Search Results (79)

Molybdenum disulfide is more attractive and valuable at the molecular level due to its unique structure and exceptional properties. Here, new-type MoS₂-ring chains are constructed and theoretically investigated for relevant electronic properties influenced by the length of the chain and the bias. Different from traditional wires, our findings demonstrate that the conductance of such a new-type chain presents unusually non-exponential decay with the length of the chain, with a particularly anomalous length of seven rings, which shows stronger equilibrium conductance than a shorter four-ring chain. Multi-peaks of electron transmission and delocalized electronic states contribute such uniqueness. Mo atoms play a vital role in electron transport. Essentially, a narrower “HOMO-LUMO” (the two closest energy levels to the Fermi level of MoS₂-ring chain) gap compensates for the lower device density of states of new-type molybdenum disulfide-ring chains. The usual electronic structure of a seven-ring chain is derived from its slightly arched structure and mainly originates from interference, which is the resonance occurring between the electrodes. Noticeably, the bias could greatly enhance conductance, which could reach 1000 times more than the equilibrium conductance. At a certain bias, the conductance of a seven-ring chain even exceeds the shortest one- or two-ring chain. Furthermore, the threshold voltage (at which the maximum conductance appears) gradually decreases with the length of the chain and eventually remains at 0.7 V. The valuable negative differential resistance (NDR) effect could be found in such a molecular chain, which becomes more obvious as the length rises until the seven-ring chain reaches the peak. Our findings shed light on the relations between electronic properties and the length of a new-type molybdenum disulfide-ring chain, and provide support for such new-type chains in applications of innovative low-power and controllable electronics. Full article

S1100QL and S1300QL steels are classified as fine-grained steels with a low-carbon martensitic structure. Tandem welding is a method of creating a joint by melting two electrode wires in a one-behind-the-other configuration. This article presents the effects of creating dissimilar joints, elements of varying thicknesses made from S1100QL and S1300QL steels. The analysis focused on temperature changes in the heat-affected zone (HAZ) during welding, as well as the macro and microstructure, and the properties of the joints created at welding speeds of 80, 90, and 100 cm/min. The shortest cooling time (t8/5) in the HAZ for S1300QL steel was 9.4 s, while the longest was 12.4 s. Thermal cycle simulations were performed for the analyzed materials, with a cooling time of 5 s. The test results demonstrated that TWIN welding was stable, and an optimum welding speed is 80 cm/min. The HAZ microstructure for the highest cooling speed (t8/5 = 5 s) of S1100QL steel contains, in addition to martensite, lower bainite, while S1300QL steel consists of martensite. Tempered martensite was also detected at slower cooling rates. For all speed variants, the impact energy is above 27 J at a test temperature of −40 °C. In turn, hardness tests showed that the base material for both steels has the highest hardness. However, the lowest hardness was found for the weld. Full article

The acquisition of electroencephalography (EEG) concurrently with functional magnetic resonance imaging (fMRI) requires a careful consideration of the health hazards resulting from interactions between the scanner’s electromagnetic fields and EEG recording equipment. The primary safety concern is excessive RF-induced heating of the tissue in the vicinity of electrodes. We have previously demonstrated that concurrent intracranial EEG (icEEG) and fMRI data acquisitions (icEEG-fMRI) can be performed with acceptable risk in specific conditions using a head RF transmit coil. Here, we estimate the potential additional heating associated with the addition of scalp EEG electrodes using a body transmit RF coil. In this study, electrodes were placed in clinically realistic positions on a phantom in two configurations: (1) icEEG electrodes only, and (2) following the addition of subdermal scalp electrodes. Heating was measured during MRI scans using a body transmit coil with a high specific absorption rate (SAR), TSE (turbo spin echo), and low SAR gradient-echo EPI (echo-planar imaging) sequences. During the application of the high-SAR sequence, the maximum temperature change for the intracranial electrodes was +2.8 °C. The addition of the subdural scalp EEG electrodes resulted in a maximum temperature change for the intracranial electrodes of 2.1 °C and +0.6 °C across the scalp electrodes. For the low-SAR sequence, the maximum temperature increase across all intracranial and scalp electrodes was +0.7 °C; in this condition, the temperature increases around the intracranial electrodes were below the detection level. Therefore, in the experimental conditions (MRI scanner, electrode, and wire configurations) used at our centre for icEEG-fMRI, adding six scalp EEG electrodes did not result in significant additional localised RF-induced heating compared to the model using icEEG electrodes only. Full article

This paper presents a comprehensive assessment of the accuracy of high-frequency (HF) earth meters in measuring the tower-footing ground resistance of transmission line structures, combining simulation and experimental results. The findings demonstrate that HF earth meters reliably estimate the harmonic grounding impedance ($R_{25\mathrm{k}\mathrm{H}\mathrm{z}}$) at their operating frequency, typically 25 kHz, for a wide range of soil resistivities and typical span lengths. For the analyzed tower geometries, the simulations indicate that accurate measurements are obtained for adjacent span lengths of approximately 300 m and 400 m, corresponding to configurations with one and two shield wires, respectively. Acceptable errors below 10% are observed for span lengths exceeding 200 m and 300 m under the same conditions. While the measured $R_{25\mathrm{k}\mathrm{H}\mathrm{z}}$ does not directly represent the resistance at the industrial frequency, it provides a meaningful measure of the grounding system’s impedance, enabling condition monitoring and the evaluation of seasonal or event-related impacts, such as damage after outages. Furthermore, the industrial frequency resistance can be estimated through an inversion process using an electromagnetic model and knowing the geometry of the grounding electrodes. Overall, the results suggest that HF earth meters, when correctly applied with the fall-of-potential method, offer a reliable means to assess the grounding response of high-voltage transmission line structures in most practical scenarios. Full article

One of the prospective methods of robotic welding with a consumable electrode in shield gas metal arc welding is the GMAW Rapid HF process (GRHF, HF-high frequency), in which welded joints with deep penetration welds are obtained thanks to the specially programmed welding characteristics of the arc. A pulsed frequency equalized to 5000 Hz was used to achieve consumable electrode arc stabilization and improve penetration. This work consists of two main sections, including the research and analysis of wire electrode melting and weld pool formation in the innovative GRHF process and its influences on joint strength and the economic advantages of welding. As a result of our research and strength tests, as well as an image analysis of phenomena occurring in the welding arc and weld pool, assumptions were developed about the use of the GRHF process, which is characterized by deep penetration welds without welding imperfections that reduce the quality of the welded joints and their strength. Welding conditions and parameters leading to welded joints characterized by high relative strength related to the weight of the used filler material were proposed. As a result of our research, it was found that the use of welding processes with deep penetration leads to material savings related to the reduced consumption of filler materials while maintaining the required high strength of welded joints. Savings of filler materials reaching 80% were achieved compared with hitherto used methods. At the same time, the maximum load-carrying capacity of welding joints was maintained. Full article

In recent years, there has been a growing interest in and research efforts enabling the use of composite conductive 3D-printing filaments in material extrusion additive manufacturing processes, which can bestow novel and distinctive functions onto 3D-printed components. These composite filaments, in general blending a thermoplastic with carbon-based materials, open up new research and development avenues in electronics and sensors. Additionally, by exploring the underlying piezoresistivity of conductive filaments, they also enable the creation of novel structural components possessing integrated (intrinsic) self-sensing capabilities that can be effectively employed in structural health monitoring of critical components. However, piezoresistivity features require measuring the electrical resistance of structures made with these conductive filaments, which might be hard, especially when measuring small changes in resistance caused by mechanical loads on the component. The goal of this study is to compare the two- and four-probe methods for measuring the electrical resistance of 3D-printed parts and to look at how different types of electrical contacts and bonding may affect electrical resistivity measurement and self-sensing capabilities. The research is conducted on 3D-printed specimens using a conductive composite PLA (polylactic acid) filament from Protopasta. The efficiency of each method and the influence of the bonding and electrodes on the measurements are experimentally analyzed and discussed. Our experiments reveal that the four-probe method consistently yields resistivity values between 15.35 and 16.38 $\mathrm{\Omega }·$cm, while the two-probe method produces significantly higher values (up to 52.92–62.37 $\mathrm{\Omega }·$cm), underscoring the impact of wire and contact resistances on measurement accuracy. Full article

The application of a high-voltage electric field (HVEF) is crucial for mitigating the growth and reproduction of pathogenic microorganisms on solid surfaces. However, the electric field distribution of HVEF in the undischarged state and bactericidal effect remain largely unexplored. Herein, a unipolar wire–plate HVEF device was developed and its field strength distribution was simulated by COMOSL software (version 6.2). The simulation analysis revealed that the electric field strength and space charge density of HVEF in the undischarged state reached a maximum at the discharge electrode and a minimum at the middle of the two electrode wires. The electric field strength and the inhomogeneity of electric intensity distribution also decreased with the increase in electrode spacing. The sterilization effect of E. coli was positively correlated with voltage and treatment time, but negatively correlated with electrode spacing, which was consistent with the change in the field strength of the simulation results. When the voltage was −12.5 kv and electrode spacing 2.7 cm, the sterilization rate was 98.03% at 60 min. In addition, the increase in treatment temperature and relative humidity also affected the electric field distribution, thereby improving the bactericidal effect. Our results revealed that the electric field distribution was the main factor affecting the sterilization effect of HVEF, which provided theoretical support for the design of HVEF sterilization equipment and the optimization of sterilization performance Full article

This study proposes a high-frequency Pulse Amplitude-Modulation Temporal-Interference (PAM-TI) current stimulation device, which utilizes two sets of Amplitude-modulated transcranial alternating current stimulation (AM-tACS): one AM frequency at f0 (where f0 = 2 kHz) (source 1) and the other AM frequency at f1 = f0 + $△$f (where f1 = 2.01 kHz) (source 2), to generate a $△$f (where $△$f = 10 Hz) envelope modulated at a fc (where fc = 100 kHz) high carrier frequency. The high carrier frequency reduces body impedance and conserves more stimulation power, allowing it to penetrate the skin and reach the subcutaneous region. The proposed PAM-TI technique elevates the two current sources to a 100 kHz carrier frequency. Instead of the challenges associated with generating high-frequency stimulation currents using an MCU and DAC, the proposed PAM-TI stimulation device achieves this by simply utilizing a pair of complementary pulse-width modulations (PWMs). The push–pull technique is employed to balance the charging currents between the anode and cathode, synchronizing the current timing of Source 1 and Source 2 under the fc modulation condition. To minimize signal attenuation, the PAM circuit is integrated directly into the electrode, ensuring the high-frequency signal is generated close to the body and preventing degradation from long wires. Additionally, a dry pin-type spring-loaded electrode is used to reduce interference caused by hair when placed on the head. The device’s validity and current directionality were verified using a scalp tissue-mimicking phantom composed of agar and saline. Full article

Intermetallic compounds from the Fe-Al system are attracting increasing attention due to their outstanding properties, including excellent mechanical performance, low density, corrosion, and oxidation resistance, as well as resistance to sulfidation, carburization, and wear at elevated temperatures. These unique characteristics make Fe-Al intermetallics promising candidates for high-temperature and harsh environmental applications. However, challenges such as brittleness and low plasticity have hindered their broader use. By exploring the impact of spray conditions on coating properties, this study contributes to enhancing the performance and functionality of Fe-Al coatings in industrial applications, where durability and resistance to extreme conditions are essential. This article presents the results of research on the production of composite coatings from the Fe-Al system with in situ fabricated intermetallic phases. For this purpose, arc spraying in an inert gas was used. The coating manufacturing process was carried out by simultaneously melting two different electrode filler wires, aluminum and steel, in a stream of argon. The obtained coatings were subjected to tests of roughness, adhesion to the substrate, and microstructure. It was shown that both the roughness and adhesion to the substrate of coatings sprayed in air are higher than those sprayed in argon. The increase in roughness results from the greater oxidation of coatings sprayed in air, while better adhesion is the result of the formation of coatings at a higher temperature. Metallographic studies have shown that during the spraying process, the in situ synthesis of intermetallic phases occurred. The results showed the local occurrence of intermetallic phases from the Fe-Al system. Among the two dominant phases, i.e., Al and the Fe alloy, there are also the following phases: FeAl₃, FeAl₂, and Fe₂Al₅. Furthermore, in layers sprayed in an inert atmosphere, the share of oxides is small. Full article

Engineers, geomorphologists, and ecologists acknowledge the need for temporally and spatially resolved measurements of sediment clogging (also known as colmation) in permeable gravel-bed rivers due to its adverse impacts on water and habitat quality. In this paper, we present a novel method for non-destructive, real-time measurements of pore-scale sediment deposition and monitoring of clogging by using wire-mesh sensors (WMSs) embedded in spheres, forming a smart gravel bed (GravelSens). The measuring principle is based on one-by-one voltage excitation of transmitter electrodes, followed by simultaneous measurements of the resulting current by receiver electrodes at each crossing measuring pores. The currents are then linked to the conductive component of fluid impedance. The measurement performance of the developed sensor is validated by applying the Maxwell Garnett and parallel models to sensor data and comparing the results to data obtained by gamma ray computed tomography (CT). GravelSens is tested and validated under varying filling conditions of different particle sizes ranging from sand to fine gravel. The close agreement between GravelSens and CT measurements indicates the technology’s applicability in sediment–water research while also suggesting its potential for other solid–liquid two-phase flows. This pore-scale measurement and visualization system offers the capability to monitor clogging and de-clogging dynamics within pore spaces up to 10,000 Hz, making it the first laboratory equipment capable of performing such in situ measurements without radiation. Thus, GravelSens is a major improvement over existing methods and holds promise for advancing the understanding of flow–sediment–ecology interactions. Full article

The integrity of the machined surface in precision wire electrical discharge machining (WEDM) of electrically conductive materials is one of the most important quality indicators. The integrity parameters of the machined surface are primarily monitored in terms of micro and macro geometry parameters. This paper presents the results obtained as a part of experimental research aimed at evaluating surface crack density (SCD) when machining EN HS6-5-2C using WEDM technology. The aim was to find a combination of main technological parameters (MTP) in order to minimize the qualitative indicators SCD and Ra of the eroded surface. The results of experimental research within the framework of the evaluation of SCD and Ra indicators were processed using the Taguchi method. The integrity of the eroded surface was examined by scanning digital microscope (SDM) after application of full and multiple offset cuts with an AC Brass LP 1000 brass wire electrode. Based on the experimental measurements performed, significant facts were discovered. It was found that the largest surface integrity defects are present after the application of full cuts and the first two offset cuts. At the same time, it was found that lower values of the SCD parameter in WEDM of EN HS6-5-2C steel were recorded at thicknesses above 130.0 mm. The SCD parameter was also confronted with the Ra parameter, and it was found that they are significantly influenced by MTP. The higher value of the peak current I (19 A) and the longer duration of the discharge t_on (32 μs) result in an increase in the value of the SCD parameter from 0.005 μm·μm⁻² to 0.0256 μm·μm⁻². The resulting solutions are mathematical regression models (MRM), which allow the prediction of both monitored qualitative indicators with respect to their minimization. Full article

A numerical study was performed to analyze the particle deposition of a cold spray process for the preparation of nickel electrocatalysts used in the Hydrogen Evolution Reaction (HER). The study focused on the creation of fin-shaped geometries with an optimal porosity on the electrode surface using a mask located between the nozzle exit and the substrate. Computational Fluid Dynamics (CFD) was performed on a three-dimensional high-pressure nozzle, with nickel powder used as the injection feedstock. The behavior of particles was effectively modeled through a two-way coupled Eulerian–Lagrangian approach. As per the parametric study, four masks of varying wire thicknesses and opening sizes were investigated. The masks were placed at 4 mm increments from the nozzle exit, with the substrate placed at standoff distances (SODs) of 10 mm and 20 mm. To capture the effects of the gas inlet operating conditions, two different nozzle inlet conditions were analyzed (2 MPa and 400 °C, 4 MPa and 800 °C). It was found that the nozzle inlet operating condition had the most significant impact, as it relates to the particle velocity and powder deposition. The high-pressure operating condition resulted in a deposition efficiency (DE) greater than 99.9% for all the test cases, with nearly all the impacted particles depositing on the substrate. For the medium-pressure operating condition, the DE increased linearly as the mask SOD was increased, due to the increase in the particle velocity upon impact. Full article

Bioimpedance imaging aims to generate a 3D map of the resistivity and permittivity of biological tissue from multiple impedance channels measured with electrodes applied to the skin. When the electrodes are distributed around the body (for example, by delineating a cross section of the chest or a limb), bioimpedance imaging is called electrical impedance tomography (EIT) and results in functional 2D images. Conventional EIT systems rely on individually cabling each electrode to master electronics in a star configuration. This approach works well for rack-mounted equipment; however, the bulkiness of the cabling is unsuitable for a wearable system. Previously presented cooperative sensors solve this cabling problem using active (dry) electrodes connected via a two-wire parallel bus. The bus can be implemented with two unshielded wires or even two conductive textile layers, thus replacing the cumbersome wiring of the conventional star arrangement. Prior research demonstrated cooperative sensors for measuring bioimpedances, successfully realizing a measurement reference signal, sensor synchronization, and data transfer though still relying on individual batteries to power the sensors. Subsequent research using cooperative sensors for biopotential measurements proposed a method to remove batteries from the sensors and have the central unit supply power over the two-wire bus. Building from our previous research, this paper presents the application of this method to the measurement of bioimpedances. Two different approaches are discussed, one using discrete, commercially available components, and the other with an application-specific integrated circuit (ASIC). The initial experimental results reveal that both approaches are feasible, but the ASIC approach offers advantages for medical safety, as well as lower power consumption and a smaller size. Full article

Obstructive sleep apnea (OSA) is a prevalent source of sleep-disordered breathing. OSA is most commonly associated with dysfunctions in the genioglossus (GG) muscle. In this study, we present the first version of a medical device that produces an electromyogram (EMG) of the GG. The prototype is composed of a (custom-made) 3D-printed mouthpiece. Impressions were taken for the lower arch and scanned with a lab scanner to be converted into digital impressions. ExoCad software was used to design the appliance. Fusion 360 software was then used to modify the design and create tubes to house the electrodes in a bilateral configuration to secure excellent and continuous contact with the GG muscle. Silver–silver chloride electrodes were incorporated within the appliance through the created tubes to produce a muscle EMG. In this preliminary prototype, an EMG amplifier was placed outside the mouth, and isolated electric wires were connected to the amplifier input. To test the design, we ran experiments to acquire EMG signals from a group of OSA patients and a control group in wakefulness. The GG EMGs were acquired from the participants for 60 s in a resting state whereby they rested their tongues without performing any movement. Then, the subjects pushed their tongues against the fontal teeth with steady force while keeping the mouth closed (active state). Several features were extracted from the acquired EMGs, and statistical tests were applied to evaluate the significant differences in these features between the two groups. The results showed that the mean power and standard deviation were higher in the control group than in the OSA group (p < 0.01). Regarding the wavelength during the active state, the control group had a significantly longer wavelength than the OSA group (p < 0.01). Meanwhile, the mean frequency was higher in the OSA group (p < 0.01) at rest. These findings support research that showed that impairment in GG activity continues in the daytime and does not only occur during sleep. Future research should focus on developing the device to be more user-friendly and easily used at home during wakefulness and sleep. Full article

Oxide layers on the surface of the aluminum alloys D16 and AMg6 and on arc coatings sprayed with electrode wires made of the alloys D16 and AMg6 were synthesized using plasma electrolytic oxidation (PEO). The microstructure, phase composition and micro-hardness of the PEO layers were studied. In addition to the two main phases (α-Al₂O₃ and γ-Al₂O₃), a small amount of a metastable crystalized Al_2.427O_3.64 phase was found in their structure. A comparison was made of the wear resistance and friction coefficients of the synthesized PEO layers during friction tests in pairs with other PEO layers, a galvanic chromium coating, cast iron, steels and bronze of the BrC30 type. The results of the friction tests for the various PEO layers on aluminum alloys in tribo-contact with high-hardness elements made of hardened or chrome-plated steel justify the possibility of their use in a friction pair. We experimentally showed the influence of glycerin additive in motor oil 15W30 on the change in the friction coefficient of the PEO layers synthesized on the aluminum alloys and on the arc-sprayed coatings on their surfaces in tribocouples with hardened steel. Full article
