Whispering-gallery-mode (WGM) microresonators are amongst the most promising optical sensors for detecting bio-chemical targets. A number of laser interrogation methods have been proposed and demonstrated over the last decade, based on scattering and absorption losses or resonance splitting and shift, harnessing the high-quality factor and ultra-small volume of WGMs. Actually, regardless of the sensitivity enhancement, their practical sensing operation may be hampered by the complexity of coupling devices as well as the signalprocessing required to extract the WGM response. Here, we use a silica microsphere immersed in an aqueous environment and efficiently excite optical WGMs with a free-space visible laser, thus collecting the relevant information from the transmitted and back-scattered light without any optical coupler, fiber, or waveguide. We show that a 640-nm diode laser, actively frequency-locked on resonance, provides real-time, fast sensing of dielectric nanoparticles approaching the surface with direct analog readout. Thanks to our illumination scheme, the sensor can be kept in water and operate for days without degradation or loss of sensitivity. Diverse noise contributions are carefully considered and quantified in our system, showing a minimum detectable particle size below 1 nm essentially limited by the residual laser microcavity jitter. Further analysis reveals that the inherent laserfrequency instability in the short, -mid-term operation regime sets an ultimate bound of 0.3 nm. Based on this work, we envisage the possibility to extend our method in view of developing new viable approaches for detection of nanoplastics in natural water without resorting to complex chemical laboratory methods. Full article

A novel application of microresonators for refractometric sensing in aqueous media is presented. To carry out this approach, microspheres of different materials and sizes were fabricated and doped with Nd³⁺ ions. Under 532 nm excitation, the microspheres presented typical NIR Nd³⁺ emission bands with superimposed sharp peaks, related to the Whispering Gallery Modes (WGMs), due to the geometry of the microspheres. When the microspheres were submerged in water with increasing concentrations of glycerol, spectral shifts for the WGMs were observed as a function of the glycerol concentration. These spectral shifts were studied and calibrated for three different microspheres and validated with the theoretical shifts, obtained by solving the Helmholtz equations for the electromagnetic field, considering the geometry of the system, and also by calculating the extinction cross-section. WGM shifts strongly depend on the diameter of the microspheres and their refractive index (RI) difference compared with the external medium, and are greater for decreasing values of the diameter and lower values of RI difference. Experimental sensitivities ranging from 2.18 to 113.36 nm/RIU (refractive index unit) were obtained for different microspheres. Furthermore, reproducibility measurements were carried out, leading to a repeatability of 2.3 pm and a limit of detection of 5 × 10⁻⁴ RIU. The proposed sensors, taking advantage of confocal microscopy for excitation and detection, offer a robust, reliable, and contactless alternative for environmental water analysis. Full article

The optical Vernier effect has been widely studied due to its remarkable effect in improving the sensitivity and resolution of optical sensors. This effect relies on the overlapping envelope of two signals with slightly detuned frequencies. In the application of on-chip optical waveguide resonant cavities with whispering gallery modes, due to the on-chip space limitations, the length of the resonant cavity is restricted, resulting in an increased free spectral range. In the case of a small Vernier effect detuning, the required large Vernier envelope period often exceeds the available wavelength range of the detection system. To address this issue, we propose a novel on-chip waveguide structure to optimize the detection range of the cascaded Vernier effect. The proposed spiral resonant cavity extends the cavity length to 7.50 m within a limited area. The free spectral width (27.46 MHz) is comparable in size to the resonant linewidth (9.41 MHz), shrinking the envelope free spectral width to 371.29 MHz, which greatly facilitates the reading of the Vernier effect. Finally, by connecting two resonant cavities with similar cavity lengths in series and utilizing the Vernier effect, temperature sensing was verified. The results show that compared with a single resonant cavity, the sensitivity was improved by a factor of 14.19. This achievement provides a new direction for the development of wide-range and high-sensitivity Vernier sensing technologies. Full article

Industry 4.0 is transforming predictive failure management by utilizing deep learning to enhance maintenance strategies and automate production processes. Traditional methods often fail to predict failures in time. This research addresses this issue by developing a time-to-fault prediction framework that utilizes an enhanced long short-term memory (LSTM) model to predict machine faults. The proposed method integrates real-time sensor data, including current, voltage, and temperature calibrated via ultra-sensitive optical sensing technologies based on the typical whispering gallery optical mode (WGM) to create a robust dataset. Due to the high-quality factor that these sensors exhibit, any minute change on the surrounding medium will makes a significant change on its transmission spectrum. The LSTM model trained on these data demonstrated rapid and stable convergence, outperforming other deep learning techniques with a mean absolute error (MAE) of 0.83, a root mean squared error (RMSE) of 1.62, and a coefficient of determination (R²) of 0.99. The results show the superior performance of LSTM in predicting machine failures early in real-world environments within 10 min lead time, improving productivity and reducing downtime. This framework advances smart industries by improving fault prediction in manufacturing precision robotics components, demonstrated through two humanoid robots, GUCnoid 1.0 and ARAtronica. Full article

Axially uniform optical fibers provide a low-cost, scalable platform for the emission of whispering gallery mode (WGM) lasers. This paper proposes a method for generating and controlling WGM lasers based on the design of a flexible optical fiber array structure. By adjusting the spacing between the flexible fibers, the coupling relationship between different WGM modes is modulated, achieving a transition from regular to random WGM (R-WGM) mechanisms. Additionally, the application of this laser in information security encryption is demonstrated and explored. Full article

A new instrument for label-free measurements based on optical Low-Q Whispering Gallery Modes (WGMs) for various applications is used for a detailed study of the deposition and release of Layer-by-Layer polymer coatings. The two selected coating pairs interact either via hydrogen bonding or electrostatic interactions. Their assembly was followed by common Quartz Crystal Microbalance (QCM) technology and the Low-Q WGMs. In contrast to planar QCM sensor chips of 1 cm, the WGM sensors are fluorescent spherical beads with diameters of 10.2 µm, enabling the detection of analyte quantities in the femtogram range in tiny volumes. The beads, with a very smooth surface and high refractive index, act as resonators for circular light waves that can revolve up to 10,000 times within the bead. The WGM frequencies are highly sensitive to changes in particle diameter and the refractive index of the surrounding medium. Hence, the adsorption of molecules shifts the resonance frequency, which is detected by a robust instrument with a high-resolution spectrometer. The results demonstrate the high potential of the new photonic measurement and its advantages over QCM technology, such as cheap sensors (billions in one Eppendorf tube), simple pre-functionalization, much higher statistic safety by hundreds of sensors for one measurement, 5–10 times faster analysis, and that approx. 25, 000 fewer analyte molecules are needed for one sensor. In addition, the deposited molecule amount is not superposed by hydrated water as for QCM. A connection between sensors and instruments does not exist, enabling application in any transparent environment, like microfluidics, drop-on slides, Petri dishes, well plates, cell culture vasculature, etc. Full article

A method for achieving the single-mode and efficient unidirectional emission of a whispering gallery mode (WGM) semiconductor laser is presented herein. Hybrid square-rectangular lasers (HSRLs) and hybrid square/rhombus-rectangular lasers (HSRRLs) consisting of a Fabry–Pérot (FP) cavity and a square or rhombus cavity microcavity are described. In addition, a transmitter optical subassembly (TOSA) based on an HSRRL chip was fabricated, which has a wide and continuous wavelength tuning range. Wavelength channels from 1555.75 nm to 1568.15 nm with a spacing of 50 GHz were demonstrated with a good side mode suppression ratio (SMSR) and good output power. These devices have the potential to meet the typical requirements of optical communication networks. Full article

Optical microresonators supporting whispering-gallery modes (WGMs) have become a versatile platform for achieving electromagnetically induced transparency-like (EIT-like) phenomena. We theoretically and experimentally demonstrated the tunable coupled-mode induced transparency based on the surface nanoscale axial photonics (SNAP) microresonator. Single-EIT-like and double-EIT-like (DEIT-like) effects with one or more transparent windows are achieved due to dense mode families and tunable resonant frequencies. The experimental results can be well-fitted by the coupled mode theory. An automatically adjustable EIT-like effect is discovered by immersing the sensing region of the SNAP microresonator into an aqueous environment. The sharp lineshape and high slope of the transparent window allow us to achieve a liquid refractive index sensitivity of 2058.8 pm/RIU. Furthermore, we investigated a displacement sensing phenomenon by monitoring changes in the slope of the transparent window. We believe that the above results pave the way for multi-channel all-optical switching devices, multi-channel optical communications, and biochemical sensing processing. Full article

The layer-by-layer (LbL) assembling of oppositely charged polyelectrolytes was studied using semi-synthetic polysaccharide derivatives, namely the polycations 6-aminoethylamino-6-deoxy cellulose (ADC) and cellulose (2-(ethylamino)ethylcarbamate (CAEC), as well as the polyanion cellulose sulfate (CS). The synthetic polymers poly(allylamine) (PAH) and poly(styrene sulfonate) (PSS) were employed as well for comparison. The stepwise adsorption process was monitored by whispering gallery mode (WGM) experiments and zeta-potential measurements. Distinct differences between synthetic- and polysaccharide-based assemblies were observed in terms of the quantitative adsorption of mass and adsorption kinetics. The LbL-approach was used to prepare µm-sized capsules with the aid of porous and non-porous silica particle templates. The polysaccharide-based capsule showed a switchable permeability that was not observed for the synthetic polymer materials. At ambient pH values of 7, low-molecular dyes could penetrate the capsule wall while no permeation occurred at elevated pH values of 8. Finally, the preparation of protein-loaded LbL-capsules was studied using the combination of CAEC and CS. It was shown that high amounts of protein (streptavidin and ovomucoid) can be encapsulated and that no leaking or disintegration of the cargo macromolecules occurred during the preparation step. Based on this work, potential use in biomedical areas can be concluded, such as the encapsulation of bioactive compounds (e.g., pharmaceutical compounds, antibodies) for drug delivery or sensing purposes. Full article

Whispering gallery mode (WGM) resonators have high-quality factors and can be used in high-sensitivity sensors due to the narrow line width that allows for the detection of small external changes. In this paper, a force-sensing system based on a high-Q asymmetric V-shaped CaF₂ resonator is proposed. Based on the dispersion coupling mechanism, the deformation of the resonator is achieved by loading force, and the resonant frequency is changed to determine the measurement. By adjusting the structural parameters of the asymmetric V-shaped resonator, the deformation of the resonator under force loading is improved. The experimental results show that the sensitivity of the V-shaped tip is 18.84 V/N, which determines the force-sensing resolution of 8.49 μN. This work provides a solution for force-sensing measurements based on a WGM resonator. Full article

Whispering gallery mode (WGM) resonators doped with fluorescent materials find impressive applications in biological sensing. They do not require special conditions for the excitation of WGM inside that provide the basis for in vivo sensing. Currently, the problem of materials for in vivo WGM sensors are substantial since their fluorescence should have stable optical properties as well as they should be biocompatible. To address this we present WGM microresonators of 5–7 $\mathsf{\mu }$m, where the dopant is made of carbon quantum dots (CDs). CDs are biocompatible since they are produced from carbon and demonstrate bright optical emission, which shows different bands depending on the excitation wavelength. The WGM sensors developed here were tested as label-free biosensors by detecting bovine serum albumin molecules. The results showed WGM frequency shifting, with the limit of detection down to ${10}^{-16}$ M level. Full article

Whispering gallery mode (WGM) resonators with an ultra-high quality (Q) factor provide a new idea for high-precision underwater acoustic sensing. However, acoustic energy loss due to watertight encapsulation has become an urgent problem for its underwater application. In order to solve this problem, this paper proposes a hollowed-out array structure. The finite element simulation shows that the acoustic wave transmission loss is improved by 30 dB compared with that of the flat plate encapsulation structure. Using a calcium fluoride (CaF₂) resonator with a Q factor of 1.2 × 10⁸ as an acoustic sensitive unit, the amplitude and frequency of the loaded acoustic wave are retrieved by means of the dispersion coupling response mechanism. The resonator’s underwater experimental test range is 100 Hz–1 kHz, its acoustic sensing sensitivity level reaches −176.3 dB re 1 V/µPa @ 300 Hz, and its minimum detectable pressure can be up to 0.87 mPa/Hz^1/2, which corresponds to a noise-equivalent pressure (NEP) of up to 58 dB re 1 µPa/Hz^1/2. Full article

Optical microcavities are known for their strongly enhanced light–matter interactions. Whispering gallery mode (WGM) microresonators have important applications in nonlinear optics, single-mode output, and biosensing. However, there are few studies on resonance modes in the ultraviolet spectrum because most materials with high absorption properties are in the ultraviolet band. In this study, the performance of a microdisk cavity based on boron nitride (BN) was simulated by using the Finite-difference time-domain (FDTD) method. The WGM characteristics of a single BN microdisk with different sizes were obtained, wherein the resonance modes could be regulated from 270 nm to 350 nm; additionally, a single-mode at 301.5 nm is achieved by cascading multiple BN microdisk cavities. Moreover, we found that a BN microdisk with a diameter of 2 μm has a position-independent precise sensitivity for the nanoparticle of 140 nm. This study provides new ideas for optical microcavities to achieve single-mode management and novel coronavirus size screening, such as SARS-CoV-2, in the ultraviolet region. Full article

Light confinement provided by whispering gallery mode (WGM) microresonators is especially useful for integrated photonic circuits. In particular, the tunability of such devices has gained increased attention for active filtering and lasering applications. Traditional lithographic approaches for fabricating such devices, especially Si-based ones, often restrict the device’s tuning due to the material’s inherent properties. Two-photon polymerization (2PP) has emerged as an alternative fabrication technique of sub-diffraction resolution 3D structures, in which compounds can be incorporated to further expand their applications, such as enabling active devices. Here, we exploited the advantageous characteristics of polymer-based devices and produced, via 2PP, acrylic-based WGM hollow microcylinders incorporated with the azoaromatic chromophore Disperse Red 13 (DR13). Within telecommunication range, we demonstrated the tuning of the microresonator’s modes by external irradiation within the dye’s absorption peak (at 514 nm), actively inducing a blueshift at a rate of 1.2 nm/(Wcm⁻²). Its thermo-optical properties were also investigated through direct heating, and the compatibility of both natural phenomena was also confirmed by finite element simulations. Such results further expand the applicability of polymeric microresonators in optical and photonic devices since optically active filtering was exhibited. Full article

This work studies the features of the formation of isometric polyhedral ZnO microcrystals that provide stimulated emission and whispering-gallery-mode (WGM) lasing in the near-UV range. For this purpose, the growth stages of such crystals in the process of gas-transport synthesis and the luminescent properties of the structures obtained at each stage were investigated. It was shown that the growth of laser microcrystals begins with the formation of microspheroids with thin ZnO shells. Such spheroids exhibit mainly white luminescence with a small contribution of near-UV emission. Increasing the synthesis duration results in thickening and faceting of the spheroid shells, as well as a decrease in the contribution of the yellow–red component to the luminescence spectrum. At the same time, ZnO microcrystallites nucleate and grow inside the spheroids, using as a material the remains of a liquid zinc drop and oxygen entering the spheroids through their shells. Such growth conditions allow them to take on an equilibrium polyhedral shape. Eventually, upon destruction of the spheroid shell, a polyhedral ZnO microcrystal supporting WGMs is observed. Full article
