Remote Sens. 2017, 9(11), 1123;

Assessment of MODIS BRDF/Albedo Model Parameters (MCD43A1 Collection 6) for Directional Reflectance Retrieval

State Key Laboratory of Resources and Environmental Information System, Institute of Geographic Sciences and Natural Resources Research, Chinese Academy of Sciences, Beijing 100101, China
University of Chinese Academy of Sciences, Beijing 100049, China
Global Land Cover Facility, Department of Geographical Sciences, University of Maryland, College Park, MD 20742, USA
Jiangsu Center for Collaborative Innovation in Geographical Information Resource Development and Application, Nanjing 210023, China
Collaborative Innovation Center on Forecast and Evaluation of Meteorological Disasters (CIC-FEMD), Nanjing University of Information Science & Technology, Nanjing 210044, China
Author to whom correspondence should be addressed.
Received: 6 September 2017 / Revised: 29 October 2017 / Accepted: 31 October 2017 / Published: 4 November 2017
Full-Text   |   PDF [5348 KB, uploaded 20 November 2017]   |


Measurements of solar radiation reflected from Earth’s surface are the basis for calculating albedo, vegetation indices, and other terrestrial attributes. However, the “bi-directional” geometry of illumination and viewing (i.e., the Bi-directional Reflectance Distribution Function (BRDF)) impacts reflectance and all variables derived or estimated based on these data. The recently released MODIS BRDF/Albedo Model Parameters (MCD43A1 Collection 6) dataset enables retrieval of directional reflectance at arbitrary solar and viewing angles, potentially increasing precision and comparability of data collected under different illumination and observation geometries. We quantified the ability of MCD43A1 Collection 6 for retrieving directional reflectance and compared the daily Collection 6 retrievals to those of MCD43A1 Collection 5, which are retrieved on an eight-day basis. Correcting MODIS-based estimates of surface reflectance from the illumination and viewing geometry of the Terra satellite (MOD09GA) to that of the MODIS Aqua (MYD09GA) overpass, as well as MCD43A4 Collection 6 and Landsat-5 TM images show that the BRDF correction of MCD43A1 Collection 6 results in greater consistency among datasets, with higher R2 (0.63–0.955), regression slopes closer to unity (0.718–0.955), lower root mean squared difference (RMSD) (0.422–3.142), and lower mean absolute error (MAE) (0.282–1.735) compared to the Collection 5 data. Smaller levels of noise (observed as high-frequency variability within the time series) in MCD43A1 Collection 6 in comparison to Collection 5 corroborates the improvement of BRDF parameters time series. These results corroborates that the daily MCD43A1 Collection 6 product represents the anisotropy of surface features and results in more precise directional reflectance derivation at any solar and viewing geometry than did the previous Collection 5. View Full-Text
Keywords: directional reflectance; BRDF correction; Moderate Resolution Imaging Spectroradiometer (MODIS); MCD43A1 Collection 6 directional reflectance; BRDF correction; Moderate Resolution Imaging Spectroradiometer (MODIS); MCD43A1 Collection 6

Graphical abstract

This is an open access article distributed under the Creative Commons Attribution License which permits unrestricted use, distribution, and reproduction in any medium, provided the original work is properly cited (CC BY 4.0).
