The tandem tilt-wing UAV features an advanced aerodynamic layout design and is regarded as a solution for small-scale urban air mobility. However, the tandem wing configuration exhibits complex aerodynamic interactions between the front and rear wings during cruise flight and the wing tilt transition process. The objective of this paper is to investigate the aerodynamic coupling characteristics between the front and rear wings of the tandem tilt-wing UAV under level flight and tilt transition conditions while also assessing the influence of the propellers on the aircraft’s aerodynamic performance. Through CFD numerical analysis, the aerodynamic characteristics of various aircraft components are examined at different angles of attack and wing tilt angles, and the underlying reasons for the observed differences and variations are explored. The results indicate that, during level flight, the aerodynamic interference between the wings is primarily dominated by the detrimental influence of the front wing on the rear wing. During the tilt transition process, mutual interactions between the front and rear wings occur as wing tilt angle changes, leading to more drastic variations in lift coefficients and increased control difficulty. However, the propeller’s effect contributes to smoother changes in lift and drag, thereby enhancing aircraft stability. Full article

The channel wing offers unique advantages in the short take-off and landing (STOL) application of Unmanned Aerial Vehicles (UAVs). To investigate its aerodynamic performance, an individual propeller was simulated using the actuator disk model. The computed values were in close agreement with the experimental data. To conduct an initial assessment of the aerodynamic advantages offered by the channel wing, this study compared three configurations: a clean wing, a wing with a forward propeller, and a channel wing. The analysis revealed that the channel wing exhibits a better lift-to-drag ratio than the wing with a forward propeller. Further analysis investigated how propeller-to-wing clearance, axial placement relative to the wing’s leading edge, and changes in propeller diameter influence the channel wing aerodynamic characteristics. To validate the simulation results, a test platform was designed, and the calculated results were qualitatively verified. The findings indicated that reducing the propeller-to-wing clearance enhances the channel wing’s lift force and contributes to a higher lift-to-drag ratio. Altering the propeller’s installation position along the chordwise direction of the channel wing significantly influences its aerodynamic performance. Finally, the channel wing configuration was applied to a lifting-fuselage tandem-wing drone. A comparison with the conventional forward propeller configuration demonstrated that the drone with the channel wing achieves a higher lift-to-drag ratio, with a maximum value of 18.6. Compared with “forward propeller” configuration, the lift-to-drag ratio exhibits an improvement of 97.8% under the optimal configuration. Full article

The distributed electric tilt-rotor Unmanned Aerial Vehicle (UAV) combines the vertical take-off and landing (VTOL) capability of helicopters with the high-speed cruise performance of fixed-wing aircraft, offering a transformative solution for Urban Air Mobility (UAM). However, aerodynamic interference between rotors is a new challenge to improving their flight efficiency, especially the dynamic interactions during the transition phase of non-parallel tandem dual-rotor systems, which require in-depth investigation. This study focuses on the aerodynamic performance evolution of the tilt-rotor system during asynchronous transition processes, with an emphasis on quantifying the influence of rotor tilt angles. A customized experimental platform was developed to investigate a counter-rotating dual-rotor model with fixed axial separation. Key performance metrics, including thrust, torque, and power, were systematically measured at various tilt angles (0–90°) and rotational speeds (1500–3500 RPM). The aerodynamic coupling mechanisms between the front and rear rotor disks were analyzed. The experimental results indicate that the relative tilt angle of the dual rotors significantly affects aerodynamic interference between the rotors. In the forward tilt mode, the thrust of the aft rotor recovers when the tilt angle reaches 45°, while in the aft tilt mode, it requires a tilt angle of 75°. By optimizing the tilt configuration, the aerodynamic performance loss of the aft rotor due to rotor-to-rotor aerodynamic interference can be effectively mitigated. This study provides important insights for the aerodynamic performance optimization and transition control strategies of the distributed electric tilt-rotor UAV. Full article

The drone industry is continuously growing. The regulatory framework that allows these aircraft to operate safely is gradually evolving, enabling missions with growing associated risks, although it is not progressing at the same speed as the industry itself. To provide certainty to regulators, it is necessary to employ design methodologies that are recognized in the aerospace industry. Therefore, in this work, we addressed the design and manufacturing of a lightweight unconventional-configuration unmanned aircraft by adapting widely known conceptual design methodologies from manned aviation from authors such as Torenbeek and Roskam. Manufacturing was carried out by combining new techniques for the use of composite materials with additive manufacturing. A wide variability in the results was identified across the different models used. However, taking the most restrictive estimates into account, the results show that the structural weight estimates of the wing, made using classical manned aviation methods, align with the final weight obtained, assuming the wing can withstand the aerodynamic and inertial loads applied within a certain safety margin. Full article

The effect of corrugated wings on the aerodynamic characteristics of a dragonfly-like hovering flapping wing is investigated using two-dimensional numerical simulations. Two types of pitch motion profiles, namely ‘sinusoidal’ and ‘trapezoidal’, are employed. The results obtained from the corrugated wings at Reynolds number Re = 2150 are then compared with the flat plate geometries to analyze the aerodynamic benefits of wing corrugation. The aerodynamic characteristics of corrugated wings are investigated quantitatively using cycle-averaged vertical force coefficient. For the qualitative investigation, time histories of vertical force coefficient, vorticity, and surface pressure distribution are used. The results reveal that the corrugated wings perform better than the flat plates in all three flapping configurations for both sinusoidal and trapezoidal pitch profiles. For a tandem wing with a sinusoidal pitch profile, the corrugated wings yield a vertical force generation nearly 14%, 22%, and 12%, higher than the flat plate geometries for ψ = 0°, 90°, and 180°, respectively. The corrugated wing sheds a relatively stronger detached counter clockwise vortex (CCWV) on the lower surface as compared to the flat plate, and hence, the vertical force is much higher for the corrugated wing. For a tandem wing with a trapezoidal pitch profile, the corrugated wings yield a vertical force generation nearly 27%, 22%, and 57%, higher than the flat plate geometries for ψ = 0°, 90°, and 180°, respectively. In corrugated wing geometry, the delayed stall mechanism is slightly postponed due to the corrugation shape’s ability to trap the vortex structures, leading to a positive effect on vertical force production. Full article

The present two-dimensional study investigates the ground effect on the aerodynamic characteristics of a tandem flapping wing in inclined stroke plane hovering using ANSYS Fluent. The role of various wing kinematics parameters (flapping frequency f, stroke amplitude A_o/c, and phase difference ψ = 0° and 180°), in combination with ground distance (D* = D/c), is studied. The results reveal that a large stroke amplitude A_o/c decreases vertical force generation for both in-phase and counter-stroking patterns. The vertical force notably increases for both in-phase and counter-stroking wings when D* is extremely small (D* = 0.5). A maximum vertical force enhancement of approximately 65% and 35% is observed for in-phase and counter-stroking patterns, respectively, at D* = 0.5. This enhancement is primarily attributed to the strengthening of detached vortices on the lower surface of the wings during the middle of the downstroke when flapping at extremely small ground distances. In addition, the wing–wing interaction and secondary rebound vortex, caused by wing–ground interaction, also play a key role in vertical force generation. The wing–ground interaction positively influences both vertical and thrust force generation for in-phase and counter-stroking wings at small ground distances. In general, the vertical and thrust forces generated by in-phase stroking wings are greater than those produced by counter-stroking wings. Full article

Dynamic derivatives are critical for evaluating an aircraft’s aerodynamic characteristics, dynamic modeling, and control system design during the design phase. However, due to the multiple iterations of the design phase, a method for calculating dynamic derivatives that balances computational efficiency and accuracy is required. This work presents a CFD-enhanced engineering calculation method (CEHM) for calculating tandem-wing UAVs’ dynamic derivatives. A coupling-effect-driven estimation strategy is proposed to incorporate the contribution of the rear wing to the longitudinal dynamic derivatives, and it accounts for the aerodynamic coupling effects between the front and rear wings. To enhance the accuracy of the dynamic derivative calculations, we put forward a dynamic derivative-correction mechanism based on the CFD method. It achieves three types of parameters from the static derivative CFD simulations to enhance accuracy, including parameters for aerodynamic force coefficient fitting, the dynamic pressure ratio, and the upwash and downwash gradients. The CEHM method is applied to compute the dynamic derivatives of the SULA90 tandem-wing UAV, with results compared to those obtained from the traditional engineering estimation tools (XFLR5 and OpenVSP). The simulation experiment results show that the proposed method not only calculates the acceleration derivatives but also provides higher calculation accuracy. To further validate the method’s effectiveness, open-loop model verifications were conducted using field flight test data of the SULA90. The field flight test results show that the CEHM method’s predicted results align closely with the measured flight data. The proposed method calculates dynamic derivatives in seconds, balancing accuracy and computational cost, making it highly suitable for tandem-wing aircraft during the design phase. Furthermore, this approach is generalizable and can be applied to other aircraft configurations. Full article

This paper provides a detailed review of the evolution and development of corrugated wings, a biomimetic concept that is very effective under low Reynolds number flights. We will highlight, through reviewing experimental and numerical studies, the emphasis on its aerodynamic performance for lift enhancement, flow separation delay, and drag reduction in the aerodynamics of corrugated wings. Furthermore, we focus on topics such as fluid–structure interaction and aeroacoustics, presenting the possibility of morphing wing technologies in tandem and its effects on an angle of attack at various flight modes. This review outlines durability issues, materials selection, and experimental testing complemented by numerical models while determining the importance of interdisciplinary developments within corrugated wing aerodynamics using potential AI-assisted design. Our review envisions the application of aerodynamics of corrugated wings in the development of UAVs, MAVs, and future advanced aviation systems by integrating the principles from biology to engineering. Full article

Camber deflection concepts for a VR-12 rotorcraft airfoil were studied for the optimization of unsteady aerodynamics, including dynamic stall conditions and wing–wing interactions during pitching. The designs are based on deflections of the leading edge and trailing edge sections of the airfoil. The deflection parameters were initially established using Computational Fluid Dynamics (CFD). Results from CFD and Particle Image Velocimetry (PIV) were generated for various leading and trailing edge deflection combinations for comparison of their performances. The conditions of this study are for a Reynolds number of 250,000 and pitching reduced frequency of 0.04, representing a medium regime of rotorcraft operations. Linear tandem tests were performed to simulate unsteady wing–wing interactions. The effects of the deflections are discussed and compared to the baseline. Significant benefits are observed, notably dynamic stall mitigation from the leading edge (LE) deflected wing for certain angles of attack and decrease in the separation regions. Overall, from the numerical simulations and the experimental data fields, the LE deflection provides about 10% improvement, followed by the combined LE&TE deflections (8%). It is also found that combining various deflections can provide a performance increase over drastically different areas of the range of angle of attack. Full article

In this paper, we present a physics- and data-driven study on the ground effect on the propulsive performance of tandem flapping wings. With numerical simulations, the impact of the ground effect on the aerodynamic force, energy consumption, and efficiency is analyzed, revealing a unique coupling effect between the ground effect and the wing–wing interference. It is found that, for smaller phase differences between the front and rear wings, the thrust is higher, and the boosting effect due to the ground on the rear wing (maximum of 12.33%) is lower than that on a single wing (maximum of 43.83%) For a larger phase difference, a lower thrust is observed, and it is also found that the boosting effect on the rear wing is above that on a single wing. Further, based on the bidirectional gate recurrent units (BiGRUs) time-series neural network, a surrogate model is further developed to predict the unsteady aerodynamic characteristics of tandem flapping wings under the ground effect. The surrogate model exhibits high predictive precision for aerodynamic forces, energy consumption, and efficiency. On the test set, the relative errors of the time-averaged values range from −4% to 2%, while the root mean squared error of the transient values is less than 0.1. Meanwhile, it should be pointed out that the established surrogate model also demonstrates strong generalization capability. The findings contribute to a comprehensive understanding of the ground effect mechanism and provide valuable insights for the aerodynamic design of tandem flapping-wing air vehicles operating near the ground. Full article

Dragonflies can independently control the movement of their forewing and hindwing to achieve the desired flight. In comparison with previous studies that mostly considered the same kinematics of the fore- and hindwings, this paper focuses on the aerodynamic interference of three-dimensional tandem flapping wings when the forewing kinematics is different from that of the hindwing. The effects of flapping amplitude (Φ₁), flapping mean angle ($\overline{{\varphi }_1}$), and pitch rotation duration (Δtr₁) of the forewing, together with wing spacing (L) are examined numerically. The results show that Φ₁ and $\overline{{\varphi }_1}$ have a significant effect on the aerodynamic forces of the individual and tandem systems, but Δtr₁ has little effect. At a small L, a smaller Φ₁, or larger $\overline{{\varphi }_1}$ of the forewing can increase the overall aerodynamic force, but at a large L, smaller Φ₁ or larger $\overline{{\varphi }_1}$ can actually decrease the force. The flow field analysis shows that Φ₁ and $\overline{{\varphi }_1}$ primarily alter the extent of the impact of the previously revealed narrow channel effect, downwash effect, and wake capture effect, thereby affecting force generation. These findings may provide a direction for designing the performance of tandem flapping wing micro-air vehicles by controlling forewing kinematics. Full article

The present investigations on tandem wing configurations primarily revolve around the effects of the spacing L and the phase difference $\phi$ between the forewing and the hindwing on aerodynamic performance. However, in nature, organisms employing biplane flight, such as dragonflies, demonstrate the ability to achieve superior aerodynamic performance by flexibly adjusting their flapping trajectories. Therefore, this study focuses on the effects of $\phi$, as well as the trajectory of the hindwing, on aerodynamic performance. By summarizing four patterns of wake–wing interaction processes, it is indicated that $\phi =-{90}^{\circ }$ and $0^{\circ }$ enhances the thrust of the hindwing, while $\phi ={90}^{\circ }$ and ${180}^{\circ }$ result in reductions. Furthermore, the wake–wing interactions and shedding modes are summarized corresponding to three kinds of trajectories, including elliptical trajectories, figure-eight trajectories, and double figure-eight trajectories. The results show that the aerodynamic performance of the elliptical trajectory is similar to that of the straight trajectory, while the figure-eight trajectory with positive surging motion significantly enhances the aerodynamic performance of the hindwing. Conversely, the double-figure-eight trajectory degrades the aerodynamic performance of the hindwing. Full article

This paper describes a dragonfly-inspired Flapping Wing Micro Air Vehicle (FW-MAV), named HiFly-Dragon. Dragonflies exhibit exceptional flight performance in nature, surpassing most of the other insects, and benefit from their abilities to independently move each of their four wings, including adjusting the flapping amplitude and the flapping amplitude offset. However, designing and fabricating a flapping robot with multi-degree-of-freedom (multi-DOF) flapping driving mechanisms under stringent size, weight, and power (SWaP) constraints poses a significant challenge. In this work, we propose a compact microrobot dragonfly with four tandem independently controllable wings, which is directly driven by four modified resonant flapping mechanisms integrated on the Printed Circuit Boards (PCBs) of the avionics. The proposed resonant flapping mechanism was tested to be able to enduringly generate 10 gf lift at a frequency of 28 Hz and an amplitude of 180° for a single wing with an external DC power supply, demonstrating the effectiveness of the resonance and durability improvement. All of the mechanical parts were integrated on two PCBs, and the robot demonstrates a substantial weight reduction. The latest prototype has a wingspan of 180 mm, a total mass of 32.97 g, and a total lift of 34 gf. The prototype achieved lifting off on a balance beam, demonstrating that the directly driven robot dragonfly is capable of overcoming self-gravity with onboard batteries. Full article

This paper presents the second stage of a tandem fixed-wing unmanned aerial vehicle (UAV) aerodynamic development. In the initial stage, the UAV was optimized by analyzing its characteristics only in symmetrical flight conditions. Posted requirements were that both wings should produce relevant positive lift, the initial stall must occur on the front wing first, the center of pressure should be close to the center of gravity, and longitudinal static stability should be in the optimum range. Computational fluid dynamic (CFD) analyses were performed, where the applied calculation model was derived from the authors’ previous successful projects. The eighth version TW V8 has satisfied all longitudinal requirements. Lateral-directional CFD analyses of V8 showed that the ratio of the lateral and directional stability at the nominal cruising regime was optimal, but both lateral and directional static stabilities were too high. On further development versions, the lower vertical tail was eliminated, a negative dihedral was implemented on the front wing, and four inverted blended winglets were added. Version TW V14 has largely improved lateral and directional stability characteristics, while their optimum ratio at the cruising regime was preserved. Longitudinal characteristics were also well preserved. Maximum lift coefficient and lift-to-drag ratio were increased, compared to the V8. Full article

The demography and behaviour of Teinopodagrion oscillans was studied in a protected area in the Andean region of Colombia. Adult damselflies were individually marked, and using their recapture histories, we estimated survival, longevity, sex ratio, and population size using Cormack-Jolly-Seber models. Other aspects of their behaviour were recorded. Survival, recapture, and lifespan (14.1 ± 0.59 days) were similar for both sexes and all age groups. Mature males were larger, and the distance from the water was similar for all individuals. The most supported model was the time-dependent model for survival and recapture. This suggests that weather variations affect the demography of this population in a significant way. Individuals exhibited high fidelity to their site perch, perching with open wings near water on a variety of perches. Mature males make short flights from the perch to intercept conspecific and interspecific males and to hunt prey. The tandem position was formed on macrophytes, and then the pair flew away. Oviposition lasted for 11.23 min on average, with the females ovipositing by abdomen submersion. Our results offer insights into the demographic characteristics and behaviour of this species, providing crucial information for the short- and long-term, from the demography of one species to the conservation of ecosystems of the Andean region. Full article
