Search Results (16)

The spiral case plays a role in providing stable and uniform water flow in the pump-turbine unit, and the overall structure with the surrounding concrete is an important foundation for the safe and stable operation of the unit and power plant. In order to clarify the comprehensive bearing capacity of preloading steel spiral case under pump operating conditions, this study is based on the theory of the fluid–structure coupling and contact model and uses ANSYS CFX 2021 R1 and mechanical to analyze the flow fluctuation characteristics and dynamic structural response of a preloading steel spiral case and surrounding concrete under different preloading pressures in the intermediate head pump condition. The results indicate that the main frequency of pressure fluctuations inside the main frequency ($1 f_n$) of pressure fluctuations inside the spiral case is influenced by the unstable flow. The contact state between the preloading steel spiral case and concrete is closely related to the relative magnitude of preloading pressure and hydraulic pressure. Higher preloading pressure can lead to an increase in initial preloading clearance, resulting in a decrease in contact area. The vortex motion inside the spiral case is the main factor affecting the distribution of deformation. The rotor–stator interaction also has a certain impact on the vibration of the spiral case structure, even though the influence of rotor–stator interaction on pressure fluctuation inside the spiral case is already small. The monitoring points where the maximum values of static stress and dynamic stress are located are different. Increasing the preloading pressure value does not always guarantee the safety of concrete structures, as the sticking contact area in early contact transfers most of the stress of the spiral case, resulting in significant stress concentration. Under the working conditions of this study, the concrete in contact with the inner edge and nose vane is subjected to excessive loads. Therefore, it is necessary to reinforce the structure with steel bars or other methods to improve its tensile strength. A minimum preloading pressure value of 3.2 MPa is beneficial for reducing the risk of concrete cracking. The research results can provide a deeper understanding of the behavior of preloading steel spiral cases under pump conditions and guide optimization design. Full article

Heat carried upward by atmospheric convection produces mechanical energy. An atmospheric vortex engine (AVE) uses a synthetic tornado-like vortex to capture mechanical energy from upward heat convection. The vortex is created by tangentially introducing warm or humid air into a circular wall base. Heat sources include solar energy, warm sea water, warm, humid air, and industrial waste. Earth’s natural surface collects heat, eliminating the need for solar collectors. The AVE uses the same thermodynamic principles as the solar chimney, but it uses centrifugal force in a vortex instead of a chimney and the earth’s surface instead of a collector. Turbogenerators nearby generate mechanical energy. Since the AVE uses less fuel to generate the same amount of electricity, it could reduce global warming. An AVE increases thermal power plant efficiency by lowering its cold-source temperature from the base of the troposphere to the tropopause. The AVE process could reduce global warming by lifting heat above greenhouse gases to radiate toward space. Since Pakistan is most affected by climate change and has many energy crises, this study aims to change engineers’ mindsets from inefficient conventional energy sources to more efficient non-conventional, cleaner energy sources. Full article

Gravitational water vortex turbines (GWVTs) are favored over fuel-based power plants due to its lower head requirements and smaller flow rates, making it an economically viable energy source. Different process parameters such as flow rate, cone angle, blade position, and blade type directly affect the torque generation and ultimately the efficiency of GWVTs. The objective of this research is to analyze the impact of different process parameters on torque generation and to determine the optimal efficiency by optimizing the controlling parameters through Design of Experiments (DOE) in combination with Taguchi analysis. This study involved fabricating an accurate experimental setup and conducting experiments on various parameter combinations. The results obtained showed that the blade type has a major influence on the response factor (torque). This research holds potential for advancements in renewable energy. Full article

Multiphase vortices are widely present in the metallurgical pouring processes, chemical material extraction, hydroelectric power plant energy conversion, and other engineering fields. Its critical state detection is of great significance in improving product yield and resource utilization. However, the multiphase vortex is a complex dynamics problem with highly nonlinear features, and its fluid-induced vibration-generation mechanism faces significant challenges. A fluid-solid coupling-based modeling method is proposed to explore mass transfer process with the vorticity distribution and vibration-generation mechanism. A vibration-processing method is utilized to discuss the four flow-state transition features. A fluid-induced vibration experiment platform is established to verify the numerical results. It is found that the proposed modeling method can better reveal the vibration-evolution regularities of the fluid-solid coupling process. The flow field has a maximum value in the complex water–oil–gas coupled flow process, and induces a pressure pulsation phenomenon, and its frequency amplitude is much larger than that of the water phase and water–oil two-phase flow states. In the critical generation state, the increasing amplitude and nonlinear step structure of high-frequency bands (45 Hz~50 Hz) and random pulse components can be used for the online detection of multiphase-coupling states. Full article

A dispersive solid-phase microextraction (DSPME) sorbent consisting of poly(1,6-hexanediol diacrylate)-based polymer microspheres, with embedded graphene microparticles (poly(HDDA)/graphene), was synthesized by microfluidic emulsification/photopolymerization and characterized by optical microscopy and X-ray fluorescence spectrometry. This sorbent was applied for simple, fast, and sensitive vortex-assisted DSPME of rare earth elements (RREs) in coal fly ash (CFA) leachate, prior to their quantification by inductively coupled plasma mass spectrometry (ICP-MS). Among nine DSPME variables, the Plackett–Burman screening design (PBD), followed by the central composite optimization design (CCD) using the Derringer desirability function (D), identified the eluent type as the most influencing DSPME variable. The optimum conditions with maximum D (0.65) for the chelating agent di-(2-ethylhexyl) phosphoric acid (D2EHPA) amount, the sorbent amount, the eluting solvent, the extraction temperature, the centrifuge speed, the vortexing time, the elution time, the centrifugation time, and pH, were set to 60 μL, 30 mg, 2 M HNO₃, 25 °C, 6000 rpm, 1 min, 1 min, 5 min, and 4.2, respectively. Analytical validation of the DSPME method for 16 REEs (Sc, Y, La, Ce, Pr, Nd, Sm, Eu, Gd, Tb, Dy, Ho, Er, Tm, Yb, Lu) in CFA leachate samples estimated the detection limits at the low ppt level, the recovery range 43–112%, and relative standard deviation within ± 22%. This method was applied to a water extraction procedure (EP) and acetic acid toxicity characteristic leaching procedure (TCLP) for leachate of CFA, from five different coal-fired thermoelectric power plants. The most abundant REEs in leachate (20 ÷ 1 solid-to-liquid ratio) are Ce, Y, and La, which were found in the range of 22–194 ng/L, 35–105 ng/L, 48–95 ng/L, and 9.6–51 μg/L, 7.3–22 μg/L, 2.4–17 μg/L, for EP and TCLP leachate, respectively. The least present REE in TCLP leachate was Lu (42–125 ng/L), which was not detected in EP leachate. Full article

Small-scale hydropower installations make possible a transition towards decentralized electrical power production with very low ecological footprint. However, the prediction of their power potential is difficult, because the incoming flow velocity and the inlet and outlet water heights are often outside of the control of the operator. This leads to a need for a method capable of calculating an installation’s power potential and efficiency rapidly, in order to cover for many possible load cases. In this article, the use of a previously-published theoretical framework is demonstrated with the case of a mid-scale hydropower device, a 26 m long water vortex power plant. It is shown that a simplified CFD simulation with a single output (the mass flow rate) is sufficient to obtain values for the two coefficients in the model. Once this is done, it becomes possible to evaluate the device’s real-life performance, benchmarking it against reference values anchored in physical principles. The method can be used to provide design guidance and rapidly compare different load cases, providing answers that are not easily obtained using intuition or even experiments. These results are obtained for a computing cost several orders of magnitude smaller than those associated with a full description of the flow using CFD methods. Full article

In this study, we analyzed the influence of coastal zone engineering on suspended sediment concentration (SSC) in the Yangtze River mouth based on HY-1C and Chinese GaoFen (GF) satellite data. The results show that: (1) SSC in the Yangtze River mouth is mainly in the range of 200–1300 mg/L, which changes due to natural factors as well as coastal zone engineering; (2) The sand blocking engineering effectively protects the channel from siltation, and SSC in the central line of the channel is 100–300 mg/L lower than that near the dikes in the north and south; (3) Qingcaosha Reservoir plays a stabilizing role in the hydrodynamic force, promoting the deposition of suspended matter, so that the water in the reservoir is clear. SSC inside the Qingcaosha Reservoir, located in the center of the estuary, is 100–500 mg/L lower than the high SSC water outside the reservoir; (4) The bridges interact with the current, facilitating the transport of local sediment, resulting in the increase in SSC downstream of these bridges, and obvious vortexes appear with the length up to nearly 2400 m; and (5) Corresponding protection and development suggestions were put forward as follows. A linear array of wind power plants can be built near and parallel to dikes and leading jetties; to increase the depth of the southeast end of the reservoir; and the location of the bridge should be selected in the place of river where siltation is easy. This study aimed to study the SSC distribution under the complex impact of coastal zone engineering with satellite and to provide possible improvement suggestions. Full article

In this research paper, the relationship between a crossflow turbine and propeller turbine size changes and the pond size in a free vortex power generation system was investigated. This relationship can be written in the form of a new mathematical equation using the principles of the response surface methodology (RSM) method. This study aimed to compare the efficiency of a crossflow turbine and propeller turbine to enhance a micro power plant from free vortex. The pond size in a micro power plant from free vortex was 1 m in diameter and 0.5 m in height with a 0.2 m outlet drain at the bottom. All turbines were tested at different water flowrates of 0.2, 0.3, 0.4, 0.5, and 0.6 m³/s to identify the rpm, water head, voltage, and electric current to access the waterpower, power output, and overall efficiency. At a 0.02 m³/s water flowrate, the crossflow turbine had greater overall efficiency than the propeller turbine, reaching 9.09% efficiency. From the comparison of the results of the two turbines used in the 0.5 m high cylinder-shaped generator pond, the turbine type, turbine size (height and diameter), number of blades, and water flowrate are key factors that affect the overall efficiency. The crossflow turbine can achieve greater efficiency than the propeller turbine in this generator system. Full article

Cyclone separators are widely used to eliminate particles flowing through pipelines in equipment from various industrial processes. Unlike general filters, cyclone separators can constantly and effectively eliminate foreign substances present in the fluid flowing through the equipment. In this study, we fabricated mini-hydrocyclone separators using the 3D printing method for application in the steam and water analysis system (SWAS) in a thermal power plant instead of the conventional strainer filter. The gravimetric method was used to measure the separation efficiency of the hydrocyclone separators and compare the weights of the sludge discharged from the underflow and overflow outlets. The outlet flow ratio was optimized by adjusting the diameters of the spigot and vortex finder of the separators, which influenced the outlet flow rate. To apply the gravimetric method more objectively, the optimum values of the diameters of the vortex finder and spigot with an outlet flow ratio of 1 were determined using full factorial design (FFD) in the design of experiments (DOE). The obtained values were verified through numerical analysis using the ANSYS Fluent software. Furthermore, after fabrication of the mini-hydrocyclone separators using an SLA-type 3D printer, we conducted a numerical analysis, and the results were compared with that of the actual experiment. It was observed that the use of FFD can effectively optimize the desired outlet flow ratio in the mini-hydrocyclone separator. In addition, the changes in the outlet flow ratio do not affect the separation efficiency of the cyclone separators. Full article

The operation of any hydraulic power plant is accompanied by pressure pulsations that are caused by vortex rope under the runner, rotor–stator interaction and various transitions during changes in operating conditions or start-ups and shut-downs. Water in the conduit undergoes volumetric changes due to these pulsations. Compression and expansion of the water are among the mechanisms by which energy is dissipated in the system, and this corresponds to the second viscosity of water. The better our knowledge of energy dissipation, the greater the possibility of a safer and more economic operation of the hydraulic power plant. This paper focuses on the determination of the second viscosity of water in a conduit. The mathematical apparatus, which is described in the article, is applied to data obtained during commissioning tests in a water storage power plant. The second viscosity is determined using measurements of pressure pulsations in the conduit induced with a ball valve. The result shows a dependency of second viscosity on the frequency of pulsations. Full article

The objective of the present paper is to develop a validated numerical model of a water vortex power plant that serves as a digital twin for further studies such as assessments of the ethohydraulic characteristics or the performance of such devices. The reference for the validation process is a large-scale hydraulic installation equipped with a full-scale water vortex power plant prototype installed in Dresden (Germany), where flow field measurements were carried out using three-dimensional Acoustic Doppler Velocimetry. The numerical model was implemented within the software package Star-CCM+. The unsteady, two-phase flow was solved with the Reynolds-Averaged Navier–Stokes equations in a Eulerian Multiphase approach, deploying a Volume of Fluid method to describe the free-surface flow. Water level and flow velocities were systematically compared in key areas of the device, demonstrating that the simulation is in good agreement with experimental observations. Relative differences are limited to at most 4% regarding water height in the system, and even the much more challenging velocity fields are reproduced with typical relative errors of roughly 10%. This validates the ability of the model to model the challenging flow conditions found in a water vortex power plant, enabling subsequent studies of the characteristics of this power plant concerning fish migration. Full article

The global demand for drinking water is increasing day by day. Different methods are used for desalination of water, which can help in the conservation of resources, such as seawater, highly saline, or treated water underground reservoirs. Polluted water can be treated by the utilization of different advanced techniques. In this study, wastewater mixed canal water has been taken into consideration for the utilization of humans and agriculture use as well. A two-stage conceptual methodology has been proposed to deal with the water conservation and utilization process. In the first phase, power has been produced using a Belgian vortex turbine, which is a safe, efficient, and eco-friendly technology working without disturbing waterways. The power produced by the vortex machine will be utilized to operate the water treatment plant to obtain clean water for utilization in the second phase. Since enough energy is produced, and its availability to the water head level base is a natural resource, this energy can be used to fulfill daily water requirements by maximizing the energy-driven treatment process as per WHO Guidelines. Water quality can be monitored at regular intervals, depending upon the selection and installation of a treatment plant. An increase in efficiency comes from nearly exponential patterns depending on water velocity and availability. This technique will not only help in the production of clean water but will also help in the conservation of groundwater resources and the efficient utilization of wastewater. Full article

In this study, non-powered hydraulic mixing with three layers of baffles and holes was evaluated as an alternative to vertical shaft impellers in a rapid mixing process through both computational fluid dynamics (CFD) modeling and field applications. From the CFD modeling, the turbulence (i.e., vortex rings) caused by excess kinetic energy between the inlet and second-layer baffle ensures rapid mixing of the coagulants throughout the total water flow and overcomes the damping effect of the components in a mixing basin. Although optimal inlet velocity needs to be investigated for sufficient mixing between coagulants and pollutants in raw water with relatively low energy consumption and maintenance costs, non-powered hydraulic mixing developed in this study was proved to create strong turbulence and can be applied in any water treatment plants that involves coagulation-flocculation processes. Based on the comparison of the water quality between two water treatment plants using identical raw water and coagulant operated from 2014 to 2016, no difference in water quality of treated water indicated that non-powered hydraulic mixing can be replaced with vertical shaft impellers, hence, both energy consumption and maintenance costs can be reduced. Further study is warranted to optimize non-powered hydraulic mixing for the tradeoff between mixing efficiency and energy consumption in the water treatment plants. Full article

The self-priming pump as an essential energy conversion equipment is widely used in hydropower and thermal power plants. The energy losses in the internal flow passage of the pump directly affect its work efficiency. Therefore, it is important to improve the internal flow characteristic of the pump. In the present work, a novel self-priming pump which starts without water is proposed; this pump can reduce the energy consumption as well as the time needed to start its operation. The spatial structure of the vortices in the pump is investigated by employing the Q criterion with the numerical solution of the vorticity transport equation. Based on the morphology, the vortices can be separated into three categories: Trailing Edge Vortex (TEV), Leading Edge Vortex (LEV) and Gap Leakage Vortex (GLV). Generally, the morphology of the TEV is more disorderly than that of LEV and GLV, and the intensity of TEV is significantly higher than that of the other two vortices. To determine the magnitude and distribution of energy loss in the pump, entropy production analysis is employed to study the influence of blade thickness on energy characteristics of the pump. It is found that with an increase in the flow rate, the location of energy loss transfers from the trailing edge to the leading edge of the blade, and viscous entropy production (VEP) and turbulence entropy production (TEP) are the dominant factors which influence the energy conversion in the pump. More importantly, employing the blade with a thin leading edge and a thick trailing edge can not only significantly reduce the impact of incoming flow under over-load condition (flow rate higher than the design condition) but can also increase the efficiency of the pump. Thus, an increase in thickness of the blade from the leading edge to the trailing edge is beneficial for improving the pump performance. The results of this paper can be helpful in providing guidelines for reducing the energy loss and in improving the performance of a self-priming pump. Full article

High rates of environmental pollution by boilers and thermal power plants burning coal of different grades are the main reason for active research in the world aimed at the development of alternative fuels. The solution to the formulated problem acceptable in terms of environmental, technical and economic criteria is the creation of composite slurry fuels with the use of fine coal or coal processing and enrichment waste, water of different quality, and oil sludge additive. This study considers modern technologies of burning slurry fuels as well as perspective research methods of the corresponding processes. A model combustion chamber is developed for the adequate study of ignition processes. The calculation of the basic geometric dimensions is presented. The necessity of manufacturing the combustion chamber in the form of an object of complex geometry is substantiated. With its use, several typical modes of slurry fuel ignition are determined. Principal differences of ignition conditions of a single droplet and group of fuel droplets are shown. Typical vortex structures at the fuel spray injection are shown. A comparison with the trajectories of fuel aerosol droplets in real combustion chambers used for the combustion of slurry fuels is undertaken. Full article
