Search Results (116)

This study examines the labyrinth seal disc of an aero-engine, specifically analysing the radial deformation caused by centrifugal force and heat stress during operation. This distortion may lead to discrepancies in the performance attributes of the labyrinth seal and could potentially result in contact between the labyrinth seal tip and neighbouring components. A numerical analytical model incorporating the rotor and stator cavities, along with the labyrinth seal disc structure, has been established. The sealing integrity of a standard labyrinth seal disc’s flow channel is evaluated and studied at different clearances utilising the fluid–solid-thermal coupling method. The findings demonstrate that, after considering radial deformation, a cold gap of 0.5 mm in the conventional labyrinth structure leads to stabilisation of the final hot gap and flow rate, with no occurrence of tooth tip rubbing; however, both the gap value and flow rate show considerable variation relative to the cold state. When the cold gap is 0.3 mm, the labyrinth plate makes contact with the stator wall. To resolve the problem of tooth tip abrasion in the conventional design with a 0.3 mm cold gap, two improved configurations are proposed, and a stability study for each configuration is performed independently. The leakage and temperature rise attributes of the two upgraded configurations are markedly inferior to those of the classic configuration at a cold gap of 0.5 mm. At a cold gap of 0.3 mm, the two improved designs demonstrate no instances of tooth tip rubbing. Full article

With the enhancement of thermodynamic cycle parameters and heat dissipation constraints in aero-engines, effective thermal management has become a critical challenge to ensure safe and stable engine operation. This study developed a transient temperature evaluation model applicable to the entire flight envelope, considering fluid–solid coupling heat transfer on both the main flow path and fuel systems. Firstly, the impact of heat transfer on the acceleration and deceleration performance of a low-bypass-ratio turbofan engine was analyzed. The results indicate that, compared to the conventional adiabatic model, the improved model predicts metal components absorb 4.5% of the total combustor energy during cold-state acceleration, leading to a maximum reduction of 1.42 kN in net thrust and an increase in specific fuel consumption by 1.18 g/(kN·s). Subsequently, a systematic evaluation of engine thermal management performance throughout the complete flight mission was conducted, revealing the limitations of the existing thermal management design and proposing targeted optimization strategies, including employing Cooled Cooling Air technology to improve high-pressure turbine blade cooling efficiency, dynamically adjusting low-pressure turbine bleed air to minimize unnecessary losses, optimizing fuel heat sink utilization for enhanced cooling performance, and replacing mechanical pumps with motor pumps for precise fuel supply control. Full article

Film cooling has been increasingly applied in turbine blade cooling design due to its excellent cooling performance. Although film-cooled blades demonstrate superior cooling effectiveness, the perforation design on blade surfaces compromises structural integrity, making fatigue failure prone to occur at cooling holes. Previous studies by domestic and international scholars have extensively investigated factors influencing film cooling effectiveness, including blowing ratio and hole geometry configurations. However, most research has overlooked the investigation of fatigue life in film-cooled blades. This paper systematically investigates blade fatigue life under various cooling air parameters by analyzing the relationships among cooling effectiveness, stress distribution, and fatigue life. Results indicate that maximum stress concentrations occur at cooling hole locations and near the blade root at trailing edge regions. While cooling holes effectively reduce blade surface temperature, they simultaneously create stress concentration zones around the apertures. Both excessive and insufficient cooling air pressure and temperature reduce thermal fatigue life, with optimal parameters identified as 600 K cooling temperature and 0.75 MPa pressure, achieving a maximum thermal fatigue life of 3400 cycles for this blade configuration. A thermal shock test platform was established to conduct fatigue experiments under selected cooling conditions. Initial fatigue damage traces emerged at cooling holes after 1000 cycles, with progressive damage expansion observed. By 3000 cycles, cooling holes near blade tip regions exhibited the most severe failure, demonstrating near-complete functional degradation. These findings provide critical references for cooling parameter selection in practical aeroengine applications of film-cooled blades. Full article

With the intensive development of oil and gas resources leading to a rapid increase in abandoned wells, sealing failures may cause oil and gas leakage and environmental pollution. Systematically investigating the temperature distribution patterns of thermite melting in open-hole abandoned wells under various factors is critical for effective plugging. This study overcomes the limitations of traditional single heat conduction models by integrating thermite reaction kinetics, phase change latent heat, and thermal–fluid–solid multi-field coupling effects, establishing a thermal–fluid–solid coupling model for thermite melting in open-hole abandoned wells. This model provides theoretical guidance for the effectiveness of plugging operations and temperature control during operations. The model was validated through thermite melting experiments: the simulated expansion of the sandstone borehole diameter was 9.8 mm, with a 5.5% error compared to the experimental value of 9.29 mm; and the simulated axial extension at the well bottom was 18.9 mm, with a 4.7% error compared to the experimental value of 17.19 mm, confirming the model’s accuracy. The influence of different lithologies and initial downhole temperatures on the temperature distribution in the open-hole section of abandoned wells under identical conditions was analyzed. The results show that the ultimate melting thicknesses of dolomite, limestone, and granite are 0.0354 m, 0.0350 m, and 0.0234 m, respectively, indicating superior plugging effects in dolomite and limestone. In the initial reaction stage (stage a), the phase change thickness of limestone exceeded that of dolomite by 59.78%, demonstrating better thermite melting and sealing efficacy in limestone. Additionally, model analysis reveals that the initial downhole temperature has a minimal impact on the temperature distribution of thermite melting in open-hole abandoned wells. Full article

To mitigate the influence of wellbore heat transfer on the physicochemical properties of water-based fracturing fluids in the high-temperature environments of low-permeability shale reservoirs, this study investigates the fluid filtration behavior of water-based fracturing fluids within the wellbore under such reservoir conditions. A wellbore heat-transfer model based on solid–liquid coupling was constructed in order to analyse the effects of different reservoir and wellbore factors on fluid properties (viscosity and filtration volume) in the water-based fracturing fluids. Concurrently, boundary conditions and control equations were established for the numerical model, thereby delineating the heat-transfer conditions extant between the water-based fracturing fluid and the wellbore. Furthermore, molecular dynamics theory and microgrid theory were utilised to elucidate the mechanisms of the alterations of the fluid properties of the water-based fracturing fluids due to wellbore heat transfer in low-permeability shale reservoirs. The findings demonstrated that wellbore heat transfer in low-permeability shale reservoirs exerts a pronounced influence on the fluid viscosity and filtration volume of the water-based fracturing fluids. Parameters such as wellbore wall thickness, heat-transfer coefficient, radius, and pressure differential introduce distinct variation trends in these fluid properties. At the microscopic scale, the disruption of intermolecular hydrogen bonds and the consequent increase in free molecular content induced by thermal effects are the fundamental mechanisms driving the observed changes in viscosity and fluid filtration. These findings may offer theoretical guidance for improving the thermal stability of water-based fracturing fluids under wellbore heat-transfer conditions. Full article

During the operation of a solid rocket motor, the nozzle, which is a key component, is subjected to extreme conditions, including high temperatures, high-speed gas flow, and discrete-phase particles. For composite nozzles incorporating a carbon/carbon (C/C) throat liner and a carbon/phenolic expansion section, thermochemical ablation and the formation of ablation steps during the ablation process significantly hinder nozzle performance and engine operational stability. In this study, the fluid and solid domains and the physicochemical interactions between them during nozzle operation were analyzed. An innovative thermochemical ablation model for composite nozzles was developed to account for wall recession. The coupled model covered multi-component gas flow, heterogeneous chemical reactions on the nozzle surface, structural heat transfer, variations in material parameters induced by carbon/phenolic pyrolysis, and the dynamic recession process of the nozzle profile due to ablation. The model achieved coupling between gas flow, heterogeneous reactions, and structural heat transfer through interfacial mass and energy balance relationships. Based on this model, the distribution of the nozzle’s thermochemical ablation rate was analyzed to investigate the mechanisms underlying ablation step formation. Furthermore, detailed calculations and analyses were performed to determine the effects of the gas pressure, temperature, H₂O concentration, and aluminum concentration in the propellant on the ablation rate of the throat liner and the thickness of the ablation steps. This study provides a theoretical foundation for the thermal protection design and performance optimization of composite nozzles, improving the reliability and service life of solid rocket motor nozzles and advancing technological development. Full article

To address the challenges of high flow resistance and poor temperature uniformity in conventional PCM–liquid cooling hybrid heat exchangers—which significantly impair the performance and lifespan of electronic devices—a topology optimization approach was adopted. A dual-objective function, aimed at minimizing the average temperature and pressure drop, was introduced to reconstruct the cooling channel layout and PCM filling region. A two-dimensional transient thermo-fluid model coupling the solid–liquid phase-change process with coolant flow and heat transfer was established, alongside the development of an experimental platform. A comprehensive comparison was performed against a conventional liquid cooling plate with straight channels. The results showed that the topology-optimized cooling plate exhibited a pressure drop of 15.80 Pa and a pumping power of 1.19 × 10⁻⁴ W, representing reductions of 38.28% and 38.02%, respectively. The PCM solidification time was shortened by 6 min. Under these conditions, the convective heat transfer coefficient (h_w) and performance evaluation criterion (j/f) of the optimized plate reached 1319.06 W/(m²·K) and 0.56, which corresponded to increases of 60.71% and 47.5%, respectively. The topology-optimized configuration significantly improved temperature uniformity and overall cooling performance. As the inlet velocity increased from 0.05 m/s to 0.2 m/s, h_w increased by 38.65%; however, j/f decreased by 57.14%, due to the limited thermal conductivity of the PCMs, resulting in only a slight reduction in the average PCM temperature. Furthermore, the topology-optimized cooling plate demonstrated stronger steady-state regulation capability under fluctuating thermal loads. This study provides valuable insights and design guidance for the development of high-efficiency hybrid liquid cooling plates. Full article

In this paper, a double-mode self-calibration tension system is proposed, which adopts the conversion of hydraulic meter tension and the monitoring of standard force sensors. According to the material characteristics of the jack and the viscosity and temperature characteristics of the hydraulic oil, the differential model of heat conduction in the hydraulic cylinder and the mathematical model of oil film friction heat generation are established, and the internal thermodynamic characteristics of the jack are theoretically analyzed, which provides theoretical support for the temperature compensation of the hydraulic oil pressure gauge of the jack. A simulation analysis was conducted on the thermodynamic characteristics of the hydraulic jack, and the distribution patterns of the temperature field, thermal stress field, and thermal strain field inside the hydraulic cylinder during normal operation were determined by measuring the temperature changes in five different parts of the jack at different times (t = 200 s, 2600 s, 5000 s, 7400 s, and 10,000 s). For the issue of heat generation due to oil film friction in the hydraulic jack, a simulation calculation model is developed by integrating Computational Fluid Dynamics (CFD) techniques with dynamic grid and slip grid methods. By simulating and analyzing frictional heating under conditions where the inlet pressures are 0.1 MPa, 0.3 MPa, 0.5 MPa, 0.7 MPa, and 0.9 MPa, respectively, we can obtain the temperature distribution on the jack, determine the frictional resistance, and subsequently conduct a theoretical analysis of the simulation results. Using the high-precision standard force sensor after data processing and the hydraulic oil gauge after temperature compensation, the online self-calibration of the tensioning system is carried out, and the regression equation of the tensioning system under different oil temperatures is obtained. The double-mode self-calibration tensioning system with temperature compensation is used to verify the compensation accuracy of the proposed double-mode self-calibration tensioning system. Full article

The growing demand for high-power battery output in the ever-evolving electric vehicle and energy storage sectors necessitates the development of efficient thermal management systems. High-power lithium-ion batteries (LIBs), known for their outstanding performance, are widely used across various applications. However, effectively managing the thermal conditions of high-power battery packs remains a critical challenge that limits the operational efficiency and hinders broader market acceptance. The high charge and discharge rates in LIBs generate significant heat, and, as a result, inadequate heat dissipation adversely impacts battery performance, lifespan, and safety. This study utilized theoretical analysis, numerical simulations, and experimental methodologies to address these issues. Considering the anisotropic heat transfer characteristics of laminated pouch cells, this study developed a fluid–solid coupling simulation model tailored to the liquid-cooled structure of pouch battery modules, supported by an experimental test setup. A U-shaped “bathtub-type” cooling structure was designed for a 48 V/8 Ah high-power-density battery pack intended for start–stop power supply applications. This design aimed to resolve heat dissipation challenges, optimize the cooling efficiency, and ensure stable operation under varying conditions. During the performance assessments of the cooling structure conducted through simulations and experiments, extreme discharge conditions (320 A) and pulse charging/discharging cycles (80 A) at ambient temperatures of up to 45 °C were simulated. An analysis of the temperature distribution and its temporal evolution led to critical insights. The results showed that, under these severe conditions, the maximum temperature of the battery module remained below 60 °C, with temperature uniformity maintained within a 5 °C range and cell uniformity within 2 °C. Consequently, the battery pack meets the operational requirements for start–stop power supply applications and provides an effective solution for thermal management in high-power-density environments. Full article

In the operation process of modern industrial equipment, as the core transmission component, the operation state of the gearbox directly affects the overall performance and service life of the equipment. However, the current gear operation is still faced with problems such as poor monitoring, a single detection index, and low data utilization, which lead to incomplete evaluation results. In view of these challenges, this paper proposes a shape and property integrated gearbox monitoring system based on digital twin technology and artificial intelligence, which aims to realize real-time fault diagnosis, performance prediction, and the dynamic visualization of gear through virtual real mapping and data interaction, and lays the foundation for the follow-up predictive maintenance application. Taking the QPZZ-ii gearbox test bed as the physical entity, the research establishes a five-layer architecture: functional service layer, software support layer, model integration layer, data-driven layer, and digital twin layer, forming a closed-loop feedback mechanism. In terms of technical implementation, combined with HyperMesh 2023 refinement mesh generation, ABAQUS 2023 simulates the stress distribution of gear under thermal fluid solid coupling conditions, the Gaussian process regression (GPR) stress prediction model, and a fault diagnosis algorithm based on wavelet transform and the depth residual shrinkage network (DRSN), and analyzes the vibration signal and stress distribution of gear under normal, broken tooth, wear and pitting fault types. The experimental verification shows that the fault diagnosis accuracy of the system is more than 99%, the average value of the determination coefficient (R²) of the stress prediction model is 0.9339 (driving wheel) and 0.9497 (driven wheel), and supports the real-time display of three-dimensional cloud images. The advantage of the research lies in the interaction and visualization of fusion of multi-source data, but it is limited to the accuracy of finite element simulation and the difficulty of obtaining actual stress data. This achievement provides a new method for intelligent monitoring of industrial equipment and effectively promotes the application of digital twin technology in the field of predictive maintenance. Full article

The lubrication behavior and mechanical characteristics of the main bearing area of an aero-engine main shaft bearing determine the reliability and life of the main shaft bearing. In aero-engine main shaft bearings, the lubricant not only plays the role of lubrication but also affects the dynamic characteristics of the bearing; therefore, if the lubricant drag force is insufficient, it will lead to rolling body slipping. Slipping not only affects the reliability of the bearing operation but also will make the temperature of the contact area instantaneously increase, leading to the occurrence of gluing, scraping and other lubrication failure phenomena in the main bearing area. A lubricant under the shear conditions of traction characteristics is actually the external manifestation of rheological properties. Rheological properties are one of the elastic fluid power lubrication theories and are an important part of the study. Elasto-hydrodynamic lubrication theory of the oil film pressure, film thickness and temperature and solid domains interact to form a thermal–fluid–solid coupling relationship; this coupling relationship affects the main bearing area of the lubrication behavior and mechanical properties, thus affecting the lubrication state of the bearings and dynamic characteristics. With the continuous improvement of aero-engine performance requirements for main shaft bearings, it is of great significance to carry out a coupling study of the lubrication behavior and mechanical properties of the bearing contact zone under heavy load, high speed and high temperature conditions to improve the service performance, reliability and life of the bearings. Full article

To address the challenges of unclear thermo-mechanical coupling mechanisms and unpredictable multi-field synergistic effects in segmented tire molds during vulcanization, this study focuses on segmented tire molds and proposes a multi-physics coupling numerical model. This model integrates fluid flow dynamics into heat transfer mechanisms. It systematically reveals molds’ heat transfer characteristics, stress distribution and deformation behavior under combined high-temperature and mechanical loading. Based on a fluid-solid-thermal coupling framework and experimental validations, simulations indicate that the internal temperature field of the mold is highly uniform. The global temperature difference is less than 0.13%. The temperature load has a significant dominant effect on the deformation of key components such as the guide ring and installation ring. Molding forces play a secondary role in total stress. The error between multi-field coupling simulation results and experimental results is controlled within 6%, verifying the model’s reliability. This research not only provides a universally applicable multi-field coupling analysis method for complex mold design but also highlights the critical role of temperature fields in stress distribution and deformation analysis. This lays a theoretical foundation for the intelligent design and process optimization of high-temperature, high-pressure forming equipment. Full article

In this study, a multi-physical and thermal–fluid–solid coupling model was developed to simulate the autoclave curing process of composite materials, aiming to explore the influence mechanism of the external flow field on the curing process. First, the extended layerwise method (XLWM) and finite volume method were adopted to simulate the composite laminates and heating airflows, respectively. Then, the thermo-chemical–mechanical-seepage analysis was carried out for the composite laminates. Considering the interaction between the airflows and laminates, a weak coupling method was proposed to solve the thermal–fluid–solid coupling problem, which consists of two parts: unidirectional coupling and bidirectional coupling. In numerical examples, the results of the two coupling schemes were compared, which indicated that the bidirectional coupling scheme consumed fewer computing resources but achieved similar accuracy. Full article

This study employs the meshfree Smoothed Particle Hydrodynamics (SPH) method to simulate the fluid–solid coupling process of gear meshing rotation with lubricating oil or oil jet lubrication fluids, considering the heat-transfer process under preset initial temperature conditions. While traditional grid methods face challenges in simulating the dynamic interaction between gear-meshing rotation and lubricating fluids, such as time-dependent contact in fluid–solid coupling and heat transfer, difficulties in handling meshing gaps, and the complexity of dynamic mesh setup, our approach leverages the unique advantages of meshless methods. In the established fluid–solid–heat coupling model, gears are considered as rigid bodies, and both fluids and gears are discretized into SPH particles, achieving fluid–solid coupling through the interaction between fluid particles and solid SPH particles. The model considers three cooling scenarios: oil pool cooling, oil jet cooling, and combined cooling. Simulation results show that oil pool cooling is more effective than oil jet cooling, but oil jet cooling can achieve localized spot cooling. The model exhibits good computational stability and efficiency in simulating the fluid–solid coupling and heat-transfer processes of gear rotation, oil jetting, and oil pool fluids. This study provides an effective numerical simulation method for gear lubrication cooling and has significant application potential for simulating complex scenarios such as gear operation and oil pool sloshing in coal mining machine arms. Compared to previous SPH work, this study couples a thermodynamic model in the simulation, thus enabling the modeling of fluid–thermal–solid coupled processes. Full article

As shale gas development gradually advances to a deeper level, the economic exploitation of deep shale gas has become one of the key technologies for sustainable development. Large-scale, long-term and effective hydraulic fracturing fracture networks are the core technology for achieving economic exploitation of deep shale gas. Due to the high-pressure and high-temperature characteristics of deep shale gas reservoirs, traditional seepage models cannot effectively simulate gas flow in such environments. Therefore, this paper constructs a fluid–solid–thermal coupling model, considering the creep characteristics of deep shale, the effects of proppant embedment and deformation on fracture closure, and deeply analyzes the effects of proppant parameters on the shale gas production process. The results show that factors such as proppant concentration, placement, mechanical properties and particle size have a significant effect on fracture width, fracture surface seepage characteristics and final gas production. Specifically, an increase in proppant concentration can expand the fracture width but has limited effect on increasing gas production; uneven proppant placement will significantly reduce the fracture conductivity, resulting in a significant decrease in gas production; proppants with smaller sizes are more suitable for deep shale gas fracturing construction, which not only reduces construction costs but also improves gas seepage capacity. This study provides theoretical guidance for proppant optimization in deep shale gas fracturing construction. Full article
