Various short-range radars, such as impulse-radio ultra-wideband (IR-UWB) and frequency-modulated continuous-wave (FMCW) radars, are currently employed to monitor vital signs, including respiratory and cardiac rates (RRs and CRs). However, these methods do not consider the motion of an individual, which can distort the phase of the reflected signal, leading to inaccurate estimation of RR and CR because of a smeared spectrum. Therefore, motion compensation (MOCOM) is crucial for accurately estimating these vital rates. This paper proposes an efficient method incorporating MOCOM to estimate RR and CR with super-resolution accuracy. The proposed method effectively models the radar signal phase and compensates for motion. Additionally, applying the super-resolution technique to RR and CR separately further increases the estimation accuracy. Experimental results from the IR-UWB and FMCW radars demonstrate that the proposed method successfully estimates RRs and CRs even in the presence of body movement. Full article

Simultaneous localization and mapping (SLAM) is an essential component for smart robot operations in unknown confined spaces such as indoors, tunnels and underground. This paper proposes a novel tightly-coupled ranging-LiDAR-inertial simultaneous localization and mapping framework, namely RLI-SLAM, which is designed to be high-accuracy, fast and robust in the long-term fast-motion scenario, and features two key innovations. The first one is tightly fusing the ultra-wideband (UWB) ranging and the inertial sensor to prevent the initial bias and long-term drift of the inertial sensor so that the point cloud distortion of the fast-moving LiDAR can be effectively compensated in real-time. This enables high-accuracy and robust state estimation in the long-term fast-motion scenario, even with a single ranging measurement. The second one is deploying an efficient loop closure detection module by using an incremental smoothing factor graph approach, which seamlessly integrates into the RLI-SLAM system, and enables high-precision mapping in a challenging environment. Extensive benchmark comparisons validate the superior accuracy of the proposed new state estimation and mapping framework over other state-of-the-art systems at a low computational complexity, even with a single ranging measurement and/or in a challenging environment. Full article

Abstract: While software-defined radars can switch their transmitted waveform on the go, they cannot transmit all waveforms at the same time, meaning they must balance the advantages and drawbacks of each configuration. Here, we propose theoretically and demonstrate experimentally the universal radar, which can apply the desired waveform in the post-processing stage after the physical measurement has been performed. This method also allows using a single measurement of a scene to design and test any other radar in complex scenarios without having to take it to the field. The method is based on post-processing the frequency response measured by a synthetically broadband stepped-frequency continuous wave radar, such as a vector network analyzer. An algorithm for overcoming distortions due to moving targets is derived as well. This approach not only provides an ultra-wideband software-only defined radar, but it also enables the acquired data from any measured site to be used for the design and analysis of almost any other future radar system, significantly cutting the time and cost of new developments. The method suggests the creation of radar raw data repositories that can be shared across diversely different radar platforms. Full article

Stride length (SL), foot clearance (FC), and foot progression angle (FPA) are the key parameters for diagnosing gait disorders. This study used the distance data between two feet measured by ultra-wideband (UWB) sensors installed on shoes and proposed a method for estimating the three gait parameters. Here, a method of compensating the offset of the UWB sensor and estimating the distances between a base sensor installed on one foot during the stance phase and three UWB sensors on the other during the swing phase was applied. Foot trajectory was acquired in a gait experiment with ten healthy adults walking on a treadmill. The results were compared with those obtained using a motion capture system (MCS). The UWBs sensor displayed average errors of 45.84 mm, 7.60 mm, and 2.82° for SL, FC, and FPA, respectively, compared with the MCS. A similar accuracy level was achieved in a previous study that used an inertial measurement unit (IMU). Thus, these results suggest that UWB sensors can be extensively applied to sensor systems used to analyze mobile gait systems. Full article

In GNSS-denied environments, especially when losing measurement sensor data, inertial navigation system (INS) accuracy is critical to the precise positioning of vehicles, and an accurate INS error compensation model is the most effective way to improve INS accuracy. To this end, a two-level error model is proposed, which comprehensively utilizes the mechanism error model and propagation error model. Based on this model, the INS and ultra-wideband (UWB) fusion positioning method is derived relying on the extended Kalman filter (EKF) method. To further improve accuracy, the data prefiltering algorithm of the wavelet shrinkage method based on Stein’s unbiased risk estimate–Shrink (SURE-Shrink) threshold is summarized for raw inertial measurement unit (IMU) data. The experimental results show that by employing the SURE-Shrink wavelet denoising method, positioning accuracy is improved by 76.6%; by applying the two-level error model, the accuracy is further improved by 84.3%. More importantly, at the point when the vehicle motion state changes, adopting the two-level error model can provide higher computational stability and less fluctuation in trajectory curves. Full article

The smart unmanned aerial vehicle (UAV) with a mini-SAR payload provides an advanced earth observation capability for target detection and imaging. Simiar to large-scale SAR, mini-SAR also has an increasing requirement for high resolution and wide swath. However, due to the low cruising altitude of UAVs, small coverage angles in the direction range, and the insufficient operating range of mini-SAR, expanding the swath has become an urgent problem for mini-SAR. To solve this problem, this paper proposes a W-Band active phased array miniaturized SAR (APA mini-SAR), whose scanning capacity has been proven on the multi-rotor UAV platform. Many efforts, including the novel active phased array antenna scheme, the sparse triangular arrangement of antenna elements, the wideband chirp source, and the three-dimensional integration technology, have been made to develop this APA mini-SAR for the first time in the W-Band. The volume of this APA mini-SAR is 69 × 82 × 87 mm³, with a weight of 600 g. Combined with a new motion compensation strategy and the ω-k imaging algorithm, the focused image is finally obtained. Experiments have been conducted, and the results indicate that this APA mini-SAR has a resolution of 4.5 cm, the imaging swath is three times that of the traditional single-channel mini-SAR, and the operating range is increased to 800 m. Full article

As an important and basic platform for remote life sensing, unmanned aerial vehicles (UAVs) may hide the vital signals of an injured human due to their own motion. In this work, a novel method to remove the platform motion and accurately extract human respiration is proposed. We utilized a hovering UAV as the platform of ultra-wideband (UWB) radar to capture human respiration. To remove interference from the moving UAV platform, we used the delay calculated by the correlation between each frame of UWB radar data in order to compensate for the range migration. Then, the echo signals from the human target were extracted as the observed multiple range channel signals. Owing to meeting the independent component analysis (ICA), we adopted ICA to estimate the signal of respiration. The results of respiration detection experiments conducted in two different outdoor scenarios show that our proposed method could accurately separate respiration of a ground human target without any additional sensor and prior knowledge; this physiological information will be essential for search and rescue (SAR) missions. Full article

Stepped-frequency waveform may be used to synthesize a wideband signal with several narrow-band pulses and achieve a high-resolution range profile without increasing the instantaneous bandwidth. Nevertheless, the conventional stepped-frequency waveform is Doppler sensitive, which greatly limits its application to moving targets. For this reason, this paper proposes a waveform design method using a staggered pulse repetition frequency to improve the Doppler tolerance effectively. First, a generalized echo model of the stepped-frequency waveform is constructed in order to analyze the Doppler sensitivity. Then, waveform design is carried out in the stepped-frequency waveform by using a staggered pulse repetition frequency so as to eliminate the high-order phase component that is caused by the target’s velocity. Further, the waveform design method is extended to the sparse stepped-frequency waveform, and we also propose corresponding methods for high-resolution range profile synthesis and motion compensation. Finally, experiments with electromagnetic data verify the high Doppler tolerance of the proposed waveform. Full article

A novel coherent integration method for the wideband radar is proposed in this paper based on two-dimensional frequency correction. The method realizes the motion compensation by data re-alignment in the fast time frequency-Doppler domain and can be implemented quickly and efficiently based on chirp-Z transform. The proposed method is validated by simulation and measured data. The work in this paper provides a new and effective way for coherent integration in wideband radar. Full article

While there is a wide range of approaches to monitor industrial machinery through their static components, rotating components are usually harder to monitor, since sensors are difficult to be mounted on them and continuously read during operation. However, the characteristics of rotating components may provide useful information about the machine condition to be included in monitoring algorithms, specially for long-term data analysis. In this work, wireless vibration monitoring of rotating machine parts is investigated using surface acoustic wave (SAW) radio frequency identification (RFID) tags coupled with sensors. The proposed augmented transponder solution, combined with low-latency interrogation and signal processing, enables real-time identification and wideband vibration sensing. On top of that, a multi-channel interrogation approach is used to compensate motion effects. This approach enhances the signal-to-noise ratio of low-power high-frequency components present on the vibration signatures and enables discriminant information extraction from rotating machine parts. Final feasibility is evaluated with induction motors and vibration measurements on rotating shafts are verified. In addition, a condition classification algorithm is implemented in an experimental setup based on different motor states. The results of this work open the possibility to feed predictive maintenance algorithms using new features extracted in real-time from wideband vibration measurements on rotating components. Full article

Recognizing and tracking the targets located behind walls through impulse radio ultra-wideband (IR-UWB) radar provides a significant advantage, as the characteristics of the IR-UWB radar signal enable it to penetrate obstacles. In this study, we design a through-wall radar system to estimate and track multiple targets behind a wall. The radar signal received through the wall experiences distortion, such as attenuation and delay, and the characteristics of the wall are estimated to compensate the distance error. In addition, unlike general cases, it is difficult to maintain a high detection rate and low false alarm rate in this through-wall radar application due to the attenuation and distortion caused by the wall. In particular, the generally used delay-and-sum algorithm is significantly affected by the motion of targets and distortion caused by the wall, rendering it difficult to obtain a good performance. Thus, we propose a novel method, which calculates the likelihood that a target exists in a certain location through a detection process. Unlike the delay-and-sum algorithm, this method does not use the radar signal directly. Simulations and experiments are conducted in different cases to show the validity of our through-wall radar system. The results obtained by using the proposed algorithm as well as delay-and-sum and trilateration are compared in terms of the detection rate, false alarm rate, and positioning error. Full article

In-situ, wide-angle, and ultra-wideband inverse synthetic aperture radar (ISAR) imaging of vehicles and drones is demonstrated using a portable ultra-wideband radar. In order to form well-focused ISAR images, motion compensation is performed before applying the k-space imaging algorithm. While the same basic motion compensation methodology is applied to both types of targets, a more complex motion model is needed to better capture the flight path of the drone. The resulting ISAR images clearly show the geometrical outline of the targets and highlight locations of prominent backscattering. The ISAR images are also assessed against images generated through instrumented targets or laboratory measurements, and the image quality is shown to be comparable. Full article

A high resolution inverse synthetic aperture radar (ISAR) technique is presented using modified Doppler history based motion compensation. To this purpose, a novel wideband ISAR system is developed that accommodates parametric processing over extended aperture length. The proposed method is derived from an ISAR-to-SAR approach that makes use of high resolution spotlight SAR and sub-aperture recombination. It is dedicated to wide aperture ISAR imaging and exhibits robust performance against unstable targets having non-linear motions. We demonstrate that the Doppler histories of the full aperture ISAR echoes from disturbed targets are efficiently retrieved with good fitting models. Experiments have been conducted on real aircraft targets and the feasibility of the full aperture ISAR processing is verified through the acquisition of high resolution ISAR imagery. Full article
