This study examines how leading-edge inclination angles affect a two-stage centrifugal compressor’s aerodynamic performance using numerical and experimental methods. Five impellers with varied inclination configurations were designed for both stages. The results show that negative inclination improves the pressure ratio and efficiency under near-choke conditions, with greater enhancements in the low-pressure stage. Positive inclination significantly boosts the pressure ratio and efficiency under near-stall conditions, particularly in the low-pressure stage. Negative inclinations optimize blade loading and choke flow capacity, while effectively reducing incidence angle deviations induced by interstage pipeline distortion and decreasing outlet pressure fluctuation amplitude in the high-pressure stage. Positive inclinations delay flow separation, suppress tip leakage vortices, and extend the stall margin. Full article

Since the beginning of the 21st century, the supercritical carbon dioxide (sCO₂) Brayton cycle has emerged as a hot topic of research in the energy field. Among its key components, the sCO₂ compressor has received significant attention. In particular, axial-flow sCO₂ compressors are increasingly being investigated as power systems advance toward high power scaling. This paper reviews global research progress in this field. As for performance characteristics, currently, sCO₂ axial-flow compressors are mostly designed with large mass flow rates (>100 kg/s), near-critical inlet conditions, multistage configurations with relatively low stage pressure ratios (1.1–1.2), and high isentropic efficiencies (87–93%). As for internal flow characteristics, although similarity laws remain applicable to sCO₂ turbomachinery, the flow dynamics are strongly influenced by abrupt variations in thermophysical properties (e.g., viscosities, sound speeds, and isentropic exponents). High Reynolds numbers reduce frictional losses and enhance flow stability against separation but increase sensitivity to wall roughness. The locally reduced sound speed may induce shock waves and choke, while drastic variation in the isentropic exponent makes the multistage matching difficult and disperses normalized performance curves. Additionally, the quantitative impact of a near-critical phase change remains insufficiently understood. As for the experimental investigation, so far, it has been publicly shown that only the University of Notre Dame has conducted an axial-flow compressor experimental test, for the first stage of a 10 MW sCO₂ multistage axial-flow compressor. Although the measured efficiency is higher than that of all known sCO₂ centrifugal compressors, the inlet conditions evidently deviate from the critical point, limiting the applicability of the results to sCO₂ power cycles. As for design and optimization, conventional design methodologies for axial-flow compressors require adaptations to incorporate real-gas property correction models, re-evaluations of maximum diffusion (e.g., the DF parameter) for sCO₂ applications, and the intensification of structural constraints due to the high pressure and density of sCO₂. In conclusion, further research should focus on two aspects. The first is to carry out more fundamental cascade experiments and numerical simulations to reveal the complex mechanisms for the near-critical, transonic, and two-phase flow within the sCO₂ axial-flow compressor. The second is to develop loss models and design a space suitable for sCO₂ multistage axial-flow compressors, thus improving the design tools for high-efficiency and wide-margin sCO₂ axial-flow compressors. Full article

Dynamic compressors are widely used in many industrial sectors, such as air, land, and marine vehicle engines, aircraft environmental control systems (ECS), air-conditioning and refrigeration, gas turbines, gas compression and injection, etc. The data-driven formulas of mass flow rate and isentropic efficiency of dynamic compressors are required for the design, energy analysis, performance simulation, and control- and/or diagnosis-oriented dynamic simulation of such compressors and the related systems. This work develops data-driven models for predicting the performance of dynamic compressors, including empirical models for mass flow rate and isentropic efficiency, which have high prediction accuracy and broad application range. The performance maps of two multi-stage axial compressors of an aero engine and a centrifugal compressor of an aircraft ECS were chosen for evaluation of the existing empirical formulas and testing of the new models. There are 16 empirical models of mass flow rate and 14 empirical models of isentropic efficiency evaluated, and the results show that it is necessary to develop highly accurate empirical formulas both for mass flow rate and isentropic efficiency. With the data-driven method, two empirical models for mass flow rate and one for isentropic efficiency are developed. They are in general form, with some terms removable to make them simple while enhancing their applicability and prediction accuracy. The new models have much higher prediction accuracy than the best existing counterparts. The new mass flow rate models predict for the three compressors a mean absolute relative deviation (MAD) not greater than 1.3%, while the best existing models all have MAD > 2.0%. The new efficiency model predicts for the three compressors an MAD of 1.0%, 0.4%, and 1.9%, respectively, while the best existing model predicts for the three compressors an MAD of 1.8%, 0.8%, and 3.2%, respectively. Full article

Compressors and pumps are machines frequently used in petroleum and chemical industries for fluid transportation through flow systems to keep industrial processes running permanently. As their failure can produce costly disruption, developing fault detection and diagnosis tools is essential for accurately detecting and diagnosing faults. This research proposes a bi-dimensional representation of the vibration signal corresponding to the Mel Frequency Cepstral Coefficients (MFCC) and their first two derivatives as features. The pseudo-periodic nature of the fault signature in rotating machines is exploited to put forward an efficient and accurate patch-wise fault classification method. This approach enables the classification of 13 combined types of faults in a multi-stage centrifugal pump and 17 faults in a reciprocating compressor. Classification is performed using the Long Short-Term Memory (LSTM) network, the bidirectional Long Short-Term Memory (BiLSTM) neural network, and the Convolutional Neural Network (CNN). Accurate classification over 99% is attained, showing that the proposed feature extraction procedure correctly classifies a large set of faults simultaneously appearing in such rotating machines. Full article

The supercritical carbon dioxide (S-CO₂) Brayton cycle efficiency increases as the compressor inlet condition approaches the critical point. However, the thermodynamic properties of CO₂ vary dramatically near the critical point, and phase change is most likely to happen. Both cavitation and condensation bring about significant adverse effects on the performance of compressors. In this paper, the quantitative effects of nonequilibrium condensation and cavitation on the performance of an S-CO₂ centrifugal compressor with different inlet-relative entropy values are investigated. The properties of CO₂ were provided by the real-gas property table, and the nonequilibrium phase-change model was adopted. The numerical simulation method with the nonequilibrium phase-change model was validated in the Lettieri nozzle and Sandia compressor. Furthermore, simulations were carried out in a two-stage centrifugal compressor under conditions of various inlet-relative entropy values. The type of nonequilibrium phase change can be distinguished by inlet-relative entropy. Cavitation makes the choke mass flow rate decrease due to the drop in the speed of sound. Condensation mainly occurs on the leading edge of the main blade at a large mass flow rate, but cavitation occurs on the splitter. The condensation is more evenly distributed on the main blade, but the cavitation is mainly centered on the leading edge. Full article

Understanding the influence of environmental boundary parameters on the through-flow characteristics of two-stage supercharged centrifugal compressors is the key to maximizing the power recovery potential of diesel engines at high altitudes. In this paper, the influence of the compressor through-flow characteristics on the full-load thermal cycle performance of a diesel engine under variable altitude is studied by means of tests and simulation. The results show that with the increase in altitude, the range of stable work flow decreases, and the pressure ratio of the plugging point changes greatly with altitude. The efficiency of the compressor with the same mass flow point decreases, and the highest efficiency point moves in the direction of the small flow range. With the goal of maximizing the torque of the diesel engine under full load and low speed, the key geometric parameters of the variable-altitude through-flow characteristics of the two-stage supercharged compressor were optimized as follows: at the altitudes of 0 m, 2500 m, and 5500 m, the diesel engine torque increased by 5.89%, 3.78%, and 2.18%, respectively. Based on the optimization method of the compressor through-flow design, a new direction is provided to break through the research on the independent limitation of the diesel engine thermal cycle performance optimization and compressor flow control. Full article

This paper presents the development of high-specific-speed mixed flow/centrifugal compressor vaned diffusers. Specifically, the design of a test rig that will make the visualization of shock waves on diffuser vanes manageable is addressed in the current study. In this particular case, linearization of an existing state-of-the-art compressor stage was used. For the computational modeling, a series of RANS analyses were conducted to examine the flow characteristics of the two cases explored: a complete transonic cascade and an idealized periodic passage. The distinct behavior exhibited by each vane passage within the entire cascade offers the opportunity to analyze the shockwave structures across a mass flow range of ±9% around the design point. Overall, the pressure coefficient distributions and flow field patterns appear to align with the single-passage conditions, although there are some minor lateral wall influences, particularly in the first passage close to the suction lateral wall. However, because of the nature of the flow, which is characterized by high velocity and density differences near the vanes, the equivalent mass flow per individual passage was difficult to estimate. This may also be attributed to the small endwall axial vortices; nonetheless, for the purposes of this paper, this was of little consequence. Full article

The surge is a typical aerodynamic instability phenomenon in the compression system, which can lead to serious consequences such as engine performance degradation and structural damage. A deep understanding of the surge process can support the development of a compressor with a wider operating range. In this paper, an experimental study was carried out and high-responding pressure sensors were used to obtain the aerodynamic instability process and the post-surge characteristics of an axial–centrifugal compressor at design and off-design speeds. The evolution of the flow field and instability behavior before and after the surge were analyzed. The results showed that the inlet temperature change can reflect the aerodynamic instability to some extent, and as the operating condition moves from the choke to surge boundary, the inlet temperature undergoes a sudden increase at a certain condition and further increases with the decrease in mass flow rate. At the design speed, the instability of the combined compressor featured a deep surge with an obvious rotating stall behavior before its inception, and the amplitude of the stall cell was gradually enhanced, finally leading to the surge. At the off-design speed, affected by the stage mismatching, the axial stage mainly worked near the unstable operating condition. Therefore, the compressor successively experiences two modes of mild surge and deep surge, and the rotating stall can also be observed during the surge cycle. Full article

The decision-making process behind the selection of a gas turbine engine (GT) is crucial and must be made in accordance with economic, environmental, and technical requirements. This paper presents the relevant economic, exergoeconomic and exergoenvironmental analyses for four GT engines with different compressor configurations. The GT engine configurations are identified according to the type of compressor: axial, axial-centrifugal, two-stage centrifugal, and centrifugal-centrifugal. The performances of the four GT engines were validated against manufacturer supplied data using specialized software. The economic analysis, a detailed life cycle costing considering the cost to be paid per unit net power obtained from the GT, and subsequent shortest payback period showed that the GT with centrifugal-centrifugal compressor was most economically feasible. This was followed, in order, by the GT-axial, GT-axial-centrifugal, and finally the GT-two-stage centrifugal configuration, where the cost of ownership for a 20 year plan ranges between 8000 USD/kW to about 12,000 USD/kW at different operational scenarios during the life cycle costing. Exergoeconomic assessment provided useful information to enhance the cost-effectiveness of all four systems by evaluating each component separately. The axial-centrifugal configuration registered the lowest CO₂ emissions (about 0.7 kg/kWh); all environmental indicators confirmed it is the most environmentally friendly option. Full article

This study used computational fluid dynamics for low greenhouse effect refrigerant (R-513A) simulation analysis in the two-stage 150 USRT class oil-free centrifugal refrigerant compressor using integrated part load value (IPLV) and internal flow field. The compressor rotor speed and mass flow rate for the IPLV working conditions with various loads were planned using Stage 1 and Stage 2 simulations, respectively. The performance and flow field numerical simulation analyses for the two-stage centrifugal compressor is discussed. This study used Ansys-CFX software for numerical simulation analysis and the conservation form of a 3D steady-state Navier–Stokes equation set with the finite volume discretization method for computation. The computing mode produced better computing efficiency and flexible mesh setting using the k-omega (k-ω) model, which has better computational performance in the near wall boundary layer and low Reynolds number flow field (used as the turbulence model) for simulation. The R-513A refrigerant property setting was calculated using the Soave–Redlich–Kwong gas equation. This study discusses the shaft work, pressure ratio, and isentropic efficiency and also describes the main research findings with the meridional pressure, isentropic efficiency contour maps, and flow field velocity vector diagrams. According to the numerical simulation results, in Stage 1 and Stage 2 simulations, the isentropic efficiency produced the highest numerical results in the 75% load case, which are 88.19% and 89.06%, respectively. The isentropic efficiency decreased to 75.93% and 82.26%, respectively, in the 25% load case. The flow field velocity vector diagram shows that in the 25% load case, there was back-flow field distribution near the impeller shroud. The compressor performance was also analyzed. Full article

At present, two-stage centrifugal compressors based on air bearing and high-speed motor technology are widely used in automotive hydrogen fuel cells. The low-pressure stage and high-pressure stage of the compressor are directly connected through an interstage pipeline, thus the structure of the interstage pipeline has an important influence on the aerodynamic performance of the compressor. In this work, a two-stage compressor with three different interstage pipelines were investigated experimentally and numerically. Results show that affected by the interstage pipeline bend section, the flow distortion will be induced at the impeller inlet of the high-pressure stage, and the distortion intensity changes with the pipeline structure. Among the three models, the EPC (elbow pipe change) model induces the most intense total pressure distortion at the condition of 80 kr/min and 130% mass flow rate, resulting in an efficiency reduction of 2 and 1.5 percentage points compared with the SPC (straight pipe change) and the TPC (total pipe change) model, respectively. Further research indicates that the upstream distortion has obvious influence on the downstream rotor blades. As the blade height decreases, the load becomes more uniform on the main blades, while the load extremum migrates to the trailing edge on the splitter blades. Finally, three models are tested, and their performance is compared at three typical rotational speeds., It is recommended that interstage pipelines similar to SPC models should be chosen to improve the two-stage compressor efficiency in the design. Full article

Chillers are widely used in commercial buildings for air conditioning, and their energy consumption is the main contribution to the building’s carbon emissions. Currently, the COPs of small- and medium-capacity screw chillers are still generally lower than 6.5, whereas large-capacity commercial centrifugal chillers have achieved an ultra-high energy-efficiency level of COP ≥ 7.0. To achieve an ultra-high energy efficiency of COP ≥ 6.5 in medium-capacity chillers, the authors developed a 200 RT screw chiller by adopting the technologies of two-stage compression and interstage vapor injection. The whole development process, including the design, simulation, analysis, and experiment, is presented in this paper. It was found that the two-stage compression technology could effectively boost the performance of the chiller’s compressor to a maximum volumetric and adiabatic efficiency of 99% and 80%, respectively. With the interstage vapor injection technology, the chiller’s cooling capacity and COP were increased by more than 11% and 8%, respectively. When the use of these two technologies was combined, the maximum COP of the chiller reached 7.17. Additionally, under these working conditions, the COP and integrated part-load value (IPLV) were 6.74 and 10.04, respectively. In all, the combination use of vapor injection and two-stage compression technologies shows great potential to improve the performance of chillers. The work and conclusions described here might provide an effective reference for the future development of high-efficiency small- and medium-capacity screw chillers. Full article

As the main noise source in the hydrogen fuel cell system, the noise level of the centrifugal air compressor greatly affects the comfort of the hydrogen fuel cell vehicle. For reducing the noise level of centrifugal air compressors, the noise characteristics and control of a high-speed two-stage compressor prototype are studied in this paper. Firstly, the near-field noise measurement, along with the independent component analysis, is carried out to identify the noise source of the developed compressor. Results showed that the “buzz-saw” noise at the rotating fundamental frequency and its low order harmonic frequency in the aerodynamic noise is prominent in the noise spectrum. Thus, the aerodynamic noise characteristics are predicted and analyzed using the CFD–BEM coupling aeroacoustic calculation model. Based on the analysis results, a noise control method coupling the structure optimization and perforated muffler is proposed. The results show that the sound pressure level of the air compressor at 1 m away from the surface is reduced by 4.1 dBA after the structural optimization. A perforated muffler applied in the pipe system of the air compressor can accomplish a reduction of 5.8 dBA in the sound pressure level of the air compressor by impeding the noise transmission on the path. With the coupled noise control methods above, the sound pressure level of the air compressor is reduced from 78.8 dBA to 68.9 dBA under the rated condition. Full article

Nowadays, several technologies for desalination processes are available and widely employed. However, they consume a considerable amount of energy and involve high capital and operating costs. Therefore, the techno-economic analysis of a system coupling different energy sources with the desalination processes is of value. The possibility of coupling a small gas turbine combined heat and power system (GT CHP) with hybrid desalination plants (HDPs) has been assessed in this study. The proposed gas turbine power generation system, based on a single-stage centrifugal compressor and an uncooled centripetal turbine, provides design simplicity and reasonable installation costs for the power generating plant. The hybrid desalination technique, based on the use of two different desalination technologies, i.e., Reverse Osmosis (RO) and a thermal desalination process, has been chosen to better exploit the electrical and thermal energy produced by the mini CHP plant. The proposed solution is numerically investigated from both thermodynamic and economic points of view, and the results of the thermodynamic analysis of the cycle are used as input for the evaluation of the amount of freshwater produced and of costs. The economic assessment of standalone desalination systems is also shown for the comparison with the hybrid solutions here proposed. Results show that the total cost of the water produced by MED + RO was less than the total cost of the water obtained by MSF + RO, and that the energy cost of MED + RO hybrid desalination system was about 15% less than that for stand-alone RO desalination technology. Thus, the MED + RO hybrid desalination system can be considered a promising solution for the coupling with the proposed mini GT CHP plant, which, due to the small size and cost, as well as the easy installation, can be easily applied in off-grid or remote areas. Full article

In this paper, the numerical model of a centrifugal compressor low-flow stage is verified. The gaps and labyrinth seals were simulated in the numerical model. The task was to determine the optimal settings for high-quality modeling of the low-flow stages. The intergrid interface application issues, turbulence and roughness models are considered. The obtained numerical model settings are used to validate seven model stages for the range of the optimal conditional flow coefficient with Φ_opt = 0.008–0.018 and the conditional Mach number M_u = 0.785–0.804. The simulation results are compared with the experimental data. The high pressure stage-7 (HPS-7) stage with Φ_opt = 0.010 and M_u = 0.60 at different inlet pressure of 4, 10 and 40 atm is considered separately. Acceptable validation results are obtained with the recommended numerical model settings; the modeling uncertainty for the polytropic pressure coefficient δη*pol < 4% for the efficiency coefficient δη*pol exceeds the limit of 4% only in the two most low-flow stages, U and V. Full article
