Abstract
Unidirectional multilevel back-to-back (BTB) converters are widely employed in renewable energy generation systems and in motor drives for coal mining operations. However, the current zero-crossing distortion (CZCD) on the grid side and the neutral-point potential (NPP) imbalance on the common DC bus all restrict its applicability, such as in grids with stringent low harmonic requirements and in medium to high power situations. This paper proposes a coordinated control strategy to simultaneously address these issues theoretically. The study focuses on topology comprising a Vienna rectifier structure on the grid side and a three-level NPC inverter structure on the load side. In the proposed strategy, the current distortion angle, the manifestation of CZCD, is first eliminated by reactive current compensation on the Vienna rectifier side. Furthermore, the coupling between CZCD and NPP imbalance is resolved by reconstructing the neutral-point current target function. Ultimately, the optimal zero-sequence voltage (ZSV) is obtained using an interpolation function and then injected into the three-phase reference voltages of the inverter side to balance the NPP on the DC bus. The strategy transforms the influence of the rectifier on the NPP from an unknown coupling factor into a known disturbance and enables the inverter to actively compensate for variations in the overall converter system. An experimental platform was independently developed to verify the effectiveness of the proposed control strategy.
