Whispering-gallery-mode (WGM) microresonators are amongst the most promising optical sensors for detecting bio-chemical targets. A number of laser interrogation methods have been proposed and demonstrated over the last decade, based on scattering and absorption losses or resonance splitting and shift, harnessing the high-quality factor and ultra-small volume of WGMs. Actually, regardless of the sensitivity enhancement, their practical sensing operation may be hampered by the complexity of coupling devices as well as the signalprocessing required to extract the WGM response. Here, we use a silica microsphere immersed in an aqueous environment and efficiently excite optical WGMs with a free-space visible laser, thus collecting the relevant information from the transmitted and back-scattered light without any optical coupler, fiber, or waveguide. We show that a 640-nm diode laser, actively frequency-locked on resonance, provides real-time, fast sensing of dielectric nanoparticles approaching the surface with direct analog readout. Thanks to our illumination scheme, the sensor can be kept in water and operate for days without degradation or loss of sensitivity. Diverse noise contributions are carefully considered and quantified in our system, showing a minimum detectable particle size below 1 nm essentially limited by the residual laser microcavity jitter. Further analysis reveals that the inherent laserfrequency instability in the short, -mid-term operation regime sets an ultimate bound of 0.3 nm. Based on this work, we envisage the possibility to extend our method in view of developing new viable approaches for detection of nanoplastics in natural water without resorting to complex chemical laboratory methods. Full article

CdS nanowires have garnered considerable attention lately for their promising potential in next-generation nanolaser devices, attributed to their relatively high stability and exceptional emission efficiency within the Ⅱ–Ⅵ semiconductor family. In this study, tin-doped CdS nanowires with varying dimensions were synthesized, and the underlying mechanisms responsible for the formation of micro-cavities within these nanowires were systematically explored through scanning electron microscopy (SEM) analysis and photoluminescence mapping. The results show that a very distinct hexagonal-shaped micro-cavity is observed on the cross-section of CdS nanowires, and the size of the micro-cavity is determined by the radius of the nanowire. Additionally, through the use of angle-resolved micro-fluorescence Fourier imaging technology, it is found that under high excitation density conditions, the micro-cavity mode is more prominent at higher collection angles, which is consistent with the mode of the wall-pass cavity micro-cavity. Finally, the formation of the full reflection spectrum of the micro-cavity mode is confirmed through the wavelength shift and intensity shift phenomena related to the excitation power. These results further deepen our understanding of the micro-cavity modes in tin-doped cadmium sulfide nanowires, which may be of great significance for the application of these nanowires in new optical devices. Full article

We propose a low-frequency magnetic sensing method using a magnetically modulated microcavity resonant mode. Our magnetically sensitive unit with periodically changing magnetic poles is formed by combining an AC excitation coil with a microcavity. The microcavity vibrates at the frequency of the AC amplitude-modulated signal and changes its resonant mode when the sensing unit interacts with a low-frequency magnetic field. Signal processing is performed on the resonant spectrum to obtain low-frequency magnetic signals. The results of the experiment show that the measured sensitivity to a 0.5 Hz magnetic field is 12.49 V/mT, and a bias instability noise of 16.71 nT is achieved. We have extended the measurable frequency range of the whispering gallery mode microcavity magnetometer and presented a development in microcavity magnetic sensing and optical readout. Full article

A method for achieving the single-mode and efficient unidirectional emission of a whispering gallery mode (WGM) semiconductor laser is presented herein. Hybrid square-rectangular lasers (HSRLs) and hybrid square/rhombus-rectangular lasers (HSRRLs) consisting of a Fabry–Pérot (FP) cavity and a square or rhombus cavity microcavity are described. In addition, a transmitter optical subassembly (TOSA) based on an HSRRL chip was fabricated, which has a wide and continuous wavelength tuning range. Wavelength channels from 1555.75 nm to 1568.15 nm with a spacing of 50 GHz were demonstrated with a good side mode suppression ratio (SMSR) and good output power. These devices have the potential to meet the typical requirements of optical communication networks. Full article

Optical microcavities are known for their strongly enhanced light–matter interactions. Whispering gallery mode (WGM) microresonators have important applications in nonlinear optics, single-mode output, and biosensing. However, there are few studies on resonance modes in the ultraviolet spectrum because most materials with high absorption properties are in the ultraviolet band. In this study, the performance of a microdisk cavity based on boron nitride (BN) was simulated by using the Finite-difference time-domain (FDTD) method. The WGM characteristics of a single BN microdisk with different sizes were obtained, wherein the resonance modes could be regulated from 270 nm to 350 nm; additionally, a single-mode at 301.5 nm is achieved by cascading multiple BN microdisk cavities. Moreover, we found that a BN microdisk with a diameter of 2 μm has a position-independent precise sensitivity for the nanoparticle of 140 nm. This study provides new ideas for optical microcavities to achieve single-mode management and novel coronavirus size screening, such as SARS-CoV-2, in the ultraviolet region. Full article

Raman microlasers form on-chip versatile light sources by optical pumping, enabling numerical applications ranging from telecommunications to biological detection. Stimulated Raman scattering (SRS) lasing has been demonstrated in optical microresonators, leveraging high Q factors and small mode volume to generate downconverted photons based on the interaction of light with the Stokes vibrational mode. Unlike redshifted SRS, stimulated anti-Stokes Raman scattering (SARS) further involves the interplay between the pump photon and the SRS photon to generate an upconverted photon, depending on a highly efficient SRS signal as an essential prerequisite. Therefore, achieving SARS in microresonators is challenging due to the low lasing efficiencies of integrated Raman lasers caused by intrinsically low Raman gain. In this work, high-Q whispering gallery microresonators were fabricated by femtosecond laser photolithography assisted chemo-mechanical etching on thin-film lithium niobate (TFLN), which is a strong Raman-gain photonic platform. The high Q factor reached 4.42 × 10⁶, which dramatically increased the circulating light intensity within a small volume. And a strong Stokes vibrational frequency of 264 cm⁻¹ of lithium niobate was selectively excited, leading to a highly efficient SRS lasing signal with a conversion efficiency of 40.6%. And the threshold for SRS was only 0.33 mW, which is about half the best record previously reported on a TFLN platform. The combination of high Q factors, a small cavity size of 120 μm, and the excitation of a strong Raman mode allowed the formation of SARS lasing with only a 0.46 mW pump threshold. Full article

In recent years, all-inorganic cesium lead bromide (CsPbBr₃) perovskites have garnered considerable attention for their prospective applications in green photonics and optoelectronic devices. However, the development of efficient and economical methods to obtain high-quality micron-sized single-crystalline CsPbBr₃ microplatelets (MPs) has become a challenge. Here, we report the synthesis of CsPbBr₃ MPs on Si/SiO₂ substrate by optimizing the ultrafast antisolvent method (FAS). This technique is able to produce well-dispersed, uniformly sized, and morphologically regular tetragonal phase single crystals, which can give strong green emission at room temperature, with excellent stability and excitonic character. Moreover, the crystals demonstrated lasing with a whispering gallery mode with a low threshold. These results suggest that the single-crystalline CsPbBr₃ MPs synthesized by this method are of high optical quality, holding vast potential for future applications in photonic devices. Full article

Whispering gallery mode resonators have proven to be robust and sensitive platforms for the trace detection of chemical and/or biological analytes. Conventional approaches using serially addressed resonators face challenges in simultaneous multi-channel (i.e., multi-species) detection. We present an alternative monitoring scheme that allows for the spatial multiplexing of whispering gallery mode resonators with the simultaneous observation of the resonance spectra from each of them. By imaging arrays of microspheres and monitoring the glare spot intensities through image processing routines, resonance spectra from multiple resonators may be simultaneously recorded without interference or confounding effects of serial excitation/detection. We demonstrate our multiplexed imaging approach with bulk refractive index variations and virus–antibody binding. Full article

The investigation of optical microcavity solitons is in demand both for applications and basic science. Despite the tremendous progress in the study of microresonator solitons, there is still no complete understanding of all features of their nonlinear dynamics in various regimes. Controlling soliton properties is also of great interest. We proposed and investigated experimentally and theoretically a simple and easily reproducible way to generate Raman solitons with controllable spectral width in an anomalous dispersion region in a functionalized silica microsphere with whispering gallery modes (WGMs) driven in a normal dispersion regime. To functionalize the microsphere, coating (TiO₂ + graphite powder) was applied at the pole. The coating is used for effective thermalization of the radiation of an auxiliary laser diode launched through the fiber stem holding the microsphere to control detuning of the pump frequency from exact resonance due to the thermo-optical shift of the WGM frequencies. We demonstrated that the thermo-optical control by changing the power of an auxiliary diode makes it possible to switch on/off the generation of Raman solitons and control their spectral width, as well as to switch Raman generation to multimode or single-mode. We also performed a detailed theoretical analysis based on the Raman-modified Lugiato–Lefever equation and explained peculiarities of intracavity nonlinear dynamics of Raman solitons. All experimental and numerically simulated results are in excellent agreement. Full article

High-quality factor dielectric microcavities like whispering-gallery-mode resonators can be widely applied in fields such as laser, optical sensor, switch, and filter. We propose the whispering-gallery-mode double-disk cavity comprising dielectric disks apart along the face of the disk. The electric field of each disk with opposite phases was excited; the emitted radiation field was annihilated by destructive interference. We numerically achieved a 5.67-fold enhancement in quality factor at the double-disk cavity with a radius, thickness, and gap distance of 850 nm, 220 nm, and 220 nm, respectively, compared to a single dielectric disk with the same structural conditions. Full article

Liquid crystals (LCs) have been widely used as sensitive elements to construct LC biosensors based on the principle that specific bonding events between biomolecules can affect the orientation of LC molecules. On the basis of the sensing interface of LC molecules, LC biosensors can be classified into three types: LC–solid interface sensing platforms, LC–aqueous interface sensing platforms, and LC–droplet interface sensing platforms. In addition, as a signal amplification method, the combination of LCs and whispering gallery mode (WGM) optical microcavities can provide higher detection sensitivity due to the extremely high quality factor and the small mode volume of the WGM optical microcavity, which enhances the interaction between the light field and biotargets. In this review, we present an overview of the basic principles, the structure, and the applications of LC biosensors. We discuss the important properties of LC and the principle of LC biosensors. The different geometries of LCs in the biosensing systems as well as their applications in the biological detection are then described. The fabrication and the application of the LC-based WGM microcavity optofluidic sensor in the biological detection are also introduced. Finally, challenges and potential research opportunities in the development of LC-based biosensors are discussed. Full article

Microlasers hold great promise for the development of photonics and optoelectronics. At present, tunable microcavity lasers, especially regarding in situ dynamic tuning, are still the focus of research. In this study, we combined a 0.7Pb(Mg_1/3Nb_2/3)O₃-0.3PbTiO₃ (PMN-PT) piezoelectric crystal with a Poly [9,9-dioctylfluorenyl-2,7-diyl] (PFO) microring cavity to realize a high-quality, electrically tunable, whispering-gallery-mode (WGM) laser. The dependence of the laser properties on the diameter of the microrings, including the laser spectrum and quality (Q) value, was investigated. It was found that with an increase in microring diameter, the laser emission redshifted, and the Q value increased. In addition, the device effectively achieved a blueshift under an applied electric field, and the wavelength tuning range was 0.71 nm. This work provides a method for in situ dynamic spectral modulation of microcavity lasers, and is expected to provide inspiration for the application of integrated photonics technology. Full article

Quantitative detection of cardiac troponin biomarkers in blood is an important method for clinical diagnosis of acute myocardial infarction (AMI). In this work, a whispering gallery mode (WGM) microcavity immunosensor based on a prefab hollow glass microsphere (HGMS) with liquid crystal (LC) sensitization was proposed and experimentally demonstrated for label-free cardiac troponin I-C (cTnI-C) complex detection. The proposed fiber-optic immunosensor has a simple structure; the tiny modified HGMS serves as the key sensing element and the microsample reservoir simultaneously. A sensitive LC layer with cTnI-C recognition ability was deposited on the inner wall of the HGMS microcavity. The arrangement of LC molecules is affected by the cTnI-C antigen—antibody binding in the HGMS, and the small change of the surface refractive index caused by the binding can be amplified owing to the birefringence property of LC. Using the annular waveguide of the HGMS, the WGMs were easily excited by the coupling scanning laser with a microfiber, and an all-fiber cTnI-C immunosensor can be achieved by measuring the resonant wavelength shift of the WGM spectrum. Moreover, the dynamic processes of the cTnI-C antigen—antibody binding and unbinding was revealed by monitoring the wavelength shift continuously. The proposed immunosensor with a spherical microcavity can be a cost-effective tool for AMI diagnosis. Full article

Whispering-gallery-mode (WGM) microbubble resonators are ideal optical sensors due to their high quality factor, small mode volume, high optical energy density, and geometry/design/structure (i.e., hollow microfluidic channels). When used in combination with microfluidic technologies, WGM microbubble resonators can be applied in chemical and biological sensing due to strong light–matter interactions. The detection of ultra-low concentrations over a large dynamic range is possible due to their high sensitivity, which has significance for environmental monitoring and applications in life-science. Furthermore, WGM microbubble resonators have also been widely used for physical sensing, such as to detect changes in temperature, stress, pressure, flow rate, magnetic field and ultrasound. In this article, we systematically review and summarize the sensing mechanisms, fabrication and packing methods, and various applications of optofluidic WGM microbubble resonators. The challenges of rapid production and practical applications of WGM microbubble resonators are also discussed. Full article

A kind of novel and compact magnetic field sensor has been proposed and investigated experimentally. The proposed sensor consists of a tapered single mode fiber coupled with a nanostructured magnetic fluid-infiltrated photonic crystal fiber, which is easy to be fabricated. The response of magnetic fluid to magnetic field is used to measure the intensity of magnetic field via whispering gallery mode. The magnetic field-dependent shift in resonance wavelength is observed. The maximum magnetic field intensity sensitivity is 53 pm/mT. The sensor sensitivity is inversely proportional to the thickness of the photonic crystal fiber cladding. Full article
