This article presents an innovative method for planning and tracking the trajectory in the image plane for the visual control of a quadrotor. The community of researchers working on 2D control widely recognizes this challenge as complex, because a trajectory defined in image space can lead to unpredictable movements of the robot in Cartesian space. While researchers have addressed this problem for mobile robots, quadrotors continue to face significant challenges. To tackle this issue, the adopted approach involves considering the separation of altitude control from the other variables, thus reducing the workspace. Furthermore, the movements of the quadrotor (pitch, roll, and yaw) are interdependent. Consequently, the connection between the inputs and outputs cannot be reversed. The task complexity becomes significant. To address this issue, we propose the following scenario: When the quadrotor is equipped with a downward-facing camera, flying at high altitude is sensible to spot a target. However, to minimize disturbances and conserve energy, the quadrotor needs to descend in altitude. This can result in the target being lost. The solution to this problem is a new methodology based on the principle of differential flatness, allowing the separation of altitude control from the other variables. The system first detects the target at high altitude, then plots a trajectory in the image coordinate system between the acquired image and the desired image. It is crucial to emphasize that this step is performed offline, ensuring that the image processing time does not affect the control frequency. Through the proposed trajectory planning, complying with the constraints of differential flatness, the quadrotor can follow the imposed dynamics. To ensure the tracking of the target while following the generated trajectory, the proposed control law takes the form of an Image Based Visual Servoing (IBVS) scheme. We validated this method using the RVCTOOLS environment in MATLAB. The DJI Phantom 1 quadrotor served as a testbed to evaluate, under real conditions, the effectiveness of the proposed control law. We specifically designed an electronic card to transfer calculated commands to the DJI Phantom 1 control joystick via Bluetooth. This card integrates a PIC18F2520 microcontroller, a DAC8564 digital-to-analogue converter, and an RN42 Bluetooth module. The experimental results demonstrate the effectiveness of this method, ensuring the precise tracking of the target as well as the accurate tracking of the path generated in the image coordinate system. Full article

This paper investigates one way to reduce the computational burden of continuous-time model predictive control (MPC) laws by representing the input/output signals and related models using B-spline functions. Such an approximation allows to implement the resulting feedback control law more efficiently, requiring less online computational effort. As a result, the proposed controller formulates the control signals as continuous polynomial spline functions. All constraints assumed over the prediction horizon are then expressed as constraints acting on the B-splines control polygon vertices. The performance of the proposed theoretical framework has been demonstrated with several real-time experiments using the well-known 2-DOF laboratory helicopter setup. The aim of the presented experiments was to track given step-like reference trajectories for pitch and yaw angles under notable parameter uncertainties. In order to suppress the influence of uncertainties, the control algorithm is implemented in an adaptive mode, equipped with the recursive least squares (RLS) estimation of model parameters and with the adaptation of stabilizing terminal set and terminal cost calculations. Thanks to the presented framework, it is possible to significantly reduce the computational burden, measured by the number of decision variables and input constrains, indicating the potential of the proposed concept for real-time applications, even when using embedded control hardware. Full article

This paper deals with the longitudinal movement control of an airplane (pitch angle) using fractional order adaptive controllers (FOACs). It shows the improvements achieved in the plane’s behavior, in terms of the minimization of a given performance index. At the same time, less control effort is needed to accomplish the control objectives compared with the classic integer order adaptive controllers (IOACs). In this study, fractional order direct model reference adaptive control (FO-DMRAC) is implemented at the simulation level, and exhibits a better performance compared with the classic integer order (IO) version of the DMRAC (IO-DMRAC). It is also shown that the proposed control strategy for FO-DMRAC reduces the resultant system control structure down to a relative degree 2 system, for which the control implementation is simpler and avoids oscillations during the transient period. Moreover, it is interesting to note that this is the first time that an FOAC with fractional adaptive laws is applied to the longitudinal control of an airplane. A suitable model for the longitudinal movement of the airplane related to the pitch angle θ as the output variable with the lifter angle (δe) as the control variable, is first analyzed and discussed to obtain a reliable mathematical model of the plane. All of the other input variables acting on the plane are considered as perturbations. For certain operating conditions defined by the flight conditions, an FO-DMRAC is designed, simulated, and analyzed. Furthermore, a comparison with the implementation of the classical adaptive general direct control (relative degree ≥ 2) is presented. The boundedness and convergence of all of the signals are theoretically proven based on the new Lemma 3, assuring the boundedness of all internal signals ω(t). Full article

A numerical procedure was developed to determine a variable-pitch law that maximized the performance of a vertical-axis wind turbine (VAWT). The methodology was based on the determination, for each blade, of the angle of attack maximizing the stationary aerodynamic efficiency at prescribed azimuthal positions. The angles of attack were determined by means of a panel method with a low computational effort, and the methodology was implemented in Matlab${}^{\circledR }$ software (version R2021a) allowing us to achieve in real time a variable-pitch law suitable for the turbine geometry. The variable pitch law was validated by considering its effect on the torque of a 2D model of an H-Darrieus turbine. U-RANS analyses were carried out with a $K-\omega SST$ model and a sliding-mesh technique was used to prescribe the blade motion around the shaft and pitch motion. Results showed how the variable-pitch law delayed the dynamic stall and improved the aerodynamic performance considerably. Full article

This paper addresses the issue of a complex three-dimension (3-D) terminal guidance process that is used against maneuvering targets while considering both the terminal impact angle (TIA) and field-of-view (FOV) angle constraints. According to the highly coupled and nonlinear 3-D terminal guidance model, an adaptive back-stepping sliding-mode guidance law algorithm is proposed in order to guarantee the stability and robustness of the guidance system. Considering the explicit expression of the line-of-sight (LOS) angle in the kinematics and dynamics of the terminal guidance process, the TIA constraint is transformed into an LOS constraint based on their well-known relationship. In view of the challenges in obtaining the motion information of maneuvering targets, an adaptive law design is introduced in order to estimate and compensate for external disturbances caused by the maneuvering of the target and modeling uncertainty. In addition, because the FOV angle represented by the overall leading angle is not a state variable in the sliding-mode guidance system, it is decoupled into two partial leading angles based on a specific transformation relation, so the 3-D terminal guidance control problem is converted into separate tracking system control issues in the pitch and yaw planes. Then, the Lyapunov stability theory is utilized to substantiate the stability of the guidance system, where the Lyapunov functions in both of the subsystems consist of the LOS and partial FOV state error terms. Finally, a series of simulations of various motion states of maneuvering targets under different terminal cases were carried out. It was proved that the terminal guidance design based on the strategies presented above was able to obtain the desired LOS constraints with satisfying the FOV limitation, and the simulation results verified the effectiveness, universality, and significance for practical applications of the proposed guidance design method. Full article

To solve the design problem of non-circular gears with cusp pitch curves, this paper proposed a new variable-involute and incomplete variable-cycloid composite tooth profile (VIIVC-CTF), deduced the new VIIVC-CTF mathematical model, and constructed the conjugate gear model based on the envelope method. The design software of the non-circular gear with a cusp pitch curve was developed based on MATLAB. The variation law of rolling radius on an incomplete cycloid profile and its characteristics such as pressure angle and radius of curvature were analyzed. The variation relationship of the rolling radius on the meshing line and the contact ratio of the VIIVC-CTF were studied. The variation relationship of incomplete variable-cycloid profile shape, pressure angle, and curvature radius corresponding to different elliptical eccentricities were analyzed. The meshing analysis of the non-circular gear transmission mechanism was carried out based on virtual software. A comparison of the consistency of the theoretical value and simulation value of the transmission ratio curve verified that the tooth profile design method was feasible, and the VIIVC-CTF was applied to the seedling pick-up mechanism of the non-circular gear planetary gear train. Through the seedling picking experiment of the seedling pick-up mechanism, the feasibility of the application of the VIIVC-CTF was verified. Full article

Wind speed variations affect the performance of the wind energy conversion systems (WECSs) negatively. This paper addressed an advanced law of the backstepping controller (ABC) for enhancing the integration of doubly fed induction generator (DFIG)-based grid-connected WECS under wind range of wind speed. This enhancement was achieved through three control schemes, which were blade pitch control, rotor-side control, and grid-side control. The blade pitch control was presented to adjust the wind turbine speed when the wind speed exceeds its rated value. In addition, the rotor and grid-side converter controllers were presented for improving the direct current link voltage profile and achieving maximum power point tracking (MPPT) under speed variations, respectively. To evaluate the effectiveness of the proposed ABC control, a comparison between PI and sliding-mode control (SMC) was presented, considering the parameters of a 1.5 MW DFIG wind turbine in the Assilah zone in Morocco. Moreover, some changes in the DFIG parameters were introduced to investigate the robustness of the proposed controller under parameter uncertainties. Simulation results showed the capability of the proposed ABC controller to enhance the performance of the DFIG-WECS based on variable speed and variable pitch turbine, at both below and above-rated speed, leading to an error around 10⁻³ (p.u), with an ATE = 0.4194 in the partial load region; in terms of blade pitch control, an error of 2.10⁻⁴ (p.u) was obtained, and the DC-link voltage profile showed a measured performance of 5 V and remarkable THD value reduction compared to other techniques, with a measured THD value of 2.03%, 1.67%, and 1.46% respectively, in hyposynchronous, hypersynchronous, and pitch activation modes of operation. All simulations were performed using MATLAB/SIMULINK based on real wind profiles in order to make an exhaustive analysis with realistic operating conditions and parameters. Full article

This study presents a fast terminal synergetic control (FTSC) scheme to investigate the nonlinear control problem of permanent magnet vernier generator (PMVG)-based variable-speed wind energy conversion systems (WECSs). In wind turbines, better speed tracking and fast dynamic behavior is required to achieve the maximum power extraction. To do this, the FTSC method is firstly proposed to improve the dynamic performance of tracking the speedby, addressing the turbulent wind and uncertainties in the PMVG system, which improves the wind energy extraction efficiency and alleviates mechanical stress over the turbine. Next, the closed-loop FTSC with a macro variable and novel reaching law is presented to enhance the convergence of the speed error signal when it is far from equilibrium in finite time. At this time, the controller’s output is a zero chattering generator torque reference that can operate the system in both below- and above-rated wind conditions, in addition to pitch control. Then, the proposed control method is verified for its effectiveness in energy capture through numerical simulation and experimental verification of a 5 kW direct drive PMVG-based WECS. Finally, comparative results confirm the better performance of the proposed system under transients than other controllers considered in this analysis. Full article

Around the cooperative path-following control for the underactuated surface vessel (USV) and the unmanned aerial vehicle (UAV), a logic virtual ship-logic virtual aircraft (LVS-LVA) guidance principle is developed to generate the reference heading signals for the USV-UAV system by using the “virtual ship” and the “virtual aircraft”, which is critical to establish an effective correlation between the USV and the UAV. Taking the steerable variables (the main engine speed and the rudder angle of the USV, and the rotor angular velocities of the UAV) as the control input, a robust adaptive neural cooperative control algorithm was designed by employing the dynamic surface control (DSC), radial basic function neural networks (RBF-NNs) and the event-triggered technique. In the proposed algorithm, the reference roll angle and pitch angle for the UAV can be calculated from the position control loop by virtue of the nonlinear decouple technique. In addition, the system uncertainties were approximated through the RBF-NNs and the transmission burden from the controller to the actuators was reduced for merits of the event-triggered technique. Thus, the derived control law is superior in terms of the concise form, low transmission burden and robustness. Furthermore, the tracking errors of the USV-UAV cooperative control system can converge to a small compact set through adjusting the designed control parameters appropriately, and it can be also guaranteed that all the signals are the semi-global uniformly ultimately bounded (SGUUB). Finally, the effectiveness of the proposed algorithm has been verified via numerical simulations in the presence of the time-varying disturbances. Full article

In order to increase the driving force of the voice coil actuator while reducing its size and mass, the structural parameters of the coil and magnet in the actuator are optimized by combing Biot–Savart law with Lagrangian interpolation. A 30 mm × 30 mm × 42 mm robot based on a 3-RPS parallel mechanism driven by voice coil actuators is designed. The Lagrangian dynamic equation of the robot is established, and the mapping relationship between the driving force and the end pose is explored. The results of dynamic analysis are simulated and verified by the ADAMS software. The mapping relationship between the input current and the end pose is concluded by taking the driving force as the intermediate variable. The robot can bear a load of 10 g. The maximum axial displacement of the robot can reach 9 mm, and the maximum pitch angle and return angle can reach 40 and 35 degrees, respectively. The robot can accomplish forward movement through vibration, and the maximum average velocity can reach 4.1 mm/s. Full article

This paper proposes an adaptive fault tolerant control (FTC) design for a variable speed wind turbine (WT) operating in the high wind speeds region. It aims at mitigating pitch actuator faults and regulating the generator power to its rated value, thereby reducing the mechanical stress in the high wind speeds region. The proposed FTC design implements a sliding mode control (SMC) approach with an adaptation law that estimates the upper bounds of the uncertainties. System stability and uniform boundedness of the outputs was proven using the Lyapunov stability theory. The proposed approach was validated on a 5 MW three-blade wind turbine modeled using the National Renewable Energy Laboratory’s (NREL) Fatigue, Aerodynamics, Structures and Turbulence (FAST) wind turbine simulator. The controller’s performance was assessed in the presence of several pitch actuator faults and turbulent wind conditions. Its performance was also compared to that of a standard SMC approach. Mitigation of blade pitch actuator faults, generation of uniform power, smoother pitching actions and reduced chattering compared to standard SMC approach are among the main features of the proposed design. Full article

Vertical axis turbines, also called Darrieus turbines, present interesting characteristics for offshore wind and tidal applications but suffer from vibrations and a lower efficiency than the more conventional horizontal axis turbines. The use of variable pitch, in order to control the angle of attack of the blades continuously during their rotation, is considered in this study to overcome these problems. 2D blade-resolved unsteady Reynolds-Averaged Navier–Stokes (RANS) simulations are employed to evaluate the performance improvement that pitching blades can bring to the optimal performance of a three-straight-blade vertical axis tidal turbine. Three pitching laws are defined and tested. They aim to reduce the angle of attack of the blades in the upstream half of the turbine. No pitching motion is used in the downstream half. The streamwise velocity, monitored at the center of the turbine, together with the measurement of the blades’ angle of attack help show the effectiveness of the proposed pitching laws. The decrease in the angle of attack in the upstream half of a revolution leads to a significant increase in the power coefficient ($+40\%$) and to a better balance of the torque generated in the upstream and downstream halves. Both torque and thrust ripples are therefore significantly reduced. Full article

One of the challenges for single-screw micro-extrusion or additive manufacturing (AM), thus 3D printing, of polymers is controlling the melting efficiency so that energy and equipment costs can be minimized. Here, a numerical model is presented for AM process design, selecting acrylonitrile–butadiene–styrene (ABS) as viscoelastic reference polymer. It is demonstrated that AM melting is different compared to conventional melting due to variation in extrusion dimensions, leading to a different balance in heating by conduction and viscous heat dissipation as caused by the shearing between the melt layers in the associated film layer near the barrel. The thickness of this melt film layer is variable along the screw length, and it is shown that simplified models assuming an overall average value are too approximate. It is highlighted that the screw frequency, pitch angle and compression ratio are important process parameters to control the point of melt finalization. In addition, the power-law index reflecting the shear thinning nature of the polymer melt is showcased as a key parameter. Moreover, AM process results assuming constant and temperature dependent specific heat capacities and thermal conductivities are compared. The current work opens the door for on-line AM process control, addressing all relevant operating and material parameters. Full article

This paper proposes a new variable structure control scheme for a variable-speed, fixed-pitch ducted wind turbine, equipped with an annular, brushless permanent-magnet synchronous generator, considering a back-to-back power converter topology. The purpose of this control scheme is to maximise the aerodynamic power over the entire wind speed range, considering the mechanical safety limits of the ducted wind turbine. The ideal power characteristics are achieved with the design of control laws aimed at performing the maximum power point tracking control in the low wind speeds region, and the constant speed, power, and torque control in the high wind speed region. The designed control laws utilize a Luenberger observer for the estimation of the aerodynamic torque and a shallow neural network for wind speed estimation. The effectiveness of the proposed method was verified through tests in a laboratory setup. Moreover, a comparison with other solutions from the literature allowed us to better evaluate the performances achieved and to highlight the originality of the proposed control scheme. Full article

In this paper, an adaptive neural fault-tolerant tracking control scheme is presented for the yaw control of an unmanned-aerial-vehicle helicopter. The scheme incorporates a non-affine nonlinear system that manages actuator faults, input saturation, full-state constraints, and external disturbances. Firstly, by using a Taylor series expansion technique, the non-affine nonlinear system is transformed into an affine-form expression to facilitate the desired control design. In comparison with previous techniques, the actuator efficiency is explicit. Then, a neural network is considered to approximate unknown nonlinear functions, and a time-varying barrier Lyapunov function is employed to prevent transgression of the full-state variables using a backstepping technique. Robust adaptive control laws are designed to handle parameter uncertainties and unknown bounded disturbances to cut down the number of learning parameters and simplify the computational burden. Moreover, an auxiliary system is constructed to guarantee the pitch angle of the UAV helicopter yaw control system to satisfy the input constraint. Uniform boundedness of all signals in a closed-loop system is ensured via Lyapunov theory; the tracking error converges to a small neighborhood near zero. Finally, when the numerical simulations are applied to a yaw control of helicopter, the adaptive neural controller demonstrates the effectiveness of the proposed technique. Full article
