Based on the widely used Gullstrand–Le Grand eye model, a scattering individual eye model was constructed with Zemax, which has individual ocular wavefront aberration and the scattering particles distributed in the eye. There are three main steps to build the model. Firstly, the Gullstand-Le Grand eye model was constructed, and converted into a non-sequential model. The axial lengths of all ocular components, and the corneal curvatures were input into the optical model. Secondly, a high-order aspheric surface-Zernike Fringe Sag surface was chosen to fit the wavefront aberrations measured with the ocular wavefront aberrometer. Thirdly, an embedded scattering lens within the crystalline lens was developed, of which parameters of scattering particles can be selected flexibly. The scattering individual eye model can be used to quantitatively investigate interaction between ocular aberrations and scattering light on retina image quality. The results demonstrated that when scattering particles were uniformly distributed across the optical pupil, MTFs at all spatial frequencies decreased proportionally with increasing particle density, independent of aberrations. When scattering particles were located in regions with smaller wavefront aberrations, the combined effect of scattering and aberrations synergistically degraded retinal image quality. In contrast, when particles were concentrated in zones of larger aberrations, the scattered light could partially compensate for the aberrational effects, leading to improved optical performance Full article

Atmospheric turbulence introduces distortions to the wavefront of propagating optical radiation. It causes image resolution degradation in astronomical telescopes and significantly reduces the power density of radiation on the target in focusing applications. The impact of turbulence fluctuations on the wavefront can be investigated under laboratory conditions using either a fan heater (roughly tuned), a phase plate, or a deformable mirror (finely tuned) as a turbulence-generation device and a wavefront sensor as a wavefront-distortion measurement device. We designed and developed a software simulator and an experimental setup for the reconstruction of atmospheric turbulence-phase fluctuations as well as an adaptive optical system for the compensation of induced aberrations. Both systems use two 60 mm, 92-channel, bimorph deformable mirrors and two tip-tilt correctors. The wavefront is measured using a high-speed Shack–Hartmann wavefront sensor based on an industrial CMOS camera. The system was able to achieve a 500 Hz correction frame rate, and the amplitude of aberrations decreased from 2.6 μm to 0.3 μm during the correction procedure. The use of the tip-tilt corrector allowed a decrease in the focal spot centroid jitter range of 2–3 times from ±26.5 μm and ±24 μm up to ±11.5 μm and ±5.5 μm. Full article

Optical aberrations represent a critical issue for gravitational wave interferometers, as they impact the stability and controllability of the experiment. In the next generation of detectors, the circulating power in the cavity arms is expected to increase by up to a factor of 20 compared to current ones. This significant increase makes the mitigation of power-dependent optical aberrations extremely challenging. In this paper, we describe the problem of absorption in the optics and its role in generating some of the most important wavefront distortions, along with the present compensation strategy. To meet the new stringent requirements, new technologies must be designed, and existing ones upgraded. We present a review of the strategies and concepts in the field of aberration control in gravitational wave detectors and discuss the challenges for future detectors like the high-power operation of the Einstein Telescope. Full article

Free Space Optical (FSO) communication is extensively utilized in the telecommunication industry for both ground and space wireless links, as well as last-mile applications, as a result of its lesser Bit Error Rate (BER), free spectrum, and easy relocation. However, atmospheric turbulence, also known as Wavefront Aberration (WA), is considered a serious issue because it causes higher BER and affects coupling efficiency. In order to address this issue, a Sensor-Less Adaptive Optics (SLAO) system is developed for FSO to enhance performance. In this research, the compensation of WA in SLAO is obtained by proposing the Brownian motion and Directional mutation scheme-based Coati Optimization Algorithm, BDCOA. Here, the BDCOA is developed to search for an optimum control signal value of actuators in Deformable Mirror (DM). The incorporated Brownian motion and directional mutation are used to avoid the local optimum issue and enhance search space efficiency while searching for the control signal. Therefore, the dynamic control signal optimization for DM using BDCOA helps to enhance the coupling efficiency. Thus, the WAs are compensated for and optical signal concentration is enhanced in FSO. The metrics used for analyzing the BDCOA are Root Mean Square (RMS), BER, coupling efficiency, and Strehl Ratio (SR). The existing methods, such as Simulated Annealing (SA) and Stochastic Parallel Gradient Descent (SPGD), Advanced Multi-Feedback SPGD (AMFSPGD), and Oppositional-Breeding Artificial Fish Swarm (OBAFS), are used for evaluating the performance of BDCOA. The RMS of BDCOA for iterations 500 is 0.12, which is less than that of the SA-SPGD and OBAFS. Full article

Optical aspheres are demanded with extremely high precision to meet functional requirements in space telescopes, extreme ultraviolet lithography, and other modern large optical systems. The nano-precision fabrication of optical aspheres requires high-precision measurements to guide deterministic optical processing. Null test is the preferred method for high-precision measurements. Null optics are required to compensate for the incident wavefront in the null test of optical aspheres. However, wavefront aberrations caused by the transmission flat or transmission sphere of interferometer and null optics can limit measurement accuracy and need to be separated. A nano-precision measurement method is proposed for the even optical aspheres of high order in this paper. A computer-generated hologram is used as a null optic to realize a null test on optical aspheres. Mapping distortion correction is performed on the measurement results to ensure that the transverse coordinates of the measurement results correspond correctly to those of the test surface. Absolute testing is applied to separate the wavefront aberrations caused by the computer-generated hologram and interferometer optics. Finally, the results obtained by this method were used to guide deterministic optical processing, enabling the nano-precision fabrication of optical aspheres. Full article

To satisfy the demands of high image quality and resolutions, telescope alignment is indispensable. In this paper, a wavefront sensorless method based on a modified stochastic parallel gradient descent algorithm (SPGD) called the adaptive moment estimation SPGD (Adam SPGD) algorithm is proposed. Simulations are carried out using a four-mirror telescope, whose aperture is 6 m and fields of view are Φ2°. Three misalignments are shown as examples. Positions of the secondary mirror and third mirror are employed to compensate aberrations. The results show that merit functions and energy distributions of corrected images match with the designed ones. The mean RMS of residual wavefront errors is smaller than λ/14 (λ = 0.5 μm), indicating that the misalignments are well compensated. The results verify the effectiveness of our method. Full article

With off-axis reflection systems with specific distortion values serving as objectives or collimators, it is possible to compensate and correct for spectral line bending in spectroscopic instruments. However, there is limited research on the precise control of distortion, which poses particular challenges in large field-of-view optical systems. This paper presents a method for controlling distortion in off-axis reflection systems. Based on Seidel aberration theory and the relationship between distortion wavefront error and primary ray error, we construct objective functions with structural constraints and aberration constraints. The initial structure with specific distortion values is then solved using a differential evolution algorithm. The effectiveness and reliability of this method are verified through the design of an off-axis three-reflection system. The method provided in this study facilitates the design of remote sensing instruments. Full article

This paper presents the conceptual design of an on-axis 6 metre aperture space telescope designed to cover a field of view of ±0.2 degrees with an optical quality at the diffraction limit within a spectral range between 0.5 μm and 2.5 μm. The plate scale is 3 arcsec/mm, and the overall length is less than 12 m. A Korsch layout has been selected based on the superb aberration compensation offered by Three-Mirror Anastigmat systems. The proposed design presents some characteristics: an almost flat response in RMS wavefront error across the field and for the entire spectral range; a flat mirror has been included to reduce the overall volume, and this has been adjusted to be placed at an intermediate pupil position, acting as a baffle for stray light and as a Lyott to restrict background radiation. This mirror presents a central hole, defined to the aperture of the pupil, allowing the transmission of the beam towards the image focal plane, where it can be split for multiple payloads. It also allows the transmission of the central field, at 90 degrees with respect to the science beam, to be used for Active Optics monitoring and correction of the primary mirror in order to ensure optimum optical performance. This on-axis solution significantly reduces the technical complexity for manufacturing, metrology, integration, and tests and has an important impact in the cost of the telescope. Full article

Wavefront distortion caused by atmospheric turbulence can be described as different types of aberrations, such as piston, tilt, defocusing, astigmatism, coma and so on. The operation of dual deformable mirrors can have mutual coupling effects, which affect the correction effect of wavefront distortion. This study combines a fast-steering mirror (FSM) and a deformable mirror (DM) to form a dual-deformable-mirrors wavefront correction system, and proposes a decoupling algorithm that can correct any specified aberration. In this decoupling algorithm, both the FSM and the DM are controlled using the mode method, and the specific corrected aberrations are obtained based on a limited matrix. The compensation ability of the DM is directly characterized by the mode coefficients of the aberrations, which can achieve independent correction of any order of aberrations and effectively reduce the coupling effect of the dual-deformable-mirrors wavefront correction system. An adaptive optical dual-deformable-mirrors wavefront correction system experiment was built to verify the decoupling algorithm. When the DM corrects the 3rd-, 10th-, and 25th-order aberrations, and the FSM only corrects the 1st- and 2nd-order aberrations, the coupling coefficients are approximately $1.17\times 10^{-3}$, $1.814\times 10^{-2}$ and $7.81\times 10^{-3}$, respectively, and their magnitude reaches 10⁻² and below 10⁻², respectively. The experimental results show that the decoupling algorithm can effectively suppress the coupling effect between the FSM and the DM. Full article

A shape adjustment method for subreflectors based on minimizing the residual wavefront error of the large dual-reflector antenna is presented. This method is used to compensate for the antenna structural deformation caused by environment loading. The shape of the subreflector is adjusted using actuators fixed under the panels. The shape adjustment response function for the subreflector shape and the actuators’ adjustment amount is established, which is based on the inverse distance weighting function, and then the control function of the subreflector shape is obtained. The actuators’ adjustment amount can be calculated using the least squares matrix transformation with the minimum residual wavefront error. Analysis of the experiment’s results shows the residual wavefront error and primary aberration are greatly reduced under different elevation angles, and the effectiveness of the proposed method is verified. Full article

The projection objective lens holds a pivotal role in lithography, directly influencing imaging system quality and, consequently, the lithography machine’s feature dimensions. Optical inspection methods for this lens require advancements in calibrating systematic error and enhancing alignment precision of auxiliary devices, given their impact on calibration accuracy. In the random averaging method, random ball can give rise to additional wavefront aberrations due to misalignment and numerical aperture mismatch. To mitigate these aberrations and enhance the accuracy of systematic error calibration, this paper introduces a random ball residual compensation (RBRC) model. Additionally, when combined with the random averaging technique, it elevates the calibration accuracy of the measured lens’s wavefront aberrations. The experimental results underscore the method’s effectiveness, accurately determining optical component eccentricities and numerical aperture errors. After eliminating these errors, more accurate values of lens wavefront aberrations are achieved. This research significantly contributes to enhancing error calibration of lithography objective lens systems. Full article

Ellipticity performance of space telescopes is important for exploration of dark matter. However, traditional on-orbit active optical alignment of space telescopes often takes “minimum wavefront error across the field of view” as the correction goal, and the ellipticity performance after correcting the wave aberration is not optimal. This paper proposes an active optical alignment strategy to achieve optimal ellipticity performance. Based on the framework of nodal aberration theory (NAT), the aberration field distribution corresponding to the optimal full field-of-view ellipticity is determined using global optimization. The degrees of freedom (DOFs) of the secondary mirror and the folded flat mirror are taken as the compensation DOFs to achieve the optimal ellipticity performance. Some valuable insights into aberration field characteristics corresponding to optimal ellipticity performance are presented. This work lays a basis for the correction of ellipticity for complicated optical systems. Full article

Various diffractive, refractive and holographic optical elements, such as diffraction gratings; microlens raster; phase plates; multi-order diffractive optical elements; adaptive mirrors; diffractive and refractive axicons; holographic multiplexes and many others are used to analyze wavefront aberrations. We shortly discuss the features (advantages and disadvantages) of various wavefront aberration sensors in the Introduction. The main part of the paper is devoted to the analysis of the weight coefficients of Zernike polynomials obtained during medical examinations of the cornea in the human eye. Using data obtained by aberrometers, the average values of the Zernike polynomial coefficients for the anterior and posterior surfaces of the healthy eye cornea and a myopic one were calculated. The original wavefront for the anterior and posterior surfaces of the cornea was restored separately, as well as the total wave aberration. For an objective assessment of the quality of vision, the corresponding point spread functions (PSFs) were calculated. We propose to compensate for the aberrations of the myopic eye, taking into account the physical features of the corneal surface. The results of numerical simulation showed that in order to improve the quality of the patient’s vision, it is necessary to take into account high-order aberrations of the anterior surface of the cornea in the form of a coma of the third order and aberrations of the fourth order. Full article

Adaptive optics (AO) is an effective method to compensate the wavefront distortion caused by atmospheric turbulence and system distortion. The accuracy and speed of aberration restoration are important factors affecting the performance of adaptive optics correction. In recent years, an AO correction method based on a convolutional neural network (CNN) has been proposed for the non-iterative extraction of light intensity image features and recovery of phase information. This method can directly predict the Zernike coefficient of the wavefront from the measured light intensity image and effectively improve the real-time correction ability of the AO system. In this paper, a turbulence aberration restoration based on two frames of a light intensity image using GoogLeNet is established. Three depth scales of GoogLeNet and different amounts of data training are tested to verify the accuracy of Zernike phase difference restoration at different turbulence intensities. The results show that the training of small data sets easily overfits the data, while the training performance of large data sets is more stable and requires a deeper network, which is conducive to improving the accuracy of turbulence aberration restoration. The restoration effect of third-order to seventh-order aberrations is significant under different turbulence intensities. With the increase in the Zernike coefficient, the error increases gradually. However, there are valley points lower than the previous growth for the 10th-, 15th-, 16th-, 21st-, 28th- and 29th-order aberrations. For higher-order aberrations, the greater the turbulence intensity, the greater the restoration error. The research content of this paper can provide a network design reference for turbulence aberration restoration based on deep learning. Full article

Instead of acquiring the previous aberrations of an optical wavefront with a sensor, wavefront sensor-less (WFSless) adaptive optics (AO) systems compensate for wavefront distortion by optimizing the performance metric directly. The stochastic parallel gradient descent (SPGD) algorithm is pervasively adopted to achieve performance metric optimization. In this work, we incorporate CoolMomentum, a method for stochastic optimization by Langevin dynamics with simulated annealing, into SPGD. Numerical simulations reveal that, compared with the state-of-the-art SPGD variant, the proposed CoolMomentum-SPGD algorithm achieves better convergence speed under various atmospheric turbulence conditions while requiring only two tunable parameters. Full article
