Search Results (19)

Timely and accurate detection of wind turbine blade surface defects is crucial for ensuring operational safety and improving maintenance efficiency with respect to large-scale wind farms. However, existing methods often suffer from poor generalization, background interference, and inadequate real-time performance. To overcome these limitations, we developed an end-to-end defect recognition framework, structured as a three-stage process: blade localization using YOLOv5, robust feature extraction via the large vision model DINOv2, and defect classification using a Stochastic Configuration Network (SCN). Unlike conventional CNN-based approaches, the use of DINOv2 significantly improves the capability for representation under complex textures. The experimental results reveal that the proposed method achieved a classification accuracy of 97.8% and an average inference time of 19.65 ms per image, satisfying real-time requirements. Compared to traditional methods, this framework provides a more scalable, accurate, and efficient solution for the intelligent inspection and maintenance of wind turbine blades. Full article

Real-time non-intrusive monitoring of wind turbines, blades, and defect surfaces poses a set of complex challenges related to accuracy, safety, cost, and computational efficiency. This work introduces an enhanced deep learning-based framework for real-time detection of wind turbine blade defects. The WindDefNet is introduced, which features the Inception-ResNet modules, Visual Transformer (ViT), and multi-scale attention mechanisms. WindDefNet utilizes modified cross-convolutional blocks, including the powerful Inception-ResNet hybrid, to capture both fine-grained and high-level features from input images. A multi-scale attention module is added to focus on important regions in the image, improving detection accuracy, especially in challenging areas of the wind turbine blades. We employ pertaining to Inception-ResNet and ViT patch embedding architectures to achieve superior performance in defect classification. WindDefNet’s capability to capture and integrate multi-scale feature representations enhances its effectiveness for robust wind turbine condition monitoring, thereby reducing operational downtime and minimizing maintenance costs. Our model WindDefNet integrates a novel advanced attention mechanism, with custom-pretrained Inception-ResNet combining self-attention with a Visual Transformer encoder, to enhance feature extraction and improve model accuracy. The proposed method demonstrates significant improvements in classification performance, as evidenced by the evaluation metrics attain precision, recall, and F1-scores of 0.88, 1.00, and 0.93 for the damage, 1.00, 0.71, and 0.83 for the edge, and 1.00, 1.00, and 1.00 for both the erosion and normal surfaces. The macro-average and weighted-average F1 scores stand at 0.94, highlighting the robustness of our approach. These results underscore the potential of the proposed model for defect detection in industrial applications. Full article

Interface debonding between high-strength grouting materials and the inner surfaces of steel tubes in grouting jacket connections (GJCs), which have been widely employed in offshore wind turbine support structures, negatively affects their mechanical behavior. In this study, an interface debonding defect detection and localization approach for scaled underwater GJC specimens using surface wave measurements with piezoelectric lead zirconate titanate (PZT) actuation and sensing technology was validated experimentally. Firstly, GJC specimens with artificially mimicked interface debonding defects of varying dimensions were designed and fabricated in the lab, and the specimens were immersed in water to replicate the actual underwater working environment of GJCs in offshore wind turbine structures. Secondly, to verify the feasibility of the proposed interface debonding detection approach using surface wave measurements, the influence of the height and circumferential dimension of the debonding defects on the output voltage signal of PZT sensors was systematically studied experimentally using a one pitch and one catch (OPOC) configuration. Thirdly, a one pitch and multiple catch (OPMC) configuration was further employed to localize and visualize the debonding defect regions. An abnormal value analysis was carried out on the amplitude of the output voltage signals from PZT sensors with identical wave traveling paths, and the corresponding abnormal surface wave propagation paths were identified. Finally, based on the influence of interface debonding on the surface wave measurements mentioned above, the mimicked interface debonding defect was detected successfully and the region of debonding was determined with the intersection of the identified abnormal wave travelling paths. The results showed that the mimicked debonding defect can be visualized. The feasibility of this method for interface debonding defect detection in underwater GJCs was confirmed experimentally. The proposed approach provides a novel non-destructive debonding defect detection approach for the GJCs in offshore wind turbine structures. Full article

Interface debonding between the steel tube and grouting materials in grouting jacket connections (GJCs) of offshore wind turbine supporting structures leads to negative effects on the load-carrying capacity and safety concerns. In this paper, an interface debonding defect detection and localization approach for scale underwater GJC specimens using surface wave measurement is proposed and validated numerically. A multi-physics finite element model (FEM) of underwater GJCs with mimicked interface debonding defects, surrounded by water, and coupled with surface-mounted piezoelectric lead zirconate titanate (PZT) patches is established. Under the excitation of a five-cycle modulated signal, the surface stress wave propagation, including transmission, diffraction, and reflection, within the outer steel tube, grouting material, and inner steel tube is simulated. The influence of mimicked interface debonding defects of varying dimensions on stress wave propagation is systematically analyzed through stress wave field distributions at distinct time intervals. Additionally, the response of surface-mounted PZT sensors in the underwater GJC model under a one-pitch-one-catch (OPOC) configuration is analyzed. Numerical results demonstrate that the wavelet packet energy (WPE) of the surface wave measurement from the PZT sensors corresponding to the traveling path with a mimicked interface debonding defect is larger than that without a defect. To further localize the debonding region, a one pitch and multiple catch (OPMC) configuration is employed, and an abnormal value analysis is conducted on the WPEs of PZT sensor measurements with identical and comparable wave traveling patches. The identified debonding regions correspond to the simulated defects in the models. Full article

Due to the numerous disadvantages that come with having anchors in the detection process, a lot of researchers have been concentrating on the design of object detectors that do not rely on anchors. In this work, we use anchor-free object detectors in the field of computer vision for surface defect detection. First, we constructed a surface defect detection dataset about real wind turbine blades, which was supplemented with several methods due to the lack of natural data. Next, we used a number of popular anchor-free detectors (CenterNet, FCOS, YOLOX-S, and YOLOV8-S) to detect surface defects in this blade dataset. After experimental comparison, YOLOV8-S demonstrated the best detection performance, with a high accuracy (79.55%) and a short detection speed (9.52 fps). All the upcoming experiments are predicated on it. Third, we examined how the attention mechanism added to various YOLOV8-S model positions affected the two datasets—our blade dataset and the NEU dataset—and discovered that the insertion methods on the two datasets are the same when focusing on comprehensive performance. Lastly, we carried out a significant amount of experimental comparisons. Full article

Wind turbine blades (WTBs) are prone to damage from their working environment, including surface peeling and cracks. Early and effective detection of surface defects on WTBs can avoid complex and costly repairs and serious safety hazards. Traditional object detection methods have disadvantages of insufficient detection capabilities, extended model inference times, low recognition accuracy for small objects, and elongated strip defects within WTB datasets. In light of these challenges, a novel model named DCW-YOLO for surface damage detection of WTBs is proposed in this research, which leverages image data collected by unmanned aerial vehicles (UAVs) and the YOLOv8 algorithm for image analysis. Firstly, Dynamic Separable Convolution (DSConv) is introduced into the C2f module of YOLOv8, allowing the model to more effectively focus on the geometric structural details associated with damage on WTBs. Secondly, the upsampling method is replaced with the content-aware reassembly of features (CARAFE), which significantly minimizes the degradation of image characteristics throughout the upsampling process and boosts the network’s ability to extract features. Finally, the loss function is substituted with the WIoU (Wise-IoU) strategy. This strategy allows for a more accurate regression of the target bounding boxes and helps to improve the reliability in the localization of WTBs damages, especially for low-quality examples. This model demonstrates a notable superiority in surface damage detection of WTBs compared to the original YOLOv8n and has achieved a substantial improvement in the mAP@0.5 metric, rising from 91.4% to 93.8%. Furthermore, in the more rigorous mAP@0.5–0.95 metric, it has also seen an increase from 68.9% to 71.2%. Full article

This study addresses the challenge of accurately calculating the depth of inclusion defects in Glass Fiber-Reinforced Plastic (GFRP), which is commonly used in onshore wind turbine blades. To overcome this issue, we proposed a novel Excess Surface Temperature Peak Time (ESPT) estimation method that combines a conjugate gradient algorithm with a conventional analytical approach. This research employed the Inverse Heat Transfer Problem (IHTP) solution method to estimate the boundary conditions of an experimental sample subjected to pulse excitation. By drawing analogies with traditional depth detection methods, we analyzed specific physical models and determined the calculated thickness of the sample. The Excess Surface Temperature Peak Time characteristics were then used to estimate the defect depth, and the resulting estimates and relative errors were evaluated. Our results demonstrated that the proposed method achieved a relative error of less than 15% when calculating defect depth, confirming its effectiveness. This approach provides new insights and possibilities for improving defect depth estimation in GFRP materials, offering valuable contributions to the assessment and maintenance of wind turbine blade safety. Full article

Wind energy is a renewable resource with abundant reserves, and its sustainable development and utilization are crucial. The components of wind turbines, particularly the blades and various surfaces, require meticulous defect detection and maintenance due to their significance. The operational status of wind turbine generators directly impacts the efficiency and safe operation of wind farms. Traditional surface defect detection methods for wind turbines often involve manual operations, which suffer from issues such as high subjectivity, elevated risks, low accuracy, and inefficiency. The emergence of computer vision technologies based on deep learning has provided a novel approach to surface defect detection in wind turbines. However, existing datasets designed for wind turbine surface defects exhibit overall category scarcity and an imbalance in samples between categories. The algorithms designed face challenges, with low detection rates for small samples. Hence, this study first constructs a benchmark dataset for wind turbine surface defects comprising seven categories that encompass all common surface defects. Simultaneously, a wind turbine surface defect detection algorithm based on improved YOLOv5 is designed. Initially, a multi-scale copy-paste data augmentation method is proposed, introducing scale factors to randomly resize the bounding boxes before copy-pasting. This alleviates sample imbalances and significantly enhances the algorithm’s detection capabilities for targets of different sizes. Subsequently, a dynamic label assignment strategy based on the Hungarian algorithm is introduced that calculates the matching costs by weighing different losses, enhancing the network’s ability to learn positive and negative samples. To address overfitting and misrecognition resulting from strong data augmentation, a two-stage progressive training method is proposed, aiding the model’s natural convergence and improving generalization performance. Furthermore, a multi-scenario negative-sample-guided learning method is introduced that involves incorporating unlabeled background images from various scenarios into training, guiding the model to learn negative samples and reducing misrecognition. Finally, slicing-aided hyper inference is introduced, facilitating large-scale inference for wind turbine surface defects in actual industrial scenarios. The improved algorithm demonstrates a 3.1% increase in the mean average precision (mAP) on the custom dataset, achieving 95.7% accuracy in mAP_50 (the IoU threshold is half of the mAP). Notably, the mAPs for small, medium, and large targets increase by 18.6%, 16.4%, and 6.8%, respectively. The experimental results indicate that the enhanced algorithm exhibits high detection accuracy, providing a new and more efficient solution for the field of wind turbine surface defect detection. Full article

In order to solve the problems of low efficiency, time consumption and high costs in the detection of defects on wind turbine surfaces in industrial scenarios, an improved YOLOv5 algorithm for wind turbine surface defect detection is proposed, named YOLOv5s-L. Firstly, the C3 module of YOLOv5s is replaced with the C2f module, which is more abundant in gradient flow, to enhance the ability of feature extraction and feature fusion. Secondly, the Squeeze and Excitation (SE) module is embedded in the YOLOv5 Backbone network to filter out redundant feature information and retain important feature information. Thirdly, the weighted Bidirectional Feature Pyramid Network (BiFPN) is introduced to replace the FPN + PAN, which can achieve a higher level of feature fusion while keeping the weight light. Finally, the Focal Loss function is used to replace the CIOU Loss function of the YOLOv5 algorithm to optimize the training model and improve the accuracy of the algorithm. The experimental results show that, compared with the traditional YOLOv5 algorithm, the average precision mAP is improved by 1.9%, and the frame rate FPS can reach 145 F/s without increasing the model parameters; it can satisfy the requirements for real-time, accurate detection on mobile devices. This method provides effective support for surface defect detection of wind turbines and provides reference for intelligent wind farm operation and maintenance. Full article

The processing of aerial images taken by drones is a challenging task due to their high resolution and the presence of small objects. The scale of the objects varies diversely depending on the position of the drone, which can result in loss of information or increased difficulty in detecting small objects. To address this issue, images are either randomly cropped or divided into small patches before training and inference. This paper proposes a defect detection framework that harnesses the advantages of slice-aided inference for small and medium-size damage on the surface of wind turbine blades. This framework enables the comparison of different slicing strategies, including a conventional patch division strategy and a more recent slice-aided hyper-inference, on several state-of-the-art deep neural network baselines for the detection of surface defects in wind turbine blade images. Our experiments provide extensive empirical results, highlighting the benefits of using the slice-aided strategy and the significant improvements made by these networks on an ultra high-resolution drone image dataset. Full article

The fast and accurate detection of wind turbine gearbox surface defects is crucial for wind turbine maintenance and power security. However, owing to the uneven distribution of gear surface defects and the interference of complex backgrounds, there are limitations to gear-surface defect detection; therefore, this paper proposes a multiscale feature reconstruction-based detection method for wind turbine gearbox surface defects. First, the Swin Transformer was used as a backbone network based on the PSPNet network to obtain global and local features through multiscale feature reconstruction. Second, a Feature Similarity Module was used to filter important feature sub-blocks, which increased the inter-class differences and reduced the intra-class differences to enhance the discriminative ability of the model for similar features. Finally, the fusion of contextual information using the pyramid pooling module enhanced the extraction of gear surface defect features at different scales. The experimental results indicated that the improved algorithm outperformed the original PSPNet algorithm by 1.21% and 3.88% for the mean intersection over union and mean pixel accuracy, respectively, and significantly outperformed semantic segmentation networks such as U-Net and DeepLabv3+. Full article

Wind turbine blades (WTBs) are critical sub-systems consisting of composite multi-layer material structures. WTB inspection is a complex and labour intensive process, and failure of it can lead to substantial energy and economic losses to asset owners. In this paper, we proposed a novel non-destructive evaluation method for blade composite materials, which employs Frequency Modulated Continuous Wave (FMCW) radar, robotics and machine learning (ML) analytics. We show that using FMCW raster scan data, our ML algorithms (SVM, BP, Decision Tree and Naïve Bayes) can distinguish different types of composite materials with accuracy of over 97.5%. The best performance is achieved by SVM algorithms, with 94.3% accuracy. Furthermore, the proposed method can also achieve solid results for detecting surface defect: interlaminar porosity with 80% accuracy overall. In particular, the SVM classifier shows highest accuracy of 92.5% to 98.9%. We also show the ability to detect air voids of 1mm differences within the composite material WT structure with 94.1% accuracy performance using SVM, and 84.5% using Naïve Bayes. Lastly, we create a digital twin of the physical composite sample to support the integration and qualitative analysis of the FMCW data with respect to composite sample characteristics. The proposed method explores a new sensing modality for non-contact surface and subsurface for composite materials, and offer insights for developing alternative, more cost-effective inspection and maintenance regimes. Full article

Wind power has become an important source of electricity for both production and domestic use. However, because wind turbines often operate in harsh environments, they are prone to cracks, blisters, and corrosion of the blade surface. If these defects cannot be repaired in time, the cracks evolve into larger fractures, which can lead to blade rupture. As such, in this study, we developed a remote non-contact online health monitoring and warning system for wind turbine blades based on acoustic features and artificial neural networks. Collecting a large number of wind turbine blade defect signals was challenging. To address this issue, we designed an acoustic detection method based on a small sample size. We employed the octave to extract defect information, and we used an artificial neural network based on model-agnostic meta-learning (MAML-ANN) for classification. We analyzed the influence of locations and compared the performance of MAML-ANN with that of traditional ANN. The experimental results showed that the accuracy of our method reached 94.1% when each class contained only 50 data; traditional ANN achieved an accuracy of only 85%. With MAML-ANN, the training is fast and the global optimal solution is automatic searched, and it can be expanded to situations with a large sample size. Full article

Wind turbines are known to be the most efficient method of green energy production, and wind turbine blades (WTBs) are known as a key component of the wind turbine system, with a major influence on the efficiency of the entire system. Wind turbine blades have a quite manual production process of composite materials, which induces various types of defects in the blade. Blades are susceptible to the damage developed by complex and irregular loading or even catastrophic collapse and are expensive to maintain. Failure or damage to wind turbine blades not only decreases the lifespan, efficiency, and fault diagnosis capability but also increases safety hazards and maintenance costs. Hence, non-destructive testing (NDT) methods providing surface and subsurface information for the blade are indispensable in the maintenance of wind turbines. Damage detection is a critical part of the inspection methods for failure prevention, maintenance planning, and the sustainability of wind turbine operation. Industry 4.0 technologies provide a framework for deploying smart inspection, one of the key requirements for sustainable wind energy production. The wind energy industry is about to undergo a significant revolution due to the integration of the physical and virtual worlds driven by Industry 4.0. This paper aims to highlight the potential of Industry 4.0 to help exploit smart inspections for sustainable wind energy production. This study is also elaborated by damage categorization and a thorough review of the state-of-the-art non-destructive techniques for surface and sub-surface inspection of wind turbine blades. Full article

Recently, the machine-vision-based blades surface damage detection technique has received great attention for its low cost, easy operation, and lack of a need for prior knowledge. The rapid progress of deep learning has contributed to the promotion of this technology with automatic feature extraction, a broader scope of application, and stronger expansibility. An image recognition method of wind turbine blade defects using attention-based MobileNetv1-YOLOv4 and transfer learning is proposed in this paper. The backbone convolution neural network of YOLOv4 is replaced by the lightweight MobileNetv1 for feature extraction to reduce complexity and computation. Attention-based feature refinement with three distinctive modules, SENet, ECANet, and CBAM, is introduced to realize adaptive feature optimization. To solve the problem of slow network convergence and low detection accuracy caused by insufficient data, a two-stage transfer learning approach is introduced to fine-tune the pre-trained network. Comparative experiments verify the efficacy of the proposed model, with higher detection accuracy but a significantly faster response speed and less computational complexity, compared with other state-of-the-art networks by using images of the wind turbine blades taken by an unmanned aerial vehicle (UAV). A sensitivity study is also conducted to present the effects of different training dataset sizes on the model performance. Full article
