An Optimization Study on Soot-Blowing of Air Preheaters in Coal-Fired Power Plant Boilers

1
School of Electrical and Control Engineering, North University of China, Taiyuan 030051, China
2
Department of Automation, Shanghai Jiao Tong University, and Key Laboratory of System Control and Information Processing, Ministry of Education of China, Shanghai 200240, China
3
School of Data Science and Technology, North University of China, Taiyuan 030051, China
4
Autonomous Systems and Intelligent Control International Joint Research Center, Xi’an Technological University, Xi’an 710021, China
*
Author to whom correspondence should be addressed.
Received: 28 January 2019 / Revised: 7 March 2019 / Accepted: 8 March 2019 / Published: 12 March 2019
(This article belongs to the Section Energy Fundamentals and Conversion)
Full-Text   |   PDF [2287 KB, uploaded 13 March 2019]   |

Abstract

This paper presents a comprehensive approach for optimization of soot-blowing of air preheaters in a coal-fired power plant boiler. In the method, modeling of the cleanliness factor is firstly proposed to monitor the ash deposition status of the air preheaters. Then, the statistical fitting of the ash fouling status is subsequently obtained to analyze the ash fouling dynamics and assessment of optimized soot-blowing strategies. Soot-blowing strategies are finally developed to optimize the steam consumption and heat transfer efficiency. Our methods can achieve the fouling monitoring and soot-blowing optimization of air preheater (APH) by using the existing monitoring data, not requiring additional special instruments and complex computing systems. The methodology is validated with the actual operating data of a 300 MW coal-fired power plant boiler. The results show the effectiveness of the proposed method. It can be used for the soot-blowing optimization in most coal-fired power plant boiler with air preheaters. View Full-Text
Keywords: coal-fired power plant boiler; air preheater; ash fouling monitoring; cleanliness factor; fouling dynamics; soot-blowing optimization coal-fired power plant boiler; air preheater; ash fouling monitoring; cleanliness factor; fouling dynamics; soot-blowing optimization
Figures

Figure 1

This is an open access article distributed under the Creative Commons Attribution License which permits unrestricted use, distribution, and reproduction in any medium, provided the original work is properly cited (CC BY 4.0).
SciFeed

Share & Cite This Article

MDPI and ACS Style

Shi, Y.; Wen, J.; Cui, F.; Wang, J. An Optimization Study on Soot-Blowing of Air Preheaters in Coal-Fired Power Plant Boilers. Energies 2019, 12, 958.
