The rapid advancements in optical communication and sensing technologies have significantly increased the demand for advanced tunable spectral systems. This study presents a dual-band terahertz transmission and manipulation approach by leveraging the topologically protected properties of valley-topological photonic crystal edge states. The designed structure facilitates the excitation of the K valley within the range of 0.851–0.934 THz and the K′ valley from 1.604 to 1.686 THz, while also demonstrating anomalous refraction and birefringence. The calculated emission angles, derived through momentum matching, enable transitions between single-wave and dual-wave emissions and allow for precise angle control. The introduction of the liquid crystal material NJU-LDn-4 enables continuous tuning of the dual-band spectral range under a varying electric field, broadening the operating frequency bands to the ranges of 0.757–0.996 THz and 1.426–1.798 THz, respectively. These findings suggest promising applications in tunable filter design, optical communication, photonic computing, optical sensing, and high-resolution imaging, particularly in novel optical devices requiring precise control over spectral characteristics and light propagation. Full article

The refractive index is an important optical property of materials which can be used to understand the composition of materials. Therefore, refractive index sensing plays a vital role in biological diagnosis and therapy, material analysis, (bio)chemical sensing, and environmental monitoring. Conventional optical refractive index sensors based on optical fibers and ridge waveguides have relatively large sizes of a few millimeters, making them unsuitable for on-chip integration. Photonic crystals (PCs) have been used to significantly improve the compactness of refractive index sensors for on-chip integration. However, PC structures suffer from defect-introduced strong scattering, resulting in low transmittance, particularly at sharp bends. Valley photonic crystals (VPCs) can realize defect-immune unidirectional transmission of topological edge states, effectively reducing the scattering loss and increasing the transmittance. However, optical refractive index sensors based on VPC structures have not been demonstrated. This paper proposes a refractive index sensor based on a VPC Mach–Zehnder interferometer (MZI) structure with a high forward transmittance of 0.91 and a sensitivity of 1534%/RIU at the sensing wavelength of λ = 1533.97 nm within the index range from 1.0 to 2.0, which is higher than most demonstrated optical refractive index sensors in the field. The sensor has an ultracompact footprint of 9.26 μm × 7.99 μm. The design can be fabricated by complementary metal–oxide semiconductor (CMOS) fabrication technologies. Therefore, it will find broad applications in biology, material science, and medical science. Full article

We introduce a novel approach to achieve broadband rainbow trapping in a 2D photonic crystal (PC) platform. By exploiting the concept of valley PCs, we engineer a structure that supports robust topological edge states. A carefully designed rotational angle gradient along the edge state path induces frequency-dependent light localization, forming a topological rainbow with a significantly expanded bandwidth. This phenomenon of topological rainbow trapping is attributed to the interplay between valley-dependent topological edge states and the engineered rotational angle gradient. To further enhance light localization and broaden the trapping spectrum, we incorporate a graded radius profile in the bottom row of dielectric columns. Through a combination of rotational angle modulation and radius grading, we successfully realize broadband rainbow trapping with enhanced light localization. Our findings reveal a broad trapping bandwidth spanning from $0.8314c/a$ to $0.9205c/a$, showcasing the potential of this approach for applications in optical frequency filtering, sensing, and information processing. Full article

Topological edge states, emerging at boundaries between regions with distinct topological properties, enable unidirectional transmission with robustness against defects and disorder. However, achieving dual-band operation with high performance remains challenging. Here, we integrate dual-band topological edge states into a valley photonic crystal cavity operating in the mid-infrared region, leveraging triangular scatterers. A key contribution of this work is the simultaneous realization of ultra-high Q-factors (up to 6.1593 × 10⁹) and uniform mode distribution (inverse participation ratio < 2) across both bands. Moreover, the dual-band cavity exhibits exceptional defect tolerance. These findings provide a promising platform for mid-infrared photonic integration, paving the way for high-performance optical cavities in multifunctional photonic systems. Full article

This study introduces a topological photonic slow-light waveguide based on a honeycomb unit cell, which allows for the convenient tuning of the group index and bandwidth through the valley-locked effect. The topological properties of the unit cell are initially assessed. By adjusting the air gap in the topologically protected photonic crystal (PhC) waveguide, it is possible to continuously vary the group index from 47 to 6 and the normalized group index–bandwidth product (NGBP) from 0.495 to 0.573. Furthermore, the chiral propagation characteristics and propagation loss of the topologically protected PhC waveguide are evaluated. The findings indicate that the structure supports chiral propagation and maintains a high transmission rate even after passing through sharp corners. The results contribute to a deeper understanding of topological photonics and suggest potential for applications in future photonic technologies, such as dynamic topological photonic retarders and nonlinear localization enhancers. Full article

Optical computing offers advantages such as high bandwidth and low loss, playing a crucial role in signal processing, communication, and sensing applications. Traditional optical logic gates, based on nonlinear fibers and optical amplifiers, suffer from poor robustness and large footprints, hindering their on-chip integration. All-optical logic gates based on topological photonic crystals have emerged as a promising approach for developing robust and monolithic optical computing systems. Expanding topological photonic crystal logic gates from a single operating band to dual bands can achieve high throughput, significantly enhancing parallel computing capabilities. This study integrates the topological protection offered by valley photonic crystals with linear interference effects to design and implement seven optical computing logic gates on a silicon substrate. These gates, based on dual-band valley photonic crystal topological protection, include OR, XOR, NOT, NAND, NOR, and AND. The robustness of the implemented OR logic gates was verified in the presence of boundary defects. The results demonstrate that multi-band parallel computing all-optical logic gates can be achieved using topological photonic crystals, and these gates exhibit high robustness. The all-optical logic gates designed in this study hold significant potential for future applications in optical signal processing, optical communication, optical sensing, and other related areas. Full article

Spectral tunable technology has to meet the requirements of strong robustness and wide spectral range. We propose a method for the transmission and manipulation of infrared topological photonic crystal valley states based on tunable refractive index method that exhibits broad-spectrum and multi-band characteristics, along with a tunable emission angle. With this structure, different rotational directions of vortex light sources can independently excite the K valley and K′ valley within the frequency band ranging from 75.64 THz to 99.61 THz. At frequencies from 142.60 THz to 171.12 THz, it is possible to simultaneously excite both the K valley and K′ valley. The dual refractive index tunable design allows for the adjustment of the emission angle at a fixed frequency, enabling control over the independent excitation of either a single K valley or K′ valley, as well as their simultaneous excitation. This capability has significant implications for photonic computation and tunable filtering, offering enhanced operational flexibility and expanded functionality for future optical communications and integrated optical circuits. Full article

The combination of higher-order topological insulators and valley photonic crystals has recently aroused extensive attentions due to the great potential in flexible and efficient optical field manipulations. Here, we computationally propose a photonic device for the 1550 nm communication band, in which the topologically protected electromagnetic modes with high quality can be selectively triggered and modulated on demand. Through introducing two valley photonic crystal units without any structural alteration, we successfully achieve multi-dimensional coupled topological states thanks to the diverse electromagnetic characteristics of two valley edge states. According to the simulations, the constructed topological photonic devices can realize Fano lines on the spectrum and show high-quality localized modes by tuning the coupling strength between the zero-dimensional valley corner states and the one-dimensional valley edge states. Furthermore, we extend the valley-locked properties of edge states to higher-order valley topological insulators, where the selected corner states can be directionally excited by chiral source. More interestingly, we find that the modulation of multi-dimensional coupled photonic topological states with pseudospin dependence become more efficient compared with those uncoupled modes. This work presents a valuable approach for multi-dimensional optical field manipulation, which may support potential applications in on-chip integrated nanophotonic devices. Full article

Polarized optical microscopy (POM), scanning electron microscopy (SEM), and synchrotron microbeam wide-angle X-ray diffraction (WAXD) were used to investigate the mechanisms of periodic assemblies leading to ring-banded crystal aggregates with light-grating capacity for iridescence in poly (1,4-butylene adipate) (PBA) modulated with poly (ethylene oxide) (PEO). A critical finding is that the PBA crystal assembly on the top surface and in the interior constitutes a grating architecture, with a cross-bar pitch equaling the inter-band spacing. The inner lamellae are arranged perpendicularly to the substrate under the ridge region, where they scroll, bend, and twist 90° to branch out newly spawned lamellae to form the parallel lamellae under the valley region. The cross-hatch grating with a fixed inter-spacing in the PBA aggregated crystals is proved in this work to perfectly act as light-interference entities capable of performing iridescence functions, which can be compared to those widely seen in many of nature’s organic bio-species or inorganic minerals such as opals. This is a novel breakthrough finding for PBA or similar polymers, such as photonic crystals, especially when the crystalline morphology could be custom-made and modulated with a second constituent. Full article

The topological nanophotonic wavelength router, which can steer light with different wavelength signals into different topological channels, plays a key role in optical information processing. However, no effective method has been found to realize such a topological nanophotonic device. Here, an on-chip topological nanophotonic wavelength router working in an optical telecom band is designed based on a topology optimization algorithm and experimentally demonstrated. Valley photonic crystal is used to provide a topological state in the optical telecom band. The measured topological wavelength router has narrow signal peaks and is easy for integration. This work offers an efficient scheme for the realization of topological devices and lays a foundation for the future application of topological photonics. Full article

Counting rate is an important factor for CdZnTe photon counting detectors as high-flux devices. Until recently, there has been a lack of knowledge on the relationship between X-ray photocurrent response and the photon counting performance of CdZnTe detectors. In this paper, the performance of linear array 1 × 16-pixel CdZnTe photon counting detectors operated under different applied biases is investigated. The relation between experimental critical flux and applied bias show an approximate quadratic dependence, which agrees well the theoretical prediction. The underlying relationship among X-ray photocurrents, carrier transport properties, and photon counting performance was obtained by analyzing X-ray current–voltage and time current curves. The typical X-ray photocurrent curve can be divided into three regions, which may be explained by the photoconductive gain mechanism and electric field distortion characteristics. To keep CdZnTe photon counting detectors working in a “non-polarized state”, the applied bias should be set on the left side of the “valley region” (high bias direction) in the X-ray I-V curves. This provides an effective measurement for determining the proper working bias of CdZnTe detectors and screening photon counting detector crystals. Full article

A novel twin-core photonic crystal fiber-based sensor for simultaneous measurement of curvature, strain and temperature is proposed. The fiber sensor is constructed by splicing the homemade twin-core photonic crystal fiber between two segments of single mode fiber. Affected by the coupling between two cores, the transmission spectrum of the fiber sensor has different wavelength responses to curvature, strain, and temperature. The maximal sensitivities to curvature, strain and temperature are 10.89 nm/m⁻¹, 1.24 pm/με and 73.9 pm/°C, respectively. Simultaneous measurement of curvature, strain and temperature can be achieved by monitoring the wavelength shifts of selected valleys in the transmission spectrum. Contrast experiment based on traditional twin-core fiber is carried out. Experimental results demonstrate that twin-core photonic crystal fiber-based sensor has higher sensitivity and better linearity than traditional twin-core fiber-based sensor. Full article

Group-IV semiconductors, which provide the leading materials platform of micro- electronics, are generally unsuitable for light emitting device applications because of their indirect- bandgap nature. This property currently limits the large-scale integration of electronic and photonic functionalities on Si chips. The introduction of tensile strain in Ge, which has the effect of lowering the direct conduction-band minimum relative to the indirect valleys, is a promising approach to address this challenge. Here we review recent work focused on the basic science and technology of mechanically stressed Ge nanomembranes, i.e., single-crystal sheets with thicknesses of a few tens of nanometers, which can sustain particularly large strain levels before the onset of plastic deformation. These nanomaterials have been employed to demonstrate large strain-enhanced photoluminescence, population inversion under optical pumping, and the formation of direct-bandgap Ge. Furthermore, Si-based photonic-crystal cavities have been developed that can be combined with these Ge nanomembranes without limiting their mechanical flexibility. These results highlight the potential of strained Ge as a CMOS-compatible laser material, and more in general the promise of nanomembrane strain engineering for novel device technologies. Full article
