Search Results (27)

Rock slopes exhibiting anti-inclined interbedded strata have widespread distribution and complex deformation mechanisms. In this study, we used a physical model test with basal friction to replicate the evolution process of the slope deformation. Digital Image Correlation (DIC) and Particle Image Velocimetry (PIV) methods were used to capture the variation in slope velocity and displacement fields. The results show that the slope deformation is conducted by bending of soft rock layers and accumulated overturning of hard blocks along numerous cross joints. As the faces of the rock columns come back into contact, the motion of the slope can progressively stabilize. Destruction of the toe blocks triggers the formation of the landslides within the toppling zone. The toppling fracture zones form by tracing tensile fractures within soft rocks and cross joints within hard rocks, ultimately transforming into a failure surface which is located above the hinge surface of the toppling motion. The evolution of the slope deformation mainly undergoes four stages: the initial shearing, the free rotation, the creep, and the progressive failure stages. Full article

In this study, statistical analysis was conducted to categorize a large number of actual typical cases and analyze the formation conditions of toppling deformation in bedding rock slopes. Based on geological prototypes and similarity theory, a bottom friction test was conducted on the toppling deformable body while considering the excavation process. Based on the deformation and failure phenomena observed in the bottom friction test model, along with the displacement curves at key points, the deformation process in steep bedding rock slopes can be divided into the following five distinct stages: the initial phase, the unloading–rebound phase, the tensile failure phase, the bending creep phase, and the bending–toppling damage phase. To evaluate the stability, a new constitutive model of the nonlinear viscoelastic–plastic rheology of rock masses was developed. This model is based on a nonlinear function derived from analyzing the creep test data of rock masses under fractional loading. Furthermore, a mechanical equilibrium differential equation for rock slabs was formulated to quantitatively describe the aging deformation and failure processes of slopes with delayed instability. Finally, a stability criterion and a quantitative evaluation model for toppling deformation slopes that considered time-varying factors were established. The stability of the model was calculated using a hydropower station slope case, and the results were found to be in good agreement with the actual situation. Full article

This study presents the geological and geomorphological characterization of the Pie de la Cuesta landslide, a large (>60 ha) slow-moving (up 4.5 m/month) landslide in Southern Peru. The landslide has been active since 1975 and underwent a significant re-activation in 2016; the mass movement has caused the loss of property and agricultural land and it is currently moving, causing further damage to property and land. We use a combination of historical aerial photographs, satellite images and field work to characterize the landslide’s geology and geomorphology. The landslide is affecting the slope of the Vitor Valley, constituted by a coarsening upward sedimentary sequence transitioning from layers of mudstone and gypsum at the base, to sandstone and conglomerate at the top with a significant ignimbrite layer interbedded within conglomerates near the top of the sequence. The landslide is triggered by an irrigation system that provides up to 10 L/s of water infiltrating the landslide mass. This water forms two groundwater levels at lithological transitions between conglomerates and mudstones, defining the main failure planes. The landslide is characterized by three main structural domains defined by extension, translation and compression deformation regimes. The extensional zone, near the top of the slope, is defined by a main horst–graben structure that transitions into the translation zone defined by toppling and disaggregating blocks that eventually become earth flows that characterize the compressional zone at the front of the landslides, defined by thrusting structures covering the agricultural land at the valley floor. The deformation rates range from 8 cm/month at the top of the slope to 4.5 m/month within the earth flows. As of May 2023, 22.7 ha of potential agricultural land has been buried. Full article

The construction of major hydropower projects globally is challenged by slope deformation in reservoir areas. The deformation and failure mechanisms of large rock slopes are complex and poorly understood, making prevention and management extremely challenging. In order to explore the influence mechanism of the water level variation on the deformation of steep toppling bedding rock slopes, this paper takes the right bank slope near the dam area of the Longtou Hydropower Station as an example, and field investigations, deformation monitoring, physical simulation tests and numerical analyses are carried out. It is found that the slope deformation response is obvious under the influence of the reservoir water level variation, which is mainly reflected in the change in the slope groundwater level, rock mechanical parameters and seepage field in the slope body. The toe of the slope produces plastic deformation and maximum displacement. With the increase in the reservoir water level, the plastic zone expands and the displacement increases, which leads to the intensification of the slope deformation. This paper puts forward that the deformation and failure modes of the steep and toppling bedding rock slope caused by water level variation are due to shear dislocation, bending deformation and toppling fracture. This study reveals the influence mechanism of the water level variation on the deformation of steep and toppling bedding rock slopes, which can provide theoretical support for the construction of major hydropower projects. Full article

The current deformation and stable state of slopes with historical shatter signs is a concern for engineering construction. Suspected landslide scarps were discovered at the rear edge of the Genie slope on the Tibetan Plateau during a field investigation. To qualitatively determine the current status of the surface deformation of this slope, this study used high-resolution optical remote sensing, airborne light detection and ranging (LiDAR), and interferometric synthetic aperture radar (InSAR) technologies for comprehensive analysis. The interpretation of high-resolution optical and airborne LiDAR data revealed that the rear edge of the slope exhibits three levels of scarps. However, no deformation was detected with differential InSAR (D-InSAR) analysis of ALOS-1 radar images from 2007 to 2008 or with Stacking-InSAR and small baseline subset InSAR (SBAS-InSAR) processing of Sentinel-1A radar images from 2017 to 2020. This study verified the credibility of the InSAR results using the standard deviation of the phase residuals, as well as in-borehole displacement monitoring data. A conceptual model of the slope was developed by combining field investigation, borehole coring, and horizontal exploratory tunnel data, and the results indicated that the slope is composed of steep anti-dip layered dolomite limestone and that the scarps at the trailing edges of the slope were caused by historical shallow toppling. Unlike previous remote sensing studies of deformed landslides, this paper argues that remote sensing results with reliable accuracy are also applicable to the study of undeformed slopes and can help make preliminary judgments about the stability of unexplored slopes. The study demonstrates that the long-term consistency of InSAR results in integrated remote sensing can serve as an indicator for assessing slope stability. Full article

Since the beginning of spring 2022, successive landslides have occurred in the eastern pit slope of the Wolong Coal Mine in Qipanjing Town, Otog Banner, Inner Mongolia, which has adversely affected the mine’s production safety. This study aims to reveal the deformation patterns and failure mechanisms of landslides. Firstly, this study establishes the stratigraphic structure of the eastern pit slope of the Wolong Coal Mine using extensive field geological surveys combined with unmanned aerial vehicle photography, drilling, and comprehensive physical exploration techniques. Indoor geotechnical tests and microscopic experiments reveal that rock mass typically exhibits the characteristics of expansibility and water sensitivity. Moreover, the mechanical parameters of the rock mass were determined using a combination of the window sampling method, the Geological Strength Index, and the Hoek–Brown strength criterion estimation theory. Finally, this study consolidates the previously mentioned insights and employs FLAC3D (7.0) software to assess the stress–strain characteristics of the excavated slope. The results indicate that the deformation mode of the Wolong open pit coal mine is the toppling failure of soft-hard-interbedded anti-inclined layered rock slopes. The unloading effect and rock expansion-induced softening lead to stress concentration at the slope corners and more substantial deformation, thereby accelerating upper slope deformation. The deformation and destabilization process of landslides is categorized into four stages: the initial deformation stage, the development stage of lateral shear misalignment, the development stage of horizontal tensile-shear damage, and the slip surface development to the preslip stage. This research offers valuable references and engineering insights for future scientific investigations and the prevention of similar slope-related geological hazards. Full article

The mountainous areas of Southwest China have the characteristics of valley deep-cutting, a large topographic gradient, complex geological structures, etc. With the development of infrastructure construction in the area, the construction of bridges across valleys has gradually increased, and the phenomenon of slope failure occurs more and more frequently. As the weak interlayer, the fault fracture zones have a significant influence on the geological structure and stability of slopes, while the complexity of the mechanism of the deformation and failure of slopes increases with the combination of the development of the fracture zones and toppling deformation. This paper took the toppling bank slope of bridge foundations developed with fault fracture zones in Lancang River as the research object. Through an on-site field survey and geological survey technologies, it identified the distribution range of the fracture zones on the bank slope and determined the characteristics of the rock mass in the fracture zones. A stability evaluation model for the bank slope of the bridge foundations was established using the limit equilibrium method and discrete element method. Based on the two-dimensional limit equilibrium analysis, the potential failure modes of the bank slope were explored, and the stability of the bank slope under bridge loads was calculated. Through the three-dimensional geological model of the bank slope, including the fracture zones and toppling bodies, the three-dimensional discrete element numerical simulation method was adopted to simulate and calculate the deformation and failure process of the bank slope under different bridge loads and working conditions. According to the calculation results, the influence of bridge loads and reservoir water on the stability of the bank slope was analyzed from the perspectives of displacement, plastic zone, stability coefficient, and other factors. The formation process of the plastic zone and the development of the sliding surface were revealed, the incentive mechanism of bridge loads and reservoir water on the deformation and failure of the bank slope was analyzed, and the influence of fault fracture zones on the stability of the bank slope and the development of toppling deformation was determined. The results indicate that the fault fracture zones are important geological structures that affect the deformation and failure of the bank slope as a weak interlayer. Under the influence of bridge loads and reservoir water, the stability of the bank slope is affected by the quality of the rock mass and the development of the fault fracture zones, resulting in the unmet need for safety requirements and maybe leading to instability. Based on the calculation results of the stability evaluation prediction model for the bridge foundation bank slope and the engineering geological conditions, the bridge scheme has been selected. Full article

Deep, unstable slopes are highly developed in mountainous areas, especially in the Minjiang River Basin, Sichuan Province, China. In this study, to reveal their deformation evolution characteristics for stability evaluation and disaster prevention, multi-period optical remote sensing images (2010–2019), SBAS-InSAR data (January 2018–December 2019), and on-site real-time monitoring (December 2017–September 2020) were utilized to monitor the deformation of a large deep-seated toppling, named the Tizicao (TZC) Toppling. The obtained results by different techniques were cross-validated and synthesized in order to introduce the spatial and temporal characteristics of the toppling. It was found that the displacements on the north side of the toppling are much larger than those on the south side, and the leading edge exhibits a composite damage pattern of “collapse failure” and “bulging cracking”. The development process of the toppling from the formation of a tensile crack at the northern leading edge to the gradual pulling of the rear edge was revealed for a time span of up to ten years. In addition, the correlation between rainfall, earthquakes, and GNSS time series showed that the deformation of the toppling is sensitive to rainfall but does not change under the effect of earthquakes. The surface-displacement-monitoring method in this study can provide a reference for the evolution analysis of unstable slopes with a large span of deformation. Full article

The foundation of a large river crossing bridge is often located on high and steep slopes in mountainous area, and the stability of the slope has a significant impact on the safety of the bridge. Not only the bridge load, but also the hydro-dynamical action in the reservoir area has a significant impact on the stability of the bank slope where the bridge foundation is located, especially for the toppling bank slope. This paper takes the stability of the toppling bank slope where the one major bridge foundation is located at on the Lancang River in China as an example. Through on-site exploration, drilling data and core conditions, and television images of the borehole, the geological structure of the on-site bank slope were conducted. Based on the development of the dumping body obtained from on-site exploration, corresponding indicators have been proposed from the perspectives of rock inclination, deformation, and rock quality to clarify the degree of dumping along the depth of the bank slope. The failure mechanism of the overturned bank slope under the action of a bridge was analyzed from a mechanical perspective. Numerical simulations were conducted using GeoStudio 2018:SEEP/W and FLAC3D 6.0 software to analyze the failure modes of bridge loads and hydrodynamic forces under different water levels and rainfall conditions. The seepage field characteristics, failure modes, and stability characteristics were analyzed from a two-dimensional perspective, while the displacement characteristics, plastic zone, and stress–strain characteristics were explored from a three-dimensional perspective, which revealed the evolution mode of overturned deformation under the action of bridge foundation loads. Finally, the stability of the wide slope was numerically calculated using the strength reduction method, and the stability calculation data was combined with the numerical simulation results to determine the optimal location of the bridge foundation. Full article

The phenomenon of toppling deformation and failure is common in slopes with anti-dip structures, especially in soft metamorphic rock slopes. This paper aims to explore the instability mechanism of anti-dip layered soft metamorphic rock landslides. Taking the slope of a mining area in the southern Qinling Mountains of China as a geological prototype, a large-scale centrifuge model test and a numerical simulation based on the combined finite and discrete element method (FDEM) were performed. The deformation and failure process, failure mode, and failure path of the slope under rainfall and excavation conditions were simulated. The results show that both the physical centrifuge model test and the new numerical model test can simulate the instability process of anti-dip layered soft metamorphic rock slopes, and the phenomena simulated by the two methods are also very close. Rainfall mainly weakens the mechanical properties of rock, while the excavation at the slope toe mainly changes the stress field distribution and provides space for slope deformation, both of which accelerate the instability of the anti-dip soft metamorphic rock slope. The failure process of an anti-dip layered soft rock slope can be described as follows: bending of the rock layer–tensile fracture along the layer–flexural toppling and cracking perpendicular to the rock layer–extension and penetration of the tensile fracture surface–sliding and instability of the slope. Full article

Controlled by regional geological background, and affected by human activity and weathering, toppling deformation slopes occur in different regions in China. Based on statistics about domestic toppling deformation slopes and their distribution, the regional geological susceptibility zonation area of toppling deformation slopes was determined. Firstly, a regional geological susceptibility evaluation was conducted according to these toppling deformation slopes, choosing landform, stratigraphic age, seismic intensity and tectonic stress distribution, and the study area was divided into very low, low, medium, high and very high susceptibility areas. Secondly, a geographic position susceptibility evaluation was conducted aimed at different sections of typical rivers in western China and the toppling deformation slopes related to them, and the study area was divided into upstream, midstream and downstream of 11 rivers that were respectively classified into very low, low, high and very high susceptibility areas. Thirdly, based on the results, associations between the toppling deformation factors (lithology, slope height, elevation, horizontal depth and vertical depth) and the distribution of deformation slopes were revealed. Finally, the development regularity was analyzed comprehensively. The results show that the toppling deformation slopes of hydropower projects are more developed in Sichuan, Qinghai and Yunnan provinces of China. With regard to regional geography, besides the Yellow River, both the Lancang River and the Yalong River flow through areas with toppling deformation that are classified as highly susceptible geological zones in all levels. The results of this study can be used as references for site selection plans in hydropower projects. Full article

Toppling-sliding failure is a typical mode of deep-seated toppling failure. In this mode, massive collapsed rock masses form the main sliding body, which is sensitive to rainfall events and prone to instability under rainfall due to its unique slope structure. In the present study, based on the detailed investigation on the geology and deformation characteristics, we studied the deformation and failure mechanism of a large-scale deep-seated toppling in Nandongzi Village, Pingquan City, Hebei Province. We constructed an engineering geology model to describe the toppling-sliding failure under rainfall. In addition, based on the saturated–unsaturated seepage theory and using the SLOPE/W and SEEP/W modules in the GeoStudio software, we explored the seepage law and factors controlling the seepage failure of toppling-sliding under rainfall. From surface to interior, the slope can be divided into topplingalling zone, strong toppling zone, slight toppling zone, and non-deformation zone. The geological structure consisting of an upper strong slab and an underlying weak rock layer, controls the early deformation, and the deformation and failure mode is compressing-bending-toppling. Due to the influence of excavation and rainfall, the sliding movements occur along planar rupture planes in the toppling-falling zone in the later stage, during which the failure mode switches to creeping-cracking. At present, the stability of the slope is highly sensitive to rainfall. When the rainfall intensity exceeds 220 mm/day (50 years return period storm), the factor of safety will fall below 1.05 and subsequently the sliding failure may be triggered. Because of the difference in permeability characteristics between the toppling-falling zone and the strong toppling zone, high pore-water pressure is developed at their boundary, leading to a drastic decrease in the factor of safety. Specifically, the more considerable difference in permeability, the lower the safety factor. Overall, this study is significant in scientific guiding for evaluating and preventing such slope failures. Full article

The research of structural masonry associated with geo-hydrological hazards in Cultural Heritage is a multidisciplinary issue, requiring consideration of several aspects including the characterization of used materials. On 25 May 2016, loss of water from the subterranean pipes and of the aqueduct caused an Arno riverbank failure damaging a 100 m long portion of the historical embankment wall of Lungarno Torrigiani in Florence. The historical masonry was built from 1854–1855 by Giuseppe Poggi and represents a historical example of an engineering approach to riverbank construction, composed of a scarp massive wall on foundation piles, with a rubble masonry internal core. The failure event caused only a cusp-shaped deformation to the wall without any shattering or toppling. A complete characterization of the mortars was performed to identify the technologies, raw materials and state of conservation in order to understand why the wall has not collapsed. Indeed, the mortars utilized influenced the structural behavior of masonry, and their characterization was fundamental to improve the knowledge of mechanical properties of civil architectural heritage walls. Therefore, the aim of this research was to analyze the mortars from mineralogical–petrographic, physical and mechanical points of view, to evaluate the contribution of the materials to damage events. Moreover, the results of this study helped to identify compatible project solutions for the installation of hydraulically and statically functional structures to contain the riverbank. Full article

Reservoir bank landslides are a frequent phenomenon, and the stability of these landslides is affected by two essential factors: rainfall and reservoir level changes. Studying the response patterns of reservoir bank landslide movements to these variables is crucial in preventing their occurrence and mitigating their effects. To this end, this study employed 103 European Space Agency (ESA) Copernicus Sentinel-1 images and the SBAS-InSAR (small baseline subset interferometric synthetic aperture radar) technique to obtain a time series of the Guobu slope deformation from September 2015 to December 2019. The Guobu slope showed significant toppling damage. The satellite line of sight (LOS) detected a maximum subsidence rate of −447 mm/y (the negative sign indicates movement away from the satellite, i.e., subsidence) in the upper section of the slope. Subsequently, three wavelet tools were used to quantitatively analyze the effect of rainfall and reservoir water level on the deformation of the Guobu slope. The results demonstrate a positive correlation between rainfall and the deformation of the Guobu slope. Moreover, the deformation lags behind the rainfall by approximately 70 days. In contrast, the reservoir water level and the deformation of the Guobu slope exhibit an inverse relationship. The deformation of the leading edge of the slope body lags behind the reservoir level by approximately 19 days, while the middle and upper sections of the slope body, which have the most significant rate of variability, lag by about 80 days. Among these factors, rainfall plays a dominant role in the deformation of the Guobu slope, while reservoir levels play a synergistic role. The findings of this study highlight the importance of monitoring and understanding the impact of changes in rainfall and reservoir water levels on the stability of reservoir bank landslides. This understanding is crucial in preventing the occurrence of such landslides and minimizing their impact. The use of remote sensing techniques, together with wavelet analysis, enables the accurate and timely monitoring of the deformation of the Guobu slope, providing valuable insights for disaster warnings and disaster prevention and reduction efforts. Full article

In this study, we conducted small-scale physical modeling tests to consider the impact of the infiltration of rainfall in order to investigate the processes involved in wedge slope deformation and failure. The experiments were conducted under controlled conditions of the intersection angle and half-wedge angle. The observations obtained during each stage of deformation and failure were used to explain how gravity deformation varies on wedge slopes and infer how rainfall influences slope failure. The results indicated that half-wedge angle is a crucial factor in the deformation failure of slopes. The failure mechanisms of small-intersection angle slopes (sliding model) differ considerably from those of large-intersection angle slopes (free falling or toppling model). The infiltration of surface water can have a significant influence on rock layer deformation and the speed of failure. Details of the failure characteristics of wedge slope models were discussed in this paper. Full article
