Energies 2016, 9(4), 275;

Effect of Guide Vane Clearance Gap on Francis Turbine Performance

State Key Laboratory of Hydroscience and Engineering, Department of Thermal Engineering, Tsinghua University, Beijing 100084, China
Turbine Testing Lab, Kathmandu University, P.O. Box 6250, Dhulikhel, Nepal
Author to whom correspondence should be addressed.
Academic Editor: Jang-Ho Lee
Received: 4 January 2016 / Revised: 6 March 2016 / Accepted: 10 March 2016 / Published: 11 April 2016
(This article belongs to the Special Issue Selected Papers from 5th Asia-Pacific Forum on Renewable Energy)
Full-Text   |   PDF [9540 KB, uploaded 11 April 2016]   |


Francis turbine guide vanes have pivoted support with external control mechanism, for conversion of pressure to kinetic energy and to direct them to runner vanes. This movement along the support is dependent on variation of load and flow (operating conditions). Small clearance gaps between facing plates and the upper and lower guide vane tips are available to aid this movement, through which leakage flow occurs. This secondary flow disturbs the main flow stream, resulting performance loss. Additionally, these increased horseshoe vortex, in presence of sand, when crosses through the gaps, both the surfaces are eroded. This causes further serious effect on performance and structural property by increasing gaps. This paper discusses the observation of the severity in hydropower plants and effect of clearance gaps on general performance of the Francis turbine through computational methods. It also relates the primary result with the empirical relation for leakage flow prediction. Additionally, a possible method to computationally estimate thickness depletion has also been presented. With increasing clearance gap, leakage increases, which lowers energy conversion and turbine efficiency along with larger secondary vortex. View Full-Text
Keywords: guide vanes; sediment erosion; clearance gap; performance; leakage flow guide vanes; sediment erosion; clearance gap; performance; leakage flow

Figure 1

This is an open access article distributed under the Creative Commons Attribution License which permits unrestricted use, distribution, and reproduction in any medium, provided the original work is properly cited (CC BY 4.0).
