In this study, a Ni-coated carbon fiber reinforced Al-matrix (Ni-CF/Al) composite is prepared utilizing a pressure-free infiltration process. The CFs are coated with a layer of Ni through an electroless plating process, which facilitates the spontaneous infiltration behavior driven by the Al-Ni binary reaction. The spontaneous infiltration process, observed via synchrotron radiation in the direction opposite to gravity, demonstrates a fastest velocity of 31.02 ± 1.08 μm/s. By increasing the infiltration temperature, the interfacial microstructure of the composite can be enhanced, characterized by a reduction in un-infiltrated defects and promoted by the interfacial Al-Ni reaction. Notably, large-size Al-Ni intermetallic compounds (IMCs) at the interface are replaced by fine (Al+Al₃Ni) eutectic structure, given an optimal fabrication temperature of 720 °C. This contributes to a significantly enhanced ultimate tensile strength (UTS) of the composite, reaching a maximum of 135 ± 4 MPa, which is 159.6% higher than that of the matrix. Full article

Structural and spatial aspects of cell degradation are studied using a combination of diffraction-and imaging-based tools applying laboratory X-rays, neutron scattering and synchrotron radiation with electrochemical and thermal characterization. Experimental characterization is carried out on cylindrical cells of 21700-type, where four regimes of cell degradation are identified, which are supplemented by an increased cell resistance and surface temperature during cell operation. The amount of intercalated lithium in the fully charged anodes in the fresh and aged states is determined by ex situ X-ray diffraction radiography and in situ X-ray diffraction computed tomography. The qualitatively similar character of the results revealed a loss of active lithium along with the development of a complex heterogeneous distribution over the electrode stripe. Full article

Synchrotron radiation dynamic imaging technology combined with the static characterization method was used to study the microstructural evolution and the growth kinetics of intermetallic compounds (IMCs) at the liquid Al/solid Cu interface. The results show that the interfacial microstructure can be divided into layered solid diffusion microstructures (AlCu₃, Al₄Cu₉, Al₂Cu₃ and AlCu) and solidification microstructures (Al₃Cu₄, AlCu and Al₂Cu) from the Cu side to the Al side. Meanwhile, the growth of bubbles formed during the melting, holding and solidification of an Al/Cu sample was also discussed, which can be divided into three modes: diffusion, coalescence and engulfment. Moreover, the growth of AlCu₃ and (Al₄Cu₉ + Al₂Cu₃) near the Cu side is all controlled by both interfacial reaction and volume diffusion. The growth of Al₃Cu₄ adjacent to the melt is mainly controlled by the interfacial reaction, which plays a major role in the growth of the total IMCs. Full article

The continued development of metal additive manufacturing (AM) has expanded the engineering metallic alloys for which these processes may be applied, including beta-titanium alloys with desirable strength-to-density ratios. To understand the response of beta-titanium alloys to AM processing, solidification and microstructure evolution needs to be investigated. In particular, thermal gradients (Gs) and solidification velocities (Vs) experienced during AM are needed to link processing to microstructure development, including the columnar-to-equiaxed transition (CET). In this work, in situ synchrotron X-ray radiography of the beta-titanium alloy Ti-10V-2Fe-3Al (wt.%) (Ti-1023) during simulated laser-powder bed fusion (L-PBF) was performed at the Advanced Photon Source at Argonne National Laboratory, allowing for direct determination of Vs. Two different computational modeling tools, SYSWELD and FLOW-3D, were utilized to investigate the solidification conditions of spot and raster melt scenarios. The predicted Vs obtained from both pieces of computational software exhibited good agreement with those obtained from in situ synchrotron X-ray radiography measurements. The model that accounted for fluid flow also showed the ability to predict trends unobservable in the in situ synchrotron X-ray radiography, but are known to occur during rapid solidification. A CET model for Ti-1023 was also developed using the Kurz–Giovanola–Trivedi model, which allowed modeled Gs and Vs to be compared in the context of predicted grain morphologies. Both pieces of software were in agreement for morphology predictions of spot-melts, but drastically differed for raster predictions. The discrepancy is attributable to the difference in accounting for fluid flow, resulting in magnitude-different values of Gs for similar Vs. Full article

In the last two decades, X-ray imaging techniques have been used increasingly to study metal solidification in real-time as, thanks to advances in X-ray sources (synchrotron and laboratory-based) and detector technology, images can now be obtained with spatio-temporal resolutions sufficient to record key phenomena and extract quantitative information, primarily relating to crystal growth. This paper presents an overview of the research conducted at the University of Oxford over the last 6 years as a partner in the UK’s Future Liquid Metal Engineering (LiME) Manufacturing Hub. The focus is on in situ X-ray radiography to investigate the solidification of Al alloys, including the formation of primary $\alpha$-Al crystals, and the formation and growth of secondary intermetallic phases. Technologically, the thrust is to understand how to control as-cast phases, structures and element distributions, particularly elements associated with recycling, as a means to facilitate greater recirculation of aluminium alloys. We first present studies on refinement of primary $\alpha$-Al, including extrinsic grain refinement using inoculation and intrinsic refinement based on dendrite fragmentation. Second, we describe studies on intermetallic phase formation and growth, because intermetallic fraction, morphology and distribution are frequently a limiting factor of alloy mechanical properties and recyclability. Then we present some of the latest progress in studying liquid flow during solidification and associated hot tear formation. Finally, future research directions are described. Full article

The high longitudinal and lateral coherence of synchrotron X-rays sources radically transformed radiography. Before them, the image contrast was almost only based on absorption. Coherent synchrotron sources transformed radiography into a multi-faceted tool that can extract information also from “phase” effects. Here, we report a very simple description of the new techniques, presenting them to potential new users without requiring a sophisticated background in advanced physics. We then illustrate the impact of such techniques with a number of examples. Finally, we present the international collaboration SYNAPSE (Synchrotrons for Neuroscience—an Asia-Pacific Strategic Enterprise), which targets the use of phase-contrast radiography to map one full human brain in a few years. Full article

To control the final grain structure and the density of structural crystalline defects in silicon (Si) ingots is still a main issue for Si used in photovoltaic solar cells. It concerns both innovative and conventional fabrication processes. Due to the dynamic essence of the phenomena and to the coupling of mechanisms at different scales, the post-mortem study of the solidified ingots gives limited results. In the past years, we developed an original system named GaTSBI for Growth at high Temperature observed by Synchrotron Beam Imaging, to investigate in situ the mechanisms involved during solidification. X-ray radiography and X-ray Bragg diffraction imaging (topography) are combined and implemented together with the running of a high temperature (up to 2073 K) solidification furnace. The experiments are conducted at the European Synchrotron Radiation Facility (ESRF). Both imaging techniques provide in situ and real time information during growth on the morphology and kinetics of the solid/liquid (S/L) interface, as well as on the deformation of the crystal structure and on the dynamics of structural defects including dislocations. Essential features of twinning, grain nucleation, competition, strain building, and dislocations during Si solidification are characterized and allow a deeper understanding of the fundamental mechanisms of its growth. Full article

Under the JST-ERATO project in progress to develop X-ray and neutron phase-imaging methods together, recent achievements have been selected and reviewed after describing the merit and the principle of the phase imaging method. For X-ray phase imaging, recent developments of four-dimensional phase tomography and phase microscopy at SPring-8, Japan are mainly presented. For neutron phase imaging, an approach in combination with the time-of-flight method developed at J-PARC, Japan is described with the description of new Gd grating fabrication. Full article

Operando laboratory X-ray radiographies were carried out for imaging of two different silver-based gas diffusion electrodes containing an electroconductive Ni mesh structure, one gas diffusion electrode composed of 95 wt.% Ag and 5 wt.% polytetrafluoroethylene and one composed of 97 wt.% Ag and 3 wt.% polytetrafluoroethylene, under different operating parameters. Thereby, correlations of their electrochemical behavior and the transport of the 30 wt.% NaOH electrolyte through the gas diffusion electrodes were revealed. The work was divided into two parts. In the first step, the microstructure of the gas diffusion electrodes was analyzed ex situ by a combination of focused ion beam technology and synchrotron as well as laboratory X-ray tomography and radiography. In the second step, operando laboratory X-ray radiographies were performed during chronoamperometric measurements at different potentials. The combination of the ex situ microstructural analyses and the operando measurements reveals the impact of the microstructure on the electrolyte transport through the gas diffusion electrodes. Hence, an impact of the Ni mesh structure within the gas diffusion electrode on the droplet formation could be shown. Moreover, it could be observed that increasing overpotentials cause increasing electrolyte transport velocities and faster droplet formation due to electrowetting. In general, higher electrolyte transport velocities were found for the gas diffusion electrode with 97 wt.% Ag in contrast to that with 95 wt.% Ag. Full article

Zirconia-based cast refractories are widely used for glass furnace applications. Since they have to withstand harsh chemical as well as thermo-mechanical environments, internal stresses and microcracking are often present in such materials under operating conditions (sometimes in excess of 1700 °C). We studied the evolution of thermal (CTE) and mechanical (Young’s modulus) properties as a function of temperature in a fused-cast refractory containing 94 wt.% of monoclinic ZrO₂ and 6 wt.% of a silicate glassy phase. With the aid of X-ray refraction techniques (yielding the internal specific surface in materials), we also monitored the evolution of microcracking as a function of thermal cycles (crossing the martensitic phase transformation around 1000 °C) under externally applied stress. We found that external compressive stress leads to a strong decrease of the internal surface per unit volume, but a tensile load has a similar (though not so strong) effect. In agreement with existing literature on β-eucryptite microcracked ceramics, we could explain these phenomena by microcrack closure in the load direction in the compression case, and by microcrack propagation (rather than microcrack nucleation) under tensile conditions. Full article

Radiography has long been the standard approach to characterize carious lesions. Spatially resolved X-ray diffraction, specifically small-angle X-ray scattering (SAXS), has recently been applied to caries research. The aims of this combined SAXS and micro computed tomography (µCT) study were to locally characterize and compare the micro- and nanostructures of one natural carious lesion and of one artificially induced enamel lesion; and demonstrate the feasibility of an automated approach to combined SAXS and µCT data in segmenting affected and unaffected enamel. Enamel, demineralized by natural or artificial caries, exhibits a significantly reduced X-ray attenuation compared to sound enamel and gives rise to a drastically increased small-angle scattering signal associated with the presence of nanometer-size pores. In addition, X-ray scattering allows the assessment of the overall orientation and the degree of anisotropy of the nanostructures present. Subsequent to the characterization with µCT, specimens were analyzed using synchrotron radiation-based SAXS in transmission raster mode. The bivariate histogram plot of the projected data combined the local scattering signal intensity with the related X-ray attenuation from µCT measurements. These histograms permitted the segmentation of anatomical features, including the lesions, with micrometer precision. The natural and artificial lesions showed comparable features, but they also exhibited size and shape differences. The clear identification of the affected regions and the characterization of their nanostructure allow the artificially induced lesions to be verified against selected natural carious lesions, offering the potential to optimize artificial demineralization protocols. Analysis of joint SAXS and µCT histograms objectively segmented sound and affected enamel. Full article

Pressure induced densification and compression of a reprocessed sample of borosilicate glass has been studied by X-ray radiography and energy dispersive X-ray diffraction using a Paris-Edinburgh (PE) press at a synchrotron X-ray source. The reprocessing of a commercial borosilicate glass was carried out by cyclical melting and cooling. Gold foil pressure markers were used to obtain the sample pressure by X-ray diffraction using its known equation of state, while X-ray radiography provided a direct measure of the sample volume at high pressure. The X-ray radiography method for volume measurements at high pressures was validated for a known sample of pure α-Iron to 6.3 GPa. A sample of reprocessed borosilicate glass was compressed to 11.4 GPa using the PE cell, and the flotation density of pressure recovered sample was measured to be 2.755 gm/cc, showing an increase in density of 24%, as compared to the starting sample. The initial compression of the reprocessed borosilicate glass measured by X-ray radiography resulted in a bulk modulus of 30.3 GPa in good agreement with the 32.9 GPa value derived from the known elastic constants. This method can be applied to variety of amorphous materials under high pressures. Full article
