LiDAR- and AR-Based Monitoring of Evolved Building Façades upon Zoning Conflicts
Department of Architecture, National Taiwan University of Science and Technology, Taipei 106, Taiwan
*
Author to whom correspondence should be addressed.
Sensors 2020, 20(19), 5628; https://doi.org/10.3390/s20195628
Received: 13 September 2020
/
Revised: 23 September 2020
/
Accepted: 25 September 2020
/
Published: 1 October 2020
(This article belongs to the Special Issue Sensors for Cultural Heritage Monitoring)
Zoning conflicts have transformed Old Street fabrics in terms of architectural style and construction material in Lukang, Taiwan. This transformation should be assessed as a contribution to digital cultural sustainability. The objective of this study was to compare the evolved façades resultant from the changes made by the development of architectural history and urban planning. A combination of 3D scan technology and a smartphone augmented reality (AR) app, Augment®, was applied to the situated comparison with direct interaction on-site. The AR application compared 20 façades in the laboratory and 18 façades in four different sites using a flexible interface. The comparisons identified the correlation of evolved façades in real sites in terms of building volumes and components, pedestrian arcades on store fronts, and previous installations. The situated comparisons were facilitated in a field study with real-time adjustments to 3D models and analyses of correlations across details and components. The application of AR was demonstrated to be effective in reinstalling scenes and differentiating diversified compositions of vocabulary in a remote site.
View Full-Text
Keywords:
markerless AR; LiDAR; old street heritage; building façade; architecture style; situated study; smartphone
▼
Show Figures
Figure 1
This is an open access article distributed under the Creative Commons Attribution License which permits unrestricted use, distribution, and reproduction in any medium, provided the original work is properly cited
