Search Results (37)

Nickel-based superalloys, renowned for their exceptional high-temperature strength, oxidation resistance, and corrosion resistance, have become essential materials in the aerospace, defense, and nuclear industries. However, due to their poor machinability, common cutting processes often result in poor surface quality, difficulties in chip breaking, and significant tool wear. This study investigates the surface integrity of nickel-based superalloys during ultrasonic elliptical vibration cutting. The effects of various process parameters on the surface roughness, residual stress, and microhardness are systematically analyzed. The results indicate that under ultrasonic elliptical vibration cutting conditions, the surface roughness of the workpiece increases with the ultrasonic amplitude, cutting depth, and feed rate. It initially decreases and then increases with cutting speed, and decreases with an increase in the tool tip radius. The post-cutting residual stress in the nickel-based superalloy decreases with higher cutting speed and ultrasonic amplitude, but increases with greater cutting depth and tool tip radius. The surface microhardness increases with the cutting speed up to a point, after which it decreases, while it significantly increases with a higher ultrasonic amplitude, feed rate, and cutting depth. A comparative experiment was conducted between ultrasonic elliptical vibration and conventional cutting. The research results showed that when the cutting depth was 2 µm, the surface roughness and wear decreased by 19% and 53%, respectively, and the residual compressive stress and microhardness increased by 44% and 21%, respectively. This further verified the significant advantages of ultrasonic elliptical vibration cutting in optimizing machining performance. Full article

The thin and straight horn of the ultrasonic transducer is located in the center of the thick transducer, so that the tool tip of the ultrasonic vibration turning tool holder cannot be located on the outermost side of the entire tool holder, which leads to the structural interference between the tool holder and the part during turning. In order to solve this problem, this paper proposes a longitudinal-bending elliptical vibration ultrasonic transducer with a bending horn for ultrasonic vibration-assisted cutting (UVAC). The designed transducer can be used for the partial separation continuous high-speed elliptic ultrasonic vibration cutting (HEUVC) of external surface and internal cavity. The ultrasonic vibration amplitude of the transducer can meet the needs of HEUVC. When using an ultrasonic transducer with a bending horn for HEUVC, compared with conventional cutting (CC), HEUVC can improve the tool life by about 50%. Full article

The conversion of ambient mechanical vibrational energy into electrical energy through piezoelectric devices has received an increasing attention in recent years. The main challenges are to develop efficient devices that operate over a wide frequency range, adapting to diverse environmental energy sources. This work presents a framework for the analysis of a nonlinear vibration-based energy harvesting devices combining the nonlinear finite element method with a reduced-order model, which provides a broader dynamical investigation. On this basis, a flexible tool is developed, allowing the multimodal analysis of nonlinear systems. A bistable piezoelectric energy harvesting device is investigated considering the influence of multimodal and nonlinear effects on the system performance. Bistability is due to magnetic interactions among magnets and the beam tip, modeled by cubic nonlinearities. Numerical simulations show the influence of vibration sources on the dynamics and performance of the device. Nonlinear effects furnish rich dynamics, presenting periodic and chaotic responses. All these effects can be combined to enhance energy harvesting capacity. Full article

The article presents an analytical and experimental method for determining the dynamic coefficients of cutting tools, with particular emphasis on turning tools. The method involves aligning the acceleration profile obtained from empirical investigations with a mathematical model describing the oscillations of the cutting tool tip. The stiffness (k) and damping (c) coefficients determined using this approach enable the design of tools with desired dynamic characteristics, tailored to specific machining processes, such as machining with long overhangs. From the perspective of mechanical dynamics, selecting appropriate stiffness and damping values allows for the design of tools with optimal dynamic properties. High stiffness reduces the occurrence of deformations under external forces, while adequate damping facilitates the rapid attenuation of vibrations, thereby minimising their adverse effects on the machining process. The developed method could serve as a practical tool for identifying the dynamic parameters applicable to a wide variety of cutting tools. The analysis includes three types of turning tools: one with a steel shank, another with a carbide-core steel shank, and a third with a carbon fibre-core steel shank. The results of the tests indicate that the E-A20Q SDUCL 11 tool is best suited for operations requiring high stability and minimal vibration, owing to its favourable damping and stiffness properties. Full article

Turbomachinery engines face significant failure risks due to the combination of thermal loads and high-amplitude vibrations in turbine and compressor blades. Accurate stress distribution measurements are critical for enhancing the performance and safety of these systems. Blade tip timing (BTT) has emerged as an advanced alternative to traditional measurement methods, capturing blade dynamics by detecting deviations in blade tip arrival times through sensors mounted on the stator casing. This research focuses on developing an analytical model to quantify the uncertainty budget involved in designing a calibration setup for BTT systems, ensuring targeted performance levels. Unlike existing approaches, the proposed model integrates both operational variability and sensor performance characteristics, providing a comprehensive framework for uncertainty quantification. The model incorporates various operating and measurement scenarios to create an accurate and reliable calibration tool for BTT systems. In the broader context, this advancement supports the use of BTT for qualification processes, ultimately extending the lifespan of turbomachinery through condition-based maintenance. This approach enhances performance validation and monitoring in power plants and aircraft engines, contributing to safer and more efficient operations. Full article

The smoothing of linear toolpaths plays is critical in improving machining quality and efficiency in five-axis CNC machining. Existing corner-smoothing methods often overlook the impact of spline curvature fluctuations, which may lead to acceleration variations, hindering surface quality improvements. The paper presents a five-axis toolpath corner-smoothing method based on the space of master–slave movement (SMM), aiming to minimize curvature fluctuations in five-axis machining and improve surface quality. The concept of movement space in master–slave cooperative motion is introduced, where the tool tip position and tool orientation are decoupled into a main motion trajectory and two master–slave movement space trajectories. By deriving the curvature monotony conditions of a dual Bézier spline, a G2-continuous tool tip corner-smoothing curve with minimal curvature fluctuations is constructed in real-time. Subsequently, using the SMM and the asymmetric dual Bézier spline, a high-order continuous synchronization relationship between the tool tip position and tool orientation is established. Simulation tests and machining experiments show that with our smoothing algorithm, maximum acceleration values for each axis were reduced by 21.05%, while jerk was lowered by 22.31%. These results indicate that trajectory smoothing significantly reduces mechanical vibrations and improves surface quality. Full article

This article discusses the issue of the joint use of neural network algorithms for data processing and deterministic mathematical models. The use of a new approach is proposed, to determine the discrepancy between data from a vibration monitoring system of the cutting process and the calculated data obtained by modeling mathematical models of the digital twin system of the cutting process. This approach is justified by the fact that some coordinates for the state of the cutting process cannot be measured, and the vibration signals measured by the vibration monitoring system (the vibration acceleration of the tip of the cutting tool) are subject to external disturbing influences. Both the experimental method and the Matlab 2022b simulation method were used as research methods. The experimental research method is based on the widespread use of modern analog vibration transducers, the signals from which undergo the process of digitalization and further processing in order to identify arrays of additional information required for virtual digital twin models. The results obtained allow us to formulate a new conceptual approach to the construction of systems for determining the degree of cutting tool wear, based on the joint use of computational virtual models of the digital twin system and data obtained from the vibration monitoring system of the cutting process. Full article

One of the most effective methods to limit the mechanical vibrations of bladed disks is the use of friction damping at mechanical joint interfaces. Unfortunately, dedicated tests to assess the impact of mistuning and the effectiveness of friction dampers are uncommon. This paper presents an original design of an academic demonstrator to perform an experimental analysis of the dynamic response of a tip-free bladed disk with under-platform dampers (UPDs), including an identification of intrinsic and contact mistuning introduced by the UPDs. The 48-blade disk was tested in a vacuum spinning rig by using permanent magnets. Vibration measurements were performed with the Blade Tip-Timing system. Tests were simulated using the Policontact tool, which predicted the average experimental nonlinear response in the presence of UPD, confirming the tool’s ability to capture the general nonlinear dynamic behavior of the mistuned bladed disk. This study presents a novel approach combining experimental Blade Tip Timing (BTT) with numerical simulations using Policontact (ver. 3.0) software and a model update based on experimental evidence to validate nonlinear dynamic responses. It distinguishes between intrinsic and contact mistuning effects, providing new insights into their impact on bladed disk vibrations. Additionally, a comparison of aluminum and steel UPDs reveals that steel offers a 26% greater damping efficiency due to its higher density and preload, significantly improving vibration reduction. Full article

Nucleic acid tests are key tools for the detection and diagnosis of many diseases. In many cases, the amplification of the nucleic acids is required to reach a detectable level. To make nucleic acid amplification tests more accessible to a point-of-care (POC) setting, isothermal amplification can be performed with a simple heating source. Although these tests are being performed in bulk reactions, the quantification is not as accurate as it would be with digital amplification. Here, we introduce the use of the vibrating sharp-tip capillary for a simple and portable system for tunable on-demand droplet generation. Because of the large range of droplet sizes possible and the tunability of the vibrating sharp-tip capillary, a high dynamic range (~2 to 6000 copies/µL) digital droplet loop-mediated isothermal amplification (ddLAMP) system has been developed. It was also noted that by changing the type of capillary on the vibrating sharp-tip capillary, the same mechanism can be used for simple and portable DNA fragmentation. With the incorporation of these elements, the present work paves the way for achieving digital nucleic acid tests in a POC setting with limited resources. Full article

Inconel 718 has excellent thermal and chemical properties and is widely used in the manufacture of aerospace parts; however, there are some problems in the machining of Inconel 718, such as a large milling force, serious tool wear, and poor surface quality. In this research, a type of longitudinal–torsional ultrasonic milling (LTUM) tool is designed based on theoretical computations and FEM simulation analysis. To verify the design rationality of the developed LTUM tool, milling experiments are performed. It is verified that the LTUM tool can realize an elliptical vibration path at the tool tip. The resonance frequency of the tool is 21.32 kHz, the longitudinal amplitude is 6.8 µm, and the torsional amplitude is 1.4 µm. In the milling of Inconel 718, the experimental data of LTUM are compared with those of conventional milling (CM). The comparative experiments show that the LTUM tool can effectively lessen the milling force and tool wear in the milling of Inconel 718, improve the surface quality, inhibit the generation of burrs, and improve the chip breaking ability. The application potential of the LTUM tool in high-performance milling of Inconel 718 parts is proven. Full article

Ultrasonic elliptical vibration-assisted cutting (UEVC) has been successfully applied in the precision and ultra-precision machining of hard and brittle materials due to its advantages of a low cutting force and minimal tool wear. This study developed a novel double-excitation ultrasonic elliptic vibration-assisted cutting (D-UEVC) device by coupling ultrasonic vibrations in orthogonal dual paths. A two-degree-of-freedom vibration system of the D-UEVC was modeled, form which the elliptical trajectory of the end under different phase angle φ values was derived. The initial dimensions of the D-UEVC device were obtained through theoretical calculations. Subsequently, with the aid of finite element analysis methods, structural dynamic analysis of the device was conducted to obtain the elliptical vibration trajectory under different phase differences of the excitation source. In order to verify the cutting trajectory and cutting performance of the D-UEVC device, a prototype of the device was developed, and a series of vibration performance tests as well as the Inconel 718 cutting experiment were conducted. The experimental results illustrated that the D-UEVC device can achieve the elliptical vibration trajectory at the tool tip with a resonant frequency of 36.5 KHz. The adjustable elliptical vibration trajectories covered a range of ±4 μm in the axial and radial directions. Compared with the surface roughness Ra = 0.36 μm under the conventional cutting, the surface roughness of Inconel 718 under D-UEVC was Ra = 0.215 μm. Thus, the surface quality can be significant improved by utilizing the D-UEVC device. Full article

Strategies for obtaining deep slots in soft materials can vary significantly. Conventionally, the tool travels along the slot, removing material mainly with the side cutting edges. However, a “plunge milling” strategy is also possible, performing the cut vertically, taking advantage of the tip cutting edges that almost reach the center of the tool. Although both strategies are already commonly used, there is a clear gap in the literature in studies that compare tool wear, surface roughness, and productivity in each case. This paper describes an experimental study comparing the milling of deep slots in AA7050-T7451 aluminum alloy, coated with a novel DLCSiO500W3.5O₂ layer to minimize the aluminum adhesion to the tool, using conventional and plunge milling strategies. The main novelty of this paper is to present a broad study regarding different factors involved in machining operations and comparing two distinct strategies using a novel tool coating in the milling of aeronautical aluminum alloy. Tool wear is correlated with the vibrations of the tools in each situation, the cycle time is compared between the cases studied, and the surface roughness of the machined surfaces is analyzed. This study concludes that the cycle time of plunge milling can be about 20% less than that of conventional milling procedures, favoring economic sustainability and modifying the wear observed on the tools. Plunge milling can increase productivity, does not increase tool tip wear, and avoids damaging the side edges of the tool, which can eventually be used for final finishing operations. Therefore, it can be said that the plunge milling strategy improves economic and environmental sustainability as it uses all the cutting edges of the tools in a more balanced way, with less global wear. Full article

During micro-milling, regenerative chatter will decrease the machining accuracy, destabilize the micro-milling process, shorten the life of the micro-mill, and increase machining failures. Establishing a mathematical model of chatter vibration is essential to suppressing the adverse impact of chatter. The mathematical model must include the dynamic motions of the cutting system with the spindle–holder–tool assembly and tool runout. In this study, an integrated model was developed by considering the centrifugal force induced by rotational speeds, the gyroscopic effect introduced by high speeds, and the tool runout caused by uncertain factors. The tool-tip frequency-response functions (FRFs) obtained by theoretical calculations and the results predicted by simulation experiments were compared to verify the developed model. And stability lobe diagrams (SLDs) and time-domain responses are depicted and analyzed. Furthermore, experiments on tool-tip FRFs and micro-milling were conducted. The results validate the effectiveness of the integrated model, which can calculate the tool-tip FRFs, SLDs, and time responses to analyze chatter stability by considering the centrifugal force, gyroscopic effect, and tool runout. Full article

DNA identification is possible by detecting its components through vibrational spectroscopy. Conventional Raman, Surface-enhanced Raman spectroscopy (SERS) and Tip-enhanced Raman spectroscopy (TERS) have shown a high capacity for the exploration of different molecules and materials (semi-conducting material, carbon nanotubes and biologicals molecules as DNA, proteins). Their applications extended to biological systems and brought significant information to this field. This review summarizes a high number of studies and research conducted with conventional Raman, SERS and TERS on every DNA component starting from the four different nucleic acids in their different forms (nucleosides, deoxyribonucleosides, deoxyribonucleotides) to their biological interaction to form one and double DNA strands. As SERS has an advantage on conventional Raman by exploiting the optical properties of metallic nanostructures to detect very small quantities of molecules, it also clarifies the DNA structure’s orientation in addition to its composition. It also clarifies the influence of different parameters, such as the presence of a spacer or a mutation in the strand on the hybridization process. TERS was shown as a relevant tool to scan DNA chemically and to provide information on its sequence. Full article

In this paper, the tool-tip responses for ball end milling, due to the coupling effects of a flexible rotor-bearing system, are investigated numerically. The milling machine tool spindle is modelled as the flexible rotor-bearing system. The critical speeds, natural modes, and unbalance responses of the system are calculated by applying the generalized polynomial expansion method. This generalized polynomial expansion method expresses the displacement as a series formed by the product of generalized coordinates and axial coordinate polynomials. According to the dynamic cutting force obtained by some scholars in the past, combined with the characteristics of the flexible rotor, the dynamic response of the tool-tip for ball end milling is numerically analyzed. The responses, including time histories, orbits, and FFT diagrams, are plotted to analyze the dynamic behaviors of the tool-tip. The coupling effects of the flexible rotor-bearing system on the system for ball end milling are first studied using the generalized polynomial expansion method. Unlike previous studies, the natural frequency varies with spindle speed and which of the different modes are included in the tool-tip response depends mainly on the spindle speed. Thanks to the gyroscopic effect, the critical speeds and responses of tool-tips can be discussed with respect to various spindle speed and tool flutes. The natural modes are accurately determined, and will excite critical speeds for certain modes, including forward and backward modes, thereby significantly affecting tool-tip response. In addition, the cutting force component associated with the tool-tip response affects the rotor-bearing system parameters, complicating the issue. Milling at higher spindle speed (2160–19,950 rpm), an important new result is found that the tool-tip oscillates with the cutting-force frequency, accompanied by a longer period vibration of the first backward mode of the rotor-bearing system. It can also be seen from the frequency spectrum analysis that, as the spindle speed increases, the peak amplitude of the first backward mode becomes larger. Milling at lower spindle speed (960, 1320 rpm), the in-plane vibration trajectory of the tool-tip gradually expands outwards clockwise around the origin until a stable loop is reached. This is because only the first backward mode of the rotor-bearing system is excited. Considering the coupling effect of the rotor-bearing system to perform the vibration analysis of the milling machine system, the parameters of the system can be designed or the spindle speed can be selected to avoid severe vibration during machining. Full article
