Search Results (38)

This study presents a detailed analysis of the influence of hole presence and size on the behavior of CFRP composite plates subjected to axial compression. The plates were manufactured by an autoclave method from eight-ply laminate in a symmetrical fiber arrangement [45°/−45°/90°/0°₂/90°/−45°/45°]. Four central hole plates of 0 mm (reference), 2 mm, 4 mm, and 8 mm in diameter were analyzed. Tests were conducted using a Cometech universal testing machine in combination with the ARAMIS digital image correlation (DIC) system, enabling the non-contact measurement of real-time displacements and local deformations in the region of interest. The novel feature of this work was its dual use of independent measurement methods—machine-based and DIC-based—allowing for the assessment of boundary condition effects and grip slippage on failure load accuracy. The experiments were carried out until complete structural failure, enabling a post-critical analysis of material behavior and failure modes for different geometric configurations. The study investigated load–deflection and load–shortening curves, failure mechanisms, and ultimate loads. The results showed that the presence of a hole leads to localized deformation, a change in the failure mode, and a nonlinear reduction in load-carrying capacity—by approximately 30% for the largest hole. These findings provide complementary data for the design of thin-walled composite components with technological openings and serve as a robust reference for numerical model validation. Full article

Titanium alloy/carbon fiber-reinforced polymer (TA1/CFRP) laminates, representing the latest fourth generation of fiber metal laminates (FMLs), is a kind of high-performance composite material. However, the fragility of the fiber/resin and metal/resin interface layers in these composites directly impacts their mechanical properties. To enhance these properties, this paper investigates the preparation process of multi-walled carbon nanotube (MWCNT)-reinforced ultra-thin TA1/CFRP laminates and explores the impact of MWCNT content on the interlayer properties of these ultra-thin TA1/CFRP laminates. Initially, the challenge of dispersing carbon nanotubes using ultrasonic dispersion devices and dispersants was addressed. Vacuum-curing pressure studies revealed minimal overflow at 0.8 bar vacuum. Subsequently, the impact of MWCNT content on interlayer properties was investigated. The results indicated a significant increase in interlayer shear strength and interlayer fracture toughness with MWCNT additions at 0.5 wt% and 0.75 wt%, whereas the interlayer properties decreased at 1.0 wt% MWCNT. Fracture morphology analysis revealed that MWCNT content exceeding 0.75 wt% led to agglomeration, resulting in resin cavity formation and stress concentration. Full article

Polyethylene storage tanks are widely used for storing water and chemicals due to their lightweight and corrosion-resistant properties. Despite these advantages, their structural performance under seismic conditions remains a concern, mainly because of their low mechanical strength and weak bonding characteristics. In this study, a method of external strengthening using fiber-reinforced polymer (FRP) laminates is proposed and explored. The research involves a combination of laboratory testing on carbon fiber-reinforced polymer (CFRP)-strengthened polyethylene strips and finite element simulations aimed at assessing bond strength, anchorage length, and structural behavior. Results from tensile tests indicate that slippage tends to occur unless the anchorage length exceeds approximately 450 mm. To evaluate surface preparation, grayscale image analysis was used, showing that mechanical sanding increased intensity variation by over 127%, pointing to better bonding potential. Simulation results show that unreinforced tanks under seismic loads display stress levels beyond their elastic limit, along with signs of elephant foot buckling—common in thin-walled cylindrical structures. Applying CFRPs in a full-wrap setup notably reduced these effects. This approach offers a viable alternative to full tank replacement, especially in regions where cost, access, or operational constraints make replacement impractical. The applicability is particularly valuable in seismically active and densely populated areas, where rapid, non-invasive retrofitting is essential. Based on the experimental findings, a simple formula is proposed to estimate the anchorage length required for effective crack repair. Overall, the study demonstrates that CFRP retrofitting, paired with proper surface treatment, can significantly enhance the seismic performance of polyethylene tanks while avoiding costly and disruptive replacement strategies. Full article

This article presents, in detail, design considerations for a thin-walled glass fiber reinforced plastic (GFRP) liner on a fluid-cooled stator lamination of an electric motor. In addition to structural requirements due to the cooling fluid pressure, the GFRP liner needs to guarantee impermeability. Analytical considerations deriving from different coefficients of thermal expansion (CTEs) determine the two-layered laminate design. Empirical investigations show two innovative, simple, and, therefore, efficient test setups for the leakage of liquid media through a GFRP liner. The weeping investigations employ two different GFRP systems with four different configurations of interfiber failure (IFF) and, therefore, crack densities. The weeping investigations show that at least one ply in the laminate needs to be flawless regarding IFF cracks in order to guarantee the sealing function. Alternatively, a third sealing layer can be used. Full article

This paper investigates the flutter characteristics of composite laminates in hypersonic yawed flow using numerical simulations. The governing equations are derived based on Hamilton’s principle and were discretized using the assumed mode method. The unsteady aerodynamic force is calculated by using the piston theory, including the influence of the yaw angle. Several laminate models are designed to study the effects of the stacking sequence, thickness ratio, and fiber orientation on the critical dynamic pressure and the amplitude of the limit cycle oscillation. Numerical results show that positioning the material with higher stiffness on the upper layer can lead to a higher critical dynamic pressure and a smaller amplitude of the limit cycle oscillation. In the case of large yaw angles, increasing the thickness of the material with larger stiffness can clearly suppress the amplitude of the limit cycle oscillation. Fiber orientation symmetry to the x-axis can improve the flight stability with the change in the yaw angle. Full article

Natural fractures within the lacustrine mixed shale oil reservoirs of the upper member of the Lower Ganchaigou Formation (E₃²) in the Ganchaigou area of the Qaidam Basin are pivotal to the exploration and development of shale oil and gas. This research investigates the developmental characteristics and controlling factors of natural fractures and their impact on the reservoir quality based on cores, image logs, thin sections, scanning electron microscopy observations, and experimental and production data. The results indicate that natural fractures in the E₃² are categorized into tectonic fractures, diagenetic fractures, and abnormal high-pressure fractures. Tectonic fractures are characterized by a significant variation in dip angles, a wide range of apertures, low density, and a high filling degree. Diagenetic fractures typically exhibit low dip angles, small apertures, high density, and a low filling degree. Abnormal high-pressure fractures display chaotic orientations and complex styles, often consisting of filled fractures. The development and distribution of natural fractures are jointly influenced by mineral composition and brittleness, lamination structure, organic matter content and maturity, diagenesis, tectonic factors, and abnormal high pressure. A high content of dolomite, thin-bedded structures comprising carbonate laminae and felsic laminae, and abundant mature organic matter provide a favorable foundation for fracture development. Diagenesis, including dissolution, pressure solution, and mineral dehydration shrinkage, acts as a beneficial guarantee for fracture development. Tectonic locations near the hanging wall of faults and the core of anticlines are the main regions for fracture development. Abnormal high pressure is a crucial driving force for fracture development. Interconnected natural fractures of various types and scales significantly expand reservoir space and enhance pore connectivity and flow capacity, serving a vital function in maintaining high and stable production in lacustrine mixed shale oil reservoirs. Full article

The development of new encapsulating coatings for flexible solar cells (SCs) can help address the complex problem of the short lifespan of these devices, as well as optimize the technological process of their production. In this study, new laminate-type protective composite coatings were prepared using a silicon oxynitride thin-film matrix obtained by curing the pre-ceramic polymer perhydropolysilazane (PHPS) through two low-temperature methods: (i) thermal annealing at 180 °C and (ii) exposure to UV radiation at wavelengths of 185 and 254 nm. Single-walled carbon nanotubes (SWCNTs) were used as fillers via dry transfer, facilitating their horizontal orientation within the matrix. The optical, adhesive, and structural properties of the matrix films and SiO_xN_y/SWCNT composite coatings, along with their long-term stability, were studied using Fourier transform infrared spectroscopy (FTIR), UV-Vis spectroscopy, HR-SEM, spectral ellipsometry, and a progressive-load scratch test. In this work, the optical constants of PHPS-derived films were systematically studied for the first time. An antireflection effect was observed in the composites revealing their two-component nature associated with (i) the refractive index of the SiO_xN_y matrix film and (ii) the embedding of a SWCNT filler into the SiO_xN_y matrix. The curing method of PHPS was shown to significantly affect the resulting properties of the films. In addition to being used as protective multifunctional coatings for SCs, both SiO_xN_y/SWCNT composites and SiO_xN_y matrix films also function as broadband optical antireflective coatings. Furthermore, due to the very low friction coefficients observed in the mechanical tests, they show potential as scratch resistant coatings for mechanical applications. Full article

A comprehensive review is presented on the main analytical methods used in the specialized literature to evaluate the buckling loads of thin-walled cylindrical shells (TWCS) subjected to different mechanical loads or load combinations. The analytical formulations are first presented for unstiffened TWCS, followed by stiffened TWCS in different configurations (stiffeners in the axial direction, circumferential direction or both axial and circumferential directions, placed on the external or internal surface of the shell). This research can serve as a helpful resource for researchers investigating this field, allowing the analytical methods to be used as a reference basis for numerical and experimental results regarding the behavior of structures in the category of TWCS. Full article

This research focuses on investigating the buckling strength of thin-walled composite structures featuring various shapes of holes, laminates, and composite materials. A parametric study is conducted to optimize and identify the most suitable combination of material and structural parameters, ensuring the resilience of structure under both mechanical and thermal loads. Initially, a numerical approach employing the finite element method is used to design the C-section thin-walled composite structure. Later, various structural and material parameters like spacing ratio, opening ratio, hole shape, fiber orientation, and laminate sequence are systematically varied. Subsequently, simulation data from numerous cases are utilized to identify the best parameter combination using machine learning algorithms. Various ML techniques such as linear regression, lasso regression, decision tree, random forest, and gradient boosting are employed to assess their accuracy in comparison with finite element results. As a result, the simulation model showcases the variation in critical buckling load when altering the structural and material properties. Additionally, the machine learning models successfully predict the optimal critical buckling load under mechanical and thermal loading conditions. In summary, this paper delves into the study of the stability of C-section thin-walled composite structures with holes under mechanical and thermal loading conditions using finite element analysis and machine learning studies. Full article

This paper proposes a new type of composite box beam combined with cold-formed thin-walled steel and glued laminated timber to develop green building structures while improving the load-carrying capacity of a single steel girder and glued timber girder. Two composite beams composed of laminated timber and Q235 cold-formed thin-walled steel were designed and fabricated. Then, the shear performance test with quadratic loading was carried out to analyze the load carrying capacity, damage modes, and deformation characteristics of the test beams, as well as their influencing factors. Subsequently, a finite element model of the composite beam was established, and the loading mode was the same as that of the test to further study the parameters affecting the shear performance of the composite beam. The results of the study indicate that steel and glued timber in composite beams connected by adhesive bonding can work and deform together under load and each give full play to its material properties, especially the composite beams, which exhibit higher shear strength than a steel or timber beam. The effects of parameters such as steel cross-sectional area, shear span ratio, steel skeleton form, and steel cross-sectional strength on the shear capacity of the composite beams were observed, among which the shear span ratio had the greatest effect on the shear capacity of the composite beams. The shear capacity decreased by 14.3% and 19.5% when the shear span ratio was increased from 1.5 to 2.0 and 2.5, respectively. The shear capacity of the combined composite beams increased by 10.6%, 6.3%, and 5.8% when the thickness was increased from 1.5 mm to 2.0 mm, 2.5 mm, and 3.0 mm, respectively. When the combination of the steel cross-section was a box beam, the overall shear-bearing capacity could be increased by 12% compared with the “I” type composite beam, although its shear stiffness was close to that of the “I” section composite beam. Full article

When a tsunami occurs, people can enter floating shelters and save their lives. Tsunami shelters consisting of thin-walled fiber-reinforced plastic (FRP) spherical shells have been developed and are currently in use. In this study, a novel three-layer laminated spherical tsunami shelter and its fabrication method have been proposed as an alternative to the conventional thin-walled spherical FRP tsunami shelter. First, the inner and outer layers were made of thin-walled stainless-steel spherical shells using the integral hydro-bulge-forming (IHBF) method. The inter-layers between the inner and outer layers were filled with elastic rubber to provide a laminated spherical tsunami shelter with elastic cushioning layers. After the fabrication process was developed, a laminated spherical tsunami shelter with a plate thickness of 1.0 mm, an inner spherical shell design radius of 180 mm, and an outer spherical shell design radius of 410 mm was fabricated. The shape accuracy of the process was determined. The roundness values of the inner and outer layers of the spherical shell were 0.88 and 0.85 mm, respectively. The measured radii of the actual inner and outer spherical shells were 180.50 and 209.97 mm, respectively, and the errors between the design and measured radii were 0.28% and −0.01%. In this study, acceleration sensors were attached to the inner and outer layers of the processed, laminated spherical tsunami shelter. A hammer impact load was applied to the outer layer, and the response acceleration values measured by the acceleration sensors in the inner and outer layers were compared. It was confirmed that the response acceleration value of the inner layer was 10.17% smaller than that of the outer layer. It was then verified that the spherical tsunami shelter proposed in this study has a good cushioning effect and processing performance. Full article

Composite structural insulated panels (CSIPs) are eco-friendly, high-performance materials, which not only good have mechanical properties, but also good waterproof, moisture-proof, fire-proof, and anti-corrosion characteristics, so they have been used to build envelope structures in recent years. However, how to improve stiffness of CSIPs remains unsolved. The poor stiffness is one of the biggest obstacles for the application of CSIPs in the load-bearing members of civil engineering. In this study, the layout of glass–polypropylene (PP) laminate layers is designed to enhance its stiffness, and this study applies CSIPs as load-bearing members of civil engineering for the first time. Thus, the bend model of CSIP thin-wall box-beams under uniform loading is built, based on Timochenko’s theory. The deflection curve equation is presented, considering shearing deformation. The expressions for the bending of normal strain flanges of the beam and the equation considering principal shearing strain at the beam’s web are obtained, respectively. Finally, mechanical properties of the thin-wall box-beam under uniformly distributed loads were performed by FE. FE results are entirely consistent with the theoretical results, thereby making the theoretical method applicable for the design of thin-wall box-beams, which are made of composite materials. Different from other beams, the shearing deformation is a critical factor that influences the deformation of thin-walled box-beams. Full article

This study investigated thin-walled plate elements with a central cut-out under axial compression. The plates were manufactured from epoxy/carbon laminate (CFRP) with an asymmetric layup. The study involved analyzing the buckling and post-buckling behavior of the plates using experimental and numerical methods. The experiments provided the post-buckling equilibrium paths (P-u), which were then used to determine the critical load using the straight-line intersection method. Along with the experiments, a numerical analysis was conducted using the Finite Element Method (FEM) and using the ABAQUS^® software. A linear analysis of an eigenvalue problem was conducted, the results of which led to the determination of the critical loads for the developed numerical model. The second part of the calculations involved conducting a non-linear analysis of a plate with an initial geometric imperfection corresponding to structural buckling. The numerical results were validated by the experimental findings, which showed that the numerical model of the structure was correct. Full article

Lamb waves occur in thin-walled structures in two wave modes—the symmetric and the antisymmetric mode. Their oscillation on the structures‘ surfaces is either in phase (symmetric) or shifted by a phase angle of $\pi$ (antisymmetric). In this work, a method is developed by which to compare the surfaces’ oscillation phase relation to answer the question of whether fiber metal laminates show the same surface oscillation behavior as described for metals. The evaluation of time signals regarding the instantaneous phase angle is performed by using the continuous wavelet transformation and the short-time Fourier transformation. Numerical simulations utilizing the finite element method provide time signals from the top and bottom surface of different thin-walled structures of different material settings and configurations. The numerically obtained time signals are evaluated by the developed methods with respect to the oscillation phase. Subsequently, the oscillation phase is evaluated experimentally for the wave propagation in a fiber metal laminate. It is shown that the method based on the continuous wavelet transformation is suitable for the evaluation of oscillation phase relations in time signals. Additionally, it is proven that fiber metal laminates show only two phase relations, which indicates the occurrence of Lamb waves. Full article

The study investigated short, thin-walled Z-shaped carbon–epoxy laminate columns. Z-columns were compressed while considering the eccentric force realized from the center of gravity of the column section. The study involved performing a nonlinear analysis of the structures with implemented geometric imperfections reflecting the first buckling modes. The nonlinear analysis was performed by using the Tsai–Wu criterion to determine the effort of the composite material. The computations were run until the critical parameter was reached in the Tsai–Wu criterion, allowing for a description of the failure initiation mechanism in the composite material. The first signs of damage to the composite material were determined by using the acoustic emission method. Based on the results, postcritical equilibrium paths of the numerical models were determined. The equilibrium paths were then compared with the experimental characteristics of real structures. The numerical results and experimental findings show a satisfactory agreement. The results confirmed that the numerical models were adequate for estimating the performance of composite structures in the postcritical range, depending on the amplitude of compressive load eccentricity. The research topic undertaken is important because the thin-walled structure design relates to actual loads which, in most cases, differ from the idealized theoretical load conditions. Full article
