Search Results (28)

Clay mineral authigenesis and transformation are key diagenetic processes that influence the evolution of sandstone reservoir quality. Although smectite formation and its transformation to illite have been widely studied in clay-rich and feldspathic systems, their development in highly quartz-rich sands remains less well constrained. This study investigates the experimental formation of authigenic smectite and its subsequent illitization in a quartz-dominated sand under controlled hydrothermal experiments. Quartz-rich glass sand from the Middle Jurassic Mariedal Formation (Skåne, Sweden) was reacted with natural Red Sea water in sealed reactors at 80, 150, 200, and 250 °C for 14 days to simulate progressive burial diagenesis. Mineralogical, textural, and geochemical changes were evaluated using thin-section petrography, SEM-EDS, WD-XRF, XRD, and ICP-OES. The starting material is composed predominantly of quartz (91.3%), with minor K-feldspar (6.2%) and muscovite (1.4%), providing limited but sufficient reactive components for clay mineral formation. Dissolution of K-feldspar and muscovite began at 80 °C and continued throughout the experiments. Authigenic smectite was first detected at 150 °C as discontinuous grain-coating phases, indicating nucleation through dissolution–precipitation reactions linked to feldspar alteration and uptake of Mg from the reacting fluid. At 200 °C, the smectite coating became thicker and more extensive, with the onset of transformation to illite through mixed layer stages. By 250 °C, illite becomes the dominant clay mineral, recording progressive smectite illitization with increasing temperature. Fluid chemistry shows systematic variations with temperature, including decreasing Mg and evolving K concentrations, reflecting progressive mass transfer between solid and fluid phases. These results demonstrate that even highly quartz-rich sands can generate authigenic clay minerals when minor reactive phases and suitable fluid chemistry are present. The experiments provide a process-based analogue for clay mineral evolution in quartz-rich sandstone reservoirs and highlight the importance of coupled mineral–fluid reactions during burial diagenesis. Full article

Glauconite-rich sands can generate authigenic clays during burial, as glauconite breaks down and supplies material for smectite that may subsequently transform into illite. The smectite-to-illite transformation is a key burial diagenetic reaction that strongly influences sandstone reservoir quality; however, the reaction pathways and resulting textures in glauconite-rich sands remain insufficiently documented. To better constrain illitization in glauconitic systems, we conducted four hydrothermal batch experiments using glauconitic greensand from the Arnager Greensand Formation (Bornholm Island, Denmark), reacted with Red Sea water at 80 °C, 150 °C, 200 °C, and 250 °C for 21 days. Reaction products were characterized using bulk and clay-fraction XRD, XRF, and SEM–EDS, together with pre- and post-reaction fluid chemistry. At 80 °C, early dissolution of glauconite and other detrital components (K-feldspar, muscovite and calcite) was observed, resulting in increased concentrations of dissolved ions in the fluid but no authigenic clay formation. Authigenic smectite first developed at 150 °C, occurring primarily as grain-coating clay. With further heating to 200 °C, smectite began to transform into mixed-layer illite–smectite, accompanied by the first clear development of illite textures. At 250 °C, illitization advanced significantly, and the reacted products were dominated by wavy to fibrous illite. The resulting clay minerals and their grain-coating morphologies are comparable to coatings reported from buried sandstone reservoirs. These findings suggest that glauconite alteration can generate grain-coating clays that may help limit quartz cement growth and preserve porosity. However, the development of wavy/fibrous illite may also obstruct pore spaces and reduce permeability. Overall, glauconite-derived clay evolution may preserve porosity while still degrading permeability, and the net reservoir effect depends on the morphology and distribution (thickness and coverage) of the newly developed clay minerals. Full article

Given the challenges posed by high groundwater levels, thick sand layers, and strong permeability in water-rich sandy strata, cut-off walls often fail to fully isolate the hydraulic connection between the inside and outside of a foundation pit. As a result, dewatering inside the pit—especially from confined aquifers—can cause significant external groundwater drawdown and subsequent ground settlement. Using a deep excavation conducted in Xiamen as a case study, this study developed a two-dimensional hydro-mechanical coupled finite element model to systematically investigate the effects of various dewatering scenarios and soil permeability coefficients on surface settlement around the pit, and to reveal settlement patterns induced by dewatering and excavation in such strata. Field monitoring data were incorporated to validate the numerical model, ensuring accuracy and reliability. Key findings include the following: (1) Dewatering contributes to over 76% of the total settlement at each stage, with confined drawdown being the dominant factor, implying that dewatering optimization should take priority over controlling excavation rate. (2) Under confined dewatering, the settlement influence zone extends beyond 80 m, far exceeding the extension caused by excavation alone; thus, monitoring and protection ranges must be adjusted dynamically. (3) The horizontal permeability of sand shows a nonlinear positive correlation with settlement, and this sensitivity grows with depth, highlighting the need for accurate permeability determination and stricter controls in deep excavations within water-rich sand layers. From an engineering perspective, these findings underscore the importance of prioritizing confined aquifer dewatering management, dynamically expanding settlement monitoring zones, and rigorously characterizing permeability profiles to mitigate excessive ground settlement and protect adjacent infrastructure. Full article

The impact of short-distance lateral shield tunneling threatens the safety of operational high-speed railways (HSRs). To address the engineering challenge of “how to select isolation pile density under fixed cost constraints,” this study focuses on the Xi’an Metro shield tunnel section passing laterally adjacent to the Daxi and Zhengxi Passenger Dedicated Lines. Under the constraint of identical total economic costs, two isolation pile schemes—low-density and high-density—were established to investigate the control patterns of different densities on HSR bridge piles and surrounding ground surface deformation. A three-dimensional (3D) numerical model was developed for the lateral shield tunneling process. Combined with field-measured data, numerical simulations were conducted for corresponding construction stages to analyze the disturbance effects of shield tunneling on HSR piers and the surrounding ground, as well as the deformation restraint performance of isolation piles. The results indicate that the high-density isolation pile scheme (pile spacing: 2.0 m; pile length: 22 m) provides superior control compared to the low-density scheme (pile spacing: 4 m; pile length: 28 m). Following single- and double-track excavation, the vertical displacement of HSR piers was reduced by 0.6 mm and 1.1 mm, respectively—a reduction of 40–74%. Furthermore, the pier displacement along the depth direction shifted from non-uniform to relatively uniform. The difference in surface settlement between the two schemes was only 0.2 mm, suggesting that isolation pile density has a marginal impact on ground deformation. The horizontal displacement of high-density isolation piles stabilized at 1.7–1.9 mm, with vertical heave ranging from 1.2 to 1.4 mm. The lateral displacement profile exhibited a regular “double-C outward expansion” shape, which is better suited to the characteristics of water-rich sand layers. Initial excavation causes significant disturbance to the original strata, necessitating enhanced stress field protection measures. The high-density scheme is recommended for engineering applications, as it achieves optimal control of bridge pile deformation under cost constraints and meets regulatory specifications. Full article

Deep foundation excavation in water-rich sand strata presents complex deformation characteristics driven by fluid–solid interaction, which distinguishes it from excavations in cohesive soft clay. This study investigates the spatiotemporal evolution and deformation mechanisms of retaining structures through a comparative analysis of field monitoring data and 3D numerical simulation, based on a subway station project in Xi’an. While the numerical simulation predicted a continuous “bulging” deformation mode, field monitoring revealed a distinct transition from a “bulging” profile to a “step-like” deformation pattern as the excavation deepened. Quantitatively, while the simulation captured the spatial trend, the measured maximum surface settlement (7.8 mm) exceeded the simulated value (1.2 mm), highlighting the dominant role of seepage consolidation. Detailed analysis indicates that this discrepancy—and the unique step-like evolution—is primarily driven by two mechanisms: the rapid stress relaxation of cohesionless sand during the time lag of support installation, and the superimposed seepage forces induced by continuous dewatering, which are often simplified in standard elastoplastic models. The study further identifies that the vertical displacement of the pile top is governed by the combined effects of basal heave and the “kick-out” deformation at the pile toe. These findings demonstrate that in high-permeability water-rich sand, deformation control depends critically on minimizing the unsupported exposure time of the excavation face. This research provides a theoretical basis for optimizing the spatiotemporal sequencing of excavation in similar geological conditions. Full article

Urban underground pipeline aging and leakage can result in soil erosion and ground collapse, constituting a major threat to urban public safety. To investigate this disaster mechanism, this present study established a two-dimensional numerical model based on the computational fluid dynamics–discrete element method (CFD–DEM) two-way fluid–solid coupling approach, simulating and reproducing the entire process from soil erosion, soil arch evolution to ground collapse caused by underground pipeline leakage in water-rich sand layers. The simulation shows that under the action of seepage pressures, soil particles are eroded and lost, forming a cavity above the pipeline defect. As soil continues to be lost, the disturbed zone expands toward the ground surface, causing ground settlement, and in water-rich sand layers, a funnel-shaped sinkhole is eventually formed. The ground collapse process is closely related to the groundwater level and the thickness of the overlying soil layer above the pipeline. Rising groundwater levels reduce the effective stress and shear strength of the soil, significantly exacerbating seepage erosion. Increasing the thickness of the overlying soil layer can enhance the confining pressure, improve soil compactness, and promote the formation of soil stress arch, thereby effectively slowing down the rate of ground collapse. This study reproduces the process of ground collapse numerically and reveals the mechanism of ground collapse induced by underground pipeline leakage in water-rich sand layers. Full article

Earth Pressure Balance (EPB) shield machines have been widely used in subway construction due to their versatility and safety. During the shield tunneling process, the earth pressure in the shield machine chamber is crucial for controlling ground settlement and ensuring the safety of surrounding buildings. However, current research on the temporal and spatial evolution of earth pressure in water-rich sand layers and its relationship with ground settlement is relatively insufficient. This study focuses on the shield tunneling project between Liuzhou East Road and Puzhou Road on Nanjing Metro Line 11. First, laboratory and on-site tests were conducted to optimize the slump properties of the sediment. Then, based on Terzaghi’s theory and statistical methods, the temporal and spatial evolution trends of the earth pressure in the shield chamber under water-rich sand conditions were explored. Finally, by adjusting earth pressure control parameters on-site and monitoring ground settlement, the impact of earth pressure changes on ground settlement was analyzed. Results showed a linear correlation between the actual earth pressure and shield burial depth. For water-rich sand with medium permeability, the theoretical earth pressure was calculated using Terzaghi’s water-soil combined method in shallow sections, and the average of combined and separated methods in deep sections. The decay envelope showed an exponential downward trend, with rapid decay initially and slower decay later. As earth pressure control values increased, pre-consolidation settlement increased, instantaneous settlement decreased, pre-consolidation settlement rate slightly increased, and instantaneous settlement rate decreased. When excavation pressure was below theoretical pressure, higher instantaneous settlement rates could threaten surface structures. This research offers vital theoretical and data references for shield tunneling in water-rich sand layers and supports related EPB shield machine theory studies. Full article

To investigate the mechanisms underlying the continuous failure of deep foundation pits in tropical water-rich sandy strata, this study comprehensively examines a foundation pit project in Haikou city, China. Using the PLAXIS^3D 24.1 software, a three-dimensional finite element numerical model was developed. The analysis integrates design schemes, field investigations, monitoring data, and other relevant information to elucidate the mechanisms of disaster damage, such as foundation pit water inrush, floor collapse, and sidewall failure. The results indicate that the water barrier layer is the thinnest at the elevator shaft foundation pit, with a rapid shortening of seepage paths following the extraction of steel sheet piles; the seepage velocity increases by approximately 120%, leading to groundwater breaching both the water barrier and cushion layers. The inadequate length of the suspended impervious curtain in the confined aquifer results in a maximum seepage velocity at the defect site that is 40 times greater than that at other locations, facilitating groundwater influx into the foundation pit. As the excavation deepens, significant alterations occur in the groundwater seepage field at the defect location in the water-resisting curtain, with the seepage velocity increasing from 6.4 mm/day outside the pit to 78.8 mm/day inside the pit, thereby threatening the stability of the pit foundation. Additionally, construction quality defects arising from the three-axis mixing method in the silty sand layer cause a downward shift in the maximum horizontal displacement of the supporting structure, with displacement increments near the defects reaching 63%. Unreasonable emergency pumping measures can lead to floor collapses and sidewall damage. The soil in the pit significantly affects the back pressure, but it is also affected by the distance, and the increase in seepage velocity in the elevator shaft remains under 1% and does not significantly impact the damaging incident. Full article

A suitable range of paste and mortar margins (α and β) to enhance compressive strength in Rich-Mix cemented sand gravel and rock (CSGR) material for application in CSGRD construction is critical. SL 678-2014 recommends margins > 1, which are specifically designed to fill the voids within the fine and coarse aggregates with paste and mortar, respectively, while allowing some excess for workability. However, the optimum ranges of values after 1 are inadequately determined, often leading to high efforts and time-consuming trial mixes that are not economical. This study evaluates two datasets to identify the optimal ranges of α and β margins for compressive strength development in Rich-Mix CSGR, aiming to achieve the compressive strength class C₁₈₀20, intended for use as cushion, protective, and seepage control layers in CSGRD. Using Pearson correlations, t-statistics, and p-values, the first dataset (7, 28, 90, and 180 days) showed weak correlations between paste margins and compressive strengths (coefficients 0.172 to 0.418, p-values > 0.05) and negligible relationships for mortar margins (coefficients −0.269 to 0.204, p-values > 0.05), affirming the contribution of other factors in the compressive strength development in CSGR. The second dataset (14, 28, 90, and 180 days) revealed significant positive correlations between paste margins and strengths at 14, 90, and 180 days (coefficients up to 0.850, p-values < 0.05). Mortar margins, however, negatively impacted strength (coefficients −0.544 to −0.628, p-values < 0.05), revealing the need to control the sand ratio. The optimal range of values was 1.05 ≤ α ≤ 1.09 and 1.15 ≤ β ≤ 1.25, with a water–binder ratio of 0.7~1.3, vibrating–compacted value (VC) of 2~8 s, and sand ratio of 18~35%. These findings highlight the significance of precise paste and mortar margin ranges in the compressive strength development of Rich-Mix CSGR. Full article

Background: The restoration of the degraded sandy grasslands in Hulun Buir is crucial for maintaining the local ecological balance and sustainable development. Caragana microphylla Lam., a shrub species widely employed in the restoration of sandy vegetation. It is essential to understand its impact on the understory vegetation and soil properties during this process. Methods: This study employed ANOVA, Pearson correlation, and redundancy analysis to systematically analyze the impact of C. microphylla on the three critical stages of desertified grassland vegetation recovery: semi-fixed dunes, fixed dunes, and sandy grasslands. It provided strategies for the restoration of desertified grassland vegetation and offered additional theoretical evidence for the role of vegetation in promoting the recovery of sandy lands. Results: (1) As the degree of vegetation recovery in desertified grasslands increases, the species richness of understory vegetation, Shannon–Wiener index, community height, and biomass also increase. Both the community height and biomass within shrublands are higher than outside, with species richness within the shrublands being higher than outside during the semi-fixed and fixed-sand land stages. (2) In both the 0~10 cm and 10~20 cm soil layers, soil water content showed an increasing trend, peaking in the sandy grassland stage (1.2%), and was higher within the shrublands than outside. The soil water content at 10~20 cm was higher than in the 0~10 cm layer. In both layers, clay and silt content gradually increased with the degree of vegetation recovery in the sandy land, and higher within the shrublands than outside, while the opposite was true for sand content. (3) In both soil layers, soil organic carbon gradually increased with the degree of vegetation recovery, peaking in the sandy grassland stage (4.12 g·kg⁻¹), and was higher within the shrublands than outside. Total nitrogen increased from the semi-fixed-sand land stage to the fixed-sand land stage, with higher levels within the shrublands than outside at all stages. Soil pH within the shrublands decreased as the degree of vegetation recovery increased. There was no significant change in the total phosphorus content. (4) In both soil layers, soil physicochemical characteristics accounted for 59.6% and 46.9% of the vegetation changes within and outside the shrublands, respectively, with the main influencing factors being the soil particle size, total nitrogen, soil water content, and soil organic carbon. Conclusions: In the process of sandy grassland restoration, C. microphylla facilitates the growth and development of vegetation by enhancing the underlying soil physicochemical properties, specifically regarding the soil particle size distribution, soil water content, soil organic carbon, and total nitrogen. Full article

The high permeability of gravel sand increases the risk of water spewing from the screw conveyor during earth pressure balance (EPB) shield tunnelling. The effectiveness of soil conditioning is a key factor affecting EPB shield tunnelling and construction safety. In this paper, using polymer, a foaming agent, and bentonite slurry as conditioning additives, the permeability coefficient tests of conditioned gravel sand are carried out under different injection conditions based on the factorial experiment design. The interactions between different concentrations of conditioning additives are analyzed. A prediction model for soil conditioning during shield tunneling based on particle swarm optimization (PSO) and relevance vector machine (RVM) algorithms is proposed to accurately and efficiently obtain the soil conditioning parameters in the water-rich gravel sand layer. The experimental results indicate that the improvement effect of the foaming agent on the permeability of the conditioned gravel sand gradually diminishes with the growing concentration of bentonite slurry. Under conditions of high polymer concentration, further increasing the concentration of bentonite slurry and foaming agent has a weak impact on the permeability coefficient when the concentration of bentonite slurry exceeds 10%. The significance of main effects, first-order interactions, and second-order interaction on the permeability of conditioned gravel sand are as follows: polymer concentration (A) > foaming agent concentration (B) > bentonite slurry concentration (C) > first-order interactions (A × B, A × C, B × C) > second-order interaction (A × B × C). The first-order interaction mainly manifests as a synergistic effect, while the second-order interaction primarily exhibits an antagonistic effect. Case studies show that the maximum relative error between predicted and experimental values is less than 3%. A field application of shield tunneling demonstrates the good performance of real-time optimization of soil conditioning parameters based on the PSO–RVM algorithm. This research provides a new method for evaluating the effectiveness of soil conditioning in the water-rich gravel sand layer. Full article

The existence of defects in the enclosure structure is the primary cause of water and sand leakage in foundation pits, as well as being a significant source of danger in pit construction, but current research lacks an in-depth investigation of the generation mechanism and gestation process. In this paper, which comprehensively considers the microscopic particles and macroscopic level, the development mechanism of a water and sand leakage disaster in a foundation pit with a water-rich sand layer was studied using the principle of computational fluid dynamics and discrete element method coupled analysis (CFD–DEM); moreover, based on the anisotropy of the particle force and fluid energy analysis, the deformation of the stratum and ground stress field were analyzed. The results show that the stress field will produce a plugging effect at a certain distance from the defect, and the strata exhibit a dominant displacement tendency in the vertical direction, resulting in the emergence of a gradually concave stress relaxation zone and an elliptical contour in the strata displacement map near the defect. The fluid energy describes the displacement of the sand layer very well, and it is separated into the sand layer’s centralized loss region and the major loss area based on the high and low levels of the fluid energy class. The impact of fluid at the defect reaches the maximum kinetic energy, which penetrates the structural weakness and causes the loss of sand particles, and the cross-section of the water influx near the defect gradually expands with the loss of particles, indicating that there is a danger of further expansion of the defect under the impact of water flow. These results have technical implications for the management of water and sand leakage disasters in foundation pit engineering. Full article

Electrical resistivity and borehole data are applied to delineate lithostratigraphic boundaries and image the geometry of confining-unit breaches in Eocene coastal-plain deposits to evaluate inter-aquifer exchange pathways. Eight dipole–dipole array surveys were carried out, and apparent resistivity was inverted to examine the lateral continuity of lithologic units in different water-saturation and geomorphic settings. In addition, sensitivity analysis of inverted resistivity profiles to electrode spacing was performed. Resistivity profiles from Shelby Farms (SF) highlight the effect of varied electrode spacing (2.5, 5, and 10 m), showing an apparent ~0.63 to 0.75 depth shift in resistivity-layer boundaries when spacing is halved, with the 10 m spacing closely matching borehole stratigraphy. Grays Creek and Presidents Island profiles show clay-rich Eocene Cook Mountain Formation (CMF), with resistivity ranging from 10 to 70 Ω-m, overlying the Eocene Memphis Sand—a prolific water-supply aquifer. Resistivity profiles of SF and Audubon Park reveal sandy Cockfield Formation (CFF) paleochannels inset within and through the CMF, providing hydrogeologic connection between aquifers, and clarifying the sedimentary origin of confining-unit breaches in the region. The results underscore the efficacy of the electrical resistivity method in identifying sand-rich paleochannel discontinuities in a low-resistivity regional confining unit, which may be a common origin of breaches in coastal-plain confining units. Full article

The compression release of pore water in clayey aquitards has a significant impact on groundwater quality. Iron is an active variable element that mediates biochemical reactions in groundwater systems, but its transformation mechanisms in clayey aquitards remain unclear. The sediment and pore water samples from the shallow clayey aquitard (thickness = ~20 m) in the Chen Lake area of China were collected in three boreholes. The spatial distribution and influencing factors of Fe occurrence in the aquitard were revealed using hierarchical extraction, statistical analysis, and simulation calculations. The results indicate that the background value of alluvial–lacustrine sediments primarily affects the Fe concentration of clayey sediments. The dissimilatory reduction in free Fe oxide was the main source of Fe ions in pore water, resulting in a major percentage of Fe²⁺ in the total Fe concentration (0.07−5.91 mg/L). The abundant organic matter in organic-rich clay promoted a dissimilatory reduction in Fe (III) oxides, while the Fe concentrations of sediment and pore water were lower in the sand-rich stratum because of its weak adsorption capacity. The impact of human reclamation activities on the aquitard was mainly concentrated in the shallow layer ($>-3 \mathrm{m}$), resulting in water drainage and O₂ and CO₂ input, which induced the crystallization of poorly crystalline Fe oxides. The input of reactive organic matter from reclaimed crops promoted the dissimilatory reduction in Fe oxides and the enrichment of Fe in deep pore water. The copious Fe²⁺ in deep stratum pore water tended to interact with CO₃²⁻ and S²⁻ to form coprecipitation with Fe (II). The concentrations of As, Cr, Sr, Zn, and Mn in pore water followed a similar variation trend to the Fe ion concentration, and their release could be attributed to the reduction dissolution of sediment Fe (III) oxides. Full article

The distribution characteristics of a seepage field generated by precipitation affects the deformation damage of the geological body and engineering geological stability, especially a seepage field with a water-rich ultra-thick sand and gravel layer. In order to study the seepage field distribution characteristics of a water-rich ultra-thick sand and gravel layer, taking Luoyang Metro Line 1 as the engineering background, combined with the actual monitoring data of on-site precipitation, numerical simulation was used to study the seepage characteristics of the pit project precipitation with a suspended water-stop curtain. Through the study, the distribution characteristics of the seepage field under different precipitation depths and aquifer thicknesses were obtained, and the changes in pore water pressure characteristics, flow velocity and water inflow, depending on the precipitation depth and aquifer thickness, were analyzed. The research results show that, when comparing the calculated and measured results of the water level drop in the foundation pit, the average value of the error of the water level drop value in the pit and the descending well is 11.7%, which indicates that the calculation model meets the needs for its use in calculation and analysis. Under the conditions of a suspended water-stop curtain and precipitation, for the pore water pressure characteristics, the variation amplitude of the pore water pressure inside the pit increases with the precipitation depth and aquifer thickness. For the maximum flow velocity, all characteristics are present at the bottom of the suspended water-stop curtain, near the inside of the pit. The maximum flow velocity increases linearly with the precipitation depth and there is a threshold when the aquifer thickness is five times the precipitation depth. For water inflow, it increases with the increase in the precipitation depth and aquifer thickness, but, with a continuous increase in the aquifer thickness, the magnitude of water inflow growth decreases. Full article
