Search Results (28)

Denil fishways exhibit limited passage efficiency for weak-swimming and benthic species, partly due to severe near-bed hydrodynamics generated by the sharp V-notch apex of conventional baffles. Modifying bottom geometry is a promising optimization pathway, but previous studies often lack rigorous comparison under constrained baffle openness ratios. This study employed CFD with the RNG $k-\epsilon$ turbulence model to evaluate conventional V-shaped (TDF), equivalent U-shaped (SCDF), and rectangular (RDF) baffles under a unified openness ratio. A layered hydrodynamic evaluation framework demarcated by the effective blocking height was developed to distinguish flow responses in the upper jet-dominated and lower baffle-controlled layers. Results show that the upper-layer conveyance indicators remain broadly comparable across configurations, whereas the lower-layer indicators show configuration-related differences within the tested discharge range. The RDF and SCDF reduce lower-layer mean velocity and TKE relative to the TDF baseline across the tested discharge range, with the RDF achieving the larger velocity reduction and the SCDF the larger TKE reduction. The maximum relative reduction in lower-layer TKE, approximately 22%, occurs under intermediate discharge. These results suggest that bottom baffle geometry can provide a potential means of adjusting near-bed hydraulic conditions in Denil fishways, although the ecological consequences require further verification. Full article

In the present work, three-dimensional (3D) simulations have been performed for the characterization of a rectangular column for a uniform gas distributor with µm-sized holes at a ratio of 5. The model is first validated with experimental data from the literature. Simulations are then performed for a gas distributor with identical pitch but two different hole sizes, namely 600 µm and 200 µm. Three superficial gas velocities, namely 0.002 m/s, 0.004 m/s, and 0.006 m/s, were used for each distributor type. The gas movement in the fluid is found to be a strong function of hole size. For a 600 µm hole size, the operating condition has minimal impact on gas plume movement and moves centrally in a fully aerated regime. However, for a hole size of 200 µm, for all superficial velocities, the gas plume movement is dynamic and partially aerated. The plume moves along the right wall initially and then follows vertically. These characteristics are different from the meandering plume in centrally located spargers. The liquid mixing in the bulk is a function of time. During the plume development flow, different shapes are observed. Based on the analogy with the shapes found in nature, these shapes have been termed as balloon, cap, jet or candle flame, bull horn, mushroom, tree shape, and disintegrated mushroom shapes. Quantitative insights have been obtained in the form of time-averaged radial profiles of both volume fractions and liquid axial velocities. A symmetric parabolic shape for a hole size of 600 µm and skewed asymmetric shapes for a 200 µm hole size for three different axial positions, namely 0.1, 0.25, and 0.4 m, are observed. Correlations for gas holdup and liquid velocity have been proposed for low superficial velocities, which are in good agreement with the CFD simulation data, with a deviation of 15–20%. The deviations are partly due to the use of the k-ε turbulent model. The correlations perform better than the correlations available in the reported literature for similar superficial gas velocities. Full article

Cavitation in aircraft hydraulic systems continues to pose a serious problem for the aviation industry. This paper presents a new study on cavitation in aviation hydraulic fluid AMG-10 at its inception condition, corresponding to a relative pressure drop of Δp = 0.58, within a small-scale rectangular throttle channel of specified dimensions. Numerical simulations were performed in a quasi-steady-state framework using the realizable k–ε turbulence model combined with the Enhanced Wall Treatment approach, and the results were validated against time-integrated experimental data obtained via the shadowgraphy method. Cavitation was modeled using the Zwart–Gerber–Belamri model. The validated numerical model, which showed a pressure deviation of less than 10% from experimental data on the upper and lower walls, also demonstrated good agreement in the dimensions of the cavitation regions, confirming that the upper region is consistently larger than the lower one. Quantitative analysis demonstrated that regions with high vapor concentration are highly localized, representing only 0.048% of the channel volume at a 0.8 vapor fraction threshold. The analysis reveals that the cavitation regions spatially coincide with local pressure drops to values as low as 214 and 236 Pa near the upper and lower walls. These regions are also associated with wall jets, accelerated by the flow constriction to velocities up to 41.98 m/s. Furthermore, the cavitation region corresponds to a distinct peak in the mean turbulent kinetic energy field, reaching 164.5 m²/s², which decays downstream. Full article

Medium- and large-scale heat sinks are critical for thermal load management in high-performance systems. However, their high heat flux densities and limited space complicate cooling, leading to risks of overheating, performance degradation, or failure. This study employs the Cascaded Lattice Boltzmann Method (CLBM) to enhance their thermal performance. This numerical approach is known for being stable, accurate when dealing with complex boundaries, and efficient when computing in parallel. The numerical code was validated against a benchmark configuration and an experimental setup to ensure its reliability and accuracy. While previous studies have explored mixed convection in cavities or heat sinks, few have addressed configurations involving side air injection and boundary conditions periodicity in the transition-to-turbulent regime. This gap limits the understanding of realistic cooling strategies for compact systems. Focusing on mixed convection in the transition-to-turbulent regime, where buoyancy and forced convection interact, the study investigates the impact of Rayleigh number values ($5\times {10}^7$ to $5\times {10}^8$) and Reynolds number values (${10}^3$ to $3\times {10}^3$) on heat transfer. Simulations were conducted in a rectangular cavity with periodic boundary conditions on the vertical walls. Two heat sources are located on the bottom wall ($T_h$ = 50 °C). Two openings, one on each side of the two hot sources, force a jet of fresh air in from below. An opening at the level of the cavity ceiling’s axis of symmetry evacuates the hot air. Mixed convection drives the flow, exhibiting complex multicellular structures influenced by the control parameters. Calculating the average Nusselt number (Nu) across the surfaces of the heat sink reveals significant dependencies on the Reynolds number. The proposed correlation between Nu and Re, developed specifically for this configuration, fills the current gap and provides valuable insights for optimizing heat transfer efficiency in engineering applications. Full article

The airflow structure of enclosures directly affects the spread of COVID-19 and is also closely related to indoor air quality, the thermal comfort of personnel, and buildings’ energy consumption. A large number of studies on airflow field under mixing and displacement ventilation with a single air inlet in rectangular rooms have been conducted; however, to the best of the authors’ knowledge, only a limited number of studies have dealt with airflow structures in a multi-slot ventilation enclosure with opposed jets. Therefore, this paper uses PIV to study the velocity, turbulence information, and entropy of an unstable airflow field in a multi-slot ventilation enclosure with opposed jets under isothermal and non-isothermal conditions. This paper also presents, due to the collision of the jets to form two large-scale eddies, the airflow field structure being unstable. In the region without air supply inlets and exhaust outlets, a large-scale vortex is formed in the airflow field, resulting in the high information entropy of the flow field. The thermal plume suppresses the large-scale flow field structure and increases the small-scale flow field structure. Full article

The aeroacoustic field of a rectangular subsonic jet impinging on a slotted plate was investigated experimentally using microphones and stereoscopic particle image velocimetry (S-PIV). The study was carried out with a Reynolds number of 6700 and an impact distance of 4 cm. The current configuration represents a benchmark standpoint, featuring high levels of generated noise. A control mechanism consisting of a thin rod was introduced downstream from the jet exit to suppress the self-sustained tones. A total of 1085 positions of the rod between the jet exit and impinging plate were tested to identify positions of optimal noise reduction. Two zones were distinguished in terms of control efficacy: a zone where the sound pressure level (SPL) dropped by up to 19 dB and another zone where the SPL increased by up to 14 dB. The velocity fields show that the presence of the rod divides the jet into two lateral secondary jets on both sides of the main jet axis. The outer part of the secondary jets expanded radially with less interaction with the plate compared to the case without the control. This behavior affected the deformation of vortices against the slot. Proper orthogonal decomposition was applied to the velocity field for a better understanding of the turbulence dynamics with and without the control rod. Full article

Weapons bays have gained much attraction in the last decade, mainly in the context of next-generation aircraft. Although internal store carriage provides numerous advantages, aero-mechanical challenges still exist, particularly for safe store separation. Therefore, it is essential to gain fundamental knowledge of the flow field within weapons bays, which can be achieved by studying the flow within a more simplified geometry of a cavity. In this study, detached eddy simulations are performed using the Elastic-Zonal-Navier–Stokes-Solver (EZNSS) to characterize the unsteady turbulent flow within NASA’s benchmark rectangular cavity with a store model located at various positions. Simulations are performed at a Mach number of 0.4 and a Reynolds number of 7 million to form a transitional cavity flow, which is common in jet-fighter weapons bays. The numerical results are validated with experimental data for the empty cavity and cavity-with-store configurations. The effect of the store’s position on the cavity flow characteristics is analyzed and verified, as well as the aerodynamic loads exerted on the store. Results show a complex interaction between the store model and the cavity flow field, manifested by distortion of the wall pressure fluctuations and mean flow structures and large amplitude fluctuations of the loads exerted on the store. The insights reported herein can serve future development efforts of more accurate numerical frameworks for cavity-with-store configurations towards improving their applicability for weapons bays store separation in certification procedures. Full article

High-aspect-ratio (HAR) rectangular jets have attracted attention in automobile air conditioning (A/C) systems and turbulent jet applications owing to their excellent air delivery and mixing and attractive interior design. Active flow control (AFC) of rectangular jets using plasma actuators (PAs) has proven to be a promising technique because the actuator is simple, has low energy consumption, and can create flow features without interference. This research aims to understand the interaction between PAs and flow from a HAR rectangular nozzle using hot-wire anemometry, particle image velocimetry, and theoretical studies. Understanding how PAs affect the flow is beneficial for designing air vents to fit automobile A/C systems and various engineering applications by recreating the flow features with other AFC techniques and actuators. The combination of periodic excitation and vectoring effects transfers the flow’s mean energy to organized structures—known as spanwise vortexes—as large as 6 mm. The interaction between these coherent structures and the dissipative environment compresses the vortexes, resulting in the flow converging on the spanwise–streamwise (X–Z) plane and diverging on the transverse–streamwise (X–Y) plane. HAR rectangular jet flow features controlled by PAs can be predicted for specific cases by calculating the Strouhal number based on PA operating parameters. Full article

Due to its simple structure and lack of moving parts, the supersonic air ejector has been widely applied in the fields of machinery, aerospace, and energy-saving. The performance of the ejector is influenced by the flow channel structure and the velocity of the jet, thus the confined jet is an important limiting factor for the performance of the supersonic air ejector. In order to investigate the effect of the confined jet on the performance of the ejector, an air ejector with a rectangular section was designed. The effects of the section width (W_c) on the entrainment ratio, velocity distribution, turbulent kinetic energy distribution, Mach number distribution, and vorticity distribution of the rectangular section air ejector were studied numerically. The numerical results indicated that the entrainment ratio of the rectangular section air ejector increased from 0.34 to 0.65 and the increment of the ER was 91.2% when the section width increased from 1 mm to 10 mm. As W_c increased, the region of the turbulent kinetic energy gradually expanded. The energy exchange between the primary fluid and the secondary fluid was mainly in the form of turbulent diffusion in the mixing chamber. In addition to W_c limiting the fluid flow in the rectangular section air ejector, the structure size of the rectangular section air ejector in the XOY plane also had a limiting effect on the internal fluid flow. In the rectangular section air ejector, the streamwise vortices played an important role in the mixing process. The increase of W_c would increase the distribution of the streamwise vortices in the constant-area section. Meanwhile, the distribution of the spanwise vortices would gradually decrease. Full article

For the new idea of a gas-curtain launcher with a grooved tube, the gas-curtain flow field and interior ballistic characteristics are mainly investigated in this paper. The coupling of the gas–liquid interaction model and interior ballistic equations is realized by solving the gas flow equation. Analyses have focused on the morphological evolution of the gas-curtain, pressure distribution, turbulence intensity evolution, and interior ballistic performance. The results show that multiple groove jets first expand independently of each other, and their shape changes from rectangular to triangular. The groove jets then come into contact with each other and form a gas-curtain. Meanwhile, the gas-curtain expansion results in complex changes in the pressure and turbulence intensity of the flow field in the tube. The parameters distribution in the flow field gradually have a simple tendency as the gas-curtain increases and the projectile moves. The moment the projectile starts moving, the gas volume fraction reaches 83%, indicating that the gas-curtain has made remarkable achievements in drag reduction. Significantly, under the calculated conditions in this paper, an initial velocity of 360.58 m/s was obtained at a maximum chamber pressure of 86.34 MPa. Full article

No alternatives are currently available to operate industrial furnaces, except for hydrocarbon fuels. Plant managers, therefore, face at least two challenges. First, environmental legislation demands emission reduction. Second, changes in the origin of the fuel might cause unforeseen changes in the heat release. This paper develops the hypothesis for the detailed control of the combustion process using computational fluid dynamic models. A full-scale mock-up of a rotary cement kiln is selected as a case study. The kiln is fired by the non-premixed combustion of Dutch natural gas. The gas is injected at Mach $0.6$ via a multi-nozzle burner located at the outlet of an axially mounted fuel pipe. The preheated combustion air is fed in (co-flow) through a rectangular inlet situated above the attachment of the fuel pipe. The multi-jet nozzle burner enhances the entrainment of the air in the fuel jet. A diffusion flame is formed by thin reaction zones where the fuel and oxidizer meet. The heat formed is transported through the freeboard, mainly via radiation in a participating medium. This turbulent combustion process is modeled using unsteady Favre-averaged compressible Navier–Stokes equations. The standard k-$ϵ$ equations and standard wall functions close the turbulent flow description. The eddy dissipation concept model is used to describe the combustion process. Here, only the presence of methane in the composition of the fuel is accounted for. Furthermore, the single-step reaction mechanism is chosen. The heat released radiates throughout the freeboard space. This process is described using a P1-radiation model with a constant thermal absorption coefficient. The flow, combustion, and radiative heat transfer are solved numerically using the OpenFoam simulation software. The equations for flow, combustion, and radiant heat transfer are discretized on a mesh locally refined near the burner outlet and solved numerically using the OpenFoam simulation software. The main results are as follows. The meticulously crafted mesh combined with the outlet condition that avoids pressure reflections cause the solver to converge in a stable manner. Predictions for velocity, pressure, temperature, and species distribution are now closer to manufacturing conditions. Computed temperate and species values are key to deducing the flame length and shape. The radiative heat flux to the wall peaks at the tip of the flame. This should allow us to measure the flame length indirectly from exterior wall temperature values. The amount of thermal nitric oxide formed in the flame is quantified. The main implication of this study is that the numerical model developed in this paper reveals valuable information on the combustion process in the kiln that otherwise would not be available. This information can be used to increase fuel efficiency, reduce spurious peak temperatures, and reduce pollutant emissions. The impact of the unsteady nature of the flow on the chemical species concentration and temperature distribution is illustrated in an accompanying video. Full article

This paper discusses accuracy improvements to Reynolds-Averaged Navier–Stokes (RANS) modeling of supersonic flow by assessing a wide range of factors for physics capture. Numerical simulations reveal complex flow behavior resulting from shock and expansion waves and so, a supersonic jet emanating from rectangular nozzle is considered. PIV based experimental data for the jet is available from literature and is used for validation purposes. Effect of various boundary conditions and turbulence modeling approaches is assessed qualitatively and quantitatively. Of particular interest are the inlet conditions considering the turbulence intensity and the effect of upstream air supply duct, the effect of nozzle wall surface roughness on nozzle internal flow and downstream, wall y+ sensitivity for boundary layer resolution and laminar to turbulent transition modeling. In addition to mesh sensitivity, domain dependency is conducted to evaluate the appropriate domain size to capture the kinetic energy dissipation downstream of the nozzle. To further improve the flow characteristics, accounting for the anisotropy of Reynolds stresses is also one of the focuses. Therefore, non-linear eddy viscosity-based two-equation model and Reynolds stress transport model are also investigated. Additionally, the results of baseline linear (Boussinesq) RANS are compared. Corresponding comparisons with high-fidelity LES are presented. Jet self-similar behavior resulting from all simulation fidelities is assessed and it appears that turbulent flow in LES becomes self-similar, but not in RANS. Finally, various factors such as the nozzle geometry and numerical modeling choices influencing the anisotropy in jet turbulence are discussed. Full article

Supersonic incoming flow has a large momentum, which makes it difficult for transverse jets to have a large penetration depth due to the strong compression of the incoming flow. This impacts the mixing efficiency of the jet in the supersonic combustor. This paper proposes a method to improve the mixing efficiency of a rectangular flow field model using pulsed energy deposition, which is verified numerically. In the simulations, the Navier–Stokes equations with an energy source are solved to simulate the effects of energy deposition with various distributions on the fuel mixture. The results show that the energy deposition increases the turbulent kinetic energy, which enlarges the scale of the flow vortex and improves the fuel mixing performance. The energy deposition is distributed upstream and significantly improves the mixing performance. Energy deposition can improve the penetration depth of fuel, which is more significant when the energy deposition is distributed downstream of the jet orifice. The energy deposition also slightly reduces the total pressure recovery coefficient. In general, an energy deposition that is distributed upstream of the jet has the best effect on the mixing efficiency. Full article

Turbulence is governed by various mechanisms, such as production, dissipation, diffusion, dilatation and convection, which lead to its evolution and decay. In high-speed flows, turbulence becomes complicated due to compressibility effects. Therefore, the goal of the current work is to characterize these mechanisms in rectangular supersonic jets by directly evaluating their contributions in turbulent kinetic energy (TKE) budget equation. The budgets are obtained using high-fidelity Large Eddy Simulations that employ WALE subgrid-scale model. Jet nearfield data are validated with PIV experimental measurements, available from the literature, which include mean flow and second-order statistics. To ensure spatial resolution and temporal convergence of higher-order statistics, qualitative performance metrics are presented. The results indicate that TKE production is the major source term, while pressure-dilatation term acts as a sink throughout the development of the jet. The diffusion term has the highest contribution from triple-velocity correlations, followed by pressure diffusion and molecular diffusion. Subgrid-scale diffusion and dissipation are also evaluated and their contributions are minimal. Each term is presented on both minor and major axis plane and reveals asymmetry in the statistics. A detailed explanation of budget contributions is provided, leading to the mechanisms responsible for the anisotropy of TKE. Full article

The turbulence jet centerline velocity and temperature decay intensely along the centerline flow direction. Thus, improving it could benefit engineering applications, such as air conditioners. However, active flow control techniques with high-aspect-ratio jets, especially for controlling the temperature, have not been widely investigated. This paper presents the velocity and temperature performance of a high-aspect-ratio rectangular jet controlled by two dielectric barrier discharge plasma actuators located on the longer sides of the nozzle and controlled by high-voltage and high-frequency pulse-width modulation sinusoidal waves. The scanning method was used to cover 362 cases as combinations of working parameters (modular frequency vs. duty vs. phase difference) for the velocity and temperature performances of the jets. Results show that plasma actuators can control both velocity and temperature distribution with minor input power compared with the rectangular jet’s kinetic energy and heat flux. The velocity increased up to 4% and decreased to 11%, measured at the interest position where $x/h$ = 70 on the centerline. There were a 5% increase and a 4% decrease compared to the temperature-based case. Distinctive velocity and temperature distributions were observed under noteworthy cases, indicating the potential of the actuator to create various flow features without installing new hardware on the flow. Full article
