Search Results (21)

Control of elbow exoskeletons using muscular signals, although promising for the rehabilitation of millions of patients, has not yet been widely commercialized due to challenges in real-time intention estimation and management of dynamic uncertainties. From a practical perspective, millions of patients with stroke, spinal cord injury, or neuromuscular disorders annually require active rehabilitation, and elbow exoskeletons with precise and safe motion intention tracking capabilities can restore functional independence, reduce muscle atrophy, and lower treatment costs. In this research, an intelligent control framework was developed for an elbow joint exoskeleton, designed with the aim of precise and safe real-time tracking of the user’s motion intention. The proposed framework consists of two main stages: (a) real-time estimation of desired joint angle (as a proxy for movement intention) from High-Density Surface Electromyography (HD-sEMG) signals using an LSTM network and (b) implementation and comparison of three PID, impedance, and sliding mode controllers. A public EMG dataset including signals from 12 healthy individuals in four isometric tasks (flexion, extension, pronation, supination) and three effort levels (10, 30, 50 percent MVC) is utilized. After comprehensive preprocessing (Butterworth filter, 50 Hz notch, removal of faulty channels) and extraction of 13 time-domain features with 99 percent overlapping windows, the LSTM network with optimal architecture (128 units, Dropout, batch normalization) is trained. The model attained an RMSE of 0.630 Nm, R² of 0.965, and a Pearson correlation of 0.985 for the full dataset, indicating a 47% improvement in R² relative to traditional statistical approaches, where EMG is converted to desired angle via joint stiffness. An assessment of 12 motion–effort combinations reveals that the sliding mode controller consistently surpassed the alternatives, achieving the minimal tracking errors (average RMSE = 0.21 Nm, R² ≈ 0.96) and showing superior resilience across all tasks and effort levels. The impedance controller demonstrates superior performance in flexion/extension (average RMSE ≈ 0.22 Nm, R² > 0.94) but experiences moderate deterioration in pronation/supination under increased loads, while the classical PID controller shows significant errors (RMSE reaching 17.24 Nm, negative R² in multiple scenarios) and so it is inappropriate for direct myoelectric control. The proposed LSTM–sliding mode hybrid architecture shows exceptional accuracy, robustness, and transparency in real-time intention monitoring, demonstrating promising performance in offline simulation, with potential for real-time clinical applications pending hardware validation for advanced upper-limb exoskeletons in neurorehabilitation and assistive applications. Full article

Full use of the upper limb is necessary to carry out most tasks of daily life. Upper limb deficiencies, whether through complete or incomplete paralysis, inevitably lead to a loss of autonomy. Assistive orthoses are a potential method for restoring some autonomy. Pronation and supination, the turning of the wrist relative to the elbow, receives less focus than other joint movements in the arm. First, the utility of this degree-of-freedom in the arm is less obvious. Second, when compared to flexion and extension of the elbow, wrist prono-supination has no clear center of rotation due to the combined movement of the ulna and the radius bones as they cross and uncross in the forearm. This paper presents initial work in the design of a mechanism for a portable assistive orthosis that is expected to include powered prono-supination. The component proposed in this work is based on a spherical mechanism architecture. The capacity of these mechanisms to have a hollow center and to produce paths that follow arcs on spheres makes them worth consideration in this application. An optimization was carried out to perform path generation of a single spherical four-bar with the intent of replicating it three times to create the device proposed in this work. The mechanical design was modeled and a conceptual prototype was constructed to perform preliminary operational evaluations. Full article

The present study aims to investigate the multi-year effects (5 years) of individualized whole-body vibration (WBV) on locomotion, postural control, and handgrip strength in a 68-year-old man with relapse remitting multiple sclerosis (PwRRMS). The dose–response relationship induced by a single session was quantified by determining the surface electromyographic activity (sEMG) of the participant. The participant wore an orthosis to limit the lack of foot dorsiflexion in the weakest limb during walking in daily life. The gait alteration during walking was assessed at 1, 2 and 3 km/h (without the orthosis) through angle–angle diagrams by quantifying the area, perimeter and shape of the loops, and the sEMG of leg muscles was recorded in both limbs. The evaluation of postural control was conducted during upright standing by quantifying the displacement of the center of pressure (CoP). The handgrip strength was assessed by measuring the force–time profile synchronized with the sEMG activity of upper arm muscles. The participant improved his ability to walk at higher speeds (2–3 km/h) without the orthosis. There were greater improvements in the area and perimeter of angle–angle diagrams for the weakest limb (Δ = 36–51%). The sEMG activity of the shank muscles increased at all speeds, particularly in the tibialis anterior of weakest limbs (Δ = 10–68%). The CoP displacement during upright standing decreased (Δ = 40–60%), whereas the handgrip strength increased (Δ = 32% average). Over the 5-year period of intervention, the individualized WBV improved locomotion, postural control and handgrip strength without side effects. Future studies should consider the possibility of implementing an individualized WBV in PwRRMS. Full article

Upper limb assistive exoskeletons help stroke patients by assisting arm movement in impaired individuals. However, effective control of these systems to help stroke survivors is a complex task. In this paper, a novel approach is proposed to enhance the control of upper limb assistive exoskeletons by using torque estimation and prediction in a proportional–integral–derivative (PID) controller loop to more optimally integrate the torque of the exoskeleton robot, which aims to eliminate system uncertainties. First, a model for torque estimation from Electromyography (EMG) signals and a predictive torque model for the upper limb exoskeleton robot for the elbow are trained. The trained data consisted of two-dimensional high-density surface EMG (HD-sEMG) signals to record myoelectric activity from five upper limb muscles (biceps brachii, triceps brachii, anconeus, brachioradialis, and pronator teres) during voluntary isometric contractions for twelve healthy subjects performing four different isometric tasks (supination/pronation and elbow flexion/extension) for one minute each, which were trained on long short-term memory (LSTM), bidirectional LSTM (BLSTM), and gated recurrent units (GRU) deep neural network models. These models estimate and predict torque requirements. Finally, the estimated and predicted torque from the trained network is used online as input to a PID control loop and robot dynamic, which aims to control the robot optimally. The results showed that using the proposed method creates a strong and innovative approach to greater independence and rehabilitation improvement. Full article

Background: Finger orthoses are essential for treating injuries, deformities, and disorders of the upper limbs by supporting, immobilizing, or correcting deformities. Recent advances in three-dimensional (3D) printing have significantly enhanced precision and customization compared to traditional fabrication methods such as thermoplastic molding, plaster or fiberglass casting, and the use of prefabricated splints. Methods: The present review was conducted using PubMed, Scopus, and other databases with keywords such as “hand therapy”, “additive manufacturing”, “finger and thumb”, and “orthosis”. Only English-language publications were considered, with a primary focus on articles published between 2010 and 2025. Key themes were identified and categorized into conditions necessitating finger orthoses, types and classifications, ergonomic design considerations, and advancements in additive manufacturing. Results: Finger orthoses address musculoskeletal injuries, inflammatory diseases, and neuromuscular disorders. Three-dimensional printing provides enhanced customization, reduced material waste, rapid prototyping, and the ability to create complex geometries, improving patient comfort and functionality. Conclusions: Finger orthoses effectively treat various conditions by supporting and stabilizing fingers. A thorough understanding of anatomy, biomechanics, and fabrication methods is crucial for achieving functional and comfortable designs. Three-dimensional printing offers a transformative approach to producing lightweight, customizable, and cost-effective orthoses, enabling innovative and personalized solutions. By bridging clinical needs and design strategies, this review may guide future innovations in patient-specific orthotic development. Full article

Purpose: The effectiveness of the customised solutions compared to the conventional ones and the emergence of advanced production technologies, such as Additive Manufacturing (AM) techniques, strengthened the trend towards an enhanced individualization of the clinical treatments. In the present research, the value of topological optimisation (TO) in the manufacturing process of tailor-made orthopaedic appliance (upper-limb orthosis) was analysed. Methodology: From the morphology of a patient’s arm, orthotic models were developed. Nonparametric optimization (Simulia Tosca) was performed, based on the Finite Element Analysis (FEA) program (Abaqus), and contributed to the development of TO orthotic models with diverse levels of volume reduction fraction. The modelling and manufacturing framework for customising orthotic solutions was evaluated with a discussion on the feasibility of lightweight and high-performance products, encompassing production time and cost. Pilot products were produced with a Material Extrusion (MEX) printer. Findings: TO proved to be a practical and valuable approach for the advanced customisation of orthopaedic devices, offering lightweight solutions able to withstand stresses also during patient rehabilitation and remission. From the rapid prototyping perspective, specific strategies must be adopted to prevent the escalation of production costs and time. Originality: The research delves into the overall benefit of implementing an advanced modelling technique within the context of manufacturing highly customised orthoses, analysing how TO activity impacts the rapid prototyping process. Beyond product evaluation, the analysis explores broader implications, including the assessment of feasibility and the development of strategies for integrating the approach into clinical workflows and hospital settings. Full article

Arm and hand function play a critical role in the successful completion of everyday tasks. Lost function due to neurological impairment impacts millions of lives worldwide. Despite improvements in the ability to assess and rehabilitate arm deficits, knowledge about underlying sources of impairment and related sequela remains limited. The comprehensive assessment of function requires the measurement of both biomechanics and neuromuscular contributors to performance during the completion of tasks that often use multiple joints and span three-dimensional workspaces. To our knowledge, the complexity of movement and diversity of measures required are beyond the capabilities of existing assessment systems. To bridge current gaps in assessment capability, a new exoskeleton instrument is developed with comprehensive bilateral assessment in mind. The development of the BiLateral Upper-limb Exoskeleton for Simultaneous Assessment of Biomechanical and Neuromuscular Output (BLUE SABINO) expands on prior iterations toward full-arm assessment during reach-and-grasp tasks through the development of a dual-arm and dual-hand system, with 9 active degrees of freedom per arm and 12 degrees of freedom (six active, six passive) per hand. Joints are powered by electric motors driven by a real-time control system with input from force and force/torque sensors located at all attachment points between the user and exoskeleton. Biosignals from electromyography and electroencephalography can be simultaneously measured to provide insight into neurological performance during unimanual or bimanual tasks involving arm reach and grasp. Design trade-offs achieve near-human performance in exoskeleton speed and strength, with positional measurement at the wrist having an error of less than 2 mm and supporting a range of motion approximately equivalent to the 50th-percentile human. The system adjustability in seat height, shoulder width, arm length, and orthosis width accommodate subjects from approximately the 5th-percentile female to the 95th-percentile male. Integration between precision actuation, human–robot-interaction force-torque sensing, and biosignal acquisition systems successfully provide the simultaneous measurement of human movement and neurological function. The bilateral design enables use with left- or right-side impairments as well as intra-subject performance comparisons. With the resulting instrument, the authors plan to investigate underlying neural and physiological correlates of arm function, impairment, learning, and recovery. Full article

Upper-limb spasticity, frequent after central nervous system lesions, is typically treated with botulinum neurotoxin type A (BoNT-A) injections to reduce muscle tone and increase range of motion. However, performing adjunct physical therapy post-BoNT-A can be challenging due to residual weakness or spasticity. This study evaluates the feasibility of hand therapy using a robotic hand orthosis (RELab tenoexo) with a mobile phone application as an adjunct to BoNT-A injections. Five chronic spastic patients participated in a two-session pilot study. Functional (Box and Block Test (BBT), Action Research Arm Test (ARAT)), and muscle tone (Modified Ashworth Scale (MAS)) assessments were conducted to assess functional abilities and impairment, along with usability evaluations. In the first session, subjects received BoNT-A injections, and then they performed a simulated unsupervised therapy session with the RELab tenoexo in a second session a month later. Results showed that BoNT-A reduced muscle tone (from 12.2 to 7.4 MAS points). The addition of RELab tenoexo therapy was safe, led to functional improvements in four subjects (two-cube increase in BBT as well as 2.8 points in grasp and 1.3 points in grip on ARAT). Usability results indicate that, with minor improvements, adjunct RELab tenoexo therapy could enhance therapy doses and, potentially, long-term outcomes. Full article

This paper investigated the feasibility of using 3D printing processes, specifically material extrusion (MEX) and vat photopolymerization (DLP—Digital Light Processing), to produce customized wrist–hand orthoses. Design, printability, and usability aspects were addressed. It was found that minimizing printing time for orthoses with intricate shapes, ventilation pockets, and minimal thickness is difficult. The influence of build orientation and process parameters, such as infill density, pattern, layer thickness, and wall thickness, on printing time for ten parameter configurations of orthoses in both ready-to-use and flat thermoformed shapes was examined. The findings revealed that the optimized orientations suggested by Meshmixer and Cura (Auto-orient option) did not reliably yield reduced printing times for each analyzed orthoses. The shortest printing time was achieved with a horizontal orientation (for orthoses manufactured in their ready-to-use form, starting from 3D scanning upper limb data) at the expense of surface quality in contact with the hand. For tall and thin orthoses, 100% infill density is recommended to ensure mechanical stability and layer fill, with caution required when reducing the support volume. Flat and thermoformed orthoses had the shortest printing times and could be produced with lower infill densities without defects. For the same design, the shortest printing time for an orthosis 3D-printed in its ready-to-use form was 8 h and 24 min at 60% infill, while the same orthosis produced as flat took 4 h and 37 min for the MEX process and half of this time for DLP. Usability criteria, including perceived immobilization strength, aesthetics, comfort, and weight, were evaluated for seven orthoses. Two healthy users, with previous experience with traditional plaster splints, tested the orthoses and expressed satisfaction with the 3D-printed designs. While the Voronoi design of DLP orthoses was visually more appealing, it was perceived as less stiff compared to those produced by MEX. Full article

Three-dimensional printing—especially with fused deposition modeling (FDM)—is widely used in the medical field as it enables customization. FDM is versatile owing to the availability of various materials, but selecting the appropriate material for a certain application can be challenging. Understanding materials’ mechanical behaviors, particularly those of polymeric materials, is vital to determining their suitability for a given application. Physical testing with universal testing machines is the most used method for determining the mechanical behaviors of polymers. This method is resource-intensive and requires cylinders for compression testing and unique dumbbell-shaped specimens for tensile testing. Thus, a specialized fixture must be designed to conduct mechanical testing for the customized orthosis, which is costly and time-consuming. Finite element (FE) analysis using an appropriate material model must be performed to identify the mechanical behaviors of a customized shape (e.g., an orthosis). This study analyzed three material models, namely the Bergström–Boyce (BB), three-network (TN), and three-network viscoplastic (TNV) models, to determine the mechanical behaviors of polymer materials for personalized upper limb orthoses and examined three polymer materials: PLA, ABS, and PETG. The models were first calibrated for each material using experimental data. Once the models were calibrated and found to fit the data appropriately, they were employed to examine the customized orthosis’s mechanical behaviors through FE analysis. This approach is innovative in that it predicts the mechanical characteristics of a personalized orthosis by combining theoretical and experimental investigations. Full article

This article proposes the integration of two novel aspects into the production of 3D-printed customized wrist-hand orthoses. One aspect involves the material, particularly Colorfabb varioShore thermoplastic polyurethane (TPU) filament with an active foaming agent, which allows adjusting the 3D-printed orthoses’ mechanical properties via process parameters such as printing temperature. Consequently, within the same printing process, by using a single extrusion nozzle, orthoses with varying stiffness levels can be produced, aiming at both immobilization rigidity and skin-comfortable softness. This capability is harnessed by 3D-printing the orthosis in a flat shape via material extrusion-based additive manufacturing, which represents the other novel aspect. Subsequently, the orthosis conforms to the user’s upper limb shape after secure attachment, or by thermoforming in the case of a bi-material solution. A dedicated design web app, which relies on key patient hand measurement input, is also proposed, differing from the 3D scanning and modeling approach that requires engineering expertise and 3D scan data processing. The evaluation of varioShore TPU orthoses with diverse designs was conducted considering printing time, cost, maximum flexion angle, comfort, and perceived wrist stability as criteria. As some of the produced TPU orthoses lacked the necessary stiffness around the wrist or did not properly fit the palm shape, bi-material orthoses including polylactic acid (PLA) inserts of varying sizes were 3D-printed and assessed, showing an improved stiffness around the wrist and a better hand shape conformity. The findings demonstrated the potential of this innovative approach in creating bi-material upper limb orthoses, capitalizing on various characteristics such as varioShore properties, PLA thermoforming capabilities, and the design flexibility provided by additive manufacturing technology. Full article

Stroke represents the third cause of long-term disability in the world. About 80% of stroke patients have an impairment of bio-motor functions and over half fail to regain arm functionality, resulting in motor movement control disorder with serious loss in terms of social independence. Therefore, rehabilitation plays a key role in the reduction of patient disabilities, and 3D printing (3DP) has showed interesting improvements in related fields, thanks to the possibility to produce customized, eco-sustainable and cost-effective orthoses. This study investigated the clinical use of 3DP orthosis in rehabilitation compared to the traditional ones, focusing on the correlation between 3DP technology, therapy and outcomes. We screened 138 articles from PubMed, Scopus and Web of Science, selecting the 10 articles fulfilling the inclusion criteria, which were subsequently examined for the systematic review. The results showed that 3DP provides substantial advantages in terms of upper limb orthosis designed on the patient’s needs. Moreover, seven research activities used biodegradable/recyclable materials, underlining the great potential of validated 3DP solutions in a clinical rehabilitation setting. The aim of this study was to highlight how 3DP could overcome the limitations of standard medical devices in order to support clinicians, bioengineers and innovation managers during the implementation of Healthcare 4.0. Full article

Orthoses are commonly prescribed to relieve symptoms for musculoskeletal and neurological conditions; however, patients stop wearing orthoses as recommended for many reasons. When considering the effectiveness of orthoses, there needs to be an objective way to monitor whether participants wear the orthosis as instructed, because if this is not followed, the orthoses will not work as intended. This review aimed to identify, summarise, and compare objective methods used to measure compliance with orthoses applied to the extremities. Databases (Scopus, Web of Science, Embase, CINAHL, and MEDLINE) were searched for eligible studies. Twenty-three studies were accepted in the final review, including five studies that employed upper limb orthoses, two that employed hip orthoses, and fifteen that employed lower limb orthoses. To measure compliance objectively, studies utilised temperature sensors, pressure sensors, accelerometers, a step counter, or a combination of sensors. All sensor types have their own advantages and disadvantages and should be chosen based on study-specific parameters. Sensor-derived monitoring provides quantitative, objective data that are beneficial in both clinical and research settings. The ideal solution to monitoring compliance would consist of both objective and user-reported aspects that, in combination, would provide an all-encompassing picture of the orthotic treatment prescribed. Full article

Parkinson’s disease (PD) is a chronic, neurodegenerative movement disorder, whose symptoms have a negative impact on quality of life and functionality. Although its main treatment is pharmacological, non-pharmacological aids such as the dynamic elastomeric fabric orthosis (DEFO) merit an evaluation. Our objective is to assess the DEFO in upper limb (UL) functional mobility and in the quality of life of PD patients. A total of 40 patients with PD participated in a randomized controlled crossover study, and were assigned to a control group (CG) and to an experimental group (EG). Both groups used the DEFO for two months, the experimental group the first two months of the study and the control group the last two. Motor variables were measured in the ON and OFF states at the baseline assessment and at two months. Differences from the baseline assessment were observed in some motor items of the Kinesia assessment, such as rest tremor, amplitude, rhythm or alternating movements in the ON and OFF states with and without orthosis. No differences were found in the unified Parkinson’s disease rating scale (UPDRS) or the PD quality-of-life questionnaire. The DEFO improves some motor aspects of the UL in PD patients but this does not translate to the amelioration of the standard of functional and quality-of-life scales. Full article

In this paper, the designs and manufacturing process of a powered upper limb orthosis are presented. The orthosis is an exoskeleton worn on one arm by the user and fixed to the trunk. The orthosis’ architecture, design, and manufacturing process are presented and discussed. Estimations of the ranges of movement related to daily living activities are presented. The preliminary tests to verify the functionality of the design show encouraging results. Full article
