Search Results (372)

This study presents the design, implementation, and experimental validation of an integrated fastening monitoring platform for vehicle ground equipment, aimed at supporting structural maintenance and operational safety. Rather than introducing a fundamentally new sensing principle, the work focuses on the system-level integration and verification of existing sensing, communication, and control technologies for reliable bolt loosening detection and torque-controlled pneumatic fastening. The proposed platform consists of a Smart Control Gateway (SCG), a Signal Transducer Socket (STS), and a Smart Washer Set (SWS), incorporating smart nuts and clamping-force sensing washers for M50 and M35 bolts. Sub-GHz wireless RF communication and wired RS-485 transmission are employed to provide scalable and robust connectivity among system components. The SCG hardware and firmware are fully implemented and verified, enabling continuous acquisition and transmission of fastening-state data. Experimental evaluations include functional verification, mechanical integration tests, and durability assessments. The smart washers demonstrate stable sensing performance over 100 assembly and disassembly cycles without observable degradation. The STS is validated through 200,000 impact cycles under intermittent loading conditions (3 s impact, 3 s pause), confirming its suitability for repeated industrial operation. Real-time data transmission tests verify the system’s capability to detect bolt loosening events induced by vibration or external interference. The results indicate that the proposed platform provides a practical and reliable solution for fastening-state monitoring in safety-relevant ground equipment. This work contributes validated engineering evidence for deploying integrated smart fastening systems in industrial maintenance applications and establishes a foundation for future studies on environmental robustness, false-alarm characterization, and real-time performance guarantees. Full article

To address the issue of low efficiency in recovering low-frequency vibration energy during vehicle operation, this paper proposes a piezoelectric energy capture harvester based on wheel vibration. The device employs a parallel configuration of dual cantilever beam piezoelectric transducers in its mechanical structure, with additional mass blocks to optimize its resonant characteristics in the low-frequency range. A synchronous switch energy harvesting circuit was designed. By actively synchronizing the switch with the peak output voltage of the piezoelectric element, it effectively circumvents the turn-on voltage threshold limitations of diodes in bridge rectifier circuits, thereby enhancing energy conversion efficiency. A dynamic model of this device was established, and multiphysics simulation analysis was conducted using COMSOL-Multiphysics to investigate the modal characteristics, stress distribution, and output performance of the energy harvester. This revealed the influence of the piezoelectric vibrator’s thickness ratio and the mass block’s weight on its power generation capabilities. Experimental results indicate that under 20 Hz, 12 V sinusoidal excitation, the system achieves an average output power of 3.019 mW with an average open-circuit voltage reaching 16.70 V. Under simulated road test conditions at 70 km/h, the output voltage remained stable at 6.86 V, validating its feasibility in real-world applications. This study presents an efficient and reliable solution for self-powering in-vehicle wireless sensors and low-power electronic devices through mechatronic co-design. Full article

In this study, we investigate a magnetically levitated electromagnetic vibration energy harvester (EMEH), in which a movable permanent magnet levitates between two fixed magnets with like poles facing the central magnet. We develop a nonlinear EMEH model and validate it experimentally, achieving strong agreement with the prototype (R² = 0.95 for RMS EMF). Using this model, we perform a parametric analysis of excitation frequency and the spacing between the fixed magnets (d), yielding practical design criteria for geometry selection. The validated model predicts a narrow maximum; for the present configuration and parameter bounds, it occurs at d ≈ 28 mm with P_out ≈ 151.94 mW, and the corresponding energy density is ρ_E ≈ 9.84 mW cm⁻³. These results yield a practical design rule for selecting d given target metrics and dimensional constraints, providing guidance for the design of compact, low-frequency harvesters powering autonomous sensor nodes. Full article

Low-frequency acoustic logging transducers are pivotal to far-acoustic imaging logging technology and permeability logging technology. This study presents a monopole acoustic transducer driven by electromagnetic force, exploiting the low-frequency vibration characteristics of a flextensional shell. Finite element simulations were employed to evaluate multiple magnetic circuit configurations under dimensional constraints typical of logging tools. An inner magnet circuit was selected and optimized through parametric analysis. Concurrently, the vibration shell was designed and simulated under borehole conditions, accompanied by the development of a dedicated excitation circuit. The fabricated prototype (64 mm outer diameter, 154 mm height, 100 mm shell height) demonstrated operation frequency at 1300 Hz with a sound pressure level of approximately 150 dB and uniform circumferential radiation, satisfying the requirements of logging applications. Full article

This study presents the design, modeling, and experimental validation of a frequency-tuned mechanical sensor (MS) integrating a fiber bragg grating (FBG) for the detection of leak-induced vibrations in pressurized steel pipelines. Unlike conventional bonded FBGs—which directly follow the local wall deformation—the proposed MS consists of a base-fiber-mass transducer geometrically tuned so that its natural frequencies coincide with the dominant vibration modes of the pipe in the 5–7 kHz range. A combined framework of finite element analysis (FEA), computational fluid dynamics (CFD), and laboratory measurements was developed to assess the coupling between the pipe and the sensor. Results show that the MS behaves as a selective mechanical amplifier, enhancing strain sensitivity and signal-to-noise ratio (SNR) by up to 15 dB compared to a directly bonded FBG. The workflow integrates modal tuning, an equivalent harmonic excitation derived from CFD-based pressure fields, and frequency–response validation, leading to a mechanically optimized FBG transducer capable of discriminating high-frequency leak signatures. The excellent agreement between the simulation and experiment confirms that geometric resonance coupling provides an effective route to amplify leak-induced strain, offering a compact, scalable, and high-sensitivity solution for vibration-based leak detection in industrial pipelines. Full article

The ultrasonic sensor method is the most significant and widely accepted technique for measuring liquid levels in tanks. Ultrasonic waves are particularly advantageous in the case of explosive, flammable, or aggressive liquids because of the possibility of introducing ultrasonic pulses through the tank wall safely. Often, the measurement of these liquids should be performed automatically using electronic devices to ensure that the tank remains sealed. In the case of ultrasound, measurements are made using the echo method, with a transmitting-receiving (transceiver) ultrasonic transducer that sends vibration pulses into the tank. The measured delay between the transmitted pulse and the pulse reflected from the liquid surface is proportional to the liquid level in the tank. The volume of liquid can be calculated on the basis of the dimensions of the tank. In this method, it is very important to accurately determine the delay by detecting the beginning of the reflected pulse, which determines the accuracy of the measurement of the level of the liquid and its quantity in the tank. To improve this accuracy, this paper proposes the use of the Akaike Information Criterion (AIC) used in statistics for model selection. As part of the research, ultrasonic test measurements were performed for a tank filled with water and extraction gasoline. This allowed a favorable comparison of the AIC method with the most commonly used threshold method and for determining the accuracy of liquid volume measurements in the tank using both methods in relation to the parameters of several selected ultrasonic sensors. The accuracy obtained using the AIC method was found to be better than that of the fixed-fractional amplitude threshold method. Furthermore, the AIC method is more versatile because it is less sensitive to interference and is capable of detecting the onset of a pulse regardless of its shape and frequency, even in noise. It is suitable for real-time embedded systems for liquid level measurement as well. Full article

A slender piezoelectric cantilever for energy harvesting features high efficiency but a low operational frequency, which cannot meet the requirements for self-powered transformer monitoring. In this research, a piezoelectric vibration energy harvester with a zigzag root section was proposed. The harvester has a vertically arranged zigzag root section, enabling the capability of integrating multiple piezoelectric transducers as well as increasing the resonant frequency and reducing strain. A linear electromechanical coupling model was formulated. The theoretical and experiential base-movement analysis demonstrates that the zigzag root section of the piezoelectric cantilever beam can effectively reduce the equivalent mass of the system and thereby increase the resonant frequency of the slender beam to 100 Hz, the vibration frequency of a transformer. It was also experimentally shown that the harvester can output 13.54 mW of power. An STM32 microcontroller (MCU) based sensor node with a wireless data transmission module was then designed for evaluations. The piezoelectric harvester with a zigzag root section can successfully support a wireless sensor for transformer monitoring. Full article

Structural Health Monitoring (SHM) of steel bridges is vital for ensuring the longevity, safety, and reliability of critical transportation infrastructure. This review synthesizes recent advancements in SHM technologies and methodologies for steel bridges, highlighting the shift from traditional vibration-based monitoring to data-driven, intelligent systems. It covers core technological themes, including various sensing systems such as wireless sensor networks, fiber optics, and piezoelectric transducers, along with the impact of machine learning, artificial intelligence, and statistical pattern recognition. The paper explores applications for damage detection, such as fatigue life assessment and monitoring of components like expansion joints. Persistent challenges, including deployment costs, data management complexities, and the need for real-world validation, are addressed. The future of SHM lies in integrating diverse sensing technologies with computational analytics, advancing from periodic inspections to continuous, predictive infrastructure management, which enhances bridge safety, resilience, and economic sustainability. Full article

Air-coupled ultrasonic detection demands high transmission performance from piezoelectric micromachined ultrasonic transducers (PMUTs). However, existing microelectromechanical system (MEMS)-based PMUTs deliver limited output, which compromises measurement accuracy and constrains further development. This work proposes a novel PMUT design with a cantilevered, boundary-suspended diaphragm that relieves residual stress, relaxes edge constraints, increases the mechanical degrees of freedom, and enables larger vibration amplitudes. Additionally, this work develops an accurate air-coupling model to predict device performance and a streamlined micro-nanofabrication process for device realization. Experimental results show that under a 1 Vpp (−5 Voffset) drive, the device achieves a peak acoustic pressure of 4.004 Pa at 69.3 kHz, measured at 10 cm distance in air, corresponding to a maximum sound pressure level of 106.02 dB (re 2 × 10⁻⁵ Pa). Compared to a traditional PMUT at 98.45 dB, this represents a 7.57 dB improvement and, to our knowledge, the highest reported sound pressure level at 10 cm for a single PMUT operating near 70 kHz under a 1 Vpp excitation. These results validate the significant enhancement in transmission performance achieved by the proposed topological structure, offering a solution to overcome the common bottleneck of insufficient output in PMUTs, and indicate strong potential for broader air-coupled sensing applications. Full article

Gas pipelines are a critical means of transportation in industrial production. To detect gas pipeline leaks, ultrasonic transducers with specific center frequencies and high sensitivity are required. This paper proposes a novel air-coupled ultrasonic transducer design based on a horn-type matching layer and a bending-mode type of piezoelectric material, specifically tailored for gas leak detection scenarios. The transducer design is optimized by the finite element method, focusing on the basic components of the piezoelectric bimorph, the horn and the supporting tube. First, the influence of various dimensional parameters of the piezoelectric bimorph on the bending vibration mode was analyzed. Then, the effects of the other two components, the horn and the supporting tube, on the piezoelectric bimorph vibration mode were investigated. A parametric scan on the dimensions of these components was conducted to optimize the transducer’s output. Finally, ultrasonic transducers using PMN-PT and PZT were fabricated and tested. The results show that the sensitivity of those transducers surpasses that of similar commercial transducers, especially the PMN-PT one with a center frequency of 40 kHz and a peak receiving sensitivity of −51.1 dB. This transducer, benefiting from the high-performance piezoelectric material and the bending vibration mode, proves to be a promising candidate for high-precision leak detection in gas pipelines. Full article

This paper presents a three-dimensional, acoustic streaming-driven circular micromixer with sharp-edge structures and the coupling mechanism between acoustic streaming and background flow in biological systems. A piezoelectric transducer induces vibrations in the sharp-edge structures, generating a localized, intense acoustic field that produces a nonlinear acoustic streaming vortex at the tip. The disk-shaped mixing chamber design enhances acoustic field perturbation. This study incorporates the actual background flow field into the model to elucidate the strong interaction between acoustic streaming and steady-state flow. In the sharp-edge structural region, structural curvature induces local variations in acoustic amplitude, generating a non-zero mean Reynolds stress that significantly perturbs the background laminar flow, reduces flow stability, and substantially enhances mixing. The effects of displacement amplitude, Reynolds number, sharp-edge angle, and excitation frequency on the mixing efficiency are systematically investigated. Furthermore, the mixing performances of two different fluids, water and blood, are compared to elucidate the influence of fluid properties on mixing behavior. This mechanism provides theoretical support for microscale active mixing and offers novel insights for microfluidic device design. Full article

Microelectromechanical systems (MEMSs) are increasingly used for both industrial and consumer applications. To improve the accuracy and efficiency of MEMS fabrication and to overcome the limitations of conventional contactless positioning systems, this study introduces a novel positioning concept that combines ultrasonic levitation with electromagnetic actuation. Squeeze-film effects generated by high-frequency ultrasonic transducers enable levitation, while fast-response reluctance forces from electromagnets govern the positioning dynamics without requiring bulky mounting frames. The focus of this paper is on proposing a novel double-acting ultrasonic transducer with a Gaussian profile horn, ensuring an approximately uniform vibration distribution and increased levitation force. The double-acting design enables levitation on both surfaces, simplifying the mounting and thermal compensation of the transducer’s expansion while reducing interactions among transducers. A model-based control strategy ensures resonant operation and constant vibration amplitude. Experiments demonstrate levitation forces up to 343 N, with a total levitation height of 25 µm, resulting from two levitation air gaps. Comprehensive performance characterization validates the feasibility of this transducer design for integration into the proposed positioning system. Full article

Piezoelectric synthetic jet actuators typically struggle to generate high-speed jets at low driving frequencies due to the coupling effect between jet frequency and jet intensity. This limitation to some extent restricts their application in flow control within low-speed flow fields. To address this issue, this study presents two methods of signal modulation. The effects of driving signal modulation on dual synthetic jet actuator (DSJA) characteristics were experimentally investigated. A laser displacement meter was used to measure the central point amplitude of the piezoelectric diaphragm, while the velocity at the exit of the DSJAs was measured using a hot-wire anemometer. The effects of signal modulation on the amplitude of the piezoelectric diaphragm, the maximum jet velocity, and the frequency domain characteristics of the dual synthetic jet (DSJ) were thoroughly analyzed. Experimental results demonstrate that driving signal modulation can enhance jet velocity at relatively low driving frequencies. The modulated DSJ exhibits low-frequency characteristics, rendering it suitable for flow control applications that require low-frequency jets. Furthermore, the coupling effect between jet frequency and jet intensity in the piezoelectric DSJA is significantly alleviated. Starting from the vibration displacement of the piezoelectric transducer (PZT), this paper systematically elaborates on the corresponding relationship between PZT displacement and the peak velocity at the jet outlet, and the “low-frequency and high-momentum jet generation method based on signal modulation” proposed herein is expected to break through the momentum–frequency coupling limitation of traditional piezoelectric dual-stenosis jet actuators (DSJAs) and enhance their application potential in low-speed flow control. Full article

The proliferation of wireless sensor networks in industrial Internet of Things (IIoT) applications demands sustainable power solutions that eliminate battery replacement requirements while maintaining operational reliability in varying vibration environments. This paper presents a frequency-tunable magnetoelectric (ME) energy harvester that addresses the fundamental challenge of frequency mismatch between ambient industrial vibrations and harvester resonance through position-dependent magnetic force manipulation. The proposed system employs a Terfenol-D/PMNT/Terfenol-D sandwich transducer mounted on a cantilever beam within an adjustable magnetic circuit, enabling continuous frequency tuning through air gap modification for different magnetic field configurations. A comprehensive theoretical framework incorporating position-dependent magnetic forces was developed to predict the system behavior. Additionally, Multi-walled carbon nanotube (MWCNT)-enhanced epoxy bonding layers with 2 wt.% concentration were analyzed and demonstrated six-fold power improvement over conventional epoxy. The experimental validation shows frequency tuning from 40 Hz to 65 Hz through air gap adjustment of only 1 mm, corresponds to a 62.5% tuning range. Further experimental investigation proves a ten-fold power output improvement up to 2 mW by employing a four-magnet circuit design compared to the two-magnet configuration through specific adjustment of the air gap width. Full article

This article presents numerical and physical studies of a symmetrical piezoelectric ultrasonic vibration system (UVS), which consists of a double bidirectional axial piezoelectric transducer with two disks arranged perpendicular to its axis of symmetry. The UVS was designed, modeled, and constructed so that the symmetrical bidirectional axial piezoelectric transducer located in the center would work as a longitudinal vibration resonant system, which causes the disks attached at the ends to vibrate at a resonant frequency. Such a UVS design was conceived with the aim of applying it in air purification systems—an acoustic field is formed between the disks of the system, which forms lower- and higher-pressure zones in the air contaminated with particles. Particle agglomeration occurs in these zones. The stuck and thickened particles are subsequently cleaned by conventional methods. A special stand was used for the physical study, in which the UVS was installed. During the numerical research, calculations of the possibilities of particle agglomeration were performed. Tests were conducted in several different operating modes of the stand, and the results showed that such UVS can help agglomerate particulate matter in the air stream and thus improve air quality. Full article
