This paper proposes a mechanically reconfigurable multi-polarization antenna based on a 3D-printed anisotropic dielectric polarizer, offering wide bandwidth, high gain, and extremely low cost. The working mechanism of the dielectric polarizer is analyzed, demonstrating its ability to efficiently convert linear polarization (LP) to circular polarization (CP) over a wide frequency range. Furthermore, the polarizer exhibits subwavelength characteristics. For a given duty cycle, its phase response depends only on the height and is independent of the aperture size. This property enables miniaturized and customized designs of the polarizer’s aperture size. Subsequently, the polarizer is placed above a Ku band waveguide and standard horn antennas. The results show that by rotating the dielectric polarizer and adjusting the positions of the antennas, right-handed CP (RHCP), left-handed CP (LHCP), and dual LP radiation switching can be achieved in the 12.4–18.0 GHz band, verifying the quad-polarization reconfigurability. Additionally, the polarizer significantly enhances the gain of the waveguide antenna by approximately 9.5 dB. Furthermore, due to the low-cost 3D printing material, the manufacturing cost of the polarizer is exceptionally low, making it suitable for applications such as anechoic chamber measurements and wireless communications. Finally, the measurement results further validate the accuracy of the simulations. Full article

We propose a Multispectral Earth Polarization Imager (MEPI), which is located at the Earth–Moon system’s Lagrange point L1. The imager can be used to measure the sunlight reflected by the Earth and the Moon. The measured sunlight has specific polarization information and spectral information, which can provide strong support for a comprehensive understanding of the Earth system and the construction of a perfect Earth–Moon system model. The MEPI provides multispectral images with wavelengths of 400–885 nm, and uses four sub-aperture systems to share a main system. The imager can capture the two-dimensional shape and polarization spectral information of the entire Earth at a spatial resolution of 10 km, and all spectral images can be simultaneously acquired on a single detector. The optical system of the instrument was designed and simulated. The simulation and analysis results showed that the camera can obtain high-quality images of the Earth disc with a 2.5° field of view (FOV). The novel MEPI provides a new way to generate climate-related knowledge from the perspective of global Earth observation. The imager can also be used for lunar observation to obtain spectral polarization information on the lunar surface. In addition, it also shows great potential in other applications of space remote sensing spectral imaging. Full article

Compact high-power sub-nanosecond laser pulse sources with a wavelength of 940 nm are developed and studied. A design for laser pulse sources based on a vertical stack is proposed, which includes a semiconductor laser chip and a current switch chip. To create a compact high-speed current switch, a three-electrode heterothyristor is developed. It is found that the use of heterothyristor-based current switches allows the creation of a low-loss pump current circuit, generating short current pulses and operating the semiconductor laser in gain-switching mode. For the semiconductor laser chip, an asymmetric semiconductor heterostructure with a quantum-well active region is designed. The design of the emitting aperture of the laser chip is optimized to improve the operating characteristics of the laser beam when generating sub-ns optical pulses. It is shown that the transition to a monolithic emitting aperture design reduces the laser pulse turn-on spatial inhomogeneity, which is 90 ps over the entire range of optical powers studied. It is also demonstrated that by increasing the emitting aperture width to 400 μm, laser pulses with a peak power of 39.5 W and a pulse width at full width at half maximum (FWHM) of 120 ps can be generated. Full article

The unique P-band synthetic aperture radar (SAR) instrument, BIOMASS, is scheduled for launch in 2024. This satellite will enhance the estimation of subcanopy topography, owing to its strong penetration and fully polarimetric observation capability. In order to conduct global-scale mapping of the subcanopy topography, it is crucial to calibrate systematic errors of different strips through interferometric SAR (InSAR) DEM (digital elevation model) block adjustment. Furthermore, the BIOMASS mission will operate in repeat-pass interferometric mode, facing the atmospheric delay errors introduced by changes in atmospheric conditions. However, the existing block adjustment methods aim to calibrate systematic errors in bistatic mode, which can avoid possible errors from atmospheric effects through interferometry. Therefore, there is still a lack of systematic error calibration methods under the interference of atmospheric effects. To address this issue, we propose a block adjustment model considering atmospheric effects. Our model begins by employing the sub-aperture decomposition technique to form forward-looking and backward-looking interferograms, then multi-resolution weighted correlation analysis based on sub-aperture interferograms (SA-MRWCA) is utilized to detect atmospheric delay errors. Subsequently, the block adjustment model considering atmospheric effects can be established based on the SA-MRWCA. Finally, we use robust Helmert variance component estimation (RHVCE) to build the posterior stochastic model to improve parameter estimation accuracy. Due to the lack of spaceborne P-band data, this paper utilized L-band Advanced Land Observing Satellite (ALOS)-1 PALSAR data, which is also long-wavelength, to emulate systematic error calibration of the BIOMASS mission. We chose climatically diverse inland regions of Asia and the coastal regions of South America to assess the model’s effectiveness. The results show that the proposed block adjustment model considering atmospheric effects improved accuracy by 72.2% in the inland test site, with root mean square error (RMSE) decreasing from 10.85 m to 3.02 m. Moreover, the accuracy in the coastal test site improved by 80.2%, with RMSE decreasing from 16.19 m to 3.22 m. Full article

Recently, the community has seen a rise in interest and development regarding holographic antennas. The planar hologram is made of subwavelength metal patches printed on a grounded dielectric board, constituting flat metasurfaces. When a known reference wave is launched, the hologram produces a pencil beam towards a prescribed direction. Most earlier works on such antennas have considered only a single beam. For the few later ones that studied multiple beams, they were achieved either by having each beam taken care of by a distinct frequency or by partitioning the hologram, thereby depriving each beam of the directivity it could have had it not shared the holographic aperture with other beams. There have been recent studies related to the use of tensor surface impedance concepts for the synthesis of holograms which have attained control over the polarizations and intensities of the beams. However, this approach is complicated, tedious, and time-consuming. In this paper, we present a method for designing a planar holographic leaky-wave multi-beam metasurface antenna, of which each simultaneous beam radiating at the same frequency towards any designated direction has a tailorable amplitude, phase, and polarization, all without hologram partitioning. Most importantly, this antenna is exempted from the need for the cumbersome technique of tensor impedance. Such features of beam configurability are useful in selective multiple-target applications that require differential gain and polarization control among the various beams. Only a single source is needed, which is another benefit. In addition, effective methods to mitigate sidelobes are also proposed here. Designs by simulations according to the method are herein validated with measurements performed on fabricated prototypes. Full article

Circular synthetic aperture radar (CSAR) possesses the capability of multi-angle observation, breaking through the geometric observation constraints of traditional strip SAR and holding the potential for three-dimensional imaging. Its sub-wavelength level of planar resolution, resulting from a long synthetic aperture, makes CSAR highly valuable in the field of high-precision mapping. However, the motion geometry of CSAR is more intricate compared to traditional strip SAR, demanding high precision from navigation systems. The accumulation of errors over the long synthetic aperture time cannot be overlooked. CSAR exhibits significant coupling between the range and azimuth directions, making traditional motion compensation methods based on linear SAR unsuitable for direct application in CSAR. The dynamic nature of flight, with its continuous changes in attitude, introduces a significant deformation error between the non-rigidly connected Inertial Measurement Unit (IMU) and the Global Positioning System (GPS). This deformation error makes it difficult to accurately obtain radar position information, resulting in imaging defocus. The research in this article uncovers a correlation between the deformation error and radial acceleration. Leveraging this insight, we propose utilizing radial acceleration to estimate residual motion errors. This paper delves into the analysis of Position and Orientation System (POS) errors, presenting a novel high-resolution CSAR motion compensation method based on airborne platform acceleration information. Once the system deformation parameters are calibrated using point targets, the deformation error can be directly calculated and compensated based on the acceleration information, ultimately resulting in the generation of a high-resolution image. In this paper, the effectiveness of the method is verified with airborne flight test data. This method can compensate for the deformation error and effectively improve the peak sidelobe ratio and integral sidelobe ratio of the target, thus improving image quality. The introduction of acceleration information provides new means and methods for high-resolution CSAR imaging. Full article

The generation of moiré lattices by superimposing two identical sublattices at a specific twist angle has garnered significant attention owing to its potential applications, ranging from two-dimensional materials to manipulating light propagation. While macroscale moiré lattices have been widely studied, further developments in manipulating moiré lattices at the subwavelength scale would be crucial for miniaturizing and integrating platforms. Here, we propose a plasmonic metasurface design consisting of rotated nanoslits arranged within N + N′ round apertures for generating focused moiré lattices. By introducing a spin-dependent geometric phase through the rotated nanoslits, an overall lens and spiral phase can be achieved, allowing each individual set of round apertures to generate a periodic lattice in the focal plane. Superimposing two sets of N and N′ apertures at specific twist angles and varying phase differences allows for the superposition of two sublattices with different periods, leading to the formation of diverse moiré patterns. Our simulations and theoretical results demonstrate the feasibility of our proposed metasurface design. Due to their compactness and tunability, the utilization of metasurfaces in creating nanoscale photonic moiré lattices is anticipated to find extensive applications in integrated and on-chip optical systems. Full article

The efficiency of thin film photoelectric devices can be improved by redirecting incident electromagnetic radiation along their surface layers. Redirection can be achieved using antireflection coatings made of subwavelength dielectric particle arrays. In this study, we fabricate such coatings, consisting of Ge particles on quartz glass substrates via solid-state dewetting, transforming thin Ge films into compact particles. Using optically transparent substrates, we measure reflection and transmission spectra and determine absorption spectra, showing that substrates coated with Ge particles absorb much more strongly than substrates coated with continuous Ge films. The spectra obtained using objective lenses with different aperture angles indicate that scattered radiation is predominantly directed at glancing angles to the substrate surface. The lateral propagation of scattered radiation is the result of destructive interference, which suppresses both reflected and transmitted radiation. Full article

In this work, three types of machine learning algorithms are applied for synthetic aperture radar (SAR) wind retrieval in tropical cyclones (TCs), and the optimal method is confirmed. In total, 30 Sentinel-1 (S-1) images in dual-polarization (vertical–vertical [VV] and vertical–horizontal [VH] were collected during the period from 2016 to 2021, which were acquired in interferometric-wide and extra-wide modes with pixels of 10 m and 40 m, respectively. More than 100,000 sub-scenes with a spatial coverage of 3 km are extracted from these images. The dependences of variables estimated from sub-scenes, i.e., VV-polarized and VH-polarized normalized radar cross-section (NRCS), as well as the azimuthal wave cutoff wavelength, on wind speeds from the stepped-frequency microwave radiometer (SFMR) and the soil moisture active passive (SMAP) radiometer are studied, showing the linear relations between wind speed and these three parameters; however, the saturation of VV-polarized NRCS and the azimuthal wave cutoff wavelength is observed. This is the foundation of selecting input variables in machine learning algorithms. Two-thirds of the collocated dataset (20 images) are used for training the process using three machine learning algorithms, i.e., eXtreme Gradient Boosting (XGBoost), Multi-layer Perceptron, and K-Nearest Neighbor, and the coefficients are fitted after training completion through 20 images collocated with SFMR and SMAP data. Another 10 images are taken for validation up to 70 m/s, yielding a 2.53 m/s root mean square error (RMSE) with a 0.96 correlation and 0.12 scatter index (SI) using XGBoost. The result is better than the >5 m/s error achieved using the existing cross-polarized geophysical model function and the other two machine learning algorithms; moreover, the comparison between wind retrievals using XGBoost and Level-2 CyclObs products shows about 4 m/s RMSE and 0.18 SI. This suggests that the machine learning algorithm XGBoost is an effective method for inverting the TC wind field utilizing SAR measurements in dual-polarization. Full article

To improve their spatial resolution and detection capabilities, future ground-based optical telescopes will have a size of 30 m, and the aperture of space telescopes will be increased to 10 m. Such large optical systems necessitate the development of large integrated testing equipment. In this study, spectrum and system alignment measurements and wavefront quality checking were performed using the sub-aperture detection method and a fiber-connected Photonics Scanning Pentaprism (PSP). First, the system was aligned using an optical truss, ensuring that the optical axis was properly positioned. Second, using a sub-aperture light beam though the entrance pupil, light spots were formed on the focal plane and transmitted to the spectrometer via fibers to obtain the corresponding spectral components. Then, by taking measurements at different system positions, a full-aperture spectrum response could be reached. Lastly, by photon-integrated interference on the focal plane, intensity interference fringes could be projected at the entrance pupil of the system. And the wavefront quality of the system could be verified by observing the fringe deformation. The measurement accuracy of the optical axis of the system is better than 2 mrad. The spectral measurement accuracy was better than 5%, and the wavefront measurement accuracy surpassed 0.1 wavelengths (1 wavelength = 633 nm). This study effectively enhanced the detection and in situ calibration capabilities of large telescope systems, ensuring that the performance requirements can be met in the design of future telescopes. Full article

Similar to optical vortex beams, terahertz (THz) vortex beams (TVBs) also carry orbital angular momentum (OAM). However, little research has been reported on the generation of TVBs. In this paper, based on the detour phase technique, we design a series of spintronic terahertz emitters with a helical Fresnel zone plate (STE-HFZP) to directly generate focused TVBs with topological charges (TCs) of l = ±1, ±2 and ±3, respectively. The STE-HFZP is a hybrid THz device composed of a terahertz emitter and a THz lens, and it has a high numerical aperture (NA), achieving subwavelength focal spots. Its focus properties are surveyed systemically through accurate simulations. This STE-HFZP can also generate focused TVBs with higher order TCs. More importantly, the components of the focused electric field with OAM make up the majority of the intensity and have potential applications in the field of THz communications, THz imaging and atom trapping. Full article

In this work, we demonstrate a novel structure that can generate extraordinary optical transmission with a silicon hemisphere placed on a conventional bull’s eye structure. There is a single subwavelength aperture surrounded by concentric periodic grooves on a substrate. The extraordinary optical transmission in this work is realized by the coupling of the surface plasmon polaritons in the periodic grooves and the localized electromagnetic field generated by the Mie resonance in the silicon hemisphere. The maximum normalized-to-area transmission peak can reach up to 662 with a decreasing device area and size. The electromagnetic field distribution at different geometry parameters is analyzed to clarify the mechanisms of the work in this paper. Additionally, the use of dielectric material in the aperture can avoid ohmic losses of metal material compared with the conventional one, which may suggest that a wider range of bull’s-eye-structure applications is possible. Full article

Negative group delay may be observed in dispersive media with anomalous dispersion in a certain frequency range. The fact that an outgoing wave packet precedes an incoming one does not violate the causality principle but is only a consequence of a waveform reshaping. This effect is observed in media such as photonic crystals, hyperbolic and epsilon-near-zero metamaterials, undersized waveguides, subwavelength apertures, side-by-side prisms, and resonant circuits at various frequencies. The current work is devoted to the design of a simple negative-group-delay medium with tunable properties in the THz frequency range. This medium consists of a bismuth-based frequency-selective surface on a dielectric substrate and may be tuned both statically and dynamically. While a geometry variation defines a main form of an effective permittivity dispersion and group delay/group velocity spectra, an external voltage allows one to adjust them with high precision. For the configuration proposed in this work, all frequency regions with noticeable change in group delay/group velocity lie within atmospheric transparency windows, which are to be used in 6G communications. This medium may be applied to THz photonics for a tunable phase-shift compensation, dispersion management in systems of THz signal modulation, and for encoding in next-generation wireless communication systems. Full article

Tightly focused vector fields, which can be generated by focusing a light beam through a high-numerical-aperture objective, play an important role in nano-optics research. How to fully characterize this kind of field in the subwavelength scale is a challenging but important task. The Mie scattering nanointerferometry technique has been proposed to reconstruct the tightly focused vector field accurately. In this work, we theoretically demonstrate that the technique can be realized by collecting the transmitted light with two orthogonal polarization states simultaneously. Therefore, when nanoparticles are employed to scan the fields to be measured, more information of the scattering field can be acquired in the far field. This is helpful for solving the linear inverse scattering problem by reducing the number of scanning points, thus making the measurement more efficient. Full article

In this study, we investigated the quality of Interferometric Synthetic Aperture Radar (InSAR) data to measure surface displacements in upstate New York, an area with dense vegetation, snowy winters, and strong seasonal signals. We used data from the German Space Agency’s TerraSAR-X and TanDEM-X satellites (X-band, 3.1 cm radar wavelength) as well as the European Space Agency’s Sentinel-1 satellite (C-band, 5.6 cm radar wavelength); both datasets covered a ~3-year time period from 2018 to 2021. Using persistent scatterer interferometry (PSI), we were able to observe several deforming features in the region with sub-centimeter/year deformation rates. We also examined a version of the X-band data that we spatially averaged to the same pixel size as the Sentinel-1 imagery in order to separate out the effects of wavelength and pixel size on PSI accuracy and coverage. Overall, the largest number of stable PS points was found in the full-resolution X-band data, which was followed by the C-band data and then by the downsampled X-band data. Our analysis also included a subset of snow-free imagery so that we could assess the effect that snow-covered images had on the distribution and accuracy of PS points and the resulting time series. This analysis revealed that PS populations increased by 50–60% for the snow-free data when compared with analyses using the full datasets. The average deformation rates inferred from the time series generated using only snow-free images were nearly identical to those estimated from the full time series. We assessed the accuracy of the inferred rates through comparisons between the results of different datasets and with limited ground survey data. We found that all of the inferred deformation rates from each of the datasets agreed with in situ measurements in an area of known ground subsidence above an underground salt mine in Lansing, NY. The S1 datasets, however, had higher levels of noise. Full article
