Search Results (74)

Syntactic foams are a promising candidate for applications in marine, oil and gas industries in underwater cables and pipelines due to their excellent insulation properties. The effective transmission of electrical energy through cables requires insulation materials with a low loss factor and low dielectric constant. Similarly, in transporting fluid through pipelines, thermal insulation is crucial. However, both applications are susceptible to potential environmental degradation from moisture exposure, which can significantly impact the material’s properties. This study addresses the knowledge gap by examining the implications of prolonged moisture exposure on thermoplastic polyurethane elastomer (TPU) and TPU-derived syntactic foam via various multi-scale material characterization methods. This research investigates a flexible syntactic foam composed of TPU and glass microballoons (GMBs) fabricated through selective laser sintering. The study specifically examines the effects of moisture exposure over periods of 90 and 160 days, in conjunction with varying GMB volume fractions of 0%, 20%, and 40%. It aims to elucidate the resulting microphase morphological changes, their underlying mechanisms, and the subsequent impact on thermal transport and dielectric properties, all in comparison to unaged samples of the same material. Our findings reveal that increasing the volume fraction of GMB in TPU-based syntactic foam reduces its thermal conductivity and specific heat capacity. However, moisture exposure did not significantly affect the foam’s thermal conductivity. Additionally, we found that the dielectric constant of the syntactic foams decreases with increasing volume fraction of GMB and decreasing frequency of the applied field, which is due to limited molecular orientation in response to the field. Finally, moisture exposure affects the dielectric loss factor of TPU-based syntactic foams with GMBs, possibly due to the distribution morphology of hard and soft segments in TPU. Full article

Evaporative cooling systems have emerged as low-energy consumption alternatives to traditional vapor compression systems for building air conditioning. This study explored the feasibility of utilizing polymeric foamed materials produced through additive manufacturing as wetting materials in evaporative cooling systems. Specifically, two different commercial polylactic acid filaments, each containing a percentage of a chemical blowing agent, were studied. Experiments were designed to evaluate the influence of critical process parameters (line width, flow rate, speed, and layer height) on the performance of the resulting foamed materials in terms of evaporative cooling by conducting water absorption, capillarity, porosity, and wettability tests. Considering that high water absorption, capillarity, and porosity, coupled with an intermediate contact angle, are advantageous for evaporative cooling effectiveness, a low flow rate was found to be the most important parameter to improve these properties’ values. The results showed that the appropriate combination of polymer and process parameters allowed the production of foamed polymer-based materials processed by additive manufacturing technology with optimal performance. Full article

Recently, clothing development 3D printing and the evaluation of its physical characteristics have been explored. However, few studies have tackled thermal comfort, which is a major contributor to the wearers’ comfort. Therefore, this study was designed to suggest effective materials and hole sizes for clothing obtained by 3D printing to maintain a comfortable clothing environment. In particular, two main variables, namely five different materials and three-hole sizes, were analyzed. All samples were placed on a hot plate (36 °C), and their surface temperature and humidity were measured for 10 min. The samples with only thermoplastic polyurethane (TPU) achieved the largest temperature change of 3.2~4.8 °C, whereas those with ethylene-vinyl acetate (EVA) foam exhibited the lowest temperature change of −0.1~2.0 °C. Similarly, the samples with only TPU showed the greatest humidity change of −0.7~−5.5%RH. Moreover, the hole size had a larger effect on humidity change than material type. The samples with large holes achieved the largest humidity change of −4.4%RH, whereas the samples without holes had the smallest humidity change of −1.5%RH after 10 min (p < 0.001). Based on these results, various combinations of materials and hole sizes should be considered to fit the purpose of 3D printing clothing. Full article

Thermoplastic extrusion, a widely used method for processing thermoplastic materials, requires precise temperature control to ensure product quality. However, existing computer-aided engineering tools often oversimplify the temperature distribution calculations, leading to additional discrepancies between simulations and the actual processes. This study introduces a novel multi-region modeling approach to address this issue. By employing realistic temperature control conditions, the methodology overcomes the limitations of current numerical modeling tools. The key contributions include the development of a transient, incompressible, non-isothermal solver integrated into the OpenFOAM computational library and the implementation of a specialized boundary condition that emulates Proportional-Integral-Derivative (PID) control using real-time thermocouple measurements. The findings highlight temperature deviations at the flow channel walls and total pressure drop while demonstrating a smaller impact on velocity and flow uniformity at the outlet under steady-state conditions. This research substantially advances the understanding of thermal dynamics in extrusion processes, offering crucial insights for enhancing temperature control and laying the groundwork for more effective and precise operational strategies. Full article

This study addresses the challenge of achieving foam with a high expansion ratio and poor mechanical properties, caused by the low melt viscosity of semi-crystalline polypropylene (PP). We systematically employ a modification approach involving blending PP with polyolefin elastomers (POE), irradiation crosslinking, and fiber reinforcement to prepare fiber-reinforced crosslinked PP/POE composite foam. Through optimization and characterization of material composition and processing conditions, the obtained fiber-reinforced crosslinked PP/POE composite foam exhibits both low density and high performance. Specifically, at a crosslinking degree of 12%, the expansion ratio reaches 16 times its original value, and a foam density of 0.057 g/cm³ is reduced by 36% compared to the non-crosslinked PP/POE system with a density of 0.089 g/cm³. The density of the short-carbon-fiber-reinforced crosslinked sCF/PP/POE composite foam is comparable to that of the crosslinked PP/POE system, but the tensile strength reaches 0.69 MPa, representing a 200% increase over the crosslinked PP/POE system and a 41% increase over the non-crosslinked PP/POE system. Simultaneously, it exhibits excellent impact strength, tear resistance, and low heat shrinkage. Irradiation crosslinking is beneficial for enhancing the melt strength and resistance to high temperature thermal shrinkage of PP/POE foam, while fiber reinforcement contributes significantly to improving mechanical properties. These achieve a good complementary effect in low-density and high-performance PP foam modification. Full article

This article proposes the integration of two novel aspects into the production of 3D-printed customized wrist-hand orthoses. One aspect involves the material, particularly Colorfabb varioShore thermoplastic polyurethane (TPU) filament with an active foaming agent, which allows adjusting the 3D-printed orthoses’ mechanical properties via process parameters such as printing temperature. Consequently, within the same printing process, by using a single extrusion nozzle, orthoses with varying stiffness levels can be produced, aiming at both immobilization rigidity and skin-comfortable softness. This capability is harnessed by 3D-printing the orthosis in a flat shape via material extrusion-based additive manufacturing, which represents the other novel aspect. Subsequently, the orthosis conforms to the user’s upper limb shape after secure attachment, or by thermoforming in the case of a bi-material solution. A dedicated design web app, which relies on key patient hand measurement input, is also proposed, differing from the 3D scanning and modeling approach that requires engineering expertise and 3D scan data processing. The evaluation of varioShore TPU orthoses with diverse designs was conducted considering printing time, cost, maximum flexion angle, comfort, and perceived wrist stability as criteria. As some of the produced TPU orthoses lacked the necessary stiffness around the wrist or did not properly fit the palm shape, bi-material orthoses including polylactic acid (PLA) inserts of varying sizes were 3D-printed and assessed, showing an improved stiffness around the wrist and a better hand shape conformity. The findings demonstrated the potential of this innovative approach in creating bi-material upper limb orthoses, capitalizing on various characteristics such as varioShore properties, PLA thermoforming capabilities, and the design flexibility provided by additive manufacturing technology. Full article

Thermoplastic polyurethane (TPU) is a versatile polymer with unique characteristics such as flexibility, rigidity, elasticity, and adjustable properties by controlling its soft and hard segments. To properly design and understand the TPU foaming process through supercritical CO₂, a design of experiments approach, the Box–Behnken design (BBD) was adopted using commercial TPU 85A as the model compound. The effect of saturation pressure, saturation temperature, and immersion time on the mean pore size and expansion ratio were investigated. The design space for the production of TPU foam was shown, and the significance of process parameters was confirmed using the analysis of variance (ANOVA). In addition, extrapolation foaming experiments were designed and validated the feasibility of the response surface model developed via BBD. It was found that the pore size of TPU 85A foam could be controlled within 13 to 60 μm, and a stable expansion ratio could be designed up to six. Full article

The search for alternatives to petroleum-based thermoplastic polyamide elastomers (TPAEs) has recently drawn great interest. In this study, a bio-massed TPAE, PA12,36, was synthesized using 1,12-dodecanediamine (DDA) and fatty dimer acid (FDA, Pripol^TM1009) precursors via catalyst and solvent-free melt polycondensation. The molecular structure and molecular weight of the PA12,36 were characterized by ¹H NMR, FTIR, and GPC. PA12,36 displayed a low melting temperature of 85.8 °C, an initial degradation temperature of 425 °C, and a glass-transition temperature of 30.4 °C, whereas it sustained satisfactory tensile strength (10.0 MPa) and superior strain at break (1378%). Furthermore, PA12,36 was foamed by supercritical CO₂, and the cell size, cell density, and porosity were determined. The entangled long-chained FDA component generated a physically crosslinked network, which promoted the melt viscosity of PA12,36 against elongations of foam cell growth and increased foamability significantly. As a result, uniform structured cellular foams with a cell diameter of 15–24 µm and high cell density (10¹¹ cells/cm³–10¹² cells/cm³) were successfully achieved. The foaming window was widened from 76 to 81 °C, and the expansion ratio was increased from 4.8 to 9.6. Additionally, PA12,36 foam with a physically crosslinked structure presented a better creep shape recovery percentage (92–97.9%) and sturdier dimensional stability. This bio-based PA12,36 foam is a promising candidate to replace petroleum-based thermoplastic elastomer foams for engineering applications, particularly shoe soles. Full article

This research examines the flexural fatigue response of 3D-printed foot orthoses produced from various thermoplastic polyurethane (TPU) filaments, including Filaflex 60A, Filaflex 70A, Filaflex 82A, PolyFlex 90A, and varioShore. To subject the insoles to repeated flexion in the metatarsophalangeal area, specialized equipment was developed. A real-world testing scenario was applied to the Filaflex 82A insole, demonstrating that it can sustain over 1,400,000 steps over several months of normal walking (a cadence of approximately 120 steps per minute). Consequently, the experimental conditions were adjusted to double this pace to obtain pertinent results within a shorter testing timeframe. The insoles were subjected to 250 cycles per minute at constant clamping pressures of 176 kPa in the forefoot region. The objective of the evaluation was to determine if 700,000 testing cycles, equivalent to more than two and a half months of daily walking, would induce any damages in the internal structure (infill failure) or external condition (delamination, cracks) of the insoles. Except for compression marks, particularly notable on the foamed material (varioShore TPU) within the clamping zones of the testing device, none of the tested insoles exhibited any signs of external damage after 700,000 cycles. Moreover, the deformations observed in the insoles were non-permanent and nearly entirely disappeared within a few days of rest. The only insole that displayed deterioration of the infill structure was a TPU 82A insole that had been previously worn and then left on a shelf for approximately one year in uncontrolled conditions before being tested at repeated flexion on the apparatus. Additionally, a fifteen-minute walking test was carried out to assess the comfort of each insole, and it was found that the varioShore model, which had a 20% infill density and was 3D-printed at a temperature of 220 °C, stood out as the most comfortable among the tested insoles. Full article

Aluminum foam is expected to be one of the candidates for lightweight materials for structural components as it is lightweight and has excellent shock absorption and sound absorption properties. However, aluminum foam has low tensile and flexural strength due to its thin cell walls. Therefore, aluminum foam is used by combining with dense materials. In particular, with the recent trend toward multi-materials, research on the combination with lightweight resins is expected. In this study, we attempted to join aluminum foam fabricated by the precursor method to a thermoplastic resin polycarbonate (PCTA) plate by friction welding. It was found that the aluminum foam and PCTA plate can be joined in about 1 min by friction welding, by rotating the aluminum foam at 2000 rpm and pressing 1 mm into the PCTA plate. In addition, in the friction welding of aluminum foam and PCTA plate, it was found that the pores of the aluminum foam were maintained without being collapsed. The anchoring effect is presumably caused by the penetration of PCTA softened by the frictional heat generated by the friction welding into the pores. Furthermore, tensile tests of the joined samples showed that fracture occurred either at the joining interface or at the base material of the aluminum foam, and that the joining strength was equivalent to the tensile strength of the aluminum foam itself. Full article

Ethylene-vinyl acetate copolymer (EVA) was added at different contents to the thermoplastic polyurethane (TPU) matrix to form a non-compatible blending system, and foaming materials with high pore density were prepared using the supercritical carbon dioxide extrusion method. The influence of the phase morphology and crystal morphology of the TPU/EVA blend on its foaming behavior was studied. The results show that EVA changed the phase morphology and crystal morphology of the blends, leading to the improved melt viscosity and crystallinity of the blend system. At the same time, interfacial nucleation increases the density of cells and decreases the cell thickness and size, which is beneficial for improving the foaming properties of the blends. For the EVA content of 10% (mass fraction), the cell size is small (105.29 μm) and the cell density is the highest (3.74 × 10⁶ cells/cm³). Based on the TPU/EVA phase morphology and crystal morphology, it is found that the sea-island structure of the blend has better foaming properties than the bicontinuous structure. Full article

This research aimed to characterize the physicochemical, in vitro digestion, and structural features of digestion residues of maize and sorghum starches subjected to thermoplastic extrusion, along with the influence of Sodium Stearoyl Lactylate (SSL), to obtain improved starches for food applications and to understand their behavior when consumed as a food ingredient. The morphology of the extruded materials showed remanent starch granules when SSL was used. A higher amount of medium and large linear glucan chains were found in these particles, influencing higher thermal stability (ΔH ≈ 4 J/g) and a residual crystallinity arrangement varying from 7 to 17% in the extrudates. Such structural features were correlated with their digestibility, where slowly digestible starch (SDS) and resistant starch (RS) fractions ranged widely (from 18.28 to 27.88% and from 0.13 to 21.41%, respectively). By analyzing the data with a Principal component analysis (PCA), we found strong influences of B2 and B3 type chains on the thermal stability of the extrudates. The amylose and smaller glucan chains (A and B1) also significantly affected the emulsifying and foam stability properties. This research contributes to the molecular knowledge of starch in extruded products with broad food applications. Full article

The simulation solutions of different plastic injection molding processes are as multifaceted as the field of injection molding itself. In this study, the simulation of a special injection molding process, which generates partially foamed integral components, was parameterized and performed. This partial and physical foaming is realized by a defined volume expansion of the mold cavity. Using the injection molding simulation software Moldex 3D, this so-called Pull and Foam process was digitally reconstructed and simulated. Since the Pull and Foam process is a special injection molding technique for producing foamed components, the validity of the simulation results was analyzed and evaluated. With the use of Moldex 3D, varied settings such as different bubble growth models and mesh topologies were set, parameterized, and then analyzed, to provide differentiated numerical calculation solutions. Actual manufactured components represent the experimental part of this study and are produced for reference. Different evaluation methods were used to quantify morphological quantities such as porosities, local densities, and cell distributions. These methods are based on two-dimensional and three-dimensional imaging techniques such as optical microscopy and X-ray microtomography (µ-CT). Thus, this structural characterization of the manufactured samples serves as the validation basis for the calculated results of the simulations. According to the illustrated results, the adequate selection of bubble growth models and especially mesh topologies must be considered for valid simulation of specific core-back techniques, such as the Pull and Foam injection molding process. Full article

In this study, a novel hybrid metamaterial has been developed via fulfilling hyperbolic chiral lattice with polyurethane (PU) foam. Initially, both the hyperbolic and typical body-centered cubic (BCC) lattices are fabricated by 3D printing technique. These lattices are infiltrated in a thermoplastic polyurethane (TPU) solution dissolved in 1,4-Dioxane, and then freeze casting technique is applied to achieve the PU-foam-filling. Intermediate (IM) layers possessing irregular pores, are formed neighboring to the lattice-foam interface. While, the foam far from the lattice exhibits a multi-layered structure. The mechanical behavior of the hybrid lattice metamaterials has been investigated by monotonic and cyclic compressive tests. The experimental monotonic tests indicate that, the filling foam is able to soften the BCC lattice but to stiffen the hyperbolic one, further to raise the stress plateau and to accelerate the densification for both lattices. The foam hybridization also benefits the hyperbolic lattice to prohibit the property degradation under the cyclic compression. Furthermore, the failure modes of the hybrid hyperbolic lattice are identified as the interface splitting and foam collapse via microscopic analysis. Finally, a parametric study has been performed to reveal the effects of different parameters on the compressive properties of the hybrid hyperbolic lattice metamaterial. Full article

The bumper beam is a crucial component of the automobile bumper system, responsible for absorbing impact energy and enhancing the safety of passengers during collisions. This paper presents the design and experimental analysis of a 3D-printed composite–plastic hybrid light structure, designed as a collapsible energy absorber. Exploratory testing was conducted using low-impact tests to investigate the failure mechanism and energy absorption capacity of a spiral structure. The design process involved optimizing the spiral diameter by testing specimens with varying diameters between 0.5 cm and 2.5 cm, while keeping other geometric parameters constant. The study employed three types of 3D composite structures, including printed thermoplastic, printed thermoplastic reinforced with Kevlar fiber composite, and printed thermoplastic filled with foam. The thermoplastic–foam composite with nine spirals (diameter = 0.97 cm) yielded the best results. The new design demonstrated high energy absorption capacity and a controlled and progressive failure mechanism, making it a suitable candidate for energy absorption applications. Full article
