Search Results (53)

Global building energy consumption is significantly increasing. Utilizing renewable energy sources may be an effective approach to achieving low-carbon and energy-efficient buildings. A combined system incorporating solar photovoltaic–thermal (PV/T) components with an air-source heat pump (ASHP) was studied for simultaneous heating and power generation in a real residential building. The back panel of the PV/T component featured a novel polygonal Freon circulation channel design. A prototype of the combined heating and power supply system was constructed and tested in Fuzhou City, China. The results indicate that the average coefficient of performance (COP) of the system is 4.66 when the ASHP operates independently. When the PV/T component is integrated with the ASHP, the average COP increases to 5.37. On sunny days, the daily average thermal output of 32 PV/T components reaches 24 kW, while the daily average electricity generation is 64 kW·h. On cloudy days, the average daily power generation is 15.6 kW·h; however, the residual power stored in the battery from the previous day could be utilized to ensure the energy demand in the system. Compared to conventional photovoltaic (PV) systems, the overall energy utilization efficiency improves from 5.68% to 17.76%. The hot water temperature stored in the tank can reach 46.8 °C, satisfying typical household hot water requirements. In comparison to standard PV modules, the system achieves an average cooling efficiency of 45.02%. The variation rate of the system’s thermal loss coefficient is relatively low at 5.07%. The optimal water tank capacity for the system is determined to be 450 L. This system demonstrates significant potential for providing efficient combined heat and power supply for buildings, offering considerable economic and environmental benefits, thereby serving as a reference for the future development of low-carbon and energy-saving building technologies. Full article

Water, acetone, and TiO₂/nano-silver water (NSW) nanofluids were investigated as working fluids in loop thermosyphon battery thermal management systems (LTBMS) under simulated electric vehicle (EV) conditions to evaluate scalability and robustness across inclinations (0° to 60°) and ambient temperatures (−10 °C to 20 °C). Experimental conditions were established with 60 °C as the reference temperature, corresponding to the onset of battery thermal runaway, to ensure relevance to critical thermal management scenarios. Results indicate that LTBMS A maintained battery cell temperatures at 50.4 °C with water and 31.6 °C with acetone under a 50 W heat load. In contrast, LTBMS B achieved cell temperatures of 41.8 °C with water and 42.8 °C with 0.01 vol% TiO₂ nanofluid, however, performance deteriorated at higher nanofluid concentrations due to increased viscosity and related thermophysical constraints. In heating mode, LTBMS A elevated cell temperatures by 16 °C at an ambient temperature of −10 °C using acetone, while LTBMS B attained 52–55 °C at a 100 W heat load with nanofluids. The lightweight LTBMS design demonstrated superior thermal performance compared to conventional air-cooling systems and performance comparable to liquid-cooling systems. Pure water proved to be the most effective working fluid, while nanofluids require further optimization to enhance their practical applicability in EV thermal management. Full article

In response to the global imperative to reduce greenhouse gas emissions and fossil fuel dependency, electric vehicles (EVs) have emerged as a sustainable transportation alternative, primarily utilizing lithium-ion batteries (LIBs) due to their high energy density and efficiency. However, LIBs are highly sensitive to temperature fluctuations, significantly affecting their performance, lifespan, and safety. One of the most critical threats to the safe operation of LIBs is thermal runaway (TR), an uncontrollable exothermic process that can lead to catastrophic failure under abusive conditions. Moreover, thermal runaway propagation (TRP) can rapidly spread failures across battery cells, intensifying safety threats. To address these challenges, developing advanced battery thermal management systems (BTMS) is essential to ensure optimal temperature control and suppress TR and TRP within LIB modules. This review systematically evaluates advanced cooling strategies, including indirect liquid cooling, water mist cooling, immersion cooling, phase change material (PCM) cooling, and hybrid cooling based on the latest studies published between 2020 and 2025. The review highlights their mechanisms, effectiveness, and practical considerations for preventing TR initiation and suppressing TRP in battery modules. Finally, key findings and future directions for designing next-generation BTMS are proposed, contributing valuable insights for enhancing the safety and reliability of LIB applications. Full article

Lithium-ion batteries are required to equip the cooling system for high power performance, quick charge, and safety. Trimethylolethane (TME) hydrate is known as phase change material (PCM), a cooling medium that offers large dissociation heat and 30 °C form/dissociation temperature under atmospheric pressure. This study demonstrates the design of a practical cooling system with TME hydrate. This cooling method involves cooling outdoor air through water contact, exchanging heat between the cooled outdoor air and the aqueous solution of TME hydrate, exchanging heat from the resulting TME hydrate with a refrigerant, and finally supplying the processed refrigerant to the cooling LIB. Koyama et al. conducted a study on the physical properties of TME hydrate. They measured equilibrium temperatures and dissociation heats of TME mass fractions from 0.20 to 0.80. Their findings revealed that at a mass fraction of 0.60, the system reached its highest equilibrium temperature of 29.6 °C, and the dissociation heat peaked at 190.1 kJ/kg. This cooling system employed TME hydrate. These results underscore the potential of TME hydrates in energy-efficient cooling systems and demonstrate that they are suitable for lithium-ion battery cooling systems. Full article

A hybrid cooling method for 18650 lithium-ion batteries has been investigated using both experimental and numerical approaches for electric vehicle applications. The experimental setup includes a heater section, a phase change material (PCM) reservoir, and a cooling section. The heater section simulates battery heat generation with two cylindrical aluminum housings, each sized to match an 18650 battery, two cartridge heaters, and an aluminum heat sink. An airflow channel is incorporated into the cooling section. Heat transfers sequentially from the heaters to aluminum housings, the heat sink, through three copper-water heat pipes (HPs), to/from the PCM, and finally to the cooled air in the airflow channel. This innovative design eliminates direct contact between the PCM and the batteries, unlike recent studies where the PCM has been in direct contact with the batteries. Decoupling the PCM reduces system design complexity while maintaining effective thermal management. Temperature measurements at various locations are analyzed under different heater powers, air velocities, and scenarios with and without PCM. Results show that the experimental design effectively maintains battery temperatures within acceptable limits. For a power input of 16 W, steady-state temperatures are reduced by approximately 14%, 10%, and 4% with PCM compared to without PCM for air velocities of 2 m/s, 3 m/s, and 4 m/s, respectively. A transient three-dimensional numerical model was developed in ANSYS-FLUENT to provide insights into the underlying physics. The phase change was simulated using the enthalpy-porosity approach, with computational results showing reasonable agreement with experimental data. Full article

In electric vehicles (EVs), the batteries are arranged in the battery pack (BP), which has a small layout space and difficulty in dissipating heat. Therefore, in EVs, the battery thermal management systems (BTMSs) are critical to managing heat to ensure safety and performance, particularly under higher operating temperatures and longer discharge conditions. To solve this problem, in this article, the thermal analysis models of a 3-battery-cell BP were created, including scenarios (1) natural air cooling without a BTMS; (2) natural air cooling with water cooling hybrid BTMS; and (3) forced air cooling plus water cooling composite BTMS. The thermal performances of the pack-level BPs were simulated and analyzed based on computational fluid dynamics (CFD). A variety of boundary conditions and working parameters, such as ambient temperature, inlet coolant flow rate and initial temperature, discharge rate, air flow rate, and initial temperature, were considered. The results show that without a BTMS (Scenario 1), the maximum temperature in the BP rises rapidly and continuously to reach 63.8 °C, much higher than the upper bound of the recommended operating temperature range (ROTR between +20 °C to +35 °C) under the extreme discharge rate of 3 C and even if the discharge rate is 2 C. With a hybrid BTMS (Scenario 2), the maximum temperature in BP rises to about 38.7 °C, slightly above the upper bound of the ROTR. Lowering the coolant (water) initial temperature can effectively lower the temperature up to 5.7 °C in BP, but the water flow rate cannot since the turbulence model. While with a composite BTMS (Scenario 3), the temperature can be further lowered up to 1.5 °C under the extreme discharge rate of 3C, just reaching the upper bound of the ROTR. In addition, lowering the initial coolant temperature or air temperature can effectively decrease the temperatures up to 5.1 and 1.0 °C, respectively, in BP, but the coolant flow rate (due to the turbulence model) and the air flow rate cannot. Finally, the thermal performances of the different battery cells in the BP with different cooling systems and at the different positions of the BP were compared and analyzed. The present work may contribute to the design of BTMSs in the EV industry. Full article

Hydrogen (H2) offers a green medium for storing the excess from renewables production instead of dumping it, thus being crucial to decarbonisation efforts. Hydrogen also offers a storage medium for the grid’s cheap electricity to be used during grid peak demand or grid power cutoffs. Funded by the Scottish Government’s Emerging Energy Technologies, this paper presents the design and performance analysis of a hydrogen uninterruptible power supply (H2GEN) for Cygnas Solutions Ltd., which is intended to enable continuity of supply in the residential sector while eradicating the need for environmentally and health risky lead–acid batteries and diesel generator backup. This paper presents the design, optimal sizing and analysis of two H2Gen architectures, one powered by the grid alone and the other powered by both the grid and a renewable (PV) source. By developing a model of each architecture in the HOMER space and using residential location weather data, the home yearly load–demand profile, and the grid yearly power outages profile in the developed models, the optimal sizing of each H2Gen design was realised by minimising the costs while ensuring the H2Gen meets the home power demand during grid outages To enable HOMER to optimise its selection, the sizes, technical specifications and costs of all the market-available H2GEN components were added in the HOMER search space. Moreover, the developed models were also used in assessing the sensitivity of the simulation outputs to several changes in the modelled system design and settings. Using a residential home with frequent power outages in New Delhi, India as a case study, it was found that the optimal sizing of H2Gen Architecture 1 is comprised of a 2 kW electrolyser, a 0.2 kg type-I tank, and a 2 kW water-cooled fuel cell directly connected to the AC bus, offering an operational lifetime of 14.3 years. It was also found that the optimal sizing of Architecture 2 is comprised of a 1 kV PV utilised with the same 2 kW electrolyser, 0.2 kg type-I tank and 2 kW water-cooled fuel cell connected to the AC bus. While the second design was found to have a higher capital cost due to the added PV, it offered a more cost-effective and environmentally friendly architecture, which contributes to the ongoing energy transition. This paper further investigated the capacity expansion of each H2GEN architecture to meet higher load demands or increased grid power outages. From the analysis of the simulation results, it has been concluded that the most feasible and cost-effective H2GEN system expansion for meeting increased power demands or increased grid outages can be realised by using the developed models for optimally sizing the expanded H2Gen on a case-by-case basis because the increase in these profiles is highly time-dependent (for example, an increased load demand or increased grid outage in the morning can be met by the PV, while in the evening, it must be met by the H2GEN). Finally, this paper investigated the impact of other environmental variables, such as the temperature and relative humidity, on the H2GEN’s performance and provided further insights into increasing the overall system efficiency and cost benefit through utilising the H2GEN’s exhaust heat in the home space for heating/cooling and selling the electrolyser exhaust’s O₂ as a commodity. Full article

Lithium-ion batteries have been increasingly demonstrated in reuse applications for environmental and economic reasons, and stationary energy storage systems (ESS) and mobile ESS are emerging as reuse applications for electric vehicle batteries. Most mobile ESS deployments are at large scales, necessitating experimental data on thermal runaway (TR) to ensure comprehensive safety. In this study, TR induction and suppression experiments were conducted using fully charged NCM-based batteries at the cell (750 Wh), module (7.5 kWh), and pack (74 kWh) levels. The stepwise TR experiments measured changes in temperature, voltage, heat release rate, volatile organic compound concentrations, and vent gas composition. The suppression experiments assessed the effective water injection rate, timing, and volume required to mitigate TR propagation. The results demonstrate that in the case of TR caused by thermal abuse, early detection of battery abnormalities is possible through monitoring pre-TR indicators, such as temperature and vent gas concentration. It was also confirmed that CO₂ injections can effectively cool the battery without causing damage. Furthermore, it is proposed that rapid water injection, directly contacting the battery immediately after the onset of TR, can successfully prevent TR propagation. Full article

Thermal energy storage (TES) systems open up alternative paths for air conditioning to increase the range of battery electric vehicles (BEVs) by reducing power consumption. The central prerequisites for this purpose are high storage densities: high-temperature TES systems are being focused on for heat demands, while effective solutions for cooling are missing. Due to their lower temperature potentials, concepts with high storage capacities and heat transports between the storage and cold transferring medium are needed. Latent TES systems based on water enable these capacities but require adequate internal structures for effective heat transfer. Due to the large number of geometric options, high simulation efforts must be conducted to identify favored structures, or the possible design space must be limited for investigations. For this purpose and for the first time, an alternative way is presented using newly developed dimensionless models in a top-down methodology for time-efficient design studies and evaluations. These models were successfully validated and used as a design tool to identify effective structures in latent TES systems for cooling demands in BEVs. A wide array of variation studies on tube, finned plate and novel Triply Periodic Minimal Surface (TPMS) structures were performed and uniformly evaluated with regard to storage densities, cooling efficiencies and geometry. The results show high storage densities for novel TPMS structures, including the enclosure of 100 Wh/kg or 102.2 kWh/m³ with average cooling capacities of 1 kW over 30 min, confirming the usability of latent TES systems in terms of compactness and efficiency for cooling demands in BEVs. Full article

The market share of blade batteries is rising rapidly due to their high energy density, efficient space utilization, and low cost. Nevertheless, effective cooling solutions for blade batteries are crucial to ensure the safe operation of electric vehicles, especially in extreme high-temperature environments. This paper numerically investigates the effects of a cooling plate and the blade battery parameters on maximum battery temperature, maximum temperature difference, and cooling water pressure drop. Additionally, the energy efficiency of these solutions under various cooling demands is analyzed. The numerical results show that increasing the channel number and changing the flow direction does not significantly improve the cooling performance of the cooling plate. Moreover, the effect of cooling water temperature on the maximum temperature difference in blade batteries is negligible. Furthermore, increasing the cooling water mass flow rate and the rotational speed of the cooling fan is preferred when T_max − T_a > 6 K, while reducing the cooling water temperature is more energy-efficient when T_max − T_a < 6 K. These results are expected to offer theoretical guidance and data support for designing cooling systems for blade batteries in extreme high-temperature environments. Full article

This study investigated the application of nanophase change material emulsions (NPCMEs) for thermal management in high-capacity ternary lithium-ion batteries. We formulated an NPCME of n-octadecane (n-OD) and n-eicosane (n-E) with a mass fraction of 10%, whose phase change temperatures are 25.5 °C and 32.5 °C, respectively, with specific heat capacities 2.1 and 2.4 times greater than water. Experiments were conducted to evaluate the thermal control performance and latent heat utilization efficiency of these NPCMEs. The NPCMEs with an n-OD mass fraction of 10% (NPCME-n-OD), particularly reduced the battery pack’s maximum temperature and temperature difference to 41.6 °C and 3.72 °C under a 2 C discharge rate, lower than the water-cooled group by 1.3 °C and 0.3 °C. This suggests that nano emulsions with phase change temperatures close to ambient temperatures exhibit superior cooling performance. Increased flow rates from 50 mL/min to 75 mL/min significantly lowered temperatures, resulting in temperature reductions of 2.73 °C for the NPCME-n-OD group and 3.37 °C for the NPCME-n-E group. However, the latent heat utilization efficiency of the nano emulsions decreased, leading to increased system energy consumption. Also, it was found that the inlet temperature of the NPCMEs was very important for good thermal management. The right inlet temperatures make it easier to use phase change latent heat, while excessively high temperatures may make thermal management less effective. Full article

This study presents a novel approach that will address escalating demands for water and cooling in regions vulnerable to climate change through the proposal of an optimal integrated cooling–freshwater cogeneration system powered by renewable energy sources. Comprising three subsystems (integrated multi-effect evaporation distillation, absorption heat pump, and vapor compression refrigeration (MAV); renewable energy unit incorporating solar panels, wind turbines, batteries, and hydrogen facilities (RHP/BH); and combined heat and power (CHP)), the system aims to produce both cooling and freshwater. By recovering cooling from combined desalination and refrigeration subsystems to chill the air taken into the gas turbine compressor, the system maximizes efficiency. Through the recovery of waste heat and employing an integrated thermo-environ-economic framework, a novel objective function, termed modified total annual cost (MTAC), is introduced for optimization. Using a genetic algorithm, parametric iterative optimization minimizes the MTAC. The results reveal that under optimum conditions, the MAV, RHP/BH, and CHP subsystems account for 67%, 58%, and 100% of total annual, exergy destruction, and environmental costs, respectively. Notably, the system exhibits lower sensitivity to fuel prices than renewable energy sources, suggesting a need for future research that will incorporate dynamic product prices and greater fuel consumption to produce enhanced operational robustness. Full article

Maintaining the peak temperature of a battery within limits is a mandate for the safer operation of electric vehicles. In two-wheeler electric vehicles, the options available for the battery thermal management system are minuscule due to the restrictions imposed by factors like weight, cost, availability, performance, and load. In this study, a multi-strategical cooling approach of forced convection and mist cooling over a single-cell 21,700 lithium-ion battery working under the condition of 4C is proposed. The chosen levels for air velocities (10, 15, 20 and 25 m/s) imitate real-world riding conditions, and for mist cooling implementation, injection pressure with three levels (3, 7 and 14 bar) is considered. The ANSYS fluent simulation is carried out using the volume of fluid in the discrete phase modelling transition using water mist as a working fluid. Initial breakup is considered for more accurate calculations. The battery’s state of health (SOH) is determined using PYTHON by adopting the Newton–Raphson estimation. The maximum temperature reduction potential by employing an airflow improviser (AFI) and additives (Tween 80, 1-heptanol, APG0810, Tween 20 and FS3100) is also explored. The simulation results revealed that an additional reduction of about 11% was possible by incorporating additives and AFI in the multi-strategical approach. The corresponding SOH improvement was about 2%. When the electric two-wheeler operated under 4C, the optimal condition (Max. SOH and Min. peak cell temp.) was achieved at an air velocity of 25 m/s, injection pressure of 7 bar with AFI and 3% (by wt.) Tween 80 and a 0.1% deformer. Full article

Thermal events in lead-acid batteries during their operation play an important role; they affect not only the reaction rate of ongoing electrochemical reactions, but also the rate of discharge and self-discharge, length of service life and, in critical cases, can even cause a fatal failure of the battery, known as “thermal runaway.” This contribution discusses the parameters affecting the thermal state of the lead-acid battery. It was found by calculations and measurements that there is a cooling component in the lead-acid battery system which is caused by the endothermic discharge reactions and electrolysis of water during charging, related to entropy change contribution. Thus, under certain circumstances, it is possible to lower the temperature of the lead-acid battery during its discharging. The Joule heat generated on the internal resistance of the cell due to current flow, the exothermic charging reaction, and above all, the gradual increase in polarization as the cell voltage increases during charging all contribute to the heating of the cell, overtaking the cooling effect. Of these three sources of thermal energy, Joule heating in polarization resistance contributes the most to the temperature rise in the lead-acid battery. Thus, the maximum voltage reached determines the slope of the temperature rise in the lead-acid battery cell, and by a suitably chosen limiting voltage, it is possible to limit the danger of the “thermal runaway” effect. The overall thermal conditions of the experimental cell are significantly affected by the ambient temperature of the external environment and the rate of heat transfer through the walls of the calorimeter. A series of experiments with direct temperature measurement of individual locations within a lead-acid battery uses a calorimeter made of expanded polystyrene to minimize external influences. A hitherto unpublished phenomenon is discussed whereby the temperature of the positive electrode was lower than that of the negative electrode throughout the discharge, while during charging, the order was reversed and the temperature of the positive electrode was higher than that of the negative electrode throughout the charge. The authors relate this phenomenon to the higher reaction entropy change of the active mass of the positive electrode than that of the negative electrode. Full article

Battery thermal management systems (BTMSs) ensure that lithium-ion batteries (LIBs) in electric vehicles (EVs) are operated in an optimal temperature range to achieve high performance and reduce risks. A conventional BTMS operates either as an active system that uses forced air, water or immersion cooling, or as a complete passive system without any temperature control. Passive systems function without any active energy supply and are therefore economically and environmentally advantageous. However, today’s passive BTMSs have limited cooling performance, which additionally cannot be controlled. To overcome this issue, an innovative BTMS approach based on heat pipes with an integrated thermal switch, developed by the Fraunhofer Cluster of Excellence Programmable Materials (CPM), is presented in this paper. The suggested BTMS consists of switchable heat pipes which couple a passive fin-based cold plate with the battery cells. In cold state, the battery is insulated. If the switching temperature is reached, the heat pipes start working and conduct the battery heat to the cold plate where it is dissipated. The environmental benefits of this novel BTMS approach were then analysed with a Life Cycle Assessment (LCA). Here, a comparison is made between the suggested passive and an active BTMS. For the passive system, significantly lower environmental impacts were observed in nearly all impact categories assessed. It was identified as a technically promising and environmentally friendly approach for battery cooling in EVs of the compact class. Furthermore, the results show that passive BTMS in general are superior from an environmental point of view, due their energy self-sufficient nature. Full article
