Space-based gravitational wave detection missions impose extremely stringent requirements on the measurement precision of the laser interferometer, where tilt-to-length coupling noise emerges as a critical factor degrading performance. This paper focuses on geometric tilt-to-length noise in the test mass interferometer, conducting both theoretical modeling and experimental validation. First, based on the principles of geometrical optics, an analytical expression is derived for the optical path length difference variation induced by test mass angular jitter, clarifying the coupling mechanisms of the various system parameters to the tilt-to-length coupling. Numerical simulations demonstrate an excellent agreement between the theoretical model and simulation results. To further validate the theoretical model, an experimental system combining laser heterodyne interferometry and differential wavefront sensing technique is designed and constructed, with a fast steering mirror employed to simulate test mass angular jitter, enabling precise measurement of both the optical path and angular variations. By varying the lateral displacement $d_{\mathrm{lat}}$ of the fast steering mirror, the experimental data exhibit strong consistency with the theoretical prediction of the first-order tilt-to-length coupling coefficient, with a linear fitting error as low as 1.5%. Moreover, the independence of the second-order and zero-order terms relative to $d_{\mathrm{lat}}$ also aligns with the theoretical expectation. Thus, the first experimental verification of the geometric tilt-to-length coupling model is presented in this paper. Full article

Based on vector wave aberration theory, this paper analyzes the relative positions of the third-order coma node and astigmatism nodes under pupil decenter and proposes an initial structure selection criterion in which the coma node coincides with the geometric midpoint of the two astigmatism nodes. Using this criterion, an F/6 off-axis catadioptric telephoto optical system with a focal length of 900 mm and an entrance pupil diameter of 150 mm was designed. The measured on-axis RMS wavefront error was better than 0.025λ at 632.8 nm. The results demonstrate that the system meets the requirements for high-resolution long-focal-length imaging. Full article

Point diffraction interferometers (PDIs) utilize a near-ideal spherical wavefront generated by point diffraction as the reference, providing a high-quality measurement benchmark independent of reference surface quality. In this work, a compact dual-oblique-fiber heterodyne phase-shifting point diffraction interferometer (DOF-HPSPDI) is proposed. A dual-oblique-fiber point diffraction wavefront generator (DOF-PDWG) is designed to generate the reference and measurement beams separately. The proposed configuration enables efficient utilization of the divergence of the fiber-generated diffracted wavefront, while the reflective structure at the fiber end faces allows the two beams to propagate along a common path. In addition, the close spacing between the two oblique fibers minimizes system errors. Heterodyne phase-shifting interferometry (HPSI) is employed to retrieve the wavefront phase from the interferograms. Theoretical system errors are analyzed through simulations, and experiments verify the feasibility and stability of the proposed system. This work provides a low-cost, compact, and highly stable point diffraction interferometer, offering a promising device for high-precision optical testing and sub-aperture stitching of large-aperture optical components. Full article

Volume phase holographic gratings (VPHGs) are high-performance dispersive elements characterized by high diffraction efficiency and low noise. When used as dispersive components in imaging spectrometers for CO₂ detection, they can significantly enhance instrument performance, detection capability, and measurement accuracy. However, for short-wave infrared (SWIR) applications requiring high dispersion and operational efficiency, traditional design approaches struggle to effectively balance the trade-offs among multidimensional diffraction performance metrics, resulting in low optimization efficiency. Furthermore, as spectrometers require dispersive elements, established fabrication methods lack robust methodologies for producing large-area VPHGs. To address these gaps, we developed both a design approach and a fabrication process for VPH gratings tailored to CO₂ detection. On the design front, we propose a novel method that integrates a multi-objective simulated annealing optimization algorithm with Kogelnik’s coupled-wave theory. The optimized gratings achieve diffraction efficiencies of 95.35% (TE polarization) and 82.21% (TM polarization) across the target spectral range, with polarization sensitivity maintained below 6.57%. For fabrication, we developed holographic plate fabrication via a blade-coating technique coupled with an optimized aging protocol. A medium-to-large aperture holographic recording and exposure system with a wavefront error better than λ/25 RMS was developed. Post-processing conditions were systematically optimized based on experimental diffraction efficiency measurements, enabling the successful fabrication of VPHGs. It is explicitly noted that the experimental validation of the fabricated VPHGs is limited to the 1.620–1.630 μm wavelength range, while the full target design range of 1.620–1.650 μm has not been experimentally verified in this work. This work provides a valuable reference for the selection of dispersive elements for next-generation CO₂ detection satellites. The designed gratings fully meet application requirements, while the established fabrication process lays a solid foundation for the production of high-performance VPHGs. Full article

Accurate estimation of curvature radius from interference fringes is critical in optical metrology and precision manufacturing. Conventional interferogram analytical approaches often require manual intervention and are sensitive to fringe variations related to noise and environmental vibrations. To address these limitations, we combine an improved Twyman–Green interferometer with different artificial intelligence (AI) deep learning models and utilize a self-developed MATLAB analysis program to propose a non-destructive and rapid measurement system for optical coating substrates. The proposed AI-assisted Twyman–Green interferometric system differs fundamentally from conventional wavefront sensing techniques in both principle and implementation. This paper utilizes the Twyman–Green interferometer to generate interference fringe datasets on B270 glass and sapphire substrates, and employs convolutional neural network (CNN), ResNet-18, and VGG-16 models for training and evaluation. The proposed method integrates image enhancement, fringe pattern clustering, and analysis and validation based on fast Fourier transform (FFT). Experimental results show that ResNet-18 outperforms other models, with a mean absolute percentage error of 5.44% on sapphire substrates and 3.40% on B270 glass substrates. These findings highlight the effectiveness and robustness of deep learning models, especially residual networks, in automatic ROC prediction for optical measurement applications. Full article

We propose a field-transformation-based framework for generating phase-only light-field holograms from a single RGB image. The method establishes an explicit pipeline from monocular scene inference to holographic wavefront synthesis, without requiring multi-view capture or task-specific hologram-network training. First, we construct a layered occlusion RGB-D model from the input image using monocular depth estimation, connectivity-based layer decomposition, and occlusion-aware inpainting, which provides a lightweight 3D prior for sparse-view rendering in the small-parallax regime. Second, we transform the rendered sparse RGB-D light field into a target complex wavefront on the recording plane through local frequency mapping, thereby bridging explicit scene geometry and wave-optical field construction. Third, we optimize the phase-only hologram under multi-plane amplitude constraints using a geometrically consistent initial phase and an error-driven adaptive depth-sampling strategy, which improves convergence stability and reconstruction quality under a limited computational budget. Numerical experiments show that the proposed method achieves better depth continuity, occlusion fidelity, and lower speckle noise than representative layer-based and point-based methods, and improves the average PSNR and SSIM by approximately 3 dB and 0.15, respectively, over Hogel-Free Holography. Optical experiments further confirm the physical feasibility and robustness of the proposed framework. Full article

Laser beam combining is essential for achieving high-power and high-radiance output. However, atmospheric turbulence induces independent tip–tilt aberrations across discrete sub-beams in laser array systems, which severely degrades the concentration of far-field energy. Traditional wavefront sensing techniques are primarily designed for the continuous wavefront of a single laser and are not directly applicable to laser array, whereas indirect optimization-based methods often suffer from slow convergence and limited real-time performance. To address these limitations, this study introduces a tip–tilt aberration compensation system for laser array propagation based on cooperative beacons with a shared-aperture transmit–receive configuration. The primary innovation consists of a modified Shack–Hartmann wavefront sensor (SHWFS) tailored to a discrete multi-beam layout, which facilitates the direct, independent, and simultaneous measurement of tip–tilt aberrations for each sub-beam. In conjunction with a segmented deformable mirror (SDM), the architecture can facilitate real-time closed-loop correction with high bandwidth and high precision. Numerical simulations of a 7-, 19-, and 37-beam laser array, together with validation experiments utilizing a 30-beam configuration, demonstrate that the proposed approach effectively suppresses tip–tilt error induced by turbulence. After closed-loop correction, the Strehl ratio (SR) increases above 0.92 ($r_0=5\mathrm{cm}$), while the beam quality factor β reduces below 1.37 ($r_0=5\mathrm{cm}$). Furthermore, the system retains performance stability as the number of sub-beams increases, demonstrating the scalability of the proposed method. In contrast to conventional approaches designed for a continuous wavefront, the proposed method offers a feasible approach for a discrete laser array system, providing robust and scalable tip–tilt correction under varying atmospheric conditions. Full article

This study proposes a principal component analysis-based convolutional neural network (PC-CNN) to correct atmospheric turbulence-induced aberrations. Unlike traditional Zernike polynomials (ZPs)-based methods (ZP-CNN), PC-CNN avoids mode aliasing and cross-coupling via the strict orthogonality of principal components (PCs). A coefficient magnification strategy is incorporated to further enhance efficacy, maximally preserving the intrinsic physical information within the PCs coefficients. A series of systematic experiments was conducted under conditions from weak to strong turbulence, characterized by $D/r_0$ from 1 to 25, where $D$ is the pupil diameter and $r_0$ is the atmospheric coherence length. Quantitative results show PC-CNN achieves a lower mean relative error (MRE) in coefficient prediction than ZP-CNN under equivalent conditions. It also yields a higher Strehl ratio, reduced speckles, and enhanced spot clarity while requiring fewer basis terms, demonstrating high stability and robustness in strong turbulence. These findings emphasize that basis function orthogonality and physically informed preprocessing are critical design principles for deep-learning-based wavefront sensor-less adaptive optics (AO), establishing a robust foundation for real-time intelligent AO systems in astronomy and free-space optical communications. Full article

Silicon carbide (SiC), owing to its excellent physical and chemical properties, has emerged as a leading third-generation semiconductor material. Conventional diamond wire cutting faces challenges in producing ultra-large, ultra-thin wafers. In contrast, the femtosecond laser has attracted significant attention in recent years due to its low kerf loss and high slicing speed. However, during femtosecond laser stealth slicing, spherical aberration induced by the refractive index mismatch between air and the SiC crystal severely degrades the slicing quality. Based on the analysis and calculation of wavefront aberration at a specific focal depth of 175 μm, we designed and implemented a static aberration correction method to reduce the thickness of the modified layer and improve the slicing quality. This method effectively mitigates focus elongation caused by refractive index mismatch, thereby reducing the modified layer thickness and the tensile stress required for wafer separation, while improving the surface quality of the separated wafers. Furthermore, this method eliminates the need for active optical components in aberration correction, simplifying the system and avoiding errors associated with the limited response speed of active optics. The technique demonstrates potential for practical application in industrial wafer slicing. Full article

In size, weight, and power (SWaP)-constrained optical systems, such as spaceborne LiDAR, high-precision centroid localization often relies on focal-plane measurements without dedicated wavefront sensors. Under such conditions, the nonlinear coupling between optical aberrations and sensor noise introduces systematic bias that is difficult to mitigate using conventional centroiding methods. To address this issue, we propose a physics-conditioned feature correction framework based on an aberration-conditioned attention mechanism. A hybrid CNN–Transformer architecture is employed to predict and compensate for systematic centroid bias. Specifically, convolutional layers encode the degraded spot morphology, while a multi-head attention mechanism leverages Seidel aberration coefficients to adaptively modulate spatial features for precise regression. Given the unavailability of absolute ground-truth coordinates in empirical scenarios, a physics-consistent simulation framework based on scalar diffraction theory is constructed to generate synthetic data for supervised learning. Simulation results indicate that the proposed method objectively reduces anisotropic systematic bias, achieving a localization root-mean-square error (RMSE) of 0.011 to 0.021 pixels, and maintains stable sub-pixel accuracy even under a 10% empirical prior perturbation. To evaluate generalization performance and engineering reliability, a wedge-based double-spot platform is developed to verify physical consistency via geometric invariance. Experimental results demonstrate a measured spacing standard deviation (SD) of 0.015 to 0.039 pixels. This validates the framework’s transferability from theoretical simulation to controlled physical measurements, providing an algorithmic foundation for precision optical metrology in hardware-constrained environments. Full article

Cylindrical surfaces with complex parameters (CSCPs) have off-axis and aspheric properties. High-precision measurement of cylindrical surfaces is a key research focus in optical metrology. Two-dimensional pseudo lateral shearing interferometry (2DPLSI) enables non-null generalized interferometry for cylindrical surfaces. However, due to the non-rotational symmetry of cylindrical surfaces with complex parameters, measuring them using two-dimensional pseudo lateral shearing interferometry inevitably introduces misalignment aberrations, degrading the accuracy of cylindrical surface reconstruction. To address this issue, we propose a novel non-null testing method: the cylindrical surface is translated in the orthogonal directions to carry out the shearing process, and wavefront errors are eliminated through second-order differencing. Furthermore, a reconstruction algorithm in one direction is proposed. Using only the partial derivative in the x direction, the wavefront error of misalignment aberrations can be reconstructed, enabling high-precision recovery of the cylindrical surface. Experimental results using a Fizeau interferometer demonstrate that the proposed method effectively reconstructs misalignment aberrations. The reconstructed cylindrical surface achieves a peak-to-valley (PV) value of 0.45λ (λ = 632.8 nm) and a root-mean-square (RMS) value of 0.12λ, comparable to the 0.37λ PV and 0.09λ RMS obtained via null testing. The repeatability of the proposed method is superior to λ/1000 RMS. Full article

The spatial response of rectangular pulse heterodyne phase-sensitive optical time-domain reflectometry ($\varphi$-OTDR) to an acoustic event is characterized by a windowing function rather than a point-like sensitivity. This effect degrades the system’s spatial resolution and introduces systematic errors in array signal processing. This work presents modeling analysis and a mitigation strategy for this fundamental limitation. The spatial windowing effect is modeled as a point spread function (PSF) derived from physical mechanisms and system parameters, including the pulse width, gauge length, and intra-pulse intensity dynamics. The PSF model is validated against measurements under near-ideal conditions using a fiber-coupled tuning fork. A Wiener filter-based deconvolution method is utilized to invert the windowed spatial response towards a point-like response. The effectiveness of this inversion is demonstrated through enhanced spatial resolution and accurate reconstruction of two-dimensional wavefront geometry. Furthermore, the impact of this effect on array signal processing is quantitatively evaluated. The results demonstrate that the proposed method effectively suppresses systematic errors in wavefield analysis, and specifically enhances the accuracy and confidence of steered response power—phase transform (SRP-PHAT) spatial spectrum estimation. This study provides a systematic framework for understanding, quantifying, and inverting the spatial response in $\varphi$-OTDR, enabling accurate and interpretable acoustic field sensing. Full article

To better meet the wavefront measurement requirements for large-aperture segmented mirrors after in-orbit deployment, this paper designs a measurement system based on an optical camera and targets. This system utilizes photogrammetry principles to measure target positions, fit the wavefront of the segmented mirror, and form a closed-loop control with the calibration mechanism. Based on the wavefront measurement range and accuracy requirements during the coarse calibration phase of the segmented mirror, the optical system was first designed. The measurement camera features a 16° × 12° rectangular field of view with a 100 mm focal length, achieving near-diffraction-limited imaging quality. The structural fundamental frequency of the measurement camera exceeds 400 Hz. Under a 4 °C temperature rise environment, the surface error of the optical lens remains better than 1/80$\lambda$. Based on error theory, a quantitative analysis of error sources and their impact on target position measurement accuracy was conducted, yielding theoretical measurement errors of ±0.0853 mm in the Z-direction and ±0.1525 mm in the X-direction. Through focal length calibration and imaging tests of the prototype, the measurement camera achieved a modulation transfer function greater than 0.11 with excellent imaging quality. With a focal length of 101.356 mm and a measurement range exceeding ±4 mm, it meets design requirements. Finite element simulation and Monte Carlo methods analyzed wavefront fitting accuracy under different operating conditions, yielding peak-to-valley values of 0.397 mm and root mean square values of 0.073 mm. The wavefront measurement system designed in this paper meets the structural rigidity and temperature adaptability requirements for in-orbit measurement systems. The prototype’s field of view satisfies the wavefront measurement range requirements, the camera’s focal length meets design specifications with good imaging quality, and the wavefront measurement deviation meets the accuracy requirements for the coarse calibration phase. Compared to current wavefront measurement systems, the proposed system significantly expands the measurement range, offering a novel wavefront measurement method for coarse calibration of tiled mirrors. Full article

Off-axis reflective telescopes are prone to component misalignment due to external environmental factors and mechanical vibrations. This misalignment introduces low-order aberrations, which severely degrade imaging quality. Thus, active misalignment correction is crucial for maintaining the imaging performance of off-axis reflective telescopes. Current computer-aided alignment technologies for optical systems mostly rely on wavefront sensors to acquire aberrations at multiple fixed fields of view (FOVs) or even the full FOV. This significantly increases system complexity and hinders practical engineering applications. To address this issue, this study first conducts sensitivity analysis of misaligned degrees of freedom (DOFs) using a mode truncation algorithm based on singular value decomposition (SVD). A compensation strategy is proposed to avoid the aberration coupling effect. Furthermore, two novel misalignment aberration compensation methods for off-axis reflective telescopes are presented. These methods require only a single focal spot image and eliminate the need for aberration detection and iterative calculations. One method directly solves component misalignment errors using a convolutional neural network (CNN) based on the system’s point spread function (PSF). To further improve compensation performance, an improved method fusing spot images and Zernike coefficients is proposed. In practical misalignment correction, both methods input a single acquired focal spot image into a well-trained model to obtain the misalignment compensation amount. Simulation experiments demonstrate that the improved method, which uses Zernike polynomial coefficients as an intermediate feature bridge, effectively establishes the mapping relationship between spot images and misalignment amounts. It achieves higher solution accuracy and better aberration compensation effect compared to the direct CNN method. This verifies the necessity of extracting Zernike polynomial coefficient features from spot images. Comparative experiments with the traditional sensitivity matrix method show that the two proposed methods outperform the sensitivity matrix method in aberration compensation accuracy over a large misalignment range. Comprehensive simulation results confirm the feasibility and effectiveness of the proposed methods. They overcome the limitations of existing methods, such as complex structure, high cost, and low efficiency, to a certain extent. Full article

Differential wavefront sensing (DWS) is widely adopted for high-precision angular detection in interferometric systems, yet its measurement range is constrained by the nonlinear implicit phase–angle relationship. This paper proposes a strategy-enhanced differential evolution algorithm, termed Bi-inheritance and Tournament-Selection-based Differential Evolution (BiTsDE), to suppress nonlinear angular errors. The method introduces fitness-guided inheritance of mutation and crossover factors and tournament-based elite parent selection, enabling adaptive balance between global exploration and local exploitation. Unlike conventional DE variants that mainly tune control parameters, BiTsDE optimizes the evolutionary search strategy, enhancing early-stage diversity and late-stage convergence stability. Simulations demonstrate angular resolution better than 0.06 nrad within ±1 mrad. Experiments show that up to 600 μrad, BiTsDE reduces demodulation error by 99.9% compared with linear DWS, achieving 17.9 nrad precision and 42% faster convergence. These results validate BiTsDE as an effective solution for nonlinear error suppression in DWS-based high-precision optical metrology, particularly for space-based gravitational wave detection. Full article
