Open AccessArticle
Remote Sens. 2018, 10(2), 345; https://doi.org/10.3390/rs10020345

Impacts of Insufficient Observations on the Monitoring of Short- and Long-Term Suspended Solids Variations in Highly Dynamic Waters, and Implications for an Optimal Observation Strategy

1
School of Remote Sensing and Information Engineering, Wuhan University, Wuhan 430079, China
2
State Key Laboratory of Information Engineering in Surveying, Mapping and Remote Sensing, Wuhan University, Wuhan 430079, China
3
Department of Civil and Environmental Engineering, The Hong Kong Polytechnic University, Kowloon, Hong Kong, China
4
State Key Laboratory of Tropical Oceanography, South China Sea Institute of Oceanology, Chinese Academy of Sciences, Guangzhou 510301, China
*
Author to whom correspondence should be addressed.
Received: 7 December 2017 / Revised: 10 February 2018 / Accepted: 16 February 2018 / Published: 23 February 2018
  |
PDF [5477 KB, uploaded 23 February 2018]
  |

Abstract

Coastal water regions represent some of the most fragile ecosystems, exposed to both climate change and human activities. While remote sensing provides unprecedented amounts of data for water quality monitoring on regional to global scales, the performance of satellite observations is frequently impeded by revisiting intervals and unfavorable conditions, such as cloud coverage and sun glint. Therefore, it is crucial to evaluate the impacts of varied sampling strategies (time and frequency) and insufficient observations on the monitoring of short-term and long-term tendencies of water quality parameters, such as suspended solids (SS), in highly dynamic coastal waters. Taking advantage of the first high-frequency in situ SS dataset (at 30 min sampling intervals from 2007 to 2008), collected in Deep Bay, China, this paper presents a quantitative analysis of the influences of sampling strategies on the monitoring of SS, in terms of sampling frequency and time of day. Dramatic variations of SS were observed, with standard deviation coefficients of 48.9% and 54.1%, at two fixed stations; in addition, significant uncertainties were revealed, with the average absolute percent difference of approximately 13%, related to sampling frequency and time, using nonlinear optimization and random simulation methods. For a sampling frequency of less than two observations per day, the relative error of SS was higher than 50%, and stabilized at approximately 10%, when at least four or five samplings were conducted per day. The optimal recommended sampling times for SS were at around 9:00, 12:00, 14:00, and 16:00 in Deep Bay. The “pseudo” MODIS SS dataset was obtained from high-frequency in situ SS measurements at 10:30 and 14:00, masked by the temporal gap distribution of MODIS coverage to avoid uncertainties propagated from atmospheric correction and SS models. Noteworthy uncertainties of daily observations from the Terra/Aqua MODIS were found, with mean relative errors of 19.2% and 17.8%, respectively, whereas at the monthly level, the mean relative error of Terra/Aqua MODIS observations was approximately 10.7% (standard deviation of 8.4%). Sensitivity analysis between MODIS coverage and SS relative errors indicated that temporal coverage (the percentage of valid MODIS observations for a month) of more than 70% is required to obtain high-precision SS measurements at a 5% error level. Furthermore, approximately 20% of relative errors were found with the coverage of 30%, which was the average coverage of satellite observations over global coastal waters. These results highlight the need for high-frequency measurements of geostationary satellites like GOCI and multi-source ocean color sensors to capture the dynamic process of coastal waters in both the short and long term. View Full-Text
Keywords: coastal waters; suspended solids; remote sensing; sampling strategy; high frequency coastal waters; suspended solids; remote sensing; sampling strategy; high frequency
Figures

Graphical abstract

This is an open access article distributed under the Creative Commons Attribution License which permits unrestricted use, distribution, and reproduction in any medium, provided the original work is properly cited (CC BY 4.0).
SciFeed

Share & Cite This Article

MDPI and ACS Style

Zhou, Q.; Tian, L.; Wai, O.W.H.; Li, J.; Sun, Z.; Li, W. Impacts of Insufficient Observations on the Monitoring of Short- and Long-Term Suspended Solids Variations in Highly Dynamic Waters, and Implications for an Optimal Observation Strategy. Remote Sens. 2018, 10, 345.
