In recent years, the number of transistors on electronic chips has surpassed Moore’s law, resulting in overheating and energy consumption problems in data centers (DCs). Chip-level microchannel cooling is expected to address these challenges. Grooved heat sinks with droplet-shaped fins were introduced to modify the overall capability of the cooling system. The degree of impact of the distribution of grooves and fins was analyzed and optimized using the Taguchi method. Moreover, the coupling effect of flow and temperature fields was explained using the field synergy theory. The key findings are as follows: for thermal resistance, pump power, and overall efficiency, the influence degree is the number of combined units > number of fins in each unit > distribution of the combined units. The optimal configuration of 21 combined units arranged from dense to sparse with one fin in each unit achieves 14.05% lower thermal resistance and 8.5% higher overall efficiency than the initial heat sink. The optimal configuration of five combined units arranged from sparse to dense with one fin in each unit reduces the power energy consumption by 27.61%. After optimization, the synergy angle between the velocity vector and temperature gradient is reduced by 4.29% compared to the smooth heat sink. The coupling effect between flow and heat transport is strengthened. The optimized configuration can better balance heat dissipation and energy consumption, improve the comprehensive capability of cooling system, provide a feasible solution to solve the problems of local overheating and high energy consumption in DCs. Full article

Improving the reliability and durability of internal combustion engines in marine vessels is a complex issue. The vibrations generated in these engines significantly affect their proper operation. One of the current research challenges is identifying effective methods to reduce, among other things, torsional vibrations generated within the crank–piston system. To mitigate these vibrations, viscous dampers are commonly used. The selection of a viscous damper for a high-power multi-cylinder engine, such as those in marine power plants, requires a thorough understanding of the thermo-hydrodynamic properties of oil films formed in the spaces between the damper housing and the inertial mass. The description of the phenomena involved is complicated by the variable positioning of the inertial mass center relative to the housing during operation. Most previous studies assume a concentric alignment between these components. The main novelty of this work lies in highlighting the combined effect of the eccentric motion of the inertial ring on both hydrodynamic resistance and thermal characteristics, which has not been fully addressed in existing studies. This article defines the oil flow resistance coefficients and develops static characteristics of the dampers. Additionally, it evaluates the impact of the size of the frontal and cylindrical surfaces of the damper on its heat dissipation capacity. The presented characteristics can be utilized to assess the performance parameters of this type of damper. Full article

This study investigated the thermo-hydrodynamic groundwater environment of a sandy beach where a unique sand bathing method attracts many visitors. The discussed temperatures covered a wide range, from the normal to the boiling temperature of water. We, at first, examined the feasible conditions for sand bathing and found that the volumetric water content was the crucial factor. Comprehensive field observations were implemented to elucidate two physical quantities: the groundwater flow and the temperature in the sand layer. The latter one was found to be governed by the groundwater level and tidal fluctuations. The characteristics obtained were found to be consistent with the feasible conditions in the landward area. While in the offshore area, the temperature was proved to have suddenly dropped. These results strongly suggest that the underground heat source is distributed in specific spots. A numerical model to describe the groundwater flows and the heat transfer mechanism was developed based on a saturated/unsaturated seepage flow model. The computational results were found to adequately reproduce the observed spatial temperature distribution. The reproduction ability of the model was found to be limited in terms of temporal variations; it was good for the groundwater level, but not for the temperature in the sand. Full article

Lubricating oil and cylinder liner surface textures can significantly reduce the friction coefficient between the piston ring and the cylinder liner, thereby improving engine performance. However, the friction-diminishing mechanisms between the lubricating oil and surface texture remain unclear. Properly combining lubricating oil and surface texture can achieve better friction reduction effects. This paper, based on a transient thermo-hydrodynamic model developed in MATLAB 2020a, conducted numerous simulation experiments to explore the matching characteristics of textured cylinder liners. The study provides theoretical support for the future selection of lubricating oils for textured cylinder liners. The results show that, within the range of the circular texture parameters used in this study, the texture radius is directly proportional to the reduction in friction mean effective pressure (FMEP), while the texture depth is inversely proportional to the FMEP reduction. At the same rotational speed, as the viscosity of the lubricating oil increases, the friction-reducing effect of the texture on the piston ring–cylinder liner pair decreases. When the texture depth is 2 μm, the engine speed is inversely proportional to the reduction in FMEP. As the texture depth increases from 2 μm to 6 μm, there is a significant change in the friction-reducing effect: for the 2 μm texture, the friction-reducing impact decreases with increasing lubricant viscosity, while for the 6 μm texture, the friction-reducing effect increases with increasing lubricant viscosity. Full article

As the energy density and efficiency requirements of air compressors continue to increase, gas foil thrust bearings face a high risk of thermal failure due to their elevated speed and limited cooling space. This paper proposes a novel structure for gas foil thrust bearings with enhanced thermal characteristics. A thermo-elastic–hydrodynamic model is developed using a thermal-fluid–solid interaction approach to investigate aerodynamic and thermal performance. The load capacity and thermal characteristics of nine different boundary angles are analyzed. The model is validated, and the actual characteristics of gas foil bearings with various boundary angles are examined using a test rig. The results indicate that, compared to conventional gas foil thrust bearings with a boundary angle of 0°, the new structure with a boundary angle ranging from −10° to −5° not only maintains the load carrying capacity but also improves thermal characteristics. Furthermore, this improvement becomes more pronounced with higher rotational speeds. Therefore, the proposed optimization is advantageous in reducing the risk of thermal failure. Full article

The cylinder liner and piston ring form the most crucial friction pair in the diesel engine, contributing 35–40% of its overall friction losses. Recent research indicates that transient heat transfer significantly affects piston ring lubrication. However, the impact of such a transfer on varying surface textures and lubrication traits remains unclear. This paper takes the piston ring–cylinder liner of a certain diesel engine as the research object, which is based on a two-dimensional averaged Reynolds function and Greenwood–Tripp micro convex body contact model; establishes a numerical calculation model of the transient heat fluid lubrication characteristics of a vertical piston ring–cylinder liner assembly by combining the oil film thickness equation, energy equation, lubricating oil viscosity–temperature, and viscosity pressure characteristics; avoids large errors associated with assuming different temperature values for lubricants; and also uses the cylinder liner surface texturing technique to examine the effects of surface texturing on lubrication properties in the presence of transient thermal fluids. The findings indicate that employing transient thermal fluid for determining the mean value of the oil film temperature in isothermal lubrication calculations yields comparable values for minimum oil film thickness and frictional power consumption, while the friction power consumption calculated by the transient thermal fluid is slightly lower. The depth of the recesses on the surface of the cylinder liner should be minimized, while the radius of the texture should be maximized, taking into consideration the current circumstances. Compared with a cylindrical texture, a spherical texture achieves lower friction with good lubrication indexes. Full article

The performance of gas foil thrust bearings is critical to the successful design and operation of the high axial load rotatory machines that employ gas foil bearings. However, our understanding of gas foil thrust bearings remains incomplete. To enhance our understanding and predict the performance of gas foil thrust bearings, we have established a detailed three-dimensional thermo-elastic-hydrodynamic model of a gas foil thrust bearing based on a fluid-thermal-structure interaction approach in this study. To validate the accuracy of our model, a gas foil thrust bearing test rig was developed. Moreover, we present a numerical investigation of the influence of bump foil configurations on gas foil thrust bearing performance. The results show that the gas foil thrust bearing that fixes the bump foil at the trailing edge and splits the bump foil into several strips exhibits a 36.4% increase in load capacity compared to the gas foil thrust bearing that fixes a whole piece of bump foil at the leading edge. Fixing the bump foil at the trailing edge and splitting it into several strips effectively decreases power loss and reduces the risk of bearing thermal failure. Full article

This research focuses on the computational modelling and comparative analysis of friction stir welding (FSW) and stationary shoulder friction stir welding (SSFSW) applied to AA6061-T6 aluminium alloy. SSFSW, an FSW variant, employs a stationary shoulder and a rotating pin. This study introduces a numerical model for both processes, using the innovative Smoothed Particle Hydrodynamics (SPH) technique to capture their distinct thermo-mechanical characteristics. The aim is to unravel its mechanics and multi-physics in SSFSW and compare it with conventional FSW. The temperatures predicted by the model exhibited a close agreement between the advancing side (AS) and retreating side (RS). Plastic strain patterns show that regular FSW is different from SSFSW. In SSFSW, the strain is less, and the plastic area is comparatively slightly narrower. The distinct “ironing effect” resulting from the stationary shoulder in SSFSW reduces the heat-affected zone (HAZ). Yet, it maintains efficient plasticisation and material flow within the pin-affected zone (PAZ). This research emphasises the significant impact of temperature, strain, material flow, and thermo-mechanical characteristics on the quality of joints. Future suggestions include exploring process parameters more broadly, examining dissimilar welding techniques and hybrid approaches, and comprehensively investigating the diverse effects of SSFSW under various configurations and joint angles. Full article

In order to study the effect of surface roughness on lubrication performance of an elastic support water-lubricated tilting pad thrust bearing, a mixed lubrication (ML) deterministic model is hereby presented based on a unified Reynolds equation model. This very model incorporates the elastic–plastic deformation of asperities and polymer matrix of the thrust pad, as well as the elastic deformation of the rubber support. The randomly distributed surface roughness of the thrust pad is generated by a mathematical model and shares the same distribution characteristics as the measured surface roughness. The Greenwood and Williamson asperity contact model and thin plate deformation model are combined to solve the asperities contact stress and deformation. Meanwhile, the bearing ML performance is compared with the results calculated by a thermohydrodynamic (THD) lubrication model and a thermo-elasto-hydrodynamic (TEHD) lubrication model, while the film thickness is also compared with measurements. The results show that the water film thickness calculated by the ML model is smaller than that by the THD model and the TEHD model, but the water film temperature is higher. The roughness has a great influence on the contact area ratio and the lubrication state, but little effect on the average film thickness. A higher roughness indicates a higher rotational speed required for the bearing to achieve full hydrodynamic lubrication. The film thickness calculated by the mixed lubrication model is closer to the measured results. Overall, it is proved that the mixed lubrication model can more accurately predict the lubrication performance of bearings. Compared to the thin plate deformation model, the elastic deformation simulation based on the half-infinite space model severely overestimates the elastic deformation of the pad surface, making it unsuitable for calculating the elastic deformation of the polymer matrix of the thrust pad under contact force or water film pressure. This ML deterministic model provides an effective means for high-precision prediction of the lubrication performance of the elastic supported water-lubricated thrust bearings coupled with multi-layer soft materials. Full article

The profile of sealing land is a sensitive factor affecting the thermo-hydrodynamic lubrication characteristics of the slipper pair. In this paper, the non-uniform wear of the running surface under the slipper was presented and defined as the boundary condition. Based on the finite volume method and the successive over-relaxation iteration method, a discrete numerical model coupled with the temperature, pressure, and thickness of the oil film was constructed. The Newton and sequential circulation methods were used to solve the coupling equations. The influence of the wear profile on the film thickness, sliding attitude, and leakage were discussed. The analyzed results show that the control of the wear on the outer side of sealing land and the contour vertex position, and the avoidance of the wear on the inner side of sealing land could improve the thermo-hydrodynamic lubrication performance of the slipper pair. Full article

In order to obtain the leakage characteristics of an upstream pumping face seal with inclined ellipse dimples under high-temperature and high-speed liquid lubricating conditions, a thermo-hydrodynamic lubricating model is developed. The novelty of this model is that it takes the thermo-viscosity effect and cavitation effect into account. The influence of operating parameters, such as rotational speed, seal clearance, seal pressure, ambient temperature and structural parameters, such as dimple depth, inclination angle, slender ratio and dimple number on the opening force and leakage rate, is numerically calculated. The results obtained show that the thermo-viscosity effect makes the cavitation intensity decrease noticeably, leading to an increase in the upstream pumping effect of ellipse dimples. Moreover, the thermo-viscosity effect may make both the upstream pumping leakage rate and opening force increase by about 10%. It can also be found that the inclined ellipse dimples can produce an obvious upstream pumping effect and hydrodynamic effect. Based on the reasonable design of the dimple parameter, not only can the sealed medium achieve zero leakage, but the opening force can also increase by more than 50%. The proposed model has the potential to provide the theoretical basis for and guide the future designs of upstreaming liquid face seals. Full article

The thermo- and pH-responsive polymer brushes based on methoxy[oligo(propyleneglycol)₈-block-oligo(ethyleneglycol)₈]methacrylate with different concentrations of N-[3-(dimethylamino)propyl]methacrylamide (from 0% to 20%) were synthesized via RAFT polymerization. The “grafting-through” approach was used to prepare the low-molar-mass dispersion samples (M_w/M_n ≈ 1.3). Molar masses and hydrodynamic characteristics were obtained using static and dynamic light scattering and viscometry. The solvents used were acetonitrile, DMFA, and water. The molar masses of the prepared samples ranged from 40,000 to 60,000 g·mol^–1. The macromolecules of these polymer brushes were modeled using a prolate revolution ellipsoid or a cylinder with spherical ends. In water, micelle-like aggregates were formed. Critical micelle concentrations decreased with the content of N-[3-(dimethylamino)propyl]methacrylamide. Molecular brushes demonstrated thermo- and pH-responsiveness in water–salt solutions. It was shown that at a given molecular mass and at close pH values, the increase in the number of N-[3-(dimethylamino)propyl]methacrylamide units led to an increase in phase separation temperatures. Full article

The force equilibrium and moment equilibrium play a significant role on the sealing performance of gas split floating ring seals. A small deflection angle may generate seriously wear on sealing surface and cause seal failure. Therefore, the thermo-hydrodynamic lubrication analysis of gas split floating ring seal with Rayleigh grooves is investigated considering the deflection angle and frictional heat of surface contact, which is beneficial to grasp the hydrodynamic characteristics and rules under high-temperature and high-speed conditions. Pressure and temperature distributions of sealing rings are numerically calculated for the cases with different deflection angle, rational speed, seal pressure and ambient temperature. Then, the hydrodynamic effect and sealing performance are analyzed. The obtained results show that, the surface Rayleigh step grooves do not present obvious hydrodynamic effect when split seal ring has no deflection. While, a significant hydrodynamic effect can be obtained when the split seal ring presents a deflection angle about dozens of micro radians. Here, a 10% increase of opening force is achieved when the deflection angle reaches 80 μrad in the case of speed 30,000 r/min and seal pressure 0.2 MPa. Moreover, the hydrodynamic effect becomes obvious with increasing deflection angle as well as rotational speed. Meanwhile, the growth of rotational speed results in an obvious increase of film temperature. The increase of ambient temperature has a significant influence on the decrease of leakage rate. When the ambient temperature increases from 340 K to 540 K, the leakage rate reduces exceeding 50%, however, it does not present obvious effect on the opening force. The proposed model has the potential to provide the theoretical basis and design guidance for surface grooves of gas split floating ring seal in the future. Full article

This paper presents a detailed three-dimensional (3D) thermo-elastic-hydrodynamic (TEHD) multi-physics model of the bump-type gas foil thrust bearing based on computational fluid dynamics (CFD). In this model, the moving mesh technology is applied in the fluid flow domain, and the new boundary condition of fully developed flow is applied at the inlet and outlet boundaries, which is consistent with the continuous property of fluid flow and has better convergence performance in CFD. The groove between pads is set as the symmetry boundary. The contact pairs with Coulomb friction and contact/separation behaviors are considered in the structure deformation and heat transfer. The simulation results indicated that the boundary pressure has a significant influence on the foil deformation. It also revealed the heat flux transfer path and temperature distribution in the gas foil thrust-bearing (GFTB) system. Full article

The purpose of this paper is to study the oil film and friction characteristics of valve plates with a micro-textured surface and to explore the influence of textures of different shapes and sizes on the valve plates. Firstly, on the basis of thermohydrodynamic theory, this paper established the lubrication model of the oil film on the valve plate pair of swashplate axial piston pumps, according to the Reynolds equation. Secondly, the micro-texture was added to the mathematical model of the valve plate pair’s oil film. A combination of the energy equation, oil-film-thickness equation, elastic deformation equation, viscosity–pressure and viscosity–temperature equation, the finite difference method, as well as the relaxation iteration method, was used to solve the problem, and the textured and non-textured valve plate surfaces were simulated. The nephogram of the oil-film-thickness distribution, elastic deformation distribution, oil-film-pressure distribution and oil-film-temperature distribution were generated. Then, the control variable method was used to change the cylinder rotational speed, tilt angle, oil viscosity, initial oil film thickness and other parameters to analyze their effects on oil film characteristics. In addition, the friction characteristics of non-textured surfaces, square textured surfaces, triangular textured surfaces and circular textured surfaces were compared and analyzed. It was found that the textured surface of valve plates can obviously improve friction efficiency under the same operating conditions. The square texture, especially, is the preferable shape, rather than the triangular texture and the circular texture, and the friction performance is at its best when the texture depths are between 20 $\mathsf{\mu }\mathrm{m}$ and 50 $\mathsf{\mu }\mathrm{m}$. The results provide a theoretical basis for the design and improvement of the valve plate. Full article
