Search Results (18)

Sloshing in liquid storage tanks is a critical phenomenon that affects the stability, performance, and safety of various engineering systems, including fuel tanks, offshore structures, and industrial storage units. The presence of internal structures, such as vertical baffles, significantly influences the natural sloshing frequencies and fluid motion. However, existing theoretical models often rely on simplified assumptions that restrict their capacity to capture the complexities of fluid–structure interactions in baffled tanks. This study integrates the coupled Eulerian–Lagrangian method with the impulse excitation technique to predict natural sloshing frequencies in a rectangular tank with vertical baffles. By analyzing the system’s response to an impulse excitation, we extracted the dominant sloshing frequencies while considering the impact of baffles on fluid dynamics. This computational approach provides a more realistic representation of sloshing phenomena and enables a parametric analysis of how various tank dimensions, fluid properties, and baffle configurations influence sloshing behavior. The findings of this study contribute to the improved design and optimization of liquid storage tanks, ensuring enhanced stability and performance in practical engineering applications. The integration of impulse excitation with the coupled Eulerian–Lagrangian method marks a significant advancement in sloshing analysis, offering a robust framework for understanding and mitigating the effects of sloshing in baffled tanks. Full article

Reusable rockets must rely on well-designed Guidance, Navigation and Control (GNC) algorithms. Because they are tested and verified in closed-loop, high-fidelity simulators, emphasizing the strategy to achieve such advanced models is of paramount importance. A wide spectrum of complex dynamic behaviors and their cross-couplings must be captured to achieve sufficiently representative simulations, hence a better assessment of the GNC performance and robustness. This paper focuses on of the main aspects related to the physical (acausal) modeling of reusable rockets, and the integration of these models into a suitable simulation framework oriented towards GNC Validation and Verification (V&V). Firstly, the modeling challenges and the need for physical multibody models are explained. Then, the Vertical Landing Vehicles Library (VLVLib), a Modelica-based library for the physical modeling and simulation of reusable rocket dynamics, is introduced. The VLVLib is built on specific principles that enable quick adaptations to vehicle changes and the introduction of new features during the design process, thereby enhancing project efficiency and reducing costs. Throughout the paper, we explain how these features allow for the rapid development of complex vehicle simulation models by adjusting the selected dynamic effects or changing their fidelity levels. Since the GNC algorithms are normally tested in Simulink^®, we show how simulation models with a desired fidelity level can be developed, embedded and simulated within the Simulink^® environment. Secondly, this work details the modeling aspects of four relevant vehicle dynamics: propellant sloshing, Thrust Vector Control (TVC), landing legs deployment and touchdown. The CALLISTO reusable rocket is taken as study case: representative simulation results are shown and analyzed to highlight the impact of the higher-fidelity models in comparison with a rigid-body model assumption. Full article

Steel storage tanks are widely used in different fields. Most of these tanks contain hazardous materials, which may lead to disasters and environmental damage for any design errors. There are many reasons which cause the failure of these tanks such as excessive base plate settlement, shear failure of soil, liquid sloshing, and buckling of the tank shell. In this study, five models of above-ground steel storage tanks resting over different types of clay soils (medium-stiff clay, stiff clay, and very stiff clay soils) are analyzed using the finite element program ADINA under the effect of static and dynamic loading. The soil underneath the tank is truly simulated using a 3D solid (porous media) element and the used material model is the Cam-clay soil model. The fluid in the tank is modeled depending on the Navier–Stokes fluid equation. Moreover, the earthquake record used in this analysis is the horizontal component of the Loma Prieta Earthquake. The analyzed tanks are circular steel tanks with the same height (10 m) and different diameters (ranging from 15 m to 40 m). The soil under the tanks has a noticeable effect on the dynamic behavior of the studied tanks. The tanks resting over the medium-stiff clay (the weakest soil) give a lower permanent settlement after the earthquake because of its low elastic modulus which leads to the absorption of the earthquake waves in comparison to the other types of soil. There are 29.6% and 35.6% increases in the peak dynamic stresses under the tanks in the cases of stiff clay and very stiff clay soils, respectively. The maximum values of the dynamic vertical stresses occur at a time around 13.02 s, which is close to the peak ground acceleration of the earthquake. Full article

Liquid sloshing in the tank can seriously affect the stability of hazardous chemical tanker trucks during operation. To this end, this paper proposes a solution based on an electromagnetic semi-active suspension system to prevent chemical spills and ensure safe driving of hazardous chemical tank vehicles. A comprehensive investigation was conducted across four domains: theoretical research, simulation model establishment, co-simulation platform construction, and simulation data analysis. Three fuzzy controllers were used to suppress the vibration of the tank vehicles, and a simulation study of the stability control of the tank vehicles under electromagnetic semi-active suspension was carried out. The results show that the electromagnetic semi-active suspension can significantly reduce the vertical, pitch, and roll vibrations of the tank vehicles by 17.60%, 25.78%, and 27.86%, respectively. The research results of this paper are of great significance for improving the safety and stability of hazardous chemical tanker trucks. Full article

Liquid sloshing is a common phenomenon in ocean engineering, and one which not only affects the stability of ship navigation, but also poses a threat to both the marine environment and human life. Ascertaining how best to reduce the amplitude of liquid sloshing has always been a key problem in ocean engineering. In this study, based on an improved moving-particle semi-implicit method, the BM-MPS method, the damping effect of a vertical slotted screen under rotation excitation was simulated and studied, and the influence of baffle porosity and the rotation amplitude on the resonance period and impact pressure was discussed. The results showed that the porosity had an obvious effect on the resonance period. A significant resonance period transformation happened when the porosity was 0.1, but a porosity of 0.15 was the point at which the maximum impact pressure in the resonance was at its minimum. Meanwhile, the impact duration curve was related to porosity. With the increasing of porosity, the impact duration curve changed from having no peak to a single peak, and then to double peak. In addition, the amplitude of rotation excitation was also one of the factors that affected the resonance period. Full article

As part of the Sloshing Wing Dynamics H2020 EU project, an experimental campaign was conducted to study slosh-induced damping in a vertically excited tank filled with liquid water or oil and air. In this work, we simulate these experiments using two numerical approaches. First, a single-phase, weakly compressible liquid model is used, and the gas flow (air) is not modeled. For this approach, a proven Smoothed Particle Hydrodynamics (SPH) model is used. In the second approach, both phases are simulated with an incompressible liquid and weakly compressible gas model via a Finite Volume Method (FVM) using Volume-of-Fluid (VOF) to track the liquid phase. In both approaches, the energy distribution of the flow is calculated over time in two- and three-dimensional simulations. It is found that there is reasonable agreement on the energy dissipation evolution between the methods. Both approaches show converging results in 2D simulations, although the SPH simulations seem to have a faster convergence rate. In general, the SPH results tend to overpredict the total dissipation compared to the experiment, while the finite volume 2D results underpredict it. Time histories of the center of mass positions are also compared. The SPH results show a much larger vertical center of mass motion compared to the FVM results, which is more pronounced for the high Reynolds number (water) case, probably linked to the absence of the air phase. On the other hand, the limited center of mass motion of the FVM could be linked to the need for higher spatial resolutions in order to resolve the complex gas–liquid interactions, particularly in 3D. Full article

As part of a wider project to understand the applicability of utilising slosh-based damping for wing-like structures, simulations of partially filled tanks subjected to harmonically oscillating and vertical motion are presented. The Volume of Fluid modelling approach is used to capture the air–water interface and different turbulence models based on the Reynolds Averaged Navier–Stokes equations employed. No-model simulations are also conducted to demonstrate the efficacy of using turbulence models in the simulation of sloshing flows. Accuracy of the models is assessed by comparing with recent well-validated experimental data in terms of the damping effect of the sloshing. A wide range of excitation amplitudes are considered in the study to demonstrate the effectiveness of different turbulence models in representing the flow feature of weak and very violent sloshing. The results show that standard turbulence models can produce an excessive dissipation, especially at the interface, leading to inaccuracies in the estimation of sloshing dynamics of the violent sloshing. This issue is absent in the no-model simulations, and better results are obtained for all tested sloshing conditions, suggesting approaches to mitigate this interfacial dissipation within RANS-based modelling is an important consideration for future direction. Full article

This paper makes use of sloshing reduced-order models to investigate the effects of sloshing dynamics on aeroelastic stability and response of flying wing structure. More specifically, a linear frequency-domain operator derived by an equivalent mechanical model is used to model lateral (linear) sloshing dynamics whereas data-driven neural-networks are used to model the vertical (nonlinear) sloshing dynamics. These models are integrated into a formulation that accounts for both the rigid and flexible behavior of aircraft. A time domain representation of the unsteady aerodynamics is achieved by rational function approximation of the fully unsteady aerodynamics obtained via the doublet lattice method. The case study consists of the so called Body Freedom Flutter research model in two different configurations with one or two tanks partially filled with liquid with a mass comprising 25% of the aircraft structure. The results show that linear sloshing dynamics are able to change the stability margin of the aircraft in addition to having non-negligible effects on rigid body dynamics. On the other hand, vertical sloshing acts as a nonlinear damper and eventually provides limit cycle oscillations after flutter onset. Full article

The added damping generated by liquid sloshing in a tank has been utilized in a number of civil applications, including aviation, to reduce the vibration of the system. As part of a wider EU H2020 project called SLOWD (Sloshing Wing Dynamics), the presented study performed numerical simulations on the slosh-induced damping of liquid in tanks that were under free decay oscillations and embedded in an aircraft wing-like structure. A new open-source partitioned fluid–structure interaction software framework is presented and employed for the numerical simulations. Periodic sloshing waves and violent vertical fluid motions are observed in the study. These demonstrate the effects of slosh-induced damping under different excitation amplitudes of the structure and a varying number of baffled regions within the tank. Various sloshing patterns caused by different combinations of the excitation amplitude and compartment numbers lead to different induced dampings of the free decay motion. We observed a distinctly non-monotonic function on the slosh damping when the initial excitation amplitude is small (i.e., 0.25), with a 59% reduction when we increase the number of baffled compartments from one to four, and a 153% increase when moving from one to eight compartments. This is due to the change in the sloshing wave frequency, resulting in a significant change in the impact of the fluid between the tank ceiling and the wave crests. When the initial excitation amplitude is large (i.e., 1.0), there is no significant change in the slosh-induced damping when changing the number of compartments in the tank, for the range of parameters considered, due to the highly turbulent fluid motion. This work is expected to form the basis of further, more detailed studies within the context of the SLOWD project and its ever-expanding experimental data output. Full article

In this work, the most fundamental aspects of an aeronautical sloshing problem have been studied using an alternative and simplified model. This model consists of a single degree of freedom version of the original problem which keeps the essence of the fluid structure interaction and also the most relevant physical aspects of the industrial case. Two independent methodologies have been used: first an experimental rig has been designed to measure and visualize different magnitudes of the problem and also a smoothed particle hydrodynamics formulation has been adapted to obtain a local representation of the flow interaction. Two very different fluids in terms of viscosity have been tested, and the differences in terms of the characteristics of the sloshing regimes, free surface fragmentation and relative kinetic energy have been described and compared. Apart from the comparison of the results obtained by both methodologies in terms of tank acceleration, sloshing forces and free surface evolution, a deep study of the sloshing force has been performed. This study focuses on a deeper understanding of the different aspects that constitute the sloshing force, such as its synchronization with the tank movement, the relation to the movement of the liquid’s center of mass and the physical projection of the force on the pressure and viscous parts. Additionally, a reconstruction of the sloshing force as a sum of the pressure signal recorded by a finite number of pressure sensors has been also performed. Full article

Vertical sloshing of liquid-filled tanks has been shown to induce substantial dissipative effects. Building upon these previous results obtained on simpler sloshing systems, a scaled wing prototype is presented here, equipped with a fuel tank that allows the observation of liquid sloshing and quantification of induced dynamic effects. Based on experiments conducted at a 50% filling level for a baffled wing fuel tank model, substantial additional damping effects were demonstrated with liquid inside the tank regardless of the vertical acceleration amplitude. A numerical model based on a finite element wing structural model and a surrogate 1DOF fluid model was explored, with numerical simulations showing good agreement compared to experiments throughout the decaying motion of the system. Full article

We present the CFD based non-dimensional characterization of violent slosh induced energy dissipation due a tank under vertical excitation. Experimentally validated CFD is used for this purpose as an ideally suited and versatile tool. It is thus first demonstrated that a weakly compressible VoF based CFD scheme is capable of computing violent slosh induced energy dissipation with high accuracy. The resulting CFD based energy analysis further informs that the main source of energy dissipation during violent slosh is due liquid impact. Next, a functional relationship characterising slosh induced energy dissipation is formulated in terms of fluid physics based non-dimensional numbers. These comprised contact angle and liquid–gas density ratio as well as Reynolds, Weber and Froude numbers. The Froude number is found the most significant in characterising verticle violent slosh induced energy dissipation (in the absence of significant phase change). The validated CFD is consequently employed to develop scaling laws (curve fits) which quantify energy dissipation as a function of the most important fluid physics non-dimensional numbers. These newly developed scaling laws show for the first time that slosh induced energy dissipation may be expressed as a quadratic function of Froude number and as a linear function of liquid–gas density ratio. Based on the aforementioned it is postulated that violent slosh induced energy dissipation may be expressed as a linear function of tank kinetic energy. The article is concluded by demonstrating the practical use of the novel CFD derived non-dimensional scaling laws to infer slosh induced energy dissipation for ideal experiments (with exact fluid physics similarity to the full scale Aircraft) from (non-ideal) slosh experiments. Full article

Understanding the damping mechanism of baffles is helpful to make more reasonable use of them in suppressing liquid sloshing. In this study, the damping effect and mechanism of vertical baffles in shallow liquid sloshing under a rotational excitation are investigated by an improved particle method. By incorporation of a background mesh scheme and a modified pressure gradient model, the accuracy of impact pressure during sloshing is significantly enhanced. Combined with the advantages of the particle method, the present numerical method is a wonderful tool for the investigation of liquid sloshing issues. Through the analysis of impact pressure, the influences of baffle height and baffle position on the damping mechanism are discussed. The results show that the damping effect of vertical baffles increases with the increase of the elevation of baffle top and decreases with the increase of the elevation of the baffle bottom. Moreover, the resonance characteristics of sloshing are altered when static water is divided into two parts by the vertical baffle. The dominant damping mechanism of vertical baffles depends on the configurations. Full article

There is growing interest for water-wave flows through arrangements of cylinders with application to the performance of porous marine structures and environmental flows in coastal vegetation. For specific few cases experimental data are available in the literature concerning the modification of the dispersion equation for waves through a dense array of vertical cylinders. This paper presents a numerical study of the porosity effects on the dispersion relation of water waves through such configurations. To this aim, the sloshing problem in a tank full of vertical cylinders intersecting the free surface is studied using the finite element method, and the influence of the porosity on the wave number is quantified. On the basis of numerical results, a new modification of a dispersion relation for porous medium is suggested based on a wide range of collected data. Moreover, the domain of validity of this new dispersion relation is examined considering the number of cylinders and the extrapolation to the infinite medium. Full article

Verification results for the LOGOS software package as applied to numerical simulations of tsunami waves are reported. The module of the LOGOS software package that is used for tsunami simulations is based on the numerical solution of three-dimensional Navier–Stokes equations. The verification included two steps. The first step involved the verification of LOGOS free-surface flow simulations on the test cases of a collapsing water column and gravity water sloshing in a tank and the known test cases of wave generation by objects falling into water or lifted out of it. The verification of LOGOS specifically for tsunami simulations was performed using a reference set of international benchmarks including the propagation and run-up of a single wave onto a flat slope and a vertical wall, the sliding of a wedge-shaped body down a slope, flow around an island and wave run-up over an obstacle. The results of the verification simulations demonstrate that LOGOS provides sufficient accuracy in numerical simulations of tsunami waves, namely, their generation, propagation and run-up. Full article
