This paper investigates the microstructural evolution and mechanical performance of dissimilar friction stir-welded (FSW) T-joints produced from AA5083-H111 and AA7020-T651 aluminium alloys. The study focuses on the effects of tool rotational speed, traverse speed, and tool pin length on joint quality and mechanical strength. Welding experiments were conducted at two rotational speeds (400 and 700 rpm) and three traverse speeds (50, 100, and 200 mm/min) using two Triflute tools with pin lengths of 4.8 mm and 6.8 mm. The welded joints were examined by macro- and microstructural observations, microhardness measurements, and bending tests performed under pull-out loading conditions. The results showed that the use of the longer pin significantly improved material mixing and reduced the extent of internal defects, resulting in higher bending strength. Increasing the traverse speed improved the mechanical performance, whereas an excessively high rotational speed reduced joint strength due to increased heat input and unfavourable microstructural changes. Microhardness profiles showed no reduction in hardness within the heat-affected zones relative to the base materials and indicated localised hardening in the stir zone. For the investigated material configuration and tool geometries, the highest joint strength was obtained at a rotational speed of 400 rpm and a traverse speed of 200 mm/min using the longer-pin tool. The study confirms the critical role of process parameter optimisation and tool geometry in producing high-quality dissimilar FSW T-joints suitable for lightweight structural applications. Full article

This study evaluates the mechanical performance of FDM-printed poly(lactic acid) (PLA) structures joined using a portable Friction Stir Welding (FSW) device. A non-destructive optical band method was employed to assess weld homogeneity and material flow consistency. The influence of substrate infill density (15% and 100%) and tool pin geometry (cylindrical and truncated conical) was systematically analyzed. Results indicate that substrate density is the primary determinant of joint integrity; 100% infill specimens demonstrated superior structural homogeneity and consistent intensity profiles, whereas 15% infill specimens exhibited significant intensity fluctuations and poor consolidation, even with the addition of filler material. The mechanical evaluation revealed that the use of a tool pin is essential for effective load transfer, as specimens welded without internal agitation achieved only baseline tensile strengths of approximately 4 MPa. Among the pin-driven configurations, the cylindrical geometry outperformed the truncated conical design, reaching a peak tensile stress of 8.02 ± 1.42 MPa, corresponding to a joint efficiency of 27% relative to the 100% infill base material, compared to 6.25 ± 1.43 MPa. This performance gap is attributed to the cylindrical pin’s ability to maintain higher shear rates and more uniform pressure distribution at the weld root. These findings demonstrate the feasibility of portable FSW for structural joining of additively manufactured polymers and establish critical processing parameters for the optimization of portable FSW in engineering applications. Full article

This study examines the influence of straight square (SQ) and taper threaded (TT) tool pin geometries on the friction stir processing (FSP) of pure aluminum-based composites. Both pins had a shoulder-to-pin ratio of 3, with FSP conducted at 2400 rpm, 40 mm/min, and 11.2 kN axial force. Elemental and XRD analyses showed that the TT pin achieved superior reinforcement dispersion and formation of longer intermetallic chains. The TT pin also produced higher tensile strength (84.68 MPa) and elongation (27.92%), with SEM revealing ductile fracture features. The TT pin demonstrated better overall performance and is recommended for pure aluminum-based composite fabrication. Full article

Excessive surface friction encountered during metal-forming processes typically leads to die wear and seizure in part surfaces, which consequently shortens the die’s service lifespan and lowers the surface quality of the formed parts. To minimize surface friction, tool surface modification is required. This study focuses on reducing the sliding friction of SKH51 high-speed steel by fabricating micro-grooves with various crosshatch angles using a nanosecond pulse laser. The effects of laser texturing parameters on achieving the groove aspect ratio of 0.1 were investigated. This aspect ratio facilitates lubricant retention and enhances lubrication performance on the contact surfaces. The influence of groove crosshatch angles (30°, 60°, and 90°) on the friction in the sliding contact between a textured high-speed steel disc and an AISI304 stainless steel pin was evaluated using a pin-on-disc test with a constant load. Moreover, the contact pressure distribution and stress concentration associated with each groove pattern were numerically analyzed using the finite element method. The results demonstrated that a laser power of 20 W effectively produced groove geometries with the desired aspect ratio. Among the tested patterns, the surface textured with a 60° crosshatch angle exhibited the lowest coefficient of friction of 0.111, compared to 0.148 for the untextured surface. Finite element analysis further revealed that the 60° crosshatch pattern provided the most balanced combination of load redistribution, reduced mean pressure, and average stress, which may reduce the friction under sliding conditions. These findings confirm that laser surface texturing, particularly with an optimized crosshatch angle, can significantly reduce sliding friction and enhance the tribological performance of high-speed steel tools. Full article

The incorporation of multi-material design (MMD) to achieve lightweight vehicles requires Friction Stir Spot Welding (FSSW) to join steel with aluminum, magnesium, or composites. This study investigates the mechanisms, challenges, and performance of FSSW in MMD based on the information available in the literature. It also explores the effect of FSSW tool geometries and design on the spot weld formation and mechanical strength. Larger shoulder and pin diameters increase heat generation during welding. A concave shoulder profile produces a stronger weld compared to flat and convex profiles due to its ability to trap materials and transfer materials to the sheet interface efficiently for the development of a sound weld. Grooves such as Fibonacci and involute, and threads on P-FSSW and R-FSSW tools, also contribute to effective material flow during welding, hence assisting in heat generation. This review also provides recommendations on tool design for FSSW, P-FSSW, and R-FSSW. Full article

Over the past decade, friction stir spot welding (FSSW) has gained increasing attention, making it a competitor to conventional welding methods such as resistance welding, rivets, and screws. This type of welding is environmentally friendly because it does not require welding tools and is solid-state welding. This study attempts to demonstrate the importance of pin geometry on temperature distribution and joint quality by using threaded and non-threaded pins for similar and dissimilar alloys. To this end, thermal analysis of the welded joints was conducted using real-time monitoring from a thermal camera and an infrared thermometer, in addition to finite element method (FEM) simulations. The thermal analysis showed that the generated temperatures were higher in dissimilar alloys (Al-Cu) than in similar ones (Al-Al), reaching about 350 °C. In addition, dissimilar alloys show more pronounced FSSW stages through extended periods for each plunging, dwelling, and drawing-out time. The FEM simulation results are consistent with those obtained from thermal imaging cameras and infrared thermometers. The dwelling time was influential, as the higher it was, the more heat was generated, which could be close to the melting point, especially in aluminum alloys. This study provides an in-depth experimental and numerical investigation of temperature distribution throughout the welding cycle, utilizing different pin geometries for both similar and dissimilar non-ferrous alloy joints, offering valuable insights for advanced industrial welding applications. Full article

In this paper, we are looking for the answer to the following question: what geometric deviations do polymer gears made by 3D printing have from the theoretical geometry? From a practical point of view, the question is whether the currently installed injection-molded gear can be replaced by a 3D-printed gear. Thus, the measurements are also carried out on the sample gear and the comparison is made with this data as well. Knowing the data of the existing gear wheel, the CAD model was created, and based on this, samples of the gear were printed using various 3D printing machines. The printed gears were then subjected to geometrical analysis. During the inspection, we performed the measurement of the chordal thickness of the gear wheel using a gear tool caliper, instead of pin measurement and span measurement using a special micrometer, and 3D scanning and analysis. A surface roughness measurement was carried out as well. By conducting measurements on the injection-molded and 3D-printed samples, this research seeks to evaluate the reliability and limitations of the 3D-printed gears, providing insights into their industrial use. This study aims to determine whether 3D printing technologies can produce gears with sufficient accuracy and surface quality for practical applications. Based on the conducted analysis, general conclusions were drawn regarding the potential applicability of the 3D-printed gears. The experimental results indicate notable differences in dimensional accuracy between gears manufactured using Fused Deposition Modeling (FDM) and Selective Laser Sintering (SLS). In terms of chordal thickness measurements, FDM gears exhibited a mean relative error of 1.96 mm, whereas SLS gears showed a significantly higher average deviation of 5.64 mm. For the pin measurement, the relative error averaged 0.193 mm in the case of FDM gears, compared to 0.616 mm for SLS gears. Similarly, the span over four teeth measurements resulted in an average deviation of 0.153 mm for FDM gears, while SLS gears demonstrated a markedly higher mean error of 0.773 mm. With regard to surface roughness, it can be concluded that SLS-manufactured gears exhibit superior performance compared to FDM gears, with an average Ra value of 2.65 µm versus 9.28 µm, although their surface quality remains inferior to that of the injection-molded gear. In light of the higher relative errors observed in SLS gears compared to FDM gears, the dimensions of the theoretical model should be refined to improve the manufacturing accuracy of SLS-produced gears. Full article

The trailing edge of gas turbine blades encounters concentrated heat loads, necessitating cooling techniques distinct from those used in mid-chord regions. Narrow cooling channels in these areas typically incorporate pin fins or dimples for internal cooling. In contrast, external cooling relies on cutback film cooling configurations, which differ significantly from mid-chord designs. Large eddy simulation (LES) has emerged as a powerful tool for investigating heat transfer in these challenging environments, capturing intricate flow phenomena and turbulence effects that Reynolds-Averaged Navier–Stokes (RANS) simulations often cannot resolve. This review synthesizes findings from 54 LES-based studies on trailing edge cooling, focusing on three key configurations: pin fin arrays, dimpled surfaces, and cutback film cooling. LES consistently demonstrated higher accuracy in predicting heat transfer and cooling effectiveness, outperforming RANS by resolving complex flow structures such as horseshoe vortices, shear layer vortices, and unique flow interactions inherent to these geometries. Furthermore, LES provided detailed turbulence statistics and local heat transfer distributions, offering critical insights for optimizing and improving predictive models. Beyond its demonstrated capabilities, this review underscores the future potential of LES in advancing shape optimization, transient flow analysis, and multi-physics simulations, including conjugate heat transfer and flow-structure interactions. Full article

Friction stir spot welding (FSSW) technology relies on the generation of frictional heat during the rotation of the welding tool in contact with the workpiece as well as the stirring effect of the tool pin to produce solid-state spot joints, especially for lightweight materials. Although FSSW offers significant advantages over traditional fusion welding, the oxidation of the interfacial bond line remains one of the most challenging issues, affecting the quality and strength of the joint under both static and cyclic loading conditions. In this experimental study, inert argon gas was employed to surround the joint, aiming to prevent or minimize the formation of the interfacial oxides. Two welding processes were conducted with identical welding process parameters and welding tool geometry: the conventional process and another that employs an inert gas cover. Micrographs of as-welded specimens were analyzed using a computerized optical microscope to characterize the interfacial bond lines and an energy-dispersive spectroscope (EDS) was used to quantify the interfacial oxides. Specimens from both welding conditions were tested under static and cyclic loads to investigate the static and fatigue behaviors, respectively. The fatigue tested specimens were examined under different load levels to investigate the fatigue crack behavior and the modes of failure at low-cycle and high-cycle fatigue conditions. The optical micrographs showed significant improvement in bond line morphologies (33% enlarged fully bonded area) and both static and fatigue strengths (35% reduced partially bonded area) when the inert gas cover was used. The EDS analysis revealed a maximum reduction of the interfacial oxide of 41% in the bond line achieved in the argon-surrounded joints compared to specimens of the conventional welding process. Accordingly, an improvement of 14% in the static strength was reached, along with 60% and 26% in the fatigue strengths at low- and high-cycle fatigue conditions, respectively. Full article

The CERCHAR abrasivity test is a widely used index test in earth and subsurface works, delivering numerical values for abrasion that are critical to the selection of excavation tools, TBM performance or cost and project schedule estimates. The test evaluates the wear of the tip of a standardized metal pin after a scratch test on a rock surface. However, excavatability is not considered in this test. The present study presents an approach to assessing the material removal of a rock specimen due to the scratching action of a steel pin. The concept is tested for a broad range of sedimentary, metamorphic and igneous rocks. The volume of removed rock material is determined by measuring the width of the scratch groove and assuming an idealized trapezoid geometry. The CAI and volumetric removal are used to calculate the CERCHAR abrasivity ratio (CAR), and the results are in good agreement with those from the literature where specialized equipment was used. A classification scheme to estimate the excavatability of rock based on the CAI in combination with the material removal of a rock specimen is introduced. Based on the amount of material removed and the wear on the pin, an estimate can be made as to whether the excavation is likely to be economical in terms of time and material costs. The approach does not require additional testing, but rather makes use of the inherent geometry of the steel pin and the scratch groove on the rock specimen. The approach can be implemented as a complementary analysis to the existing CERCHAR test with little additional effort. Full article

To meet the demand for energy-efficient and, at the same time, durable, functional components, the improvement of tribological behavior is playing an increasingly important role. One approach to reducing friction in lubricated tribological systems is the microtexturing of the surfaces tailored to the application, but in most cases, this leads to increased manufacturing costs and thus often makes their use in industry more difficult. In this work, we, therefore, present an approach for an efficient design and fully integrated production process using a cam tappet as an example. For the used cam tappet contact, we first determined the optimal texture geometries using two differently complex EHL (elastohydrodynamic lubrication) simulation models. Based on these, textured tappets were manufactured in a combined manner using sheet-bulk metal-forming and deposition with a diamond-like-carbon (DLC) coating for additional wear protection without further post-processing of the coating. We show that the simulation approach used has a rather subordinate influence on the optimization result. The combined forming of components with textured surfaces is limited by the local material flow, the resulting texture distortion, and tool wear. However, a targeted process design can help to exploit the potential of single-stage forming. The applied DLC coating has good adhesion and can completely prevent wear in subsequent reciprocal pin-on-disc tests, while the friction in the run-in behavior is initially higher due to the soothing effects of the coating. The experiments also show a tendency for shallow textures to exhibit lower friction compared to deeper ones, which corresponds to the expectations from the simulation. Full article

Parts produced using a 3D printer are combined with friction stir welding (FSW). In the FSW processing of parts with a low infill ratio, welding errors occur due to a lack of material. In this study, plates were created using two different-colored PLA Plus filaments with different infill ratios in the weld area (20%, 60%, and 100%). Triangular pin geometry, different feed rates (20, 40, and 60 mm/min), and different tool rotation speeds (1250, 1750, and 2250 rpm) were used as FSW process parameters. Tensile testing was performed to determine weld strength and hardness measurements, and visual inspections were performed. Color measurements were made on the test samples before and after the welding process, and the relationship between welding performance and color was evaluated. The best welding strength was obtained as 17.83 ± 0.68 MPa at a feed rate of 20 mm/min, a tool rotation speed of 1750 rpm, and a part with a 60% infill ratio in the welding zone. In the sample with the best weld strength, the temperature was measured as 198.97 °C. Color changes in the weld area of parts with 60% and 100% infill ratios were measured between 78.9–82.2 and 79.1–84.5, respectively. It was determined that the color change decreases as the weld strength increases in these parts. The results show that with the proposed new part design, the FSW method can be used at low infill ratios, and the weld strength can be evaluated based on the color changes in the weld zone. Full article

Aluminium matrix composites (AMCs) represent an important group of high-performance materials. Due to their specific strength and a high thermal conductivity, these composites have been considered for the large-scale production of brake discs. However, preconditioning the friction surfaces is necessary to avoid severe wear of both the brake discs and the brake linings. This can be achieved through controlled friction against commercially available brake-lining materials and the formation of transfer or reactive layers (tribosurfaces). Homogeneous tribosurfaces allow for nearly wear-free brake systems under moderate brake conditions. In this work, preconditioning was carried out with a pin-on-disc tester, aiming for the fast creation of homogeneously formed and stable tribosurfaces. The influence of surface microedges perpendicular to the direction of friction on the machined AMC surfaces on the build-up speed and homogeneity of the tribosurfaces was investigated. The microedges were generated using ultrasonic-vibration-superimposed face turning. Thereby, the vibration direction corresponded to the direction of the passive force. For research purposes, the distance of the microedges was changed by varying the cutting speed and feed. The experiments were carried out using AMC disc specimens with a reinforcement content of a 35% volume proportion of silicon carbide particles. Machining was realised with CVD-diamond-tipped indexable inserts. The evaluation of the generated surfaces before and after preconditioning was achieved using 3D laser scanning microscopy and scanning electron microscopy. It was demonstrated that ultrasonic-vibration-superimposed face turning effectively generated microedges on the AMC surfaces. The results show that larger distances between the microedges enhanced the formation of stable tribosurfaces. Thus, the tribosystem’s steady state was reached quickly. Therefore, the benefits of AMC-friction-surface microstructuring on the generation of tribosurfaces under laboratory conditions were proven. These findings contribute to the development of high-performance AMC brake systems. Full article

Within the drilling, petrochemical, construction, and related industries, coatings are used to recover components that failed during service or to prevent potential failures. Due to high stresses, such as wear and corrosion, which the materials are subjected to, industries require the application of coating between dissimilar materials, such as carbon steels and stainless steels, through arc welding processes. In this work, an austenitic stainless steel (ER308) coating was applied to an H13 tool steel substrate using the gas metal arc welding (GMAW) robotic process. The heat input during the process was calculated to establish a relationship between the geometry obtained in the coating and its dilution percentage. Furthermore, the evolution of the microstructure of the coating, interface, and substrate was evaluated using XRD and SEM techniques. Notably, the presence of martensite at the interface was observed. The mechanical behavior of the welded assembly was analyzed through Vickers microhardness, and a pin-on-disk wear test was employed to assess its wear resistance. It was found that the dilution percentage is around 18% at high heat input (0.813 kJ/mm) but decreases to about 14% with reduced heat input. Microhardness tests revealed that at the interface, the maximum value is reached at about 625 HV due to the presence of quenched martensite. Moreover, increasing the heat input favors wear resistance. Full article

Friction Stir Welding is a suitable solid-state joining technology to connect dissimilar materials. To produce an effective joint, a phase of optimization is required which leads to the definition of process parameters such as pin geometry, tool rotational speed, rotation direction, welding speed, thickness of the sheets or tool tilt angle. The aim of this review is to present a complete and detailed frame of the main process parameters and their effect on the final performance of a friction stir welded joint in terms of mechanical properties and microstructure. Attention was focused in particular on the connection between different aluminum alloys. Moreover, the experimental results were correlated to the development and the applications of tools which can be effectively used in the design of the manufacturing process such as finite element analyses, artificial neural networks, and statistical studies. The review also aims to be a point of reference to identify the best combinations of process parameters based on the dissimilar aluminum to be joined. Full article
