Search Results (21)

Seismic isolation systems play a crucial role in enhancing structural resilience during earthquakes, with lead rubber bearings being a widely adopted solution. These bearings incorporate lead cores to effectively dissipate seismic energy. However, their widespread application is constrained by significant drawbacks, including high costs and environmental concerns associated with lead. This study introduces a novel sustainable S-shaped steel damper made from standard steel. The influence of key geometrical parameters—thickness, width, and the distance from the bolt hole to the arc’s start—on the cyclic behavior of the dampers was investigated. Seven prototypes were designed, manufactured, and experimentally tested to evaluate their horizontal stiffness and damping performance. Subsequentially, the experimental results were considered for the validation of a numerical model based on a full 3D Finite Element discretization. The model, calibrated using simple uniaxial steel material tests, facilitates the identification of optimal geometric features for the production of S-shaped steel dampers without the need for extensive prototype fabrication and experimental testing. Additionally, the model can be seamlessly integrated into future numerical structural analyses, enabling a comprehensive evaluation of performance characteristics. In conclusion, this research provides critical insights into the geometric optimization of S-shaped steel dampers as cost-effective and sustainable dissipation devices. It offers both experimental data and a robust numerical model to guide future designs for improved seismic mitigation performances. Full article

A novel three-dimensional isolation system consisting of thick rubber bearing (TNRB), disc spring bearing (DSB), and laminated rubber bearing (LRB) in series combination was designed, and its composition, principle, and isolation effect were comprehensively analyzed. By combining numerical examples, the whole structure method is used to compare and analyze the dynamic characteristics, dynamic response, and structural damage of large-span isolation structures containing new three-dimensional systems, large-span horizontal isolation structures based on LRB, and corresponding non-isolation structures under multi-dimensional seismic excitation. The results show that compared with the horizontal isolation structure based on LRB, the structure of the new three-dimensional isolation system has a 33% longer vertical natural vibration period, a 17.85% attenuation in the overall damage index, and a 36.86% increase in vertical energy dissipation capacity. It can achieve good isolation effects in both horizontal and vertical directions, which can form a favorable complement to the horizontal isolation structure based on LRB in terms of vertical isolation and energy dissipation. Full article

Non-isolated structures have strong destructive effects and poor isolation effects when encountering earthquakes. Setting isolation bearings can prolong the natural vibration period of the structure, reduce the horizontal seismic response of the structure under the influence of variables such as acceleration, base reaction, and inter story displacement, and enhance the overall seismic performance of the structure. The new material—epoxy plate thick layer rubber isolation bearing—has unique advantages compared to other bearings, such as effective energy absorption, simple construction, and low cost. This study establishes a three-dimensional isolated nuclear power plant containment structure based on the principle of similarity ratio, and compares and analyzes the acceleration, base reaction, and displacement responses of non-isolated and isolated structures. At the same time, the incremental dynamic analysis method (IDA) is used to analyze the seismic vulnerability of the structure, and the isolation performance of the nuclear containment structure using epoxy plate thick layer rubber isolation bearings is comprehensively and deeply explored. The results show that the epoxy plate thick layer rubber isolation bearing effectively prolongs the natural vibration period of the structure, reduces the horizontal seismic response of the structure, reduces the dome acceleration response by 66.55%, and reduces the base horizontal shear force by 55.51%. Therefore, setting epoxy plate thick layer rubber isolation bearings in the isolation layer can effectively enhance the seismic performance of the structure, thereby improving the redundancy of the nuclear power plant containment structure. Full article

Potential damage caused by earthquakes combined with reduced comfort due to traffic has become a big challenge when designing modern buildings, and base-isolation is one of the most effective solutions to such a problem. However, most isolation bearings cannot provide sufficient mitigation for both earthquakes and traffic-induced vibrations simultaneously. To this end, this research proposes a new type of three-dimensional isolation bearing for the mitigation of both earthquake effects and traffic-induced vibrations, which is composited by a thick rubber bearing, an auto-reset flat sliding bearing, and a double concave friction pendulum bearing. In this study, the analytical hysteresis model of the proposed isolation bearing was derived and experimentally validated. In addition, the fatigue performance and vertical compression performance of the proposed isolation bearing was tested and analyzed. Finally, the mitigation effect for traffic-induced vibrations of the proposed isolation bearing was validated through a field test. Full article

It is known that a large amount of vibration mechanical energy will be generated during train operation. If the mechanical energy can be obtained from the track structure, it can greatly optimize the energy configuration of the metro. Currently, most sensors are limited to disk or cymbal structures and are not used in the track bed; different from existing structures, this paper designs a spherical energy harvester based on a rubber bearing floating slab track, wherein the size range of the spherical energy harvesting structure was approximately determined based on the geometric spatial relationships of the actual track bed internal structure. Compared to the traditional disk and cymbal energy harvesters, the mechanical and electrical properties of the spherical energy harvesting structure was studied by a numerical simulation method, and the optimal size of the spherical energy was determined by calculation. The main conclusions are as follows: (1) Compared with the traditional disk harvester and cymbal harvester, the spherical harvester had better mechanical and electrical properties. (2) By calculating the output power of energy harvesters under load matching, we found that the output power of the spherical harvester was two orders of magnitude higher than that of the disk harvester and 53% higher than that of the cymbal harvester. (3) The optimum size of the spherical harvester was when the thickness of piezoelectric layer was 2 mm, the radius was 16 mm, the axial ratio of the spherical shell was 0.4, and the thickness of the spherical shell was 4 mm. Full article

The aim of this study was to further research the mechanical properties of epoxy thick-layer rubber isolation bearings, adopting orthogonal design and efficacy coefficient methods in order to optimize the geometric dimensions and material parameters of the bearing, summarizing the influence of various factors on the overall performance indicators of the bearing, and determining the optimal plan through parameter adjustment. Through a combination of experiments and simulations, the fundamental characteristics of epoxy thick-layer rubber isolation bearings are studied to determine the influence law of vertical pressure on their horizontal stiffness, vertical stiffness, and damping ratio. The analysis results suggest that epoxy plate thick-layer rubber isolation bearing exhibits stable deformation ability and possesses distinctive damping characteristics. Furthermore, it is observed that the horizontal stiffness of these bearings gradually diminishes as the vertical pressure increases. When the shear displacement reaches 80 mm, there is a notable strengthening effect observed in the horizontal stiffness of the bearing. This strengthening phenomenon proves advantageous in preventing damage to the bearing due to excessive displacement; furthermore, it is noteworthy that the vertical stiffness and damping ratio of the bearing increased with the rise in vertical pressure. Full article

In order to study the effect of surface roughness on lubrication performance of an elastic support water-lubricated tilting pad thrust bearing, a mixed lubrication (ML) deterministic model is hereby presented based on a unified Reynolds equation model. This very model incorporates the elastic–plastic deformation of asperities and polymer matrix of the thrust pad, as well as the elastic deformation of the rubber support. The randomly distributed surface roughness of the thrust pad is generated by a mathematical model and shares the same distribution characteristics as the measured surface roughness. The Greenwood and Williamson asperity contact model and thin plate deformation model are combined to solve the asperities contact stress and deformation. Meanwhile, the bearing ML performance is compared with the results calculated by a thermohydrodynamic (THD) lubrication model and a thermo-elasto-hydrodynamic (TEHD) lubrication model, while the film thickness is also compared with measurements. The results show that the water film thickness calculated by the ML model is smaller than that by the THD model and the TEHD model, but the water film temperature is higher. The roughness has a great influence on the contact area ratio and the lubrication state, but little effect on the average film thickness. A higher roughness indicates a higher rotational speed required for the bearing to achieve full hydrodynamic lubrication. The film thickness calculated by the mixed lubrication model is closer to the measured results. Overall, it is proved that the mixed lubrication model can more accurately predict the lubrication performance of bearings. Compared to the thin plate deformation model, the elastic deformation simulation based on the half-infinite space model severely overestimates the elastic deformation of the pad surface, making it unsuitable for calculating the elastic deformation of the polymer matrix of the thrust pad under contact force or water film pressure. This ML deterministic model provides an effective means for high-precision prediction of the lubrication performance of the elastic supported water-lubricated thrust bearings coupled with multi-layer soft materials. Full article

This paper proposes a fluid-structure interaction (FSI) numerical calculation method for investigation of the elastohydrodynamic lubrication performance of the rubber-plastic double-layer water-lubricated journal bearings. The accuracy and rapidity of the FSI method are improved by studying the effect of mesh density and by comparing the calculation results with those in the literature. Based on the proposed method, a series of numerical simulations are carried out to reveal the influence of operating conditions and structural parameters on the lubrication performance of the rubber-plastic bearings. Numerical results show that the bush deformation of the rubber-plastic bearing is between that of the rubber bearing and the plastic bearing, and the deformation area is close to that of the rubber bearing. The bearing load carrying capacity increases significantly with the rotational speed, eccentricity ratio, bearing length, and decrease with the clearance. But the influences of the plastic layer elastic modulus and thickness on bearing load are unremarkable. The effect of bush deformation on bearing load is noticeable when the eccentricity ratio is more than 0.8. The results are expected to provide design references for the bearings. Full article

This study focused on comprehensively analyzing the construction, mechanism, and design theory of the Thick Rubber Bearing–Disk Spring Bearing (TNRB-DSB) system, with the aim of evaluating its isolation effect. Mechanical tests were conducted to examine the dynamic characteristics of large-span isolated structures equipped with TNRB-DSBs, and laminated rubber bearings (LRBs), as well as the dynamic responses of non-isolated structures and large-span horizontal isolated structures equipped with natural rubber bearings (NRBs) and LRBs, under various seismic excitations. Finite element software was utilized to compare the behaviors of these structures. The study revealed that the large-span isolated structure equipped with TNRB-DSBs and LRBs had a vertical natural vibration period 1.23 times as long as that of the isolated structure with NRBs and LRBs, and 4.27 times as long as that of the non-isolated structure. The TNRB-DSB system demonstrated good vertical and horizontal isolation capabilities, which compensated for the isolation limitations of other rubber bearings to some extent. Full article

High-damping rubber (HDR) material has been widely used in bearings for seismic-isolation devices in structures. Nevertheless, HDR has not yet been developed in dampers to reduce the response of structures to earthquake excitations by dissipating the energy applied to the structures under direct axial load. The purpose of this paper was to evaluate the feasibility of using novel hyperelastic composite material (HECM), which is an HDR material, in experimental investigations to determine its damping ratio, compressibility, and elasticity behavior under axial dynamic load for the development of novel dampers in the future. First, a series of tests on HECM was conducted using the double-shear method to determine the most suitable sample for a purely dynamic compression test. Subsequently, the HECM was used in a device working as a scaled-down damper under both direct tension and compression dynamic load conditions, and pure direct compression dynamic load conditions were tested. Various thicknesses of the HECM (6, 8, and 10 mm) used in the testing damper were examined under a constant force with various frequencies of 0.01, 0.1, 0.25, and 0.5 Hz. The results show that the 10 mm thick HECM can provide a high damping ratio of 10% to 13% under axial conditions. Hence, this study is important for evaluating HECM, which has the potential for use in developing a full-scaled rubber damper system to resist axial force in the future. The damper is a novel rubber damper with high damping capability to dissipate energy under axial load. Furthermore, the damper can serve as an alternative choice that is more durable and overcomes the current weaknesses of passive dampers. Full article

Focusing on the dilemma that the traditional lateral shear keys are ineffectual in limiting the displacement and repair of small-to-medium spanning highway bridges, this paper briefly describes the necessity of considering fiber-reinforced polymer concrete with the shear keys design, and studies the seismic performance of an alternative retainer that focuses on three functions of “limiting displacement”, “energy consumption”, and “alternative link”. In order to study the anti-seismic effectiveness under the seismic loads, four alternative retainer specimens with different sizes were designed. The quasi-static tests were carried out on four specimens, respectively. The seismic damage mode of the quasi-static alternative retainer was investigated. We examined the influence of the designed parameter of the alternative retainer on the anti-seismic effectiveness of the alternative retainer. Taking a two-span simply supported girder bridge, for example, the comparison between the seismic response of the bridge with retainers and without is analyzed based on a consideration of the sliding plate rubber bearings and the test results of the new retainers. The results show that the failure mode of the new alternative retainers is a two-stage process involving the alternative links: firstly shear failure and then the overall retainer damages, which is convenient to retrofit and reinforce post-earthquake. The thickness of the web of the alternative link, as a sensitive factor, influences the bearing capacity of the new retainers, yield displacement, ultimate displacement, ductility coefficient and overall energy consumption. The height of the alternative link will merely influence the ultimate bearing capacity, and transverse replacement of the main girder with the new alternative retainers is greatly reduced compared to without retainers, and the seismic response increase in the pier is gentle. Full article

The semi-fixed dowel joint studied in this paper consists of a steel dowel with rubber sleeves and a rubber pad to connect the superstructure and the substructure and to support the main beam. This type of joint is suitably used in retrofitting a jointed bridge with high-stiffness substructure into a semi-integral bridge. This study aimed to investigate the nonlinear stiffness of the joint, which is the key parameter in the retrofitting design. Taking the real joint in a retrofitted semi-integral bridge as a prototype, tests on full-scale models were carried out, in which the wall thickness of the rubber sleeve and the thickness of the rubber pad were taken as parameters. The test results show that the wall thickness of the rubber sleeve is the main factor affecting the radial stiffness and the flexural stiffness of the semi-fixed dowel joint. With the decrease of the wall thickness of the rubber sleeve, the radial stiffness decreases while the flexural stiffness increases. However, the thickness of the rubber pad has little influence on both the radial and flexural stiffness of the joint, and its main role is only vertical loading-bearing. If the longitudinal deformation of the main beam of a bridge under maximum temperature variation is 10 mm as the allowance value of engineering design, the wall thickness of the rubber sleeve for this joint should not be less than 40 mm. At last, on the basis of experimental research and theoretical analysis, the formulas of radial stiffness and flexural stiffness are fitted; it can be used as reference for practical engineering application, or for formulation of relevant specifications. Full article

The rotordynamic stability of journal gas foil–polymer bearings (GFPBs) applied to a dual-rotor bearing system was investigated. The GFPB has a high damping structure, i.e., it has an additional polymer layer, and top/bump/bottom foil structures. Test GFPBs were fabricated with nitrile butadiene rubber polymer layers with a thickness of 2 mm. Static-load-deflection tests of test gas foil bearings (GFBs) and GFPBs were performed to estimate the geometric bearing clearance (200 µm). The dual-rotor rotordynamic test rig consisted of a motor rotor, test rotor, and beam-type coupling. Two journal test bearings were installed on both the drive-end and non-drive-end sides of the test rotor. Predicting and testing the natural mode characteristics of the dual rotors revealed that the relative error between them was less than 7%, indicating that the first and second natural frequencies were 15 Hz and 160 Hz, respectively, and the third natural frequency was 1835 Hz in the tests. Based on the API 612 standard, the upper limit of the rotating speed for the test rig was limited to be approximately 92 krpm with a separation margin of 26%. Rotordynamic tests were conducted to examine the stability performance of GFBs and GFPBs, where the adjusted bearing clearance was 150 µm. The test results indicate that GFPBs have better stability performance in terms of delaying and suppressing unstable vibrations than GFBs. Specifically, GFPBs showed stable synchronous and subsynchronous responses up to a maximum rotating speed of 80 krpm. As a result, GFPB is a reliable lubricating element that can be used for vibration dampening in machines operating at relatively low temperatures. Full article

To improve the structural design rationality of cement concrete bridge deck pavement systems and reduce diseases such as interlayer displacement and rutting in the early stage of bridge deck use, this paper studies the influence and law of the coupling effect of various factors of the waterproof system on the typical stress of bridge deck pavement and determines the best structure combination for the bridge deck pavement structure. A finite element model was established by using commercial software to simulate the mechanical response of different types of waterproof bonding layer, waterproof leveling layer, and impervious structure layer under different parameters. The simulation results show that when the thickness of the pavement layer was 8 cm, the maximum shear stress of the pavement layer occurred in the middle of the wearing course and the junction between layers. When the pavement layers were continuous, the maximum strain of the waterproof bonding layer with the “rubber asphalt + protective plate” structure in the transverse and longitudinal directions was the largest. When the waterproof leveling layer was cement concrete, the structure bore a large amount of stress and easily produced cracks, resulting in water damage. High-density water-based asphalt concrete with a low permeability coefficient can reduce the interlayer shear stress and effectively ensure the interlayer bonding effect. On this basis, the following bridge deck pavement structure was proposed: waterproof system + multifunctional waterproof layer + load-bearing structure layer + surface functional layer. Full article

A high damping rubber bearing (HDRB) is widely utilized in base-isolation structures due to its good energy dissipation capacity and environmentally friendly properties; however, it is incapable of isolating the vertical vibration caused by earthquakes and subways effectively. Thick rubber bearings with a low shape factor have become one of the important vertical isolation forms. This paper provides an experimental comparative study on high damping rubber bearings with low shape factor (HDRB-LSF), thick lead–rubber bearings (TLRB), and lead–rubber bearings (LRB). The abilities of the bearing and energy dissipation of the above bearings are analyzed contrastively considering the influence of vertical pressure, loading frequency, shear strain, and pre-pressure. Firstly, the HDRB-LSF, TLRB, and LRB are designed according to the Chinese Code for seismic design of buildings. Secondly, cyclic vertical compression tests and horizontal shear tests, as well as their correlation tests, are conducted, respectively. The vibrational characteristics and hysteresis feature of these three bearings are critically compared. Thirdly, a corrected calculation of vertical stiffness for the thick rubber bearings is proposed based on the experimental data to provide a more accurate and realistic tool measuring the vertical mechanical properties of rubber bearings. The test results proved that the HDRB-LSF has the most advanced performance of the three bearings. For the fatigue property, the hysteresis curves of the HDRB-LSF along with TLRB are plump both horizontally and vertically, thus providing a good energy dissipation effect. Regarding vertical stiffness, results from different loading cases show that the designed HDRB-LSF possesses a better vertical isolation effect and preferable environmental protection than LRB, a larger bearing capacity, and, similarly, a more environmentally friendly property than TLRB. Hence, it can avoid the unfavorable resonance effect caused by vertical periodic coupling within the structure. All the experimental data find that the proposed corrected equation can calculate the vertical stiffness of bearings with a higher accuracy. This paper presents the results of an analytical, parametric study that aimed to further explore the low shape factor concepts of rubber bearings applied in three-dimensional isolation for building structures. Full article
