The advancement of Internet of Things (IoT) technology has enabled battery-powered devices to be deployed across a wide range of applications; however, it also introduces challenges such as high energy consumption and security vulnerabilities. To address these issues, adiabatic logic circuits offer a promising solution for achieving energy efficiency and enhancing the security of IoT devices. Adiabatic logic circuits are well suited for energy harvesting systems, especially in applications such as sensor nodes, RFID tags, and other IoT implementations. In these systems, the harvested bipolar sinusoidal RF power is directly used as the power supply for the adiabatic logic circuit. However, adiabatic circuits require a peak detector to provide bulk biasing for pMOS transistors. To meet this requirement, a diode-connected MOS transistor-based voltage doubler circuit is used to convert the sinusoidal input into a usable DC signal. In this paper, we propose a novel adiabatic logic design that maintains low power consumption while optimizing energy and current fluctuations across various input transitions. By ensuring uniform and complementary current flow in each transition within the logic circuit’s functional blocks, the design reduces energy variation and enhances resistance against power analysis attacks. Evaluation under different clock frequencies and load capacitances demonstrates that the proposed adiabatic logic circuit exhibits lower fluctuation and improved security, particularly at load capacitances of 50 fF and 100 fF. The results show that the proposed circuit achieves lower power dissipation compared to conventional designs. As an application example, we implemented an ultrasonic transmitter circuit within a LoRaWAN network at the end-node sensor level, which serves as both a communication protocol and system architecture for long-range communication systems. Full article

This paper introduces a high-efficiency buck converter designed for a wide load range, targeting low-power applications in medical devices, smart homes, wearables, IoT, and technology utilizing WiFi and Bluetooth. To achieve high efficiency across varying loads, the proposed converter employs a low-power adaptive on-time (AOT) controller that ensures output voltage stability and seamless mode transitions. An adaptive comparator (ACP) with variable output impedance is introduced, offering a variable DC gain and bandwidth to be suitable for different load conditions. A negative-level shifter (NLS) circuit, with its swing ranging from −0.5 V to the battery voltage (V_BAT), is proposed to control the smaller power p-MOS transistors. By using an NLS, the chip area, which is mostly occupied by power CMOS transistors, is reduced while the power efficiency is improved, particularly under a heavy load. A status time detector (STD) block which provides control signals to the ACP and NLS for optimized power consumption is added to identify load conditions (heavy, light, ultra-light). By employing a 180 nm CMOS technology, the active chip area occupies about 0.31 mm². With an input voltage range of 2.8–3.3 V, the controller’s current consumption ranges from 1.2 μA to 16 μA, corresponding to the output load current varying from 12 μA to 120 mA. Although the output load can vary, the output voltage is regulated at 1.2 V with a ripple between 3 and 12 mV. The proposed design achieves a peak efficiency of 96.2% under a heavy load with a switching frequency of 1.3 MHz. Full article

Using the Bridgman technique, GaSe single crystals were obtained which were mechanically split into plane-parallel plates with a wide range of thicknesses. By heat treatment in air at 820 °C and 900 °C, for 30 min and 6 h, micro- and nanocomposite layers of Ga₂Se₃–Ga₂O₃ and β–Ga₂O₃ (native oxide) with surfaces made of nanowires/nanoribbons were obtained. The obtained composite Ga₂Se₃–Ga₂O₃ and nanostructured β–Ga₂O₃ are semiconductor materials with band gaps of 2.21 eV and 4.60 eV (gallium oxide) and photosensitivity bands in the green–red and ultraviolet-C regions that peaked at 590 nm and 262 nm. For an applied voltage of 50 V, the dark current in the photodetector based on the nanostructured β–Ga₂O₃ layer was of 8.0 × 10⁻¹³ A and increased to 9.5 × 10⁻⁸ A upon 200 s excitation with 254 nm-wavelength radiation with a power density of 15 mW/cm². The increase and decrease in the photocurrent are described by an exponential function with time constants of τ_1r = 0.92 s, τ_2r = 14.0 s, τ_1d = 2.18 s, τ_2d = 24 s, τ_1r = 0.88 s, τ_2r = 12.2 s, τ_1d = 1.69 s, and τ_2d = 16.3 s, respectively, for the photodetector based on the Ga₂Se₃–Ga₂S₃–GaSe composite. Photoresistors based on the obtained Ga₂Se₃–Ga₂O₃ composite and nanostructured β–Ga₂O₃ layers show photosensitivity bands in the spectral range of electronic absorption bands of ozone in the same green–red and ultraviolet-C regions, and can serve as ozone sensors (detectors). Full article

Exploring tazarotene, a third-generation retinoid for potential hand osteoarthritis treatment, this study presents the development and validation of an ultra-performance liquid chromatography with quadrupole detector mass spectrometry (UPLC-QDa) method for the simultaneous quantification of tazarotene and tazarotenic acid, its active metabolite, in porcine skin. Method development involved a design-of-experiments approach for chromatographic optimization of gradient steepness, organic solvent volume, column temperature, capillary voltage, flow rate, and cone voltage. Central composite orthogonal design was used to optimize peak area, peak width, retention time, and resolution. Validation was performed in accordance with U.S. Food and Drug Administration guidelines. The method was linear over the concentration range of 0.4–18,750 ng/mL for tazarotene and 13.3–12,500 ng/mL for tazarotenic acid, with r² values of ≥0.99. Chromatographic analysis demonstrated acceptable accuracy and precision (<15%), and stability tests confirmed the analytes’ stability under various conditions. This validated method offers a reliable and accurate approach for the simultaneous analysis of tazarotene and tazarotenic acid, facilitating further research into their therapeutic applications for hand osteoarthritis. Full article

To meet the application requirements of neutron detectors, a novel large-area microchannel plate photomultiplier tube with a gate function (G-MCP-PMT) was developed in this study. A kind of regular hexagonal mesh electrode as the gated electrode was designed to achieve excellent gating functions for target pulse signals. The photoelectron transmittances for different mesh electrode sizes and voltages were studied via numerical simulations. To increase the effective detection area of the photocathode, an electrostatic-focusing electrode was designed in the G-MCP-PMT. By optimizing the structure of the focusing electrode, an effective photocathode detection surface diameter of 80 mm was achieved based on commercially available MCPs with a diameter of 56 mm. By adjusting the channel diameter configurations of the dual MCPs, the output pulse peak and time response of the large-area G-MCP-PMT can be flexibly adjusted. The experimental results indicate that when the large-area G-MCP-PMT is operated at −2700 V, the gate establishment time is approximately 50 ns. The extinction ratio of the large-area G-MCP-PMT is higher than 3000:1, and the maximum linear output current is greater than 300 mA at 250 ns FWHM, meeting application needs in various fields such as white neutron detection and laser radar. Full article

The silicon carbide (SiC) Schottky diode (SBD) detector in a SiC hybrid photomultiplier tube (HPMT) generates signals by receiving photocathode electrons with an energy of 10 keV. So, the performance of the SiC SBD under electron irradiation with an energy of 10 keV has an important significance for the application of the SiC-HPMT. However, studies on 10 keV radiation effects on the SiC SBDs were rarely reported. In this paper, the performance degradation of the SiC SBDs irradiated by 10 keV electrons at different fluences was investigated. After the irradiation, the forward current of the SiC SBDs increased, and the turn-on voltage decreased with the irradiation fluences until 1.6 × 10¹⁶ cm⁻². According to the capacitance–voltage (C-V) curves, the effective doping concentration increased slightly after the irradiation, and an obvious discrepancy of C-V curves occurred below 5 V. Moreover, as a radiation detector, the peak position of the α-particles’ amplitude spectrum changed slightly, and the energy resolution was also slightly reduced after the irradiation due to the high collection charge efficiency (CCE) still being larger than 99.5%. In addition, the time response of the SiC SBD to the 50 ns pulsed X-ray was almost not affected by the irradiation. The results indicated that the performance degradation of the SiC SBD irradiated at the fluence of 1.5 × 10¹⁷ cm⁻² would not result in a deterioration of the properties of the SiC-HPMT and showed an important significance for the supplement of the radiation resistance of the SiC SBD radiation detector. Full article

We report a novel dual-band barrier infrared detector (DBIRD) design using InAs/GaSb type-II superlattices (T2SLs). The DBIRD structure consists of back-to-back barrier diodes: a “blue channel” (BC) diode which has an nBp architecture, an n-type layer of a larger bandgap for absorbing the blue band infrared/barrier/p-type layer, and a “red channel” (RC) diode which has a pBn architecture, a p-type layer of a smaller bandgap for absorbing the red band infrared/barrier/n-type layer. Each has a unipolar barrier using a T2SL lattice matched to a GaSb substrate to impede the flow of majority carriers from the absorbing layer. Each channel in the DBIRD can be independently accessed with a low bias voltage as is preferable for high-speed thermal imaging. The device modeling of DBIRDs and simulation results of the current–voltage characteristics under dark and illuminated conditions are also presented. They predict that the dual-band operation of the DBIRD will produce low dark currents and 45–56% quantum efficiencies for the in-band photons in the BC with ${\lambda }_c$ = 5.58 μm, and a nearly constant 32% in the RC with ${\lambda }_c$ = 8.05 μm. The spectral quantum efficiency of the BC for 500 K blackbody radiation is approximately 50% over the range of $\lambda$ = 3–4.7 μm, while that of the RC has a peak of 42% at 5.9 μm. The DBIRD may provide improved high-speed dual-band imaging in comparison with NBn dual-band detectors. Full article

This paper presents a low-power, energy-efficient, 12-bit incremental zoom analog-to-digital converter (ADC) for multi-channel bio-signal acquisitions. The ADC consists of a 7-stage ring voltage-controlled oscillator (VCO)-based incremental ΔΣ modulator (I-ΔΣM) and an 8-bit successive approximation register (SAR) ADC. The proposed VCO-based I-ΔΣM can provide fast phase-alignment of the ring-VCO to reduce the interval settling time; thereby, the I-ΔΣM can accommodate time-division-multiplexed input signals without phase leakage between consecutive measurements. The SAR ADC also adopts splitting unit capacitors that can support V_CM-free tri-level switching and prevent invalid states from the phase frequency detector with minimal logic gates and switches. The proposed ADC has been fabricated in a standard 180 nm standard 1P6M CMOS process, exhibiting a 67-dB peak signal-to-noise ratio, a 74-dB dynamic range, and a Walden figure of merit of 19.12 fJ/c-s, while consuming a power of 3.51 μW with a sampling rate of 100 kS/s. Full article

This paper presents a response time/time constant of III-V material-based interband long wavelength multistage infrared detector optimized for a wavelength of 10.6 µm at 200 K. The device is based on the InAs/InAsSb type-II superlattice with highly doped p⁺/n⁺ tunneling junctions among the stages. The detector exhibits a response time of 9.87 ns under zero voltage condition, while for 0.15 V reverse bias, that time decreases to approximately 350 ps. The presented device shows a significant increase in response time, especially for low bias, and for a voltage of −0.2 V, the decrease in the detector’s response time by an order of magnitude was estimated. Higher voltage slightly affects the time constant, and between −0.3 V and −1 V, it varies between 300 and 400 ps. The significant change in the detector’s response time between −0.1 V and −0.2 V probably results from electric field drop over entire absorber region. The optimal operating condition can be reached for −0.15 V, where the time constant reaches approximately 350 ns with peak detectivity at a level of ~3 × 10⁹ Jones. Full article

A sensitive non-contact sensing system based on the CoFeNiSiB amorphous ribbon giant magnetoimpedance (GMI) effect is proposed for current testing. The sensing system consists of a GMI probe, a sinusoidal current generator, a voltage follower, a preamplifier, a low-pass filter, and a peak detector. Four different GMI probes derived from amorphous ribbon meanders are designed and fabricated through MEMS processes. GMI probes were driven by a 10 MHz, 5 mA AC current. A permanent magnet was used to provide a bias magnetic field for the probe. The effect of the bias magnetic field on the output DC voltage was investigated. This non-contact current sensing system exhibits good sensitivity and linearity at a bias magnetic field H_bias = 15 Oe. The sensitivity can reach up to 24.2 mV/A in the ±1.5 A range. Full article

The effects of optical sampling pulse power, RF power, and electronic back-end bandwidth on the performance of time- and wavelength-interleaved photonic analog-to-digital converter (PADC) with eight-channel 41.6 GHz pulses have been experimentally investigated in detail. The effective number of bits (ENOB) and peak-to-peak voltage (V_pp) of converted 10.6 GHz electrical signals were used to characterize the effects. For the 1550.116 nm channel with 5.2 G samples per second, an average pulse power of 0 to −10 dBm input to the photoelectric detector (PD) has been tested. The V_pp increased with increasing pulse power. And the ENOB for pulse power −9~−3 dBm was almost the same and all were greater than four. Meanwhile, the ENOB decreased either when the pulse power was more than −2 dBm due to the saturation of PD or when the pulse power was less than −10 dBm due to the non-ignorable noise relative to the converted weak signal. In addition, RF powers of −10~15 dBm were loaded into the Mach–Zehnder modulator (MZM). The V_pp increased with the increase in RF power, and the ENOB also showed an increasing trend. However, higher RF power can saturate the PD and induce greater nonlinearity in MZM, leading to a decrease in ENOB, while lower RF power will convert weak electrical signals with more noise, also resulting in lower ENOB. In addition, the back-end bandwidths of 0.2~8 GHz were studied in the experiments. The V_pp decreased as the back-end bandwidth decreased from 8 to 3 GHz, and remained nearly constant for the bandwidth between the Nyquist bandwidth and the subsampled RF signal frequency. The ENOB was almost the same and all greater than four for a bandwidth from 3 to 8 GHz, and gradually increased up to 6.5 as the back-end bandwidth decreased from the Nyquist bandwidth to 0.25 GHz. A bandwidth slightly larger than the Nyquist bandwidth was recommended for low costs and without compromising performance. In our experiment, the −3 to −5 dBm average pulse power, about 10 dBm RF power, and 3 GHz back-end bandwidth were recommended to accomplish both a high ENOB more than four and large V_pp. Our research provides a solution for selecting optical sampling pulse power, RF power, and electronic back-end bandwidth to achieve low-cost and high-performance PADC. Full article

Bi₂Sr₂Co₂O_y thin films were grown on 10° vicinal-cut Al₂O₃ (0001) single crystalline substrates by pulsed laser-deposition techniques with in situ annealing, post-annealing and non-annealing process, respectively. The pure phase Bi₂Sr₂Co₂O_y thin film was obtained with a non-annealing process. The result of X-ray diffraction showed that Bi₂Sr₂Co₂O_y thin film was obviously c-axis preferred orientation. The laser-induced thermoelectric voltage signals were detected in Bi₂Sr₂Co₂O_y thin films, which originated from the anisotropy of the Seebeck coefficient. The maximum peak value of laser-induced thermoelectric voltage was strong and could reach as large as 0.44 V and the response time was 1.07 μs when the deposition time was 6 min. Furthermore, the peak voltage enhanced linearly with the single-pulse laser energy. These characteristics demonstrate that Bi₂Sr₂Co₂O_y thin film is also an excellent choice for laser energy/power detectors. Full article

A novel Epitaxial Cadmium Selenide (CdSe) on Lead Selenide (PbSe) type-II heterojunction photovoltaic detector has been demonstrated by Molecular Beam Epitaxy (MBE) growth of n-type CdSe on p-type PbSe single crystalline film. The use of Reflection High-Energy Electron Diffraction (RHEED) during the nucleation and growth of CdSe indicates high-quality single-phase cubic CdSe. This is a first-time demonstration of single crystalline and single phase CdSe growth on single crystalline PbSe, to the best of our knowledge. The current–voltage characteristic indicates a p–n junction diode with a rectifying factor over 50 at room temperature. The detector structure is characterized by radiometric measurement. A 30 μm × 30 μm pixel achieved a peak responsivity of 0.06 A/W and a specific detectivity (D*) of 6.5 × 10⁸ Jones under a zero bias photovoltaic operation. With decreasing temperature, the optical signal increased by almost an order of magnitude as it approached 230 K (with thermoelectric cooling) while maintaining a similar level of noise, achieving a responsivity of 0.441 A/W and a D* of 4.4 × 10⁹ Jones at 230 K. Full article

Radiation detectors based on Cadmium Zinc Telluride (CZT) compounds are becoming popular solutions thanks to their high detection efficiency, room temperature operation, and to their reliability in compact detection systems for medical, astrophysical, or industrial applications. However, despite a huge effort to improve the technological process, CZT detectors’ full potential has not been completely exploited when both high spatial and energy resolution are required by the application, especially at low energies (<10 keV), limiting their application in energy-resolved photon counting (ERPC) systems. This gap can also be attributed to the lack of dedicated front-end electronics which can bring out the best in terms of detector spectroscopic performances. In this work, we present the latest results achieved in terms of energy resolution using SIRIO, a fast low-noise charge sensitive amplifier, and a linear-array pixel detector, based on boron oxide encapsulated vertical Bridgman-grown B-VB CZT crystals. The detector features a 0.25-mm pitch, a 1-mm thickness and is operated at a −700-V bias voltage. An equivalent noise charge of 39.2 el. r.m.s. (corresponding to 412 eV FWHM) was measured on the test pulser at 32 ns peaking time, leading to a raw resolution of 1.3% (782 eV FWHM) on the 59 keV line at room temperature (+20 °C) using an uncollimated ²⁴¹Am, largely improving the current state of the art for CZT-based detection systems at such short peaking times, and achieving an optimum resolution of 0.97% (576 eV FWHM) at 1 µs peaking time. The measured energy resolution at the 122 keV line and with 1 µs peaking time of a ⁵⁷Co raw uncollimated spectrum is 0.96% (1.17 keV). These activities are in the framework of an Italian collaboration on the development of energy-resolved X-ray scanners for material recycling, medical applications, and non-destructive testing in the food industry. Full article

This paper presents a single-inductor boost converter for thermoelectric energy harvesting. A two-stages startup circuit with a three-phase operation is adopted to obtain self-startup with a single inductor. To extract the maximum energy, a coarse- and fine-tuning MPPT is proposed to adaptively and effectively track the internal source resistance. By designing a zero-current detector, the synchronization loss is reduced, which significantly improves the peak efficiency. The boost converter is implemented in a 0.18-μm standard CMOS process. Simulation results show that the converter self-starts the operation from a TEG voltage of 128 mV and achieves 88% peak efficiency, providing a maximum output power of 3.78 mW. The improved MPPT enables the converter to sustain the operation at an input voltage as low as 7.5 mV after self-startup. Full article
