Automated Directional Measurement System for the Acquisition of Thermal Radiative Measurements of Vegetative Canopies
Abstract
:1. Introduction
2. Materials and Methods
2.1. Original Goniometric Setup
2.2. Improvements
2.2.1. Automated Control
2.2.2. Viewing Angles
2.2.3. Operational calibration
2.3. Sensors
2.4. Fieldsites
3. Results and Discussion
3.1. Within-species Differences in Canopy Structure
3.1.1. Grass
3.1.2. Maize
3.2. Inter-species Differences in Canopy Structure
3.3. Discussion
4. Conclusions
Acknowledgments
References and Notes
