During the excavation of the underground cavern at the Baihetan hydropower station, significant time-dependent deformation of the surrounding rock was observed, posing a serious challenge to the long-term stability control of the caverns. In this study, numerical models of the layered excavation for typical monitoring sections in the main and auxiliary powerhouses on both banks of the Baihetan hydropower station were established using a viscoplastic damage model. The time-dependent deformation responses of the surrounding rock during the entire underground cavern excavation process were successfully simulated, and the deformation and failure mechanisms of the surrounding rock during layered excavation were analyzed in combination with field monitoring data. The results demonstrate that the maximum stress trajectories at the right-bank powerhouse under higher stress conditions exceeded those at the left-bank powerhouse by 6 MPa after the powerhouse excavation. A larger stress difference caused stress trajectories to move closer to the rock strength surface, therefore making creep failure more likely to occur in the right bank. Targeted reinforcement in high-disturbance zones of the right-bank powerhouse reduced the damage progression rate at borehole openings from 0.295 per month to 0.0015 per month, effectively suppressing abrupt deformations caused by cumulative damage. These findings provide a basis for optimizing the excavation design of deep underground caverns. Full article

The escalating disasters caused by the movement of shallow buried strata in China’s western mining areas are increasingly threatening operational safety. A critical issue in ensuring secure mining practices in these areas is the creep failure of weakly cemented soft rock under low-stress conditions. The unique particle contact mechanisms in weakly cemented mudstone, combined with the persistence of the cemented materials and the particulate matter they form, lead to mechanical responses that differ significantly from those of typical soft rocks during loading. Building on an existing multivariate linear regression equation for new similar materials, this study developed qualified weakly cemented medium similar materials, offering appropriate materials for long-term creep tests of weakly cemented formations. This was accomplished by employing orthogonal proportioning tests. The principal findings of our investigation are as follows: The new, similar material exhibits low strength and prominent creep characteristics, accurately simulating weakly cemented materials in western mining areas. The concentration of rosin–alcohol solution has a measurable impact on key parameters, such as σ_c, E, and γ in the weakly cemented similar material specimens. Furthermore, the creep characteristics of the specimens diminish progressively with an increase in the proportion of iron powder (I) and barite powder (B). The material was applied to a similar indoor model test simulating the weakly cemented material surrounding the auxiliary haulage roadway in Panel 20314 of the Gaojialiang Coal Mine, with speckle analysis employed for detailed examination. The experimental findings suggest that both the conventional mechanical properties and long-term creep characteristics of the material align with the required specifications, offering robust support for achieving optimal outcomes in the similar model test. Full article

The time-dependent deformation control of weakly cemented soft rock in deep underground engineering is a critical scientific issue that directly affects the long-term stability of roadways. Traditional Nishihsara models encounter limitations in accurately capturing the weakening effects of material parameters during rock creep failure and in describing the accelerated creep stage, making them insufficient for analyzing the creep failure mechanisms of weakly cemented surrounding rock. To address these limitations, this study integrates SEM and X-ray scanning results to reveal the microscopic degradation process during creep: under external forces, clay minerals, primarily bonded face-to-face or through cementation, gradually fracture, leading to continuous microcrack propagation and progressive parameter degradation. Based on damage theory, an enhanced Nishihara creep model is proposed, incorporating a time-dependent damage factor to characterize the attenuation of the elastic modulus and a nonlinear winding element connected in series to represent the accelerated creep stage. The corresponding three-dimensional constitutive equations are derived. Using the Levenberg–Marquardt (L-M) algorithm for parameter inversion, the model achieves over 98% fitting accuracy across the full creep stages of weakly cemented soft rock, validating its applicability to other rock types such as salt rock and anthracite. The damage creep model is numerically implemented through secondary development in FLAC3D 6.0, with simulation results showing less than 5% deviation from experimental data and the failure mode is similar. These findings provide a solid theoretical foundation for further understanding the creep behavior of weakly cemented soft rocks. Full article

Confined water inrush caused by fault activation is the main form of water disaster in deep mining. With theoretical analysis and similar simulation tests, the mechanism and evolution law of delayed water inrush caused by fault activation are revealed. At the theoretical level, the expansion and extension of the internal microstructure in the fault zone under the action of the mining stress field and seepage field are the essential causes of fault activation. Overlying strata movement and surrounding rock creep failure are the basic reasons for delayed water inrush caused by fault activation, and delayed time caused by surrounding rock creep failure is much longer than that of overlying strata movement. A similar simulation test was carried out with self-development solid–liquid coupling with similar simulation materials; the results show that delayed water inrush caused by fault activation with mining includes three stages. Micro-activation stage: Water inrush weakness point is formed because of the expansion and extension of the micro-fissure and structure at the bottom of the fault zone. Macro-activation stage: With the change in the stress of the waterproof coal pillar and surrounding rock, the micro-fissures and structures in the stress relief area and tension area of the fault zone expand and extend sharply; meanwhile, water intrudes into the interlayer stratification of the floor in the stress relief area, forming a strong laminar flow phenomenon, and cracks in the floor form and expand; finally, water-conducting channels in the fault zone and floor are formed. Water inrush stage: The waterproof coal pillar and water-resisting layer fail and are destroyed, and the first confined water inrush point is located at the junction of the waterproof coal pillar and gob floor. Full article

During the excavation and support construction process used in coal mine roadways, the stress path is the unloading of in situ stress and the compensation of support stress. The 150 mm × 150 mm × 150 mm coal mass samples were obtained in situ underground and prepared, the true triaxial loading–unloading–confining pressure restoring test method was used, and the mechanical response and deformation failure evolution characteristics of the coal seam during the excavation and support process of the shallow, medium depth, and deep coal roadways in the coal mine were simulated and studied. Based on the distribution law of the bolt and cable support stress field, the support compensation stress required for the stability of the surrounding rock after the excavation of the coal roadway with different burial depths was determined, and the corresponding roadways’ surrounding rock control technologies were proposed. This study’s results indicate that the compensation stress required for support in shallow coal roadways (with a burial depth of about 200 m) was much less than 0.1 MPa. A single rock bolt support can keep the surrounding rock of the roadway stable; the compensation stress required for support in the medium buried coal roadway (with a depth of about 600 m) is around 0.1 MPa, and the combined support of rock bolts and cables can meet the support requirements. Deep coal roadways under high stress (with a depth of about 1000 m) require support to provide compensation stress. Even if the compensation stress reaches 0.2 MPa, the surrounding rock of the roadway will experience varying degrees of creep. In this study, it was necessary to increase the support density and surface area of rock bolts and cables, the pre-tension forces of rock bolts and cables were improved, and in synergy with grouting modification, destressing and other technologies could control the large deformation of the surrounding rock of the roadway in 1000 m deep coal mines. This study’s results provide a theoretical basis for the selection of control technologies for use in coal roadways at different depths. Full article

In order to study the influence of the long-term strength of the rock surrounding deep roadways under the action of groundwater on surrounding rock stability, taking the rock surrounding the deep roadway of the Wanfu Coal Mine as the main research object, uniaxial compression and uniaxial creep tests were carried out on sandstone samples under different water-content states. It was found that the water content had an obvious softening effect on short-term and long-term strength, and both strengths showed a negative exponentially declining relationship. The viscosity modulus (${\overline{E}}_v$) was put forward to describe viscoelastic creep deformation. And damage variables corresponding to E (the instantaneous elastic modulus) and ${\overline{E}}_v$ were proposed. A sticky element that can describe the accelerated creep behavior was also established to improve the Nishihara model, based on the experimental results and damage theory. A comparison of the identified parameters and the experimental curves showed that the model can describe the mechanical behavior of various creep stages well. The model was developed using the ABAQUS user subroutine function, and the uniaxial compression creep experiment was simulated. The simulation results were basically consistent with the experimental results, which provide a basis for the further long-term stable use of roadway and creep failure simulation and have important practical and guiding significance. Full article

Creep is a fundamental property that naturally exists in some types of rock, which is significant for the long-term stability of roadways during the mining process. In this paper, the long-term strength of coal and rock were determined via laboratory experiments, and a Cvisc elasto-viscoplastic model was adopted and introduced in FLAC3D, based on the 31101 transport roadway in the Hongqinghe Coal Mine, to investigate the influence of creep on the stability of a deep high-stress roadway. The test results show that the long-term strength of 3-1 coal and sandy mudstone was 18.65 MPa and 39.95 MPa, respectively. The plastic zone, the deformation, and the damage of the roadway’s surrounding rock displayed an obvious increase after being excavated for 720 d as the creep model was chosen. The plastic zone failure was modeled with shear-p (1090.7 m³), shear-n (381.7 m³), tension-n (98.4 m³), and tension-p (30.8 m³). The damage value had an obvious increment of 21.2% (0.053), and the deformation increased in the order of the two sidewalls (1978 mm), the roof (907 mm), and the floor (101 mm). The creep of the roadway can be divided into three stages: the accelerating stage, the decaying stage, and the stable stage. The creep speed of each stage is greatly affected by the presence or absence of anchor spray support: the creep speed of the bare roadway roof, sidewalls, and floor stability was 1.01, 1.02, and 0.12 mm/d, respectively. After anchor spray support, the creep velocity, correspondingly, decreased to 0.69, 0.37, and 0.12 mm/d, and the amount of surrounding rock damage decreased from 0.302 to 0.243. This indicates that the anchor spray support can significantly reduce the creep effect of the roadway. The Cvisc creep model was verified to be reliable and can provide guidance for deep high-stress coal roadway support. Full article

Tunnel projects in the southwestern mountainous area of China are in full swing. According to the tunnel burial depth, structural characteristics, and chemical erosion environments of the Lixiang railway tunnel, carbonaceous slate specimens obtained in the field were taken to experimentally investigate the physical, mechanical, and creep characteristics of the bedding’s slate specimens after chemical erosion. The results of scanning electron microscopy (SEM) indicate that chemical erosion leads to internal damage in the carbonaceous slate specimens, and the internal damages are increasing with the increase of erosion days. Moreover, the specimens’ ultrasonic test (UT) results prove that specimens with smaller bedding angles suffer a more serious erosion and induce more internal cracks. Under conventional triaxial compression conditions with 40 MPa of confining pressures, the conventional triaxial compressive strength (σ_s) decreases with the decrease of the bedding angle and the increase of erosion days, and the failure modes of the specimens are mainly controlled by oblique shear fractures and accompanied by the occurrence of slip dislocation fractures between the bedding inclination. Under creep conditions with 40 MPa of confining pressures, the final deformations of specimens are increasing with the increase of erosion days, which means the longer the erosion days, the greater the deformations. The failure modes of the specimens under creep conditions are controlled by shear fractures, and for the specimen with a 60° bedding angle and long-term erosion, there are block separations and many cavities along the shear planes. Therefore, more attention should be paid to prevent serious failure of the surrounding rock if the surrounding rock has a bedding angle of 60° or suffers long-term erosion. Full article

The creep associated with unloading surrounding rock during the excavation of deep tunnels seriously affects the stability of the tunnel, and a high seepage pressure will aggravate the strength attenuation and structural deterioration of the surrounding rock. Based on the background of the excavation-induced unloading of the surrounding rock of a deeply buried granite tunnel with high seepage pressure, in this paper we carry out a triaxial unloading seepage creep test that considers the effects of both excavation disturbance and seepage pressure. We also analyze the mechanism of unloading and seepage pressure leading to sample failure and construct a fractional creep damage constitutive model that considers the unloading effect. The results include the following findings, firstly, seepage pressure will affect the creep deformation of rock for a long time, and the circumferential expansion of the granite creep process is more obvious than the axial expansion. Secondly, a high seepage pressure will reduce the rock bearing capacity. Under 0, 2 and 4 MPa seepage pressures, the long-term strength of the samples are 193.7 MPa, 177.5 MPa and 162.1 MPa, respectively. Thirdly, the rock damage factor increases with increasing seepage pressure, time and deviatoric stress. Finally, the rationality of a fractional-order model that considers the effect of unloading and seepage is verified by the test data. These research results may provide some reference for the stability analysis of surrounding rock during excavation in environments under high-stress and high-seepage-pressure. Full article

Dolomitic limestone is the main surrounding rock material in Yangzong tunnel engineering; the instantaneous mechanical properties and creep behaviors of limestone are significant for stability evaluation during the stages of tunnel excavation and long-term maintenance. Herein, four conventional triaxial compression tests were carried out to explore its instantaneous mechanical behavior and failure characteristics; subsequently, the creep behaviors of limestone subjected to multi-stage incremental axial loading at the confinements of 9 MPa and 15 MPa were studied by employing an advanced rock mechanics testing system (i.e., MTS815.04). The results reveal the following. (1) comparing the curves of axial strain–, radial strain–, and volumetric strain–stress under different confining pressures shows that these curves present a similar trend, whereas the stress drops during the post-peak stage decelerate with the increase in confining pressure, suggesting that the rock transits from brittleness to ductility. The confining pressure also has a certain role in controlling the cracking deformation during the pre-peak stage. Besides, the proportions of compaction- and dilatancy-dominated phases in the volumetric strain–stress curves differ obviously. Moreover, the failure mode of the dolomitic limestone is a shear-dominated fracture but is also affected by the confining pressure. (2) When the loading stress reaches a creep threshold stress, the primary and steady-state creep stages occur successively, and a higher deviatoric stress corresponds to a greater creep strain. When the deviatoric stress surpasses an accelerated creep threshold stress, a tertiary creep appears and then is followed by creep failure. Furthermore, the two threshold stresses at 15 MPa confinement are greater than that at 9 MPa confinement, suggesting that the confining pressure has an obvious impact on the threshold values and a higher confining pressure corresponds to a greater threshold value. Additionally, the specimen’s creep failure mode is one of “abrupt” shear-dominated fracturing and is similar to that under a conventional triaxial compression test at high confining pressure. (3) A multi-element nonlinear creep damage model is developed by bonding a proposed visco-plastic model in series with the Hookean substance and Schiffman body, and can accurately describe the full-stage creep behaviors. Full article

During the mining activity under the super-thick nappe formed by thrust fault, the law of mine pressure behavior is complex, and it is difficult to control the deformation and failure of surrounding rock. Combined with the actual engineering conditions, the influence of different roof lithology conditions, the thickness of nappe, the mining height, the size of the barrier coal pillar, and the creep time on mine pressure behavior was studied by UDEC numerical simulation software. The results showed that with the advancement of the coal face, due to the influence of the mining of the coal face and the slip dislocation of the super-thick nappe along the thrust faults, the roof-to-floor convergence, the two-sided convergence, and the maximum concentrated stress in the roadway-concentrated areas are significantly increased. For the above five influencing factors, the greater the thickness of the nappe and the mining height, the longer the creep time, and the stronger the ground pressure behavior. The larger the size of the barrier coal pillar, the stronger the roof lithology, and the gentler the ground pressure behavior. The research results can provide some reference for monitoring the law of ground pressure behavior in roadway-concentrated areas under super-thick nappe. Full article

The long-term stability of coal mine roadway engineering is critical to the safe mining of coal resources and the protection of the surface environment. In this paper, the creep test of coal samples in coal roadway was carried out by multi-stage constant load method, and the test results showed that when the stress level was low, the creep curve had a attenuated stage and a steady-state stage, and the steady-state creep rate tended to increase with the increase in the stress level; When the stress level was higher than the yield stress, the creep rate curve appeared to have an acceleration stage after the steady-state stage. The instability failure mode of the coal sample was mainly shear failure with local tension failure. For this, a New Fractional-order Nonlinear Viscoelastic-plastic Rheological Model (NFNVRM) was established by introducing Abel elements and Nonlinear elements, and the constitutive equation of the model was deduced. The new model can fully reflect the stable decay stage and accelerated rheological stages of coal samples, and the parameter identification curve was consistent with the experimental results, which verifies the correctness and reasonableness of the NFNVRM. Meanwhile, based on the FLAC3D secondary development interface, the constitutive equations of the NFNVRM were written into the software to obtain new Dynamic Link Library (DLL) files. The simulation results were consistent with the experimental results when the DLL file was called. Finally, the NFNVRM.dll was applied to predict the surrounding rock deformation of an S mine. The study’s findings offer suggestions for environmental protection. Full article

The proportion of the coal and rock masses in different areas of surrounding rocks is quite different when a large-section coal roadway is excavated in gently inclined soft coal seams. Different creep failure occurs in coal and rock masses under high stress, which results in uneven deformations of roadways and difficulties in maintenance. This work studied the belt grooves of the 2103 working face in the lower coal group of the Wulihou Coal Mine. Theoretical analysis and measured geomechanical evaluation were used to analyze the failure causes of the surrounding rocks of the roadway. The failure law of large-section roadways in the gently inclined soft coal seams was studied using finite-difference numerical simulation software. Combined with the results of mathematical analysis, surrounding rocks were divided into regions. Surrounding-rock control schemes for different areas, such as grouting reinforcement, strengthening support, and pressure-relief grooving, were proposed separately and verified by numerical simulations. Strengthening the supports could reduce the deformations of area I, and pressure-relief grooving could control the deformations of area IV. The roadway and support system formed an anchored composite supporting body after grouting reinforcement, which greatly improved the bearing capacity and controlled the deformations of surrounding rocks. The fine on-site application effect and the improved non-symmetrical deformation verified the theoretical analysis, numerical simulations, and control technologies. The results provide a scientific basis and useful reference for similar projects. Full article

Since underground structures such as tunnels are inevitably surrounded by rocks, their long-term safety and stability are primarily governed by the comportment of these materials. Being able to express the time-dependent behavior of rocks, creep is one of the most interesting mechanical properties considered in the study of tunnels. Based on relevant research efforts, this article aims to provide a comprehensive review of pertinent information on rock creep and its potential influencing factors. It also presents the latest progress in constitutive models of rock creep and discusses their applicability to the long-term stability of deep underground structures. The results show that rock creep is significantly influenced by various potential factors both external and internal. These are mainly hydraulic pressure, stress level, water content, temperature, damage, and time-to-failure. For instance, the creep lifetime of andesite is drastically reduced by the presence of water. It is about 180 times shorter in wet conditions than in dry conditions, under the same stress conditions. By the combined influence of high stresses, high pressures, and high temperatures, creep rupture occurs in a semi-brittle manner for most types of hard rocks. The characteristics and installation period of the lining structures also have a strong influence on the evolution of creep in the rocks surrounding the underground structures. It is suggested that despite the colossal research efforts already made in this area, more accurate creep constitutive models are still needed for more adequate applications to the long-term stability of deep rock tunnels. Accordingly, key perspectives for future investigations are highlighted. This work can serve as a good reference in the establishment of new constitutive models of rock creep aimed at improving their accuracy, and facilitate appropriate actions to predict the long-term stability of deep tunnels in realistic situations. Full article

In this research, the combination of theoretical approach and numerical simulation was employed to comprehensively understand the initiation mechanism of time-delayed rockburst and analyze the time-delayed failure laws for surrounding rock after excavation unloading without prompt support. The investigations are principally at the angle of time and space, which refers to the creep property and damaged scope for surrounding rock. For the theoretical method, the analytical elastic and elastoplastic models for deep tunnel cross section and the creep model for brittle rock material from a microscopic view were combined. It was found that the time-delayed failure for surrounding rock resulted from the damage accumulation with crack development during the creep process. The surrounding rock with the elastic state was more stable than that in the plastic zone and the creep duration increased with growing distance from the center of tunnel section. Based on the theoretical creep model, the numerical simulation ulteriorly analyzed the brittle creep duration on the key positions. The surrounding rock tended to fail more in the strong excavation damage zone (SEDZ) than that in the weakly damaged zone (WEDZ), and brittle creep failure mainly occurred on the excavation border (EB) in a short space of time. In addition, the increase in the radius for tunnel cross section and the higher in situ stress distribution around the opening led to the acceleration of the creep process for surrounding rock, and the irregular cross-section shape of the tunnel caused the local damaged range extension and decreased the duration for time-delayed failure. Full article
