This research presents a novel methodology based on data analysis for improving voltage stability in transmission systems. The proposal aims to determine a single distributed generator’s optimal location and sizing using the Fast Voltage Stability Index (FVSI) as the primary metric under $N-1$ contingency conditions. The developed strategy systematically identifies the most critical transmission lines close to instability through a frequency analysis of the FVSI in the base case and across multiple contingency scenarios. Subsequently, the weak buses associated with the most critical line are determined, on which critical load increases are simulated. The Distributed Generator (DG) sizing and location parameters are then optimized through a statistical analysis of the inflection point and the rate of change of the FVSI statistical parameters. The methodology is validated in three case studies: IEEE systems with 14, 30, and 118 buses, demonstrating its scalability and effectiveness. The results show significant reductions in FVSI values and notable improvements in voltage profiles under stress and contingency conditions. For example, in the 30-bus IEEE system, the average FVSI for all contingency scenarios was reduced by 26% after applying the optimal solution. At the same time, the voltage profiles even exceeded those of the base case. This strategy represents a significant contribution, as it is capable of improving the stability of the electrical power system in all $N-1$ contingency scenarios with overload at critical nodes. Using a single DG as a low-cost and highly effective corrective measure, the proposed approach outperforms conventional solutions through statistical analysis and a data-centric approach. Full article

The integration of intermittent Distributed Generations (DGs) like solar photovoltaics into Radial Distribution Systems (RDSs) reduces system losses but causes voltage and power instability issues. It has also been observed that seasonal variations affect the performance of such DGs. These issues can be resolved by placing optimum-sized Battery Energy Storage (BES) Systems into RDSs. This work proposes a new approach to the placement of optimally sized BESSs considering multiple objectives, Active Power Losses, the Power Stability Index, and the Voltage Stability Index, which are prioritized using the Weighted Sum Method. The proposed multi-objectives are investigated using the probabilistic and Polynomial Multiple Regression (PMR) approaches to account for the randomness in solar irradiance and its effect on BESS sizing and placements. To analyze system behavior, simultaneous and sequential strategies considering aggregated and distributed BESS placement are executed on IEEE 33-bus and 94-bus Portuguese RDSs by applying the Improved Grey Wolf Optimization and TOPSIS techniques. Significant loss reduction is observed in distributed BESS placement compared to aggregated BESSs. Also, the sequentially distributed BESS stabilized the RDS to a greater extent than the simultaneously distributed BESS. In view of the uncertainty, the probabilistic and PMR approaches require a larger optimal BESS size than the deterministic approach, representing practical systems. Additionally, the results are validated using Improved Particle Swarm Optimization–TOPSIS techniques. Full article

In practical engineering, it has been observed that increasing local generators’ capacity in receiving-end power grids can lead the system to transition from voltage instability to power angle instability after a fault. This contradicts the typical engineering experience, where increasing the generators’ capacity at the receiving end is expected to enhance voltage stability, making it challenging to define an appropriate pre-control range for generators. This paper aims to quantify the impact of local generators on the stability of AC/DC receiving-end power grids. First, the paper describes the instability phenomena observed under different generators’ capacity conditions in actual AC/DC receiving-end power grids. Next, by using a simplified single-machine-load-infinite-bus model, the paper explores how the system’s instability characteristics evolve from being dominated by load instability to being driven by generator instability as the ratio of local generators to load varies. This study conducts an in-depth analysis of the coupling mechanism between power angle stability and voltage stability. For the first time, it quantitatively characterizes the stable operating region of the system using power angle and induction motor slip as dual constraint conditions, providing a new theoretical framework for power system stability analysis. Additionally, addressing the lack of quantitative research on the upper limit of generator operation in current systems, this study constructs post-fault power recovery curves for loads and DC power sources. Based on the equal-area criterion, it proposes a quantitative index for the upper limit of local generator operation, filling a research gap in this field and providing a crucial theoretical basis and reference for practical power system operation and dispatch. Full article

The integration of large-scale renewable energy and power electronic devices into the grid, as well as the uneven distribution of power units and loads, further increases the risk of transient instability at critical load centers. The installation of synchronous condensers (SCs) in the grid can enhance its transient stability. Therefore, it is necessary to focus on the siting and sizing of SCs, considering both economic and safety factors. To address this issue, this paper proposes a configuration method based on full electromagnetic transient (EMT) simulation. Initially, relevant indicators for measuring transient voltage stability are defined. Subsequently, the most severe fault scenario was identified through EMT simulation, and the reactive power voltage sensitivity index was generated. Finally, an optimization configuration model is established with the objective of minimizing installation costs and the constraint of ensuring transient voltage stability, and the model is solved using an iterative linear optimization algorithm. The proposed method is applied in a case study of the power grid platform in S Province, and simulation results indicate that it effectively improves transient voltage stability within heavily loaded regions, demonstrating its economic and practical effectiveness. Full article

In order to evaluate the short-term voltage stability of an electrical power grid, it is necessary to employ not only systematic and well-targeted fault simulations, but also an evaluation method that assesses the criticality of the individual scenarios. A binary decision between stable or unstable, or whether a threshold value is exceeded or not, is inadequate, particularly in instances where the modeling of the system is subject to a certain degree of uncertainty. Since systematic deviations are subject to natural principles and an intervention limit can thus be determined deterministically, an evaluation method is therefore required that allows a statement to be made about the proximity to instability or to a threshold value. It is common practice to employ indices for the evaluation of voltage recovery following a fault event in simulations or from real measurements. However, depending on the specific question being analyzed, the requirements for an index may vary. A review of the literature revealed the existence of several indices that have been developed and applied in the context of various problems and analyses. These indices have been shown to be effective in the respective contexts. However, none of them fully satisfy the requisite criteria for addressing the aforementioned issue. This paper presents and discusses a new index that was developed explicitly for the problem at hand in dealing with model uncertainties, derived requirements from it, and compared it with existing indices from the literature. The benefits of this novel index in comparison with the established ones were visualized based on a number of indicative simulations. Subsequently, the uncertainties inherent in the load parameterization and their implications on the voltage recovery were presented via Monte Carlo simulations. The evaluations of these effects in terms of the distance from the permissible threshold value were then analyzed using the various indices. All simulations were executed within the framework of the IEEE 39 bus New England system. Full article

In a multi-fed DC environment, the UHV DC recipient grid faces significant challenges related to DC phase shift failure and voltage instability due to the high AC/DC coupling strength and low system inertia level. While the new large-capacity synchronous condensers (SCs) can provide effective transient reactive power support, the associated investment and operation costs are high. Therefore, it is valuable to investigate the optimization of SC configuration at key nodes in the recipient grid in a scientific and rational manner. This study begins by qualitatively and quantitatively analyzing the dynamic characteristics of DC reactive power and induction motors under AC faults. The sub-transient and transient reactive power output model is established to describe the SC output characteristics, elucidating the coupling relationship between the SC’s reactive power output and the DC reactive power demand at different time scales. Subsequently, a critical stabilized voltage index for dynamic loads is defined, and the SC’s reactive power compensation target is quantitatively calculated across different time scales, revealing the impact of transient changes in DC reactive power on the transient voltage stability of the multi-fed DC environment with dynamic load integration. Finally, an optimal configuration model for the large-capacity SC is proposed under the critical stability constraint of dynamic loads to maximize the SC’s reactive power support capability at the lowest economic cost. The proposed model is validated in a multi-fed DC area, demonstrating that the optimal configuration scheme effectively addresses issues related to DC phase shift failures and voltage instability resulting from AC bus voltage drops. Full article

Intelligent voltage stability monitoring remains an essential feature of modern research into secure operations of power system networks. This research developed an adaptive neuro-fuzzy expert system (ANFIS)-based predictive model to validate the viability of two contemporary voltage stability indices (VSIs) for intelligent voltage stability monitoring, especially at intricate loading and operation points close to voltage collapse. The Novel Line Stability Index (NLSI) and Critical Boundary Index are VSIs deployed extensively for steady-state voltage stability analysis, and thus, they are selected for the predictive model implementation. Six essential power system operational parameters with data values calculated at varying real and reactive loading levels are input features for ANFIS model implementation. The model’s performance is evaluated using reliable statistical error performance analysis in percentages ($MAPE$ and $RRMS{E}_p$) and regression analysis based on Pearson’s correlation coefficient (R). The IEEE 14-bus and IEEE 118-bus test systems were used to evaluate the prediction model over various network sizes and complexities and at varying clustering radii. The percentage error analysis reveals that the ANFIS predictive model performed well with both VSIs, with CBI performing comparatively better based on the comparative values of $MAPE$, $RRMS{E}_p$, and R at multiple simulation runs and clustering radii. Remarkably, CBI showed credible potential as a reliable voltage stability indicator that can be adopted for real-time monitoring, particularly at loading levels near the point of voltage instability. Full article

Distributed photovoltaic (PV) output exhibits strong stochasticity and weak adjustability. After being integrated with the network, its interaction with stochastic loads increases the difficulty of assessing the distribution network’s static voltage stability (SVS). In response to this issue, this article presents a probabilistic assessment method for SVS in a distribution network with distributed PV that considers the bilateral uncertainties and correlations on the source and load sides. The probabilistic models for the uncertain variables are established, with the correlation between stochastic variables described using the Copula function. The three-point estimate method (3PEM) based on the Nataf transformation is used to generate correlated samples. Continuous power flow (CPF) calculations are then performed on these samples to obtain the system’s critical voltage stability state. The distribution curves of critical voltage and load margin index (LMI) are fitted using Cornish-Fisher series. Finally, the utility function is introduced to establish the degree of risk of voltage instability under different scenarios, and the SVS assessment of the distribution network is completed. The IEEE 33-node distribution system is utilized to test the method presented, and the results across various scenarios highlight the method’s effectiveness. Full article

This paper proposes a novel methodology to improve stability in a transmission system under critical conditions of operation when additional loads that take the system to the verge of stability are placed in weak bus bars according to the fast voltage stability index (FVSI). This paper employs the Newton–Raphson method to calculate power flows accurately and, based on that information, correctly calculate the FVSI for every transmission line. First, the weakest transmission line is identified by considering $N-1$ contingencies for the disconnection of transmission lines, and then all weak nodes associated with this transmission line are identified. Following this, critical scenarios generated by stochastically placed loads that will take the system to the verge of instability will be placed on the identified weak nodes. Then, the methodology will optimally size and place a single static VAR compensator SVC in the system to take the transmission system to the conditions before the additional loads are connected. Finally, the methodology will be validated by testing the system for critical contingencies when any transmission line associated with the weak nodes is disconnected. As a result, this paper’s methodology found a single SVC that will improve the system’s stability and voltage profiles to similar values when the additional loads are not connected and even before contingencies occur. The methodology is validated on three transmission systems: IEEE 14, 30, and 118 bus bars. Full article

In order to solve the risk of transient voltage instability caused by the increasing proportion of new energy represented by photovoltaic (PV) and dynamic load in the power grid, a dynamic reactive power compensation device configuration method with high-permeability PV is proposed considering transient voltage stability. Firstly, a typical reactive power compensation device configuration is constructed, and evaluation indexes based on transient voltage disturbance and transient voltage peak are proposed. The static index based on complex network characteristics and the dynamic index based on sensitivity theory are used to guide the candidate nodes of dynamic reactive power compensation. Secondly, when reactive power capacity is configured, a differentiated dynamic reactive power compensation optimization model is established, and the multi-objective marine predator algorithm is used to solve the configured capacity, aiming to improve the transient voltage stability at the lowest reactive power investment cost. The final configuration scheme is selected by using the improved entropy weight ideal solution sorting method. Finally, the simulation results of the improved IEEE39-node system verify the effectiveness of the proposed method. Full article

Voltage instability is a serious condition that can occur in a power system. An imbalance in reactive power, inadequate utilization of voltage control devices, loss of a component or an abrupt rise in load demand can cause this entire disturbance which leads a system to blackout, either partial or complete. In order to avoid the condition of voltage collapse, we need to predict the state of buses in the system so that we can prevent the occurrence of major outages. This research puts forward two methods for voltage collapse prediction. The first one is to compute a new line stability index (NLSI_1) through an artificial neural network, and the other one is to present a normalized power change index (NPCI) for the prediction. These indices are applied and examined on the IEEE-14 bus system; they check the state of the buses and tell us about the stability of the system. A detailed methodology and explanation are given in the following sections. According to the neural network outcomes, the normalized power change index (NPCI) proves to be more accurate than NLSI_1 for the test system. Full article

The influence of photovoltaic (PV) output with stochasticity and uncertainty on the grid-connected system’s voltage stability is worth further exploration. The long-term voltage stability of a 3-bus system with a large-scale PV power station considering the adjustment of an on-load tap changer (OLTC) was studied. In this typical system, two supercritical Hopf bifurcation (SHB) points are found using the bifurcation calculation. At the SHB point that appears first, a small sudden increase in reactive load power or a sudden increase in PV active power P_pv can eventually cause a voltage collapse after a long increasing oscillation. The long-term collapse phenomenon shows that SHB cannot be ignored in the PV grid-connected system. Meanwhile, the time constant of OLTC can affect the progress of long-term voltage collapse, but it has different effects under different disturbances. When P_pv drops suddenly at the SHB point, due to the adjustment of OLTC, the load bus voltage can recover to near the target value of OLTC after a long period of time. Similarly, the time constant of OLTC can affect the progress of long-term voltage recovery. To prevent the long-term voltage collapse when P_pv increases suddenly at the SHB point, a new locking-OLTC index I_lock, depending on the value of P_pv corresponding to the SHB point, and a locking OLTC method are proposed, and the voltage can be recovered to an acceptable stable value quickly. Compared with the system without OLTC, OLTC adjustment can effectively prevent long-term voltage oscillation instability and collapse, so that PV power can play a bigger role in power systems. Full article

Identifying the weak buses in power system networks is crucial for planning and operation since most generators operate close to their operating limits, resulting in generator failures. This work aims to identify the critical/weak node and reduce the system’s power loss. The line stability index ($L_{mn}$) and fast voltage stability index (FVSI) were used to identify the critical node and lines close to instability in the power system networks. Enhanced particle swarm optimization (EPSO) was chosen because of its ability to communicate with better individuals, making it more efficient to obtain a prominent solution. EPSO and other PSO variants minimized the system’s actual/real losses. Nodes 8 and 14 were identified as the critical nodes of the IEEE 9 and 14 bus systems, respectively. The power loss of the IEEE 9 bus system was reduced from 9.842 MW to 7.543 MW, and for the IEEE 14 bus system, the loss was reduced from 13.775 MW of the base case to 12.253 MW for EPSO. EPSO gives a better active power loss reduction and improves the node’s voltage profile than other PSO variants and algorithms in the literature. This suggests the feasibility and suitability of EPSO to improve the grid voltage quality. Full article

An electrical power system (EPS) is subject to unexpected events that might cause the outage of elements such as transformers, generators, and transmission lines. For this reason, the EPS should be able to withstand the failure of one of these elements without changing its operational characteristics; this operativity functionality is called $N-1$ contingency. This paper proposes a methodology for the optimal location and sizing of a parallel static Var compensator (SVC) in an EPS to reestablish the stability conditions of the system before $N-1$ contingencies take place. The system’s stability is analyzed using the fast voltage stability index (FVSI) criterion, and the optimal SVC is determined by also considering the lowest possible cost. This research considers $N-1$ contingencies involving the disconnection of transmission lines. Then, the methodology analyzes every scenario in which a transmission line is disconnected. For every one of them, the algorithm finds the weakest transmission line by comparing FVSI values (the higher the FVSI, the closer the transmission line is to instability); afterward, when the weakest line is selected, by brute force, an SVC with values of 5 Mvar to 100 Mvars in steps of 5 Mvar is applied to the sending bus bar of this transmission line. Then, the SVC value capable of reestablishing each line’s FVSI to its pre-contingency value while also reestablishing each bus-bar’s voltage profile and having the lowest cost is selected as the optimal solution. The proposed methodology was tested on IEEE 14, 30, and 118 bus bars as case studies and was capable of reestablishing the FVSI in each contingency to its value prior to the outage, which indicates that the algorithm performs with 100% accuracy. Additionally, voltage profiles were also reestablished to their pre-contingency values, and in some cases, they were even higher than the original values. Finally, these results were achieved with a single solution for a unique SVC located in one bus bar that is capable of reestablishing operational conditions under all possible contingency scenarios. Full article

In this paper, the robust stabilization for the networked microgrid system is presented. A microgrid implements master-slave control architecture where the communication channel is utilized to exchange the reference current signals. With this structure, a time delay exists in the reference control signal which may lead to instability. The analysis of the control strategy is carried out in dq reference frame. The microgrid is constituted by PV and wind energy sources supplying a load through voltage source inverters. The stochastic nature of renewable energy sources introduces uncertainties which can be represented as fluctuations in the voltage and the current. The main contribution of the paper is formulating the controller design of the microgrid with communication delay and uncertainties in the model as H∞ control problem and Lyapunov–Krasovskii functional is utilized to develop stability criterion in bilinear matrix inequality form. Grey wolf optimizer is used to minimize the performance index and derive the stabilizing controller. The microgrid performance is tested through simulation using the time-varying nonlinear model of the microgrid. The results prove that satisfactory current and power-sharing are attained even with the existence of time delays and uncertainties. Full article
