BK Byun); Ongnyong-myeon, Gwangyang-si, 8 August 2018 (leg. BK Byun); [JJ] 1♀, Ibseokdong, 30 June 1994 (leg. BK Byun); 1♀, Sanghyo-dong, Seogwipo-si, 1 August 2018 (leg. BK Byun)-coll. HNUSEL.
Distribution. Korea, China, Hong Kong, Japan, Brunei Darussalam, India, Indonesia, Malaysia, Sri Lanka, Taiwan, Thailand, Viet Nam.
Host plants. Camellia sinensis L. [Theaceae] in Korea (in this study). C. japonica L., C. sasanqua Thunb., Thea sinensis L. [Theaceae] in China [1,20]. C. japonica L., C. sasanqua Thunb., T. sinensis L. [Theaceae] in Japan [1,2]. C. theifera Griff., T. sinensis L. [Theaceae] in India [1,32,111]. C. theifera Griff. [Theaceae] in Sri Lanka [1,112].
Remarks. This species was reared from Camellia sinensis L. of the family Theaceae in this study.

3.3.27. Caloptilia xanthos sp. nov. Kim and Byun, 2022 No-rang-jeom-ga-neun-na-bang

Type. Holotype. [KOREA] [JN] 1♀, Namseong-ri, Cheonggye-myeon, Muan-gun, 3 July 2019 (leg. BK Byun), gen. slide no. HNUSEL-5602-coll. HNUSEL.
Distribution. Korea (endemic, Muan-gun).
Host plants. Unknown.

3.3.28. Caloptilia yasudai Kumata, 1982 No-lan-i-ppal-ga-neun-na-bang

Caloptilia yasudai Kumata, 1982: 51–53 [2]. TL: Hokkaido, Japan. TD: EIHU (Holotype; Paratyeps).
Forewing length 6 mm.
Distribution. Korea, Japan.
Host plants. Unknown.
Remarks. This species could not be examined in this study.

3.3.29. Caloptilia zachrysa (Meyrick, 1907) Sa-gwa-ip-ga-neun-na-bang

Gracillaria zachrysa Meyrick, 1907: 983 [110]. TL: Ceylon, Sri Lanka. TD: BMNH (Syntypes).
Caloptilia zachrysa: Issiki, 1957 [30].
Forewing length 6 mm.
Material examined. [GG] 1♂, Suweon, 10 July 1976 (leg. KT Park), gen. slide no. HNUSEL-5042-coll. HNUSEL; 1♂, Suweon, 24 September 1980 (leg. CG Yoo), gen. slide no. HNUSEL-5599-coll. HNUSEL; 1♂, Mt. Yeogi, 19 August 1983 (leg. DJ Im)-coll. HNUSEL; 1♂, Gwangleung, 10 July 1990 (leg. KT Park)-coll. HNUSEL.
Distribution. Korea, China, Japan, India, Sri Lanka, Taiwan.
Host plants. Malus pumila Mill., Prunus persica (L.) Batsch in Korea [Rosaceae] [1,113]. M. pumila Mill., Photinia glabra (Thunb.) Maxim., Rubus sp. in China [Rosaceae] [1,20]. M. pumila Mill., Ph. glabra (Thunb.) Maxim., R. sp. in Japan [Rosaceae] [1,2]. M. pumila Mill., M. sylvestris Mill. in India [Rosaceae] [1,21,114,115]. Ph. sp. in Taiwan [Rosaceae] [1,2].

4. Discussion

The genus Caloptilia has not been studied extensively in Korea to date, when compared with that in the neighboring countries, especially regarding the number of known species, e.g., Japan has more than 50 reported species [1]. The first record of Caloptilia in Korea, which included five species, was reported in 1983 by Park. Later, Park and Han (1986) reported six species of Gracillaridae. In the 2000s and the 2010s, Park and Lee (2001) [70] and Sohn (2007) [44] reported one and four species, respectively. Shin et al. (2015) [5] enumerated 19 species of the genus, with four newly recorded species from Korea. All the known species from Korea including this study, were enumerated with synonymies, distribution and host plant respectively (File S1).
The genus Caloptilia can be distinguished from the other genera in the family Gracillariidae, based on their males having weakly membranous 7th and 8th abdominal segments, and females with signa present in the corpus bursae of their genitalia. Among the species of Caloptilia, the identification keys can be used to identify each species; however, slight differences exist. In addition, most species of Caloptilia morphologically resemble each other, with triangular patches on the forewing, a pair of signa in the female genitalia, and valva dilated toward the apex in the male genitalia. The host plant might be an exact identification key for Gracillariidae moths, because they have high host plant specificity (Davis, 1987 [116]; Brito et al., 2016 [117]), except for some polyphagous species. In this study, we reared a total of nine species of Caloptilia from host plants when they were in larval stages. Among them, three species that were investigated provided new host plant information, and one of them, Ailanthus altissima (Mill.) was recorded as a new host plant of the family Gracillariidae. Based on the host plant survey in this study, all the known host plants were summarized for the gracillariid species (Table S1). In total 106 species of 15 families were investigated for host plants of Caloptilia in the world. Most of them consisted of Salicaceae (27 species), Sapindaceae (23 species), Ericaceae (14 species), Betulaceae (12 species) and Fagaceae (11 species) [1]. The monophagous character is an obvious characteristic in the genus Caloptilia, but some species were shown to be polyphagous in this study. Caloptilia stigmatella were investigated with three families of host plants, and both C. recitata and C. magnoliae had two families, respectively.
In future research in Korea, DNA barcodes will function as exact identification keys for microlepidoptera. In this study, we tried to extract the DNA barcodes targeting all species of Caloptilia in Korea. However, it was difficult to get successful results, especially on some old specimens or other specimens, due to unknown reasons. We are now preparing and collecting more fresh material. After this, we will try to study the taxonomies and conduct systematic study with species delimitation and DNA data in future.

Supplementary Materials

The following supporting information can be downloaded at: https://www.mdpi.com/article/10.3390/insects13121107/s1, Table S1: Host plants of the Korean Caloptilia species, File S1: Annotaded Checklist for the Korean Caloptilia species.

Author Contributions

Conceptualization, D.-S.K. and B.-K.B.; Methodology, D.-S.K.; Investigation, D.-S.K.; Resources, Y.-M.S. and J.-Y.L.; Data curation, D.-S.K., Y.-M.S. and J.-Y.L.; Writing—original draft, D.-S.K.; Writing—review & editing, B.-K.B.; Project administration, B.-K.B. All authors have read and agreed to the published version of the manuscript.

Funding

This research was partially supported by the National Research Foundation of Korea (NRF) (grant number: NRF-2021R1I1A2059745), funded by the Government of Korea and ‘R&D Program for Forest Science Technology (Projected No. 2017042B10-2223-CA01)’ provided by Korea Forest Service (Korea Forestry Promotion Institute).

Institutional Review Board Statement

Not applicable.

Data Availability Statement

Data is contained within the article or supplementary material.

Acknowledgments

We would like to express our deep thanks to the late Kumata T, Hokkaido University, Sapporo, Japan and David L., the Natural History Museum, London, UK, for their kind help in examining the materials and their advice in the study of the Gracillariidae during our visiting study there. We also thank Kyu-Tek Park (The Korean Academy of Science and Technology) for his preliminary work on the Korean Gracillariidae. We are also grateful to Yang-Seop Bae (Incheon National University); Gwan-Seok Lee (National Institute of Agricultural Sciences); Bong-Woo Lee (Korea National Arboretum); Un-Hong Heo; Ga-Eun Lee (Jeju National University) for providing specimens with access to examine specimens. This work was supported by the National Research Foundation of Korea (NRF) (grant number: NRF-2021R1I1A2059745) and partially funded by the Government of Korea and ‘R&D Program for Forest Science Technology (Projected No. 2017042B10-2223-CA01)’ provided by Korea Forestry Promotion Institute.

Conflicts of Interest

The authors declare no conflict of interest.

Abbreviations

GGGyeonggi-do
SSeoul
CBChungcheongbuk-do
DJDaejeon
SJSejeong
GBGyeongsangbuk-do
GNGyeongsangnam-do
GWGangwon-do
JBJeollabuk-do
JNJeollanam-do
JJJeju-do
TLType locality
TDType depository
BMNHThe Natural History Museum, London, U.K.
EIHUEntomological Institute, Hokkaido University, Japan
GLAHMThe Hunterian Museum and Art Gallery, United Kingdom
HNUSELSystematic Entomologu Lab., Hannam University, Korea
INUDepartment of Life Sciences, Incheon National University, Korea
IZASInstitute of Zoology, Academia Sinica, Beijing, China
KNAEEntomological Collection, Korea National Arboretum, Korea
NAASNational Academy of Agricultural Science, Korea
RNHLNaturalis Biodiversity Center, Leiden, Netherlands

References

  1. De Prins, J.; De Prins, W. Global Taxonomic Database of Gracillariidae (Lepidoptera). World Wide Web Electronic Publication. Available online: http://www.gracillariidae.net (accessed on 5 February 2022).
  2. Kumata, T. A taxonomic revision of the Gracillaria group occurring in Japan (Lepidoptera: Gracillariidae). Ins. Matsum. Ser. 1982, 26, 1–186. [Google Scholar]
  3. Kumata, T. A new stem-miner of Alder in Japan, with a review of the larval transformation in the Gracillariidae (Lepidoptera). Ins. Matsum. 1978, 13, 1–27. [Google Scholar]
  4. Byun, B.K.; Lee, B.W.; Park, K.T.; Bae, Y.S. A Checklist of the Microlepidoptera in Korea (Lepidoptera); Korea National Arboretum: Pocheon, Republic of Korea, 2009; pp. 1–413. [Google Scholar]
  5. Shin, Y.M.; Lee, B.W.; Byun, B.K. Taxonomic review of the genus Caloptilia Hübner (Lepidoptera: Gracillariidae) in Korea. J. Asia-Pac. Entomol. 2015, 18, 83–92. [Google Scholar] [CrossRef]
  6. Kim, D.S.; Choi, C.W.; Lee, S.; Byun, B.K. Taxonomic notes on Phyllocnistis citrella (Lepidoptera: Gracillariidae) with genital structures and DNA barcode from Korea. J. Asia-Pac. Biodivers. 2015, 8, 295–297. [Google Scholar] [CrossRef] [Green Version]
  7. Kim, D.S.; Byun, B.K. First discovery of winter-emerging leaf-miner: Phyllonorycter styracis (Kumata, 1963) (Lepidoptera, Gracillariidae) from Korea with DNA barcode. J. Asia-Pac. Biodivers. 2016, 9, 477–480. [Google Scholar] [CrossRef] [Green Version]
  8. Kim, D.S.; Byun, B.K. Taxonomic review of the genus Phyllonorycter Hübner (Lepidoptera: Gracillariidae) in Korea. J. Asia-Pac. Entomol. 2017, 20, 1377–1386. [Google Scholar] [CrossRef]
  9. Kim, D.S.; Byun, B.K. An annotated catalogue of the two genera Licrobyla and Spulerina of the family Gracillariidae (Lepidoptera) from Korea with new records. J. Asia-Pac. Biodivers. 2019, 12, 444–447. [Google Scholar] [CrossRef]
  10. Kim, D.S.; Byun, B.K. Genus Eteoryctis Kumata & Kuroko, 1988 (Lepidoptera: Gracillariidae) in Korea with description of a new species. Zootaxa 2022, 5120, 402–408. [Google Scholar]
  11. Kim, D.S.; Lee, J.Y.; Byun, B.K. Korean species of Gracillaria Haworth, 1828 (Lepidoptera: Gracillariidae). J. Asia-Pac. Biodivers. 2022, 15, 408–413. [Google Scholar] [CrossRef]
  12. Kim, D.S.; Ahn, N.H.; Byun, B.K. The Genus Cameraria Chapman, 1902 (Lepidoptera: Gracillariidae: Lithocolletinae), New to Korea. Korean J. Appl. Entomol. 2022, 61, 313–318. [Google Scholar]
  13. Kim, D.S.; Oh, J.I.; Byun, B.K. Five Species of the Subfamily Acrocercopinae (Lepidoptera: Gracillariidae) New to Korea. Anim. Syst. Evol. Divers. 2022, 38, 113–121. [Google Scholar]
  14. Kim, D.S.; Oh, J.I.; Byun, B.K. Taxonomic review of the genus Spulerina Vári 1961 (Lepidoptera: Gracillariidae) in Korea. Orient. Insect 2022. [Google Scholar] [CrossRef]
  15. Lee, S.; Kim, D.S.; Kim, I.K.; Choi, C.W.; Hwang, R.; Ku, D.S.; Byun, B.K. Indigenous parasitoids as effective natural enemies of Phyllocnistis citrella (Lepidoptera: Gracillariidae) in Korea. J. For. Res. 2017, 28, 183–187. [Google Scholar] [CrossRef]
  16. Lee, G.E.; Jeun, Y.C. Eighteen species of microlepidoptera (Lepidoptera) new to Korea. J. Asia-Pac. Biodivers. 2022, 15, 241–253. [Google Scholar] [CrossRef]
  17. Kim, D.S.; Byun, B.K. Genus Telamoptilia Kumata & Kuroko, 1988 (Lepidoptera: Gracillariidae) new to Korea. Anim. Syst. Evol. Divers. 2022, 38, 162–166. [Google Scholar]
  18. Kim, D.S.; Byun, B.K. Korean species of Aristaea Meyrick, 1907 (Lepidoptera: Gracillariidae: Gracillariinae. Korean J. Appl. Entomol. 2022, 61, 651–656. [Google Scholar] [CrossRef]
  19. Kumata, T. Descriptions of twenty new species of the genus Ca1optilia Hübner from Japan including the Ryukyu islands (Lepidotera: Gracillariidae). Ins. Matsum. 1966, 29, 1–22. [Google Scholar]
  20. Liu, Y.; Yuan, D. A study of the Chinese Caloptilia Hübner, 1825 (Lepidoptera: Gracillariidae: Gracillariinae). Sinozoologia 1990, 7, 181–207. [Google Scholar]
  21. Meyrick, E. Exotic Microlepidoptera 2; Marlborough: Bolton, UK, 1918; Volume 2, pp. 97–224. [Google Scholar]
  22. van Deventer, W. Microlepidoptera van Java. Tijdschr. Entomol. 1904, 47, 1–42. [Google Scholar]
  23. Holloway, J.D.; Bradley, J.D.; Carger, D.J. CIE Guides to Insects of Importance to Man, 1st ed.; Lepidoptera CAB International: London, UK, 1987; pp. 1–262. [Google Scholar]
  24. Landry, B. The Gracillariidae (Lepidoptera, Gracillarioidea) of the Galapagos Islands, Ecuador, with notes on some of their relatives. Rev. Suisse Zool. 2006, 113, 437–485. [Google Scholar] [CrossRef]
  25. Ermolaev, V.P. New species of gracillariid mining moths (Lepidoptera, Gracillariidae) from the Far East. In Systematics and Zoogeography of the Lepidoptera of the Asiatic Part of the USSR; Trudy Zoologicheskogo Instituta, Akademija Nauk SSSR: Vladivostok, Russia, 1981; Volume 103, pp. 84–88. [Google Scholar]
  26. Ermolaev, V.P. Gracillariid moths of the genus Lithocolletis Hbn. (Lepidoptera, Gracillariidae) trophically associated with elm and maple in the south of the Far East. Entomol. Obozr. Entomol. Rev. 1988, 67, 346–359. [Google Scholar]
  27. Liu, Y.Q.; Shen, G. Lepidoptera: Microlepidoptera. In Iconography of Forest Insects in Hunan China; Peng, J., Liu, Y., Eds.; Academia Sinica & Hunan Forestry Institute: Changsha, China, 1992; pp. 666–755. [Google Scholar]
  28. Ermolaev, V.P. A contribution to the study on the leaf-mining family Gracillariidae of the southern Far East. In Terr. Arhtropoda Far East; Far East Scientific Center: Vladivostok, Russia, 1979; pp. 23–27. [Google Scholar]
  29. Ermolaev, V.P. Material on the fauna of Gracillariidae from Sakhalin and the southern Kuril Islands. In Lepidoptera of the Soviet Far East; Ler, P.A., Kirpichnikova, V.A., Kononenko, V.S., Eds.; Far East Scientific Center: Vladivostok, Russia, 1987; pp. 25–36. [Google Scholar]
  30. Issiki, S. Icones Heterocerorum Japonicorum in Coloribus Naturalibus; Esaki, T., Issiki, S., Inoue, H., Mutuura, A., Ogata, M., Okagaki, H., Eds.; Hoikusha: Osaka, Japan, 1957; Volume 1, pp. 29–30. [Google Scholar]
  31. Issiki, S. Iconographia Insectorum Japonicorum, 2nd ed.; Esaki, T., Kuwayama, S., Ishii, T., Shiraki, T., Kawamura, T., Uchida, S., Kinoshita, S., Yuasa, H., Eds.; Hokuryukan: Tokyo, Japan, 1950; pp. 451–454. [Google Scholar]
  32. Fletcher, T.B. Life-histories of Indian Insects. Microlepidoptera. VI. Gracillariadae. Mem. Dep. Agric. India. 1921, 1–217. [Google Scholar]
  33. Hübner, J. (Ed.) Verzeichniss Bekannter Schmettlinge; Verlag: Augsburg, Germany, 1816; pp. 1–431. [Google Scholar]
  34. Hübner, J. (Ed.) Sammlung Europäischer Schmetterlinge. Achte Horde. Tineae DieSchaben; Nach der Natur Geordnet, Beschrieben und Vorgestellt; Verlag: Augsburg, Germany, 1796; pp. 1–81. [Google Scholar]
  35. Meyrick, E. On a collection of Lepidoptera from upper Burma. Trans. Entomol. Soc. Lond 1894, 1–29. [Google Scholar]
  36. Agassiz, J.L.R. Nomenclator Zoologicus. Index Universalis Continens Nomina Systematica Generum Animalium Tam Viventium Quam Fassilium, Secundum Ordinem Alphabeticum Disposita, Adjectis Auctoribus, Libris in Quibus Reperiuntor, Anno Editionis, Etymologia, et Familis, ad Quas Pertinent, in Variis Classibus; Part 12; Jent et Glassmann: Soloduri, Indonesia, 1847; pp. 1–1135. [Google Scholar]
  37. Zeller, P.C. Versuch einer naturgemässen Eintheilung der Schaben. Isis. Oder Enzyklopädische Ztg. Oken 1839, 3, 167–220. [Google Scholar]
  38. Treitschke, F. Die Schmetterlinge von Europa. Neunter Band. Zweyte Abtheilung. Schaben. Geistchen. G. Hypsolopha-Orneode; Ernst Fleischer: Leipzig, Germany, 1833; pp. 1–294. [Google Scholar]
  39. Vári, L. South African Lepidoptera. Vol. I. Lithocolletidae; Transvaal Museum: Pretoria, South Africa, 1961; p. 238. [Google Scholar]
  40. Meyrick, E. Descriptions of Lepidoptera from the South Pacific. Trans. Entomol. Soc. Lond. 1886, 3, 189–296. [Google Scholar] [CrossRef]
  41. Brants, A. Mededeeling te en ven eene, zeer belangrijke waarneming van den Phytopathologischen Dienst. Verslag van de acht- en- zestigste Zomervergadering der Nederlandse entomologische Vereeniging. Tijdschr. Entomol. 1913, 56, 1xx–1xxii. [Google Scholar]
  42. Busck, A. A new Gracilaria on Azalea (Lepidoptera, Gracillariidae). Insecutor Inscitiae Menstruus 1914, 2, 1–2. [Google Scholar]
  43. Meyrick, E. Exotic Microlepidoptera 4; Marlborough: Bolton, UK, 1931; Volume 4, pp. 161–192. [Google Scholar]
  44. Sohn, J.C. Faunistic contribution to the Korea Microlepidoptera and Pyralids (1)-40 Species new to Korea. Tinea 2007, 20, 12–27. [Google Scholar]
  45. Dugdale, J.S. Lepidoptera—Annotated Catalogue, and Keys of Family-Group Taxa; Entomology Division, DSIR: Auckland, New Zealand, 1988; pp. 1–262. [Google Scholar]
  46. Kusdas, K.; Reichl, E.R. Die Schmetterlinge Oberösterreichs. Tell 6: Microlepidoptera (Kleinschmetterlinge); Landesmuseum zu Linz: Linz, Austria, 1990; pp. 1–332. [Google Scholar]
  47. Šumpich, J.; Liška, J.; Sitek, J.; Marek, J.; Skyva, J.; Uricar, J.; Fiala, F.; Jakeš, O.; Dvorák, I.; Maršik, L. Faunistic records from the Czech Republic. Klapalekiana 2011, 47, 281–298. [Google Scholar]
  48. Larsen, C.S. Tillæg til Fortegnelse over Danmark Microlepidoptera. Entomol. Medd. 1927, 17, 7–211. [Google Scholar]
  49. Buhl, O.; Falck, P.; Jørgensen, B.; Karsholt, O.; Larsen, K.; Vilhelmsen, F. Fund af småsommerfugle fra Danmark i 1998 (Lepidoptera). Entomol. Medd. 1998, 67, 103–112. [Google Scholar]
  50. Réal, P.; Balachowsky, A.S. Famille des Gracillariidae (=Lithocolletidae). In Entomologie Appliquée à L’agriculture. Tome 2; Balachowsky, A.S., Ed.; Masson et Cie éditeurs: Paris, France, 1966; pp. 309–335. [Google Scholar]
  51. Voigt, G. Beiträge zur Kenntnis der Minen und ihrer Erreger, sowie Beobachtungen über das Vorkommen von Minen im Rheingau und benachbarten rheinischen Gebieten. Jahrb. Nassauer Ver. Nat. 1929, 80, 24–74. [Google Scholar]
  52. Biesenbaum, W. Die Lepidopterenfauna der Rheinlande und Westfalens. Band 15. Familie Bucculatricidae Fracker, 1915. Familie: Gracillariidae Stainton, 1854. Unterfamilie: Gracillariinae Stainton, 1854; Westfälischer Lepidopterologists Association: Rheinisch, Germany, 2010; p. 168. [Google Scholar]
  53. Eckstein, K. Die Schmetterlinge Deutschlands mit Besonderer Berücksichtigung Ihrer Biologie und Wirtschaftlichen Bedeutung. 5. Band; Stuttgart, K.G., Ed.; Lutz’ Verlag: Lörrach, Germany, 1933; p. 223. [Google Scholar]
  54. Huisman, K.J.; Koster, J.C.; Muus, T.S.T.; van Nieukerken, E.J. Microlepidoptera in Nederland, vooral in 2007–2010 met een terugblik op 30 jaar faunistisch onderzoek. Entomol. Ber. 2013, 73, 91–117. [Google Scholar]
  55. Corley, M.F.V.; Rosete, J.; Marabuto, E.; Maravalhas, E.; Pires, P. New and interesting Portuguese Lepidoptera records from 2013 (Insecta: Lepidoptera). SHILAP Rev. Lepidopterol. 2014, 42, 587–613. [Google Scholar]
  56. Hrubý, K. Prodromus Lepidopter Slovenska; Vydavateľstvo SAV: Bratislava, Slovakia, 1964; pp. 1–962. [Google Scholar]
  57. Benander, P. Sveriges Lithocolletider (Gracilariidae). Opusc. Entomol. 1944, 9, 79–137. [Google Scholar]
  58. Whitebread, S.E.; Joos, R. Nachtfalter und Kleinschmetterlinge. In Basler Natur-Atlas I.; Blattner, M., Ritter, M., Ewald, K.C., Eds.; Basler Naturschutz: Basel, Switzerland, 1986; pp. 116–121. [Google Scholar]
  59. Meyrick, E. Exotic Microlepidoptera 3; Marlborough: Bolton, UK, 1927; Volume 3, pp. 321–384. [Google Scholar]
  60. Emmet, A.M. A Field Guide to the Smaller British Lepidoptera, 2nd ed.; British Entomological & Natural History Society: Wokingham, UK, 1988; p. 288. [Google Scholar]
  61. Heppner, J.B. Arthropods of Florida and Neighbouring Land Areas. Lepidoptera of Florida. Part 1. Introduction and Catalogue. Fla. Dep. Agric. 2003, 17, 1–670. [Google Scholar]
  62. Meyrick, E. Exotic Microlepidoptera 5(1-2); CABI: Marlborough, UK, 1936; Volume 1–2, pp. 1–64. [Google Scholar]
  63. Park, K.T.; Han, S.S. Seven species of Gracillariidae and Lyonetiidae (Lepidoptera) new to Korea and a list of the known host plants for the familes. Korea J. Plant Prot. 1986, 25, 121–128. [Google Scholar]
  64. Christoph, H. Neue Lepidoptiera des europaeischen faunengebietes. Horae Asaocietatis Entomol. Ross. 1882, 9, 3–39. [Google Scholar]
  65. Sato, H.; Okabayashi, Y.; Kamijo, K. Structure and function of parasitoid assemblages associated with Phyllonorycter leafminers (Lepidoptera: Gracillariidae) on deciduous oaks in Japan. Environ. Entomol. 2002, 31, 1052–1061. [Google Scholar] [CrossRef] [Green Version]
  66. Ishida, T.A.; Hattori, K.; Kimura, M.T. Abundance of leafminers and leaf area loss by chewing herbivores in hybrids between Quercus crispula and Quercus dentata. Can. J. For. Res. 2004, 34, 2501–2507. [Google Scholar] [CrossRef]
  67. Ermolaev, V.P. A review of the fauna and ecology of miner-moth (Lep., Gracillariidae) of the Primorye Territory. Pro. Zool. Inst. Acad. Sci. USSR 1977, 70, 98–116. [Google Scholar]
  68. Matsumura, S. 6000 Illustrated Insects of the Japan-Empire; Tokohshoin: Tokyo, Japan, 1931; pp. 1–1497. (In Japanese) [Google Scholar]
  69. Ermolaev, V.P. New and little known species of leafblotch miners (Lepidoptera, Gracillariidae) from the south of Primorye Territory. Entomol. Obozr. 1986, 65, 741–752. [Google Scholar]
  70. Park, Y.M.; Lee, G.S. A new record of Caloptilia schicandrae Kumata (Lepidoptera: Gracillariidae) from Korea. Insecta Koreana 2001, 18, 91–93. [Google Scholar]
  71. Fabricius, J.C. Species insectorum exhibentes eorum differentias specificas, synonyma autorum, loca natalia, metamorphosin adiectis observationibus, descriptionibus. Tom II. Impensis Carol. Ernest Bohnii Hambg. Kilonii 1781, 2, 1–517. [Google Scholar]
  72. Frey, H.; Boll, J. Einige Tineen aus Texas. Entomol. Ztg. 1876, 37, 209–228. [Google Scholar]
  73. Goeze, J.A.E. Entomologische Beyträge zu des Ritter Linne Zwölften Ausgabe des Natursystems; Bey Weidmanns Erben und Reich: Leipzig, Germany, 1783; pp. 1–178. [Google Scholar]
  74. Fourcroy, A.F. Entomologia Parisiensis; Sive, Catalogus Insectorum Quae in Agro Parisiensi Reperiuntur; Privilegio Academiae: Paris, France, 1785; part 1; pp. 1–544. [Google Scholar]
  75. Haworth, A.H. Lepidoptera Britannica: Sistens Digestionem Novam Insectorum Lepidopterorum Quae in Magna Britannia Reperiuntur, Larvarum Pabulo, Remporeque Pascendi, Expansione Alarum, Mensibusque Volandi, Synonymis Atque Locis Observationibusque Variis; Taylor & Francis: London, UK, 1828; pp. 1–609. [Google Scholar]
  76. Chambers, V.T. Micro-Lepidoptera. Can. Entomol. 1872, 4, 25–29. [Google Scholar] [CrossRef]
  77. Panzer, G.W.F. Fauna Insectorum Germanicae Initia Oder Deutschlands Insecten. Heft 17; Felsecker: Nürnberg, Germany, 1794; pp. 13–24. [Google Scholar]
  78. Costa, O.G. Fauna del Regno di Napoli Ossia Enumerazione di Tutti gli Animali che Abitano le Diverse Regioni di Questo Regno e le Acque che le Bagnano Contenente la Descrizione de Nuovi o Poco Esattamente Conosciuti. Lepidotteri; Dai Torchi del Tramater: Azzolino, Napoli, 1836; pp. 1–24. [Google Scholar]
  79. Kagata, H.; Ohgushi, T. Resource partitioning among three willow leaf miners: Consequence of hostplant phenology. Entomol. Sci. 2001, 4, 257–263. [Google Scholar]
  80. Kirichenko, N.; Triberti, P.; Akulov, E.; Ponomarenko, M.; Gorokhova, S.; Sheiko, V.; Ohshima, I.; Lopez-Vaamonde, C. Exploring species diversity and host plant associations of leaf-mining micromoths (Lepidoptera: Gracillariidae) in the Russian Far East using DNA barcoding. Zootaxa 2019, 4652, 1–55. [Google Scholar] [CrossRef]
  81. Martynova, E.F. Osobennosti fauny tsheshuekrylykh yuzhnogo Priuralya i ee znatshanie dlya stepnogo lesorasvedeniya. Trudy Zoologicheskogo Instituta. Akad. Nauk. SSSR 1952, 11, 66–91. [Google Scholar]
  82. Akulov, E.N.; Kirichenko, N.I.; Ponomarenko, M.G. Contribution to the Microlepidoptera fauna of the south of the Krasnoyarsk Territory and the Republic of Khakassia. Entomol. Rev. 2018, 97, 110–146. [Google Scholar] [CrossRef] [Green Version]
  83. Mitterberger, K. Verzeichnis der im Kronlande Salzburg Bisher Beobachteten Mikrolepidopteren; Ringlschwendtner & Rathmayr: Obersulm, Germany, 1909; p. 358. [Google Scholar]
  84. Skala, H. Zur Verbreitung einiger Blattminen in Oberösterreich. Entomol. Anz. 1935, 15, 153–155, 177–179. [Google Scholar]
  85. Kasy, F. Beitrag zur Kenntnis der Schmetterlingsfauna des WWF-Naturreservates Marchauen/Marchegg (mit nani-au) in Niederösterreich. Z. Arb. Osterr. Entomol. 1989, 41, 1–24. [Google Scholar]
  86. de Crombrugghe de Picquendaele, G. Catalogue raisonné des Microlépdoptères de Belgique. Mémoires Société Entomol. Belg. 1906, 13, 1–155. [Google Scholar]
  87. Buszko, J.; Beshkov, S. A preliminary survey of leafmining moths (Insecta: Lepidopetra: Microlepidoptera) of the Bulgarian part of Eastern Rhodopes. In Biodiversity of Bulgaria. 2. Biodiversity of Eastern Rhodopes; Beron, P., Popov, A., Eds.; Pensoft Publishers: Sofia, Bulgaria, 2004; pp. 723–733. [Google Scholar]
  88. Skala, H. Minen aus Mittel- und Südeuropa (Fortsetzung und Schluss). Z. Osterr. Entomol.-Ver. 1937, 22, 10–11, 19–20. [Google Scholar]
  89. Jaroš, J.; Spitzer, K. Food plants of Lepidoptera associated with an alder carr forest in South Bohemia (Central Europe). Acta Musei Bohem. Merid. Ceské Budejovice 2002, 42, 5–60. [Google Scholar]
  90. Koch, G. Die Schmetterlinge des südwestlichen Deutschlands: Insbesondere der Umgegend von Frankfurt, Nassau und der Hessischen Staaten; Forgotten Books: Bochum, Germany, 1856; pp. 1–498. [Google Scholar]
  91. Hering, M. Beiträge zur Kenntnis der Oekologie und Systematik blattminierender Insekten. (Minenstudien VIII). Z. Für Angew. Entomol. 1928, 13, 157–198. [Google Scholar]
  92. Buhr, H. Mecklenburgische Minen. III. Lepidopteren-Minen. Stettin. Entomol. Ztg. 1935, 96, 131–159, 262–292. [Google Scholar]
  93. Klimesch, J. Contibuto alla fauna Lepidopterologica del Trentino. Studi Trentini Di Sci. Nat. Acta Biol. 1950, 27, 11–68. [Google Scholar]
  94. Hartig, F. Microlepidotteri della Venezia Tridentina e delle regioni adiacenti. Parte III. (Fam. Gelechiidae—Micropterigidae). Studi Trentini Sci. Nat. Riv. Mus. Stor. Nat. Venezia Tridentina 1964, 41, 1–292. [Google Scholar]
  95. Hartig, F. Prodromus dei Microlepidotteri della Venezia Tridentina e delle regioni adiacenti. Studi Trentini Sci. Nat. Riv. Mus. Stor. Nat. Venezia Tridentina 1956, 33, 89–148. [Google Scholar]
  96. Lienig, F. Lepidopterische Fauna von Lievland und Curland. Isis Oder Enzyklopädische Ztg. Von Oken 1846, 3–4, 175–302. [Google Scholar]
  97. Ivinskis, P.; Pakalniškis, S. Microlepidoptera of Lithuania (Gracillariidae). Liet. TSR Moksl. Akad. Darb. 1984, 1, 26–36. [Google Scholar]
  98. Ivinskis, P.; Pakalniškis, S.; Puplesis, R. Augalus Minuojantys Vabzdziai; Mokslas: Vilnius, Lithuania, 1985; pp. 1–240. [Google Scholar]
  99. Rungs, C.E.E. Catalogue Raisonné des Lepidoptères du Maroc. Inventaire Faunistique et Obsevations Écologiques. Tome 1. Trav. L’institut Sci. Série Zool. 1979, 39, 1–222. [Google Scholar]
  100. de Graaf, H.W.; Snellen, P.C.T. Microlepidoptera in Nederland waargenomen. In Bouwstoffen voor Eene Fauna van Nederland; Herklots, J.A., Ed.; EJ Brill: Leiden, The Netherlands, 1866; Volume 3, pp. 234–317. [Google Scholar]
  101. Snellen, P.C.T. De Vlinders van Nederland. Microlepidoptera, Systematisch Beschreven; Nijhoff: Leiden, The Netherlands, 1882; Volume 2, pp. 1–1197. [Google Scholar]
  102. Opheim, M. Revision of Microlepidoptera in the collections of Zoological Museum, Oslo I. Atalanta Nor. 1977, 3, 5–15. [Google Scholar]
  103. Büttner, F.O. Die pommerschen, insbesondere die Stettiner Mikrolepidoptern. Stettin. Entomol. Ztg. 1880, 41, 383–473. [Google Scholar]
  104. Buszko, J. Studies on the mining Lepidoptera of Poland X. Mining Lepidoptera of Torun and surrounding areas. Acta Zool. Crac. 1990, 33, 367–452. [Google Scholar]
  105. Buszko, J. Studies of the mining lepidoptera of Poland. XIV. Mining Lepidoptera of the Ojców National Park. Wiad. Entomol. 1993, 12, 201–214. [Google Scholar]
  106. Corley, M.F.V. Lepidoptera of Continental Portugal: A Fully Revised List; Martin Corley: Faringdon, UK, 2015; p. 282. [Google Scholar]
  107. Hrubik, P.; Juhasova, G. Occurrence of horsechestnut mining moth Cameraria ohridella Deschka et Dimic in Slovakia. Acta Hortic. Regiotect. 1998, 1, 21–23. [Google Scholar]
  108. Frey, H. Die Tineen and Pterophoren der Schweiz; Meyer und Zeller: Zürich, Switzerland; Bayerische Staatsbibliothek: München, Germany, 1856; pp. 1–430. [Google Scholar]
  109. Chambers, V.T. Art. IV. Tineina and their foodplants. Bull. USA Geol. Geogr. Surv. Territ. 1878, 4, 107–124. [Google Scholar]
  110. Meyrick, E. Descriptions of Indian Micro-Lepidoptera. IV. J. Bombay Nat. Hist. Soc. 1907, 17, 976–984. [Google Scholar]
  111. Walsingham, L. A new species of Tineidae. (Gracilaria theivora Wlsm., sp. nov.). Indian Mus. Notes 1891, 2, 49–50. [Google Scholar]
  112. Maxwell-Lefroy, H.; Howlett, F.M. Indian Insect Life. A Manual of the Insects of the Plains (Tropical India); Thacker, Spink & Co.: Calcutta, Indian; Simla and W. Thacker & Co.: London, UK, 1909; p. 786. [Google Scholar]
  113. Park, K.T. Microlepidoptera of Korea; Insecta Koreana: Seoul, Republic of Korea, 1983; Volume 3, pp. 1–189. [Google Scholar]
  114. Meyrick, E. Descriptions of South African Micro-Lepidoptera. Ann. Transvaal Mus. 1918, 6, 7–59. [Google Scholar] [CrossRef]
  115. Korean Society of Applied Entomology; The Entomological Society of Korea. Check List of Insects from Korea; Kon-Kuk University Press: Seoul, Republic of Korea, 1994; pp. 323–324. [Google Scholar]
  116. Davis, D.R. Gracillariidae. In Immature Insects; Stehr, F.W., Ed.; Kendall/Hunt Publishing Company: Dubuque, IA, USA, 1987; Volume I, pp. 372–374. [Google Scholar]
  117. Brito, R.; De Prins, J.; De Prins, W.; Mielke, O.H.H.; Conçalves, G.L.; Moreira, G.R.P. Extant diversity and estimated number of Gracillariidae (Lepidoptera) species yet to be discovered in the Neotropical region. Rev. Bras. Entomol. 2016, 60, 275–283. [Google Scholar] [CrossRef]
Insects 13 01107 g001 550
Figure 1. Adults of Caloptilia. (a). C. purpureus (Holotype, gen. slide no. HNUSEL-5592); (b). C. koreana (Holotype, gen. slide no. HNUSEL-5575); (c). C. xanthos (Holotype, gen. slide no. HNUSEL-5602).
Figure 1. Adults of Caloptilia. (a). C. purpureus (Holotype, gen. slide no. HNUSEL-5592); (b). C. koreana (Holotype, gen. slide no. HNUSEL-5575); (c). C. xanthos (Holotype, gen. slide no. HNUSEL-5602).
Insects 13 01107 g001
Insects 13 01107 g002 550
Figure 2. Male genitalia of Caloptilia. (a). C. purpureus (gen. slide no. HNUSEL-5592); (b). C. acericola (gen. slide no. HNUSEL-5571); (c). C. celtidis (gen. slide no. HNUSEL-5561); (d). C. dentata (gen. slide no. HNUSEL-5549); (e). C. kadsurae (gen. slide no. HNUSEL-5593); (f). C. recitata (gen. slide no. HNUSEL-5544); (g). C. soyella (gen. slide no. HNUSEL-5556, 5557) (Scale bars: a–g = 5 mm).
Figure 2. Male genitalia of Caloptilia. (a). C. purpureus (gen. slide no. HNUSEL-5592); (b). C. acericola (gen. slide no. HNUSEL-5571); (c). C. celtidis (gen. slide no. HNUSEL-5561); (d). C. dentata (gen. slide no. HNUSEL-5549); (e). C. kadsurae (gen. slide no. HNUSEL-5593); (f). C. recitata (gen. slide no. HNUSEL-5544); (g). C. soyella (gen. slide no. HNUSEL-5556, 5557) (Scale bars: a–g = 5 mm).
Insects 13 01107 g002
Insects 13 01107 g003 550
Figure 3. Female genitalia of Caloptilia. (a). C. purpureus (gen. slide no. HNUSEL-5591); (b). C. koreana (gen. slide no. HNUSEL-5575); (c). C. xanthos (gen. slide no. HNUSEL-5602). (Scale bars: a–e = 5 mm).
Figure 3. Female genitalia of Caloptilia. (a). C. purpureus (gen. slide no. HNUSEL-5591); (b). C. koreana (gen. slide no. HNUSEL-5575); (c). C. xanthos (gen. slide no. HNUSEL-5602). (Scale bars: a–e = 5 mm).
Insects 13 01107 g003
Insects 13 01107 g004 550
Figure 4. Adults of Caloptilia. (a). C. acericola (gen. slide no. HNUSEL-5577); (b). C. celtidis (gen. slide no. HNUSEL-5613); (c). C. dentata (gen. slide no. HNUSEL-5589); (d). C. kadsurae (gen. slide no. HNUSEL-5593); (e). C. monticola (gen. slide no. HNU-SEL-5587); (f). C. recitata (gen. slide no. HNUSEL-5577); (g). C. soyella (gen. slide no. HNUSEL-5557).
Figure 4. Adults of Caloptilia. (a). C. acericola (gen. slide no. HNUSEL-5577); (b). C. celtidis (gen. slide no. HNUSEL-5613); (c). C. dentata (gen. slide no. HNUSEL-5589); (d). C. kadsurae (gen. slide no. HNUSEL-5593); (e). C. monticola (gen. slide no. HNU-SEL-5587); (f). C. recitata (gen. slide no. HNUSEL-5577); (g). C. soyella (gen. slide no. HNUSEL-5557).
Insects 13 01107 g004
Insects 13 01107 g005 550
Figure 5. Female genitalia of Caloptilia. (a). C. acericola (gen. slide no. HNUSEL-5574); (b). C. celtidis (gen. slide no. HNUSEL-5613) (c). C. kadsurae (gen. slide no. HNUSEL-5558); (d). C. monticola (gen. slide no. HNUSEL-5587); (e). C. recitata (gen. slide no. HNUSEL-5543); (f). C. soyella (gen. slide no. HNUSEL-5597); (g). ditto, antrum (Scale bars: a–d = 5 mm).
Figure 5. Female genitalia of Caloptilia. (a). C. acericola (gen. slide no. HNUSEL-5574); (b). C. celtidis (gen. slide no. HNUSEL-5613) (c). C. kadsurae (gen. slide no. HNUSEL-5558); (d). C. monticola (gen. slide no. HNUSEL-5587); (e). C. recitata (gen. slide no. HNUSEL-5543); (f). C. soyella (gen. slide no. HNUSEL-5597); (g). ditto, antrum (Scale bars: a–d = 5 mm).
Insects 13 01107 g005
Publisher’s Note: MDPI stays neutral with regard to jurisdictional claims in published maps and institutional affiliations.

Share and Cite

MDPI and ACS Style

Kim, D.-S.; Shin, Y.-M.; Lee, J.-Y.; Byun, B.-K. Taxonomic Review of the Genus Caloptilia Hübner, 1825 (Lepidoptera: Gracillariidae) with Descriptions of Three New Species and Seven Newly Recorded Species from Korea. Insects 2022, 13, 1107. https://doi.org/10.3390/insects13121107

AMA Style

Kim D-S, Shin Y-M, Lee J-Y, Byun B-K. Taxonomic Review of the Genus Caloptilia Hübner, 1825 (Lepidoptera: Gracillariidae) with Descriptions of Three New Species and Seven Newly Recorded Species from Korea. Insects. 2022; 13(12):1107. https://doi.org/10.3390/insects13121107

Chicago/Turabian Style

Kim, Da-Som, Young-Min Shin, Ji-Young Lee, and Bong-Kyu Byun. 2022. "Taxonomic Review of the Genus Caloptilia Hübner, 1825 (Lepidoptera: Gracillariidae) with Descriptions of Three New Species and Seven Newly Recorded Species from Korea" Insects 13, no. 12: 1107. https://doi.org/10.3390/insects13121107

Note that from the first issue of 2016, this journal uses article numbers instead of page numbers. See further details here.

Article Metrics

Back to TopTop
